SmartMonitor™ Series

Plug & Connector Selection Guide

Face View

NEMA

Configuration

Electrical Ratings Perma-Link® Perma-Grip® Perma-Tite® 2

Amps Volts Plugs Connectors Plugs Connectors Plugs Connectors

Straight Blade, 2-pole, 3-wire Grounding Devices

5-15 15 125 1510-PML 1610-CML 1510-PMGL 1610-CMGL 1510-PW6PL 1610-CW6PL
5-20 20 125 1512-PML 1612-CML 1512-PMGL 1612-CMGL 1512-PW6PL 1612-CW6PL

Locking, 2-pole, 3-wire Grounding

L5-20 20 125 2310-PML 2410-CML 2310-PMGL 2410-CMGL 2310PW6PL 2410-CW6PL

Cord Clamp Style Cord Grip Style

Wa ter Tight Style

Perma-Tite2™ All Weather
Cord Grip Nut Style features:

·All weather - NEMA 6P rated

· Nickel plated solid brass blades

·Sealing cord grip nut design

·Connector includes cover

·360˚ indication

Perma-Grip™ Cord Grip
Nut Style Features:

·Nickel plated solid brass blades

·Sealing cord grip nut design

P

erma-Link™ C

ord

Clamp Style Features:

·Internal cord seal

·Dual screw self-centering clamp

·Rubberized outer body

WIRING DEVICES

Blue No Error Condition

• Ready For Use

Power Tool Cord Compatible

•Verifies Power and Safety Ground

•Immediate Visual Indication of Error Condition

•Visual Indication of Acceptable Power Source

Wide variety of grommets for multiple cord diameters.
