ESWAY ES1350, ES1350X, ES-1401 Cross Country User Manual
User Manual for ESWAY Off-road
ES1350: with Lead acid battery
ES1350X: with Lithium ion battery
Shenzhen Ocam electronic technology co., LTD
www.eswaychina.com
Welcome Use
The user manual comes with Esway for the users’ reference when Esway Smart
Vehicles are sold.
The user's manual applies to all the Esway Smart vehicles made by our factory. You
may find that some functions are different from that you have purchased before. It is
normal for different series.
The content and technical specification in this manual is valid when permitted to be
printed. But Shenzhen Ocam electronic technology co., LTD has the right to alter and
change technical specification or design without prior notification, and we will not
assume any obligation.
To ensure our Esway brings you the best driving experience, the best way is to read the
user manual carefully, you will learn how to drive the future transporter. After reading,
please keep the user manual well so that you can refer to it any time when you need.
The warranty card will come with Esway. You can find your warranty rights in the user
manual. Please read the user manual carefully so that you can know your rights and
responsibilities well.
Please maintain Esway according to the user manual so that you can keep the scooter in
the best condition. We have professional people who will supply you good after service
and answer any questions and problem you care.
Sincerely wish you have a nice driving!
Safety Instructions
For adults use only!
Please abide by your local traffic regulations!
Please wear helmet, knee and elbow guards for safety purposes.
Please read the relevant driving guidelines in this manual!
Our company is not responsible for the accident if you do not use it as the above
request.
It is hard for us to list all associated dangers when driving and maintaining Esway,
therefore, please be careful and pay attention to the safety of yourself and others when
riding.
The user manual contains important safety information --- Please read carefully.
2
2
Contents
Chapter I Introduction of Esway...........................................
4
Chapter II Parts Explanation...............................................
5
Chapter III Instruction of remote control of Esway......................
7
Chapter IV Getting Started..................................................
8
Chapter V Esway Driving.................................................
10
Chapter VI Charging.......................................................
13
Chapter VII Maintenance .................................................
14
Chapter VIII Notice ........................................................
15
Chapter IX Indicator and Sound Alarm......................... ... ....
16
Chapter X Technical Data..................................................
18
3
3
Chapter I Introduction of Esway
The working principle of the two wheeled Scooter is based on the basic principle called
"dynamic stability" which is the automatic balance ability of the vehicle itself. After
judging body posture position with a built-in precision solid gyroscope, the vehicles
electronic brain works out proper instructions through a sophisticated and high-speed
central microprocessor, electric scooter will drive the motor to balance the vehicle.
As a new transporter, Esway is difficult to classify in the traditional way, some people
think that Esway should be a kind of double-wheeled Unicycle, while other people think it
should be classed as a power stand-up Scooter, with its uniaxial double design which is
different from the traditional biaxial double scooter, for official road regulations, this
transporter is called Electric Personal Assistive Mobility Device (EPAMD)
The vehicle is equipped with dual wheels; its width is as narrow as a normal adult
shoulder's width. It is 46.5KG (Li-ion battery) or 55KG (lead acid battery) operated. It is
not necessary to have a brake or throttle during driving. When the driver leans his body
forward, Esway will run forward, when the body is upright, it will stop. It uses the
dynamic balance principle, as the body moves to change the center of gravity so as to
keep balance. Just as the human body stands and leans forwards it can lose balance, but
the body's natural instinct will maintain balance, the dynamic stability replicates this.
Esway uses the wheels to replace the function of the feet, reproducing the high precision
balance action of a human, it is also cheap and convenient to use. The energy comes from
two repeat charging BTM batteries which are free from maintenance. If sufficient power
is supplied to your battery, the full charge capacity will last continuous for 5 hours driving,
the driving range depends on the way you drive and ground conditions, driving on grass
and slopes will consume more driving power.
4
4
Chapter II Parts Explanation
Picture 1
1. Handle Bar/Turning Pipe
(1)Used to control and make the Esway turn left or right, turn around, rotate 360 degrees.
It also has support function and can play a subsidiary role in keeping body balance.
(2) The height is adjustable. The driver can adjust it according to his or her own height to
make the handle bar comfortable.
(3)Lock the steering rod after adjustment, then turn the handle bar to confirm that it has
had been locked.
(4)Above adjustment of the handle bar/ turning pipe should be locked in position before
driving.
(5)The turning pipe can be taken apart easily for carrying or storage.
5
5
2. Power Switch
(1) The power switch is used to turn on and off the power, when the power switch is on
the Esway will finish the initialization-settings.
(2) It is dangerous to stand on Esway without turning on the power.
3. Pedal Switch (SAFE switch)
(1)The pedal can be active up or down, it has a built in safety switch. Esway can check
whether someone on scooter by pedal switch.
(2) The pedal switch is safety insurance, when driving, if the driver leaves the Esway, the
pedal switch will reset and then will stop after 3 seconds siren alarm.
4. Indicator Lights on Pedal
(1)Green light (Operating light 1)
Battery is full, system is normal.
(2)Orange light (warning light 2)
Battery will run out soon.
(3)Red light (warning light 3)
Battery will run out completely
