Engine driven welder

Instruction manual and spare parts list

0700 161 100

Valid for Origo

70

(':'

Valid for OrigoTMEDW 510D serial No. 730-xxx-xxxx

TM

EDW 610D serial No. 745-xxx-xxxx

CONTENTS Page

1 SAFETY 2
2 INTRODUCTION 4
3 TECHNICAL DATA 6
4 INSTALLATION 8
5 OPERATION 9
6 MAINTENANCE 10
7 FAULT TRACING 13
8 CIRCUIT DIAGRAM 14
9 SPARE PARTS LIST 15

1 SAFETY

Users of ESAB welding equipment have the ultimate responsibility for ensuring that anyone who works on
or near the equipment observes all the relevant safety precautions. Safety precautions must meet the
requirements that apply to this type of welding equipment. The following recommendations should be
observed in addition to the standard regulations that apply to the workplace.

All work must be carried out by trained personnel well-acquainted with the operation of the welding
equipment. Incorrect operation of the equipment may lead hazardous situations which can result in injury
to the operator and damage to the equipment.

1. Anyone who uses the welding equipment must be familiar with:

• its operation

• location of emergency stops

• its function

• relevant safety precautions

• welding

2. The operator must ensure that:

• no unauthorised person is stationed within the working area of the equipment when it is started
up.

• no-one is unprotected when the arc is struck

3. The workplace must:

• be suitable for the purpose

• be free from draughts

4. Personal safety equipment

• Always wear recommended personal safely equipment, such as safety glasses, flame-proof
clothing, safety gloves.

• Do not wear loose-fitting items, such as scarves, bracelets, rings, etc., which could become
trapped or cause burns.

5. General precautions

• Make sure the return cable is connected securely.

• Work on high voltage equipment

• Appropriate fire extinguishing equipment must be clearly marked and close at hand.

• Lubrication and maintenance must

6. EMF information
To reduce your exposure to electromagnetic fields, use the following procedures:

• Keep cables close together by twisting or taping them.

• Arrange cables to one side and away from the operator.

• Do not coil or drape cables around your body.

• Connect work clamp to workpice as close to the weld as possible.

Do not dispose of electrical equipment together with normal waste!

In observance of European Directive 2002/96/EC on Waste Electrical and Electronic
Equipment and its implementation in accordance with national law, electrical equipment that
has reached the end of its life must be collected separately and returned to an
environmentally compatible recycling facility. As the owner of the equipment, you should get
information on approved collection systems from our local representative.
By applying this European Directive you will improve the environment and human health!

may only be curried out by a qualified electrician.

not

be carried out on the equipment during operation.

2

WARNING

ARC WELDING AND CUTTING CAN BE INJURIOUS TO YOURSELF AND OTHERS. TAKE
PRECAUTIONS WHEN WELDING. ASK FOR YOUR EMPLOYER’S SAFETY PRACTICES WHICH
SHOULD BE BASED ON MANUFACTURER’S HAZARD DATA.

ELECTRICAL SHOCK - Can kill

•

Install and earth the welding unit in accordance with applicable standards.

•

Do not touch live electrical parts or electrode with bare skin, wet gloves or wet clothing.

•

Insulate yourself from earth and the workpiece.

•

Ensure your working stance is safe.

FUMES AND GASES – Can be dangerous to health

•

Keep your head out of the fumes.

•

Use ventilation, extraction at the arc, or both, to keep fumes and gases from your breathing zone and

the general area.

ARC RAYS – Can injure eyes and burn skin.

•

Protect your eyes and body. Use the correct welding screen and filter lens and wear protective clothing.

•

Protect bystanders with suitable screens or curtains.

FIRE HAZARD

•

Sparks (spatter) can cause fire. Make sure therefore that there are no inflammable materials nearby.

NOISE – Excessive noise can damage hearing

•

Protect your ears. Use earmuffs or other hearing protection.

•

Warn bystanders of the risk.

MOVING PARTS – Can injure

• Do not operate with guards or covers off.

• Stop engine before servicing.

• Keep away from moving parts.

FUEL – Can cause fire or explosion

• Stop engine and let it cool before checking or adding fuel.

• Do not add fuel while smoking or if unit is near any sparks or open flames.

• Do not spill fuel. If fuel is spilled, clean up before starting engine.

BATTERY EXPLOSION – Can blind

• Always wear a face shield, rubber gloves and protective clothing when working on a battery.

• Stop engine before disconnecting or connecting battery cables or servicing battery.

• Do not allow tools to cause sparks when working on a battery.

• Observe correct polarity (+ and -) on battery.

• Disconnect negative (-) cable first and connect it last.

MALFUNCTION – Call for expert assistance in the event of malfunction.

PROTECT YOURSELF AND OTHERS!

WARNING!

Read and understand the instruction manual
before installing or operating.

Note! This product is solely intended for arc welding.

WARNING!

3

Do not use the power source for thawing frozen pipes.

2 INTRODUCTION

The Origo

TM

EDW 510/610D is a combined engine driven welding and electric power unit.
It is designed for working even under the toughest job requirements. It is suitable for MMA
welding with all types of DC electrodes, especially cellulose; scratch start TIG welding or
TIG with additional equipment for high frequency start and for arc air gouging. The
auxiliary power generator provides alternating current for power tools, lighting etc.
Continuous welding and auxiliary power can be used simultaneously.

The Origo

TM

EDW 510/610D is ideal for quality welding in assembly work, service and
repair in the field, e.g. pipelines, petrol-chemical plants, off-shore work etc.
Stationary form is a standard design. On request, the welding unit can be provided with
two or four wheel trailer.

Front control panel

213456

22
21

20

19

18
17

16
15

14

STOP

220V 220V

$

7

13

12

11

910

8

1 Engine control module
2 Fuel level gauge
3 Voltmeter (optional)
4 Ammeter (optional)
5 Current range switch
6 Welding current fine setting
7 Polarity switch (optional)
8 Workpiece connection
9 Welding terminal (MMA and TIG)
10 Gouging terminal
11 Socket 220V,16A (optional 110V)
12 Socket 220V,32A
13 Earth terminal
14 Remote control connection
15 Hot start off switch (optional)
16 Remote control switch
17 LED yellow - overheating
18 Circuit breaker - exciter circuit protection
19 Circuit breaker - fuel solenoid protection
20 Circuit breaker 220V
21 Circuit breaker 220V (optional 110V)
22 Emergency stop push button (optional)

4

The engine is the F3L912, made by Deutz, a well known manufacturer with a world wide
service network.
The engine drives three-phase synchronous welding generator, single-phase auxiliary
power generator and their exciter unit. The complete rotor assembly is statically and
dynamically balanced to assure vibration-free operation and maximum bearing life.
Bearing is fully sealed, so that no lubrication is required during the exploitation. There are
no slip rings or brushes to maintain.

The welding unit canopy is designed for single side servicing and protects the machine. It
ensures correct air flow around the engine and the generator.

The front panel is fitted with engine starting controls, welding controls and auxiliary power
outputs. The engine control module (A2) is used to start and stop the engine and indicate
fault conditions: low oil pressure, high cylinder head temperature and low battery
charging. The module automatically shuts down the engine if the oil pressure is low or the
temperature is too high.
The module has an integral tamperproof LDC hours run counter to indicate total engine
run time.

Welding coarse settings are carried out by a three-phase inductor (L1) connected to the
generator windings star (G). The range switch (SA3) is three-positioned. AC current from
the generator (G) is rectified via the diode bridge (V1.1-V1.6), and the welding current
stabilization is carried by stabilizer (L2).

Welding current fine setting is made by a rheostat (RP1), which allows adjustment of
welding amperage from minimum to maximum of the coarse range.
OCV control circuit provides max open circuit voltage of 92V, regardless of the welding
current setting. The rheostat (RP1) does not affect on OCV because it is shorted when
the arc breaks. When the arc is struck, reed relay (KR1) is operated and allows
adjustment of welding current with the rheostat (RP1).
Optional hot start switch (SA4) disables the max OCV. Switch breaks the max OCV
control circuit and allows the arc striking with open circuit voltage of 65-92V depending
on current setting.

Optional remote control is available for fine current setting.
Polarity of weld outputs is selected by an optional polarity switch.
Optional voltmeter displays voltage at the weld output terminals.
Optional ammeter displays amperage output of the unit.

The thermostat (ST2) is placed on the diode bridge’s heat sink. It prevents the power
source from overheating. The thermostat reset automatically. The yellow LED lights up in
case of overheating.

The auxiliary power generator (G1) produces a maximum of 6,2 kVA. Two sockets (220V)
are available on the front panel (one socket 110V optional). The circuit breakers QF1 and
QF2 offer short-circuit protection, overload protection and earth fault protection

.

5

3 TECHNICAL DATA

Origo

TM

EDW Origo

TM

EDW

Welding generator 510D 610D

Output current range 40-500A 40-700A
Permitted load:
at 25% duty cycle - 650A/25V
at 40% duty cycle 450A/38V 575A/43V
at 60% duty cycle 400A/36V 530A/41,2V
at 100% duty cycle 300A/32V 500A/40V
Open circuit voltage 92 V 92V
Insulation class H (180

0

C) H (1800C)

Auxiliary power generator
Max. output 6,2kVA, cosij 0,8 6,2kVA, cosij 0,8
Voltage 220V, 60Hz 220V, 60Hz
Earth fault protection 30mA 30mA

Simultaneous welding and power loads

300A/32V+6,2kVA 450A/38V+6,2kVA

Diesel engine Deutz F3L 912

Type 3-cylinder
Fuel code Diesel DIN 51601
Prime power at 1800 rpm, ISO 3046-1 32,0 kW
Reference conditions:
Ambient temperature +25

o

C
Altitude 100m
Relative humidity 30%
Speed:
no-load speed 1890 rpm
load speed 1800 rpm
Displacement 2,827 dm

3

Cooling air
Starting system, electrical 3kW /12V
Fuel tank capacity 90 l
Fuel consumption (at 100% duty cycle) 220 g/kWh (approx. 8,4 l/h)
Oil consumption (0,5% of fuel consumption) 0,042 l/h
Battery 12V/100Ah

Complete unit

Enclosure class IP23
Working ambient temperature -10

o

C to +40oC
Dimensions (LxWxH) 1610x850x990 mm
Standard EN 60974-1
Weight (dry) 775kg 795kg

Duty cycle

The duty cycle refers to the time as a percentage of a ten–minute period that you can weld
at a certain load without overloading.

Enclosure class

The IP code indicates enclosure class, i.e. the degree of protection against penetration by
solid objects and water. Equipment marked IP23 is designed for indoor and outdoor use.

6

Static characteristics Origo

100

90

80

70

60

50

U (V)

40

30

20

10

0

0 100 200 300 400 500 600 700

Static characteristics Origo

TM

EDW 510D

Welding current range for
MMA:
Step I 40-85A
Step II 60-200A
Step III 110-450A

I (A)

TM

EDW 610D

100

Welding current range for

90

80

70

60

50

U (V)

40

30

20

10

0

0 100 200 300 400 500 600 700

I (A)

MMA:
Step I 40-90A
Step II 75-235A
Step III 140-575A

7

4 INSTALLATION

The installation must be executed by a professional.

• Read this instruction book before installing or operating the machine.

4.1 Unpacking the machine

• Remove the plastic envelope from the machine.

• Lift the upper machine from the bottom machine if any.

• Remove the transport support from the bottom machine.

• Mount eye nut M30 to the bottom machine.

• Lift the bottom machine from the transport palette.

• Mount the muffler tube to the machine.

4.2 Lifting instructions

Use lifting eye to lift or move the machine.

Do not lift the machine and road tow trailer together!

Lifting eye is not designed to support added weight.

4.3 Positioning the machine

• Place the machine on a level surface at a distance of at least 1,5m from side walls.

• If the surface is not level be sure that the angle does not exceed 10

0

.

• Use the machine in open, well ventilated areas or vent the engine exhaust fumes outdoors.

4.4 Battery connection

• The diesel welding unit is shipped with the battery cables disconnected. Connect the
positive cable, than the negative cable last.

• When installing a new battery disconnect negative cable from old battery first.

• Be sure to use the correct polarity when charging the battery.

4.5 Grounding

• Always ground machine frame to transport vehicle frame to prevent electric shock and
static electricity hazards.

• Always ground machine frame to system earth ground if supplying power to a premises

(home, shop…)

4.6 Spark arrestor (optional)

A suitable spark arrestor must be installed when the diesel welding unit is operated in
certain locations where unarrested sparks may present a fire hazard.

8

Do not touch hot muffler or exhaust pipe!

• Stop the engine and let cool.

• Remove the exhaust pipe.

• Install the spark arrestor on the exhaust pipe.

• Tighten the clamp.

5 OPERATION

5.1 Starting the engine

• Disconnect all weld and power load from the generator.

• Turn the ignition key to the hand position.

• Press the pre-heat (yellow) button for required time (optional: cold starting aid –17

0

C).

• Press and hold the START (green) button for few seconds to crank the engine.

• The starter motor is disengaged automatically when the engine fires or when the START

button is released.

• The control module indicates fault conditions by LED: low oil pressure, high cylinder head

temperature and low battery charging.

• The module automatically shuts down the engine if any of following alarms are operated:

low oil pressure and high cylinder head temperature.

• The alarm output and relevant LED will remain active until the unit is reset by turning the

key to the “0” position.

• The module is provided with the LCD hours run counter which is incremented whenever

the engine is running.

• Let the engine idle for a few minutes before applying load.

5.2 Stopping the engine

• Disconnect all weld and power load from generator.

• Turn the ignition key to the off position.

• Press the emergency stop button (optional).

• When engine is not running ignition key must be in position 0 to protect battery from

discharging.

5.3 Welding output

• Select suitable welding and return cables and connect them to the welding terminals.

• Connect welding cable to the terminal marked for MMA/TIG welding or to the terminal

marked for arc air gouging.

• Select either Electrode Positive or Electrode Negative by the polarity switch.

• Connect the return cable to the work piece.

• Set the welding current range using the range switch. Current fine setting is made by a

rheostat, which allows adjustment of welding amperage from minimum to maximum of the
current range.

9

• Remote control is available only for fine current setting. For remote control, place switch in

Remote position and connect remote control to the remote control connector.

• The current range switch and the polarity switch should not be switched over during

welding operation!

• The FINE CURRENT control may be adjusted while welding!

• Check that the electrode holder has no electric connection with the return clamp!

• Do not weld anything on the welder machine!

• The thermostat mounted on the diode bridge prevents the power source from overload.

The thermostat reset automatically.

5.3.1 Selecting weld cable sizes

The following current load is recommended for the individual sectional areas, duty factors
and cable length up to 30m. For cable distance longer than 30m, use next size larger cable.

Sectional copper cable area (mm

2)

Maximum permissible current (A)

for duty factor

100% 60% 35%

35 225 243 279
50 285 316 371
70 355 403 482
95 430 498 606

5.4 Auxiliary power output

The auxiliary power generator provides alternating current for power tools, lighting etc.
Two sockets 220V are available on the front panel.
The circuit breakers offer short-circuit protection, overload protection and earth fault protection.
If the generator is overloaded circuit breaker will automatically stop supplying electricity. If this
happens disconnect your equipment, let the motor idle for a while, and then reconnect again.
The circuit breaker will cut off supply in case of an earth fault (residual current I

 30mA). If this

ΔN

happens check for faulty tools and reset switch.
This protective device will not protect the operator unless there is a good ground. It is
responsibility of person to use a good quality earth cable and connect it to the earth terminal of
the machine.
All tools must be earthed to the machine frame using an earthed type plug or should be double
insulated.

5.4.1 Testing the earth fault protection

Set the residual current circuit breaker to the position 1. Test by pressing the test button while
the engine is running. The circuit breaker should cut out and the breaker return to position 0.
Reset the breaker to position 1.

6 MAINTENANCE

6.1 Generator maintenance

The generator requires minimum of maintenance. Under normal operating conditions it is
sufficient to blow dust with dry, low pressure air once a week.

6.2 Engine maintenance

The engine requires a certain amount of maintenance (see the engine instructions).
Recommended service intervals must be observed and maintenance work carried out
conscientiously. Special care should be taken under extra demanding operating conditions.

10

1)

check

clean

every

change

Operation

Ɣ Oil level in engine/separate container

5000

3000

2000

1000

500

Ɣ Engine leaks

Recommended maintenance schedule:

Operation hours

250

125

daily

Every

10H or

2)

Ɣ

Ɣ Ɣ Oil bath and dry type air cleaners 3) 4)

Ɣ Ɣ Battery and cable connectors

Once

after

Ɣ

50-150

Ɣ Ɣ Ɣ Ɣ Cooling system 3) 6)

Ɣ Ɣ Ɣ Ɣ Ɣ Ɣ Engine oil (depending of engine use) 5)

Ɣ Ɣ Ɣ Oil filter cartridge

Ɣ Ɣ Ɣ Fuel filter cartridge

Ɣ Ɣ Ɣ Ɣ Valve clearance (adjust if necessary)

Ɣ Ɣ Warning system

Ɣ Ɣ Ɣ Engine mounts (retighten if necessary)

Ɣ Ɣ Ɣ V-belts (retension if necessary)

Ɣ Ɣ Flame glow plugs 4)

Ɣ Ɣ Fuel precleaner

Ɣ Ɣ Ɣ Mountings

Ɣ Ɣ Partial –flow oil filter

Ɣ Ɣ Sheathed element heater plugs

Ɣ Ɣ Injection valve

The specified engine maintenance times are maximum values. Depending on the operating environment, shorter maintenance intervals may be

required. Please observe the operating instructions of the engine manufacturer.

1) Recommended maximum

2) Commissioning new or reconditioned engines

3) Clean if needed

4) Change if necessary. If fitted, service after service indicator.

5) Oil change interval

6) Clean system /cooling fins

7 FAULT TRACING

Try these recommended checks and inspections before sending for an authorised service
technician.

7.1 Welding generator G

Type of fault Measure

No arc

• Check that the welding and return cables
are properly connected

• Check if circuit breakers (FR1, FR2) are
open

•

Check position of remote switch (SA1)

The welding current is interrupted
during welding

The thermal cut-out trips frequently

• Check if the thermal cut-out has tripped
(The thermostat resets automatically)

•

Check that the ratings of the welding power
source have not been exceeded (overload
of the power source)

Poor welding result

• Check that the welding and return cables
are properly connected

• Make sure the welding current set is
correct

• Check that the correct electrodes are being
used

Excessive spatter from the arc

Ɣ Damp or defective electrode
Ɣ Incorrect electrode polarity
Ɣ Incorrect terminal connection: gauging

instead of welding terminal

7.2 Auxiliary generator G1

Type of fault Measure

No voltage build-up

•

Check that the circuit breaker QF1 and
QF2 are switched On

7.3 Engine

Type of fault Measure

Engine will not crank

Engine cranks but does not start

Engine shuts down shortly after starting
Engine runs rough and slowly stopped

13

• Check battery

• Check battery connections

• Check if circuit breaker (FR2) is open

• Check fuel level

•

Check fuel filter

• Check oil level

• Check oil temperature

•

Check oil temperature

• Check oil level

• Dirty fuel or air filters

•

Water in fuel

8 CIRCUIT DIAGRAM

black

blue

brown

y-green

14

9 ORDERING OF SPARE PARTS

Spare parts may be ordered through your nearest ESAB dealer, see the last page of this
publication. When ordering, please state product type, serial number, designation and spare
part number in accordance with the spare parts list. This facilitates dispatch and ensures
correct delivery.

Accessories

Remote control, 15 m

Ordering no.

0700161041
Spark arrestor 0700161043
Earth rod 0700161042
2-wheel trolley, off road 0700161045
2-wheel trolley, highway 0700161096
4-wheel trolley, off road 0700161046
4-wheel trolley, off road heavy duty with leaf springs 0700161084

Wear parts Ordering no.

Engine maintenance set, 2000h operation 0700161087

Control panel

18

17
16

15

14

13

12
11

FRONT SIDE BACK SIDE

STOP

220V 220V

10

654321

7

RP1 PA1 PV1

$

89

SA2

XS3

Z1

25

SA3

XS1 XS2

XT2

A2

P1

SB1

QF2 QF1

XS5

24 23

FR2 FR1

XS4

19 20

KA3 KA2 KA1

A2

RP2

V6

SA1

XS6

21

22

SA4

XT1

Quantity

Item
no.

TM

Origo
EDW510D

TM

Origo
EDW610D

1 1 1 0700161064 Engine control module (DSE702) A2
2 1 1 0700161116 Fuel level gauge P1
3 1 1 0700161070 Voltmeter (optional) PV1

15

Ordering no. Denomination

C=component designation in the circuit diagram

C

4 1 1 0700161071 Ampere meter (optional) PA1

1 1 0700161097 Shunt (optional) RS1
1 1 0700161066 A/V meter kit (optional) PA1,PV1,

RS1

5 1 1 0700161009 Current range switch SA3

1 1 0700161062 Current range switch handle

6 1 1 0700161050 Rheostat (8ȍ, 200W) RP1

1 1 0700161063 Rheostat knob
7 1 1 0700161072 Polarity switch (optional) SA2
8 3 3 0700161010 Welding terminal XS1-XS3
9 1 1 0700161012 Socket 220V, 16A XS5

1 1 0700161011 Socket 110V, 16A (optional) XS5

1 1 0700161118 110V socket/breaker kit (optional)

10 1 1 0700161102 Socket 220V, 32A XS4
11 1 1 0700161007 Remote control connector (3-pole) XS6
12 1 1 0700161119 Hot start off switch (optional) SA4
13 1 1 0700161006 Remote control switch SA1
14 1 1 LED yellow V6
15 2 2 0700161113 Thermal circuit breaker (16A) FR1, FR2
16 1 1 0700161002 Circuit breaker (220V, 25A/0,03A) QF1
17 1 1 0700161126 Circuit breaker (220V, 25A) QF2

1 1 0700161123 Circuit breaker (110V, 16A/0,03A)

(optional)
18 1 1 0700161120 Emergency stop button (optional) SB1
19 1 1 0700161085 Relay KA3
20 2 2 0700161065 Relay KA1, KA2
21 1 1 0700161015 Voltage regulator A1
22 1 1 0700161112 Resistor (0,6ȍ, 30W) RP2
23 1 1 Connection block XT1
24 1 1 Connection block XT2
25 1 1 0700161121 TIG-HF filter (optional) Z1

16

Generator

C=component designation in the circuit diagram

Item

Quantity

no.

1 1 1 Coupling disc SAE 8
2 1 1 Fan

1 0700161104 Rotor complete with fan

1 0700161114 Rotor complete with fan
3 1 1 Fan support
4 Axle
5 Welding generator rotor G
6 1 1 Auxiliary generator rotor G1
7 1 1 0700161023 Bearing (6210-2RS C3)
8 1 1 0700161024 Exciter rotor
9 2 2 0700161025 Diode bridge (SKD30/08 A1) V2, V3

10 1 1 Air outlet cover
11 Welding generator stator G
12 2 2

13 Stator cover
14 1 1 0700161124 Auxiliary generator stator G1
15 1 1 Exciter stator support
16 1 1 0700161029 Exciter stator
17 Air inlet cover

TM

Origo
EDW510D

TM

Origo
EDW610D

Ordering no.

Denomination

Foot

C

17

Diesel welder

C=component designation in the circuit diagram

Item

Quantity

no.

TM

Origo
EDW510D

TM

Origo
EDW610D

1 Control panel
2 1 0700160051 Fan EV1
3 1 0700161105 Generator G, G1

1 0700161115 Generator G, G1
4 2 2 0700161036 Shock absorber
5 1 1 0700161032 Diode bridge V1.1-V1.6

1 1 0700160048 Thermostat (1000C/800C) ST2
6 1 0700161051 Inductor L1

1 0700161074 Inductor L1
7 1 0700161106 Welding stabilizer L2

1 0700161075 Welding stabilizer L2
8 1 1 0700161111 Oil drainage valve (optional)
9 1 1 Battery 100Ah,12V, DIN540A GB1

10 2 2 0700161107 Shock absorber
11 1 1 Deutz engine F3L912
12 1 1 Service door
13 1 1 0216704801 Key lock latch

Ordering no.

Denomination

C

18

14 2 2 0700161098 Hinge
15 1 1 0700161110 Latch
16 1 1 Door
17 1 1 Exhaust pipe
18 1 1 0700161117 Fuel cap
19 1 1 0700161122 Fuel filter
20 1 1 0700161108 Fuel tank (90l)

1 1 0700161109 Fuel level indicator SL1

21 1 1 0700161042 Earth rod (optional) E1

Remote control

1

2

3

C=component designation in the circuit diagram

Item

Quantity

no.

1 1 1 0700161041 Remote control, 15 m
2 1 1 0700161050 Potentiometer (8ȍ, 200W)
3 1 1 0700161047 Connector (3-pole, male)

TM

Origo
EDW510D

TM

Origo
EDW610D

Ordering no. Denomination

C

19

E

S

A

B

Europe

AUS TR IA

ESAB Ges.m.b.H
Vienna-Liesing
Tel: [phone]
Fax: [phone]

BELGIUM

S.A. ESAB N.V.
Brussels
Tel: [phone]
Fax: [phone]

THE CZECH REPUBLIC
ESAB VAMBERK s.r.o.
Prague
Tel: [phone]
Fax: [phone]

DENMARK

Aktieselskabet ESAB
Copenhagen-Valby
Tel: [phone]
Fax: [phone]

FINLAND

ESAB Oy
Helsinki
Tel: [phone]
Fax: [phone]

FRANCE

ESAB France S.A.
Cergy Pontoise
Tel: [phone]
Fax: [phone]

GERMANY
ESAB GmbH
Solingen
Tel: [phone]
Fax: [phone]

GREAT BRITAIN
ESAB Group (UK) Ltd

Waltham Cross
Tel: [phone]
Fax: [phone]

ESAB Automation Ltd
Andover
Tel: [phone]
Fax: [phone]

HUNGARY

ESAB Kft
Budapest

Tel: [phone]
Fax: [phone]

ITALY
ESAB Saldatura S.p.A.
Mesero (Mi)

Tel: [phone]
Fax: [phone]

THE NETHERLANDS
Esab Nederland B.V.
Utrecht
Tel: [phone]
Fax: [phone]

ESAB subsidiaries and representative offices

NORWAY

AS ESAB
Larvik
Tel: [phone]
Fax: [phone]

POLAND

ESAB Sp.z.o.o
Warszaw
Tel: [phone]
Fax: [phone]

PORTUGAL

ESAB Lda
Lisbon
Tel: [phone]
Fax: [phone]

SLOVAKIA

ESAB Slovakia s.r.o
Bratislava

Tel: [phone]
Fax: [phone]

SPAIN

ESAB IbErica S.A.
Alcobendas (Madrid)
Tel: [phone]

Fax: [phone]

SWEDEN

ESAB Sverige AB
Gothenburg
Tel: [phone]
Fax: [phone]

SWITZERLAND

ESAB AG
Dietikon

Tel: [phone]
Fax: [phone]

North and South
America

ARGENTINA

CONARCO
Buenos Aires
Tel: [phone]
Fax: [phone]

BRAZIL

ESAB S.A.
Contagem -MG
Tel: [phone]
Fax: [phone]

CANADA

ESAB Group Canada Inc.
Mississauga, Ontario

Tel: [phone]
Fax: [phone]

MEXICO

ESAB Mexico S.A.
Monterrey
Tel: [phone]
Fax: [phone]

USA

ESAB Welding & Cuting
Products
Florence, SC
Tel: [phone]
Fax: [phone]

Asia / Pacific

CHINA

Shanghai ESAB A/P
Shanghai
Tel: [phone]
Fax: [phone]

INDIA

ESAB India Ltd
Calcutta
Tel: [phone]
Fax: [phone]

INDONESIA

P.T. Esabindo Pratama
Jakarta
Tel: [phone]
Fax: [phone]

MALAYSIA

ESAB (Malaysia) Snd Bhd
Selangor
Tel: [phone]
Fax: [phone]

SINGAPORE

ESAB Singapore Pte Ltd
Singapore
Tel: [phone]
Fax: [phone]

ESAB Asia/Pacific Pte Ltd
Singapore
Tel: [phone]
Fax: [phone]

SOUTH KOREA

ESAB SeAH Corporation
Kyng-Nam
Tel: [phone]
Fax: [phone]

UNITED ARAB EMIRATES

ESAB Middle East
Dubai
Tel: [phone]
Fax: [phone]

Representative
offices

BULGARIA

ESAB Representative Office
Sofia
Tel/Fax: [phone]

EGYPT

ESAB Egypt
Dokki-Cairo
Tel: [phone]
Fax: [phone]

ROMANIA

ESAB Representative Office
Bucharest
Tel/Fax: [phone]

RUSIJA-CIS

ESAB Representative Office
Moscow
Tel: [phone]
Fax: [phone]

ESAB Representative Office
St Petersburg
Tel: [phone]
Fax: [phone]

20
