Essentials P70B17L-D5 Instruction Manual
—VALUE FOR MONEY
INSTRUCTION MANUAL
17 L MICROWAVE OVEN
MODEL: P70B17L-D5 (5418051)
EAN: 6001001626798
INDOOR HOUSEHOLD USE ONLY
Please save and read this instruction manual carefully before use.
ENGLISH
INTRODUCTION
PRECAUTIONS FOR AVOIDING POTENTIALLY
EXCESSIVE MICROWAVE ENERGY EXPOSURE
1. Do not attempt to operate this oven with the door open since open door operation can
result in harmful exposure to microwave energy. It is important not to defeat or tamper with the
safety interlocks.
2. Do not place any object between the front of the oven and the door or allow dirt or cleaner
residue to accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is crucial that the oven door close properly and
that there is no damage to the
a. Door (bent)
b. Hinges and latches (broken or loosened)
c. Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by anyone except properly qualified service
personnel.
CONTENT
PRECAUTIONS FOR AVOIDING POTENTIALLY EXCESSIVE MICROWAVE ENERGY
EXPOSURE ............................................................................................................................................... 1
IMPORTANT SAFETY INSTRUCTIONS .................................................................................................... 2
SPECIFICATIONS ...................................................................................................................................... 3
INSTALLATION .......................................................................................................................................... 3
RADIO INTERFERENCE ........................................................................................................................... 3
MICROWAVE COOKING PRINCIPLES ..................................................................................................... 4
GROUNDING INSTRUCTIONS ................................................................................................................. 4
BEFORE YOU CALL FOR SERVICE ......................................................................................................... 4
UTENSIL GUIDE ........................................................................................................................................ 5
COMPONENTS .......................................................................................................................................... 5
CONTROL PANEL ..................................................................................................................................... 6
OPERATION............................................................................................................................................... 6
CLEANING AND CARE .............................................................................................................................. 7
WARRANTY ............................................................................................................................................... 8
Thank you for purchasing our essentials microwave oven. Each unit has been
manufactured to ensure safety, reliability and ease of use. Before use, please
read these instructions carefully and keep safely for further reference.
2
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
Always follow these basic safety precautions
when using electrical appliances:
WARNING: To minimize the risk of burns,
electric shock, fire, personal injury or
exposure to excessive microwave energy:
1. Read all instructions before using the
appliance.
2. Use this appliance only for its intended
use as described in this manual. Do not
use corrosive chemicals or vapors in this
appliance. This type of oven is specifically
designed to heat, cook or dry food. It is not
designed for industrial or laboratory use.
3. Do not operate the oven when empty.
4. Do not operate this oven if it has a
damaged cord or plug, if it is not working
properly or if it has been damaged or
dropped. If the supply cord is damaged, it
must be replaced by the manufacturer, its
service agent or a similarly qualified
person in order to avoid a hazard.
5. WARNING: Only allow children to use the
oven without supervision when adequate
instructions have been given to ensure the
child is able to use the oven in a safe way
and understands the hazards of improper
use.
6. To reduce the risk of fire inside the oven:
When heating food in a plastic or paper
container, check the oven frequently for
possible burning.
Remove wire twist-ties from paper or
plastic bags before placing bag in oven.
If smoke is observed, switch off or unplug
the oven and keep the door closed in
order to stifle any flames.
Do not use the inside of the oven for
storage purposes. Do not leave paper
products, cooking utensils or food in the
oven when not in use.
7. WARNING: Liquid or other food must not
be heated in sealed containers as they
may explode.
8. Microwave heating of beverages can
result in delayed eruptive boiling, so care
has to be taken when handling a
container.
9. Do not fry food in the oven. Hot oil can
damage oven components and utensils
and even result in skin burns.
10. Eggs in their shell and whole cooked eggs
should not be heated in a microwave oven
as they may explode even after heating in
a microwave oven.
11. Pierce foods with heavy skins, such as
potatoes, whole squashes, apples and
chestnuts before cooking.
12. The contents of feeding bottles and baby
jars should be stirred or shaken and the
temperature should be checked before
serving in order to avoid burns.
13. Cooking utensils may become hot
because of heat transferred from the
heated food. Potholders may be needed
to handle a utensil.
14. Utensils should be checked to ensure that
they are suitable for use in a microwave
oven.
15. WARNING: It is hazardous for anyone
other than a trained person to carry out
any service or repair operation which
involves the removal of any cover which
gives protection against exposure to
microwave energy.
16. This product is a Group 2 Class B ISM
(Industrial, Scientific and Medical)
appliance, which means it uses local
radio-frequency energy to generate and/or
use electromagnetic radiation for the
treatment of material and spark erosion
equipment. Class B equipment is
equipment suitable for use in domestic
establishments and in establishments
directly connected to a low-voltage power
supply network which supplies buildings
used for domestic purposes.
17. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible for their
safety.
3
ENGLISH
18. Children should be supervised to ensure that they do not play with the appliance.
SPECIFICATIONS
Power consumption:
220-240 V~50 Hz, 1200 W (Microwave)
Rated microwave power output:
700 W
Operation frequency:
2450 MHz
Outside dimensions:
262 mm (H) × 452 mm (W) × 330 mm
(D)
Oven interior dimensions:
198 mm (H) × 315 mm (W) × 294 mm
(D)
Oven capacity:
17 litres
Cooking uniformity:
Turntable system
Net weight:
Approx.10.5 kg
INSTALLATION
1. Ensure that all packaging materials are
removed from the inside of the door.
2. WARNING: Check the oven for any
damage, such as a misaligned or bent
door, damaged door seals and sealing
surface, broken or loose door hinges and
latches and dents inside the oven or on
the door. If there is any damage, do not
operate the oven and contact qualified
service personnel.
3. This microwave oven must be placed on a
flat, stable surface to hold its weight and
the heaviest food likely to be cooked in the
oven.
4. Do not place the oven where heat,
moisture or high humidity is generated, or
near combustible materials.
5. For correct operation, the oven must have
sufficient airflow. Allow 20 cm of space
above the oven, 10 cm behind and 5 cm
on either side. Do not cover or block any
openings on the appliance. Do not remove
feet.
6. Do not operate the oven without the glass
tray, roller support and shaft in their proper
positions.
7. Ensure that the power supply cord is
undamaged and does not run under the
oven or over any hot or sharp surface.
8. The socket must be readily accessible so
that it can be easily unplugged in an
emergency.
9. Do not use the oven outdoors.
RADIO INTERFERENCE
Operation of the microwave oven can cause
interference to your radio, TV or similar
equipment.
When there is interference, it may be
reduced or eliminated by taking the following
measures:
1. Clean door and sealing surface of the
oven.
2. Reorient the receiving antenna of radio or
television
3. Move the microwave oven with respect to
the receiver.
4. Move the microwave oven away from the
receiver.
5. Plug the microwave oven into a different
outlet so that microwave oven and
receiver are on different branch circuits.
4
ENGLISH
MICROWAVE COOKING PRINCIPLES
1. Arrange food carefully. Place thickest
areas towards outer edge of dish.
2. Watch cooking time. Cook for the shortest
amount of time indicated and increase
time as needed. Severely overcooked
food can smoke or ignite.
3. Cover food while cooking to prevent
spattering and aid even cooking.
4. Turn food over once during cooking to
speed cooking of foods such as chicken
and hamburgers. Large items like roasts
must be turned over at least once.
5. Rearrange food such as meatballs
halfway through cooking (from both the
top and bottom and from the centre of the
dish to the outside).
GROUNDING INSTRUCTIONS
This oven must be earthed. It comes with a
cord with an earthing lead and plug. It must
be plugged into a power point that is properly
installed and earthed. In the event of an
electrical short circuit, earthing reduces the
risk of electric shock by providing an escape
lead for the electric current. It is
recommended that a separate circuit serving
only the oven be provided. Using a high
voltage is dangerous and may result in a fire
or other accident causing oven damage.
WARNING Improper use of the earthing plug
could lead to an electric shock risk.
Note:
1. If you have any questions about the
earthing or electrical instructions, consult
a qualified electrician or service person.
2. Neither the manufacturer nor the dealer
can accept any liability for damage to the
oven or personal injury due to failure to
observe the electrical connection
procedures.
The wires in this cable main are coloured in
accordance with the following code:
Green and Yellow = EARTH
Blue = NEUTRAL
Brown = LIVE
BEFORE YOU CALL FOR SERVICE
If the oven fails to operate:
1. Check to ensure that the oven is plugged
in securely. If it is not, remove the plug
from the outlet, wait 10 seconds and
securely plug it in again.
2. Check for a blown circuit fuse or a tripped
main circuit breaker. If these seem to be
operating properly, test the outlet with
another appliance.
3. Check to ensure that the control panel is
programmed correctly and the timer is set.
4. Check to ensure that the door is securely
closed engaging the door safety lock
system, otherwise the microwave energy
will not flow into the oven.
IF NONE OF THE ABOVE RECTIFIES THE SITUATION, CONTACT A QUALIFIED TECHNICIAN.
DO NOT TRY TO ADJUST OR REPAIR THE OVEN YOURSELF.
5
ENGLISH
UTENSIL GUIDE
1. The ideal material for a microwave utensil is the transparent one as it allows energy to pass
through the container and heat the food.
2. Microwaves cannot penetrate metal, so metal utensils or dishes with a metallic trim should not
be used.
3. Do not use recycled paper products when microwave cooking, as they may contain
small metal fragments which may cause sparks and/or fires.
4. Round /oval dishes rather than square/oblong ones are recommend, as food in corners tends to
overcook.
5. Narrow strips of aluminum foil may be used to prevent overcooking of exposed areas. But
be careful not to use too much and keep a distance of 2.54 cm between the foil and oven
walls.
The list below is a general guide to help you select the correct utensils
COOKWARE
MICROWAVE
Heat-resistant glass
Yes
Non heat-resistant glass
No
Heat–resistant ceramics
Yes
Microwave–safe plastic dish
Yes
Kitchen paper
Yes
Metal tray
No
Metal rack
No
Aluminium foil & foil containers
No
COMPONENTS
1. Door safety lock system
2. Oven window
3. Turntable roller
4. Control panel
5. Wave guide
6. Glass tray
6
ENGLISH
CONTROL PANEL
① Timer (0~30 minutes)
② Power select control
Power
Power Output
100%
High
85%
M. High
66%
Med
48%
M. Low
40%
Defrost
17%
Low
OPERATION
To set a cooking program: place food in oven and close the door.
Turn power select control Use timer to select the
to select the needed power level. correct cooking time.
NOTE: As soon as the timer is set, the oven will start cooking. When selecting a time of less than 2
minutes, turn timer past 2 minutes and then turn it back to the correct time.
CAUTION: Always return timer to the zero position if food is removed from oven before the set
cooking time has run its course or when oven is not in use. To stop oven during cooking process,
push the door release button and open the door.
7
ENGLISH
CLEANING AND CARE
1. Turn off the oven and remove the power
plug from the wall socket before cleaning.
2. Keep the inside of the oven clean. When
food splatters or spilled liquids adhere to
oven walls, wipe with a damp cloth. A mild
detergent may be used if the oven gets
very dirty. Avoid the use of sprays and
other harsh cleaners as they may stain,
streak or dull the door surface.
3. The outside surfaces should be cleaned
with a damp cloth. To prevent damage to
the operating parts inside the oven, water
should not be allowed to seep into the
ventilation openings.
4. Regularly wipe the door and window on
both sides, the door seals and adjacent
parts with a damp cloth to remove any
spills or spatters. Do not use an abrasive
cleaner.
5. Do not allow the control panel to become
wet. Clean with a soft, damp cloth. When
cleaning the control panel, leave oven
door open to prevent oven from
accidentally turning on.
6. If steam accumulates inside or around the
outside of the oven door, wipe with a soft
cloth. This may occur when the microwave
oven is operated under high humidity
conditions and is quite normal.
7. It is occasionally necessary to remove the
glass tray for cleaning. Wash the tray in
warm soapy water or in a dishwasher.
8. The roller ring and oven floor should be
cleaned regularly to avoid excessive noise.
Simply wipe the bottom surface of the
oven with a mild detergent. The roller ring
may be washed in mild soapy water or in
a dishwasher. When removing the roller
ring from oven floor for cleaning, be sure
to replace it in the proper position.
9. Remove odours from your oven by
combining a cup of water with the juice
and skin of one lemon in a deep
microwaveable bowl, and microwave for 5
minutes. Wipe thoroughly and dry with a
soft cloth.
10. When the oven light needs to be replaced,
please consult a dealer to do so.
11. The oven should be cleaned regularly and
any food deposits removed. Failure to
maintain the oven in a clean condition
could lead to deterioration of the surface,
which could adversely affect the life of the
appliance and possibly result in a hazards.
12. Please do not dispose of this appliance in
the domestic rubbish bin; it should be
disposed of at a disposal centre
specifically provided by municipalities for
this purpose.
Loading...
