EtherWan Managed Switch – V1.94.2.1 Users Manual
User’s Guide
FastFind Links
Unpacking and Installation
Computer Setup
Setting the initial IP address
EtherWAN Managed Switch – V1.94.2.1
EtherWAN Managed Switch Users Guide
1
All Rights Reserved
Dissemination or reproduction of this document, or its contents, is not authorized except
where expressly permitted. Violators are liable for damages. All rights reserved, for the
purposes of patent application or trademark registration.
Disclaimer of Liability
The information contained in this document is subject to change without notice. EtherWAN is
not liable for any errors or omissions contained herein or for resulting damage in connection
with the information provided in this manual.
Registered Trademarks
The following words and phrases are registered Trademarks of EtherWAN Systems Inc.
EtherOS™
Ethernet to the World™
All other Trademarks are property of their respective owners.
Warranty
For details on the EtherWAN warranty replacement policy, please visit our web site at:
https://kb.etherwan.com/index.php?CategoryID=13
Products Supported by this Manual:
V1.94.2 EtherWAN Managed Switch
Contact EtherWAN Systems
Corporate Headquarters
EtherWAN Systems Inc.
4570 E. Eisenhower Circle
Anaheim, CA 92807
Tel: (714) 779 3800
Fax: (714) 779 3806
Email: support@etherwan.com
EtherWAN Managed Switch Users Guide
ii
Preface
TABLE OF CONTENTS
Table of Contents ................................................................................................... iii
Table of Figures ..................................................................................................... xii
Preface ................................................................................................................... xvi
Changes in this Revision ........................................................................................ xvi
Document Conventions ..........................................................................................xvii
Safety and Warnings ..............................................................................................xvii
Typographic Conventions .......................................................................................xvii
Unpacking and Installation ................................................................................... 18
Package Contents ................................................................................................... 18
Unpacking ............................................................................................................... 18
Required Equipment and Software .......................................................................... 19
Computer Setup ..................................................................................................... 20
Management Methods and Protocols ...................................................................... 20
Default IP ................................................................................................................. 21
Login Process and Default Credentials .................................................................... 21
Setting the initial IP address ................................................................................. 22
Simple IP Addressing .............................................................................................. 22
CLI Command Usage ............................................................................................. 23
Navigating the CLI Hierarchy ................................................................................... 23
CLI Keyboard Shortcuts ........................................................................................... 23
CLI Command modes .............................................................................................. 24
General Configuration Mode .............................................................................. 24
MSTP Configuration Mode ................................................................................. 24
Interface Configuration Mode ............................................................................. 25
VLAN Database Configuration Mode ................................................................. 25
Saving a Configuration from the CLI .................................................................. 25
System Menu ......................................................................................................... 26
System Information .................................................................................................. 26
System Name/Password.......................................................................................... 28
System Name/Password using the CLI .................................................................... 29
IP Address ............................................................................................................... 30
EtherWAN Managed Switch Users Guide
iii
Preface
Static IP ............................................................................................................. 30
DHCP Client ...................................................................................................... 30
Default Gateway ................................................................................................ 30
DNS Server ........................................................................................................ 30
IP Address - Configuration using the CLI ................................................................. 32
IP Address ......................................................................................................... 32
Default Gateway ................................................................................................ 33
Domain Name Server (DNS) .............................................................................. 34
Enable/Disable DHCP Client on a VLAN ............................................................ 35
Enable/Disable Static IP on a VLAN................................................................... 35
Management Interface ................................................................ ............................. 37
HTTPS ............................................................................................................... 37
Telnet. ................................................................................................................ 37
SSH (Secure Shell) ............................................................................................ 38
Management Interface Configuration using the CLI ................................................. 39
Enabling/Disabling Telnet .................................................................................. 39
Enabling/Disabling SSH ..................................................................................... 40
Enabling/Disabling HTTP and/or HTTPS ........................................................... 41
Save Configuration Page ......................................................................................... 43
Save Configuration ............................................................................................ 43
Load Configuration ............................................................................................. 43
Backup Configuration ......................................................................................... 43
Restore Default .................................................................................................. 44
Auto Save .......................................................................................................... 44
Save Configuration Page using the CLI ................................................................... 45
Saving a Configuration ....................................................................................... 45
Restore Default Settings .................................................................................... 45
Load Configuration from a TFTP Server ............................................................ 46
Save Configuration to a TFTP Server ................................................................ 46
Auto Save Configuration .................................................................................... 47
Firmware Upgrade ................................................................................................... 48
Firmware Update using the CLI ............................................................................... 49
Reboot ................................................................................................ ..................... 50
Reboot using the CLI ............................................................................................... 50
Logout ..................................................................................................................... 50
Logout from the CLI ................................................................................................. 50
User Account Page .................................................................................................. 51
Changing the User Mode ................................................................................... 51
Creating a New User .......................................................................................... 52
Changing an Existing User Account ................................................................... 53
User Privilege Configuration .................................................................................... 54
User Account Settings using the CLI........................................................................ 56
Multi-User Mode................................................................................................. 56
EtherWAN Managed Switch Users Guide
iv
Preface
Single User Mode .............................................................................................. 56
Creating a New User .......................................................................................... 57
Permissions ....................................................................................................... 58
Diagnostics ............................................................................................................ 60
Utilization ................................................................................................................. 60
System Log.............................................................................................................. 61
System log using CLI command .............................................................................. 61
Remote Logging ...................................................................................................... 62
Remote Logging using CLI commands .................................................................... 64
ARP Table ............................................................................................................... 65
ARP Table using CLI Commands ............................................................................ 66
Route Table ............................................................................................................. 67
Route Table Using CLI Commands ......................................................................... 67
Alarm Setting ........................................................................................................... 68
Port ......................................................................................................................... 69
Configuration ........................................................................................................... 69
Port Status ............................................................................................................... 71
Rate Control ............................................................................................................ 72
RMON Statistics ...................................................................................................... 73
Per Port VLAN Activities .......................................................................................... 74
Port Security ............................................................................................................ 75
Port Configuration Examples Using CLI Commands ................................ ................ 76
Setting the Port Description ............................................................................... 76
Enable or Disable a Port .................................................................................... 76
Setting the Port Speed ....................................................................................... 77
Setting Port Duplex ............................................................................................ 77
Enable or Disable Port FlowControl ................................................................... 78
Display Port Status ............................................................................................ 78
Setting a Ports Rate Control .............................................................................. 78
Display a Ports RMON Statistics ........................................................................ 79
Display a Ports VLAN Activities .......................................................................... 79
Setting MAC Port Security ................................................................................. 79
Switching ................................................................................................................ 81
Bridging ................................................................................................................... 81
Aging Time......................................................................................................... 82
Threshold Level ................................................................................................. 82
Storm Control Type ............................................................................................ 82
Port Isolation ...................................................................................................... 83
Block Multicast ................................................................................................... 83
Loopback Detect ...................................................................................................... 85
EtherWAN Managed Switch Users Guide
v
Preface
Loopback Detection (Global) .............................................................................. 85
Loopback Detect Action ..................................................................................... 85
Loopback Detect Recovery Time ....................................................................... 85
Polling Interval ................................................................................................... 86
Loopback Detection (Per Port) ........................................................................... 87
Storm Detect ............................................................................................................ 88
Enable/Disable Storm Detection ........................................................................ 88
Static MAC Entry ..................................................................................................... 90
Adding a Static MAC Address to a Port .............................................................. 90
Removing a Static MAC Address from a Port ..................................................... 91
Adding a MAC to the Static-MAC-Entry Discard Table ....................................... 91
Removing a MAC address from the Static-MAC-Entry Discard Table ................ 92
Port Mirroring ........................................................................................................... 93
Link State Tracking .................................................................................................. 95
Enable/Disable Link State Tracking ................................................................... 95
Port Settings ...................................................................................................... 95
PoE - System and Port Settings ............................................................................... 97
PoE System Setting ........................................................................................... 97
PoE Port Setting ................................................................................................ 98
PoE Scheduling ..................................................................................................... 100
Switch Configuration Examples Using CLI Commands .......................................... 102
Setting the Aging Time Value ........................................................................... 102
Enabling Port Isolation ..................................................................................... 102
Enabling Block Multicast .................................................................................. 103
Setting Storm Control ....................................................................................... 103
Enabling Loopback Detect (Global) .................................................................. 104
Setting the Loopback Detect Action ................................................................. 104
Setting the Loopback Detect Recovery Time ................................................... 104
Setting the Loopback Detect Polling Interval .................................................... 105
Enabling Loopback Detect (Port) ..................................................................... 105
Configuring Storm-Detect ................................................................................. 106
Adding a MAC Address for Static-MAC-Entry Forwarding ................................ 110
Adding a MAC Address for Static-MAC-Entry Discarding ................................. 110
Configuring Port Mirroring ................................................................................ 111
Enabling a Link State Tracking Group .............................................................. 111
Assigning a Port to a Link State Tracking Group .............................................. 112
Setting PoE Power Budget ............................................................................... 112
PoE Port Settings............................................................................................. 113
PoE Scheduling ............................................................................................... 116
Trunking ............................................................................................................... 119
Overview ............................................................................................................... 119
Static Channel Trunking ................................................................................... 119
EtherWAN Managed Switch Users Guide
vi
Preface
Link Aggregation Control Protocol .................................................................... 119
Port Trunking ......................................................................................................... 120
LACP Trunking ...................................................................................................... 123
Trunking Configuration Examples Using CLI Commands ....................................... 127
Adding an Interface to a Static Trunk ............................................................... 127
Adding an Interface to a LACP Trunk ............................................................... 127
Setting the LACP Port Priority .......................................................................... 128
Setting the LACP Timeout ................................................................................ 128
STP/Ring Page – Overview ................................................................................. 129
Choosing the Spanning Tree Protocols .................................................................. 129
Spanning Tree Protocol (STP) ......................................................................... 129
Rapid Spanning Tree protocol (RSTP) ............................................................. 129
Multiple Spanning Tree Protocol (MSTP) ................................ ......................... 129
STP/Ring Page - Configuring RSTP ................................................................... 130
Global Configuration Page ..................................................................................... 130
Enabling the RSTP Protocol ............................................................................ 130
Additional Global Configuration page settings .................................................. 130
The Root Bridge & Backup Root Bridge ........................................................... 132
Setting the MAX Age, Forward Delay and Hello Timer ..................................... 134
RSTP Port Setting Page ........................................................................................ 136
Spanning Tree Port Roles ................................................................................ 136
Path Cost & Port Priority .................................................................................. 137
Point to Point Link ............................................................................................ 139
Edge Port ......................................................................................................... 139
RSTP Configuration Examples Using CLI Commands ........................................... 140
Enabling the Spanning Tree Protocol ............................................................... 140
Bridge Priority, Max Age, Forward Delay, and Hello Time ................................ 140
Modifying the Port Priority and Path Cost ......................................................... 141
Manually Setting a Port to be a Shared or Point to Point Link .......................... 141
Enabling/Disabling a port to be an Edge Port ................................................... 142
STP/Ring Page - Configuring MSTP ................................................................ ... 143
Global Configuration Page ..................................................................................... 143
Enabling the MSTP Protocol ............................................................................ 143
The CIST Root Bridge & Backup CIST Root Bridge ......................................... 145
Setting Bridge Priority ...................................................................................... 145
Configuring the CST Network Diameter ........................................................... 147
MSTP Properties Page .......................................................................................... 148
Configuring an MSTP Region........................................................................... 148
Configuring the IST Network Diameter ............................................................. 150
MSTP Instance Setting Page ................................................................................. 151
vii
EtherWAN Managed Switch Users Guide
Preface
Setting an MSTP Instance ............................................................................... 151
Modifying MSTP parameters for load balancing ............................................... 152
MSTP Port Setting page ........................................................................................ 154
Adjusting the blocking port in a MSTP network ................................................ 154
MSTI Instance Port Membership ...................................................................... 156
MSTP Configuration Examples Using CLI Commands .......................................... 157
Enabling Spanning Tree for MSTP ................................................................... 157
Bridge Priority, Max Age, Forward Delay, and Hello Time ................................ 158
IST MAX Hops ................................................................................................. 158
MSTP Regional Configuration Name and the Revision Level ........................... 159
Creating an MSTI Instance .............................................................................. 159
Setting MSTI Priority ........................................................................................ 160
Modifying CIST Port Priority and Port Path Cost .............................................. 160
Adding a Port to an MSTI Instance .................................................................. 161
STP/Ring Page - Alpha Ring ............................................................................... 162
Alpha Ring Setting Page ........................................................................................ 162
EtherWAN α-Ring Technology ......................................................................... 162
Implementing a Simple α-Ring ......................................................................... 162
Connecting two α-Ring Networks together ....................................................... 164
STP/Ring Page – Alpha Chain ............................................................................ 165
The Alpha Chain Protocol ...................................................................................... 165
General Overview .................................................................................................. 165
Alpha Chain Settings ............................................................................................. 166
Global Settings ................................................................................................ 166
Configuring the Alpha Chain Ports ................................................................... 167
Alpha Chain Pass-Through Ports ........................................................................... 169
Configuring Alpha Chain using CLI commands ...................................................... 170
Storm Control ................................................................................................... 170
Configuring Chain Ports ................................................................................... 170
Configuring Chain Pass-Through Ports ............................................................ 171
STP/Ring Page - Advanced Setting .................................................................... 172
Advanced Bridge Configuration ............................................................................. 172
Advanced Per Port Configuration ........................................................................... 173
Configuring Spanning Tree Advanced Settings using CLI commands.................... 174
Enabling BPDU Guard Globally ....................................................................... 174
Enabling BPDU Guard on a Port ...................................................................... 174
Enabling BPDU Guard Error Disable-timeout ................................................... 175
VLAN ..................................................................................................................... 176
Port Based VLAN vs. Tagged Based VLAN ........................................................... 176
viii
EtherWAN Managed Switch Users Guide
Preface
Configuring VLANs in Port Based VLAN Mode ...................................................... 176
Enabling Port Based VLAN .............................................................................. 176
Port Based VLAN Configuration Examples ...................................................... 177
Port Based VLAN Configuration Examples using CLI Commands ................... 179
VLAN Configuration in 802.1Q Tag Based VLAN Mode ......................................... 180
General Overview ............................................................................................ 180
Enabling 802.1Q Tagged Based VLAN ............................................................ 181
Configuring 802.1Q VLAN Database................................................................ 182
802.1Q Tag Based VLAN Configuration Examples Using CLI Commands ............ 183
Configuring a 802.1Q VLAN ............................................................................. 183
Configuring an IP Address for a Management VLAN ....................................... 183
Removing an IP Address from a Management VLAN ....................................... 184
Configuring an Access Port .............................................................................. 184
Configuring a Trunk Port .................................................................................. 185
Add an IP to the Management VLAN ..................................................................... 186
Configuring the Port Type and the PVID setting ..................................................... 187
Configuring the VLAN Egress (outgoing) Member Ports .................................. 188
QoS ....................................................................................................................... 190
Global Configuration Page ..................................................................................... 191
Web GUI Interface ........................................................................................... 191
QoS Global Configuration using the CLI Interface ................................................. 193
Enable/Disable QoS Trust ................................................................................ 194
Configuring the Egress Expedite Queue .......................................................... 194
802.1p Priority Page .............................................................................................. 196
Web GUI Interface ........................................................................................... 196
802.1p Priority Submenu – CLI Interface ............................................................... 197
DSCP Page – HTTP Interface ............................................................................... 198
DSCP Submenu – CLI Interface ............................................................................ 199
QoS Interface Commands – CLI Interface ............................................................. 200
ACL (Access Control List) .................................................................................. 201
General Overview .................................................................................................. 201
Configuring ACL .................................................................................................... 202
ACL Policy Map ..................................................................................................... 204
IP Access List .................................................................................................. 205
IP Access List (Extended) ................................................................................ 206
Mac Access List ............................................................................................... 208
Layer 4 ............................................................................................................. 210
Bandwidth Limiting ........................................................................................... 211
Applying a Policy Map to a Port ....................................................................... 213
Modifying/Adding an Existing Policy Map ......................................................... 214
Adding a New ACL Class to an Existing Policy Map ........................................ 214
EtherWAN Managed Switch Users Guide
ix
Preface
Adding an Existing ACL Class to an Existing Policy Map ................................ . 215
Removing an ACL Class .................................................................................. 217
ACL Configuration Examples Using CLI Commands ............................................. 221
Enabling QoS ................................................................................................... 221
Creating a Standard IP Access List .................................................................. 222
Creating an Extended IP Access List ............................................................... 222
Creating a MAC Access List ............................................................................ 223
Creating an ACL Class Map with Layer 4 Access List ...................................... 224
Creating a ACL Class Map with an IP or MAC Access List .............................. 225
Creating an ACL Policy Map ............................................................................ 226
Appling an Existing ACL Policy to a Port .......................................................... 227
Deleting an ACL Class ..................................................................................... 227
Deleting an ACL Policy .................................................................................... 228
SNMP .................................................................................................................... 229
SNMP General Settings ......................................................................................... 229
Configuring SNMP v1 & v2 Community Groups ..................................................... 232
Configuring SNMP v3 Users .................................................................................. 233
Adding SNMP v3 Users to the switch ............................................................... 233
Deleting SNMP v3 Users from the switch ......................................................... 236
SNMP Configuration Examples Using CLI Commands .......................................... 237
Enabling SNMP and configuring general settings............................................. 237
Configuring SNMP Traps ................................................................................. 238
Configuring SNMP v1 & v2 Community Groups ............................................... 240
Adding SNMP v3 Users ................................................................................... 240
IEEE 802.1X .......................................................................................................... 241
Configuring 802.1X from the GUI system ............................................................... 241
Enabling Radius ............................................................................................... 241
Adding a Radius Server ................................................................................... 242
Enabling 802.1X on a Port ............................................................................... 244
LLDP ..................................................................................................................... 246
LLDP General Settings .......................................................................................... 247
Enable/Disable LLDP ................................ ....................................................... 247
Holdtime Multiplier ........................................................................................... 247
Global TLV Setting ........................................................................................... 248
LLDP Ports Settings .............................................................................................. 250
Enabling LLDP transmission for a specific Port ................................................ 250
Enabling LLDP Reception for a specific Port .................................................... 250
Enabling Notifications ...................................................................................... 250
LLDP Neighbors .................................................................................................... 252
LLDP Statistics ...................................................................................................... 253
EtherWAN Managed Switch Users Guide
x
Preface
LLDP Configuration Examples Using CLI Commands ........................................... 254
Enable/Disable LLDP ................................ ....................................................... 254
LLDP Holdtime Multiplier .................................................................................. 255
LLDP Transmit Interval .................................................................................... 255
Enable/Disable Global LLDP TLVs .................................................................. 256
Enabling LLDP Transmit on a Port ................................................................... 257
Enabling LLDP Receive on a Port .................................................................... 257
Enabling LLDP Notify ................................ ....................................................... 258
Enabling Transmission of the Management IP ................................................. 258
Enabling Specific TLV’s on a Port .................................................................... 259
Other Protocols.................................................................................................... 260
GVRP .................................................................................................................... 260
General Overview ............................................................................................ 261
Enabling the GVRP Protocol at the Global Level ............................................. 262
Enabling the GVRP Protocol at the Port Level ................................................. 263
GVRP Configuration Examples Using CLI Commands .................................... 264
IGMP Snooping ..................................................................................................... 267
General Overview ............................................................................................ 267
Enabling the IGMP Snooping Modes ............................................................... 268
Configuring IGMP Snooping General properties .............................................. 269
Configuring IGMP Passive Mode Specific properties ....................................... 270
Configuring IGMP Querier Mode Specific properties ........................................ 271
Configuring IGMP Unknown Multicast Forwarding ........................................... 272
Monitoring Registered Multicast Groups .......................................................... 276
IGMP Configuration Examples Using CLI Commands ..................................... 277
Network Time Protocol .......................................................................................... 285
Enabling NTP ................................................................................................... 285
Setting the NTP Server IP Address .................................................................. 285
Setting the Timezone ....................................................................................... 285
Setting the Polling Period ................................................................................. 285
Manually Syncing Time .................................................................................... 286
Daylight Savings Time - Weekday Mode .......................................................... 286
Daylight Savings Time – Date Mode ................................................................ 287
Network Time Protocol Configuration Examples Using CLI Commands ........... 289
GMRP .................................................................................................................... 292
General Overview ............................................................................................ 292
GMRP Normal mode ........................................................................................ 292
GMRP Fixed mode .......................................................................................... 292
GMRP Forbidden mode ................................................................................... 293
GMRP Forward All mode ................................................................................. 293
GMRP Disabled mode ..................................................................................... 293
Enabling the GMRP Feature Globally on the Switch ........................................ 293
EtherWAN Managed Switch Users Guide
xi
Preface
Configuring the GMRP Feature Per Port .......................................................... 294
GMRP Configuration Examples Using CLI Commands .................................... 297
DHCP Server ......................................................................................................... 299
General Overview ............................................................................................ 299
Configuring the DHCP Server .......................................................................... 299
DHCP Configuration Examples Using CLI Commands .................................... 302
TABLE OF FIGURES
Figure 1: Login screen ......................................................................................................... 21
Figure 2: Assigning an IP address ....................................................................................... 22
Figure 3: System Information .............................................................................................. 27
Figure 4: System Name/Password ...................................................................................... 28
Figure 5: IP Address............................................................................................................ 31
Figure 6: Management Interface.......................................................................................... 38
Figure 7: Save Configuration Page ...................................................................................... 44
Figure 8: Firmware Upgrade Page ...................................................................................... 49
Figure 9: User Mode............................................................................................................ 51
Figure 10: Creating Users ................................................................................................... 52
Figure 11: Selecting an Existing User Account .................................................................... 53
Figure 12: Deleting a User Account ..................................................................................... 53
Figure 13: User Privilege Page ............................................................................................ 55
Figure 14: Utilization Page .................................................................................................. 60
Figure 15: System Log ................................................................................................ ........ 61
Figure 16: Remote Logging Page ........................................................................................ 63
Figure 17: ARP Table .......................................................................................................... 65
Figure 18: Route Table ........................................................................................................ 67
Figure 19: Alarm Trigger ..................................................................................................... 68
Figure 20: Trigger Enable .................................................................................................... 68
Figure 21: Port Configuration .............................................................................................. 70
Figure 22: Port Status ......................................................................................................... 71
Figure 23: Rate Control ....................................................................................................... 72
Figure 24: RMON Page ....................................................................................................... 73
Figure 25: Port VLAN Activities ........................................................................................... 74
Figure 26: Port Security ....................................................................................................... 75
Figure 27: Bridging .............................................................................................................. 84
Figure 28: Loopback Detection ............................................................................................ 86
Figure 29:Loopback Detection (port) ................................................................................... 87
Figure 30: Storm Detect – Global ........................................................................................ 88
EtherWAN Managed Switch Users Guide
xii
Preface
Figure 31: Storm Detect – Per Port ..................................................................................... 89
Figure 32: MAC Static Entry ................................................................................................ 90
Figure 33: Removing a Static MAC ..................................................................................... 91
Figure 34: Adding a MAC – Static-MAC-Entry Table ................................ ........................... 91
Figure 35: Deleting a MAC – Static-MAC-Entry Table ......................................................... 92
Figure 36: Port Mirroring ..................................................................................................... 94
Figure 37: Disabling Port Mirroring ...................................................................................... 94
Figure 38: Link State Tracking ............................................................................................. 95
Figure 39: Link State Tracking – Port Settings..................................................................... 96
Figure 40: PoE System Setting ........................................................................................... 97
Figure 41: PoE Port Setting ................................................................................................. 99
Figure 42: Selecting a Port ................................................................................................ 100
Figure 43: PoE Power Scheduling ..................................................................................... 101
Figure 44: Port Trunking – Version 1 ................................................................................. 121
Figure 45: Port Trunking – Version 2 ................................................................................. 122
Figure 46: LACP Trunking Version 1 ................................................................................. 124
Figure 47: LACP Trunking – Version 2 .............................................................................. 126
Figure 48: STP/Ring Global Configuration ......................................................................... 131
Figure 49: Bridge ID .......................................................................................................... 132
Figure 50: Bridge ID Display .............................................................................................. 133
Figure 51: Max Age, Hello Timer & Forward Delay ............................................................ 135
Figure 52: Spanning Tree Port Roles ................................................................................ 136
Figure 53: Port ID ................................ ................................................................ .............. 137
Figure 54: Port Priority and Path Cost ............................................................................... 138
Figure 55: Enabling MSTP ................................................................................................ 144
Figure 56: Bridge ID .......................................................................................................... 145
Figure 57: Bridge ID Display .............................................................................................. 146
Figure 58: Max Age, Hello Timer & Forward Delay ............................................................ 148
Figure 59: MSTP Region and Revision Level ................................ .................................... 149
Figure 60: MSTP Properties – Max Hops .......................................................................... 150
Figure 61: VLAN Instance Configuration ........................................................................... 152
Figure 62: VLAN Instance ID ............................................................................................. 152
Figure 63: Setting the MSTI Regional Root Bridge ............................................................ 153
Figure 64: Port Cost & Priority ........................................................................................... 155
Figure 65: Port Instance Configuration .............................................................................. 156
Figure 66: Port Instance - Adding Ports ............................................................................. 157
Figure 67: α-Ring Settings ................................................................................................. 163
Figure 68: Ring Coupling ................................................................................................... 164
Figure 69: Alpha Chain Setting .......................................................................................... 167
Figure 70: Chain Ports – Master and Slave on one Switch ................................................ 167
Figure 71: Chain Ports – Master Chain Port ...................................................................... 168
Figure 72: Advanced Bridge Configuration ........................................................................ 172
Figure 73: Advanced Per Port Configuration ..................................................................... 173
EtherWAN Managed Switch Users Guide
xiii
Preface
Figure 74: Port Based VLAN ............................................................................................. 176
Figure 75: Port Based VLAN – Example 1 ......................................................................... 177
Figure 76: Port Based VLAN – Example 2 ......................................................................... 178
Figure 77: Tag-based VLAN .............................................................................................. 181
Figure 78: Add VLAN ........................................................................................................ 182
Figure 79: Add VLAN Page ............................................................................................... 182
Figure 80: Management VLAN IP Address ........................................................................ 186
Figure 81: VLAN Port Setting ............................................................................................ 187
Figure 82: VLAN Links ...................................................................................................... 188
Figure 83: VLAN Ports ...................................................................................................... 189
Figure 84: Tag or Untag ports ........................................................................................... 189
Figure 85: Global Configuration ......................................................................................... 191
Figure 86: 802.1p Priority .................................................................................................. 196
Figure 87: DSCP ............................................................................................................... 198
Figure 88: Enabling QoS ................................................................................................... 203
Figure 89: Policy Map ........................................................................................................ 204
Figure 90: IP Access List ................................................................................................... 205
Figure 91: Access List Extended ....................................................................................... 206
Figure 92: MAC Access list ............................................................................................... 208
Figure 93: Layer 4 ............................................................................................................. 210
Figure 94: IP Access List Name ........................................................................................ 211
Figure 95: Police Rate ....................................................................................................... 212
Figure 96: Policy Map Name ............................................................................................. 212
Figure 97: Applying a Policy Map to a Port ........................................................................ 213
Figure 98: Modifying a Policy Map ..................................................................................... 214
Figure 99: Adding a New ACL Class to an Existing Policy Map ......................................... 215
Figure 100: Policy Map Setting – Class Name................................................................... 216
Figure 101: Policy Map Setting .......................................................................................... 216
Figure 102: Removing an ACL Class ................................................................................ 217
Figure 103: Verifying ACL Class Removal ......................................................................... 218
Figure 104: Removing a Policy Map .................................................................................. 219
Figure 105: Policy Map 2 ................................................................................................... 220
Figure 106: Policy Map 3 ................................................................................................... 221
Figure 107: SNMP General Settings ................................................................................. 231
Figure 108: Community Name V1/V2c .............................................................................. 232
Figure 109: Add User ........................................................................................................ 233
Figure 110: SNMP v3 Settings ................................ .......................................................... 234
Figure 111: User name & Access Mode ............................................................................ 234
Figure 112: Auth Password ............................................................................................... 235
Figure 113: Privacy PassPhrase ....................................................................................... 235
Figure 114: Delete User .................................................................................................... 236
Figure 115: Select User ..................................................................................................... 236
Figure 116: Enable Radius ................................................................................................ 242
EtherWAN Managed Switch Users Guide
xiv
Preface
Figure 117: Radius Setup .................................................................................................. 243
Figure 118: Resulting Radius Server Setup ....................................................................... 244
Figure 119: Enabling 802.1X on a Port .............................................................................. 245
Figure 120: LLDP Global Settings ..................................................................................... 249
Figure 121: LLDP Ports Settings ....................................................................................... 251
Figure 122: LLDP Neighbors ............................................................................................. 252
Figure 123: LLDP Statistics ............................................................................................... 253
Figure 124: GVRP ............................................................................................................. 260
Figure 125: GVRP Configuration Distribution Switch ......................................................... 262
Figure 126: GVRP Configuration Access Switch ............................................................... 262
Figure 127: GVRP Per Port Settings ................................................................................. 263
Figure 128: IGMP Mode .................................................................................................... 268
Figure 129: IGMP General Properties ................................................................ ............... 269
Figure 130: IGMP Passive Mode ....................................................................................... 270
Figure 131: Querier Mode Properties ................................................................................ 271
Figure 132: Disabled Mode Forwarding Port ..................................................................... 272
Figure 133: PassiveForwardMode ..................................................................................... 273
Figure 134: ForceForwardMode ........................................................................................ 274
Figure 135: IGMP Querier Mode Forwarding ..................................................................... 275
Figure 136: Current Multicast Groups ................................................................................ 276
Figure 137: NTP Settings .................................................................................................. 286
Figure 138: Daylight Savings – Weekday Mode ................................................................ 287
Figure 139: Daylight Savings – Date Mode ....................................................................... 288
Figure 140: GMRP Global Setting ..................................................................................... 294
Figure 141: DHCP Server ................................................................................................. 300
Figure 142: DHCP Bindings .............................................................................................. 301
Figure 143: DHCP Binding Table ...................................................................................... 301
xv
EtherWAN Managed Switch Users Guide
Preface
Revision
Document Version
Date
Description
C
Version 1
8/21/2015
Updated for Firmware version 1.94.2.1
PREFACE
Audience
This guide is designed for the person who installs, configures, deploys, and maintains the
Ethernet network. This document assumes the reader has moderate hardware, computer,
and Internet skills.
Document Revision Level
This section provides a history of the revision changes to this document.
Changes in this Revision
Updated product image
xvi
EtherWAN Managed Switch Users Guide
Preface
Symbol
Meaning
Description
Note
Notes emphasize or supplement important points of the main text.
Tip
Tips provide helpful information, guidelines, or suggestions for performing tasks more
effectively.
Warning
Warnings indicate that failure to take a specified action could result in damage to the
device, or could result in serious bodily injury.
Electric Shock Hazard
This symbol warns users of electric shock hazard. Failure to take appropriate
precautions such as not opening or touching hazardous areas of the equipment could
result in injury or death.
Convention
Description
Bold
Indicates text on a window, other than the window title, including menus, menu options, buttons, fields, and labels.
Italic
Indicates a variable, which is a placeholder for actual text provided by the user or system. Angled brackets (< >)
are also used to indicate variables.
screen/code
Indicates text that is displayed on screen or entered by the user.
< > angled
brackets
Indicates a variable, which is a placeholder for actual text provided by the user or system. Italic font is also used to
indicate variables.
[ ] square
brackets
Indicates optional values.
{ } braces
Indicates required or expected values.
| vertical bar
Indicates that you have a choice between two or more options or arguments.
Document Conventions
This guide uses the following conventions to draw your attention to certain information.
Safety and Warnings
This guide uses the following symbols to draw your attention to certain information.
Typographic Conventions
This guide also uses the following typographic conventions.
EtherWAN Managed Switch Users Guide
xvii
UNPACKING AND INSTALLATION
This chapter describes how to unpack and install the EtherWAN Managed Switch
The topics covered in this chapter are:
Package Contents (Page 18)
Unpacking (Page 18)
Required Equipment and Software (Page 19)
Computer Setup (Page 20)
Management Methods and Protocols (Page 20)
Default IP (Page 21)
Login Process and Default Credentials (Page 21)
Setting the initial IP address (Page 22)
Package Contents
When you unpack the product package, you will find the items listed below. Please inspect
the contents, and report any apparent damage or missing items immediately to your
authorized reseller.
This Managed Switch
Product CD
Quick Installation Guide
External power adapter/Cable (depending on model)
Unpacking
Follow these steps to unpack the EtherWAN Managed Switch and prepare it for operation:
1. Open the shipping container and carefully remove the contents.
2. Return all packing materials to the shipping container and save it.
3. Confirm that all items listed in the "Package Contents" section are included in the
shipment. Check each item for damage. If any item is damaged or missing, notify your
authorized EtherWAN representative.
EtherWAN Managed Switch Users Guide
18
Required Equipment and Software
The following hardware and software are needed in order to manage the switch from the
web interface:
Computer with an Ethernet Interface (RJ-45)
Managing the switch requires a personal computer (PC) or notebook computer
equipped with a 10/100base-TX Ethernet interface and a physical RJ-45
connection. The preferred operating system for the computer is Microsoft Windows
XP/Vista/7. It is possible to use Apple OSX or Linux systems as well, but, for the
sake of brevity, all web configurations in this manual will be shown using Windows
7 as the underlying operating system.
Cat 5+ Ethernet Cables
An Ethernet cable of at least Category 5 rating is required to connect your
computer to the switch. The cable can be configured as “straight-through” or
crossover.
TFTP Server Software
Trivial file transfer protocol (TFTP) server software is needed to update the switch
firmware and to upload/download configuration files to the switch. Users not
performing these tasks do not need TFTP software installed. Several good TFTP
servers are available for free online. The server that will be used in this manual is
TFTPD32 by Philippe Jounin.
Web Browser Software
The end user can employ any of the following web browsers during switch
configuration: Internet Explorer, Firefox, or Chrome. Internet Explorer is the
preferred browser for EtherWAN switch configuration. If there is trouble with other
browsers while attempting to program the switch, Internet Explorer should be used.
19
EtherWAN Managed Switch Users Guide
COMPUTER SETUP
The end user’s management computer may need to be reconfigured prior to connecting to
the switch in order to access the switch’s web interface through its default IP address (See
Default IP).
Management Methods and Protocols
There are several methods that can be used to manage the switch. This manual
will show the details of configuring the switch using a web browser. Each section
will be followed by the CLI (Command Line Interface) commands needed to
achieve the same results as described in that section.
The methods available to manage the EtherWAN Managed Switch include:
SSH - Secure Shell CLI that is accessible over TCP/IP networks which and
is generally regarded as the most secure method of remotely accessing a
device.
Telnet - is like SSH in that it allows a CLI to be established across a
TCP/IP network, but it does not encrypt the data stream.
HTTP (Hypertext Transfer Protocol) is the most popular switch
management protocol involving the use of a web browser.
RS232 – The EtherWAN Managed Switch is equipped with a RS232 serial
port that can be used to access the switches CLI. The Serial port is DCE
DB9F. A straight through serial cable is used to connect to a typical
computer serial port.
EtherWAN Managed Switch Users Guide
20
Default IP
The switch’s default IP address is 192.168.1.10. The user will need to modify the
management computer so that it is on the same network as the switch. For
example, the user could change the IP address of the management computer to
192.168.1.100 with a subnet mask of 255.255.255.0.
Login Process and Default Credentials
Once a compatible IP address has been assigned to the management computer,
the user is ready to log in to the switch. To log in, type the URL http://192.168.1.10/
into the address field of the browser and hit return. The following will appear in the
browser window (See Figure 1)
The Default Login is root (case sensitive)
There is no password by default
Enter the login name and click the Login button
Figure 1: Login screen
21
EtherWAN Managed Switch Users Guide
SETTING THE INITIAL IP ADDRESS
Once logged in the user can now configure the switch per the network requirements. The
two major addressing options are:
Simple IP addressing
Multiple VLAN addressing (See Add an IP to the Management VLAN on page 186).
Simple IP Addressing
A new IP address can now be assigned to the switch. From the System Information screen,
go to the left hand navigation menu.
1. Click on the + next to System
2. Click on IP address
3. Enter the desired IP address and subnet mask in the IP Address/Subnet Mask
fields associated with VLAN 1
4. Click the Apply & Save button (See Figure 2)
Figure 2: Assigning an IP address
EtherWAN Managed Switch Users Guide
22
CLI COMMAND USAGE
This chapter describes accessing the EtherWAN Managed Switch by using Telnet, SSH, or
serial ports to configure the switch, navigating the Command Line Interface (CLI), typing
keyboard shortcuts, and moving between the levels. This chapter assumes the user has a
working understanding of Telnet, SSH and Terminal emulation applications.
Note: For a serial port connection use a standard DB9F to DB9M Modem Cable. The
default Serial port parameters are 115200, 8 None 1, No Flow Control.
Navigating the CLI Hierarchy
The CLI is organized into a hierarchy of levels. Each level has a group of commands for a
specific purpose. For example, to configure a setting for the VLAN server, one would
navigate to the VLAN level, which is under the config level.
CLI Keyboard Shortcuts
Ctrl + a: place cursor at the beginning of a line
Ctrl + b: backspace one character
Ctrl + d: delete one character
Ctrl + e: place cursor at the end of the line
Ctrl + f: move cursor forward one character
Ctrl + k: delete from the current position to the end of the line
Ctrl + l: redraw the command line
Ctrl + n: display the next line in the history
Ctrl + p: display the previous line in the history
Ctrl + u: delete entire line and place cursor at start of prompt
Ctrl + w: delete one word back
EtherWAN Managed Switch Users Guide
23
CLI Command modes
Throughout this manual, each section that has CLI commands relevant to that section
requires that the CLI be in a specific configuration mode. This section shows the main CLI
commands to needed to enter a specific mode.
General Configuration Mode
To set the EtherWAN Managed Switch to General configuration mode, run the
following commands from the CLI:
1. enable
2. configure terminal
Example:
switch_a>enable
switch_a#configure terminal
switch_a(config)#
MSTP Configuration Mode
To set the EtherWAN Managed Switch to General MSTP configuration mode, run the
following commands from the CLI:
1. enable
2. configure terminal
3. spanning-tree mst configuration
Example:
switch_a>enable
switch_a#configure terminal
switch_a(config)#spanning-tree mst configuration
switch_a(config-mst)#
24
EtherWAN Managed Switch Users Guide
Interface Configuration Mode
Interface mode on the EtherWAN Managed Switch is used to configure the Ethernet ports
and VLAN information. Valid interfaces are:
fe<port #> - 100mb ports use fe followed by the port number. Example: fe1
ge<port #> - Gigabit ports use ge followed by the port number. Example: ge1
vlan1.<vlan#> - VLAN’s use vlan. Followed by the VLAN ID. Example: vlan1.10
Example 1 configures 100mb port 1
switch_a>enable
switch_a#configure terminal
switch_a(config)#interface fe1
switch_a(config-if)
Example 2 configures VLAN ID 9
switch_a>enable
switch_a#configure terminal
switch_a(config)#interface vlan1.9
switch_a(config-if)
VLAN Database Configuration Mode
VLAN Database Configuration Mode on the EtherWAN Managed Switch is used to
configure the VLAN settings.
Example:
switch_a>enable
switch_a#configure terminal
switch_a(config)#vlan database
switch_a(config-vlan)#
Saving a Configuration from the CLI
Example:
switch_a>enable
switch_a#write memory
Building configuration.....
[OK]
switch_a#>
EtherWAN Managed Switch Users Guide
25
SYSTEM MENU
System Information
The System information link on the Left menu of the Web Configuration page takes you to a
page that shows the following (see Figure 3):
System Name
o The System name is typically used by network administrators. If SNMP is
enabled on the switch, the system name can be found using MIB II
(RFC1213) in the sysName property.
Firmware Version
o If SNMP is enabled on the switch, the Firmware version can be found using
MIB II in the sysDesc property
System Time
o System time can be change using NTP
MAC Address
o The hardware (MAC) address of the Management interface
Default Gateway
o The IP address of your networks Gateway (Typically a Router on your
network)
DNS Server
o The Dynamic Name Server (DNS) for your network
VLAN ID
o One or more listings depending on the number o VLANs defined on the
switch
o Lists VLAN ID, IP address, and subnet mask of the VLAN Interface(s)
Current User Information
o Lists the current the currently logged in user and their user privileges
26
EtherWAN Managed Switch Users Guide
Figure 3: System Information
EtherWAN Managed Switch Users Guide
27
System Name/Password
The System name is typically used by network administrators to make it easier to document
a networks infrastructure and locate equipment on large networks. If SNMP is enabled on
the switch, the system name can be found using MIB II (RFC1213) in the sysName property.
To change the system name:
1. Click on the + next to System.
2. Click on System Name/Password (see Figure 4).
3. Use your mouse to place the cursor in the System Name text box.
4. Replace the existing name with the name you want to assign to the switch.
5. Click on the Update Setting button.
By default there is no password assigned to the switch. To add or change a password:
1. Click on the + next to System.
2. Click on System Name/Password (see Figure 4).
3. Use your mouse to place the cursor in the Password text box.
4. Enter the new password.
5. Retype the password in the Retype Password text box.
6. Click on the Update Setting button below the Retype Password text box.
Figure 4: System Name/Password
EtherWAN Managed Switch Users Guide
28
System Name/Password using the CLI
For more information on CLI command usage see CLI Command Usage.
System Name
To set the system name on a switch, use the following CLI commands:
CLI Command Mode: General Configuration Mode
CLI Command Syntax:
hostname <name>
no hostname
Usage Example 1: Setting a Hostname
switch_a>enable
switch_a#configure terminal
switch_a(config)#hostname switch_a
switch_a(config)#q
switch_a#
Usage Example 2: Removing a Hostname
switch_a>enable
switch_a#configure terminal
switch_a(config)#no hostname
switch_a(config)#q
switch_a#
Password
To enable a password on a switch, use the following CLI commands:
CLI Command Mode: General Configuration Mode
CLI Command Syntax:
enable password <password>
Usage Example
switch_a>enable
switch_a#configure terminal
switch_a(config)#enable password mypassword
switch_a(config)#q
switch_a#
29
EtherWAN Managed Switch Users Guide
IP Address
To navigate to the IP Address page:
1. Click on the + next to System
2. Click on IP Address (see Figure 5)
There are 4 settings on this page:
Static IP (see Simple IP Addressing)
DHCP Client
Use this to enable or disable DHCP on a VLAN.
To enable the DHCP Client:
1. Use the drop down box to enable the DHCP client on a particular VLAN
2. Click the Submit Button
Default Gateway
If DHCP is enabled, the gateway setting is controlled by the DHCP server. The
setting will be grayed out and the gateway supplied by the DHCP server will be
displayed. The default gateway setting can be used when using a Static IP address.
To enable the default gateway:
1. Use the dropdown box to enable the default gateway.
2. Type in the default gateway in the Default Gateway text box.
3. Click on the Apply & Save button.
DNS Server
If DHCP is enabled, the DNS Server setting is controlled by the DHCP server. The
setting will be grayed out and the DNS Server supplied by the DHCP server will be
displayed. The DNS Server setting can be used when using a Static IP address. To
enable the DNS Server:
1. Use the dropdown box to enable the DNS Server.
2. Type in the default gateway in the Default Gateway text box.
3. Click on the Submit button.
Note: After making changes to settings in the IP address section, the
configuration needs to be saved using the System/Save configuration page
(See Save Configuration)
30
EtherWAN Managed Switch Users Guide
Loading...
