INSTALLATION INSTRUCTIONS

A guide for qualied electricians

Email: [e-mail] / [e-mail]

Visit our website: www.eterna-lighting.co.uk

Made in ChinaIssue 0117

874/2012

MODELNO.

Aluminium Range

EVENTUALLY, YOU MAY WANT TO
REPLACE THIS PRODUCT:

Regulations require the recycling of Waste from
Electrical and Electronic Equipment (European
“WEEE Direc tive” eective August 20 05—UK
WEEE Regulation s eective 2nd January 20 07).
Environment Agenc y Registered Producer : WEE/
GA0248Q Z.

WHEN YOUR PR ODUCT COMES TO TH E END OF
ITS LIFE OR YO U CHOOSE TO REPLACE I T, PLEASE
RECYCLE IT W HERE FACILITIES E XIST  DO NOT
DISPOSE WITH HOUSEHOLD WASTE.

CLEANING:

Clean this ttin g only with a soft dry clo th.

Do not use any chemic al or abrasive cleaners.

IF YOU EXPERIENCE PROBLEMS:

If you believe your p roduct is defective, p lease return
it to the place where yo u bought it. Our Technical
Team will gladly advise on any Eterna Lighting
product, bu t may not be able to give specic
instructions regarding individual installations.

LED LAM P SPECIFICATIO NS:

FULL / GRILL EYELID

Luminaire lumens (opal)

1400 lm 1300 lm

Lumens from chip (no diuser)

1900 lm 1750 lm

Useful lumens

1350 lm 1250 lm

Rated Wattage 18W 18W

Rated luminous ux 1350 lm 1250 lm

Nominal life time of the lamp 35,000 hrs 35,000 hrs

Colour temperature 4200K 4200K

Number of switching cycles
before premature lamp failure

>15,000 >15,000

Warm-up time up to 60% of the
full light output

Instant full light Instant full light

Dimmable No No

Nominal beam angle 120° 120°

Rated power 18W 18W

Rated lamp lifetime 35,000 hrs 35,000 hrs

Lamp power factor >0.9 >0.9

Lumen maintenance factor at end
of nominal life

>0.7 >0.7

Starting time <0.1s <0.1s

Colour rendering >80 Ra >80 Ra

Colour consistency

Within 6 step

Macadam ellipse

Within 6 step

Macadam ellipse

Rated peak intensity 520cd 520cd

Rated beam angle 120° 120°

Voltage / Frequency 240V~50Hz 240V~50Hz

Not suitable for accent lighting

Model:

ALMFBKFUL / ALMFWHFUL

ALMFBKEYE / ALMFWHEYE

ALMFBKGRI / ALMFWHGRI

IP65 LED Aluminium Wall Lights With Multi-Function Sensor

These instructions are provided as a guideline to assist you.

PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLATION

AND RETAIN FOR FUTURE REFERENCE

Pack contents:

1 x LED tting

READ THIS FIRST:

Check the pack and m ake sure you have all of the
parts liste d on the front of this bookle t. If not,
contact the outlet where you bought this product.

This produc t must be installed by a compet ent
person in accord ance with the current building a nd
IEE wiring regulations.

As the buyer, install er and/or user of this product it
is your own responsi bility to ensure that this tt ing
is t for the purpo se for which you have intended
it. Eterna Lightin g cannot accept any liability fo r
loss, damage or premature failure resulting from
inappropriate use.

This product is designed and constructed according
to the principles o f the appropriate British Stan dard
and is intended fo r normal domestic ser vice. Using
this tting in any oth er environments may result in
a shortened w orking life, for example w here there
is prolonged p eriods of use or higher than no rmal
ambient temper atures such as lighting public or
shared spaces or in n ursing /care home facilities.

Switch o the mains be fore commencing installati on
and remove the appro priate circuit fuse or lock o
MCB.

Suitable for outdoor use.

This produc t is designed for permanent co nnection
to xed wiring: this m ust be a suitable circuit
(protected w ith the appropriate MCB or fuse).

This produc t is suitable for installatio n on surfaces
with normal ammability e.g. wood, plasterboard
and masonry. It is not s uitable for use on highly
ammable sur faces (e.g. polystyren e, textiles).

Before makin g xing hole(s), check that there are no
obstructi ons hidden beneath the mount ing surface
such as pipes or cab les.

The chosen loc ation of your new tting shou ld
allow for the prod uct to be securely mounte d (e.g.
to a ceiling joist) and s afely connected to the mai ns
supply (lighting circuit).

When making con nections ensure that the ter minals
are tightened se curely and that no strands of wi re
protrude. Chec k that the terminals are tightene d
onto the bared cond uctors and not onto any
insulation.

This produc t must be connected to ear th
termination.

This produc t is not intended to be used by childr en
and persons wi th sensory, physical and/or ment al
impairments th at would prevent them from using i t
saf ely.

You are advised at ever y stage of your installatio n to
double-check any electrical connections you have
made. After you h ave completed your installatio n
there are elec trical tests that should b e carried out,

these tests are sp ecied in the current IEE wir ing and
building regulations.

INTRODUCTION:

The LED Aluminium Wall L ight incorporates a
microwave sensing de vice which continuously scans
the operating zo ne and immediately switch es the
light on when it det ects movement in that area.
This means that whe never movement is detecte d
within the range o f the sensor the light will switch
on automaticall y and illuminate the area you have
selected to l ight. While there is movement wi thin
range of the unit th e light will remain on.

A microwave sensor is an a ctive motion detecto r
emitting high -frequency ele ctro-magnetic waves at

5.8GHz and rece iving their echo. The senso r detects
change in the echo p attern within its detec tion
zone and the light is th en triggered. The wave can
pass through doo rs, glass and thin walls and will
continually monit or the signal within the detec tion
area.

LAMP REPLACEMENT:

INSTALLATION:

Isolate mains and lo ck o.

Choose the loc ation for your new tting accor ding to
the conditions listed opposite.

01. Undo the screws ret aining the trim and lift o.

02. Loosen gear tray s crews and rotate to remove.

03) Using the back o f your tting as a template,
mark the positio n of your xing holes on your
mounting surf ace.

04) Prepa re the holes in your mounting sur face as
appropriate for your xings.

05) Pierce the r ubber grommet in the back of yo ur
tting makin g a hole just large enough to make a
tight t around the in coming mains cable.

06) Threa d the cable through the gromm et and oer
the tting to the ce iling / wall.

07) Secure t he tting in place.

08) Check t hat the grommet is still correc tly tted in
the cable entry hole and around the incoming
cable.

09) Make the e lectrical connec tions according to the
symbols, adj acent to the connector bloc k:

Brown to live (L)
Blue to neutral (N)
Earth green & y ellow (E)

10) Set the multi -function sensor. (See
“understanding the controls” instructions on next
page).

11) Conne ct the plug / socket betw een terminal
block & gear tray.

12) Replace gear tray an d screw in position with the
three screws.

NOTE: For eyelid  ttings - ensure the arrows on
the gear tray and bas e match up.

13) Oer the diuse r onto the top of the tting and
secure in place wi th the trim.

14) Restore the pow er and switch on.

The light source cont ained in this luminaire
shall only be rep laced by the manufacturer,
service age nt or a similar qualied pers on.

CAUTION, RISK OF ELECTRIC SHOCK.

The light source is designed to last the lifetime of the
luminaire.

Yellow/Green

EARTH

L

N

Blue/Black

Brown/Red

NEUTRAL

LIVE
