ERICO CSBEZU User Manual

INSTRUCTION SHEET

CSBEZU

Easy Universal Sway Brace or Restraint Device Sway Brace Fitting

*(XX) = Finish Specifier.

Sway Brace assemblies are intended to be installed in accordance with NFPA®-13 and the manufacturer's installation instructions.

The required type, number, and size of fasteners used for the structure attachment fitting shall be in accordance with NFPA-13.

Longitudinal

Lateral

Installation Angle from Vertical

* All Brace and

Service Pipes

shown, not

included

WARNING:

ERICO products shall be installed and used only as indicated in ERICO product instruction sheets and training materials. Instruction sheets are available at

1.

www.erico.com

ERICO products must never be used for a purpose other than the purpose for which they were designed or in a manner that exceeds specified load ratings.

2. All instructions must be

3. Improper installation, misuse, misapplication or other failure to completely follow ERICO's instructions and warnings may cause product malfunction, property

4. damage, serious bodily injury and death. Products that are manufactured using spring steel components shall be used only in a non-corrosive indoor environment.

5. All pipe supports, hangers, intermediate components and structural attachments must ONLY be used as described herein and are NEVER to be used for any

6. other purpose.

NOTE: All load ratings are for static conditions and do not account for dynamic loading such as wind, water or seismic loads, unless otherwise noted.

The customer is responsible for: a. Conformance to all governing codes. b. The integrity of structures to which the products are attached, including their capability of safely accepting the loads imposed, as evaluated by a qualified engineer. c. Using appropriate industry standard hardware as noted above.

SAFETY INSTRUCTIONS: All governing codes and regulations and those required by the job site must be observed. Always use appropriate safety equipment such as eye protection, hard hat, and gloves as appropriate to the application.

Dyna-Flow is a registered trademark of Allied Tube and Conduit Corporation. EZ FLOW is a trademark of Northwest Pipe Company. FM is a registered certification mark of FM Approvals LLC, LTD. NFPA is a registered trademark of National Fire Protection Association, Inc. UL is a registered trademark of UL LLC.

CADDY, CADWELD, CRITEC, ERICO, ERIFLEX, ERITECH, and LENTON are registered trademarks of ERICO International Corporation.

TECHNICAL SUPPORT:

www.erico.com

and from your ERICO customer service representative.

completely

followed to ensure proper and safe installation and performance.

CFS386_H

1 OF 17

INSTRUCTION SHEET

CSBEZU

Easy Universal Sway Brace or Restraint Device Sway Brace Fitting

UL® Loads (Listed for Restraints) - Lateral**

Part Number

CSBEZU0200XX

CSBEZU0250XX

CSBEZU0300XX

CSBEZU0400XX

Part Number

CSBEZU0100(XX)

CSBEZU0125(XX)

CSBEZU0150(XX)

Dyna-Flow® Service Pipe

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

EZ FLOW™

Service Pipe

Dyna-Flow® Service Pipe

N/A

655 lb (2,914 N) 655 lb (2,914 N) 655 lb (2,914 N)

UL Loads (Listed for Sway Braces)

Lateral*

Sch 10

Service Pipe

N/A

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

Sch 10 Service Pipe Sch 40 Service Pipe

655 lb (2,914 N) 655 lb (2,914 N)

Longitudinal**

Sch 40

Service Pipe

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

Dyna-Flow® Service Pipe

N/A N/A N/A N/A

1,265 lb

(5,627 N)

1,265 lb

(5,627 N)

1,265 lb

(5,627 N)

Mega-Flow

Service Pipe

N/A

Sch 10

Service Pipe

1,265 lb

(5,627 N)

1,265 lb

(5,627 N)

1,265 lb

(5,627 N)

Sch 40

Service Pipe

1,265 lb

(5,627 N)

1,265 lb

(5,627 N)

1,265 lb

(5,627 N)

CSBEZU0500XX

CSBEZU0600XX

1. UL Listed for use with Lightwall Service Pipe, Schedule 10, and Schedule 40 Service Pipe, for use with 1 to 2 NPS Schedule 40 brace pipe or 1/4" angle iron. *2. 2015 lbs. (8963 N) load rating when used with 1/4" angle iron. **3. Rating with 1/4" angle iron is identical to Schedule 40 brace pipe.

N/A

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

3,000 lb

(13,345 N)

N/A

1,600 lb

(7,117 N)

1,600 lb

(7,117 N)

1,600 lb

(7,117 N)

1,600 lb

(7,117 N)

1,600 lb

(7,117 N)

1,600 lb

(7,117 N)

CADDY, CADWELD, CRITEC, ERICO, ERIFLEX, ERITECH, and LENTON are registered trademarks of ERICO International Corporation.

TECHNICAL SUPPORT:

www.erico.com

CFS386_H

2 OF 17

INSTRUCTION SHEET

CSBEZU

Easy Universal Sway Brace or Restraint Device Sway Brace Fitting

Notes: A) FM approved when used with 1", 1-1/4", 1-1/2" or 2" (DN25, DN32, DN40, DN50) NPS Schedule 40, GBT/T 3091, EN 10255 (Heavy), AS 1074 (Heavy) or JIS G3454 brace pipe. B) Load ratings for Schedule 40 above may also be applied to AS 1074 (Heavy), GB/T 3091, EN 10255 (Heavy), and JIS G3454 pipe. C) Load ratings for Schedule 10 above may also be applied to AS 1074 (Medium), GB/T 3091, EN 10255 (Medium or Heavy), JIS G3452, FM approved thinwall, and Schedule 40 unless otherwise indicated. D) Load ratings for LW above refers to FM approved lightwall pipe, commonly referred to as "Schedule 7". These ratings may also be applied to AS 1074 Lightwall, EN 10255 L, EN 10220, and GB/T 8163 pipe unless otherwise specified. E) Load ratings for "0.188 wall" above may be applied to any thicker walled pipe unless otherwise specified.

CADDY, CADWELD, CRITEC, ERICO, ERIFLEX, ERITECH, and LENTON are registered trademarks of ERICO International Corporation.

TECHNICAL SUPPORT:

www.erico.com

CFS386_H

3 OF 17

INSTRUCTION SHEET

CSBEZU

Easy Universal Sway Brace or Restraint Device Sway Brace Fitting

#1

#2

Rotate slotted stamped component over bolts. (Hardware does not have to be removed) *Slot should face away from brace pipe.

#3 #4

Tighten bolt that passes through CSBUNIV (brace clamp) to proper torque (reference torque chart) first, then proceed with other bolt.

*(XX) Finish Specifier

Finger tighten nuts and rotate assembly to desired orientation.

Insert brace into clamp as far as possible. Tighten shear head set screw until head snaps off.

* All Brace and Service Pipes shown, not included

CSBEZU is a Sway Brace Fitting. It is intended to be combined with a CADDY® brand Structural Attachment Fitting and "Bracing Pipe" to form a complete bracing assembly.

Sway Braces are intended to be installed in accordance with NFPA®-13 and the manufacturer's assembly and instructions.

CADDY, CADWELD, CRITEC, ERICO, ERIFLEX, ERITECH, and LENTON are registered trademarks of ERICO International Corporation.

TECHNICAL SUPPORT:

www.erico.com

CFS386_H

4 OF 17

INSTRUCTION SHEET

CSBEZU

Easy Universal Sway Brace or Restraint Device Sway Brace Fitting

CADDY, CADWELD, CRITEC, ERICO, ERIFLEX, ERITECH, and LENTON are registered trademarks of ERICO International Corporation.

TECHNICAL SUPPORT:

www.erico.com

CFS386_H

5 OF 17

INSTRUCTION SHEET

CSBEZU

Easy Universal Sway Brace or Restraint Device Sway Brace Fitting

CADDY, CADWELD, CRITEC, ERICO, ERIFLEX, ERITECH, and LENTON are registered trademarks of ERICO International Corporation.

TECHNICAL SUPPORT:

www.erico.com

CFS386_H

6 OF 17
