bosco
bookcase
1379
Thank you for purchasing this bosco bookcase. Please read the instructions carefully before use to
ensure safe and satisfactory operation of this product.
This item is HEAVY
Pre-assembly preparation
Please ensure instructions are read in full before attempting to assemble this product
Please check the pack contents before attempting to assemble this product. A full checklist of components
is given in this leaflet. If any components are missing, please contact the retailer from whom you bought
this product.
This product is HEAVY, it should b
WHEN LIFTING to avoid personal injury and (or) damage to the product.
This product takes approximately 20 MIN UTES to assemble with 2 PEOPLE.
The fittings pack contains SMALL ITEMS which should be KEPT AWAY FROM YOUNG
CHILDREN.
Necessary Tools
e assembled as near as possible to the point of use. TAKE CARE
Ref: 1819/1379
Wall fixing instructions
Thank you for purchasing this ercol product.
Please read the instructions carefully before use to ensure safe and satisfactory operation of this product.
Installation shall be carried out exactly according to the manufacturer’s instructions, otherwise a safety risk can
occur if incorrectly installed.
WARNING: In order to prevent overturning this product must be used with the wall attachment device provided.
1. Place your product in the final
position. Loosen the screws on the
metal brackets just enough so that
the slotted bracket can be extended
to meet the wall.
2. Then re-secure the screws.
3. Mark the wall for drilling through
the hole in the short face of the
bracket.
Then remove the unit from the wall
so that the marked holes can be
drilled.
Ensure you use an appropriate fixing
type for your wall (see page 3). Then
return the unit to position.
4. Secure the unit to the wall fixings
with own screws through the
brackets.
1
3 4
2
Warning
Serious or fatal crushing injuries can occur from furniture tipping over.
To prevent this furniture tipping over it must be permanently fixed to the wall.
Wall attached item only.
A guide to wall mounting and fixings
Warning
Serious or fatal crushing injuries can occur from furniture tipping over.
To prevent this furniture from tipping over it must be permanantly fixed to the wall.
Wall fixing screws are not included, since different wall materials require different types of screws / fixings.
Please ensure you use the correct screws / fixings for your type of walls and seek professional advice if you
are not sure.
Failure of the product due to incorrect fixings is the responsibility of the installer.
Important: When drilling into the walls always check that there are no hidden wires or pipes etc.
Types of walls
You can use one of the following types of wall plug if your walls are made of
brick, breezeblock, concrete, stone or wood.
1. General Purpose wall plug
Generally aerated blocks should not be used to support heavy loads, use a
specialist fitting in this case. For light loads, general - purpose wall plugs can
be used.
2. Plasterboard wall plug
For use when attaching light loads on to plasterboard partitions.
3. Cavity Fixing wall plug
For use with plasterboard partitions or hollow wooden doors.
4. Cavity Fixing - Heavy Duty wall plug
For use when fitting or supporting heavy loads such as shelving, wall
cabinets and coat racks.
5. Hammer Fixing wall plug
For use with walls stuck with plasterboard. The hammer fixing allows it to
be fixed to the wall rather than the plasterboard. Always check the fixing is
secure to the retaining wall.
6. Shield Anchor wall plug - Heavy loads
For use with heavier loads such as TV and Hi-Fi speakers and satellite dishes
etc.
Safety: Periodically check all fittings and wall fixings to ensure they
have not come loose and retighten as necessary.
If the chest is not level on your floor use the wedges provided, and snap them off so that they
do no Protrude out from the cabinet’s legs , you can also snap them lengthways if desired.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
Ercol Furniture Ltd, Summerleys Road, Princes Risborough, Buckinghamshire. HP27 9PX www.ercol.com
