3 INTRODUCTION
LTS 160, LTS 250 are welding power sources of the rectifier type designed for
mechanised TIG welding.
They are fan--cooled and also includes a cooling system for water--cooling of the
welding tool.
They is prepared for connection to an external PC.
3.1 Equipment
LTS 160 and LTS 250 are supplied with:
S Programming box with connection cable (10 m)
S Return cable (5 m) with return cable clamp
S Gashose(2m)withhoseclamp.
S End resistor.
S Programming manual in swedish, english, german och french.
S PC card.
dpb6d1ea
-- 4 9 --
GB
3.2 Programming box
The welding power source is provided with a programming box for:
S Programming of welding procedures when welding with a welding tool.
S Executing a welding process.
S Storing welding program in an internal or external memory unit (PC card).
S Transferring welding programs between programming units.
S Setting of different parameter values when welding with a TIG hand torch.
For the handling, see Programming manual.
The programming manual is available in the following languages:
Language Article no. Language Article no.
English 0457 706 X74 French 0457 706 X76
German 0457 706 X75 Swedish 0457 706 X70
Italian 0457 706 X79 Finnish 0457 706 X73
Norwegian 0457 706 X72 Danish 0457 706 X71
Dutch 0457 706 X77 Spanish 0457 706 X78
Portuguese 0457 706 X80 Russian 0457 706 X86
3.3 Applications
Welding power source LTS can be used for welding with:
S Tube welding tools for joining tubes
S Tube--to--plate welding tools for welding of tube diameters 12--60 mm
S Automatic welding machine A25 STB with floating head.
S TIG hand torch
A wire feed unit for filler wire can be connected to the welding power sour ce.
Motors for external units (roller beds, turntables, etc.) can be controlled by way of the
PAL 3 motor control unit.
ESAB accessories for mechanised and manual T IG welding are found on
page 157.
dpb6d1ea
-- 5 0 --
GB
4 TECHNICAL DA TA
LTS 160 LTS 250
Mains voltage 230 V ±10%, 1∼ 50/60 Hz 400 V ±10%, 3∼ 50/60 Hz
Permissible load at
35 % duty cycle
60 % duty cycle
100 % duty cycle
No--load power 50 W 55 W
Power factor 0,68 0,61
Efficiency ≥0,75 ≥0,75
No--load voltage 70 V 70 V
Primary current:
100% duty cycle
Arc strike HF HF
Dimensions l x w x h
without cooling unit
with cooling unit
Weight without cooling unit
with cooling unit
Temperature class F (155 _C) F (155 _C)
160 A / 16 V
110A/15V
80 A / 13 V
9A 9A
515 x 285 x 620 mm
515 x 285 x 835 mm
37 kg
56,5 kg
250 A / 20 V
180 A / 17 V
140 A / 16 V
515 x 285 x 620 mm
515 x 285 x 835 mm
38 kg
57,5 kg
Enclosure type IP 23 IP 23
Application class
Setting range
LTS 160 LTS 250
Operating range, current 5 A / 10 V -- 160 A / 16 V 5 A / 10 V -- 250 A / 20 V
Steps of adjustment, current 1A 1A
Wire feed speed 0.10--2.50 m/min 0.10--2.50 m/min
Pulse and background time 0.01 -- 25.0 s 0.01 -- 25.0 s
Pre--heat time 0 -- 600 s 0 -- 600 s
Gas pre-- and post--flow 0 -- 6000 s 0 -- 6000 s
Slope-- up and slope down 0,1 -- 25 s 0,1 -- 25 s
Sector 0--10r 0--10r
Steps of adjustment, sector
break point
Duty cycle
The duty cycle refers to the time as a percentage of a ten--minute period that you can weld at a certain load without overloading the welding power source.
0,001 r 0,001 r
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Equipment marked IP 23 is designed for indoor and outdoor use.
Application class
The symbol indicates that the power source is designed for use in areas with increased
electrical hazard.
dpb6d1ea
-- 5 1 --
GB
5 INSTALLATION
The in stallatio n must be executed by a p rofessional.
WARNING!
This product is intended for industrial use. In a domestic environment this product may cause radio
interference. It is the user’s responsibility to take adequate precautions.
Place the welding power source so as not to prevent the cooling air from circulating
through the machine.
5.1 Lifting instructions
dpb6d1ea
-- 5 2 --
GB
5.2 Mains voltage connection
S Make sure the welding power source is connected to the right mains voltage and
that it is properly fused. Connect to earth according to the regulations valid.
The rating plate with connection data.
Recommended cable areas and fuse sizes
LTS 160 LTS 250
Mains voltage 230 V 400 V
Mains frequence 50--60 Hz 50--60 Hz
Fuse, slow--blow 16 A 16 A
Cable area
3x2,5mm
2
4x1,5mm
2
5.3 Termination resistans
To avoid communication trouble the two end points of
the CAN --bus should be fitted with an termination
resistans. One of the CAN--bus end points is in the
programming box which has a built-- in resistor. The
other one is in the power source and should be fitted
with an termination resistans if the output in question is
not used. For the location of the resistor, see the
following figure.
dpb6d1ea
-- 5 3 --
GB
5.4 Connection of complete welding system
A--A Connection cable -- programming box
B--B, Z--Z Motor cable --wire feed
C--C, S--S Motor cable -- rotation
D--D Signal cable -- external PC
G--G Cooling--water hose in
H--H Cooling--water hose out
J--J Welding cable
L--L Torch contact
M--M Gas hose out
N--N Gas hose in
P--P Signal cable -- external PC
Q--Q Return cable +
R--R Connection cable -- pulsetransmitter
VEC
T--T,V--V Connection cable -- CAN 42 V
X Connection cable -- external motor
U--U Connection cable -- rotor VEC
dpb6d1ea
-- 5 4 --
GB
6 OPERATION
General safety regulations for the handling of the equipment can be found on
page 48. Read through before you start using the equipment!
6.1 Controls and connections
1 Connection for programming box 11 Fuse, slow rupture 1.25 A
(connection 230 V)
2 Connection CAN 42 V for motor control unit
PAL3 and A25 VEC motor
3 White indicating lamp, mains voltage ON 13 Connection for flow--guard, (water)
4 Orange indicating lamp, overheating 14 Connection for welding and start gas out
5 Switch for mains voltage ON/OFF 15 Connection for torch contact, TIG hand torch
6 Connection for root gas in 16 Connection for return cable (+)
7 Connection for welding gas in 17 Connection for welding cable (--)
8 Connection for start gas in 18 Connection for rotation
9 Connection for root gas out 19 Connection for wire feed
10 Fuse, slow rupture 1.25 A
(connection 230 V)
12 Connection for cooling unit 230 V, 1.25 A
20 Connection for PC/printer
dpb6d1ea
-- 5 5 --
GB
6.2 Cooling unit
N.B. To give room for the cooling unit under the welding
power source, the tool box on the carriage must be
dismounted.
Screw the cooling unit and the welding power source
together.
6.3 Overheating protection
The LTS is provided with a thermal cut--out which trips in case of too high
temperature. The welding current is interrupted and an orange indicating lamp on the
front of the power source lights up. The programming box also shows an error
message. The thermal cut--out is reset automatically when the unit has cooled down.
6.4 Flow guard, water
If there is no cooling water flowing, the flow guard will block the welding power
source. The welding current is then interrupted and an error message is displayed in
the character window of the programming unit.
6.5 Flow guard, gas
The flow guard interrupts the ongoing welding process if the gas flow falls below 6
l/min. An error message is displayed by the programming box.
6.6 Error messages
The welding power source has a built-- in function for handling error messages. All
error messages are presented in the programming box, and in some cases
measures will be taken automatically. See also programming manual 0457 706 xxx.
dpb6d1ea
-- 5 6 --
GB
7 MAINTENANCE
Note:
All warranty undertakings given by the supplier cease to apply if the customer
attempts to rectify any faults on the machine during the warranty period.
Only those persons who have appropriate electrical knowledge (authorised
personnel) may remove the safety plates to connect or carry out service,
maintenance or repair work on welding equipment.
7.1 Check--up and cleaning
Generally LTS 160 and LTS 250 does not require any
maintenance. Normally, it is sufficient to blow out the
machine using clean, compressed air (reduced pres sure) annually, and the dust filter should be cleaned
regularly. If the machine is set up in dusty or dirty
environment the machine and the dust filter should
be cleaned more often.
Dismounting the filter
8 ORDERING OF SPARE PARTS
LTS 160, LTS 250 is designed and tested in accordance with the EN 60974--1 (IEC
50199) international standard.
It is the obligation of the service unit which has carried out the service or repair work
to make sure that the product still conforms to the said standard.
Spare parts are ordered through your nearest ESAB representative, see back cover.
When ordering spare parts, please state machine type and number as well as designation and spare part number as shown in the spare parts list.
This will simplify dispatch and ensure you get the right part.
dpb6d1ea
-- 5 7 --
Loading...
