PT-19XL MECHANIZED
PLASMARC CUTTING TORCH
CAUTION
!
These instructions are for experienced operators. If you are not fully familiar with the principles of operation and safe practices for arc welding equipment, we urge you to read our booklet, “Precautions and Safe Practices for Arc Welding, Cutting and Gouging,”, Form 52-529. Do NOT permit untrained persons to install, operate, or maintain this equipment. Do NOT attempt to install or operate this equipment until you have read and fully understand these instructions. If you do not fully understand these instructions, contact your supplier for further information. Be sure and read the Safety Precautions (pages 2 & 3) before installing or operating this equipment.
SECTION 1 INTRODUCTION
1.1 INTRODUCTION
The PT-19A is a mechanized torch designed for plasma arc cutting without water injection. The torch is water cooled for long consumable life at high currents.
1.2 AVAILABLE MODELS
P/N 34956 Torch Assembly PT-19XL 4-1/2 ft.* P/N 34093 Torch Assembly PT-19XL 6 ft.* P/N 34094 Torch Assembly PT-19XL 12 ft.* P/N 34090 Torch Assembly PT-19XL 15 ft.* P/N 34095 Torch Assembly PT-19XL 17 ft.* P/N 34091 Torch Assembly PT-19XL 20 ft.* P/N 34092 Torch Assembly PT-19XL 25 ft.* P/N 20390 Torch Assembly PT-19XL 50 ft**
*Used on the ESP-1000 Plasma Cutting Outfits with ESP UL TRA-LIFE 300 or ESP-400 P ower Sources. Also used on PCM-1500 console units modified for use with PCC­12 control. **Used on PCM-150 or PCM-1500 console units with PCC-11 control.
NOTE
All of the above torches can be used with PCM-8XL pack­ages. Use of 34090 through 34095 with PCC-11/PCM­150 packages require modification of PCC-11 control (see Section 3).
NOTICE:
various U.S. and foreign patents with additional patents pend­ing. It is the policy of ESAB Welding & Cutting Products to react vigorously to patent infringement of unauthorized manufac­ture, sale, or use of its patented products or spare parts.
This torch and its components are protected by
DANGER
!
High Voltage can kill
Disconnect Power supply from incoming electrical power before touching or servicing the torch. Metal parts of the torch can be at high voltage.
DANGER
!
PLASMA Cutting can produce Deadly Fumes, Fire, or Explosion.
• Gases used for plasma cutting can cause suffoca­tion, fire, or explosion.
• Loud noise from plasma cutting can cause hear­ing loss.
Table 1-1. PT-19XL Specifications
Current Rating Duty Cycle Diameter of Torch Length of Torch W/O
Leads Cooling Requirements
Gas Consumption (Arc On)
(150 A w/PCM-150 0r PCM-1500)
15.5 inches (393.7mm)
0.75 gpm min. @ 90 psig (150 A)
1.00 gpm min. @ 120 psig (250 A)
100%
2 in. (50.8mm)
35 cfh (50 A)
65 cfh (150 AA)
110 cfh (250A)
Be sure this information reaches the operator. You can get extra copies through your supplier.
ESAB
ESAB Welding & Cutting Products
This page intentionally left blank
USER RESPONSIBILITY
This equipment will perform in conformity with the description thereof contained in this manual and accompanying labels and/or inserts when installed, operated, maintained and repaired in accordance with the instructions provided. This equipment must be checked periodically. Defective equipment should not be used. Parts that are broken, missing, worn, distorted or contaminated should be replaced immediately. Should such repair or replacement become necessary, the manufacturer recommends that a telephone or written request for service advice be made to the Authorized Distributor from whom purchased.
This equipment or any of its parts should not be altered without the prior written approval of the manufacturer. The user of this equipment shall have the sole responsibility for any malfunction which results from improper use, faulty maintenance, damage, improper repair or alteration by anyone other than the manufacturer or a service facility designated by the manufacturer.
PT-19A PLASMARC CUTTING TORCH
i
1
SECTION 2
REQUIRED EQUIPMENT
2.1 AIR CUTTING - 150 AMPS*
A. PCC-11/PT-19XL Package P/N 604472
Which includes: PCC-11 Control, P/N 16367
PT-19XL Torch, 50 ft Lines, P/N 20390 PT-19XL Start-Up Kit, P/N 20964 Gas Hose, 12.5 ft, P/N 40V77 Water Hose (2), 3 ft, P/N 20634 Air Hose, 30", P/N 678152 WC-8C Coolant Circulator, P/N 33739 Work Cable, 50 ft, P/N 678724 Mounting Bracket, P/N 20961 Adaptor, Pilot Arc, P/N 19497
*For oxygen cutting up to 150 amps, use above re­quired equipment and replace air regulator P/N 30338 with oxygen regulator P/N 998336 and add oxygen hose P/N 678725.
B. PCM-150 (P/N 30850) or PCM-1500 (P/N
680851) Power Source C. Air Regulator, P/N 30338 D. Nitrogen Regulator, P/N 998343 (Cylinder) or
P/N 19155 (Station)
E. Torch Coolant (1 gal.), P/N 156F05. Four
gallons of coolant will be required.
1 - Electrode Holder .................................P/N 34084
5 - Nozzle, 50A.........................................P/N 34730
5 - Nozzle, 150 A......................................P/N 21821
5 - Nozzle, 250A.......................................P/N 21822
4 - Gas Swirl Baffle.................................P/N 948142
1- Nozzle Retaining Cup ..........................P/N 34085
1- Insulator Assembly...............................P/N 20434
1- Contact Ring Assembly........................P/N 20395
10 - O-Ring............................................. P/N 86W85
10 - O-Ring............................................. P/N 996526
20 - O-Ring............................................. P/N 951000
20 - O-Ring............................................. P/N 996528
10 - O-Ring............................................. P/N 86W99
20 - O-Ring............................................. P/N 85W10
1- Nozzle & Electrode Stem Tool ...........P/N 999630
1- Electrode Tip Removal Tool ............... P/N 996568
1- Hex Wrench, 1/16" .........................P/N 93750006
1- Silicone Grease.................................... P/N 17672
2 - Heat Shield 50A .................................. P/N 34885
2 - Heat Shield 150/250A ....................... P/N 948186
B. Torch Mounting
1. Torch Clamp Assembly, P/N 598707, or Univer­ sal Clamp Assembly, P/N 598699, is required for mounting the PT-19XL. For stationary or boom mounting, the following parts may also be needed: Rack & Tube Assembly, P/N 39V35 Torch Adjustment Assembly, P/N 40V26 Adjustable Slide, P/N N25V39 Angle Bracket, P/N 29N04 Clamp Insulator Bushing P/N 996342
2.3 OXYGEN CUTTING - 260 AMPS WITH ESP-1000 SYSTEM
A. ESP-1000 System, contact your ESAB Sales Representative.
B. ESP-300, P/N 33520, or ESP-400, P/N 33518.
2.4 ACCESSORIES
A.PT-19XL Torch Spare Parts Kit, P/N 34314--
Recommended for maintaining the PT-19XL torch with minimum downtime. The kit contains the follow­ing PT-19XL parts and tools:
4 - Electrode, Long ................................... P/N 34086
4 - Electrode, Long N2/ArH2......................P/N 34557
PT-19XL PLASMARC CUTTING TORCH
2. For mounting on a CM-37 Carriage, mounting kit P/N 993092 may be used. The kit contains Clamp Assembly P/N 598707.
3. For cutting machine operation, the torch will mount on a standard PT-15 torch mounting setup.
C. Air Curtain Kit - P/N 34752 , consisting of :
21549 Air Curtain Assembly 33383 Control Panel
34033 Hose, 50 ft. The air curtain directs a flow of air around the arc which permits underwater cutting with O2 gas. See Form 15-128 for details.
Note: Underwater cutting cannot be done with 50A nozzle.
4
SECTION 3
3.1 INSTALLATION
To mount the PT-19XL torch, refer to F-12-528 (PCM-
8), F-14-493 (PCC-11), or F-15-116 (ESP-1000 Sys­tem). To use 4-1/2 ft. to 25 ft. torches with the PCC-11, holes must be drilled in the PCC-11 sheetmetal opposite the 7/16-20 L.H. and 7/16-20 R.H. fittings on the brass power block. These holes should be fitted with appro­priate bushings. Recommended hole size: 1.094" Dia. Recommended snap bushing: P/N 639533
The "B" L.H. fitting should be plugged with: "B" size plug (PCC-8 P/N 996857) and nut "B" L.H. (P/N 10N40).
The "C" L.H. fitting should be plugged with: "C" size plug (P/N 996856) and nut "C" L.H. (P/N 10N18).
INSTALLATION AND OPERATION
WARNING
!
Never touch any torch front end parts (Nozzle, Retaining Cup, Etc.) unless the power switch is in the off position, and primary power is shut off at the disconnect.
A. Position the torch over the edge of the
workpiece with the tip of the nozzle set at about 3/8" above workpiece (standoff).
NOTE
If piercing thick plate, increase standoff to 1/2" for up to 1/2" thick plate, 3/4" for thicker plate. Then return to 3/8" standoff after completing the pierce and you are ready to cut.
The existing 1.073" and 1.500" diameter holes should be covered or plugged.
3.2 OPERATION
DANGER
!
ELECTRIC SHOCK CAN KILL. Precautionary mea­sures should be taken to provide maximum protec­tion against electric shock. Therefore, before mak­ing any adjustments or performing any mainte­nance on the torch, make sure the power to the torch is shut off.
WARNING
!
Never use oil or grease on this torch. Handle parts only with clean hands on a clean surface. Oil and grease are easily ignited and burn violently in the presence of oxygen under pressure. Use silicone lubricant only where directed.
WARNING
!
B. Lower your protective helmet and activate
start switch. Pilot arc and high frequency will energize and gas will start flowing. The pilot arc should then transfer to the cutting arc.
NOTE
If cutting arc does not start within 6 seconds, the pilot arc will shut off. Deactivate start switch. Check to be sure gas pressures are adequate, work cable is firmly connected to workpiece, cooling water is on, standoff is about 3/8", etc. Then start from step one again.
C. Maintain the standoff of 3/8" throughout the cut
and move the torch at a rate that produces the desired cut quality. The cutting should pro­duce a straight fine spray of molten metal emitting from beneath the workpiece as illus­trated in Figure 4-1. See Table 2-1 for recom­mended cutting speed range.
D. If cutting arc is lost during a cut, the pilot arc will
immediately reignite as long as the switch is depressed. You then have about 6 seconds to move the torch close enough to work to rees­tablish the cutting arc.
Wear the usual protective gloves, clothing, and helmet. Helmet with filter lens shade No. 6 or 7 should provide adequate protection for your eyes.
PT-19XL PLASMARC CUTTING TORCH
E. The cutting arc will extinguish at the end of the
cut; however, the start switch should be re­leased to keep the pilot arc from reigniting.
5
SECTION 3
INSTALLATION AND OPERATION
F. When cutting operation is completed, wait a
few minutes before placing the POWER switch to the OFF position so that the cooling fan has
CORRECT
TOO FAST
Figure 3-1. Effect of Cutting Speed
Cutting Data PT-19XL W/Air (50 AMPS)
Metal
Low
Carbon
Steel
Stainless
Steel
Thick
1/4 1/8
1/16
1/4 1/8
1/16
Current
65 50 50
65 50 50
Standoff
1/8 to 3/16
3/16
1/8 to 3/16
time to remove the heat from the unit. Then shut off the primary power at the main discon­nect switch.
TOO SLOW
Speed
IPM
65 120 250
65
80 230
Aluminum
Note:
Pierce at 3/16 to 1/4 inch. Standoffs at the lower end of the recommended range generally produce less bevel angle.
1/4 1/8
1/16
65 50 50
1/8
Cutting Data PT-19XL W/Air & Oxygen (150 & 250 AMPS)
Current
Nozzle
34048
34101
Gas Type
& Setting
Air
Low 4
Oxygen
Low 4
Air or
Oxygen
Low 5
Standoff
For Piercing
3/8 3/8
1/2 1/2+ 1/2+
3/8
3/8
1/2 1/2+ 1/2+
1/2+ 1/2+ 1/2+ 1/2+
Piercing not
Recommended
Standoff
For Cutting
3/8 3/8 3/8 3/8 3/8 3/8
3/8 3/8 3/8 3/8 3/8
3/8 3/8 3/8 3/8 3/8 3/8
Material
Thickness
1/4 3/8 1/2 5/8 3/4
1
1/4 3/8 1/2 5/8 3/4
1/2 5/8 3/4
1
1-1/2
2
65 130 250
Carbon
Steel
130
90 60 50 40 20
130 100
65 55 45
120 100
80 60 30 15
Speed (IPM)
Stainless
Steel
140
Recommended
No Data Developed
Recommended For
Stainless Steel &
Aluminum
75 50 30 20 12
Not
Oxygen Not
Aluminum
160 115
80 60 40 20
Fig 3-2. PT-19XL Cutting Data (Range of Maximum Speeds)
PT-19XL PLASMARC CUTTING TORCH
6
SECTION 3
INSTALLATION AND OPERATION
3.3 GAS SETTINGS
A. PCC-1500/PCC-11, PCC-1500 / PCC-12 Systems
150AMP Nozzle Starting gas set to 20 psig. Cutting gas set to 45 psig.
NOTE: Do not use 02, use only air for cutting carbon
steel over 3/4" thick at 150 AMPS 50 AMP Nozzle
Use Air/Air or N2/N2 only Starting gas set to 40 psig. Cutting gas set to 60 psig.
Use 4-hole baffle for all 50A & 150A cutting.
B. PCM-8
150A Nozzle - set flowmeter to 3.0 250A Nozzle - set flowmeter to 5.0
C. ESP-1000
150A Nozzle - Run 1 Gas - Low 4 250A Nozzle - Run 1 Gas - Low 6 Start gas pressure 20 - 25 psig.
D. Operation of 50 AMP Nozzle For ESP-1000 Sys­ tems With Regulator & Gauge Kits.
1. Build up a regulator assembly as shown below:
2. Install this regulator at the "Cut Gas" connection on the ESP Plumbing Box.
3. Set control on the ESP Flow Control as follows: a. O2/N2 Switch to "N2" b. Cut Water Switch to "OFF"
c. Cut Gas Flowrate to "HIGH 7" d. Test/Run Switch to "Run 1"
4. Set Start Gas Pressure as follows: a. Test/Run Switch to "START GAS TEST" b. Adjust Start Gas Regulator to 40 psig. c. Return TEST/RUN Switch to "Run 1"
5. Set Cut Gas Pressure as follows: a. TEST/RUN Switch to "CUT GAS TEST" b. Adjust Cut Gas Regulator to 60 psig. c. Return TEST/RUN Switch to "RUN 1"
6. Set Range Switch on ESP-300 to "LOW" Adjust
Current Setting to 50 Amps (about 3 on dial). YOU ARE NOW READY TO CUT WITH N
2
TO CUT WITH AIR, Disconnect N2 from the Flow Control and connect a supply of clean filtered Air at 100 psig. to the N2 Inlet on the Flow Control.
TO RETURN THE SYSTEM TO USE WITH HIGHER CURRENTS:
a. Reconnect N2 to the N2 Inlet. b. Turn the Pressure adjusting Screw on the
Cut Gas Regulator all the way in and set the GAS Flowrate Setting Back to that recom­ mended.
c. Readjust the Start Gas Regulator to the recommended setting. d. Set the O2/N2 Switch to "O2" if desired. e. Set the ESP-300 Range Switch to "HIGH"
For PCC-11 & PCC-12 Systems
a. Set Start Gas Pressure to 40 psig. b. Set Cut Gas Pressure to 60 psig. c. Set PCC-1500 to 50 Amps (About 3 on dial).
CHECK VALVE ASSY. -21124
ADAPTOR - 999304
B-Oxy -F*
*Use Locktite Pipe Sealant on Threads, DO NOT Use Teflon Tape.
1/4 NPTM*
1/4 NPTF*
HEX NIPPLE -639501
1/4 NPTM*
Fig 3-3. PT-19XL Regulator Assembly (For Use With ESP-1000 System)
PT-19XL PLASMARC CUTTING TORCH
1/4 NPTF*
(2) 1/8" NPT Pipe Plugs
- 643792*
7
1/4 NPTF*
AIR REGULATOR ASSY. -522368
CONNECTOR -3389
1/4 NPTM*
B-Oxy-M*
SECTION 4
MAINTENANCE
4.1 INTRODUCTION
CAUTION
!
If this equipment does not operate properly, stop work immediately and investigate the cause of the malfunction. Maintenance work must be performed by an experienced person, and electrical work by a trained electrician. Do not permit untrained persons to inspect, clean, or repair this equipment. Use only recommended replacement parts.
NOTE
For detailed maintenance, troubleshooting, and parts information on the power source, see Form F-14-483 (PCM-150) and supplement F-15-027 (PCM-1500), or F-15-528 (PCM-8XL), F-15-108 (ESP-400), or F-15­109 (ESP-600). F-15-141 (ESP-300). F-15-116 (ESP-
1000).
NOTE
Removing the nozzle from torch to check electrode wear greatly reduces electrode life. To maximize electrode life, only remove nozzle when changing electrode.
4.2 REPLACING PT-19XL NOZZLE
(REFER TO FIGURE 5-1)
A. To remove nozzle, unscrew heat shield and
retaining cup, then grip the nozzle and pull straight out.
NOTE
D. Insert the nozzle into the torch. E. Screw retaining cup onto the torch slowly to
HAND TIGHTNESS. The nozzle will seat against the gas swirl baffle (P/N 948142). Do NOT overtighten.
F. Screw heat shield onto nozzle. Do NOT over-
tighten.
50 AMP NOZZLE - 34730
O-Ring - 994092
(2) O-Ring - 181W89
150 AMP NOZZLE - 21821 250 AMP NOZZLE - 21822
(2) O-Ring - 181W89
Figure 4-1. Proper O-Ring Position
(50,150 & 250A Nozzles)
4.3 REPLACING ELECTRODE AND GAS SWIRL BAFFLE
Always remove heat shield before removing retaining cup. If heat shield will not loosen, tighten retaining cup to reduce pressure on heat shield.
B. Check copper nozzle for melting from exces-
sive current, gouges from internal arcing, or nicks and deep scratches on the O-ring seal­ing surface. If any of these defects are visible, replace the nozzle. (Discoloration of the inter­nal surfaces and small black starting marks are normal.) Hafnium particles may be re­moved with fine sandpaper or steel wool.
C. Apply a light coating of silicone lubricant (P/N
17672-1 oz. tube) around the periphery of the nozzle and O-ring. Make sure the O-ring (P/N 181W89) is set evenly around the shoulder of the nozzle.
PT-19XL PLASMARC CUTTING TORCH
A. Remove heat shield, retaining cup, and nozzle
as described above.
B. Remove electrode by using the 7/16-inch nut
driver (P/N 996568 - supplied with the torch). If electrode holder did not come out with tip, then remove it by using removal tool (P/N
999630) supplied with the torch. The lugs will engage with the slots on the tip holder. Make sure you hold the nut driver or removal tool straight, whether removing or reassembling the electrode, to avoid damaging the gas baffle. The gas swirl baffle should come out with the electrode holder. If it does not, remove by using one finger.
C. Replace electrode if the hafnium insert is pit-
ted more than 0.090 inch.
8
SECTION 4
MAINTENANCE
D. Check O-ring (P/N 86W99) inside electrode
holder periodically. If nicked, it should be replaced exercising care to avoid scratching the O-ring groove. Lubricate new O-ring lightly with silicone grease before installing it into the electrode holder.
E. Replace the gas swirl baffle if it is cracked or if
the front edge (nozzle seating surface) is chipped.
F. When reassembling, slip the gas swirl baffle
over the electrode/electrode holder assembly. Then screw the electrode assembly into the torch using 7/16-inch nut driver. Tighten firmly but do NOT overtighten.
4.4 REPLACING INSULATOR ASSEMBLY
The insulator assembly (P/N 20434) should be re­moved periodically and inspected for cracking and for possible replacement of six O-rings. To remove the insulator body, do the following:
A. Remove heat shield, nozzle retaining cup,
nozzle, electrode, electrode holder, and gas swirl baffle as described above.
B. Pull the insulator body straight out.
NOTE
The pilot arc cable will be attached, so allow plenty of slack on the cable.
C. Lubricate the O-rings sparingly with silicone
grease. If necessary, replace O-rings.
D. If replacing the insulator body, disconnect the
pilot arc cable by loosening the setscrew with
the 7/64-inch hex Allen wrench (supplied with the torch) at the contact ring assembly (P/N
20395). Remove contact ring assembly from the insulator body by removing one socket head screw with a 7/64-inch hex Allen wrench.
E. Reassemble in reverse order. Align insulator
body with locating pin (P/N 996242) and push in.
4.5 REPLACING CABLES AND HOSE
A. To disconnect the power cable, water return
hose, and gas hose at the back end of the torch, unscrew the fiberglass sleeve (P/N
19483) from the stainless steel body.
B. The pilot arc cable is attached to connector
(P/N 20408) under insulator (P/N 20409). Re­move tape behind the insulator so that it can be slid up the pilot arc cable exposing the con­nector. Loosen set screws with 7/64-inch hex Allen wrench to remove cable from connector. A 12-inch long 12 gauge bare copper wire is connected to the contact ring assembly and to the connector.
C. Straighten out the services lines and make
sure the torch sleeve is straight when screwing it back onto the torch body. Threads are rather fine and easy to cross-thread. Do not force the sleeve. A little bit of silicone grease will help.
D. Secure the sleeving (P/N 995826) on the 50 ft
torch (P/N 20390) with tape or ty-wrap under the torch sleeve to protect the service lines from arc radiation. When the torch is ready to operate, make sure the service lines are well out of the way.
BACK OF SLEEVE
NOTE: Do Not Tape over the end of the P.A. cable conduit.
Figure 4-2. PT-19XL Cable and Hose Assembly,(ESP-1000 Style Cable Bundle)
3
inches
2
inches
PT-19XL PLASMARC CUTTING TORCH
Securely tape around hose bundle 2" wide. Slide braid down and tape over 4-1/4".
BOOT
SLEEVING
4 1/4
inches
NOTE: Braid does not go over Gas or (P/N - 72020003) Hose.
9
SECTION 5
REPLACEMENT PARTS
Replacement parts are keyed in Figures 5-1 through 5-4. Order replacement parts by part number and part name as shown on the illustrations. DO NOT order by part number alone. Parts may be ordered from your ESAB Welding & Cutting Products distributor or from ESAB Customer Service Department, Florence, SC 29501.
REAR MAIN BODY ASSY. - 20391
CONTACT RING ASSY. - 20395
O-RING - 996528
1
Current
& Gas
50 to 65A
Air & N
O-RING - 996527
PT-19XL Consumables
5
4
6
3
INSULATOR ASSY. - 20434 Includes: (1) 86W85 O-Ring (1) 996526 O-Ring (4) 85W10 O-Ring
2
NOTE TO ORIGINAL PT-19 TORCH USERS: The front end parts (items 1-5 above) may be used in place of the front end parts on the origional PT-
19 torch (see F-15-083) as long as these parts are used togrther. Conversely, the origional PT-19 front end parts (nozzle retaing cup 20402, nozzle assembly 20400 or
20873, electrode tip 20763, and tip holder 20398) can be used togrther on the PT-19XL in place of the first 5 items.
Application Recommended Replacement Parts
3
Nozzle
50A
34730
4
Electrode
Hafnium
34086
2
Thickness & Material
1/16 to 1/4" CS, SS, AL
1
Heat
Shield
50A
34885
2
Nozzle
Retaining Cup
34085
SLEEVE - 19483
Hose and Cable Connection (see Figures 5-3 and 5-4)
5
Electrode
Holder
Long
34084
6
Gas
Baffle
4 Hole Std.
948142
4 Hole Rev.
948143
150A
Air & N
O
2
250A
Air,O2,N
250A
H-35
150A
H-35
2
2
1/4 to 1" CS,SS,AL 1/4 to 3/4"
CS
1/2 to 2" CS,SS,AL
1/2 to 2"
SS,AL
1/2 to 1"
SS,AL
Std. 948186
H.D. 19506
Std. 948186
H.D. 19506
Std. 948186
H.D. 19506
Std. 948186
H.D. 19506
34085
34085
34085
34085
Figure 5-1. PT-19XL Plasmarc Cutting Torch
PT-19XL PLASMARC CUTTING TORCH 10
150A
21821
250A
21822
250A
21822
150A
21821
Hafnium
34086
Hafnium
34086
Tungsten
34557
Tungsten
34557
Long
34084
Long
34084
Long
34084
Long
34084
4 Hole Std.
948142
4 Hole Rev.
948143
8 Hole Std.
2075586
8 Hole Rev.
20918
4 Hole Std.
948142
4 Hole Rev.
948143
4 Hole Std.
948142
4 Hole Rev.
948143
SECTION 5
REPLACEMENT PARTS
CONTACT RING ASS'Y 20395
VIEW "A"
INSULATOR BODY
SEE
VIEW "A"
PILOT ARC CABLE SET SCREW
Remove to Release Pilot Arc Cable Use 1/16" Allen Wrench (Supplied with torch)
(2) O-RING - 951000
.176 ID X .050W
2
SOCKET HEAD SCREW
Remove to Release Contact Ring Use 7/16" Allen Wrench (Not Supplied)
3
1
Figure 5-2. Pilot Arc Cable Assembly
Item
No.
1 2 3 4
Qty.
Req.
1 4 1 2
Part
No.
20403
61330980
20408
951000
PT-19XL PLASMARC CUTTING TORCH
4
Description
P.A. BUS INSULATOR SCREW, #6-32 X 1/8 CONNECTOR, HI-FREQ. O-RING
11
Description
WATER "OUT" CABLE CONNECTION
WATER "IN" CABLE CONNECTION
GAS HOSE CONNECTION
HOSE, WATER RETURN
HOSE, GAS
CABLE,POWER
CABLE, PILOT ARC
***
No.
Part
Qty.
Req.
No.
Item
20405
20406
20404
1111111
1234567
20407
CABLE, POWER
HOSE, GAS
CABLE, POWER
HOSE, GAS
Description
WATER "OUT" CABLE CONNECTION 7/16 X 20 R.H.
WATER "IN" CABLE CONNECTION 7/16 X 20 R.H.
GAS HOSE CONNECTION 3/8 X 24 R.H.
HOSE, WATER RETURN
HOSE, GAS
CABLE,POWER
***
No.
Part
11121121121121121121121
Qty.
Req.
12345645645645645645645
No.
Item
34775
34776
34778
CABLE, PILOT ARC
34360
34357
996248
CABLE, POWER
HOSE, GAS
CABLE, PILOT ARC
CABLE, POWER
HOSE, GAS
CABLE, PILOT ARC
34363
34361
34358
21266
21260
21263
CABLE, PILOT ARC
34364
34362
34359
CABLE, POWER
HOSE, GAS
CABLE, PILOT ARC
CABLE, POWER
HOSE, GAS
CABLE, PILOT ARC
21267
21261
21264
21268
21262
21265
1
6
1
7
7/16 X 20 R.H.
6
2
7/16 X 20 L.H.
3/8 X 24 R.H.
ft.
20
25 ft.
Torch
Length
All
Lengths
4 1/2 ft.
6 ft.
12 ft.
15 ft.
17 ft.
3
2
4
Figure 5-3. PT-19XL Hose and Cable Assemblies (50 ft)
3
4
1
5
5
6
Figure 5-4. PT-19XL Hose and Cable Assemblies (6 ft - 25 ft)
7/16 X 20 R.H.*
4
7/8 X 14 L.H.
F-15-147-A 1/96 Printed in U.S.A.
5/18 X 18 R.H.
5/18 X 18 L.H.
*Note That Power Cables Have 7/16 X 20 R.H. Thread At One End,
7/16 X 20 L.H. At The Other.
7/16 X 20 L.H.*
ESAB
5/18 X 18 R.H.
ESAB Welding & Cutting Products
PO Box 100545, Florence SC 29501-0545
Loading...
