Page 1
THERMALITE®
THERMOMETER
Operating Instructions
Page 2
ON/OFF - Press ON/OFF button once to switch the thermometer on. To switch the
thermometer off press ON/OFF button and hold for three seconds.
AUTO OFF - Press the ON/OFF button six times to disable the auto power-off
function. Once disabled the ‘AUTO OFF’ icon turns off. Press the button six times
again to enable the auto power-off function. Once enabled ‘AUTO OFF’ will display.
The instrument will turn off automatically after 10 minutes.
°C/°F - While powering the unit on, hold the ON/OFF button for ve seconds to
change between °C and °F. Once changed, the unit will remain in the selected value.
CALCHECK - Switch unit on and after one second all elements on the LCD display
will light up. The screen will then display ‘CAL’ after two seconds, followed by ‘-0-’ two
seconds later, before presenting the temperature.
BATTERY REPLACEMENT - The battery will need to be replaced when the
instrument displays ‘ ’. Replace the battery with a 3 volt lithium coin cell (CR2032).
making sure the polarities are correct, close and tighten up the battery cover.
Please note: Ensure the battery cover is fully tightened after battery replacement as
this may affect the water resistant function.
BATTERY WARNING: K EEP OUT OF REACH OF CHILDREN.
If you think batteries might have been swallowed or placed
inside any part of the body, seek immediate medical attention.
ERROR MESSAGE - If the thermometer has developed a fault the instrument will
show ‘Err’. If the display shows ‘LLL.L’ the reading is out of low range (-40 °C). If the
display shows ‘HHH.H’ the reading is out of high range (300 °C).
GUARANTEE - This instrument carries a one-year guarantee against defects in either
components or workmanship. During this period, products that prove to be defective
will, at the discretion of ETI, be either repaired or replaced without charge. The
product guarantee does not cover damage caused by fair wear and tear, abnormal
storage conditions, incorrect use, accidental misuse, abuse, neglect, misapplication
or modication. Full details of liability are available within ETI’s Terms & Conditions of
Sale at etiltd.com. In line with our policy of continuous development, we reserve the
right to amend our product specication without prior notice.
WARNING - Do not expose the thermometer to temperatures over 50 °C or use in
ovens, this will result in incorrect readings or damage to the thermometer.
Clean the probe immediately with cleaning wipes after each measurement to avoid
cross contamination.
Supplied by
Electronic Temperature Instruments Ltd
Worthing · West Sussex · BN14 8HQ
01903 202151 · [email protected] · etiltd.com
810-305 WEB/26.03.25
