Ergotron EG10011 Specifications

MX Desk Mount and

Wall Mount LCD Arms

• Accommodates mid-sized displays and all-in-one
computers weighing up to 30 lbs (13.6 kg)

• Position your display for maximum ergonomic
comfort to relieve eye, neck and back strain

• Designed with our patented Constant Force™
lift-and-pivot motion technology, displays are
easily positioned with just a light touch

• Cable management feature conceals and routes
cables under the arm, out of the way

• Free up your table or desktop to increase your
workspace

• Upgrade LCD monitors and TVs with improved
ergonomic adjustment

• Pre-assembled arm oers monitor/TV theft
deterrence

• Extends LCD up to 17 (42 cm)

• Includes 10-year warranty

AFFORDABLE ELEGANCE AND ADJUSTABILITY FOR
MIDSIZED DISPLAYS OR ALLINONE COMPUTERS

Exceptional engineering and design makes the Ergotron MX LCD Arms a great
solution for mid-sized desktop displays and all-in-one computers weighing up to
30 lbs (13,2 kg). Combining premium features with an attractive, polished aluminum
finish, MX Arms oer a slim profile, 5″ (13 cm) of height adjustment, integrated tilt,
portrait-to-landscape capability and 360° rotation—all on a convenient swivel base.

Gain ergonomic comfort and enhanced productivity with a stylish and aordable desk
or wall mount arm.

© 2019 Ergotron, Inc. www.ergotron.com All rights reserved

MX Desk Mount and

Wall Mount LCD Arms

• Portrait/landscape rotation includes position lock

• Desk mounting options: desk clamp attaches to surface edge
≤ 2.6 (66 mm) thick; grommet mount attaches through surface

holes .31–2 (8–51 mm) wide and up to 3 (80 mm) thick

• Extends/retracts LCD up to 17 (42 cm); 5 (13 cm) of lift

• Cable management feature conceals and routes cables under

the arm, out of the way

• Pans at base 180°; rotates at extension 360°; pans at monitor 180°

• Rotate screen for portrait viewing — eliminate scrolling

MOUNT TO YOUR DESK WITH EITHER A GROMMET MOUNT

OR A DESK CLAMP

DUAL MONITOR & HANDLE KIT

BLACK 97718009

MONITOR & HANDLE KIT

BLACK 97760009

Part #
(color)

Includes

Typical LCD Size ≤ 30″ ≤ 42″

LCD SIZE MAY BE EXCEEDED AS LONG AS SCREEN WEIGHT DOES NOT EXCEED MAXIMUM WEIGHT CAPACITY OF THE MOUNT.

Weight Capacity

Lift 5″ (13 cm)

Tilt 80° / +75° / -5°

Pan 360°

Rotation

VESA Most VESA-compliant monitors and HDTV displays (see website)

Shipping Weight 9 lbs (4,2 kg) 10.25 lbs (4,65 kg)

Shipping Dimensions

Warranty 10 years

It is recommended that the
MX Wall Mount LCD Arm be installed
no higher than 60″ (152 cm)
above the floor

MX Desk Mount LCD Arm MX Wall Mount LCD Arm

45-214-026 (polished aluminum) 45-228-026 (polished aluminum)

MX Desk Mount Arm, desk clamp

and grommet mount

LCD SIZE IS APPROXIMATION. DIMENSION IS DIAGONAL MEASUREMENT OF SCREEN.

14–30 lbs (6,3–13,6 kg) Monitor depth greater than 4″ (10,2 cm) may diminish capacity.

Contact Ergotron for more information

90°

Portrait mode incompatible with

30″ displays

25.6″L x 7.3″W x 6.3″H
(65 x 18,5 x 16 cm)

MX Wall Mount Arm, vertical mount base,

VESA adaptor brackets

90°

29.25″L x 10.5″W x 6.5″H
(74,5 x 26,5 x 16 cm)

Download additional resources at ergotron.com.
For more information:
NORTH AMERICA: 800.888.8458 / +1.651.681.7600 / [e-mail]
EMEA: +31.33.45.45.600 / [e-mail]
APAC: [e-mail]
Custom: [e-mail]

© Ergotron, Inc. 03.17.2020
Literature made in the U.S.A.
Content subject to change.
Ergotron devices are not intended to cure, treat, mitigate or prevent any disease.
Patent information available at www.ergotron.com/patents.
