B2CC043AA-C Product Manual
2.4 GHz WLAN Access Radio Module 3
Document Date: May 30 2006
Document Number: PM-B2CC043AA-C
Document Version Number: 1
Document Status: Release
© Copyright 2005 by BelAir Networks.
All rights reserved..
Page 1 of 14
B2CC043AA-C Product Manual – 2.4 GHz WLAN Radio Module
May 30 2006 Page 2 of 14
PM-B2CC043AA-C
B2CC043AA-C Product Manual – 2.4 GHz WLAN Radio Module
Contents
About this Document.......................................................................3
Introduction...................................................................................... 4
Conditions of Use.............................................................................5
Module Installation and Service.....................................................7
Final Product Requirements........................................................... 8
Regulatory Statements .................................................................. 11
About this Document
This document is a product manual for the B2CC043AA-C 2.4 GHz WLAN
Access Radio Module 3, including its limitations on use in any product
marketed or offered for sale. It is intended as a supplement to training and
documentation by BelAir Networks Inc. or its authorized agents.
May 30 2006 Page 3 of 14
PM-B2CC043AA-C
B2CC043AA-C Product Manual – 2.4 GHz WLAN Radio Module
Introduction
The B2CC043AA-C (hereafter referred to as “the module”) is a 2.4 GHz radio
module compatible with the IEEE 802.11 standard for Wireless LAN operation.
It is designed to be interoperable with WLAN products which are based on
Direct Sequence Spread Spectrum (DSSS) radio technology.
The module contains a complete 802.11b/g radio and Medium Access Control
(MAC) protocol engine which allows implementation of an 802.11b/g access
point (AP).
The module is not intended for stand-Clone operation. It will only be marketed
as a complete product, in conjunction with a package, DC power supply and
antenna (hereafter referred to as “the product” or the “final product”).
Since the module has a BelAir networks proprietary digital interface, it cannot
be directly connected to any standard telecommunications or computer devices.
It can only be used with final products designed and authorized specifically for
that purpose.
May 30 2006 Page 4 of 14
PM-B2CC043AA-C
B2CC043AA-C Product Manual – 2.4 GHz WLAN Radio Module
Conditions of Use
General Conditions of Use
This manual is intended to supplement training provided by BelAir Networks or
authorized parties. The module B2CC043AA-C is only intended for use in
BelAir Networks products and is not for sale to the general public as a standClone module.
Please read this entire document, including the Regulatory Statements section
before attempting to install or operate the module.
Warning: Any use of B2CC043AA-C in any manner which is not
expressly specified within this manual or specifically approved by BelAir
Networks or its authorized agents will void the user’s right to operate this
module, and is expressly forbidden by BelAir Networks. This includes any
modification of the module, installation of the module in a configuration or used
with an antenna which is not expressly listed in this document or approved by
BelAir Networks.
List of Approved Final Products
The B2CC043AA-C module is only approved for use in the following BelAir
Networks products:
• BelAir200. See BelAir200 documentation for complete manufacturing
instructions.
• BelAir100. See BelAir100 documentation for complete manufacturing
instructions.
• BelAir50c. See BelAir50c documentation for complete manufacturing
instructions.
Operation of the module within the products expressly listed above is required
to ensure compliance to all FCC and Industry Canada regulations. Any
modification of the module, or its use in any configuration not expressly listed
above may void the user’s right to operate this module.
May 30 2006 Page 5 of 14
PM-B2CC043AA-C
