Page 1
After Sales Service/Warranty Repairs
Call us at 201-439-1700
http://www.electra-craft.com
Electra-Craft, Inc.
41 Woodbine Street
Bergenfi eld, NJ 07621-3513
Follow instructions to download repair order form
MOD.26160
c/o The Smith Agency, Ltd.
P.O. Box 669307
Marietta, Georgia USA 30066.0106
Phone 770.509.3006
Fax 770.509.8736
espressione@smithagy.net
Page 2
25
27
24
9
10
Fig. 1
11
22
21
5
26
12
13
14
17
23
Fig. 4 Fig. 5
Fig. 6 Fig. 7
Fig. 8 Fig. 9
7
6
4
3
15
1
18
2
A
19 20
8
16
Fig. 2
B
C
D
E F
G
I
H
L
Fig. 3
Fig. 10 Fig. 11
Page 3
EN
SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed
to reduce the risk of fi re, electric shock, and/or injury to persons; in particular, we
recommend that you:
• Read all instructions and information in this instruction book and any other literature included in the
package referring to this product before operating or using this appliance.
• Do not touch hot surfaces. Use handles or knobs.
• Children should be supervised to ensure that they do not play with the appliance.
• This appliance is intended to be used in household and similar applications such as staff kitchen areas
in shops, offi ces and other working environments; farm hotels; by clients in hotels, motels and other
residential type environments; bed and breakfast type environments.
• To protect against fi re, electric shock and personal injury do not immerse cord, plugs, or the appliance
in water or other liquid.
• Close supervision is necessary when any appliance is used by or near children.
• Switch off and unplug this appliance when not in use and before cleaning. To cool down before putting
on or taking off parts, and before cleaning the appliance.
• Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or has
been damaged in any manner. Return appliance to authorized service centre for examination, repair
or adjustment.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualifi ed persons in order to avoid a hazard.
• The use of an accessory attachments not recommended by the appliance manufacturer may result in
fi re, electric shock or injury to person.
• Do not use this appliance outdoors.
• Do not let cord hang over edge of table or counter, or touch hot surfaces.
• Do not place on or near a hot gas or electric burner, or in a oven.
• Always attach plug to appliance fi rst, then plug cord into the wall outlet, to disconnect, switch off any
control, then remove plug from wall outlet.
• Do not use appliance for other than intended use.
• Do not open top lid and turn off fi lter holder while the machine is in operation. Wait until brewing cycle
is completed and all water and steam has been used out.
This appliance is not intended for use by person (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
Appliances with glass carafes.
A. The carafe is designed for use with this appliance only. It must never be used on a range top
B. Do not put a hot carafe on a wet or cold surface.
C. Do not use a cracked carafe or a carafe having a loose or weakened handle.
D. Do not clean carafe with cleansers, steel wool pads, or other abrasive material.
FOR HOUSEHOLD USE ONLY
ALWAYS SAVE THESE
INSTRUCTIONS.
1
Page 4
EN
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the other). As a safety feature, this plug will
fi t into a polarized outlet only one way. If the plug does not fi t fully into the outlet, reverse the plug. If it
still does not fi t, contact a qualifi ed electrician. Do not attempt to modify the plug in any way.
DO NOT DEFEAT THE SAFETY PURPOSE OF THE POLARIZED PLUG.
Special Cord Set Instruction:
1. A short power-supply cord (or detachable power-supply cord) is provided to reduce the risk resulting
from becoming entangled in or tripping over a longer cord.
2. Longer detachable power-supply cords or extension cords are available and may be used if care is
exercised in their use.
3. If a long detachable power-supply cord or extension cord is used,
a. The marked electrical rating of the detachable power-supply cord or extension cord should be at
least as great as the electrical rating of the appliance,
b. If the appliance is the grounded type, the extension cord should be a grounding-type 3-wire cord,
c. The longer cord should be arranged so that it will not drape over the countertop or tabletop where
it can be pulled on by children or tripped over.
Caution!
This appliance is for household use. Any servicing other than cleaning and user maintenance
should be performed by an authorized service representative.
• Do not immerse this coffee machine in water or any other liquid.
• To reduce the risk of fi re or electric shock, do not remove the base. No user serviceable parts inside.
Repair should be done by authorized service personnel only.
• Check voltage to be sure that the voltage indicated on the bottom agrees with your voltage.
• Never use warm or hot water to fi ll the water container, use cold water only.
• Never refi ll the water chamber while this coffee machine is running. Turn the coffee machine off before
refi lling with water.
• Do not place carafe on a hot surface or in a heated oven.
• Before turning on this coffee machine, please make sure that carafe sits fl at on inside circle of heating
plate.
• Never remove carafe before brewing is completely fi nished, i.e. dripping from the fi lter holder into the
carafe has stopped completely.
• Keep your hands and the cord away from hot parts of the machine during operation.
2
Page 5
DESCRIPTION OF THE APPLIANCE (FIG.1)
EN
1 - Carafe handgrip
2 - Carafe
3 - Carafe lid
4 - Hotplate for carafe
5 - Function keys
6 - Tank fi lling compartment
7 - Tank cover
8 - American coffee fi lter lid
9 - American coffee fi lter
10 - Filter support
11 - Dispenser
12 - Steam dispensing valve
13 - Steam wand
14 - Cappuccino maker
15 - Drip tray
16 - Cup rack
17 - Power cord + plug
18 - 1-cup coffee fi lter
19 - 2-cup coffee fi lter
20 - Coffee pod fi lter
21 - Filter block stop
22 - Filter holder for coffee powder
23 - Coffee presser/measure
24 - LCD display
25 - Filter support release button
26 - Cup warmer
27 - Hot water pour nozzle
DESCRIPTION OF FUNCTION KEYS (FIG.2)
A - Heating plate heat conservation hours
B - Programme setting clock icon
C - Clock Icon actual time
D - 1 cup / 2cups Icon
E - AUTO/CAFFE Button
F - Programming Button
G-H - Arrow Buttons
I - 1 cup / 2 cups Button
L - ESPRESSO Button
3
Page 6
EN
PRELIMINARY USE STAGES
Operation
Make sure that the domestic mains voltage is the same as that on the appliance rating plate. Place the
machine on a fl at surface.
Open the tank cover (7).
Fill the tank with tap water (max. 15° hardness) (Fig. 3).
NEVER fi ll the tank above the MAX level.
Plug the appliance into the mains socket, which must be earthed.
First Use
Before using the appliance for the fi rst time and also after a long period of non-use,
prepare several cups of water (without any coffee) to rinse the system through completely:
To rinse the Espresso and cappuccino maker
• Place one of the three fi lters in the fi lter holder (22)
• Tighten the fi lter holder on the left facing the external marking and turn it fi rmly to the right
• Place a large enough container under the fi lter holder .
• Turn steam control knob (12) to close position ‘●’
• Press “1cup/2cups” button on (I), then continue to press “ESPRESSO” button (L).
So the pump is then activated. If the boiler tank (water heating system) is empty (on fi rst use for
example) it will fi ll with water with a characteristic fi lling noise.
As soon as the water is running out of the fi lter holder, press “ESPRESSO” button (L) off.
• Allow the appliance to fi nish heating the water.
• Once the “ESPRESSO” light, (L) is off, press “ESPRESSO” button (L) again, allow 1 cup (green light)
water to run through button (I).
Repeat the action and pour the equivalent of two cups of water, pressing the button (I) (red light) and
three cups of water pressing the button (I) (blue light), interchanging the three fi lters every time.
Important!
After pouring coffee, wait at least ten seconds before disengaging the fi lter holder, turn it slowly to
from right to left, to prevent sprays or splashes of water or coffee.
Important!
Like on professional coffee machines, never remove the fi lter holder when the machine is opera-
ting; scalding hazard!
• Interrupt each time the process by pressing “ESPRESSO” button again.
To rinse the steam wand
• Place a container under the steam wand (13)
• Turn the steam control knob to ‘ ’ position
• As soon as the “ESPRESSO” light is off, slowly turn the steam control knob (12) to ‘MAX’ direction and
allow the steam to escape for about 10 seconds.
• Turn steam control knob (12) to close position’’●’
• Press “1cup/2cups” button (I) until the lit indicator switches off.
Important!
During the steam dispensing stage, never touch the surface of the steam wand, as they are very
hot. Danger of scalding.
It is also necessary to use containers in a material suitable for high temperatures (ceramic or
steel).
4
Page 7
EN
To clean the American Coffee elements
We recommend rinsing the machine parts with one or two cycles with running water only , without cof fee
powder. This will remove all traces of powder deposited during transport.
• Place the fi lter support (10) inside the machine, taking care that the notch in the support meets with
the release button (25) see (Fig.4).
• Place the American coffee fi
• Close the top lid (8).
• Place the carafe (2) on the hot plate (4).
• Switch on the “AUTO/CAFFE’ ” button (E).
• As soon as the water comes out of the spout (1 1) in the fi lter support (10), switch off the “AUTO/CAFFE’ ”
button (E).
Warning!
The hot plate (4) switches on as soon as the American Coffee is poured and therefore, during this stage, it is
necessary to keep hands well away from it and to remove the carafe using the handle (1).
Remove all water from tank, glass carafe and overfl ow grill after upon action.
Now you can start to use this machine for making your delicious coffee.
HOW TO MAKE ESPRESSO
• Fill the water tank (6) with fresh water.
• Turn the steam control knob to the ‘●’ position.
• Press “1cup/2cups” button (I) to select the amount of coffee to pour. Press once to select pouring of
one cup of coffee, at the same time the green light will be illuminated;
• Press twice to select two cups of coffee, the red light will be illuminated; Three times to select 3 cups
or one cup of pod coffee will be made, the blue light will switch on. Press again to shut off pouring.
• Continue to press “ESPRESSO” button (L). The pump is then activated. The “ESPRESSO” light (L) will
be fl ashed. Wait until a small amount of water fl ows out, which means that the boiler is pressurised.
• Press “ESPRESSO” button (L) off. As soon as the system has reached the required temperature, the
“ESPRESSO” light (L) will be off.
• Preheat the coffee cups by putting them on the cup rack (26) • Insert the correct fi lter into the fi lter
holder, choose the one-cup fi lter (18), the two-cup fi lter (19) or the pod fi lter (20).
• If using the fi lters (18) or (19), fi ll them with one or two measures of ground coffee and press down with
the measure (23); alternatively use the fi lter (20) and insert the standard 7g coffee pods.
• Insert the fi lter holder and turn it fi rmly to the right..
lter (9) in the fi lter support (10) .
If too much ground coffee is put inside the fi lter, turning the fi lter holder may prove diffi cult and/
or you may get leaks from the fi lter holder when the coffee is being dispensed.
• Place one or two espresso cups beneath the fi lter holder (Place one cup if using pods).
• As soon as the “ESPRESSO” light is off, Then press “ESPRESSO” button on again.
• When a suffi cient quantity has run through (normally one fi lter coffee grounds or one pod can make
about 60ml coffee), the machine will be auto shut off the pump. Otherwise you can press “ESPRESSO” button to interrupted the produce. (if you want to pour a lower coffee).
To remove coffee residues from the fi lter, lift the release to block the fi lter (21) over the edge of the fi lter
itself. Turn the fi lter holder upside down and tap it gently (Fig. 5).
When warming up, your appliance may release small puffs of steam from the fi lter holder; this is per-
fectly normal.
Filling the water tank during use.
No special operation is necessary when the water in the tank runs out. Turn off the machine. Unplug it
from the socket-outlet. Open the lid (7). Pour cool tap water in up to the MAX level.
5
Page 8
EN
USEFUL TIPS FOR PREAPARING A GOOD ITALIAN ESPRESSO
The ground coffee in the fi lter holder has to be pressed lightly. Whether the coffee is stronger or weaker
depends on the degree the coffee is ground, the quantity put into the fi lter holder and the pressing. Just
a few seconds are needed for the coffee to fl ow down into the cups. If the dispensing time is longer, this
means that the coffee is ground too fi ne or that the coffee put into the fi lter holder has been pressed
too much.
HOW TO MAKE DRIP COFFEE
Manual mode
• Open the upper lid (7) and (8).
• Check the proper water level in the tank (7) and, if need be, fi ll with fresh still water. The reference
marks of the carafe (2) and the water tank (6) are intended to make drip coffee, even though the dispensed coffee level is slightly lower than the fi lled water level as ground coffee absorbs some water.
The use of paper fi lter is recommended for a deeper cleaning of the components.
• Lift the hot water pour nozzle (27) (Fig.6)
• Position the paper fi lter onto the fi lter (9) by adapting it on the rim.
• Pour the ground coffee into the fi lter.
Initially the use of a measuring spoon of ground coffee is recommended for a stronger coffee,
then the amount of coffee to be used will suit your own taste. Besides an overly ground coffee is
not recommended as it could obstruct water fl ow while dispensing.
• Lower the hot water pour nozzle (27) (Fig.6)
• Close the upper lid (7) and (8).
• Place the carafe (2) onto the hotplate (4).
Make sure the dispenser (11) of the fi lter support (10) is aligned with the hole situated on the
carafe lid (Fig. 7) in order to avoid coffee leakage.
• Press the button (E) “AUTO/CAFFE’ ” twice to start the manual mode.
• Stop dispensing by pressing the button (E) “AUTO/CAFFE’ ” again once the required amount has been
reached.
If the carafe is removed before the end of dispensing process to pour a cup of coffee , be careful
to put it back under the dispenser (11) within 30 seconds to avoid hot water or coffee leaks.
Automatic mode
• Once having carried out the fi lling procedures of water and coffee and the proper positioning of the
carafe, as described in the manual mode, proceed as follows:
• Press the button (E) “AUTO/CAFFE’ ” once to start the “Auto Start” function. The LCD display (24)
lights up and shows the duration of the function ”Heating plate heat maintaining” (A) for 5 seconds.
• Press the button “PROG”(F) to check the automatic mode activation time setting.
6
Page 9
EN
HOW TO MAKE CAPUCCINO
• Pour approximately 200ml of skimmed milk into a small but high container into which the steam wand
(13) can be inserted.
Please Note: use quality, fresh and cold milk; the container must be cold, too, therefore do not
rinse with warm water before the use.
• Position the steam dispensing valve (12) in position ‘ ’.(Fig.8)
• Place a container with milk under the steam wand (13).
• Press the button 1 cup/2 cups (I), the button “ESPRESSO” starts fl ashing.
• Once the button “ESPRESSO” turns of
to “MAX” position direction.
• During the froth preparing phases, be careful the capuccino maker (14) does not touch the container
bottom to avoid obstruction of steam dispensing.
• Once having got the froth (this could take 10-30 seconds), reposition the steam dispensing valve (12)
into position ‘●’ and remove the container.
• After the above steps, dispense steam for few seconds to clean the hole of the steam wand (13) and
remove possible milk remains. Clean the outside part of the steam wand and the capuccino maker
(14) by means of a damp cloth.
Warning!
Do not touch the steam nozzle parts during the dispensing phases as they are very hot. Burn
hazard.
Use only containers with material suitable for high temperatures (ceramic or steel).
SETTABLE FUNCTIONS
The machine is equipped with three settable functions.
• Drip coffee auto start time setting.
• Heat maintaining time setting.
• Digital clock setting.
f, rotate the steam dispensing valve (12) anti-clockwise slowly
When the appliance is connected to an electric socket, the “LCD Display” (24) shows the default time
setting by proposing the value 12:00AM.
• At every press of the button “PROG” (F) the following function is selected:
Drip coffee auto start (in hours)
Drip coffee auto start (in minutes)
Heating plate heat maintaining (in hours)
Clock (in hours)
Clock (in minutes)
Exit (settable functions)
Please Note: In programming mode, in case of a delay over 10 seconds between the press of a
button and the next one, the program quits automatically the programming mode by maintaining
the last shown values, then the display turns off.
If the appliance is disconnected or blackout occurs, settings are resetted.
7
Page 10
EN
PROGRAMMING PHASES
Auto start programming (Drip coffee automatic start time setting)
• Press the button “programming”(F) only once.
The icon (B) starts fl ashing together with the time.
• Press the arrow buttons “ “ ” to set the time. (As the clock has a 12 hour display, every single
time the value 12 is reached, “AM” or “PM” are shown alternatively).
• Press the button “programming”(F) again.
The digits of minutes start fl ashing.
• Press the arrow buttons “ “ ” to set the minutes.
The Auto start function is on and programmed to make coffee at the set time.
• Press the button “programming”(F) for the third time to enter the heating plate heat maintaining programming.
Heating plate heat maintaining programming
The default duration of this function and the following automatic switching off is set in 2 hours from the
last dispensing cycle.
• The 1 digit value of the duration (in hours) of the function fl ashes.
•
Set the required hour number (from 1 to 5) by pressing the arrow buttons “ ” or “ ” several
times.
The function “Heating plate heat maintaining time programming” is set.
• Press the button “programming”(F) for the fourth time to enter the clock setting.
Clock setting
The icon (C) starts fl ashing together with the time.
• Press the arrow buttons “ “ “ ” to set the time. (As the clock has a 12 hour display, every
single time the value 12 is reached, “AM” or “PM” are shown alternatively).
• By pressing the button “programming” (F) for the fi fth time, the above described settings are stored.
Please Note: The fl ashing of “:” between hours and minutes shows that the clock is working
properly and the exit from the programming mode.
8
Page 11
EN
APPLIANCE CLEANING
Warning!
Before carrying out the following cleaning procedures, switch the appliance off and disconnect it
from the plug socket.
Warning!
Maintenance and cleaning on regular basis preserve the appliance and keep it effi cient for a longer
period. Never wash the appliance components in the dishwasher. Never use direct water jets.
Warning!
Every intervention has to be carried out when the appliance is cold.
Espresso fi lter cleaning containing ground coffee
Make sure the coffee dispensing hole is not obstructed and, if need be, clean it by means of a pin (Fig.9).
Make the fi lter holder dispense hot water with the fi lter mounted without powder to dissolve or remove
possible coffee remains or impurities.
Warning!
Remove and slowly disconnect the fi lter holder as the possible residual pressure could cause squirts
or splashes.
SIt is recommended to clean the fi lters (18-19-20) with care approximately every 3 months by using
the suitable detergent tablets available at the selling points and the Authorized Service Centers and
following the instructions on the packaging or, alternatively, by using a simple cleaner tablet (without
sparkling aid or other chemical additives) for dishwasher as follows:
• Insert a dishwasher tablet into the fi lter (without coffee) when the appliance is very hot (after at least
5 heating minutes).
• Insert one of the three fi lters into the fi lter holder (22).
• Close the fi lter holder with the handgrip facing left and rotate it tightly to the right.
• Place a container big enough under the fi lter holder .
• Rotate the steam handgrip to the closed ‘●’ position.
• Press the button 1 cup/2 cups (I), then press and maintain the button “ESPRESSO” (L) pressed to start
water dispensing and dispense water for 15-20 seconds.
• Stop dispensing and let the tablet work for at least 15 minutes by maintaining the fi lter holder inserted
in the appliance.
• Repeat the water dispensing procedure by letting the pump work for approximately 15-20 seconds,
then leaving it to rest for other 15-20 seconds until two water tanks are exhausted.
• Remove the fi lter holder from the appliance, take the fi lter out and rinse it under running water tho-
roughly.
• Turn the appliance off by pressing the button 1 cup/ 2 cups (I) three times, disconnect the power supply from the plug socket and clean the fi lter holder fastening seat with a sponge to remove possible
cleaner remains.
• Switch the appliance on again, reposition the fi lter holder and dispense at least 2 water cups to com-
plete the rinse cycle.
If the coffee maker is used on a daily basis, it is recommended to carry out the cleaning procedure every
three months.
Cleaning the fi lter holder seat
With time, coffee residue may accumulate on the fi lter holder seat. It can be removed with a toothpick, a
sponge (Fig. 9), or by letting water run through without fi tting the fi lter holder.
Cleaning the steam pipe
Warning!
Perform this operation when the chrome-plated pipe is cold so as to prevent burns.
Disconnect the cappuccino maker (14) from the steam pipe(13) (Fig. 10). Wash it with running
water. The steam pipe can be cleaned with a non-abrasive cloth. Put the cappuccino maker
back on as far as it will go. If necessary, clean the small steam outlet hole again with a pin (Fig.
10). After use, always let the steam nozzle run for a few seconds so to free the outlet from any
possible residue.
9
Page 12
EN
Cleaning the tank
Periodically clean the inside of the tank with a sponge or damp cloth.
Cleaning the cup grill and drip tray
Remember to empty the drip tray (15) from time to time.
Remove the grill (16) and wash it under running water; remove the drip tray (15) from the machine,
empty it and wash it under running water.
Cleaning the machine body
Warning!
Clean the fi xed parts of the machine using only a damp, non-abrasive cloth so as to not damage
the body.
Rinsing the drip coffee fi lter
Take the fi lter (9) out of the support (10). Empty it and rinse it under running water.
Rinsing the fi lter support
Open the fi lter lid (8) after lifting the hot water pour nozzle (27) (Fig.6) and remove the
fi lter (9) by lifting it out by the handgrip (Fig.11). Take out the support (10), pressing the release
button (25) (Fig. 4). Wash the fi lter support with a mild detergent and rinse thoroughly with plenty of
water.
To refi t the support on the machine, follow the removal steps in reverse order.
Cleaning the carafe
Warning!
Clean the carafe using a non-abrasive sponge. Wash the carafe with neutral soap and thoroughly
rinse with water.
DECALCIFICATION
Good maintenance and regular cleaning will keep the machine in good working order for longer, greatly
limiting the risks of lime scale deposits forming in the appliance. If, in spite of this, appliance operation
becomes affected by frequent use with hard water, it is possible to remove the scale build up to prevent
malfunctions.
Only use specifi c citric-acid-based products. The manufacturer of this machine cannot accept any liabi-
lity for damage to the internal components of the coffee machine caused by the use of non-conforming
products due to the presence of chemical additives.
Warning!
Do not use vinegar. It could damage the appliance.
Any damages due to failure to clean the machine periodically are not covered by the warranty.
Decalcifi cation is to be performed periodically, its frequency is based on the hardness of the water as
shown in the table, or in any case every time you notice the appliance has abnormal diffi culty in dispen-
sing coffee.
water hardness decalcify after decalcifi care dopo
(fH) French
degrees
(fH) German
degrees
(n° cups of coffee)
36 20 300
18 10 600
0 0 1200
10
Page 13
EN
Scale removal from the espresso coffee circuit
To remove the scale, proceed as follows:
- Switch off the machine and unplug it from the mains power.
If the appliance is disconnected from the mains power, the settings will all be reset.
- Pour the contents of the sachet in a litre of water, taking care to allow the product to dissolve completely.
- Pour the prepared solution in the tank (7).
- Place a container with a capacity of at least half a litre under the fi lter holder. Press the 1 cup/ 2 cup
button (l) to switch on the machine. When the light on the “ESPRESSO” button (L) stops fl ashing,
press it and pour about half of the tank’s contents. Stop pouring by pressing the “ESPRESSO” button
(L). Wait for about 15 minutes and then pour out the other half of the contents of the tank.
- Switch off the machine by pressing the 1 cup/2 cups button (I) three times and unplug the machine.
- Refi ll the tank to the MAX level with fresh still water.
- Place a container with a capacity of at least half a litre under the fi lter holder seat.
- Press the 1 cup/ 2 cup button (l) to switch on the machine and start the espresso coffee function.
When the “ESPRESSO” button (L) light stops fl ashing, press the button and pour out about half of the
contents of the tank.
- Stop pouring by pressing the 1 cup/ 2 cup button (l) three times. Wait for about 15 minutes and then
pour out the other half of the contents of the tank.
- At this point the appliance is once again ready for use.
Scale removal from the drip coffee circuit
To clean and remove scale, proceed as follows:
- Switch off the machine and unplug it from the mains power.
If the appliance is disconnected from the mains power, the settings will all be reset.
- Pour the contents of the sachet in a litre of water, taking care to allow the product to dissolve completely.
- Pour the prepared solution in the tank (7).
- Place the carafe (2) under the dispenser (11) (Fig.7).
Press the AUTO/CAFFE button (E) twice and after a few seconds, the solution will start to come out
of the pour nozzle (27). Pour out about half of the tank’s contents. Stop the pouring by pressing the
AUTO/CAFFE (E) button for the third time. Wait for about 15 minutes and then pour out the other half
of the contents of the tank.
- Switch off the machine and unplug it from the mains power.
If the appliance is disconnected from the mains power, the settings will all be reset.
- Refi ll the tank to the MAX level with fresh still water.
- Place the carafe (2) under the dispenser (11) (Fig.7).
Press the AUTO/CAFFE button (E) twice and after a few seconds, water will start to come out of the
pour nozzle (27). Pour out about half the contents of the tank.
- Stop pouring by pressing the AUTO/CAFFE (E) button for the third time. Wait about 15 minutes and
then pour out the other half of the contents of the tank.
- At this point, the appliance is once again ready for use
It is important that during this operation, you use the carafe (2) provided, since the lid (3) has a
spout that serves to open the valve of the dispenser (11)
11
Page 14
EN
PUTTING OUT OF SERVICE
If you want to put the machine out of service, you must disconnect it electrically, empty the water tank
and drip tray and clean it (see the paragraph on “Cleaning the appliance”).
In the case of scrapping, you must separate the various materials used in making the machine and
dispose of them based on their composition and on the legal provisions in force in the country of use.
TROUBLESHOOTING
Warning!
If there are problems with operation, immediately turn off the machine and unplug it from the socketoutlet.
Problems Causes Solutions
The coffee maker
does not supply
boiling water for
tisanes.
Steam coming out
of the edges of
the fi lter
The coffee maker
does not supply
steam.
A few drops of
water come out of
the caraffe
holder.
Probably an excess
amount of ground coffee
has been placed in the fi l-
ter ring preventing the fi lter
ring from being correctly
tightened into its housing.
Cappuccino steam exit
hole clogged.
The machine is trying to
dispense coffee with the
steam function on. Make
sure that the steam dial is
not turned on for any reason.
There is little water and the
pump does not suck it up.
Cappuccino steam exit
hole clogged
The caraffe is not wellpositioned under the nylon
fi
lter support dispenser.
The water level in the tank
exceeds the maximum level.
Make sure the tank is properly inserted
and that the water is not below the minimum level. Repeat the operations described in the “Preliminary phases for use”
paragraph.
Unclog any deposits that may have formed in the hole of the cappuccino maker
with a pin.
Stop pouring coffee, turn the steam dispensing valve(12) to position‘●’ to
stop the steam. Wait for the light on the
”ESPRESSO” button (L) to switch off before pouring a new coffee.
Check that the water level in the tank is
correct. If necessary
water.
Unclog any deposits that may have formed in the hole of the cappuccino maker
with a pin.
Centre the carafe lid under the dispenser
in the fi lter support.
Fill the tank up to the MAX level.
, fi ll it with cool tap
12
Page 15
Problems Causes Solutions
Coffee ove-
owing from the
fl
edges of the
fi lter ring.
The coffee is not
supplied or fl ows
too slowly.
The coffee is too
watery and cold.
Probably an excess
amount of ground coffee
has been placed in the fi l-
ter ring preventing the
fi lter ring from being correctly tightened into its
housing.
Residues of ground coffee have remained on the
gasket of the fi lter holder
coupling seat.
The fi lter containing
ground coffee has a blocked outlet hole.
The holes of the perforated disc in the fi lter holder
coupling seat are clogged.
The fi lter containing
ground coffee has a blocked outlet hole.
The coffee blend is ground
too fi ne.
The coffee blend is pressed down too much.
There is little water and the
pump does not suck it up.
The blend has been
ground too coarsely
.
Slowly remove and disconnect the fi lter
holder because any remaining pressure
could cause splashes or squirts. Clean
the coupling seat with a sponge (Fig. 9).
Repeat the operation placing the correct
quantity of coffee in the fi lter.
Clean the seal with a toothpick or a sponge (Fig. 9).
Remove and slowly disengage the fi lter
holder as any residual pressure could
lead to sprays or splashes. Use a pin to
clean out the blocked outlet hole. Clean
the fi lter with the special tablets and fol-
lowing the instructions in the instruction
booklet
Turn on the machine without the fi lter hol-
der, making the water run. Turn on the
machine without the fi lter holder,
making the water run. If the water still
does not come out from all the holes
evenly, carry out the descaling cleaning
operation using the Ariete NOCAL product found at Ariete service centres, following the instructions provided in the
package.
Remove and slowly disengage the fi lter
holder as any residual pressure could
lead to sprays or splashes. Use a pin to
clean out the blocked outlet hole. Cleanse the fi lter with the special tablets and
following the instructions in the instruction booklet
Try using coarser coffee blends.
Amper coffee inside the fi lter using less
pressure.
Check that the water level in the tank is
correct. If necessary, fi ll it with cool tap
water.
A more fi nely ground blend must be used
to obtain a more concentrated and hotter
coffee.
EN
13
Loading...
