E Star MID7114 User Manual

E STAR MID7114

USER MANUAL

1

For all respected users:

Important Declaration

1. Before using the tablet PC, please read all information provided by us first so that you can use this

product correctly. Please make sure that you have read this manual carefully before using this product.

2. Our company reserves the copyright of this manual, any random duplication or interpretation of the full

or partial manual is forbidden in commercial activities.

3. The information covered in this manual is all based on the latest information when compiling the
manual, and products are subject to change without notice for further improvement. We are not committed to
any mistakes or incidences caused by the manual. For additional product information, visit the company’s
web site.

4. When using this product, please make backup for the data by yourself and this company will just be
responsible for the product's hardware itself, and will not undertake any responsibility for any loss or damage
of personal data and information due to wrong operations of hardware.

Precautions

This manual includes important information on safety precautions and proper usage of this product. To

prevent any accident, please make sure that you have read this manual carefully before using this product.
 Do not keep this product in a place with a high temperature, humidity or too much dust. Especially do not

place this product in a car with all windows closed in summer, and keep out direct sunlight.

 Avoid dropping or shocking this product heavily and avoid shaking the TFT display violently, otherwise,

the TFT display may be damaged or cannot play correctly.

 Please choose a suitable volume. Avoid excessively high volume when using a headset. If you feel any

ear noise, please decrease the volume or stop using.

 Do not break the connection suddenly when this product is conducting formatting, uploading or

downloading operations, otherwise there may be program errors.

 This company will not undertake any responsibility for any memory loss due to product damage,

repairing or other reasons.

 Do not dissemble this product by yourself and do not clean the surface of this product with alcohol,

thinner or benzene.

 Do not use this product in a place where the using of electronic device is prohibited, such as on a plane.
 Do not use this product while driving a car or walking on the street, otherwise traffic accident may occur.

 This Company reserves the right to make any improvement on this product. No further notice will be

provided on any variation on the specification and design of this product!

 (This product has no water-proof function)

2

Main Functions:

● 7” HD TFT capacitive touch screen, resolution 800*480.

● Support built-in 0.3 Mega front camera (optional)

● Support built-in microphone recording function

● Support vibration function

● Support external USB mouse, keyboard, etc;

● Support OTG function, support U-disc, portable hard disc by OTG to transfer data. (While connecting to

portable hard disc, DC power must be connected to supply power for the product; otherwise the tablet PC will
get crashed due to insufficient power supply)

●Multiple network access to the Internet. Supporting Wi-Fi, you can enjoy the internet life anywhere,

anytime.

●Gravity sensor (G-sensor), in addition to the horizontal, vertical screen switch, you can also install various

software to extent this function, such as turning the text, switching songs, and funny games, etc.

●With Google Android intelligent operating system, abundant software extension function, you can make

your personalized space with apks by yourself.

●Supporting apk installation and application, abundant software can be downloaded and installed from

Android Market in your MID or from your PC to download from the Internet.

●With this product, you can easily have business and entertainment via abundant applications, such as
E-Mail, word, website browsing, news, instant messaging, financial, blog, games online, video online, stock
market , weather report , mobile TV, maps, fun software, etc.

●Supporting MP3, M4A, WMA, APE, FLAC, AAC, MID, WAV, AMR, OGG, etc.

●Supporting full HD video decoding (2160P, 1080P, 720P, 480P); video formats: MKV, AVI, RM/RMVB,

WMV, 3GP, MOV, MP4, ASF, MPG, DAT, VOB, FLV, etc.

●Supporting JPG, JPEG, BMP, PNG, etc. formats image browsing..

●Supporting TF Card, with capacity up to 32GB.

●Personalized settings-freely adjustable brightness, key tone on or off, changing wallpaper and so on.

● Supporting multi-languages.

● More functions could be added by Firmware updating

Appearance and Buttons

Front:

Definition:

1. “ ”: Back, press this button to previous step or previous interface

2. “V-”: volume down
3“V+”: volume up

4. “ ”: Power Button-long press this button to turn On/Off the player, short

press this button to lock screen in order to avoid operation error.

5. Earphone Jack

6. MIC Recording Jack: microphone

7. USB Port: Micro USB 5 Pin data cable supports external U-disc, MP3,

MP4, wired mouse, 3G wireless Internet card, etc.

8. TF card slot

1. Quick Start
1-1. Power On/Off and unlock: at the status of power off, long press “ ”

for three seconds to turn on. It will take some time to power on, please wait.
It will take about 100 seconds to enter system, drag unlock icon “ ” to the

camera icon on the left to take photo and to the unlocking icon on the right to unlock, see below:

3

Energy-saving and locking mode: at the process of using, system will automatically enter energy-saving

mode, press “ ” to wake up the screen, system will enter unlocking mode in one second, slip “ ” to unlock.
Notes: At the status of energy saving mode, the main operation won’t stop, only LCD screen will be off,
showing black screen. Music or film continues playing.
Power Off: At the status of using, press “ ” for 5 seconds, the screen will show power off option. Select
“Power off” option, confirm your choice and system will automatically turn off. Select “Cancel” to cancel
power off operation.
Notes: At the status of low-power, it will have warning voice; connect the DC adapter and begin to charge, it
will automatically turn off. If the product cannot boot, please check the battery.

1-2. Battery and Charge

Battery should be charged for 8 to 12 hours for the first time in order to make sure battery with enough
power.
Please use charger approved by our company for charging. Before charging, insert the miniport of the
adaptor into DC jack and the other side into power socket. Then the device is being charged, the battery icon
will show the charging status. Please don’t disconnect the charger until device is fully charged. Battery icon
will show whether it is fully charged.

Please note the following precautions for protecting lithium battery
a. Don’t charge in high temperature environment (like under direct sunshine)
b. Lithium battery doesn’t need to discharge. User can charge the battery when there is still power left.
c. While charging, it is normal that both charger and device will heat up

1-3. Computer Connection & File Transfer

Connecting the product to the computer with USB cable, the top status bar will show USB has connected.

The product’s default is charging for USB connection mode. If connecting external mobile hard disk, you

need to pull automatic running list at the top status, then can see “USB connected” option. Click the option,

show USB status switch interface; according to the note icon on the right bottom “Open USB storage

equipment”, switch into USB storage status. At this time the users can access the external hard disk. At the

status of USB storage, click the icon again to disconnect USB and recover to charge mode. USB storage

mode system will limit the users’ access to the local disk reference application. Disconnecting USB storage

mode, it will recover normal status, same as the following picture:

1-4. Use of Touch Screen

4

There are various operation methods. You can view the main screen, menu and application program.

1-4-1. Click

When you want to use screen keyboard input or select the application program in the main interface, it

can be realized just use the fingers or stylus to click.

1-4-2. Press

When you want to open one available option or shortcut and main application in the main interface, just

press the option is ok.
1-4-3. Quick sway or sway

Quick sway or sway with your finger or stylus to make the vertical or horizontal drag fast action.

1-4-4. Drag

Before dragging, please use your finger or stylus to press, until get to the wanted location.

1-5. G-Sensor

The product has the function of G-sensor. After opening the function in the setting (default is open),
rotating the machine into 90 degree, the screen will realize horizontal and vertical screen switching
automatically.

Besides screen switching, it can support more function, such as turning the text, switching music and
funny games.

1-6. Solve problem of running slowly

After using the product for some time, although the used applications have been shut down but they are

still at work at background, and that will make the system run slowly. Therefore, you need to end these

programs in Advanced Task Manager to let the product run smoothly.

1-7. Text Entry

When you start application or select the text edit box to enter the text or number, the screen key board will

appear. The keyboard has the following input to select:

●Android keyboard

●Google Pinyin IME

1-7-1. Select IME

According to the preview setting of the product, Android keyboard will appear when you input the words.

1. In the main interface press the menu key, and then click the setting.

2. Click language & input

3. In the language & input area, the product will list the installed IME.

4. Tick it after selecting the IME you need.

Android Keyboard Panel

Google Pinyin IME Keyboard Panel

2. Main Interface Function/Icon

Main interface function icon definition

2-1.

5

Icon Definition Icon Definition

Google Search

Back Function Module Menu
Back to main interface from any interface
System current time

WIFI signal

New device found

Setting

Camera
Battery

Menu
Setting Menu

2-2. Main Interface

Long press power to turn on, the screen is locked after power on; slip unlock key to unlock and enter the main
interface as blow. In this interface, you can view the status, change wallpaper, add widgets, add program
shortcut, start program, etc.

2-2-1. Status Bar: With a stylus slide down to read prompts in the

status bar to open the notification bar and you can see today's date.

2-2-2. Menu. Press menu button “ ” or short press “ ” to open

interface menu:

●Wallpaper: in this menu you can choose your favorite photos as

main interface background.

●Manage Application Program: check all the programs in this

device and you can remove all installed programs

●System Set: click to enter system setting menu interface directly.

2-3. Add, move or delete desk icon

In the main interface click to enter function menu list, display applications in all webpages. Press and

hold to drag the icon to copy it to current desk, such as setting shortcuts on the desk.

You can delete the icon which is added to main interface, press and hold the icon which you are going to
delete, at this time there is a sign X on the top, just drag this icon to X to delete.

2-4. Shortcut: click to show all function icons as below:

This window shows all the function icons, click any icon to enter

correspond interface, see following definition:

apk program installer: you can install new apks, manage
installed apks. Please refer to (3. Program Installation) for operation
method.

Sending/Receiving Emails

6
