User’s Guide – Command Line Interface (CLI)
EX26262F PoE Managed Switch
- 2 -
NOTE: Emphasizes important information or calls your attention to
related features or instructions.
W
ARNING
:
Alerts you to a potential hazard that could cause personal injury.
C
AUTION
:
Alerts you to a potential hazard that could cause loss of data, or
damage the system or equipment.
Release
Date
Revision
Initial Release
2017/05/22
A1
AUDIENCE
The guide is intended for use by network administrators who are responsible for operating and
maintaining network equipment; consequently, it assumes a basic working knowledge of general
switch functions, the Internet Protocol (IP), and Simple Network Management Protocol (SNMP).
CONVENTIONS
The following conventions are used throughout this guide to show information:
Revision History
EX26262F Managed Switch Users Guide - CLI
- 3 -
CONTENTS
INTRODUCTION ............................................................................................................................... - 5 -
CLI Management ............................................................................................................................. - 6 -
AAA Commands .............................................................................................................................. - 7 -
Access Management Commands .................................................................................................... - 9 -
ACL Commands ............................................................................................................................ - 10 -
Aggregation Commands ................................................................................................................ - 16 -
ARP-inspection Commands ........................................................................................................... - 18 -
Banner Commands ........................................................................................................................ - 20 -
Clock Commands ........................................................................................................................... - 21 -
Copy Commands ........................................................................................................................... - 22 -
DHCP Commands .......................................................................................................................... - 23 -
Diagnostic Commands ................................................................................................................... - 24 -
DNS Proxy ...................................................................................................................................... - 25 -
dot1x Commands .......................................................................................................................... - 26 -
Enable / Disable ............................................................................................................................ - 28 -
Event Notifications ........................................................................................................................ - 29 -
Hostname ...................................................................................................................................... - 30 -
Green Ethernet .............................................................................................................................. - 30 -
Mac Address Table ........................................................................................................................ - 31 -
Firmware Commands .................................................................................................................... - 33 -
GVRP Commands .......................................................................................................................... - 35 -
HTTP Commands ........................................................................................................................... - 37 -
IGMP Commands .......................................................................................................................... - 38 -
Interface Configuration Commands .............................................................................................. - 42 -
IPMC Commands ........................................................................................................................... - 44 -
IP Name Server .............................................................................................................................. - 44 -
IP Route and Routing ..................................................................................................................... - 45 -
IP Source Binding / Verify Source .................................................................................................. - 45 -
IPv6 Commands............................................................................................................................. - 46 -
LACP Commands ........................................................................................................................... - 47 -
LLDP Commands............................................................................................................................ - 48 -
Logging Commands ....................................................................................................................... - 51 -
Loop Protect .................................................................................................................................. - 51 -
Port Mirroring and Monitoring ..................................................................................................... - 52 -
MLD Commands ............................................................................................................................ - 53 -
MVR Commands ............................................................................................................................ - 54 -
Network Time Protocol ................................................................................................................. - 55 -
Power Over Ethernet ..................................................................................................................... - 56 -
Port security Commands ............................................................................................................... - 58 -
Privilege level Commands ............................................................................................................. - 58 -
QoS Commands ............................................................................................................................. - 59 -
Reload............................................................................................................................................ - 64 -
RMON ............................................................................................................................................ - 64 -
SFlow Commands .......................................................................................................................... - 66 -
SMTP Commands .......................................................................................................................... - 68 -
SNMP Commands.......................................................................................................................... - 68 -
EX26262F Managed Switch Users Guide - CLI
- 4 -
SSH Commands ............................................................................................................................. - 71 -
STP Commands .............................................................................................................................. - 72 -
Terminal Commands ..................................................................................................................... - 76 -
UPnP Commands ........................................................................................................................... - 76 -
Username Commands ................................................................................................................... - 77 -
VLAN Commands ........................................................................................................................... - 78 -
Voice VLAN Commands ................................................................................................................. - 80 -
Web Commands ............................................................................................................................ - 81 -
EX26262F Managed Switch Users Guide - CLI
- 5 -
INTRODUCTION
EtherWAN's EX26262F provides a 26-port switching platform with support for IEEE802.3at Power over
Ethernet, high performance switching, and the advanced management features required for enterprise
environments.
Equipped with 24 10/100/1000BASE-TX PoE ports, in combination with 2 100/1000 SFP Combo options, the
EX26262F is feature-rich, with 9216 Bytes Jumbo Frame support, full wire speed Gigabit throughput, and QoS
support.
The PoE ports provide up to 30 Watts per port, with a total power budget of 370 Watts, allowing the switch
to operate a wide variety of Powered Devices with different bandwidth and power consumption
requirements, such as IP cameras.
Robust management features include port security, IGMP snooping, VLANs, GARP protocols, and LACP, as
well as SNMP & RMON interfaces. An intuitive GUI for web management simplifies switch configuration,
status monitoring, and maintenance activities.
The EX26262F provides the following features:
Supports IPv4/IPv6 dual stack management
Supports SSH/SSL secured management
Supports SNMP v1/v2c/v3
Supports RMON groups 1,2,3,9
Supports IGMP v1/v2/v3 Snooping
Supports MLD v1/v2 Snooping
Supports RADIUS and TACACS+ authentication
Supports IP Source Guard
Supports DHCP Relay (Option 82)
Supports DHCP Snooping
Supports ACL and QCL for traffic filtering
Supports 802.1d(STP), 802.1w(RSTP) and 802.1s(MSTP)
Supports LACP and static link aggregation
Supports Q-in-Q double tag VLAN
Supports GVRP dynamic VLAN
EX26262F Managed Switch Users Guide - CLI
- 6 -
CLI Management
MODE
PROMPT
FUNCTIONS
exec
EX26262F#
Display current configuration,
diagnostics, maintenance
config
EX26262F (config)#
Configuration commands
Config-if
EX26262F (config-interface)#
Configure ports
Config-if-vlan
EX26262F (config-if-vlan)#
Configure static vlan
Config-line
EX26262F (config-line)#
Line Configuration
Config-impc-profile
EX26262F (config-impc-profile)#
IPMC Profile
Config-snmp-host
EX26262F (config-snmp-host)#
SNMP Server Host
Config-stp-aggr
EX26262F (config-stp-aggr)#
STP Aggregation
Config-dhcp-pool
EX26262F (config-dhcp-pool)#
DHCP Pool Configuration
Config-rfc2544-profile
EX26262F (config-rfc2544-profile)#
RFC2544 Profile
Initial Configuration
Connect to the switch console by connecting the RJ45 to DB9 console cable to the RJ45 console
port of the switch and to the serial port of the computer running a terminal emulation application
(such as HyperTerminal or Putty).
Configuration settings of the terminal-emulation program: Baud rate: 115,200bps, Data bits: 8,
Parity: none, Stop bit: 1, Flow control: none.
The default login name is“root,” no password.
Baud rate 115200
Stop bits 1
Data bits 8
Parity N
Flow control none
You can also use telnet to connect to the management VLAN of the switch: 192.168.1.10. Login is
the sameL “root,” no password.
Command Modes
The CLI is divided into several modes. If a user has privilege to run a particular command,
the command must be run in the correct mode. To see the commands of the mode, enter a “?” at the
system prompt. All commands will be listed in the screen. The command modes are listed bellow:
EX26262F Managed Switch Users Guide - CLI
- 7 -
AAA Commands
Mode:
Global config
Syntax:
[no] radius-server attribute 32 <line1-255>
[no] radius-server attribute 4 <ipv4_ucast>
[no] radius-server attribute 95 <ipv6_ucast>
[no] radius-server deadtime <1-1440>
[no] radius-server host { <word1-255> | <ipv4_ucast> | <ipv6_ucast> } [ auth-port
<0-65535> ] [ acct-port <0-65535> ] [ timeout <1-1000> ] [ retransmit <1-1000> ] [ key
<line1-63> ]
[no] radius-server key <line1-63>
[no] radius-server retransmit <1-1000>
[no] radius-server timeout <1-1000>
Parameter:
deadtime Time to stop using a RADIUS server that doesn't respond
host Specify a RADIUS server
key Set RADIUS encryption key
retransmit Specify the number of retries to active server
timeout Time to wait for a RADIUS server to reply
<Minutes : 1-1440> Time in minutes
<Host4 : ipv4_ucast> IPv4 address
<Host6 : ipv6_ucast> IPv6 address
<HostName : word1-255> Hostname
acct-port UDP port for RADIUS accounting server
auth-port UDP port for RADIUS authentication server
key Server specific key (overrides default)
retransmit Specify the number of retries to active server (overrides default)
timeout Time to wait for this RADIUS server to reply (overrides default)
<AuthPort : 0-65535> UDP port number
<Seconds : 1-1000> Wait time in seconds
Switch(config)# radius-server host device key 12
AAA
This section shows you to use an AAA (Authentication, Authorization, Accounting) server to
provide access control to your network. The AAA server can be a TACACS+ or RADIUS
server to create and manage objects that contain settings for using AAA servers.
radius-server:
Configure the RADIUS accounting server parameter.
EXAMPLE:
EX26262F Managed Switch Users Guide - CLI
- 8 -
Mode
Global config
Syntax:
aaa authentication login { console | telnet | ssh | http } { { local | radius | tacacs }
[ { local | radius | tacacs } [ { local | radius | tacacs } ] ] }
Parameter:
authentication Authentication
login Login
console Configure Console
http Configure HTTP
ssh Configure SSH
telnet Configure Telnet
local Use local database for authentication
radius Use RADIUS for authentication
tacacs Use TACACS+ for authentication
Mode:
Global config
Syntax:
[no] tacacs-server deadtime <minutes>
[no] acacs-server host <host_name> [ port <port> ] [ timeout <seconds> ] [ key
<key> ]
[no] tacacs-server key <key>
[no] tacacs-server timeout <seconds>
Parameter:
deadtime Time to stop using a nonresponding TACACS+ server
host Specify a TACACS+ server
key Set TACACS+ encryption key
timeout Time to wait for a TACACS+ server to reply
<Minutes : 1-1440> Time in minutes
<Key: line1-63> Shared key
<Seconds : 1-1000> Wait time in seconds
Switch(config)# aaa suthentication login telnet radius
EX26262F(config)# tacacs-server deadtime 300
EX26262F(config)# tacacs-server host 192.168.1.2
EX26262F(config)# tacacs-server key 33
EX26262F(config)# tacacs-server timeout 300
aaa:
Configure aaa Authentication.
EXAMPLE:
tacacs-server:
Configure TACACS+
EXAMPLE:
EX26262F Managed Switch Users Guide - CLI
- 9 -
Mode:
Global config
Syntax:
[no] access management <access_id>
access management <access_id> <access_vid> <start_addr> [ to <end_addr> ]
{ [ web ] [ snmp ] [ telnet ] | all }
Parameter:
access_id: Numerical ID of entry <1-16>
access_vid: VLAN ID <1-4095>
start_addr: Starting IP address of range in IPv4 or IPV6 format
end_addr: Ending IP address of range in IPv4 or IPV6 format
<all> All services
<snmp> SNMP services
<telnet> telnet services
<web> Web services
EX26262F(config)# access management 10 3 192.168.1.1 all
Access Management Commands
Access
This section shows you to configure access management table of the Switch including HTTP/HTTPS,
SNMP, and TELNET/SSH. You can manage the Switch over an Ethernet LAN, or over the Internet..
access management:
Access management configuration.
EXAMPLE:
EX26262F Managed Switch Users Guide - CLI
- 10 -
Mode:
Global config
Syntax:
access-list ace { update<1-256> | <1-256> } [action< deny | filter |
permit >]
access-list ace { update<1-256> | <1-256> } [dmac-type < any |
broadcast | multicast | unicast >]
access-list ace { update<1-256> | <1-256> } [frametype < any | arp
| etype | ipv4 | ipv4-icmp | ipv4-tcp | ipv4-udp | ipv6 | ipv6-icmp |
ipv6-tcp | ipv6-udp >]
access-list ace { update<1-256> | <1-256> } [ ingress] [ ingress
interface { <port_type> <port_type_id> | <port_type>
<port_type_list> } | any } ]
access-list ace { update<1-256> | <1-256> } [ logging [ disable ] ]
access-list ace { update<1-256> | <1-256> } [ lookup [ disable ] ]
access-list ace { update<1-256> | <1-256> } [ mirror [ disable ] ]
access-list ace { update<1-256> | <1-256> } [ next { <1-256> |
last } ]
access-list ace { update<1-256> | <1-256> } [ policy <0-255>
[ policy-bitmask <0x0-0xFF> ] ]
access-list ace { update<1-256> | <1-256> } [ rate-limiter { <1-16>
| disable } ]
access-list ace { update<1-256> | <1-256> } [redirect | interface
{ <port_type> <port_type_id> | <port_type> <port_type_list> } |
disable } ]
access-list ace { update<1-256> | <1-256> } [shutdown]
access-list ace { update<1-256> | <1-256> } [ tag { tagged |
untagged | any } ]
access-list ace { update<1-256> | <1-256> } [ tag-priority { <0-7>
| any } ]
ACL Commands
ACL
The switch access control lists are used for packet filtering and for selecting types of traffic to be
analyzed, forwarded, or influenced in some way. The ACLs are divided into EtherTypes. IPv4, ARP
protocol, MAC and VLAN parameters etc. Here we will just go over the standard and extended
access lists for TCP/IP. As you create ACEs for ingress classification, you can assign a policy for each
port, the policy number is 1-8, however, each policy can be applied to any port. This makes it very
easy to determine what type of ACL policy you will be working with.
access-list ace:
Create or modify Access Control Entry.
EX26262F Managed Switch Users Guide - CLI
- 11 -
access-list ace { update<1-256> | <1-256> }[ vid { <1-4095> |
any } ]
Parameter:
action Access list action
dmac-type The type of destination MAC address
frametype Frame type
ingress Ingress
logging Logging frame information
lookup Second lookup
mirror Mirror frame to destination mirror port
next insert the current ACE before the next ACE ID
policy Policy
rate-limiter Rate limiter
redirect Redirect frame to specific port
shutdown Shutdown incoming port
tag Tag
tag-priority Tag priority
vid VID field
deny Deny
filter Filter
permit Permit
any Don't-care the type of destination MAC address
broadcast Broadcast destination MAC address
multicast Multicast destination MAC address
unicast Unicast destination MAC address
any Don't-care the frame type
arp Frame type of ARP
etype Frame type of etype
ipv4 Frame type of IPv4
ipv4-icmp Frame type of IPv4 ICMP
ipv4-tcp Frame type of IPv4 TCP
ipv4-udp Frame type of IPv4 TCP
ipv6 Frame type of IPv4
ipv6-icmp Frame type of IPv6 ICMP
ipv6-tcp Frame type of IPv6 TCP
ipv6-udp Frame type of IPv6 UDP
interface Select an interface to configure
<port_type> Gigabitethernet
* All switches or All ports
Gigabitethernet 1 Gigabit Ethernet port
<port_type_id> Port ID in the format of switch-no/port-no ex, 1/1-26 for
Gigabitethernet
EX26262F Managed Switch Users Guide - CLI
- 12 -
<port_type> * or Gigabitethernet
* All Switches or All ports
Gigabitethernet 1 Gigabit Ethernet Port
<port_type_list> Port list in 1/1-26
any Don't-care the ingress interface
<0-255> Policy ID
policy-bitmask The bitmask for policy ID
<0x0-0xFF> The value of policy bitmask
<1-4095> The value of VID field
<0-7> The value of tag priority
EXAMPLE:
Mode:
Global config
Syntax:
access-list rate-limiter [ <1~16> ] { pps <0-3276700> | 100kbps <0-10000> }
[default] access-list rate-limiter [ <1~16> ]
Parameter:
100kbps 100k bits per second
<RateLimiterList : 1~16> Rate limiter ID
<PpsRate : 0-3276700> Rate value
<0-10000> Rate value
Mode:
Interface Config
Syntax:
access-list action < permit | deny >
Parameter:
deny: Deny forwarding
permit: Permit forwarding
EX26262F(config)# access-list ace 10 action deny
EX26262F(config)# access-list rate-limiter 100kbps 111
access-list rate-limiter:
Configure ACL rate limiting
EXAMPLE:
access-list action:
Configure ACL port default action
EX26262F Managed Switch Users Guide - CLI
- 13 -
Mode:
Interface Config
Syntax:
access-list logging
Parameter:
none
Mode:
Interface Config
Syntax:
[no] access-list mirror
Parameter:
none
Mode:
Interface Config
Syntax:
access-list policy <0-255>
Parameter:
<1-256> ACE ID must be exist
<0-256> If the next ACE ID is non-zero, the ACE will be Placed before
this ACE in the list. If the next ACE ID is zero, the ACE will be placed last
in the list.
Mode:
Interface Config
Syntax:
access-list port-state
Parameter:
none
EX26262F(config-if)# access-list policy 10
access-list logging:
Enable access list logging. Note: The logging feature only works when the
packet length is less than 1518 (without VLAN tags) and the System Log
memory size and logging rate is limited.
access-list mirror:
Mirror frames to a destination mirror port.
access-list policy:
Configure the access-list policy value. The access-list interface
configuration will affect the received frames if it doesn't match any ACE.
EXAMPLE:
access-list port-state:
Enable access-list port state.
EX26262F Managed Switch Users Guide - CLI
- 14 -
Mode:
Interface config
Syntax:
access-list rate-limiter [ <1~16> ] { pps <1, 2, 4, 8, 16, 32, 64, 128,
256, 512> | 100pps <1-32767> | kpps <1, 2, 4, 8, 16, 32, 64, 128,
256, 512, 1024> | 100kbps <0-10000> }
Parameter:
<1-16> Rate limiter ID
kbps Kbits per second
pps Packets per second
<0-10000> Rate in 100Kbps
Mode:
Interface config
Syntax:
[no] access-list redirect interface { <port_type_id> |
<port_type_list> }
Parameter:
none
Mode:
Interface config
Syntax:
[no] access-list shutdown
Parameter:
none
EX26262F(config-if)# access-list rate-limiter 1 kbps 100
access-list rate-limiter:
Set the access control rule with rate limiter on switch.
EXAMPLE:
access-list redirect:
Redirect frame to specific port
access-list shutdown:
Shutdown incoming port. The shutdown feature only works when the
packet length is less than 1518 (without VLAN tags).
show access-list:
Show all access control entry setting or information of the switch.
EX26262F Managed Switch Users Guide - CLI
- 15 -
Mode:
Privilged exec
Syntax:
show access-list [ interface [ * | Gigabitetherne <PORT_LIST> ] ]
[ rate-limiter [ <RateLimiterList : 1~16> ] ] [ ace statistics [ <AceId :
1~256> ] ]
show access-list ace-status [ static ] [ loop-protect ] [ dhcp ] [ upnp ]
[ arp-inspection ] [ mep ] [ ipmc ] [ ip-source-guard ] [ ip-mgmt ]
[ conflicts ]
Parameter:
interface Select an interface to configure
* All Switches or All Ports
Gigbitethernet 1 Gigabit Ethernet Port
<port_type_list> Port list in 1/1-26
rate-limiter Rate limiter
< RateLimiterList : 1~16> Rate limiter ID
ace Access list entry
statistics Traffic statistics
<AceId : 1~256> ACE ID
ace-status The local ACEs status
static The ACEs that are configured by users manually
loop-protect The ACEs that are configured by Loop Protect module
dhcp The ACEs that are configured by DHCP module
upnp The ACEs that are configured by UPnP module
arp-inspection The ACEs that are configured by ARP Inspection
module
mep The ACEs that are configured by MEP module
ipmc The ACEs that are configured by IPMC module
ip-source-guard The ACEs that are configured by IP Source Guard
module
ip-mgmt The ACEs that are configured by IP Mamagement module
conflicts The conflicts ACEs that does not applied to the hardware
due to hardware limitations
EX26262F# show access-list ace statistics rate-limiter
Switch access-list ace number: 0
Switch access-list rate limiter ID 1 is 1 pps
EXAMPLE:
EX26262F Managed Switch Users Guide - CLI
- 16 -
Aggregation Commands
Mode:
Global config
Syntax:
aggregation mode { [ smac ] [ dmac ] [ ip ] [ port ] }
no aggregation mode
Parameter:
dmac Destination MAC affects the distribution
ip IP address affects the distribution
port IP port affects the distribution
smac Source MAC affects the distribution
Monde:
Interface config
Syntax:
aggregation group <uint>
no aggregation group
Parameter:
<uint> The Aggregation group id <1-14>.
EX26262F(config)# aggregation mode ip port dmac smac
EX26262F(config-if)# aggregation group 10
Aggregation
The Aggregation is used to configure the settings of Link Aggregation. You can bundle more than
one port with the same speed, full duplex and the same MAC to be a single logical port, thus the
logical port aggregates the bandwidth of these ports. This means you can apply your current
Ethernet equipment’s to build the bandwidth aggregation. For example, if there are three Fast
Ethernet ports aggregated in a logical port, then this logical port has bandwidth three times as high
as a single Fast Ethernet port has.
aggregation mode:
Set traffic distribution mode.
EXAMPLE:
aggregation group:
Configure the link aggregation group.
EXAMPLE:
EX26262F Managed Switch Users Guide - CLI
- 17 -
Mode
Privileged exec
Syntax:
show aggregation [ mode ] [ | {begin | exclude | include } <LINE>]
Parameter:
mode Traffic distribution mode
| Output modifiers
begin Begin with the line that matches
exclude Exclude lines that match
include Include lines that match
<LINE> String to match output lines
EX26262F# show aggregation Mode
Aggregation Mode:
SMAC : Enabled
DMAC : Disabled
IP : Enabled
Port : Enabled
show aggregation:
Display aggregation configurations on the switch.
EXAMPLE:
EX26262F Managed Switch Users Guide - CLI
- 18 -
ARP-inspection Commands
Mode:
Global config
Syntax:
[no] ip arp inspection
ip arp inspection entry interface <port_type> <in_port_type_id> <vlan_var>
<mac_var> <ipv4_var>
ip arp inspection translate [ interface <port_type> <in_port_type_id> <vlan_var>
<mac_var> <ipv4_var> ]
ip arp inspection vlan <in_vlan_list>
ip arp inspection vlan <in_vlan_list> logging { deny | permit | all }
Parameter:
inspection ARP inspection
entry arp inspection entry
interface arp inspection entry interface config
<port_type> Port type in Fast, Giga ethernet
<port_type_id> Port ID in the format of switch-no/port-no
<vlan_id> Select a VLAN id to configure
<mac_ucast> Select a MAC address to configure
<ipv4_ucast> Select an IP Address to configure
deny log denied entries
permit log permitted entries
all log all entries
translate arp inspection translate all entries
vlan arp inspection vlan setting
<vlan_list> arp inspection vlan list
Arp inspection
The section describes to configure the ARP Inspection parameters of the switch. You could use the
ARP Inspection configure to manage the ARP table.
ip arp inspection:
Add ARP inspection static entry.
EX26262F Managed Switch Users Guide - CLI
- 19 -
Mode:
Privilged exec
Syntax:
show ip arp
show ip arp inspection [ interface {<port_type> <port_type_list>} | vlan
<vlan_list> ]
show ip arp inspection entry [ dhcp-snooping | static ] [ interface <port_type>
<port_type_list> ]
Parameter:
inspection ARP inspection
interface arp inspection entry interface config
<port_type> Gigabitethernet
<port_type_list> Port list in 1/1-26 for Gigabitethernet
EX26262F# show ip arp
169.254.0.1 via VLAN1:00-e0-b3-3f-18-65
192.168.1.11 via VLAN1:00-e0-b3-3f-18-65
192.168.1.199 via VLAN1:30-65-ec-91-98-20
192.168.1.254 (Incomplete)
show ip arp:
Display the ARP inspection configuration information.
EXAMPLE:
EX26262F Managed Switch Users Guide - CLI
- 20 -
Banner Commands
Mode:
Global config
Syntax:
banner [ motd ] <banner>
banner exec <banner>
banner login <banner>
Parameter:
<LINE> c banner-text c, where 'c' is a delimiting character
exec Set EXEC process creation banner
login Set login banner
motd Set Message of the Day banner
banner:
Define a login banner
EX26262F Managed Switch Users Guide - CLI
- 21 -
Clock Commands
Mode:
Global config
Syntax:
clock set <icliDate> <icliTime>
clock summer-time <word16> date [ <start_month_var> <start_date_var>
<start_year_var> <start_hour_var> <end_month_var> <end_date_var>
<end_year_var> <end_hour_var> [ <offset_var> ] ]
clock summer-time <word16> recurring [ <start_week_var> <start_day_var>
<start_month_var> <start_hour_var> <end_week_var> <end_day_var>
<end_month_var> <end_hour_var> [ <offset_var> ] ]
clock timezone <word_var> <hour_var> [ <minute_var> ]
Parameter:
set set clock
summer-time Configure summer (daylight savings) time
timezone Configure time zone
<date> yyyy/mm/dd
<time> hh:mm:ss
<2000-2097> Year to start
hh:mm Time to start (hh:mm)
<1-12> Month to end
<1-31> Date to end
<2000-2097> Year to end
hh:mm Time to end (hh:mm)
<1-1440> Offset to add in minutes
<1-5> Week number to start
<1-7> Weekday to start
<1-12> Month to start
clock:
Configure time and clock settings
EX26262F Managed Switch Users Guide - CLI
- 22 -
Copy Commands
Mode:
Privilged exec
Syntax:
copy { startup-config | running-config | < flash:filename |
tftp://server/path-and-filename > } { startup-config | running-config | <
flash:filename | tftp://server/path-and-filename > } [ syntax-check ][ | { begin |
exclude | include }{ <LINE >}]
Parameter:
flash:filename | tftp://server/path-and-filename File in FLASH or on TFTP
server
running-config Currently running configuration
startup-config Startup configuration
| Output modifiers
syntax-check Perform syntax check on source
configuration
begin Begin with the line that matches
exclude Exclude lines that match
include Include lines that match
<LINE> String to match output lines
copy
Copy from source to destination.
EX26262F Managed Switch Users Guide - CLI
- 23 -
DHCP Commands
Mode:
Privilged exec
Syntax:
ip dhcp retry interface vlan <vlan_id>
Parameter:
dhcp Dhcp commands
retry Restart the DHCP query process
interface Interface
vlan Vlan interface
<vlan_id> Vlan ID
Mode:
Global config
Syntax:
[no] ip dhcp excluded-address <low_ip> [ <high_ip> ]
[no] ip dhcp pool <pool_name>
[no] ip dhcp relay
[no] ip dhcp relay information option
[no] ip dhcp relay information policy { drop | keep | replace }
[no] ip dhcp server
[no] ip dhcp snooping
ip helper-address <v_ipv4_ucast>
Parameter:
drop Drop the package when receive a DHCP message that already contains
relay information
keep Keep the original relay information when receive a DHCP message that
already contains it
replace Replace the original relay information when receive a DHCP message
that already contains it.
DHCP
Dynamic Host Configuration Protocol (DHCP) automatically provides an Internet Protocol (IP) host
with its IP address and other configuration information such as the subnet mask and default
gateway.
ip dhcp (privileged exec):
Restart the DHCP query process
ip dhcp (global):
DHCP settings and configuration.
EX26262F Managed Switch Users Guide - CLI
- 24 -
show ip dhcp:
Mode:
Privilged exec
Syntax:
show ip dhcp relay [ statistics ]
show ip dhcp snooping [ statistics ] [ interface <port_type> <port_type_list> ]
show ip dhcp detailed statistics { server | client | snooping | relay |
normal-forward | combined } [ interface <port_type_list> ]
Parameter:
interface arp inspection entry interface config
<port_type> Gigabitethernet
<port_type_list> Port list in 1/1-26 for Gigabitethernet
Syntax:
ping ip <word1-255> [ repeat <Count : 1-60> ] [ size <Size : 2-1452> ] [ interval
<Seconds : 0-30> ]
ping ipv6 <ipv6_addr> [ repeat <Count : 1-60> ] [ size <Size : 2-1452> ] [ interval
<Seconds : 0-30> ] [ interface vlan <vlan_id> ]
Parameter:
ip IP (ICMP) echo
<word1-255> ICMP destination address
repeat Specify repeat count
<Count : 1-60> 1-60; Default is 5
size Specify datagram size
<Size : 2-1452> 2-1452; Default is 56 (excluding MAC, IP and ICMP headers)
interval Specify repeat interval
<Seconds : 0-30> 0-30; Default is 0
ipv6 IPv6 (ICMPv6) echo
<ipv6_addr> ICMPv6 destination address
repeat Specify repeat count
<1-60> 1-60; Default is 5
size Specify datagram size
<2-1452> 2-1452; Default is 56 (excluding MAC, IP and ICMP headers)
interval Specify repeat interval
<0-30> 0-30; Default is 0
interface Select an interface to configure
vlan VLAN Interface
<vlan_id> VLAN identifier(s): VID
Display DHCP information.
Diagnostic Commands
ping:
Send ICMP echo messages
EX26262F Managed Switch Users Guide - CLI
- 25 -
veriphy:
Mode:
Privileged exec
Syntax:
show interface <port_type_list> veriphy
Parameter:
<port-list> Port list, available value is from 1 to 10B format:1,3-5
* All ports
Mode:
Global config
Syntax:
ip dns proxy
Parameter:
none
EX26262F# show interface * veriphy
Starting VeriPHY - Please wait
Interface Pair A Length Pair B, Length Pair C Length Pair D Length
---------------------- ------ ------ -------------- ------ ------ ------
------GigabitEthernet 1/1 Open 0 Open 0 Open 0 Open 0
GigabitEthernet 1/2 Open 0 Open 0 Open 0 Open 0
GigabitEthernet 1/3 OK 0 OK 0 OK 0 OK 0
GigabitEthernet 1/4 Open 0 Open 0 Open 0 Open 0
Run cable diagnostics
EXAMPLE:
DNS Proxy
ip dns proxy:
Set dns proxy service
EX26262F Managed Switch Users Guide - CLI
- 26 -
dot1x Commands
Syntax:
dot1x initialize [ interface ( <port_type> [ <plist> ] ) ]
Parameter:
initialize Force re-authentication immediately
interface Interface
* All switches or All ports
Gigabitethernet 1 GigabitEthernet port
<port_type_list> Port list in 1/1-26 for Gigabitethernet
Syntax:
[no] dot1x authentication timer inactivity <v_10_to_100000>
[no] dot1x authentication timer re-authenticate <v_1_to_3600>
[no] dot1x feature { [ guest-vlan ] [ radius-qos ] [ radius-vlan ] }*1
[no] dot1x guest-vlan <value>
[no] dot1x guest-vlan supplicante
[no] dot1x max-reauth-req <1-255>
[no] dot1x re-authentication
[no] dot1x system-auth-control
[no] dot1x timeout quiet-period <v_10_to_1000000>
[no] dot1x timeout tx-period <v_1_to_65535>
Parameter:
authentication Authentication
feature Globally enables/disables a dot1x feature functionality
guest-vlan Guest VLAN
max-reauth-req Guest VLAN ID used when entering the Guest VLAN.
re-authentication Set Re-authentication state
system-auth-control Set the global NAS state
timeout timeout
timer timer
inactivity Time in seconds between check for activity on
successfully authenticated MAC addresses.
re-authenticate The period between re-authentication attempts in
seconds
<10-1000000> seconds
dot1x (privileged exec):
IEEE Standard for port-based Network Access Control.
dot1x (global):
IEEE Standard for port-based Network Access Control.
EX26262F Managed Switch Users Guide - CLI
- 27 -
<1-3600> seconds
guest-vlan Globally enables/disables state of guest-vlan
radius-qos Globally enables/disables state of RADIUS-assigned
QoS.
radius-vlan Globally enables/disables state of RADIUS-assigned
VLAN.
<1-4095> The number of times a Request Identity EAPOL frame
is sent without response before considering entering the Guest VLAN.
supplicant The switch remembers if an EAPOL frame has been
received on the port for the life-time of the port. Once the switch considers
whether to enter the Guest VLAN, it will first check if this option is enabled or
disabled. If disabled (unchecked; default), the switch will only enter the Guest
VLAN if an EAPOL frame has not been received on the port for the life-time of the
port. If enabled (checked), the switch will consider entering the Guest VLAN even
if an EAPOL frame has been received on the port for the life-time of the port.
<1-255> number of times
quiet-period Time in seconds before a MAC-address that failed
authentication gets a new authentication chance.
tx-period the time between EAPOL retransmissions.
<10-1000000> seconds
<1-65535> seconds
Syntax:
dot1x re-authenticate
dot1x port-control { force-authorized | force-unauthorized | auto | single | multi |
mac-based }
no dot1x port-control
dot1x guest-vlan
dot1x radius-qos
dot1x radius-vlan
Parameter:
none
dot1x (interface):
IEEE Standard for port-based Network Access Control.
EX26262F Managed Switch Users Guide - CLI
- 28 -
Enable / Disable
Mode:
Global config
Syntax:
enable password [ <level> <1-15> ] <WORD>
enable secret { 0 | 5 } [< level> <1-15> ] <WORD>
Parameter:
password Assign the privileged level clear password
secret Assign the privileged level secret
WORD The UNENCRYPTED (cleartext) password
level Set exec level password
<1-15> Level number
0 Specifies an UNENCRYPTED password will follow
5 Specifies an ENCRYPTED secret will follow
Mode:
Privilged exec
Syntax:
disable <0-15>
Parameter:
<0-15> Privilege level
EX26262F(config)# enable password level 10 999
EX26262F(config)#
enable:
Modify password parameters
Example:
disable:
Turn off privileged commands
EX26262F Managed Switch Users Guide - CLI
- 29 -
Event Notifications
Mode:
Global config
Syntax:
event group <group_name> { level <lvl> | syslog { enable | disable } | trap
{ enable | disable } | smtp { enable | disable } | ipush { enable | disable } }
Parameter:
Group Configure trap event severity level
<word32> ACL, ACL_Log, Access_Mgmt, Auth_Failed, Cold_Start,
Config_Info, FAN_FAIL, Firmware_Upgrade, Import_Export, LACP, Link_Status,
Login, Logout, Loop_Protect, Mgmt_IP_Change, Module_Change, NAS,
Password_Change, Poe_Auto_Check, Port_Security, Temperature, VLAN,
Voltage, Warm_Start
EX26262F(config)# event group VLAN trap enable
EX26262F(config)#
event:
Set Trap event severity level.
Example:
EX26262F Managed Switch Users Guide - CLI
- 30 -
Hostname
Mode:
Global config
Syntax:
hostname < WORD >
Parameter:
none
Mode:
Global config
Syntax:
green-ethernet eee optimize-for-power
Parameter:
eee Powering down of PHYs when there is no traffic.
optimize-for-power Set if EEE shall be optimized for least power consumption
(else optimized for least traffic latency).
hostname:
Set system’s network name
Green Ethernet
green-ethernet:
Set Green Ethernet (Power reduction)
EX26262F Managed Switch Users Guide - CLI
- 31 -
Mac Address Table
Mode:
Global config
Syntax:
[no] mac address-table aging-time <0, 10-1000000>
[no] mac address-table static <mac_addr> vlan <vlan_id> interface <port_type>
<port_type_list>
Parameter:
<0, 10-1000000> Aging time in seconds, 0 disables aging
static Static MAC address
<mac_addr> 48 bit MAC address: xx:xx:xx:xx:xx:xx
vlan VLAN keyword
<vlan_id> VLAN IDs 1-4095
interface Select an interface to configure
<port_type> Port type * or Gigabitethernet
* All switches or All ports
Gigabitethernet 1 Gigabit Ethernet port
<port_type_list> Port list in 1/1-26 for Gigabitethernet
Mode:
Privileged exec
Syntax:
show mac address-table [ conf | static | aging-time | { { learning | count }
[ interface <port_type> <port_type_list> ] } | { address <mac_addr> [ vlan
<vlan_id> ] } | vlan <vlan_id> | interface <port_type> <port_type_list> ] [ | {begin |
exclude | include } <LINE>]
Parameter:
address-table Mac Address Table
conf User added static mac addresses
EX26262F(config)# mac address-table aging-time 3333
aging-time:
Configure the aging-time of MAC address entries
EXAMPLE:
show mac address-table:
Display the MAC Table or configuration information what set on the
switch
EX26262F Managed Switch Users Guide - CLI
- 32 -
static All static mac addresses
aging-time Aging time
learning Learn/disable/secure state
count Total number of mac addresses
interface Select an interface to configure
<port_type> Gigabitethernet
mac address-table learning:
Mode:
Intefrace config
Syntax:
mac address-table learning [secure]
Parameter:
secure Port secure mode
Enable learning on a port
EX26262F Managed Switch Users Guide - CLI
- 33 -
Mode:
Privileged exec
Syntax:
show version
Parameter:
none
Mode:
Privileged exec
Syntax:
firmware swap
Parameter:
none
EX26262F# show version
MEMORY : Total=78337 KBytes, Free=53703 KBytes, Max=53536 KBytes
FLASH : 0x40000000-0x41ffffff, 512 x 0x10000 blocks
MAC Address : 00-e0-b3-3f-20-8e
Previous Restart : Cold
System Contact :
System Name : EX26262F
System Location :
System Time : 2011-01-02T07:01:13+00:00
System Uptime : 1d 07:01:13
Active Image
-----------Image : managed
Version : EX26262F (standalone) v6.54.2173
Date : 2016-08-29T15:32:24+08:00
Alternate Image
--------------Image : managed.bk
Version :
Date :
Firmware Commands
firmware
This section describes how to upgrade Firmware. The Switch can be enhanced with more
value-added functions by installing firmware upgrades.
show version:
Display the active and alternate firmware image version information
EXAMPLE:
firmware swap:
Swap the active firmware image to alternate firmware image or reverse
between them
EX26262F Managed Switch Users Guide - CLI
- 34 -
Mode:
Privileged exec
Syntax:
firmware upgrade <ipv6-address> <word>
firmware upgrade <ip-hostname> <word>
Parameter:
<word> Firmware image file name
NOTE: This page facilitates an update of the firmware
controlling the switch. Uploading software will update all
managed switches to the location of a software image and
click. After the software image is uploaded, a page announces
that the firmware update is initiated. After about a minute, the
firmware is updated and all managed switches restart. the
switch restarts.
W
ARNING
:
While the firmware is being updated, Web access
appears to be defunct. The front LED flashes Green/Off with a
frequency of 10 Hz while the firmware update is in progress.
Do not restart or power off the device at this time or the
switch may fail to function afterwards.
firmware upgrade:
Upgrade the system firmware to active or alternate division
EX26262F Managed Switch Users Guide - CLI
- 35 -
Mode:
Global config
Syntax:
gvrp
Parameter:
none
Mode:
Global config
Syntax:
gvrp time { [ join-time <1-20> ] [ leave-time <60-300> ] [ leave-all-time
<1000-5000> ] }*1
Parameter:
time config gvrp timer value in units of centi seconds [cs]
Mode:
Global config
Syntax:
gvrp max-vlans <1-4095>
Parameter:
none
GVRP Commands
GVRP
GVRP is an application based on Generic Attribute Registration Protocol (GARP), mainly used to
automatically and dynamically maintain group membership information of VLANs. GVRP provides
VLAN registration service through a GARP application. It makes use of GARP Information
Declaration (GID) to maintain the ports associated with their attribute database and GARP
Information Propagation (GIP) to communicate among switches and end stations. With GID
information and GIP, GVRP state machine maintain the contents of Dynamic VLAN Registration
Entries for each VLAN and propagate these information to other GVRP-aware devices to setup and
update their knowledge database, the set of VLANs associated with currently active members, and
through which ports these members can be reached.
gvrp (global):
Enable or disable GVRP globally
gvrp time:
Config GARP protocol timer parameters. IEEE 802.1D-2004, clause 12.11.
gvrp max-vlans:
Set the number of VLANs that GVRP can control
EX26262F Managed Switch Users Guide - CLI
- 36 -
Mode:
Interface config
Syntax:
gvrp
Parameter:
none
Mode:
Interface config
Syntax:
gvrp join-request vlan <vlan_list>
Parameter:
none
Mode:
Interface config
Syntax:
gvrp leave-request vlan <vlan_list>
Parameter:
none
gvrp (interface):
Enable or disable GVRP on an interface
gvrp join-request:
Send a Join-Request for test purposes.
gvrp leave-request:
Send a leave-Request for test purposes.
EX26262F Managed Switch Users Guide - CLI
- 37 -
Mode:
Privileged exec
Syntax:
show ip http server secure status
Parameter:
none
Mode:
Global config
Syntax:
[no] ip http secure-server
Parameter:
none
Mode:
Global config
Syntax:
[no] ip http secure-redirect
Parameter:
none
HTTP Commands
show ip http:
display the secure HTTP web server status.
ip http secure-server:
Enable secure HTTP web server
ip http secure-redirect:
Enable secure HTTP web redirection. When the secure HTTP web server
is enabled, the feature automatically redirects non-secure HTTP web
connections to secure connections.
EX26262F Managed Switch Users Guide - CLI
- 38 -
Mode:
Global config or Interface config
Syntax:
[no] ip igmp snooping [VLAN, vlan_id]
Parameter:
none
Mode:
Global config
Syntax:
ip igmp unknown-flooding
Parameter:
none
Mode:
Global config
Syntax:
ip igmp host-proxy [ leave-proxy ]
Parameter:
none
Mode:
Global config
Syntax:
[no] ip igmp ssm-range <ipv4_mcast> <4-32>
Parameter:
none
IGMP Commands
ip igmp snooping:
Configure compatibility parameters on the switch
ip igmp unknown-flooding:
Flooding unregistered IPv4 multicast traffic
ip igmp host-proxy:
Configure IGMP proxy
ip igmp ssm-range:
IPv4 address range of Source Specific Multicast
EX26262F Managed Switch Users Guide - CLI
- 39 -
ip igmp snooping querier:
Mode:
Config-if-vlan
Syntax:
ip igmp snooping querier { election | address <ipv4_ucast> }
no ip igmp snooping querier { election | address }
Parameter:
none
Mode:
Config-if-vlan
Syntax:
ip igmp snooping compatibility { auto | v1 | v2 | v3 }
no ip igmp snooping compatibility
Parameter:
none
Mode:
Config-if-vlan
Syntax:
ip igmp snooping priority <0-7>
no ip igmp snooping priority
Parameter:
none
Mode:
Config-if-vlan
Syntax:
ip igmp snooping robustness-variable <1-255>
no ip igmp snooping robustness-variable
Parameter:
none
Configure IGMP querier
ip igmp snooping compatibility:
Set IGMP compatibility
ip igmp snooping priority:
Set IGMP priority
ip igmp snooping robustness-variable:
Set IGMP priority
EX26262F Managed Switch Users Guide - CLI
- 40 -
ip igmp snooping query-interval:
Mode:
Config-if-vlan
Syntax:
ip igmp snooping query-interval <1-31744>
no ip igmp snooping query-interval
Parameter:
<1-31744> Interval in tenths of seconds
Mode:
Config-if-vlan
Syntax:
ip igmp snooping query-max-response-time <0-31744>
no ip igmp snooping query-max-response-time
Parameter:
<1-31744> Time in tenths of seconds
Mode:
Config-if-vlan
Syntax:
ip igmp snooping last-member-query-interval <0-31744>
no ip igmp snooping last-member-query-interval
Parameter:
<1-31744> Time in tenths of seconds
Mode:
Config-if-vlan
Syntax:
ip igmp snooping unsolicited-report-interval <0-31744>
no ip igmp snooping unsolicited-report-interval
Parameter:
<1-31744> Time in seconds
Mode:
Interface config
Syntax:
ip igmp snooping mrouter
Parameter:
none
Set IGMP query interval
ip igmp snooping query-max-response-time:
Set maximum response time for IGMP query
ip igmp snooping last-member-query-interval:
Set Last Member Query Interval in tenths of seconds
ip igmp snooping unsolicited-report-interval:
Set Unsolicited Report Interval in seconds
ip igmp snooping mrouter:
Multicast router port configuration
EX26262F Managed Switch Users Guide - CLI
- 41 -
Mode:
Interface config
Syntax:
ip igmp snooping max-groups <1-10>
no ip igmp snooping max-groups
Parameter:
<1-10> Maximum number of groups
Mode:
Interface config
Syntax:
ip igmp snooping filter <word16>
no ip igmp snooping filter
Parameter:
<word16> Profile name
ip igmp snooping max-groups:
IGMP group throttling configuration
ip igmp snooping filter:
Access control on IGMP multicast group registration
EX26262F Managed Switch Users Guide - CLI
- 42 -
Interface Configuration Commands
Mode:
Config-if
Syntax:
[no] shutdown
Parameter:
none
Mode:
Config-if
Syntax:
speed {2500 | 1000 | 100 | 10 | auto {[10] [100] [1000]} }
no speed
Parameter:
10 10Mbps
100 100Mbps
1000 1Gbps
Mode:
Config-if
Syntax:
duplex { half | full | auto [ half | full ] }
no duplex
Parameter:
none
Mode:
Config-if
Syntax:
media-type { rj45 | sfp | dual }
no media-type
Parameter:
none
shutdown:
Shut down an interface
speed:
Configures interface speed.
duplex:
Configures interface speed.
media-type:
Configure the interface media type.
EX26262F Managed Switch Users Guide - CLI
- 43 -
flowcontrol:
Mode:
Config-if
Syntax:
flowcontrol { on | off }
no flowcontrol
Parameter:
none
Mode:
Config-if
Syntax:
[no] excessive-restart
Parameter:
none
Mode:
Config-if
Syntax:
mtu <Max_frame>
no mtu
Parameter:
Max_frame: Number from 1518 to 9600
Mode:
Config-if
Syntax:
switchport mode {access | trunk | hybrid}
no switchport mode
switchport hybrid port-type { unaware | c-port | s-port | s-custom-port }
no switchport hybrid port-type
switchport hybrid ingress-filtering
switchport hybrid acceptable-frame-type { all | tagged | untagged }
no switchport hybrid acceptable-frame-type
switchport hybrid egress-tag {none | all [except-native]}
no switchport hybrid egress-tag
Parameter:
none
Configure flow control for the interface.
excessive-restart:
Configure backoff algorithm in half duplex mode.
mtu:
Specify maximum frame size (1518 - 9600 bytes).
switchport:
Specify switching mode.
EX26262F Managed Switch Users Guide - CLI
- 44 -
IPMC Commands
Mode:
Global config
Syntax:
ipmc profile
ipmc profile <profile_name>
ipmc range <entry_name> { <v_ipv4_mcast> [ <v_ipv4_mcast_1> ]
| <v_ipv6_mcast> [ <v_ipv6_mcast_1> ] }
Parameter:
profile IPMC profile configuration
range A range of IPv4/IPv6 multicast addresses for the profile
< word16> Range entry name in 16 char's
<ipv4_mcast> Valid IPv4 multicast address
<ipv6_mcast> Valid IPv6 multicast address
Mode:
Global config
Syntax:
[no] ip name-server { <v_ipv4_addr> | dhcp [ interface vlan
<v_vlan_id> ] }
Parameter:
dhcp Dynamic Host Configuration Protocol
<v_vlan_id> VLANID
EX26262F(config)# ipmc profile test
EX26262F(config-ipmc-profile)#
ipmc:
IPv4 / IPv6 multicast configuration
EXAMPLE:
IP Name Server
ip name-server:
Configure DNS server information
EX26262F Managed Switch Users Guide - CLI
- 45 -
Mode:
Global config
Syntax:
[no] ip route <ipv4_addr> <ipv4_netmask> <ipv4_addr>
Parameter:
<ipv4_addr> IPV4 address of route
<ipv4_netmask> Mask in A.B.C.D format
<ipv4_addr> Gateway IP address
Mode:
Global config
Syntax:
[no] ip routing
Parameter:
none
Syntax:
[no] ip source binding interface <port_type_id> <vlan_id>
<ipv4_ucast> <mac_ucast>
[no] ip source binding interface <port_type_id> <vlan_id>
<ipv4_ucast> <ipv4_netmask>
[no] ip source binding interface <port_type> <in_port_type_id>
<vlan_var> <ipv4_var> <mac_var>
[no] ip verify source
[no] ip verify source limit <0-2>
[no] ip verify source translate
Parameter:
<port_type_id> Port ID in the format of switch-no/port-no, ex 1/1-26 for
Gigabitethernet
<vlan_id> Select a VLAN id to configure
EX26262F(config)# ip route 192.168.1.1 255.255.255.0 192.168.1.100
IP Route and Routing
ip route:
Add new IP route
EXAMPLE:
ip routing:
Enable IPv4 and IPv6 routing
IP Source Binding / Verify Source
ip source binding:
Configure IP source binding
EX26262F Managed Switch Users Guide - CLI
- 46 -
<ipv4_ucast> Select an IP Address to configure
<ipv4_netmask> Select a subnet mask to configure
<mac_ucast> Select a MAC address to configure
translate ip verify source translate all entries
Mode:
Global config
Syntax:
ipv6 mld host-proxy [ leave-proxy ]
ipv6 mld snooping
ipv6 mld snooping vlan <v_vlan_list>
ipv6 mld ssm-range <v_ipv6_mcast> <ipv6_prefix_length>
ipv6 mld unknown-flooding
ipv6 route <v_ipv6_subnet> { <v_ipv6_ucast> | interface vlan <v_vlan_id>
<v_ipv6_addr> }
Parameter:
mld Multicasat Listener Discovery
route Configure static routes
host-proxy MLD proxy configuration
snooping Snooping MLD
ssm-range IPv6 address range of Source Specific Multicast
unknown-flooding Flooding unregistered IPv6 multicast traffic
leave-proxy MLD proxy for leave configuration
vlan MLD VLAN
<vlan_list> VLAN identifier(s): VID
<ipv6_mcast> Valid IPv6 multicast address
X:X:X:X::X/<0-128> IPv6 prefix x:x::y/z
EX26262F(config)# ipv6 mld host-proxy leave-proxy
EX26262F(config)# ipv6 mld snooping vlan 1
EX26262F(config)#
IPv6 Commands
ipv6:
All IPV6 configuration comands.
EXAMPLE:
EX26262F Managed Switch Users Guide - CLI
- 47 -
Mode:
Global config
Syntax:
lacp system-priority <1-65535>
Parameter:
<1-65535>: LACP key
Mode:
Config-if-vlan
Syntax:
lacp
lacp key { <1-65535> | auto }
lacp role { active | passive }
lacp timeout { fast | slow }
lacp port-priority <1-65535>
Parameter:
<1-65535> Priority value, lower means higher priority
LACP Commands
lacp:
Configure the LACP key.
lacp (interface):
Configure LACP mode.
EX26262F Managed Switch Users Guide - CLI
- 48 -
Mode:
Global config
Syntax:
lldp holdtime <2-10>
lldp med datum { wgs84 | nad83_navd88 | nad83_mllw }
lldp med fast <1-10>
lldp med location-tlv altitude { meters | floors } <word11>
lldp med location-tlv civic-addr { country | state | county | city | district | block |
street | leading-street-direction | trailing-street-suffix | street-suffix | house-no |
house-no-suffix | landmark | additional-info | name | zip-code | building |
apartment | floor | room-number | place-type | postal-community-name | p-o-box |
additional-code } <string250>
lldp med location-tlv elin-addr <dword25>
lldp med location-tlv latitude { north | south } <word8>
lldp med location-tlv longitude { west | east } <word9>
lldp med media-vlan policy-list <range_list>
lldp med media-vlan-policy <0-31> { voice | voice-signaling |
guest-voice-signaling | guest-voice | softphone-voice | video-conferencing |
streaming-video | video-signaling } { tagged <vlan_id> | untagged } [ l2-priority
<0-7> ] [ dscp <0-63> ]
lldp reinit <1-10>
lldp timer <5-32768>
lldp transmission-delay <1-8192>
Parameter:
holdtime Sets LLDP hold time
med Media Endpoint Discovery.
reinit LLDP tx reinitialization delay in seconds.
timer Sets LLDP TX interval
transmission-delay Sets LLDP transmision-delay.
<2-10> 2-10 seconds.
<1-10> 1-10 seconds.
<5-32768> 5-32768 seconds.
<1-8192> 1-8192 seconds.
datum Datum (geodetic system) type.
fast Number of times to repeat LLDP frame transmission
at
fast start.
LLDP Commands
lldp:
Configure LLDP
EX26262F Managed Switch Users Guide - CLI
- 49 -
location-tlv LLDP-MED Location Type Length Value parameter.
media-vlan-policy Use the media-vlan-policy to create a policy, which
can be assigned to an interface.
nad83_mllw Mean lower low water datum 1983
nad83_navd88 North American vertical datum 1983
wgs84 World Geodetic System 1984
altitude Altitude parameter
meter Altitude value
floors Altitude value
civic-addr Civic address information and postal information
country The two-letter ISO 3166 country code in capital ASCII
chars
state National subdivisions (state, canton, region, province,
prefecture).
county County, parish, gun (Japan), district.
city City, township, shi (Japan) - Example: Copenhagen.
district City division, borough, city district, ward, chou (Japan).
block Neighbourhood, block.
street Street - Example: Poppelvej.
leading-street-direction Leading street direction - Example: N.
trailing-street-suffix Trailing street suffix - Example: SW.
street-suffix Street suffix - Example: Ave, Platz.
house-no House number - Example: 21.
house-no-suffix House number suffix - Example: A, 1/2.
landmark Landmark or vanity address - Example: Columbia
University.
additional-info Additional location info - Example: South Wing.
name Name (residence and office occupant)
zip-code Postal/zip code - Example: 2791.
building Building (structure) - Example: Low Library.
apartment Unit (Apartment, suite) - Example: Apt 42.
floor Floor - Example: 4.
room-number Room number - Example: 450F.
place-type Place type - Example: Office.
postal-community-name Postal community name - Example: Leonia.
p-o-box Post office box (P.O. BOX) - Example: 12345.
additional-code Additional code - Example: 1320300003.
<string250> Value for the corresponding selected civic address.
elin-addr Emergency Location Identification Number,
<dword25> ELIN value
north Setting latitude direction to north.
south Setting latitude direction to south.
EX26262F Managed Switch Users Guide - CLI
- 50 -
<word8> Latitude degrees (0.0000-90.0000).
policy-list Assignment of policies.
<range_list> Policies to assign to the interface.
<0-31> Policy id for the policy which is created.
voice Create a voice policy.
voice-signaling Create a voice signaling policy.
guest-voice-signaling Create a guest voice signaling policy.
guest-voice Create a guest voice policy.
softphone-voice Create a softphone voice policy.
video-conferencing Create a video conferencing policy.
streaming-video Create a streaming video policy.
video-signaling Create a video signaling policy.
tagged The policy uses tagged frames.
<vlan_id> The VLAN the policy uses tagged frames.
untagged The policy uses un-tagged frames.
l2-priority Layer 2 priority.
<0-7> Priority 0-7
dscp Differentiated Services Code Point.
<0-63> DSCP value 0-63.
EX26262F Managed Switch Users Guide - CLI
- 51 -
Mode
Global config
Syntax:
logging host { <ipv4_ucast> | <hostname> }
logging level { info | warning | error }
logging on
Parameter:
host host
<ipv4_ucast> IP address of the log server
<hostname> Domain name of the log server
level level
info Information
warning Warning
error Error
on Enable syslog server
Mode
Global config
Syntax:
loop-protect
loop-protect shutdown-time <0-604800>
loop-protect transmit-time <1-10>
Parameter:
shutdown-time Loop protection shutdown time interval
<0-604800> Shutdown time in second
transmit-time Loop protection transmit time interval
<1-10> Transmit time in second
Logging Commands
logging:
Configure syslog.
Loop Protect
loop-protect (global):
Loop protection configuration.
loop-protect (interface):
Loop protection configuration.
EX26262F Managed Switch Users Guide - CLI
- 52 -
Mode
Config-if
Syntax:
loop-protect
loop-protect action { [shutdown] [log] }*1
no loop-protect action
loop-protect tx-mode
Parameter:
none
Mode:
Global config
Syntax:
monitor destination interface <port_type> <port_type_id>
monitor source { interface <port_type> <port_type_list> | cpu } { both | rx | tx }
Parameter:
destination The destination port.
interface Interface to mirror traffic to.
source The source port.
interface Mirrort interface traffic.
<port_type> 1 Gigabit Ethernet port
* All switches or all ports
<port_type_list> Port list in 1/1-26.
cpu Mirrot CPU traffic.
both Mirror both ingress and egress traffic.
rx Setting source port to rx will mirror bothingress traffic.
tx Setting source port to tx will mirror both egress traffic.
<port_type> Port type in Gigabitethernet
<port_type_list> Port list in 1/1-26 for Gigabitethernet
Port Mirroring and Monitoring
monitor:
Set mirroring and monitoring configurations
EX26262F Managed Switch Users Guide - CLI
- 53 -
Syntax:
ipv6 mld snooping
ipv6 mld unknown-flooding
ipv6 mld host-proxy [ leave-proxy ]
ipv6 mld ssm-range <ipv6_mcast> <8-128>
no ipv6 mld ssm-range
ipv6 mld snooping vlan <vlan_list>
no ipv6 mld snooping vlan [ <vlan_list> ]
ipv6 mld snooping immediate-leave
ipv6 mld snooping mrouter
ipv6 mld snooping max-groups <1-10>
no ipv6 mld snooping max-groups
ipv6 mld snooping filter <word16>
no ipv6 mld snooping filter
ipv6 mld snooping
ipv6 mld snooping querier election
ipv6 mld snooping compatibility { auto | v1 | v2 }
no ipv6 mld snooping compatibility
ipv6 mld snooping priority <0-7>
no ipv6 mld snooping priority
ipv6 mld snooping robustness-variable <1-255>
no ipv6 mld snooping robustness-variable
ipv6 mld snooping query-interval <1-31744>
no ipv6 mld snooping query-interval
ipv6 mld snooping query-max-response-time <0-31744>
no ipv6 mld snooping query-max-response-time
ipv6 mld snooping last-member-query-interval <0-31744>
no ipv6 mld snooping last-member-query-interval
ipv6 mld snooping unsolicited-report-interval <0-31744>
no ipv6 mld snooping unsolicited-report-interval
Parameter:
<vlan-list>: VLAN list, available value is from 1 to 4094 format: 1,3-5
Forced-MLDv1: Set MLDv1 of MLD operating on hosts and routers
MLD Commands
ipv6 mld:
Set Version of MLD Operating on Hosts and Routers.
EX26262F Managed Switch Users Guide - CLI
- 54 -
Forced-MLDv2: Set MLDv2 of MLD operating on hosts and routers
MLD-Auto: Set auto mode of MLD operating on hosts and routers
<0-31744>: Range:0~31744 tenths of sec, default:100 tenths of sec.
Mode:
Global config
Syntax:
[no] mvr
[no] mvr name <mvr_name> channel <profile_name>
[no] mvr name <mvr_name> frame priority <cos_priority>
[no] mvr name <mvr_name> frame tagged
[no] mvr name <mvr_name> igmp-address <v_ipv4_ucast>
[no] mvr name <mvr_name> last-member-query-interval <ipmc_lmqi>
[no] mvr name <mvr_name> mode { dynamic | compatible }
[no] mvr vlan <v_vlan_list> [ name <mvr_name> ]
[no] mvr vlan <v_vlan_list> channel <profile_name>
[no] mvr vlan <v_vlan_list> frame priority <cos_priority>
[no] mvr vlan <v_vlan_list> frame tagged
[no] mvr vlan <v_vlan_list> igmp-address <v_ipv4_ucast>
[no] mvr vlan <v_vlan_list> last-member-query-interval <ipmc_lmqi>
[no] mvr vlan <v_vlan_list> mode { dynamic | compatible }
MVR Commands
MVR
The MVR feature enables multicast traffic forwarding on the Multicast VLAN. In a multicast
television application, a PC or a television with a set-top box can receive the multicast stream.
Multiple set-top boxes or PCs can be connected to one subscriber port, which is a switch port
configured as an MVR receiver port. When a subscriber selects a channel, the set-top box or PC
sends an IGMP join message to Switch A to join the appropriate multicast. Uplink ports that send
and receive multicast data to and from the multicast VLAN are called MVR source ports.
mvr:
Configure MVR
EX26262F Managed Switch Users Guide - CLI
- 55 -
Parameter:
name MVR multicast name
<word16> MVR multicast VLAN name
channel MVR channel configuration
<word16> Profile name in 16 char's
frame MVR control frame in TX
priority Interface CoS priority
<0-7> CoS priority ranges from 0 to 7
tagged Tagged IGMP/MLD frames will be sent
igmp-address MVR address configuration used in IGMP
<ipv4_ucast> A valid IPv4 unicast address MVR multicast VLAN name
last-member-query-interval Last Member Query Interval in tenths of seconds
<0-31744> 0 - 31744 tenths of seconds
mode MVR mode of operation
dynamic Dynamic MVR operation mode
compatible Compatible MVR operation mode
vlan MVR multicast vlan
<vlan_list> MVR multicast VLAN list
channel MVR channel configuration
<word16> Profile name in 16 char's
frame MVR control frame in TX
priority Interface CoS priority
<0-7> CoS priority ranges from 0 to 7
igmp-address MVR address configuration used in IGMP
<ipv4_ucast> A valid IPv4 unicast address
<vlan_list> MVR multicast VLAN list
last-member-query-interval Last Member Query Interval in tenths of
seconds
<0-31744> 0 - 31744 tenths of seconds
compatible Compatible MVR operation mode
Mode:
Global config
Syntax:
ntp
Network Time Protocol
ntp:
Configure NTP
EX26262F Managed Switch Users Guide - CLI
- 56 -
ntp server <1-5> ip-address <hostname>
ntp server <1-5> ip-address <ipv4_ucast>
ntp server <1-5> ip-address <ipv6_ucast>
Parameter:
server Configure NTP server
<1-5> index number
ip-address ip address
<ipv4_ucast> ipv4 address
<ipv6_ucast> ipv6 address
<hostname> domain name
Syntax:
poe management mode { class-consumption | class-reserved-power |
allocation-consumption | allocation-reserved-power | lldp-consumption |
lldp-reserved-power }
no poe management mode
poe ping-check { enable | disable }
poe select-all <port_list>
poe supply sid <1~16> <1-2000>
no poe supply [sid <1~16>]
no poe schedule-all <range_list>
poe delay-mode <range_list>
no poe delay-mode <range_list>
poe delay-time <range_list> <0-300>
Parameter:
management Use management mode to configure PoE power
management method.
select-all Configure PoE Schedule mode.
Ping-check Enable/Disable POE Ping Check.
Mode PoE Power Management Mode
allocation-consumption Max. port power determined by allocation, and
Power Over Ethernet
poe (global):
Configure power over Ethernet
EX26262F Managed Switch Users Guide - CLI
- 57 -
power is managed according to power consumption.
allocation-reserved-power Max. port power determined by alocated, and
power is managed according to reserved power.
class-consumption Max. port power determined by class, and power
is managed according to power consumption.
class-reserved-power Max. port power determined by class, and power
is managed according to reserved power.
lldp-consumption Max. port power determined by LLDP Media
protocol, and power is managed according to power consumption.
lldp-reserved-power Max. port power determined by LLDP Media
protocol, and power is managed according to reserved power.
poe (interface):
Syntax:
poe mode { standard | plus }
no poe mode
poe priority { low | high | critical }
no poe priority
poe power limit { <fword2.1> }
no poe power limit
[no] poe schedule-mode
[no] poe hour <0-23>
[no] poe Sun
[no] poe Mon
[no] poe Tue
[no] poe Wed
[no] poe Thr
[no] poe Fri
[no] poe Sat
Parameter:
management Use management mode to configure PoE power
management method.
select-all Configure PoE Schedule mode.
Ping-check Enable/Disable POE Ping Check.
Mode PoE Power Management Mode
allocation-consumption Max. port power determined by allocation, and
power is managed according to power consumption.
allocation-reserved-power Max. port power determined by alocated, and
power is managed according to reserved power.
class-consumption Max. port power determined by class, and power
is managed according to power consumption.
class-reserved-power Max. port power determined by class, and power
is managed according to reserved power.
lldp-consumption Max. port power determined by LLDP Media
protocol, and power is managed according to power consumption.
lldp-reserved-power Max. port power determined by LLDP Media
protocol, and power is managed according to reserved power.
Configure power over Ethernet
EX26262F Managed Switch Users Guide - CLI
- 58 -
Syntax:
port-security
port-security aging
port-security aging time <v_10_to_10000000>
Parameter:
aging Time in seconds between check for activity on learned
MAC addresses.
time Time in seconds between check for activity on learned
MAC addresses.
<10-10000000> seconds
Mode:
Global config
Syntax:
privilege { exec | configure | config-vlan | line | interface | if-vlan | ipmc-profile |
snmps-host | stp-aggr | dhcp-pool | rfc2544-profile } level <privilege> <cmd>
Parameter:
config-vlan VLAN Configuration Mode
configure Global configuration mode
dhcp-pool DHCP Pool Configuration Mode
exec Exec mode
if-vlan VLAN Interface Mode
interface Port List Interface Mode
Port security Commands
Port security
This section shows you to to configure the Port Security settings of the Switch. You can use the Port
Security feature to restrict input to an interface by limiting and identifying MAC addresses.
port-security:
Configure the action involved with exceeding a limit
Privilege level Commands
group:
Configure a privilege level group
EX26262F Managed Switch Users Guide - CLI
- 59 -
ipmc-profile IPMC Profile Mode
line Line configuration mode
rfc2544-profile RFC2544 Profile Mode
snmps-host SNMP Server Host Mode
stp-aggr STP Aggregation Mode
level Set privilege level of command
<LINE> Initial valid words and literals of the command to modify, in 128 char's
Mode:
Global config
Syntax:
qos map cos-dscp <0~7> dpl <dpl : 0~1> dscp { <DscpNum : 0-63> | { be | af11 |
af12 | af13 | af21 | af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 |
cs3 | cs4 | cs5 | cs6 | cs7 | ef | va } }
qos map dscp-classify { <dscpNum : 0~63> | { be | af11 | af12 | af13 | af21 | af22 |
af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5 | cs6 | cs7 |
ef | va } }
qos map dscp-cos { < dscpNum : 0~63> | { be | af11 | af12 | af13 | af21 | af22 |
af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5 | cs6 | cs7 |
ef | va } } cos <Cos : 0-7> dpl <dpl>
qos map dscp-egress-translation { < DscpNum : 0~63> | { be | af11 | af12 | af13 |
af21 | af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5
| cs6 | cs7 | ef | va } } <Dpl : 0~1> to { <Dscpnum : 0-63> | { be | af11 | af12 | af13 |
af21 | af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5
| cs6 | cs7 | ef | va } }
qos map dscp-ingress-translation { < DscpNum : 0~63> | { be | af11 | af12 | af13 |
af21 | af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5
| cs6 | cs7 | ef | va } } to { < DscpNum : 0-63> | { be | af11 | af12 | af13 | af21 | af22
| af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5 | cs6 | cs7 |
ef | va } }
Parameter:
cos-dscp Map for cos to dscp
dscp-classify Map for dscp classify enable
dscp-cos Map for dscp to cos
QoS Commands
QoS
The switch support four QoS queues per port with strict or weighted fair queuing scheduling. It
supports QoS Control Lists (QCL) for advance programmable QoS classification, based on IEEE
802.1p, Ethertype, VID, IPv4/IPv6 DSCP and UDP/TCP ports and ranges.
qos map:
Configure global QOS map/table
EX26262F Managed Switch Users Guide - CLI
- 60 -
dscp-egress-translation Map for dscp egress translation
dscp-ingress-translation Map for dscp ingress translation
dpl Specify drop precedence level
<Dpl : 0~1> Specific drop precedence level or range
dscp Specify DSCP
<DscpNum : 0-63> Specific DSCP
cos Specify class of QoS
<Cos : 0-7> Specific class of QoS
af11 Assured Forwarding PHB AF11(DSCP 10)
af12 Assured Forwarding PHB AF12(DSCP 12)
af13 Assured Forwarding PHB AF13(DSCP 14)
af21 Assured Forwarding PHB AF21(DSCP 18)
af22 Assured Forwarding PHB AF22(DSCP 20)
af23 Assured Forwarding PHB AF23(DSCP 22)
af31 Assured Forwarding PHB AF31(DSCP 26)
af32 Assured Forwarding PHB AF32(DSCP 28)
af33 Assured Forwarding PHB AF33(DSCP 30)
af41 Assured Forwarding PHB AF41(DSCP 34)
af42 Assured Forwarding PHB AF42(DSCP 36)
af43 Assured Forwarding PHB AF43(DSCP 38)
be Default PHB(DSCP 0) for best effort traffic
cs1 Class Selector PHB CS1 precedence 1(DSCP 8)
cs2 Class Selector PHB CS2 precedence 2(DSCP 16)
cs3 Class Selector PHB CS3 precedence 3(DSCP 24)
cs4 Class Selector PHB CS4 precedence 4(DSCP 32)
cs5 Class Selector PHB CS5 precedence 5(DSCP 40)
cs6 Class Selector PHB CS6 precedence 6(DSCP 48)
cs7 Class Selector PHB CS7 precedence 7(DSCP 56)
ef Expedited Forwarding PHB(DSCP 46)
va Voice Admit PHB(DSCP 44)
Mode:
Global config
Syntax:
qos qce refresh
qos qce { [ update ] } <Id : 1-256> [ { next <Id : 1-256> } | last ] [ ingress interface
*|Gigabitethernet <PORT_LIST> ] [ tag { tagged | untagged | any } ] [ vid
{ <vlan_list> | any } ] [ pcp { <pcp> | any } ] [ dei { <Dpl : 0-1> | any } ] [ smac
{ <mac_addr> | <oui> | any } ] [ dmac-type { unicast | multicast | broadcast | any } ]
[ frametype { any | { etype [ { <0x600-0x7ff,0x801-0x86dc,0x86de-0xffff> | any } ] }
| { llc [ dsap { <0-0xff> | any } ] [ ssap { <0-0xff> | any } ] [ control { <0-0xff> |
qos qce:
Configure QOS control entries
EX26262F Managed Switch Users Guide - CLI
- 61 -
any } ] } | { snap [ { <0-0xffff> | any } ] } | { ipv4 [ proto { <0-255> | tcp | udp | any } ]
[ sip { <ipv4_subnet> | any } ] [ dscp { <0~63> | { be | af11 | af12 | af13 | af21 | af22
| af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5 | cs6 | cs7 |
ef | va } | any } ] [ frag { yes | no | any } ] [ sport { <0~65535> | any } ] [ dport
{ <0~65535> | any } ] } | { ipv6 [ proto { <0-255> | tcp | udp | any } ] [ sip
{ <ipv4_subnet> | any } ] [ dscp { <0~63> | { be | af11 | af12 | af13 | af21 | af22 |
af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5 | cs6 | cs7 |
ef | va } | any } ] [ sport { <0~65535> | any } ] [ dport { <0~65535> | any } ] } } ]
[ action { [ cos { <0-7> | default } ] [ dpl { <0-1> | default } ] [ dscp { <0-63> | { be |
af11 | af12 | af13 | af21 | af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 |
cs2 | cs3 | cs4 | cs5 | cs6 | cs7 | ef | va } | default } ] } ]
Parameter:
<Id : 1-256> QCE ID
refresh Refresh QCE tables in hardware
update Update an existing QCE
action Specify action
dei Specify DEI (Drop Eligible Indicator)
dmac-type Specify DMAC type
frametype Specify frame type
ingress Ingress interfaces
last Place QCE at the end
next Place QCE before the next QCE ID
pcp Specify PCP (Priority Code Point)
smac Specify SMAC. If 'qos qce dmac-dip' is set, this parameter
specifies the DMAC
tag Specify tag options
vid Specify VLAN ID
cos Specify class of service
dpl Specify drop precedence level
dscp Specify DSCP
cos Specify class of service
<Cos : 0-7> Specific class of service
default Keep default class of service
<Dpl : 0-1> Specific drop precedence level
default Keep default drop precedence level
<Dscp : 0-63> Specific DSCP
af11 Assured Forwarding PHB AF11(DSCP 10)
af12 Assured Forwarding PHB AF12(DSCP 12)
af13 Assured Forwarding PHB AF13(DSCP 14)
af21 Assured Forwarding PHB AF21(DSCP 18)
af22 Assured Forwarding PHB AF22(DSCP 20)
af23 Assured Forwarding PHB AF23(DSCP 22)
af31 Assured Forwarding PHB AF31(DSCP 26)
af32 Assured Forwarding PHB AF32(DSCP 28)
af33 Assured Forwarding PHB AF33(DSCP 30)
EX26262F Managed Switch Users Guide - CLI
- 62 -
af41 Assured Forwarding PHB AF41(DSCP 34)
af42 Assured Forwarding PHB AF42(DSCP 36)
af43 Assured Forwarding PHB AF43(DSCP 38)
be Default PHB(DSCP 0) for best effort traffic
cs1 Class Selector PHB CS1 precedence 1(DSCP 8)
cs2 Class Selector PHB CS2 precedence 2(DSCP 16)
cs3 Class Selector PHB CS3 precedence 3(DSCP 24)
cs4 Class Selector PHB CS4 precedence 4(DSCP 32)
cs5 Class Selector PHB CS5 precedence 5(DSCP 40)
cs6 Class Selector PHB CS6 precedence 6(DSCP 48)
cs7 Class Selector PHB CS7 precedence 7(DSCP 56)
default Keep default DSCP
ef Expedited Forwarding PHB(DSCP 46)
va Voice Admit PHB(DSCP 44)
any Any
broadcast Broadcast
multicast Multicast
unicast Unicast
etype Ethernet frames
ipv4 IPv4 frames
ipv6 IPv6 frames
llc LLC frames
snap SNAP frames
<Etype : 0x600-0x7ff,0x801-0x86dc,0x86de-0xffff> Specific EtherType
interface Interfaces
<Next : 1-256> The next QCE ID
<Pcp : pcp> Specific PCP (0-7) or range (0-1, 2-3, 4-5, 6-7, 0-3 or
4-7)
<Smac : mac_addr> Specific SMAC (XX-XX-XX-XX-XX-XX)
tagged Tagged frames only
untagged Untagges frames only
<Vid : vlan_list> Specific VLAN ID or range
interface Interfaces
Gigabitethernet 1 Gigabit Ethernet Port
<PORT_LIST> Port list in 1/1-26 for Gigabitethernet
qos storm:
Configure storm policer
EX26262F Managed Switch Users Guide - CLI
- 63 -
Mode:
Global config
Syntax:
qos storm { unicast | multicast | broadcast } <Rate :
1,2,4,8,16,32,64,128,256,512,1024> [ kfps ]
Parameter:
broadcast Police broadcast frames
multicast Police multicast frames
unicast Police unicast frames
<Rate : 1,2,4,8,16,32,64,128,256,512,1024> Policer rate (default fps)
kfps Rate is kfps
Mode:
Config-if
Syntax:
qos dpl <dpl>
no qos dpl
qos pcp <0-7>
no qos pcp
qos dei <0-1>
no qos dei
qos trust tag
qos trust dscp
qos map tag-cos pcp <0~7> dei <0~1> cos <0-7> dpl <dpl>
no qos map tag-cos pcp <0~7> dei <0~1>
qos policer <uint> [ fps ] [ flowcontrol ]
no qos policer
qos queue-policer queue <0~7> <uint>
no qos queue-policer queue <0~7>
qos wrr <1-100> <1-100> <1-100> <1-100> <1-100> <1-100>
no qos wrr
qos shaper <uint>
no qos shaper
qos queue-shaper queue <0~7> <uint> [ excess ]
no qos queue-shaper queue <0~7>
qos tag-remark { pcp <0-7> dei <0-1> | mapped }
no qos tag-remark
qos map cos-tag cos <0~7> dpl <0~1> pcp <0-7> dei <0-1>
no qos map cos-tag cos <0~7> dpl <0~1>
qos dscp-translate
qos dscp-classify { zero | selected | any }
no qos dscp-classify
qos dscp-remark { rewrite | remap | remap-dp }
no qos dscp-remark
qos storm { unicast | broadcast | unknown } <100-13200000> [ fps ]
no qos storm { unicast | broadcast | unknown }
qos qce { [ addr { source | destination } ] [ key { double-tag | normal | ip-addr |
mac-ip-addr } ] }*1
no qos qce { [ addr ] [ key ] }*1
debug qos shaper cir { <100-3300000> [ cbs <4096-258048> ] } { [ eir
<100-3300000> [ ebs <4096-258048> ] ] }
no debug qos shaper
debug qos queue-shaper queue <0~7> { cir <100-3300000> [ cbs
<4096-258048> ] } { [ eir <100-3300000> [ ebs <4096-258048> ] ] } [ excess ]
no debug qos queue-shaper queue <0~7>
qos (interface commands):
Configure QOS on a port
EX26262F Managed Switch Users Guide - CLI
- 64 -
Parameter:
broadcast Police broadcast frames
multicast Police multicast frames
unicast Police unicast frames
<Rate : 1,2,4,8,16,32,64,128,256,512,1024> Policer rate (default fps)
kfps Rate is kfps
Reload
Mode:
Privilegd exec
Syntax:
reload { { cold [ sid <usid> ] } | { defaults [ keep-ip ] } }
Parameter:
cold Reload cold, i.e. reboot.
defaults Reload defaults without rebooting.
keep-ip Attempt to keep VLAN1 IP setup.r
Mode:
Global config
Syntax:
rmon alarm <1-65535> <WORD> <1-2147483647> { absolute | delta }
rising-threshold <-2147483648-2147483647> [ <0-65535> ] falling-threshold
<-2147483648-2147483647> [ <0-65535> ] { [ rising | falling | both ] }
rmon alarm <1-65535> { ifInOctets | ifInUcastPkts | ifInNUcastPkts | ifInDiscards
| ifInErrors | ifInUnknownProtos | ifOutOctets | ifOutUcastPkts | ifOutNUcastPkts |
ifOutDiscards | ifOutErrors } <uint> <1-2147483647> { absolute | delta }
rising-threshold <-2147483648-2147483647> [ <0-65535> ] falling-threshold
<-2147483648-2147483647> [ <0-65535> ] { [ rising | falling | both ] }
rmon event <1-65535> [ log ] [ trap <word127> ] { [ description <line127> ] }
no rmon alarm <1-65535>
no rmon event <1-65535>
Parameter:
alarm Configure an RMON alarm
event Configure an RMON event
<1-65535> Alarm entry ID
<WORD> MIB object to monitor
<1-2147483647> Sample interval
reload:
Reboot the switch
RMON
rmon:
Configure Remote Monitoring
EX26262F Managed Switch Users Guide - CLI
- 65 -
absolute Test each sample directly
delta Test delta between samples
rising-threshold Configure the rising threshold
<-2147483648-2147483647> rising threshold value
<0-65535> Event to fire on rising threshold crossing
falling-threshold Configure the falling threshold
<-2147483648-2147483647> falling threshold value
rising Trigger alarm when the first value is larger than the
rising threshold
falling Trigger alarm when the first value is less than the
falling threshold
both Trigger alarm when the first value is larger than the
rising threshold or less than the falling threshold (default)
ifInOctets The total number of octets received on the interface,
including framing characters
ifInUcastPkts The number of uni-cast packets delivered to a higher-layer
protocol
ifInNUcastPkts The number of broad-cast and multi-cast packets
delivered to a higher-layer protocol
ifInDiscards The number of inbound packets that are discarded
even the packets are normal
ifInErrors The number of inbound packets that contained errors
preventing them from being deliverable to a higher-layer protocol
ifInUnknownProtos The number of the inbound packets that were
discarded because of the unknown or un-support protocol
ifOutOctets The number of octets transmitted out of the interface ,
including framing characters
ifOutUcastPkts The number of uni-cast packets that request to
transmit
ifOutNUcastPkts The number of broad-cast and multi-cast packets that
request to transmit
ifOutDiscards The number of outbound packets that are discarded event
the packets is normal
ifOutErrors The The number of outbound packets that could not
be transmitted because of errors
<uint> ifIndex
<1-2147483647> Sample interval
absolute Test each sample directly
delta Test delta between samples
rising-threshold Configure the rising threshold
EX26262F Managed Switch Users Guide - CLI
- 66 -
SFlow Commands
Mode:
Global config
Syntax:
sflow agent-ip {ipv4 <ipv4_addr> | ipv6 <ipv6_addr>}
no sflow agent-ip
sflow timeout [receiver <range_list>] <0-2147483647>
no sflow timeout [receiver <range_list>]
sflow collector-address [receiver <range_list>] [<word>]
no sflow collector-address [receiver <range_list>]
sflow collector-port [receiver <range_list>] <1-65535>
no sflow collector-port [receiver <range_list>]
sflow max-datagram-size [receiver <range_list>] <200-1468>
no sflow max-datagram-size [receiver <range_list>]
sflow sampling-rate [sampler <range_list>] [<1-4294967295>]
sflow max-sampling-size [sampler <range_list>] [<14-200>]
no sflow max-sampling-size [sampler <range_list>]
sflow counter-poll-interval [sampler <range_list>] [<1-3600>]
no sflow counter-poll-interval [<range_list>]
sflow [<range_list>]
Parameter:
IPv4: IP type
IPv6: IP type
<ip-address>: IP address
<1-65535>: TCP/UDP port number. By default, the port number is
6343
<0-2147483647>: Set the receiver timeout for list of receiver ID
(RID). Collector cannot collect samples unless receivertimeout
<200-1500>: Set the reciever datagram length for list of receiver ID
(RID)
<port-list>: available value is from switch physic port density, format:
1,3-5
ALL: Sample on both RX and TX
RX: Sample on RX
SFlow
The sFlow Collector configuration for the switch can be monitored and modified here. Up to 1
Collector is supported. This page allows for configuring sFlow collector IP type, sFlow collector IP
Address and Port Number for each sFlow Collector
collector:
Set sFlow Collector Configuration
EX26262F Managed Switch Users Guide - CLI
- 67 -
TX: Sample on TX
none: Sampling is disabled
<0-4095>: If parameter sample_rate is 'N' then 1/N of packets is
sampled
<14-200>: Configures the size of the header of the sampled frame to
be copied to the Queue for further processing. The Max header size
ranges from 14 to 200 bytes
<0-3600>: Configures the polling interval for the counter sampling.
The accepted value for Counter Polling Interval ranges from 0 to 3600
seconds. Default value is 0 seconds which means polling is disabled.
EX26262F Managed Switch Users Guide - CLI
- 68 -
Syntax:
smtp delete mailaddress <1-6>
smtp delete { server | username | sender | returnpath | mailaddress
<1-6> } smtp mailaddress <1-6> <word47>
smtp ( returnpath | sender | server ) <word47>
smtp username <word31> <word31>
smtp level <0-7>
Parameter:
delete Delete command
mailaddress Configure email address
returnpath Configure email returnpath
sender Configure email sender
server Configure email server
username Configure email user name
mailaddress Delete email address
returnpath Delete returnpath
sender Delete sender
server Delete email server
username Delete username and password
<1-6> Email address index
<word47> Up to 47 characters describing mail address
<word47> Up to 47 characters describing returnpath
<word47> Up to 47 characters describing sender
<word47> Up to 47 characters describing email server
<word31> Up to 47 characters describing user name
<word31> Configure email password
Mode:
Global config
SMTP Commands
smtp:
Configure SMTP
SNMP Commands
snmp-server:
Configure SNMP
EX26262F Managed Switch Users Guide - CLI
- 69 -
Syntax:
snmp-server access <GroupName : word32> model { v1 | v2c | v3 | any } level
{ auth | noauth | priv } [ read <ViewName : word255> ] [ write <WriteName :
word255> ]
snmp-server community v2c <Community : word127> [ ro | rw ]
snmp-server community v3 <word127> [ <ipv4_addr> <ipv4_netmask> ]
snmp-server contact <line255>
snmp-server engine-id local <Engineid : word10-32>
snmp-server host <word32> [Use this command to enter config-snmps-host
mode]
snmp-server location <line255>
snmp-server security-to-group model { v1 | v2c | v3 } name <SecurityName :
word32> group <GroupName : word32>
snmp-server trap
snmp-server user <Username : word32> engine-id <Engineid : word10-32>
[ { md5 <Md5Passwd : word8-32> | sha <ShaPasswd : word8-40> } [ priv { des |
aes } <word8-32> ] ]
snmp-server version { v1 | v2c | v3 }
snmp-server view <ViewName : word32> <OidSubtree : word255> { include |
exclude }
Parameter:
<GroupName : word32> group name
model security model
any any security model
v1 v1 security model
v2c v2c security model
v3 v3 security model
level security level
auth authNoPriv Security Level
noauth noAuthNoPriv Security Level
priv authPriv Security Level
read specify a read view for the group
write specify a write view for the group
<ViewName : word255> read view name
<WriteName : word255> write view name
<line255> contact string
local Set SNMP local engine ID
<Engineid : word10-32> local engine ID
name security user
<SecurityName : word32> security user name
group security group
<GroupName : word32> security group name
md5 Set MD5 protocol
<Md5Passwd : word8-32> MD5 password
sha Set SHA protocol
EX26262F Managed Switch Users Guide - CLI
- 70 -
<ShaPasswd word8-40> SHA password
priv Set Privacy
des Set DES protocol
aes Set AES protocol
<word8-32> Set privacy password
system:
Mode:
Global config
Syntax:
system contact <v_line255>
system location <v_line255>
system name <v_line255>
system descriptuon <v_line255>
system reboot <Fri, Mon, Sat, Sun, Thr, Tue, Wed> {mode <enable/disable}
Parameter:
system contact <v_line255>
system location <v_line255>
system name <v_line255>
Mode:
Config-snmps-host
Syntax:
shutdown
Parameter:
none
Mode:
Config-snmps-host
Syntax:
host { <ipv4_ucast> | <hostname> } [ <1-65535> ] [ traps | informs ]
host <ipv6_ucast> [ <1-65535> ] [ traps | informs ]
no host
Parameter:
none
Mode:
Config-snmps-host
Syntax:
version { v1 [ <word127> ] | v2 [ <word127> ] | v3 [ probe | engineID
<word10-32> ] [ <word32> ] }
no version
Parameter:
none
Configure SNMP server
shutdown:
Disable trap configuration
host:
SNMP host configuration
version:
Set SNMP trap version.
informs:
EX26262F Managed Switch Users Guide - CLI
- 71 -
Set SNMP trap version.
Mode:
Config-snmps-host
Syntax:
informs retries <0-255> timeout <0-2147>
no informs
Parameter:
none
Mode:
Global config
Syntax:
ip ssh
Parameter:
none
Mode:
Privileged exec
Syntax:
show ip ssh
Parameter:
none
SSH Commands
ip ssh:
Enable SSH
show ip ssh:
Show SSH configuration
EX26262F Managed Switch Users Guide - CLI
- 72 -
STP Commands
Mode:
Global config
Syntax:
spanning-tree aggregation
Parameter:
none
Mode:
Global config
EX26262F(config)# spanning-tree aggregation
EX26262F(config-stp-aggr)#
STP
The Spanning Tree Protocol (STP) can be used to detect and disable network loops, and to provide
backup links between switches, bridges or routers. This allows the switch to interact with other
bridging devices (that is, an STP-compliant switch, bridge or router) in your network to ensure that
only one route exists between any two stations on the network, and provide backup links which
automatically take over when a primary link goes down.
STP - STP uses a distributed algorithm to select a bridging device (STP- compliant switch, bridge or
router) that serves as the root of the spanning tree network. It selects a root port on each bridging
device (except for the root device) which incurs the lowest path cost when forwarding a packet
from that device to the root device. Then it selects a designated bridging device from each LAN
which incurs the lowest path cost when forwarding a packet from that LAN to the root device. All
ports connected to designated bridging devices are assigned as designated ports. After
determining the lowest cost spanning tree, it enables all root ports and designated ports, and
disables all other ports. Network packets are therefore only forwarded between root ports and
designated ports, eliminating any possible network loops.
Once a stable network topology has been established, all bridges listen for Hello BPDUs (Bridge
Protocol Data Units) transmitted from the Root Bridge. If a bridge does not get a Hello BPDU after
a predefined interval (Maximum Age), the bridge assumes that the link to the Root Bridge is down.
This bridge will then initiate negotiations with other bridges to reconfigure the network to
reestablish a valid network topology.
spanning-tree aggregation:
Aggregation mode.
EXAMPLE:
spanning-tree edge:
Configure edge ports
EX26262F Managed Switch Users Guide - CLI
- 73 -
Syntax:
spanning-tree edge bpdu-filter
spanning-tree edge bpdu-guard
Parameter:
bpdu-filter Enable BPDU filter (stop BPDU tx/rx)
bpdu-guard Enable BPDU guard
EXAMPLE:
Mode:
Global config
Syntax:
spanning-tree mode { stp | rstp | mstp }
Parameter:
mstp Multiple Spanning Tree (802.1s)
rstp Rabid Spanning Tree (802.1w)
stp 802.1D Spanning Tree
Mode:
Global config
Syntax:
spanning-tree mst <Instance : 0-7> priority <Prio : 0-61440>
spanning-tree mst < Instance : 0-7> vlan <vlan_list>
spanning-tree mst forward-time <Fwdtime : 4-30>
spanning-tree mst max-age <Maxage : 6-40> [ forward-time <Fwdtime : 4-30> ]
spanning-tree mst max-hops <Maxhops : 6-40>
spanning-tree mst name <Name : word32> revision <0-65535>
Parameter:
<Instance : 0-7> instance 0-7 (CIST=0, MST2=1...)
EX26262F(config)# spanning-tree edge bpdu-filter
EX26262F(config)#
EX26262F(config)# spanning-tree mode mstp
EX26262F(config)#
spanning-tree mode:
Set stp protocol mode
EXAMPLE:
spanning-tree mst:
STP bridge instance
EX26262F Managed Switch Users Guide - CLI
- 74 -
forward-time Delay between port states
max-age Max bridge age before timeout
max-hops MSTP bridge max hop count
name Name keyword
priority Priority of the instance
vlan VLAN keyword
<Prio : 0-61440> Range in seconds
<vlan_list> Range of VLANs
<Fwdtime : 4-30> Range in seconds
<Maxage : 6-40> Range in seconds
<Maxhops : 6-40> Hop count range
<Name : word32> Name of the bridge
revision Revision keyword
<0-65535> Revision number
Mode:
Global config
Syntax:
spanning-tree recovery interval <Interval: 30 - 86400>
Parameter:
interval The interval
<Interval : 30-86400> Range in seconds
Mode:
Global config
Syntax:
spanning-tree transmit hold-count <Holdcount: 1 - 10>
EX26262F(config)# spanning-tree mst 7 vlan 10
EX26262F(config)# spanning-tree recovery interval 50
EXAMPLE:
spanning-tree recovery:
Set error recovery timeouts.
EXAMPLE:
spanning-tree transmit:
BPDUs to transmit
EX26262F Managed Switch Users Guide - CLI
- 75 -
Parameter:
hold-count Max number of transmit BPDUs per sec
<Holdcount : 1-10> 1-10 per sec, 6 is default
EX26262F(config)# spanning-tree transmit hold-count 5
EXAMPLE:
EX26262F Managed Switch Users Guide - CLI
- 76 -
Terminal Commands
Mode:
Privilegd exec
Syntax:
terminal editing
terminal exec-timeout <0-1440> [ <0-3600> ]
terminal help
terminal history size <0-32>
terminal length <0 or 3-512>
terminal width <0 or 40-512>
Parameter:
editing Enable command line editing
exec-timeout Set the EXEC timeout
help Description of the interactive help system
history Control the command history function
length Set number of lines on a screen
width Set width of the display terminal
<0-1440> Timeout in minutes
<0-3600> Timeout in seconds
size Set history buffer size
<0-32> Number of history commands, 0 means disable
<0 or 3-512> Number of lines on screen (0 for no pausing)
<0 or 40-512> Number of characters on a screen line (0 for unlimited
width)
terminal:
Set terminal line parameters
UPnP Commands
UPnP
UPnP is an acronym for Universal Plug and Play. The goals of UPnP are to allow devices to connect
seamlessly and to simplify the implementation of networks in the home (data sharing,
communications, and entertainment) and in corporate environments for simplified installation of
computer components.
upnp:
Configure UPnP settings
EX26262F Managed Switch Users Guide - CLI
- 77 -
Mode:
Global config
Syntax:
upnp
upnp advertising-duration <100 - 86400>
upnp ttl <1-255>
Parameter:
advertising-duration Set advertising duration
ttl Set TTL value
<100-86400> advertising duration
<1-255> TTL value
Syntax:
username <username> privilege <priv> password encrypted <encry_password>
username <username> privilege <priv> password none
username <username> privilege <priv> password unencrypted <password>
Parameter:
<Username: word31> User name allows letters, numbers and
underscores
privilege Set user privilege level
<privilegeLevel: 0-15> User privilege level
password Specify the password for the user
encrypted Specifies an ENCRYPTED password will follow
none NULL password
unencrypted Specifies an UNENCRYPTED password will
follow
<Password: line31> The UNENCRYPTED (Plain Text) user
password. Any character is accepted, including space. Note that there is no way
to get the Plain Text password after this command. The system will always
display the ENCRYPTED password.
<Password: word4-44> The ENCRYPTED (hidden) user password.
Note that the ENCRYPTED password will be decoded by the system internally.
You cannot directly use it as same as the Plain Text and it is not human-readable
text normally.
Username Commands
username:
Establish User Name Authentication.
EX26262F Managed Switch Users Guide - CLI
- 78 -
VLAN Commands
Mode:
Global config
Syntax:
vlan <vlan_list>
vlan ethertype s-custom-port <0x0600-0xffff>
vlan protocol { { eth2 { <0x600-0xffff> | arp | ip | ipx | at } } | { snap { <0x0-0xffffff> |
rfc_1042 | snap_8021h } <0x0-0xffff> } | { llc <0x0-0xff> <0x0-0xff> } } group
<word16>
Parameter:
<vlan_list> ISL VLAN IDs 1-4095
ethertype Ether type for Custom S-ports
protocol Protocol-based VLAN commands
s-custom-port Custom S-ports configuration
<0x0600-0xffff> Ether type (Range: 0x0600-0xffff>
eth2 Ethernet-based VLAN commands
<0x600-0xffff> Ether Type(Range: 0x600 - 0xFFFF)
arp Ether Type is ARP
ip Ether Type is IP
ipx Ether Type is IPX
at Ether Type is AppleTalk
snap SNAP-based VLAN group
<0x0-0xffffff> SNAP OUI (Range 0x000000 - 0XFFFFFF)
rfc_1042 SNAP OUI is rfc_1042
snap_8021h SNAP OUI is 8021h
<0x0-0xffff> PID (Range: 0x0 - 0xFFFF)
llc LLC-based VLAN group
<0x0-0xff> DSAP (Range: 0x00 - 0xFF)
<0x0-0xff> SSAP (Range: 0x00 - 0xFF)
group Protocol-based VLAN group commands
VLAN
To assign a specific VLAN for management purpose. The management VLAN is used to establish an
IP connection to the switch from a workstation connected to a port in the VLAN. This connection
supports a VSM, SNMP, and Telnet session. By default, the active management VLAN is VLAN 1.
Only one management VLAN can be active at a time.
vlan:
VLAN commands
EX26262F Managed Switch Users Guide - CLI
- 79 -
<word16> Group Name (Range: 1 - 16 characters)
Mode:
Config-if
Syntax:
switchport vlan mac <mac_ucast> vlan <vlan_id>
switchport vlan protocol group <word16> vlan <vlan_id>
switchport vlan ip-subnet id <1-128> <ipv4_subnet> vlan <vlan_id>
no switchport vlan ip-subnet id <1~128>
switchport access vlan <vlan_id>
no switchport access vlan
switchport trunk native vlan <vlan_id>
no switchport trunk native vlan
switchport hybrid native vlan <vlan_id>
no switchport hybrid native vlan
switchport trunk vlan tag native
switchport trunk allowed vlan {all | none | [add | remove | except] <vlan_list>}
no switchport trunk allowed vlan
switchport hybrid allowed vlan {all | none | [add | remove | except] <vlan_list>}
no switchport hybrid allowed vlan
switchport forbidden vlan {add|remove} <vlan_list>
no switchport forbidden vlan
switchport voice vlan mode { auto | force | disable }
no switchport voice vlan mode
switchport voice vlan security
switchport voice vlan discovery-protocol {oui | lldp | both}
no switchport voice vlan discovery-protocol
Parameter:
none
EX26262F(config)# vlan ethertype s-custom-port 0x1111
EX26262F(config)# vlan protocol eth2 arp group 123
EX26262F(config)#
EXAMPLE:
switchport vlan:
Configure VLAN characteristics on an interface.
EX26262F Managed Switch Users Guide - CLI
- 80 -
Voice VLAN Commands
Mode
Global config
Syntax:
voice vlan
voice vlan aging-time <aging_time>
voice vlan class { <traffic_class> | low | normal | medium | high }
voice vlan oui <oui> [ description <description> ]
voice vlan vid <vid>
Parameter:
advertising-duration Set advertising duration
vlan Vlan for voice traffic
aging-time Set secure learning aging time
<10-10000000> Aging time, 10-10000000 seconds
class Set traffic class
<0-7> Traffic class value
oui OUI configuration
<oui> OUI value
description Set description for the OUI
<line32> Description line
vid Set VLAN ID
<vlan_id> VLAN ID, 1-4095
EX26262F(config)# voice vlan aging-time 3333
EX26262F(config)# voice vlan class 7
EX26262F(config)# voice vlan vid 3333
EX26262F(config)#
Voice VLAN
Voice VLAN is VLAN configured specially for voice traffic. By adding the ports with voice devices
attached to voice VLAN, we can perform QoS-related configuration for voice data, ensuring the
transmission priority of voice traffic and voice quality.
The Voice VLAN feature enables voice traffic forwarding on the Voice VLAN, then the switch can
classify and schedule network traffic. It is recommended that there be two VLANs on a port - one
for voice, one for data. Before connecting the IP device to the switch, the IP phone should
configure the voice VLAN ID correctly.
voice:
Voice appliance attributes.
EXAMPLE:
EX26262F Managed Switch Users Guide - CLI
- 81 -
Web Commands
Mode:
Global config
Syntax:
web privilege group <CWORD> level { [ cro <0-15> ] [ crw <0-15> ] [ sro
<0-15> ] [ srw <0-15> ] }
no web privilege group [ <cword> ] level
Parameter:
privilege Web privilege
group Web privilege group
CWORD Valid words are 'Aggregation' 'Debug' 'Dhcp_Client'
'Green_Ethernet' 'IP2' 'IPMC_Snooping' 'LACP' 'LLDP' 'Loop_Protect'
'MAC_Table' 'MEP' 'MVR' 'Maintenance' 'Mirroring' 'NTP' 'POE' 'Ports'
'Private_VLANs' 'QoS' 'RPC' 'Security' 'Spanning_Tree' 'System' 'Timer' 'UPnP'
'VCL' 'VLAN_Translation' 'VLANs' 'Voice_VLAN' 'sFlow'
level Web privilege group level
cro Configuration Read-only level
crw Configuration Read-write level
sro Status/Statistics Read-only level
srw Status/Statistics Read-write level
EX26262F(config)# web privilege group ptp level sro 10
web:
Configure time of inactivity before automatic logout
EXAMPLE:
EX26262F Managed Switch Users Guide - CLI
- 82 -
EtherWAN has made a good faith effort to ensure the accuracy of the information in this document
and disclaims the implied warranties of merchantability and fitness for a particular purpose, and
makes no express warranties, except as may be stated in its written agreement with and for its
customers.
EtherWAN shall not be held liable to anyone for any indirect, special or consequential damages due
to omissions or errors. The information and specifications in this document are subject to change
without notice.
Copyright 2017. All Rights Reserved.
All trademarks and registered trademarks are the property of their respective owners
June 8, 2017
EX26262F Managed Switch Users Guide - CLI
Loading...
