INSTRUCTIONS for
PM-GST
POST-MIX HAND CUTTING TORCH
(See Fig. 2 for listing of available torch assemblies.)
These INSTRUCTIONS are for experienced operators. If you are not fully familiar with the principles of operation and safe practices for oxy-fuel gas equipment, we urge you to read our booklet “Precautions and Safe Practices for Gas Welding, Cutting and Heating,” Form 2035. Do NOT permit untrained persons to install, operate, or maintain this equipment. DO NOT attempt to install or operate this equipment until you have read and fully understand these instructions. If you do not fully understand these instructions, contact your supplier for further information.
The cutting torches covered by these instructions are listed by Underwriter’s Laboratories only when using parts manufactured by ESAB Welding & Cutting Products to the specifications on file with Underwriter’s Laboratories, Inc., and when they are used in the gas service for which they are designed and listed. The use of other parts voids the manufacturer’s warranty.
OPERATING INSTRUCTIONS
F-15-365-C
July, 2000
DO NOT use torch with any fuel gas except natural gas or propane. Using other fuel gases can over­heat and damage the torch which can cause per­sonal injury.
The PM-GST Cutting Torch is a post mixed design per­mitting the oxygen and fuel gas to be mixed externally near the exit end of the torch. No internal mixing of the combustibles occurs in the torch. Highly efficient mixing occurs due to the distribution of preheat gases and shielding gases around the cutting oxygen stream. This produces an extraordinarily long high-heat zone permit­ting high standoff of torch to workpiece, thus increasing the life of the torch and nozzle.
The PM-GST was designed for manual cutting opera­tions that require torch to be in the stand-by pilot flame mode ready for immediate use, such as emergency hot cast billet cutting. The PM-GST (Post-Mix-Gas Saving Torch) provides substantial gas savings in pilot mode but remains ready for cutting without the operator hav­ing to light the torch.
The PM-GST Cutting Torch can be used on hot or cold material and because of intense preheat capability pro­vides extremely fast starts and cutting speeds.
EQUIPMENT REQUIRED (See Fig. 1)
1. Hoses - To obtain the best performance from the
PM-GST Torch, use 1/2 -in. (12.7 mm) I.D. hose for oxygen and 3/8-in. (9.5 mm) I.D. hose for fuel gas. Attach 1/2-in. oxygen hose, such as P/N 2120399 (50-ft.) with proper size fittings (7/8"-14 right hand threads) to the oxygen supply regulator. Attach 3/8-in. fuel gas hose (9/16-18 left hand threads) to fuel gas supply regulator. Heat protection of hoses is recommended when working over hot cutting ar­eas. (Note: 3/8-in. I.D. oxygen hose may be used
but torch performance will be reduced. To use 3/8­in. I. D. oxygen hose order P/N 18X19, “C” to “B” adaptor.)
2. Regulation - High-Flow Two Outlet Regulation Panel, P/N 2119101. Panel is complete with R-52 Oxygen regulator, oxygen filter, R-6702 Fuel Gas Regulator, and H-16 Fuel Gas Safety Valve. It is OSHA approved, preassembled, and ready for per­manent or portable wall or column mounting.
3. Cutting Nozzles - Select desired nozzle from Cut­ting Data table.
OPTIONAL ACCESSORIES
1. Riding Skid, P/N 22073.
DO NOT position the torch with the pilot flame ig­nited close to any combustible materials. When pi­lot flame is ignited torch must be held firmly by the operator or in a stand-by holding fixture.
Be sure this information reaches the operator. You can get extra copies through your supplier.
CONNECTING
1. Before connecting, make sure all metal seating sur­faces of hoses, torch, and regulators are not dam­aged and cleaned free of grease and oil.
2. Connect hoses (1 oxygen; 1 fuel gas) to the proper fitting on the torch and to the manual valves down-
SAFETY PRECAUTIONS
These Safety Precautions are for your protection. They sum­marize precautionary information from the references listed in Additional Safety Information section. Before performing any installation or operating procedures, be sure to read and fol­low the safety precautions listed below as well as all other manuals, material safety data sheets, labels, etc. Failure to ob­serve Safety Precautions can result in injury or death.
PROTECT YOURSELF AND OTHERS - Some welding, cutting and gouging processes are noisy and require ear protection. Hot metal can cause skin burns and heat rays may injure eyes. Training in the proper use of the pro­cesses and equipment is essential to prevent accidents. Also:
1. Always wear safety glasses with side shields in any work area, even if welding helmets, face shields, or goggles are also re­quired.
2. Wear flameproof gauntlet type gloves, heavy long-sleeve shirt, cuffless trousers, high-topped shoes, and a welding helmet or cap for hair protection, to protect against hot sparks and hot metal. A flameproof apron may also be desirable as protection against radiated heat and sparks.
3. Hot sparks or metal can lodge in rolled up sleeves, trousers cuffs, or pockets. Sleeves and collars should be kept buttoned, and open pockets eliminated from the front of clothing.
4. Protect other personnel from hot sparks with a suitable non­flammable partition or curtains.
5. Use goggles over safety glasses when chipping slag or grind­ing. Chipped slag may be hot and can travel considerable dis­tances. Bystanders should also wear goggles over safety glasses.
FIRES AND EXPLOSIONS - Heat from a flame can act as an ignition source. Hot slag or sparks can also cause fires or explosions. Therefore:
1. Remove all combustible materials well away from the work area or completely cover the materials with a protective non­flammable covering. Combustible materials include wood, cloth, sawdust, liquid and gas fuels, solvents, paints and coat­ings, paper, etc.
2. Hot sparks or hot metal can fall through cracks or crevices in floors or wall openings and cause a hidden smoldering fire on the floor below. Make certain that such openings are protected from hot sparks and metal.
3. Do not weld, cut, or perform any other hot work on materials, containers, or piping until it has been completely cleaned so that no substances on the material can produce flammable or toxic vapors. Do not do hot work on closed containers. They may explode.
4. Have fire extinguishing equipment handy for instant use, such as a garden hose, a pail of water or sand, or portable fire extinguisher. Be sure you are trained in its use.
5. After completing operations, inspect the work area to be sure that there are no hot sparks or hot metal which could cause a later fire. Use fire watchers when necessary.
6. For additional information, refer to NFPA Standard 51B, “Fire Prevention in Use of Cutting and Welding Processes”, which is available from the National Fire Protection Association, Batterymarch Park, Quincy, MA 02269.
FUMES AND GASES - Fumes and gases, par­ticularly in confined spaces, can cause dis­comfort or injury. Do not breathe fumes or gases from welding or cutting, Therefore:
1. Always provide adequate ventilation in the work area by natu­ral or mechanical ventilation means. Do not weld, cut, or gouge on materials such as galvanized steel, stainless steel, copper, zinc, lead, beryllium, or cadmium unless positive mechanical ventilation is provided. Do not breathe fumes and gases from these materials.
2. If you develop momentary eye, nose, or throat irritation while operating, this is an indication that ventilation is not adequate. Stop work at once and take necessary steps to improve venti­lation in the work area. Do not continue to operate if physical discomfort persists.
3. Refer to ANSI/ASC Standard Z49.1 listed below for specific ventilation recommendations.
4. WARNING: This product, when used for welding or
1. Always have qualified personnel perform the installation, troubleshooting, and maintenance work. Do not operate or repair any equipment unless you are qualified to do so.
2. Keep all oxy-fuel equipment free of grease or oil. Grease, oil, and other similar combustible materials, when ignited, can burn violently in the presence of oxygen.
3. Do not abuse any equipment or accessories. Keep equipment away from heat and wet conditions, oil or grease, corrosive atmospheres and inclement weather.
4. Keep all safety devices in position and in good repair.
5. Use equipment for its intended purpose. Do not modify it in any manner.
1. Use the proper gas for the process and use the proper pres­sure reducing regulator designed to operate from the com­pressed gas cylinder. Do not use adaptors to mount the regu­lator on the cylinder. Maintain hoses and fittings in good con­dition. Follow manufacturer’s operating instructions for mount­ing the regulator to the gas cylinder.
2. Always secure cylinders in an upright position by chain or strap to suitable hand trucks, benches, walls, post, or racks. Never secure cylinders to work tables or fixtures where they may become part of an electrical circuit.
3. When not in use, keep cylinder valves closed. Have the valve protection cap in place on top of the cylinder if no regulators is installed. Secure and move cylinders by using suitable hand trucks. Avoid rough handling of cylinders.
4. Locate cylinders away from heat, sparks, or flame of a weld­ing, cutting, or gouging operation. Never strike an arc on a cylinder.
5. For additional information, refer to CGA Standard P-1, “Pre­cautions for Safe Handling of Compressed Gases in Cylin­ders:, which is available from the Compressed Gas Associa­tion, 1235 Jefferson Davis Highway, Arlington, VA 22202.
The following publications, which are available from the American Welding Society, 550 N.W. LeJuene Road, Miami, FL 33126, are recommended to you:
1. ANSI/AWS Z49.1 - “Safety in Welding and Cutting”.
2. AWS F4.1 - “Recommended Safe Practices for the Prepara­tion for Welding and Cutting of Containers and Piping That Have Held Hazardous Substances”/
3. AWS SP - “Safe Practices” - Reprint, Welding Handbook.
cutting, produces fumes or gases which contain chemicals known to the State of California to cause birth defects and, in some cases, cancer. (California Health & Safety Code §25249.5 et seq.)
EQUIPMENT MAINTENANCE - Faulty or improp­erly maintained equipment, such as torches, hoses and regulators, can result in poor work, but even more important, it can cause injury or death through fires. Therefore:
GAS CYLINDER HANDLING - Gas cylinders, if mis­handled, can rupture or explode violently. Sudden rupture of a cylinder, valve or relief device can in­jure or kill you. Therefore:
ADDITIONAL SAFETY INFORMATION - For more information on safe practices for oxy-fuel welding and cutting equipment, ask your distributor for a copy of “Precautions and Safe Practices for Gas Welding, Cutting, and Heating”, Form 2035. Gas apparatus safety guidelines are also available on video cassettes from your distributor.
MEANING OF SYMBOLS - As used throughout this manual: Means Attention! Be Alert! Your safety is involved.
Means immediate hazards which, if not avoided, will result in immediate, serious personal in-
jury or loss of life. Means potential hazards which could result in
personal injury or loss of life. Means hazards which could result in minor
personal injury.
2
SP-GA 10/98
stream of the regulator. Tighten the connecting nuts firmly using two wrenches to prevent damage to the torch.
3. Assemble desired nozzle (see Table) to the torch and tighten nozzle retaining nut firmly.
Never touch the nozzle to the work piece.
NOTE: The optimal amount of preheat oxygen is auto-
matically regulated by the torch. The pilot oxy­gen valve is used only to adjust the pilot flame.
Cutting: Preheating is done while cutting lever is fully depressed. Position torch on the far side of steel to be cut. While maintaining at least 4 in. nozzle-to-work stand­off, position the flame on the edge of the steel. Pull torch towards you to begin cutting.
ADJUSTING GAS PRESSURES
1. Depress the cutting lever fully. Adjust cutting oxy­gen regulator to the desired pressure (see Figure 1) compensating for any line loss to the torch through the hose and valve. Then immediately release the lever.
2. Adjust fuel gas regulator to provide 20 psig at the torch with flow.
TESTING FOR LEAKS
The system should be thoroughly tested for leaks after it is first hooked up, and at regular intervals thereafter. With the system pressurized down to the shutoff valves, apply Leak Test Solution suitable for oxygen service, such as P/N 998771 (8 oz. container), on all joints and connections. Bubbling of the solution indicates leakage. If leakage is detected, tighten the connection. If this does not stop leakage, then shut off the appropriate gas sup­ply and open the torch valve to remove pressure from the system. Break the leaky connection, wipe metal seat­ing surface with a clean dry cloth, and examine them for nicks and scratches. Remake the connection(s) and re­test. Do not try to light the torch until you are satisfied that all connections are gas tight.
After lighting the torch and adjusting the flames, use leak test solution to check for leakage around hose connec­tions at each valve and torch fitting.
LIGHTING AND FLAME ADJUSTMENT Lighting Pilot Flame: Open fuel gas valve fully and light
the gas about 2 inches from the nozzle with a friction lighter. DO NOT use a match. Use of a match can seri­ously burn your hand. Slowly open the pilot oxygen valve until the pilot flame is adjusted as desired. For best per­formance, a flame extending just beyond the nozzle skirt is recommended.
Cutting Flame Adjustment: While torch is lit in pilot mode, point torch in a safe direction, hold torch firmly and depress cutting lever fully. CAUTION: The torch will tend to kick back from the force of the cutting oxygen. Adjust fuel gas valve to give desired flame. Release cut­ting lever to return to pilot mode. Depress cutting lever several times, both slowly and quickly to ensure pilot flame is set properly. If torch extinguishes itself when lever is released, open pilot oxygen valve slightly to in­crease pilot oxygen flow, relight torch and readjust pilot oxygen valve.
NOTE: The flame is hottest at the edge of the cutting
oxygen stream. Placing the edge of the cutting oxygen stream on the edge of the steel will give the fastest starts.
Torch head, nozzle, and nozzle nut become VERY hot while pilot flame is on and remain hot for sev­eral minutes after torch is turned off. Do NOT allow hot torch to contact anything flammable.
SHUTTING OFF
1. Release cutting oxygen lever.
2. Close the pilot oxygen and fuel gas valves.
If operations are to be stopped for a half-hour or more, pressure should be released from all regulators in the following order:
1. Close station valve of each gas supply.
2. Open all torch shutoff valves.
3. When pressure on each regulator gauge drops down to zero, back out regulator pressure-adjusting screw.
4. Close torch shutoff valves.
OPERATING PRECAUTIONS
Flow: There must be proper flow of gases for safe op-
eration and full performance. This requires the following three conditions: (1) the regulators that determine the inlet pressure to the hoses must be set to the correct pressure: (2) the hoses and their connectors must have adequate capacity for the job (hoses that are too long, too small or have connectors with small passageways can cause problems); and (3) the throttle valves on the torch must be adjusted with the procedure shown in these instructions.
NOTE: Items (1) and (2) can be checked by measuring
the gas pressures at the torch. Gauge adaptors are available for this purpose.
Backfire: Improper operation of the torch may cause the flames to go out with a loud “pop”. Such a backfire may be caused by contact of nozzle with the work, by the use of incorrect gas pressures or by leakage at the cutting nozzle seats due to dirt or nicks on the seats or to a loose nozzle nut.
3
OPERATING DATA
GENERAL NOTE:
1. 1/2" (12.7 mm) hose is recommended for oxygen, 3/8" (9.5 mm) hose is recommended for fuel gas.
2. Oxygen pressure is measured at the torch inlet connection.
3. The conditions listed in the table are based on typical conditions for cutting mild steel at ambient temperatures. They should only be used as a starting point. Cut quality can vary depending on the temperature and metallurgical content of the steel, steel quality, surface condition, oxygen purity, etc., in addition to the pressures and cutting speed.
4. The post mix nozzles have divergent bore cutting orifices that are intended for applications where it is necessary to cut quickly. For other specific applications, contact your ESAB representative or distributor.
NON-METRIC DATA
NOZZLE STEEL GAS PRESSURE, PSIG NOZZLE GAS CONSUMPTION, CFH
PART THICKNESS NAT. GAS STAND-OFF NATURAL
NO. (IN.) OXYGEN* OR PROP.* (IN.) OXYGEN GAS
2118700 10-16 80 - 110 10 - 30 4 TO 6 2080 225-500 2118701 6-10 80 - 110 10 - 30 4 TO 6 1640 225-500 2118702 3-6 80 - 110 10 - 30 4 TO 6 1260 225-500
METRIC DATA
NOZZLE STEEL GAS PRESSURE, BARS NOZZLE GAS CONSUMPTION, M3/HR
PART THICKNESS NAT. GAS STAND-OFF NATURAL
NO. (MM) OXYGEN* OR PROP.* (MM) OXYGEN GAS
2118700 254-406 5.5 - 7.6 0.6 - 1.9 95 58 6.4-14.2 2118701 152-254 5.5 - 7.6 0.6 - 1.9 95 46 6.4-14.2 2118702 76-152 5.5 - 7.6 0.6 - 1.9 95 36 6.4-14.2
*NOTE:Oxygen pressure: Set while cutting lever is depressed; pressure measured at the torch.
Natural gas or propane pressure: Set while cutting lever is depressed and fuel gas valve is wide open; pressure measured at the torch.
Figure 1
4
MAINTENANCE
For all repairs other than those covered below, send the torch to ESAB Welding & Cutting Products Remanfacturing Center, 411 South Ebenezer Road, Flo­rence, SC 29501.
Testing Seats: Under normal use the internal seating surfaces in the nozzle socket should last the life of the torch. Should reseating be necessary, reseating should be done only by the factory or a qualified repair person. To test the seat, thinly coat the seating surfaces of a new nozzle with nondrying Prussian blueing. Insert the nozzle into the nozzle socket without the nozzle nut and rotate the nozzle by hand one half turn. Remove the nozzle and observe the seating surfaces in the socket. Blueing should be evenly distributed on both seating surfaces. Depressions or the absence of uniform blue­ing indicates the nozzle socket requires reseating.
Reseating: By hand, screw in reseating tool P/N 5230207 into nozzle head. Do not overtighten or dam­age to head could result. While gently tightening and holding threaded nut of reseating tool, slowly rotate reamer allowing tapered seat to be reseated. Make sure reamer is rotated at least two revolutions so that reseated surfaces are true. Retest seats and repeat if necessary until seating surfaces have been restored. Clean out metal shavings before putting torch back into service.
PM nozzles cannot and should not be reseated.
maximum force. If this does not eliminate leakage, try a new valve assembly. If then the valve does not shut off completely, send the torch to a repair station for reseating of the body.
Cutting Oxygen Valve
If leakage develops around the oxygen valve stem, re­place the valve packing bushing. If leakage develops through the oxygen valve, replace the valve seat. Re­placement procedure as follows:
1. Unscrew the lever attaching screw and lift the lever off.
2. Unscrew the valve stem guide and remove the valve assembly from the guide.
3. Use Leak Test Solution to moisten the stem head, then remove the packing bushing and ferrule. Re­move the sealing ring from the bushing. Lift off the spring and spring support.
4. Replace the valve seat (stem) if necessary and any other parts which are worn or damaged.
5. Reassemble the valve following the above instruc­tions in reverse order.
Cleaning Cutting Nozzle: If the cutting nozzle does not produce straight, uniform flames, or if any of the pre­heat nozzle holes become clogged, clean them by us­ing the serrated tip cleaners in the cleaning kit supplied with the torch, part number 751F00. Maintaining clean preheat holes is essential for quality performance of this equipment.
Preheat Valves: Leakage around either throttle valve can usually be corrected by tightening the packing nut slightly. If this does not stop the leakage, replace the throttle valve.
If either preheat valve fails to shut off completely, re­move the throttle valve assembly from the torch. With a clean cloth, wipe the ball in the end of the stem. Then reinsert valve assembly and tighten it several times with
If the cutting orifice becomes clogged or fouled, gently insert and twist the appropriate tapered cleaning tool found in the cleaning kit. Nozzle P/N 2118703 should only be cleaned with Oxweld nozzle cleaning compound P/N 761F00. The use of twist drills for cleaning holes is not recommended. Nozzles should be cleaned periodi­cally in a solution of OXWELD Nozzle Cleaning Com­pound (P/N 761F00), made up and used as directed on the container in which it is packed.
5
(See Detail “A”)
PARTS INFORMATION
Part Numbers
PM-GST Torch Assembly
BUSHING -
92Z18
VALVE STEM -
22080
Length 75° Head 90° Head 180° Head
4-ft 22086 22094 22098
5-ft 22087 22095 22099
GUIDE -
22083
SPRING -
6-ft 22088 22096 22100
8-ft 22089 22097 22101
28Z43
10-ft 22090 - 22102
12-ft 22091 22106** 22103
16-ft 22092 22107** 22104
BUSHING -
92Z18
18-ft 22093 - 22105
SLIP RING -
38Z64
DIAPHRAGM -
** NEW
30Z54
SCREW - 34Z50
LEVER ASS’Y - 25Y16
DETAIL “A”
(ENLARGED VIEW)
FG VALVE ASS’Y- 22084
BUSHING - 39Z58
LOCKWASHER #12
VALVE ASS’Y - 22110
2
FG VALVE ASS’Y - 22084
O
PLUG - 35Z64
O-RING - 96W97
REAR BODY -
THROTTLE VALVE ASS’Y - 54A87
22066
VALVE SEAT/STEM -
33Y43
GUIDE - 52Z88
Replaceable parts are illustrated below. When ordering parts, please give both part number and description. DO NOT order by part number alone.
O-RING - 86W70
FERRULE - 73A93
WASHER - 37A39
SPRING - 29Z37
BUSHING - 57A18
SPRING SUPPORT -
6
DETAIL “A”
(ENLAGED VIEW)
VALVE ASS’Y- 22110
2
O
73Z90
ADAPTOR -
22070
SUPPORT -
22072
HEADS
75° - 22076
90° - 22077
Fig. 2 - Replacement Parts, PM-GST Torch Assembly (75° Head illustrated)
NUT EXTENDED - 22075 (1.06"-18)
180° - 22078
RIDING SKID (NOT SHOWN) - 22073
7
F-15-365-C 07/2000 1C Printed in U.S.A.
