Etec 40E700 User Manual

For technical support, the ETEC Technical Support Center is available 9:00AM to
9:00PM (Monday to Friday) and 9:00AM to Noon (Saturday) for technical assistance
or troubleshooting. To contact us by phone, please call 1-800-936-1168.

USER’S MANUAL

40” LED TELEVISION

40E700

Ver 1.0

40E700-1

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (includ-

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The

consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,

and the point where they exit from the apparatus.

­paratus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury
from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.

15. WARNING: To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Apparatus To Rain Or
Moisture.

shall be placed on the apparatus.

17. The mains plug or appliance coupler shall remain readily operable.

18. Use in outdoors: This TV is not designed for outdoors installation. Do not expose the TV to rain, as it may

become damaged.

CAUTION

RISK OF ELECTRIC SHOCK
DO NOT OPEN

Safety:

TO REDUCE THE RISK OF ELECTRICAL SHOCK DO NOT REMOVE COVER
(OR BACK). NO USER SERVICEABLE PARTS ARE INSIDE. REFER TO QUALIFIED
SERVICE TECHNICIAN ONLY.

intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s

Instruction: The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and servicing instructions in the literature accompanying the
appliance.

to constitute a risk of electric shock to the users.

40E700-2

Safety Instructions

Please read these instructions carefully.

This product complies with all applicable US federal safety requirements, as well as those of the Canadian
Standards Association.

1. Cleaning

Always unplug the TV before cleaning. Do not use liquid or aerosol cleaners. Use a soft, slightly damp cloth to
clean.

2. Water and Moisture

Do not use this TV near water. Avoid using this TV in an excessively damp environment.

3. Stand

This TV should always be placed on a solid, sturdy surface.

4. Ventilation

To prevent overheating, do not block or obstruct the vent openings on the TV’s back panel. Also, avoid placing this
TV in a confined area with poor air flow.

5. Power Sources

This TV should be operated only from the type of power source indicated on the marking label. If you are not sure of
The type of power supply to your home, consult your electronics retailer or local power company.

6. Power Cord Polarization

This TV is equipped with a three-wire grounding type plug, a plug with a third (grounding) pin. As a safety feature, this
plug will only t into a grounded power outlet. If you are unable to insert the plug into the outlet, contact your electrician
to replace the obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.

7. Power Cord Protection

Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or

against them. Pay particular attention to cords at plugs, convenience receptacles, and the point where they exit from
the TV.

8. Lightning

To protect the TV during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV from lightning
and power-line surges.

40E700-3

Safety Instructions

9. Outdoor Antenna Grounding

If an outside antenna or cable system is connected to the TV be sure the antenna or cable system is grounded so
as to provide some protection against voltage surges and built up static charges. Article 810 of the National Electri­cal Code (U.S. A.), ANSI / NFPA 70 provides information with regard to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of anten­na-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

Example of Grounding According to National
Electrical Code Instructions

NEC - National Electrical Code

10. Power Lines

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power
circuits, or where it can fall on to power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

11. Overloading

12. Object and Liquid Entry

Never push objects of any kind into this TV through openings as they may touch dangerous voltage points or short-out

TV.

13. Servicing

Do not attempt to service this TV yourself as opening or removing covers may expose you to dangerous voltage or

14. Damage Requiring Service

a. If the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the TV has been exposed to rain or water.
d. If the TV does not operate normally by following the operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper adjustment of other controls may result in damage and will

e. If the TV has been dropped or the cabinet has been damaged.
f. If the TV exhibits a distinct change in performance.

Ground Clamp

Antenna Lead in Wire

Antenna Discharge Unit
(NEC Section 810-20)

Grounding Conductor
(NEC Section 810-21)

Ground Clamps

Electric Service

Equipment

Power Service Grounding
Electrode System (NEC
Art 250, Part H)

40E700-4

Safety Instructions

15. Replacement Parts

When replacement parts are required, be sure that only an authorized service technician has used replacement parts

16. Safety Check

Upon completion of any service or repairs to this TV, ask the service technician to perform safety checks to determine
whether the product is in proper operating condition.

17. Wall Mounting

The TV should be mounted to a wall only by a professional. The TV may slide or fall, causing serious injury to a child
or adult, and serious damage to the product. Warranty shall be voided.

18. Heat

The TV should be situated away from heat sources such as radiators, heat registers, stoves, or other products

NOTE TO CABLE / TV INSTALLER:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electric

should be connected to the grounding system of the building, as close to the point of the cable entry as practical.

FCC REGULATORY INFORMATION:

This television has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residen­tial installation. This television generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is no

electronic equipment, which can be determined by turning the television off and on, then the user is encouraged to try
to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and television.

- Connect the equipment into an outlet on a circuit different from that to which the television is connected.

- Consult your dealer or an experienced radio / TV technician for assistance.

’s

authority to operate the equipment.

guarantee that interference will not occur in a particular installation. If this television does cause interference to other

40E700-5

Table of Contents

Important Safety Instructions .........................................................................................................................................1

Table of Contents ..........................................................................................................................................................5

Introduction ....................................................................................................................................................................6

Installing the Base .........................................................................................................................................................7

Remote Control

Battery Install .................................................................................................................................................................8

Overview .......................................................................................................................................................................9

TV Overview

Front & Side Panel ......................................................................................................................................................11

Rear Panel .................................................................................................................................................................12

Installation

TV Setup

TV Channel Setup & Channel Auto Scan .....................................................................................................................21

Picture Setting

Contrast ........................................................................................................................................................................22

Brightness ....................................................................................................................................................................22

Color .............................................................................................................................................................................22

Tint ................................................................................................................................................................................22

Sharpness ....................................................................................................................................................................22

Color Temp. ..................................................................................................................................................................22

Audio Settings

Bass .............................................................................................................................................................................23

Treble ...........................................................................................................................................................................23

Balance ........................................................................................................................................................................23

Surround .......................................................................................................................................................................23

SPDIF Type ..................................................................................................................................................................23

Audio Language ...........................................................................................................................................................23

Date & Time Settings ..............................................................................................................................................24

Setup Settings

Menu Languages ..........................................................................................................................................................25

Transparent ................................................................................................................................................................25

..................................................................................................................................................................25OSD Timeout

Closed Captions.........................................................................................................................................................26

Advanced Settings ....................................................................................................................................................27

Parental Control ........................................................................................................................................................29

Channel Settings

Favorite ........................................................................................................................................................................31

Show / Hide ..................................................................................................................................................................31

Channel Label ..............................................................................................................................................................31

Zoom Modes .............................................................................................................................................................32

USB Modes ..................................................................................................................................................................33

...........................................................................................................................................................34

Troubleshooting ........................................................................................................................................................35

Connection to a Personal Computer ..............................................................................................................................17

Connection to a Home Theater System .........................................................................................................................18

Connect a digital cable box, satellite recei

ver, or DVD player with a Component connection .......................................14

Connect a digital cable box, satellite recei

ver, or DVD player with Composite cables (yellow, red, & white) ................

Connect a digital cable box, satellite recei

ver, or DVD player with an HDMI cable .......................................................13

Connecting the Power and Basic Cable connection ......................................................................................................16

Initial Setup Wizard .......................................................................................................................................................19

15

CEC Settings....... ........................................................................................................................................................28

40E700-6

Introduction

What’s In The Box

The 40E700 package includes the following items. Save the carton & packing for future shipping

• Remote Control

• AAA Batteries (2)

• Quick Start Guide

• User Manual

• Child Safety

• Audio / Video Cable

• Pedestal Base

• Screws for Pedestal Base (5)

• Pedestal Base

• Screws for Pedestal
Base (5)

• User manual

• Quick Start Guide

• Child Safety

• Remote Control

• AAA

Batteries x 2

• Audio / Video Cable

Please refer to this guide whenever you have questions about features and functions. This instruction book will get
you up and running with the best possible connection type for your devices. Enjoy!

This TV uses a 200x100 VESA mounting bracket attachment pattern. Please take this information with you when
purchasing a wall mount for this TV.

Wall Mount Information

40E700-7

Place the TV face down
on a soft cloth or cushion.

Position base as shown.

Insert 5 screws (provided)
through the holes in the bottom
of the base into the post holes
and tighten securely.
Do not over-tighten.

Installing the Base

40E700-8

Battery Install

Remote Control

Your remote control handset is powered by two (2) AAA type batteries

• Effective remote range is approximately 16 feet at an

angle of no greater than 30° to the left / right or 20° up /
down to the IR sensor.

• To avoid possible damage from battery chemical

leakage, remove the batteries if you do not plan to use
the remote for an extended period of time. Do not mix
batteries of different age and / or type. Always discard
used batteries safely.

• Do not expose the remote control to liquids, direct sun-

light or sources of excessive heat.

• The IR receiver on the TV will not work properly if the set

is in direct sunlight.

NOTE: Improper use of batteries can result in a chemical
leakage or explosion.

Comcast or Direct TV : 10030

Dish Network : 506
RCA Universal : 0030

30 30

IR Receiver

Cable / Satellite Remote Control Codes:

NOTE: The remote control from your Cable/Satellite provider can be programmed to operate most

of the major functions of this TV model which include:

POWER, INPUT / SOURCE, VOLUME +,

VOLUME - , CHANNEL +, CHANNEL - , SELECT/OK/ENTER

(based on your remote), and NUMBER

buttons. For non-major TV functions not listed, use the remote control included with this TV.

T

o program your Cable / Satellite remote to operate this ETEC TV, follow the programming instruc-

tions included with your providers’ remote and use the following codes.

• Turn the remote over and remove
battery cover.

• Place two (2) “AAA” batteries into
the battery compartment with the “+”
and “-“ ends facing as indicated.

• Replace the cover

AT & T (U-verse) : 1043

40E700-9

Remote Control

Overview

40E700

40E700-10

Remote Control

Overview

Button Function

1. POWER Turn the display ON or OFF (Standby).

2. DISPLAY Provides program information for program being viewed.

3.

PLAY/PAUSE (USB)

4. PREVIOUS (USB)

5. NEXT (USB)

6. STOP (USB)

7. REP REPEAT (USB)

8. CH.LIST Press to display a list of channels saved in the TV tuner memory.

9. GUIDE Press to review scheduled programming for the currently viewed channel.

10. FAV Press to display a listing of your favorite TV channels.

11. FREEZE Pause and still-frame the current image on the display. Press again for live TV.

13. TEMP Select the Color Temperature COOL > NORMAL > WARM.

14. qptuARROWS / ENTER

Press the navigation buttons for moving through the menu options. Press the

15. EXIT Press to exit a displayed menu.

16. RETURN Press to return to the previous menu.

17. SLEEP Press to activate the Sleep function. The TV will automatically turn off after; 5 >

18. MENU Press to display the Main menu.

19. ASPECT

Select the viewable display aspect options: Normal, Wide, Zoom, or Cinema.

20. VOLUME (+ / -) Adjust the volume up (+) or the volume down (-).

21. LAST Press to switch between the current channel and previously viewed channel.

22. MUTE Press to temporarily turn off the TV audio. Press again to resume.

23. CHANNEL (qp)

Change the channel up or down.

24. NUMBERS / DASH Select desired TV channel directly. For example: to select digital channel 4-1,

press “4”, press “-”, and press “1” = (4-1).

25. INPUT Press to display all of the input sources on screen.

27. MTS Press to select a program’s second audio channel (if available).

28. CCD

Press to select closed caption subtitles (if available) Off> On > CC on mute.

29. NUMBER KEYS

Press number keys to enter channel numbers.

12. PICTURE

Standard>Dynamic>Soft>User>Power Saving

10 > 15 > 30 > 60 > 90 > 120 > 180 > 240> (minutes)> OFF.

26. AUDIO

Standard>Music>Movie>Sports>User

40E700-11

TV Overview

IR Receiver

2. INPUT - After connecting your DVD, cable box, etc. select the appropriate input source to view. Press the
INPUT button to display the input options. Press the CH+ / CH- buttons to highlight the input source and
press the VOL+ button to select.

3. MENU - Press the MENU button to display. Press VOL+ to select from the 6 menu options available.
Press the CH+ / CH- buttons to select a feature from the selected menu then press the VOL+/VOL- buttons
to adjust the volume settings.

4. Channel (-CH+) - Press the CH- / CH+ buttons to select a channel in the TV mode.

5. Volume (-VOL+) - Press the VOL- / VOL+ buttons to adjust the volume up or down.

Front & Side Panel

    

A soft blue light illuminates when the
television power is on.

1. POWER - Press the POWER button to turn the TV ON/ OFF (standby). The screen image will
appear within a few seconds, and the Blue LED will turn on.

Input Source

PC

Media

HDMI1
HDMI2
HDMI3

40E700-12

NOTE: You must remove the
pedestal before wall mounting.

TV Overview

Rear Panel

 















8. USB Input Port

supports MP3 and JPEG.

3. HDMI

video and up to 7.1-channel digital audio all from one cable. Recommended for best performance. HDMI cable not
included.

4.

PC Audio Input (3.5mm) - 3.5mm audio cable (not included) for sound.

VGA Input - Connect an optional VGA cable (not included) from your personal computer.

5. CABLE / ANTENNA

- Connect an antenna or cable connection for television reception.

Note: Use an outdoor antenna, cable or satellite for best reception.

9. EARPHONE - Connect a stereo headphone (3.5mm - not included) for private listening.

1. COAXIAL OUT - Connect an optional coaxial digital cable (not included) through a compatible amp/receiver to

enjoy superior audio sound.

6. AV - Connect an external device to the composite VIDEO (V) and AUDIO (L/R) out jacks found on most
equipment.

7. Component Y Pb Pr Input - Connect to an AV device that features component (Y Pb Pr) video and audio output
jacks.

2. AR/L udio Out- Connect to audio receiver.

Note: HDMI3 has ARC function.

Wall Mounting

It is recommended that you
consult a professional before
mounting this TV a wall.

Use VESA 200 x 100 wall
mount hardware.

40E700-13

Installation

Connection to HDMI Input

Blu-ray, HD DVD, or Game Console

How to Connect

• On the back of your device, connect the HDMI cable form HDMI out on

device to HDMI in on the panel.

How to Use

• Press the INPUT button on the remote, then use the qp arrows to

highlight HDMI. Press ENTER .

Coaxial / RF Cable

(not included)

Optional HDMI cable ( not included )

Cable / Satellite
set top box

Optional HDMI cable ( not included )

Digital set top box, gaming console, or
blu-ray w / HDMI interface

Digital Cable / Satellite Set Top Box

How to connect

• On the back of your device, connect the HDMI cable from HDMI out on device to HDMI in on the panel.

How to Use

• Press the INPUT button on the remote, the use the qp arrows to highlight HDMI. Press ENTER .

NOTE: You can also connect a digital cable/satellite box using an RF coaxial (75 ohm) cable. Most cable/satellite
systems require the TV to be set to Ch. 3 or 4 to display a picture.

HDMI

Input Source

PC

Media

HDMI1
HDMI2
HDMI3

40E700 -14

Installation

Connection to Component
YPbPr Input

How to Connect

• Match and insert the green (Y), blue (Pb), and red (Pr) cables into

the device and TV. Next, connect the red and white (L & R) audio
cables.

*NOTE: The picture will be black & white if hooked up incorrectly.
You must hook up audio cables separately.

How to Use

• Press the INPUT button on the TV remote. Then use the qp

arrow buttons to highlight Component. Press ENTER.

Connecting a device with a Component connection.

Optional Component cables
(not included)

Digital set top box, gaming console or DVD

R L Y Pb Pr

Input Source

PC

Media

HDMI1
HDMI2
HDMI3

40E700-15

Installation

Connection to Composite Input

Connecting a device with a Composite connection.

How to Connect

• Match and insert the yellow, red, and white A / V cables into the

device and TV.

How to Use

• Press the INPUT button on the remote. Then use the qp arrow

buttons to highlight AV. Press ENTER.

Audio Video Cable (included)

Digital set top box, gaming console or DVD

Input Source

PC

Media

HDMI1
HDMI2
HDMI3

40E700-16

Installation

Connection to Antenna &
Cable / Satellite Box

We recommend using a high quality roof top antenna, digital cable, or satellite box for the best display and
performance.
Note: Reception quality is determined by your location, geographical terrain, distance from the local
broadcast transmitter, and strength of antenna.

Connecting an antenna or basic cable
service:

• Connect the RF coaxial (75 ohm) cable from

existing roof top / in door antenna, or wall outlet.

• Finger tighten the Coaxial / RF Cable end to the

TV input on the panel.

Coaxial / RF Cable (not included)

Ant./Cable

Wall Outlet

Roof Antenna / Cable Outlet Installation

Connecting to POWER IN

• Connect the power cord to a properly grounded AC outlet.

40E700-17

Installation

Connection to a Personal Computer

Connecting a PC or laptop

Connecting to an amplifer or home theater system

Recommended computer display resolution:1920x1080@60 Hz

How to Connect a PC

• Connect using a male to male VGA cable (not included) from your PC to

the “VGA” on the TV’s panel.

How to Connect Audio Sound

• Connect a 3.5mm audio cable (not included) from the computer’s mini

audio output jack to the audio input on the TV’s panel.

How to Use

• Press the INPUT button on the remote control. Use the buttons qp to

highlight PC. Press ENTER.

NOTE: If your PC uses a standard signal mode, the screen will adjust
automatically.

VGA & Audio Cable (not included)

Audio Cable (not included)

• Match and insert the red and white audio cables from “Line Out”

NOTE: The TV’s speakers will still output audio. You can turn the

TV’s speaker volume to 0 to prevent echoing.

Input Source

Media

PC

HDMI1
HDMI2
HDMI3

40E700 -18

How to Use (Video)

Press the appropriate INPUT button on the remote. Use ▼ ▲ arrow buttons to
highlight the input source to view and then press ENTER.

How to Use (Audio)

Select the appropriate input from your audio equipment.

*NOTE: Refer to the User Manual from your home theater equipment for recommended audio settings.

Installation

Connection to a Home
Theater System

Connection to a Home Theater Audio System

Connecting to a Home Theater System

Digital audio can deliver optimal 2 - channel stereo or 5.1 surround sound with
Five discrete full range channels plus a separate channel for a subwoofer.

Connect an optional digital cable directly to the television’s COAXIAL OUT
audio output and listen through all inputs except VGA. (VGA does not support
digital audio)

How To Setup Digital Output

• Press the MENU button on the remote control.

• Press the right u arrow button to select Sound.

• Press the down q arrow button to highlight Digital Audio output.

• Press u to select Raw or PCM

Optional digital cable
(not included)

Front Left
Speaker

Front Right

Speaker

Center Channel

Dolby Surround

Connection Illustration

Optional cables

(not included)

Surround Left

Speaker

Surround Right

Speaker

Digital set top box, gaming
console or DVD

Dolby Prologic

Surround Receiver

Select Move Exit

Sound Mode
Bass
Treble
Balance

MTS

Digital Audio output

Audio Language

Surround sound

STEREO

English

User

Off

Raw

50
50

0

AVL

Off

40E700-19

TV Setup

Initial Setup Wizard

Initial Setup Wizard

IMPORTANT NOTE: If your TV is connected to a Cable or
Satellite set top box DO NOT run the “Channel Auto Scan”

NOTE: the Setup Wizard only appears when turning on the TV for the first time.

How to Navigate the Setup Menus:

Use the pq arrow buttons on the remote to move to the menu selection.

in STEP 3.

After connecting your TV antenna or cable wire, turn the television ON.

The quick Setup Wizard will display on-screen to help guide you through the 3 steps listed below:

STEP 1: Choosing a Menu Language

Use the tu arrow buttons on the remote to choose the desired menu option.

Use the pq arrow buttons to select Menu Language.

Use the tu arrow buttons to select English > Francais > Espanol.

˜

Use the q arrow button to seletct Go to next step and press the

u button to complete the step.

STEP 2: Setting the Time

Use the pq arrow buttons to select Time Zone, Daylight Saving

Time, and Time Format selections.

Use the tu arrow buttons to select the desired setting.

Use the q arrow button to seletct Go to next step and press the

u button to complete the step.

40E700-20

TV Setup

Initial Setup Wizard

STEP 3: Setting Air/Cable and Channel Auto Scan

Use the tu arrow buttons to select Air or Cable based on your

type of connection (Antenna or Cable without a set top box).

For Antenna & Cable Connections WITHOUT a set top box:

Use the q arrow button to seletct Go to next step and press the

u button to begin the Channel Auto Scan.

Note: Your type of television connection will determine if you should complete the
Channel Auto Scan part of this step.

Channel Auto Scan may take several minutes to complete.

For Cable/Satellite Connections WITH a set top box:

Press the MENU button on the remote control to exit the Setup
Wizard.

NOTE: You will see the message “PLEASE RUN AUTO SCAN”
on the screen. Ignore this message as this is not necessary
when using a set top box.

Press the INPUT button on the remote control to display the

Next

Total Found

Input Source screen illustrated to the left.

Use the pq arrow buttons to highlight the input where the
set top box was installed. Press ENTER to select the desired
input.

Once Channel Auto Scan has ended, Initial Setup is
complete. You may now begin enjoying your TV, or
make further adjustments to the TV settings which are
explained in the following pages of this manual.

Input Source

PC

Media

HDMI1
HDMI2
HDMI3

Initial Setup is now complete. You may now begin enjoying your
TV, or make further adjustments to the TV settings which are
explained in the following pages of this manual.

40E700-21

TV Settings

TV Provider Setup
& Channel Auto Scan

To enter the Channel Menu:

• Press the MENU button

• Using the t u arrow buttons; scroll to highlight Channel

• Press the down q arrow buttons to highlight Air / Cable

Select Cable if you subscribe to a pay television service without a set top box.

• Press the t u arrow buttons to highlight Cable.

•

NOTE: Channel Auto Scan may take several minutes to complete.

Cable Mode

Air Mode

Select Air when TV is connected to an indoor / outdoor antenna.

• Press the t u arrow button to highlight Air.

•

NOTE: Channel Auto Scan may take several minutes to complete.

satellite set top box to one of the available inputs on the TV for viewing.

Next

Next

Total Found

Total Found

Channel List

Show/Hide

Channel Number

Channel Label

5-2

KSTP-SD

Next

Channel List

Show/Hide

Channel Number

Channel Label

5-2

KSTP-SD

Note: For Cable or Satellite users with a set-top box, there is no need to run Channel Auto Scan. Connect your cable

Yes

No

Yes

No

To make changes your TV provider or re-scan for available broadcast channels in your area, select the Channel Menu.

Press the q arrow button to highlight Auto Scan and press ENTER. Press the u arrow button to highlight YES
and press ENTER to begin Auto Scan.

Press the q arrow button to highlight Auto Scan and press ENTER. Press the u arrow button to highlight YES
and press ENTER to begin Auto Scan.

40E700-22

Menu Adjustments

Picture Settings

Note: When adjustments are completed, you may select another menu by pressing the Menu button.

The Picture menu offers options to enhance and refine the picture displayed on your TV based on ambient room light
and personal preferences. Adjustment options include contrast, brightness, color, sharpness and color temperature.

How to Navigate:

Press the MENU button on the remote control. Navigate using t u arrow buttons to select Picture. Press the down q

viewing environments. Depending on the ambient light level in the room, you may find one of the other Picture settings
more pleasing.

To make more critical adjustments based on your own preferences select the User mode.

Brightness
Contrast

Color Temperature

• Brightness

• Contrast

Press down q arrow button to highlight Brightness. Navigate
using the t u arrow buttons to increase or decrease overall
brightness.

Press down q arrow button to highlight Contrast. Navigate
using the t u arrow buttons to increase or decrease contrast
intensity.

Press down q arrow button to highlight Color. Navigate using
the t u arrow buttons to increase or decrease color intensity.

Press down q arrow button to highlight Tint. Navigate using
the t u arrow buttons to adjust colors toward green or reddish
tint.

Press down q arrow button to highlight Sharpness. Navigate
using the t u arrow buttons to soften or view crisper edges in
the picture.

Press down q arrow button to highlight your
Color Temperature preference. Navigate using the t u ar-
row buttons to select Cool (more bluish tone), Normal or Warm
setting.

• Advanced Settings

Adjust advanced video features to fine tune the picture.

Press u button to enter.

• Color

• Tint

• Sharpness

• Color Temperature.

arrow button to highlight Picture Mode, then press the u arrow button to select your viewing preference from 5 factory
options: Standard > Dynamic > Soft > User >Power Saving*. The Standard setting is recommended for most brightly lit

40E700-23

Menu Adjustments

Audio Settings

The Audio menu offers options to make sound enhancements while listening through the built-in speakers or to
select digital audio options when connected to a Dolby Digital receiver though a (SPDIF) coaxial digital output.

How to Navigate:

Press the MENU button on the remote control. Navigate using t u arrow buttons to select Sound. Press the q arrow
button to highlight Sound Mode, then press the u arrow button to select your sound preference from 5 factory options:
Music > Movie > Sports > User > Standard

Press down q arrow button to highlight Sound Mode.
Press

Press

t u button to select Music > Movie > Sports > User >

Standard.

Music: Preserves the original sound. Good for musical
programs.
Movie: Enhances treble and bass for a rich sound
experience.
Sports: Enhances vocals for TV audio.

User: Select to customize audio settings.

Standard: Produces a balanced sound in all environments.

• MTS

Press down q arrow button to highlight MTS.
Press t u button to select Mono>Stereo>SAP.
Mono: Sets the sound to mono.
Stereo: Sets the sound to stereo when stereo is not
available. The sound is automatically switched
to mono.
SAP: Sets the sound to the second audio program.

• Audio Language

Press down q arrow button to highlight Audio Language.
Press t u button to select English > Francais > Español.

• Digital Audio Output

Press MENU to enter the main menu, press t u button
to select Sound.
Press pq button to select among Digital Audio Output.
Press t u button to select (Raw / Off / PCM)

• Surround Sound

Press MENU to enter the main menu, presst u button
to select Sound.

Presspqbutton to select Surround Sound.
Presst u button to select (Off / On)

• AVL

•

Speaker

Press down q arrow button to highlight AVL.
Press t u button to select (Off / On)

Press down q arrow button to highlight SPEAKER.
Press t u button to select (Off / On)

Note: When adjustments are completed, you may select another menu by pressing the Menu button.

• Sound Mode

• Bass

• Treble

• Balance

Select Move Exit

Sound Mode
Bass
Treble
Balance

Digital Audio output

Speaker

Surround sound

User

Off

Raw

50
50

0

AVL

Off

Press down q arrow button to highlight Bass.

Press down q arrow button to highlight Treble.

Press down q arrow button to highlight Treble.

t u

Press

t u

buttons to increase or decrease low frequency

Press

t u

buttons to increase or decrease high frequency

intensity.

intensity.

buttons to adjust sound towards the left or right

speaker.

Sound Mode Standard
Bass
Treble
Balance

On

40E700-24

Menu Adjustments

Date & Time Settings

Note: When adjustments are completed, you may select another menu by pressing the Menu button.

The Time menu includes adjustment of settings for your local time zone and daylight savings time. The clock will adjust
automatically after the initial Channel Auto Scan of available broadcast channels in your area.

How to Navigate:

Press the MENU button on the remote control. Navigate using arrow t u buttons to select Time.

• Press down q arrow button to highlight Sleep Timer then
press the u arrow button to select time to view before the
television timer turns the set off: 5 Min > 10 Min > 15 Min > 30
Min > 60 Min > 90 Min > 120Min > 180 Min > 240 Min > OFF.

• Press down q arrow button to highlight Time Zone then
press the u arrow button to select between: Eastern > Central
> Mountain > Pacific > Alaska > Hawaii > Samoa >
Newfoundland >Atlantic.

• Press down q arrow button to highlight Daylight Savings
Time. Navigate using the t u arrow buttons to turn this

feature on or off.

• Press down q arrow button to highlight Time Format.
Navigate using the t u arrow buttons to turn this feature

12-hour or 24-hour.

• Press down q arrow button to highlight Auto Clock.
Navigate using the t u arrow buttons to turn this feature

on or off.

• Clock and Date are automatically set the first time the tuner

receives a broadcast channel.

1980/01/06/12:00 AM

40E700-25

Menu Adjustments

Setup Settings

In the Setup menu you may change the initial set up of preferences that include settings for language, menu display,
computer monitoring, closed captions, enhancement of black detail in the picture and resetting your TV back to its
factory default status.

How to Navigate:

Press the MENU button on the remote control. Navigate using arrow t u buttons to select Setup. Gain access to
display options by pressing the down q arrow button to highlight Menu Language or other options, then press u
arrow button on your remote to select.

NOTE: Closed Caption and Advanced are features described on the following pages.

Create labels for the devices
connected to your TV.
Press ENTER / u button to enter.

Set the parameter of audio only ,no
signal power off and no operation
power off.
Press ENTER / u button to enter.

Press the u ar row butt on t o
automatically reset all adjustments
back to their original factory settings.

• Input Label • Other Settings • Restore Default

Other languages include English,
Français, Español.

Navigate using the t u arrow but­tons to adjust the transparency of the

Adjust the duration of the
OSD (on screen display) menu.
Press t u button to select.

• Menu Languages • Transparent • OSD Time Out

Select Move Exit

Menu Language

Transparent

Closed Caption
Over Scan

OSD Timeout

Other Settings

Input Label

Restore Default
Setup Wizard

English

25%

30Sec.

• Setup Wizard

Set the first time installation.

Press ENTER / u button to enter.

CEC

•

CEC Settings

Set the options for controlling other
CEC enabled external devices
connected to the HDMI inputs.
Refer to your device

If this item is “On”, users can
control the volume of a compatible
external amplifier through adjusting
the TV’s volume.

’s manual for CEC options.

Select Move Exit

Menu Language

Transparent

Closed Caption
Over Scan

OSD Timeout

Other Settings

Input Label

Restore Default
Setup Wizard

English

25%

30Sec.

CEC

Select Move Exit

Menu Language
Transparent

Closed Caption
Over Scan

OSD Timeout

Other Settings

Input Label

Restore Default
Setup Wizard

English

25%

30Sec.

CEC

Select Move Exit

Menu Language
Transparent

Closed Caption
Over Scan

OSD Timeout

Other Settings

Input Label

Restore Default
Setup Wizard

English

25%

30Sec.

CEC

Select Move Exit

Menu Language
Transparent

Closed Caption
Over Scan

OSD Timeout

Other Settings

Input Label

Restore Default
Setup Wizard

English

25%

30Sec.

CEC

Select Move Exit

Menu Language
Transparent

Closed Caption
Over Scan

OSD Timeout

Other Settings

Input Label

Restore Default

Setup Wizard

English

25%

30Sec.

CEC

Select Move Exit

Menu Language
Transparent

Closed Caption
Over Scan

OSD Timeout

Other Settings

Input Label

Restore Default

Setup Wizard

English

25%

30Sec.

CEC

Select Move Exit

Menu Language
Transparent

Closed Caption
Over Scan

OSD Timeout

Other Settings

Input Label

Restore Default
Setup Wizard

English

25%

30Sec.

CEC

on screen display menu.

40E700 -26

Menu Adjustments

Note: When adjustments are completed, you may select another menu by pressing the Menu button.

Closed Captions

The Setup menu includes adjustments for activating the Closed Caption text feature for display on-screen and customiz-
ing CC display types and font styles.

How to Navigate:

Press the MENU button on the remote control. Navigate using arrow t u buttons to select Setup.

• Press the down q arrow button to
highlight Closed Caption then press
the u arrow button to highlight CC
Mode.

• Navigate using the t u arrow
buttons to select CC Off > CC On >
CC on Mute.

• Press down q arrow button to
highlight Analog CC. Navigate using
the t u arrow buttons to select
CC1-4, TEXT1-4.

• Press down q arrow button to
highlight Digital CC.
Navigate using the t u arrow
buttons to select Off, Service 1-6.

• Press down q arrow
button to highlight Option. Press
the u arrow button to enter a menu
with options to customize text fonts,
colors and opacities.

Select Move Exit

CC Mode

Analog CC

Option

Digital CC

CC Off

CC1

Service1

Select Move Exit

CC Mode

Analog CC

Option

Digital CC

CC Off

CC1

Service1

Select Move Exit

CC Mode
Analog CC

Option

Digital CC

CC Off

CC1

Service1

Select Move Exit

CC Mode
Analog CC

Option

Digital CC

CC Off

CC1

Service1

Select Move Exit

Menu Language
Transparent

Closed Caption

Over Scan

OSD Timeout

Other Settings

Input Label

Restore Default
Setup Wizard

English

25%

30Sec.

CEC

40E700 -27

PC Menu Adjustments

In the Setup menu you may adjust the position of images displayed on screen once you connect an input signal from
your PC. The recommended resolution is 1366x768. For use with a laptop computer, refer to your computer’s user
manual on instruction for proper display output. If your PC system uses a standard signal mode, the TV screen will
adjust automatically. Connect an optional 3.5mm audio cable for stereo sound.

Advanced Settings

How to Navigate:

After connecting to a PC, press the INPUT button on the remote control, Use the qp buttons to highlight the PC input
and press ENTER. Press the MENU button on the remote control and navigate using arrow t u buttons to select
Setup.

• Gain access to position adjustment

options by pressing the down q arrow
button to highlight PC Settings, then
press u arrow button to select from
the following options.

• Highlight H-Pos. Navigate
using the t u arrow buttons to
adjust the position of image s
displayed from side to side.

• Highlight V-Pos. Navigate
using the t u arrow buttons to
adjust the position of image s
displayed up and down.

• Highlight Clock. Navigate
using the t u arrow buttons to
control the width of the image.

• Highlight Phase. Navigate
using the t u arrow buttons to
improve focus and image stability.

• Highlight Auto. Press the u
arrow button to automatically adjust
the display to the best setting.

50

27

H-POS

V-POS

Phase
Auto

98

Clock

50

50

27

H-POS

V-POS

Phase
Auto

98

Clock

50

Select Move Exit

Select

Move

Exit

50

27

H-POS

V-POS

Phase
Auto

98

Clock

50

50

27

H-POS

V-POS

Phase

Auto

98

Clock

50

50

27

H-POS

V-POS

Phase

Auto

98

Clock

50

Select Move Exit Select Move Exit Select Move Exit

Select Move tixE

Menu Language
Transparent

Closed Caption
Over Scan

OSD Timeout

Other Settings

Input Label

Restore Default

CEC

English

25%

30Sec.

PC Settings

Menu Adjustments

CEC Settings

The CEC menu includes options for controlling functions of compatible external devices connected via the HDMI input.

Please refer to the instruction manual of your connected device to confirm if CEC control is possible.

How to Navigate:

Press the MENU button on the remote control. Navigate using arrow t u buttons to select Setup

• Press the down q arrow
button to highlight CEC then press
the u arrow button to highlight
CEC Control.

• Navigate using the t u arrow
buttons to select On > Off. When you
select On, the CEC functions open.
Otherwise the CEC functions close.

• Press down q arrow but-
ton to highlight Device Auto Power
Off. Navigate using the t u arrow
buttons to select On>Off.

If this item is “On”, the external device
will be turned off automatically when
the TV is powered off

• Press down q arrow button to
highlight TV Auto Power On.
Navigate using the t u arrow
buttons to select On> Off

If this item is “On”, when the TV is
turned on, the external device will turn
to HDMI mode automatically during
powering on.

If this item is “On”, users can control
the volume of the external amplifier
through adjusting the TV's volume.

• Press down q arrow button to
highlight Audio Receiver. Press
thet u arrow button to select On>
Off.

Note: When adjustments are completed, you may select another menu by pressing the Menu button.

Select Move Exit

Device Auto Power Off

Audio Receiver

TV Auto Power On

Connect
Root Menu

On
On

On

CEC Control On

Select Move Exit

Menu Language
Transparent

Closed Caption

OSD Timeout

Other Settings

Input Label

Restore Default

CEC

English

25%

30Sec.

Setup Wizard

Select Move Exit

Audio Receiver

TV Auto Power On

Connect
Root Menu

On
On

CEC Control On

Device Auto Power Off

On

Select Move Exit

Audio Receiver

Connect
Root Menu

On

CEC Control On
Device Auto Power Off

On

TV Auto Power On

On

Select Move Exit

Audio Receiver

Root Menu

On

CEC Control On
Device Auto Power Off

On

TV Auto Power On

On

Connect

Select Move Exit

Audio Receiver

On

CEC Control On
Device Auto Power Off

On

TV Auto Power On

On

Connect

Root Menu

Select Move Exit

Root Menu

CEC Control On
Device Auto Power Off

On

TV Auto Power On

On

Connect

Audio Receiver

On

• Press down q arrow button to
highlight Connect. Press the u ar­row button to connect TV and DVD
Player.

• Press down q arrow button to
highlight Root Menu. Press the uar­row buttons to enter DVD menu.

40E700 -28

40E700 -29

NOTE: RRT Setting and Reset RRT are not user adjustable settings.

Menu Adjustments

Parental Control

In the Lock menu, you may block television and movie programming based on TV ratings and Motion Picture Association
guidelines. To gain access and select your preferences within the Parental menu make certain your input is set to TV.

How to Navigate:

Press the MENU button on the remote control. Navigate using arrow t u buttons to select Lock. Gain access to
parental rating options by pressing the down q arrow button to highlight Enter Password. Enter your 4 digit code
(factory default code is “0000”) unless previously changed.

• To change the password, press
u arrow button to display a screen
to enter your new password, then

confirm again. (not illustrated)

• To make changes to parental

controls, highlight System Lock
then press the t u arrow button
to ON.

• To set parental controls for television
programming or DVD movies, press
the qp arrow buttons to highlight

Navigate using the t u buttons to
highlight TV / MPAA menu.

• Highlight TV, then press the u
arrow button to enter the TV Ratings
menu and select your preference.

• Highlight MPAA, then press the u
arrow button repeatedly to select
your movie rating preference.

TV-Y Appropriate for all children
TV-Y7 Appropriate for all children over 7
TV-G General Audience
TV-PG Parental Guidance Suggested
TV-14 Parents Stron

gly Cautioned

TV-MA Mature Audience Only

G General Audience
PG Parental Guidance Suggested
PG-13 Parents Strongly Cautioned
R Restricted
NC-17 No One Under 17 Permitted
X Adults Only

Off Not applicable

Select Move

Enter Password

Exit

Change Password

System Lock
Input Block
US Rating
Canada Rating

PRT Setting
Reset RRT

Off

Change Password

System Lock

US
Canada

PRT Setting
Reset RRT

On

Select Move Exit Select Move Exit

Input Block

TV RATING

Press ENTER to Lock or Unlock: BLock

ALL FV VS LD
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA

TV

MPAA G

MPAA N/A

Select Move Exit

Select Move Exit

Select Move Exit

TV

US Rating.

40E700-30

Menu Adjustments

Parental Control

In the Lock menu, you may block television and movie programming based on Canadian TV and movie rating guidelines.
To gain access and select your preferences within the Parental menu make certain your input is set to TV.

How to Navigate:

Press the MENU button on the remote control. Navigate using arrow t u buttons to select Lock. Gain access to
rating options by pressing the downq arrow button to highlight Enter Password. Enter your 4 digit code (factory
default code is “0000”) unless previously changed.
Then press the qp arrow buttons to highlight Canada. Navigate using the t u buttons to highlight Canada English.

• Navigate using down q arrow button to highlight
Canada English then press the t u arrow button
repeatedly to select your ratings preference.

Off Turn off
C Appropriate for all children
C8+ Appropriate for everyone 8 years old and up
G General Audience
PG Parental Guidance
14+ Appropriate for Children over 14 years old
18+ Mature Audience Only

• Navigate using down q arrow button to highlight

Canada French then press the t u arrow button
repeatedly to select your ratings preference.

Off Turn off
G General Audience
8 ans+ Appropriate for Children 8 years old and up
13 ans+ Appropriate for Children 13 years old and up
16 ans+ Appropriate for Children 16 years old and up
18 ans+ Mature Audience Only

Note: When adjustments are completed, you may select another menu by pressing the Menu button.

Select Move Exit

Canada English

Canada French Off

Off

Canada English

Canada French Off

Off

Select Move Exit

40E700-31

Menu Adjustments

Channel Settings

The Channel menu provides the setup / changes of your television to receive broadcast channels, store your favorite
channels, add or skip channels in memory and label or name channels.

How to Navigate:

Press the MENU button on the remote control. Navigate using arrow t u buttons to select Channel. Press the
down q button to highlight your preferences.

• Highlight Favorite to add channels to your Favorites List. Navigate using the ◄►▼▲ arrow buttons to select channels to be
added or deleted from your list. Press ENTER to add or delete a channel. A check

mark indicates a channel has been added.

You may also display your list of Favorite channels by pressing the FAV button on the remote control

• Highlight Show / Hide to select or skip channels already in memory. Navigate using the ◄►▼▲ arrow buttons to
access the list of available channels. Press ENTER to change the channels status. A checkmark indicates a channel
has been added.

• Highlight Channel Label to name or rename a broadcast channel. Navigate using the u arrow button to enter the
screen menu to re-label a channel. Use the qp arrow buttons to spell out each letter, number or character. Use t u
arrow buttons to advance to the next space.

• Favorite

• Show / Hide

• Channel Label

Select Move Exit

Air/Cable
Auto Scan

Favorite

Show/Hide

Channel list

Channel Number
Channel Label

Air

7-2

KABC-SD

Select Press ENTER change Exit

Channel Channel Label

46-1
50-0
50-1

50-2

50-3

Favorite

Select Press ENTER change Exit

Channel Channel Lael

7-0

7-1

7-2

7-3

9-0

KABC-DT

KABC-SD

KABC-WN

KCAL-DT

Hide

Select Move Exit

Air/Cable
Auto Scan
Favorite

Show/Hide

Channel list

Channel Number
Channel Label

Air

7-2

KABC-SD

Select Move Exit

Select Move Exit

Air/Cable
Auto Scan
Favorite

Show/Hide

Channel list

Channel Number

Channel Label

Air

7-2

KABC-SD

40E700-32

Aspect Modes

1. NORMAL

Recommended for viewing native widescreen content and undistorted 4:3
images (with black bars).

2. WIDE

Stretches certain 4:3 content and may reduce visible black bars.

3. ZOOM

viewing widescreen content. The Zoom effect will crop images somewhat.

4. CINEMA

n eliminating
visible side black bars. It may also eliminate or reduce black bars on certain
widescreen movies.

Press ASPECT to cycle through
the following widescreen settings.

The ASPECT function offers several viewing display options on the 16:9 screen. Press the ASPECT button to cycle
through the following widescreen settings.

NOTE: The ASPECT function is not available for digital broadcasts.

40E700-33

USB Modes

1. Press the INPUT button on the remote control to display the Input menu. Use the ▲▼ buttons to select Media.

2. Use the ◄ / ► buttons to highlight an individual USB option.

Press the ▲▼ buttons to select Media in the
Source menu, and then press the ENTER button
to enter.

• Press the ◄ / ► buttons to select Music, and
then press the ENTER button.

• Press the ◄ / ► to select the option you want
to hear , then press Enter button.

• Press the ▲ / ▼ to select return option to

return to the previous menu.

Media

PC

• Press the ◄ / ► buttons to select Photo or Mu-
sic, and then press the ENTER button to enter.

• Press the ◄ / ► buttons to select the option
you want to adjust in the main Media menu, then
press ENTER button.

• Press the ◄ / ► buttons to select Photo, and

• Press the ◄ / ► to select the option you want to

• Press the ▲ / ▼ / ◄ / ► to select return option

to return to the previous menu.

then press the ENTER button.

watch, then press Enter button.

Press the arrow buttons to select a play mode,

Press MENU to return to the previous screen

then press ENTER to select desired play mode.

Press arrow buttons to hide the menu in the bottom.

40E700-34

1920 x1080

120 W

160

40

36.5 x 3.6 X 21.6"

40E700-35

Troubleshooting

Symptom Possible Solutions

Cannot receive certain
channels through the
antenna

• Perform Channel Scan to add channels into the TV tuner memory.
See page 29.

• Readjust your antenna and retry Auto Channel Scan.

• Signal from the TV station may be weak in your area.

No color • Check the video installation of your external A / V equipment.

See pages 13-18.

Video noise or choppy picture • Readjust antenna. Keep TV away from noise sources, neon lights,

and microwave appliances.

TV blocked on certain channels • Perform Channel Scan to add channels into the TV tuner memory.

See page 29.

• Check whether the channel was deleted. See page 29.

• Check parental control settings. See page 30,31.

• Restore default settings. See page 24.

Cannot use certain functions • If the item chosen in a menu is shown in gray text, that item cannot be

selected in the current input.

No sound • Check that connected audio cables are completely inserted.

See page 22.

• Mute function may be enabled, press mute on the remote.

Black box on screen • The “Text” option is enabled and no text is available.

• Press the CCD button on the remote control to turn off.

No power • Batteries in the remote control may need replacing.

• Re-attach AC plug to wall outlet.

No picture • Digital TV channel signal maybe weak, try another channel.

• Press INPUT button to verify the desired input selected.

• Re-connect the antenna or cable wiring.

• Restore default settings. See page 27

Remote control does not function • Replace batteries with new ones.

• Check that battery polarity is correct.

• Point remote directly at the TV’s IR receiver. See page 8.

40E700-36

LIMITED ONE-YEAR TELEVISION WARRANTY

We warrant this product to be free from defects in material and workmanship under normal use for
a one-year period from the original date of purchase from an authorized ETEC dealer. We will repair
or replace the unit free of charge should it become defective under this warranty, providing you, the
original purchaser, submit proof of purchase (sales slip) along with the TV and all accessories.

During the one-year period from the original purchase date, we will service or exchange the TV, at no
charge. To obtain warranty service or replacement within the duration of the one-year warranty,
please return the product and all accessories to the original place of purchase.

For technical support, the ETEC Technical Support Center is available Monday to Friday (9:00AM to
9:00PM EST) and Saturday (9:00AM to Noon) for technical assistance or troubleshooting at
1-800-936-1168.

This warranty does not cover any product which has been subject to damage due to an act of nature,

including the antenna. Damage to any external media such as DVD, CD, and/or USB or other memory
devices are not covered nor is the cost incurred in shipping the unit for warranty repair. Under no
circumstances shall ETEC be liable for any loss (direct, indirect, incidental, foreseen, unforeseen,
special or consequential) or for any damage arising out of, or in connection with, the use of this
product.

UNDER NO CIRCUMSTANCES WILL ETEC BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES.

This warranty does not cover re-manufactured units, or product sold 'As Is'.

This warranty is valid only to the original purchaser of the Product in the United States and Canada
