ESCAM PSE6004 Series User Manual

PSE6004 Series

POE

Switch

Datasheef

POE Switch

USER GUIDE

6-Port fast Ethernet Switch 4-Port POE

Mini aluminium housing with easy-mount design

-30°C ~ +70°C operating temperature

Weight:0.8KG

PSE6004 Series

POE

Switch

Datasheef

Features:

Overview

●

Mini aluminium housing supports wall

● PSE series PoE switches not only in price can be

mount and desk-top installation

comparable to ordinary switch, and, compared

to those only work in 0 ° C ~50 ° C environment,

●

Unique thermal design, wide operating

plastic shell household switches, they specifially

temperature range -30°C ~ 70°C

for the network system needs uninterrupted

work, such as the IPC security system.

●

MTBF up to 150K hours, designed for

24-hours-working surveillance system

●

All models feature stable performance,

come

with dual surge protection circuits, so that the

●

Maxium PoE output up to 20W/port

MTBF of these switches reaches 150K hours.

Usually, these functions are ordinary business

●

Plug and play installation, non-

switches on the market do not have .

professional can quickly install it

●

The aluminum housing of PSE series switches

designed to be very compact, so you can easily
put them in a small power supply box. Therefore,
they are ideally suited for small projects or home
security systems.

Typical application ：

● IP Camera ● AP

● VoIP Phone ● Surveillance System

● Security System ● NAS

PSE6004 Series

POE

Switch

Datasheef

Typical application 1:

The switch is connected to a 90W-output power supply, and provides PoE signal through
the network cables to PoE IP cameras.

Typical application 2:

The switch is driven by a power supply with 90W output, and delivers IEEE PoE+
signal to high power devices like IR IP cameras,up to max 20W per port.
