ETC LED10 Data Sheet

GENERAL INFORMATION

The PhaseAdept Dimmer Module is a dual-density dimmer module for use in any ETC power enclosure without concern for the age of the equipment. The PhaseAdept Module provides forward- or reverse-phase angle dimming speciﬁcally designed for compatibility with LED ﬁxtures and replacement lamps. The design features high-density modular assembly, fully-magnetic and fully-rated circuit breakers. Phase angle and min scale control are available electronically when used with Sensor 3 and DRd enclosures (CEM3, E-ACP, or P-ACP controllers) and manually if used with Sensor, Sensor+, Unison DR, and Unison DRd with SmartLink (MPE , CEM, CEM+, S-ACP, CMd, or CMEd,control processor.)

APPLICATIONS

• LED replacement lamps

• Electronic low-voltage transformers

• Electronic LED power supplies requiring forward or reverse phase control

FEATURES

• High-performance dimming of LED loads compatible with any new or installed ETC Sensor or Unison rack

• Two dimmers per module

• High-density modular assembly

• Fully-rated circuit breakers

• Min scale controls

• Forward- or reverse-phase dimming

REGULATORY AND COMPLIANCE

• UL and cUL LISTED

• CE compliant

PhaseAdept Dimmer ModulesETC

Specialty Module Series

GENERAL INFORMATION

Module Variants

MODEL PART NUMBER INPUT VOLTAGE LISTING

LED10 7050A1296 120V cULus

ELED6 7070A1426 220V-240V CE

ELED6N 7070A1428 220V-240V CE

ELED6R 7070A1427 220V-240V CE

ALED5 7183A1210 277V cULus

HLED6D2 7070A1429 240V Delta -

LED10NJ 7050A1297 100V UL

LED10RJ 7050A1298 100V UL

Compatible Power Enclosures

MODEL PROCESSOR INPUT VOLTAGE LISTING

SR3(AF) CEM3 120V cULus

ESR3(AF) CEM3 230V CE

HSR3(AF) CEM3 240V UL

SR3J(AF) CEM3 100V UL

SP3(AF) CEM3 120V cULus

SR+(AF) CEM+ 120V cULus

ESR+(AF) CEM+ 230V CE

HSR+(AF) CEM+ 240V UL

HSRD2+(AF) CEM+ 240V Delta -

SR+J(AF) CEM+ 100V UL

SP+(AF) CEM+ 120V cULus

SR(AF) CEM, MPE 120V cULus

ESR(AF) ECEM 230V CE

HSR(AF) HCEM 240V UL

SRJ(AF) CEM, MPE 100V UL

SP(AF) CEM, MPE 120V UL

DRd-120 DRd Dimming

Engine

DRd-277 DRd Dimming

Engine

DR-120 CMEd, CMd 120V, 230V cULus,

DR-277 CMEd, CMd 277V cULus

Note: PhaseAdept modules do not offer Advanced Features (AF), but are compatible for use with Sensor AF enclosures.

120V, 230V cULus,

277V cULus

1 of 3

PhaseAdept Dimmer ModulesETC

Specialty Module Series

SPECIFICATIONS

FUNCTIONAL

PhaseAdept modules can be set to two different control modes: Rack mode and Local mode. The control mode is set with a dipswitch that is not accessible when the module is mounted in a dimmer rack (Image 1). Physical covers are in place to help prevent unintended use of the manual controls used in Local Mode.

Rack Mode (default) - When the dipswitch is set towards the rear/backplane side of the module, the module is controlled by the dimmer rack control processor. This mode is supported by CEM3, CEM+, and Unison DRd racks. Please ensure that your control processor software is updated to the most recent version before installing PhaseAdept modules.

Local Mode (retroﬁt) - When the dipswitch is set towards the front/ label side of the module, the module is controlled by an internal dimming engine and manual controls for phase selection (Image 2) and min scale (Image 3). This mode allows PhaseAdept modules to run in any ETC dimmer rack in the ﬁeld.

• Phase Selection - two dipswitches allow for each output circuit to be either forward or reverse (default) phase. The top and bottom circuit breakers are tied to the left and right dipswitches, respectively. Setting the switch upwards will set the circuit to forward-phase dimming, setting the switch downwards will set the circuit to reverse-phase.

• Min Scale - two dials allow for each output to be set to a different min scale value to provide a dimming curve speciﬁc to the requirements of the dimmed load. A legend for using the min scale controls is included on the module label (Image

• Micro USB - there is a micro USB connection (Image 4) next to the min scale controls which supports module ﬁrmware updates. Modules do not need to be installed in a dimmer rack in order to be updated

IMAGE 1

SPECIFICATIONS

GENERAL

• Dual-density, plug in modules, for use in any Sensor or Unison power enclosure

• Provides forward- or reverse-phase angle dimming for LEDs and electronic low-voltage transformers

• UL and cUL Listed for continuous duty at 100% of rated load

PHYSICAL

• Modular plug-in assemblies

• Cast aluminum chassis, ﬁnished with textured epoxy paint

CIRCUIT BREAKERS

• Fully magnetic to eliminate nuisance tripping

• 10x inrush current rating

• 125%, 10-120 seconds, must-trip rating

• Rated for 100% switching duty applications

ELECTRICAL

• Modules available for dimmer racks with the following mains feeds:

- 100V - dual 10A

- 120V - dual 10A

- 230V - dual 6A

- 240V - dual 6A

- 240V Delta - dual, 6A total load

- 277V - dual 5A

• 1W minimum load

• 100,000A Short Circuit Current Rating (SCCR)

• Modules withstand hot-patching of cold loads up to full rating

• Not suitable for use with magnetic loads

POWER DEVICE

• Sealed, patented assembly

• Per-circuit LED indicators

• Integral bonded heatsink

• Integral temperature sensor

FILTERING

• High quality toroidal ﬁlters (see module chart for rise times)

LOW VOLTAGE DIMMING

• PhaseAdept modules provide forward- or reverse-phase dimming and are compatible with any ETC dimmer rack

• Phase dimming performance for LED lamps varies considerably depending on the manufacturer and model.

• Visit http://www.etcconnect.com/compatibility/ for details on a variety of speciﬁc lamps and information on how to send samples to ETC for testing.

2 of 3

IMAGE 4IMAGE 3IMAGE 2
