Erco & Gener genloc 31e Command List

L’esprit Modem

Command List

An application example for the

GenLoc 31e

Reference : EG_GenLoc31e_988_CL_002_UK
Revision : 002

: 27/06/2006

Date

S.A. ERCO & GENER – ZI de St. Lambert-des-Levées – BP 30163 – F-49412 SAUMUR Cedex

Tél. : [phone] – Fax : [phone] – www.gener.fr – [e-mail]

SA CAPITAL 183244 € – R.C. SAUMUR B 332 174 820 – SIRET 332 174 820 00032 – NAF 322A – TVA Intra : FR 16 332 174 820

EG_GenLoc31e_988_CL_002_UK Page 2 / 22

Document History

Revision Modifications Author Date

000 CREATION MRE 18/05/2006
001 Added descriptions for all commands used in the application MRE 20/06/2006

002 Corrected chapter numbering MRE 27/06/2006

The main modifications in this document compared to its previous version, are easily identifiable on a
monitor by means of the blue text.

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

EG_GenLoc31e_988_CL_002_UK Page 3 / 22

CONTENTS

1 INTRODUCTION ...................................................................................................................................... 5

1.1 References .............................................................................................................................................. 5

2 COMMANDS ............................................................................................................................................ 6

2.1 General commands ................................................................................................................................ 6

2.1.1 ATI8 – Display application version and build information............................................................ 6

2.1.2 AT+HELP – Display list of available general commands............................................................. 6

2.1.3 AT+WGPSNMEA – GPS NMEA unsolicited................................................................................ 7

2.1.4 AT+WGPSRAW – Send raw data to the GPS module................................................................ 7

2.1.5 AT+WGPSPOS – Get position information ................................................................................. 8

2.1.6 AT+WGPSM – GPS module management.................................................................................. 9

2.1.7 AT+WIOR – Read GPIO value.................................................................................................. 10

2.1.8 AT+WIOW – Write GPIO value.................................................................................................. 10

2.1.9 AT+WGPSANT – GPS antenna configuration........................................................................... 11

2.1.10 AT+SHOWPOS – Automatic display of GPS coordinates......................................................... 12

2.1.11 AT+ERRORSTAT – Display NMEA and UBX frame status...................................................... 13

2.1.12 AT+WGPSCONF – GPS configuration...................................................................................... 13

2.2 UBX commands.................................................................................................................................... 14

2.2.1 AT+HELPUBX – Display list of UBX commands....................................................................... 14

2.2.2 AT+UBXMONVER – Display HW / SW version of the GPS module......................................... 14

2.2.3 AT+UBXMONHW – Display GPS module hardware status...................................................... 14

2.2.4 AT+UBXCFGDAT – Display / Set GPS DATUM....................................................................... 15

2.2.5 AT+UBXCFGDPM – Display / Set GPS module Dynamic Platform Model............................... 15

2.2.6 AT+UBXSHOW – Display UBX frames ..................................................................................... 15

2.3 Serial Flash commands ....................................................................................................................... 18

2.3.1 AT+SFHELP – Display serial flash commands ......................................................................... 18

2.3.2 AT+SFTYPE – Display serial flash type .................................................................................... 18

2.3.3 AT+SFSR – Display status register contents ............................................................................ 19

2.3.4 AT+SFWEL – Display / modify Write Enable Latch bit.............................................................. 19

2.3.5 AT+SFBP – Display / modify Block Protection bits.................................................................... 20

2.3.6 AT+SFWRTEXT – Write ascii text string to memory................................................................. 20

2.3.7 AT+SFRD – Display the contents of the memory...................................................................... 21

2.3.8 AT+SFEB – Erase block............................................................................................................ 22

2.3.9 AT+SFECHIP – Erase chip........................................................................................................ 22

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

EG_GenLoc31e_988_CL_002_UK Page 4 / 22

DISCLAIMER OF WARRANTY

This Software is provided free of charge on an 'as is' basis. No warranty is given by ERCO&GENER in
relation to the Software concerning the uses to which it may be put by you, the user, or its merchantability,
fitness or suitability for any particular purpose or conditions; and/or that the use of the Software and all
documentation relating thereto by the Licensee will not infringe any third party copyright or other intellectual
property rights.

LIMIT OF LIABILITY

In no event shall ERCO&GENER be liable for any loss or damages whatsoever or howsoever caused arising
directly or indirectly in connection with this license, the Software, its use or otherwise except to the extent
that such liability may not be lawfully excluded. Notwithstanding the generality of the foregoing,
ERCO&GENER expressly excludes liability for indirect, special, incidental or consequential loss or damage
which may arise in respect of the Software or its use, or in respect of other equipment or property, or for loss
of profit, business, revenue, goodwill or anticipated savings.

In its continuing research into improving its products, ERCO&GENER reserves the right to modify its
products and documentation at any time.

TRADEMARKS

WAVECOM®, WISMO®, MUSE Platform® are filed or registered trademarks of Wavecom S.A. in France or
in other countries. All other company and/or product names mentioned may be filed or registered trademarks
of their respective owners.

This document is the sole and exclusive property of ERCO&GENER. Not to be distributed or divulged

without prior written agreement. Ce document est la propriété exclusive de ERCO&GENER. Il ne peut être

communiqué ou divulgué à des tiers sans son autorisation préalable.

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

EG_GenLoc31e_988_CL_002_UK Page 5 / 22

1 INTRODUCTION

This document describes AT commands specific to the GenLoc31e. For a complete list of available
Wavecom commands and their descriptions, please refer to [R1].

For a complete technical description of the GenLoc31e, please refer to [R3].

1.1 References

[R1] – AT Command Interface Guide For X51 Software (ref: WM_ASW_OAT_UGD_00016 revision 6)
[R2] – Open AT ADL User Guide for Open AT 3.03 (ref: WM_ASW_OAT_UGD_00053 revision 1)
[R3] – GenLoc31e Technical Document (EG_GenLoc31e_988_UG_xxx_UK revision 0).

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

EG_GenLoc31e_988_CL_002_UK Page 6 / 22

2 COMMANDS

2.1 General commands

2.1.1 ATI8 – Display application version and build information

This command will display the version and build information of the application.

Syntax: ATI8

Example :

Command Possible Responses Notes
ATI8

2.1.2 AT+HELP – Display list of available general commands

This command will display a list of the available general commands. The list includes certain Wavecom
commands which have been recreated by the application in order to be compatible with the GenLoc31e
hardware and the original Wavecom commands (example: AT+WGPSPOS).

Syntax: AT+HELP

Example :

Command Possible Responses
AT+HELP

GenLoc31e V0.73 Jun 19 2006 14:32:38

Display application version
and build information

OK

ATI8......................Display product software version and build information

AT+WGPSNMEA=(0-1),(0-5),..Activate display of unsolicited GPS NMEA frames

AT+WGPSPOS................Display current GPS coordinate information

AT+SHOWPOS=(0-240)........Display GPS information every n seconds. (0=disable)

AT+ERRORSTAT=(0-1)........Display frame errors and total frames received (0=NMEA,

1=UBX)

AT+WIOR=(0-3).............Display logic level at input 0-2 or motion detector (3)

AT+WIOW=0,(0-1)...........Set logic level on open-collecter output. 0=low, 1=high

AT+WIOW=1,(0-1)...........RS232 interface: 0=enabled, 1=disabled

AT+WIOW=n,(0-1)...........UART2 mode: n=7/8. 0=normal(DSR/DTR), 1=RxD/TxD diverted

to DSR/DTR

AT+WGPSM=0,(0-1)..........GPS module power: 0=off, 1=on

AT+WGPSM=1,(0-1)..........GPS module reset: 0=reset, 1=normal

AT+WGPSM=3................GPS module Software and Hardware versions

AT+WGPSRAW................Send a raw UBX data stream to the GPS module

AT+WGPSANT=(0-2)(,[mode][mon])..GPS antenna configuration

AT+HELPUBX................Display list of UBX commands

OK

Note: Display general command list

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

2.1.3 AT+WGPSNMEA – GPS NMEA unsolicited

This command allows the host to activate the GPS NMEA frames provided as unsolicited messages on GSM
main serial link as follows :

$GPGGA,092003.00,4716.80272,N,00003.51569,W,1,08,1.01,28.7,M,47.9,M,,*7F
$GPGSA,A,3,20,11,23,17,24,01,04,13,,,,,2.05,1.01,1.79*0E
$GPGSV,3,1,09,20,75,044,48,11,39,138,47,23,61,168,49,17,47,261,50*7C
$GPGSV,3,2,09,24,54,302,45,01,25,045,47,33,34,201,44,04,22,303,43*75
$GPGSV,3,3,09,13,31,196,51*4A
$GPGLL,4716.80272,N,00003.51569,W,092003.00,A,A*75
$GPRMC,092004.00,A,4716.80273,N,00003.51572,W,0.004,,080606,,,A*6C
$GPVTG,,T,,M,0.004,N,0.008,K,A*2F

Syntax: AT+WGPSNMEA=<mode >[, <NMEA1>,<NMEA2>…]

EG_GenLoc31e_988_CL_002_UK Page 7 / 22

<mode>

0 Deactivate NMEA unsolicited mode (default).
1 Activate NMEA unsolicited mode

<NMEAx>: selected NMEA frame list chosen from the following list :

0 GGA GPS fix data (default)
1 GSA GPS DOP and Active satellites
2 GSV GPS satellites in view
3 RMC Recommended minimum data
4 VTG Course over ground and ground speed
5 GLL Latitude and longitude, with time of position fix and status.

Note:

If the <NMEAx> parameters are omitted, the last configuration remains active. This configuration is
stored in EEPROM.

Examples :

Command Possible Responses Notes
AT+ WGPSNMEA

AT+WGPSNMEA=1,0,2,3

AT+ WGPSNMEA?

AT+ WGPSNMEA=0

AT+ WGPSNMEA=1

AT+WGPSNMEA=(0-1),(0-5),...
OK

OK
+WGPSNMEA: 1,0,2,3

OK

OK

OK

Display syntax

These three frames will be
provided as unsolicited
messages
Display current frame
selection (GGA, GSV, RMC)

Turn off the unsolicited
mode

Turn on the unsolicited
mode (previous selection is
used)

2.1.4 AT+WGPSRAW – Send raw data to the GPS module

This command will write a raw data stream to the GPS module. The data is not interpreted inside the GSM
module.

Syntax: AT+WGPSRAW=<pdu>

Examples :

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

Command Possible Responses Notes
AT+WGPSRAW

AT+WGPSRAW=”B5
6206010600F005000
10001043200010000
0331”

EG_GenLoc31e_988_CL_002_UK Page 8 / 22

AT+WGPSRAW="raw UBX data string"
OK

OK

Display syntax

Successful transmission of
data to the GPS controller (this
example enables VTG frames
to be output from the GPS
module)

<pdu> data is entered as a binary string (in hexadecimal format) enclosed by quotes. Only the
following hexadecimal characters are allowed: ‘0’ to ’9’, and ’A’ to ’F’. Each pair of characters is
converted to a byte. For example, 41 is converted to hexadecimal value.

Notes:

The contents of <pdu> is the responsibility of the host user.
The length of <pdu> is limited to 512 characters corresponding to a frame of 256 hexadecimal bytes.

2.1.5 AT+WGPSPOS – Get position information

This command will to get the last position information received.

Syntax: AT+WGPSPOS

Response syntax:
+WGPSPOS:<fix>,<time>,<date>,<latitude>,<longitude>,<altitude>,<hdop>,<speed>,<course>,<nbsat>

Examples :

Command Possible Responses Notes
AT+WGPSPOS

<fix>

0 Invalid Fix
1 2D fix
2 3D fix

-1 It is not possible to define a position

<time> : hhmmss time of fix

ranges of values: hh (hour) 00 to 23
mm (minute) 00 to 59
ss (second) 00 to 59
Example: 130556 means 13:05:56 UTC

<date> : ddmmyy date of fix

ranges of values: dd (day) 01 to 31
mm (month) 01 to 12
yy (year) 2000 to 2099
Example: 191105 means 19

<latitude> : ddmm.mmmmm(N/S)

ranges of values: dd (degrees) 00 to 90
mm.mmmmm (minutes) 00,00000 to 59.99999
(N/S) North or South
Example: latitude of the fix 4716.80053N means 47° 16.80053’ North

<longitude> : dddmm.mmmm(E/W)

+WGPSPOS:2,100556.00,080606,4716.80053N,000

03.51560W,83.4,1.45,0.013,,07
OK

th

November 2005

See defined
values below

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

EG_GenLoc31e_988_CL_002_UK Page 9 / 22

ranges of values: dd (degrees) 00 to 180
mm.mmmm (minutes) 00,0000 to 59.9999
(E/W) East or West
Example: longitude of the fix 12303.51560W means 123° 3.51560’ West

<altitude> : mmmm.m altitude of fix in meters
<hdop> : mmm.mm horizontal dilution of position in meters
<speed> : ssss.s speed over ground, in kilometres per hour
<course> : dddmm.mmmm course in degrees, minutes

ranges of values: ddd (degrees) 000 to 360
mm.mmmm (minutes) 00.0000 to 59.9999

<nbsat> : nn number of satellites in view
Note:

Some fields may be empty depending on the availability of the information.

2.1.6 AT+WGPSM – GPS module management

This command will :

power-up or down the GPS module,
perform specific GPS module reset,
provide the current GPS module software and hardware version.

Syntax: AT+WGPSM=<type>[,<mo de>][,<reset>]

<type>

0 GPS module power management (see <mode> below)
1 GPS module reset (see <reset> below)
3 Get GPS module software and hardware version

<mode>

0 GPS module is powered down
1 GPS module is powered up (default)
If <mode> is omitted, the current status is returned

<reset>

0 GPS module is held in reset
1 GPS module is not held in reset (default)
If <reset> is omitted, the current status is returned

Examples :

Command Possible Responses Notes
AT+WGPSM

AT+WGPSM=(0-1)(3),(0-1)
OK

AT+WGPSM=0,1

OK

AT+WGPSM=0

+WGPSM: 0,1
OK

AT+WGPSM=1,0

OK

AT+WGPSM=1,1

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

Display syntax

Power up GPS module

GPS module is currently
powered up

GPS module is held in
reset

GPS module not reset

OK

AT+WGPSM=1

AT+WGPSM=3

+WGPSM: 1,1
OK

+WGPSM: SW VERSION 5.00 Jan 09
2006 12:00:00 - HW VERSION 00040001 +
Extension: M4H1.1 Jan 09 2006 15:3
9:54

OK

EG_GenLoc31e_988_CL_002_UK Page 10 / 22

GPS module is currently
not reset

Get GPS module
software and hardware
version

Note : The AT command AT+WGPSM will not provide a GPS reset with boot mode.

2.1.7 AT+WIOR – Read GPIO value

This command will read the requested SPI GPIO pin value.

Syntax: AT+WIOR=<index>

<index>

0 Opto-coupled input 0
1 Opto-coupled input 1
2 Opto-coupled input 2

3 Motion detector (

Examples :

Command Possible Responses Notes
AT+WIOR

AT+WIOR=0

AT+WIOR=1

AT+WIOR=2

AT+WIOR=3

2.1.8 AT+WIOW – Write GPIO value

AT+WIOR=(0-3)
OK

+WIOR: 0
OK

+WIOR: 1
OK

+WIOR: 0
OK

+WIOR: 0
OK

optional)

Display syntax

Opto-coupled input 0 is
low

Opto-coupled input 1 is
high

Opto-coupled input 2 is
low

Motion detector level is
low

This command will write a value to the requested SPI GPIO pin.

Syntax: AT+WIOW=<index>,<value>

<index>

0 Open-collector output (see <value> below)
1 UART1 RS232 interface (see <state> below)
7 UART2 redirection (see <mode> below)
8 UART2 redirection (see <mode> below)

<value>

0 Output pin is reset low
1 Output pin is set high

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

EG_GenLoc31e_988_CL_002_UK Page 11 / 22

<state>

0 UART1 RS232 interface is enabled (default)
1 UART1 RS232 interface is disabled (the RxD remains active allowing the unit to

continue to receive commands)

<mode>

0 Normal (default)
1 UART 2 RxD and TxD redirected to UART1 DSR and DTR (does not require reset and

external mode)

Examples :

Command Possible Responses Notes
AT+WIOW

AT+WIOW=(0,1,7,8),(0-1)
OK

AT+WIOW=0,1

OK

AT+WIOW=1,0

OK

AT+WIOW=7,1

OK

2.1.9 AT+WGPSANT – GPS antenna configuration

Display syntax

Open-collector output is
set high

UART1 RS232 interface is
enabled

UART2 RxD/TxD
redirected to UART1
DSR/DTR

This command manages the GPS antenna configuration.

Syntax: AT+WGPSANT=<type>[,<mode>][,<mon>]

Response syntax: +WGPSANT: <type>,<mode>

: <type>,<mon>
: <type>,<status>,<presence>,<voltage>

Unsolicited response syntax: +WGPSANT: <type>,<status>,<presence>,<voltage>

<type>

0 Antenna configuration (see <mode> below)
1 Antenna monitoring management (see <mon> below)
2 Antenna status (see <status> below)

<mode>

0 0v (antenna not powered)
1 3v internal (default) (antenna powered)

<mon>

0 Monitoring is deactivated (default)
1 Monitoring is activated

<status>

0 Antenna is not powered
1 Antenna is powered
Note : In the case of a short circuit, the hardware protection disconnects the antenna,
causing an open circuit. After a 10-second delay the antenna is re-powered.

<presence>

0 No antenna connected
1 Antenna connected

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

EG_GenLoc31e_988_CL_002_UK Page 12 / 22

2 Antenna loading detection not activated

<voltage>

The antenna voltage in mV.

Examples :

Command Possible Responses Notes
AT+WGPSANT

+WGPSANT=type(,[mode][mon])

Display syntax

OK

AT+WGPSANT=0

Antenna is currently
powered

OK

AT+WGPSANT=1,1

Activate antenna
monitoring

OK

Unsolicited message

+WGPSANT: 2,1,0,3282

An open circuit has been
detected. Antenna
deconnected

Unsolicited message

+WGPSANT: 2,1,1,3116

Antenna reconnected and
present

AT+WGPSANT=2

+WGPSANT: 2,1,1,3116
OK

No open circuit detected
and antenna is connected
with voltage 3.116V

Notes : It is not necessary to perform a reset for this command to be taken into account.

The AT command AT+WGPSANT will not manage the modes EXT or Single Coax Options for the
GPS antenna configuration.

2.1.10 AT+SHOWPOS – Automatic display of GPS coordinates

This command will automatically display the GPS coordinates. The output will be as if the command
AT+WGPSPOS had been entered every n seconds, i.e.:

+WGPSPOS:2,074657.00,170506,4716.80554N,00003.51461W,78.0,0.92,0.007,,08
+WGPSPOS:2,074707.00,170506,4716.80550N,00003.51490W,77.8,0.92,0.006,,08
+WGPSPOS:2,074717.00,170506,4716.80535N,00003.51490W,77.9,0.92,0.005,,08

etc.

Syntax: AT+SHOWPOS=<n>

<n>

0 Stop automatic display of GPS information
1 to 240 (seconds) : Display GPS information every n seconds

The parameter of this command will be saved immediately to the internal flash memory.

Examples :

Command Possible Responses Notes
AT+SHOWPOS

AT+SHOWPOS=10

AT+SHOWPOS?

AT+SHOWPOS=(0-240)
OK

OK
+SHOWPOS: 10

Display syntax

Display GPS information
every 10 seconds

Display current value of
SHOWPOS

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

AT+SHOWPOS=0

EG_GenLoc31e_988_CL_002_UK Page 13 / 22

OK

OK

Stops automatic display of
GPS information

2.1.11 AT+ERRORSTAT – Display NMEA and UBX frame status

This command will display the number of received NMEA and UBX frames and the number of checksum
frame errors received by UART2 from the GPS module.

Syntax: AT+ERRORSTAT=<n>

<n>

0 NMEA frames
1 UBX frames

Examples :

Command Possible Responses Notes
AT+ERRORSTAT

AT+ERRORSTAT=0

AT+ERRORSTAT=1

AT+ERRORSTAT=(0-1) (0=NMEA, 1=UBX)
OK

NMEA error status: checksum errors
= 0 / 17877 (frames received)

OK
UBX error status: checksum errors

= 0 / 10 (frames received)
OK

Display syntax

Display status for NMEA
frames. In this case zero
errors for 17877 frames
received
Display status for UBX
frames. In this case zero
errors for 10 frames
received

2.1.12 AT+WGPSCONF – GPS configuration

The AT command AT+WGPSCONF cannot be used to modify GPS settings.

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

.

EG_GenLoc31e_988_CL_002_UK Page 14 / 22

2.2 UBX commands

2.2.1 AT+HELPUBX – Display list of UBX commands

This command will display a list of the available UBX commands that use the UBX protocol between the
Wismo and the GPS module.

Syntax: AT+HELPUBX

Example :

Command Possible Responses
AT+HELPUBX

AT+UBXMONVER..............Display hardware and software

version of the GPS module

AT+UBXMONHW...............Display status of the hardware of

the GPS module

AT+UBXCFGDAT..............Display (?) or set datum (=0-215)

AT+UBXCFGDPM............

Model (=1-7)

OK

Note: Display UBX command list

.Display (?) or set Dynamic Platform

2.2.2 AT+UBXMONVER – Display HW / SW version of the GPS module

This command will display the current hardware and firmware version of the GPS module including any
extensions.

Syntax: AT+UBXMONVER

Example :

Command Possible Responses
AT+UBXMONVER

GPS module - SW version: "5.00 Jan 09 2006 12:00:00"
GPS module - HW version: "00040001"
GPS module - Extension : "M4H1.1 Jan 09 2006 15:39:54"

OK

Note: Display current hardware and firmware version of the GPS module

2.2.3 AT+UBXMONHW – Display GPS module hardware status

This command will display the status of different aspects of the hardware the GPS module, such as Antenna,
Noise Level, Automatic Gain Control (AGC) and Real-Time-Clock.

Syntax: AT+UBXMONHW

Example :

Command Possible Responses Notes
AT+UBXMONHW

Noise Level measured by GPS Core : 159
AGC Monitor : 6123
Antenna Supervisor Status : OK

Antenna PowerStatus : ON
Real-Time Clock : Calibrated

OK

Noise level.
AGC monitor level.
Antenna supervisor
state machine status.
Antenna power status.
Internal RTC set to
received GPS time.

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

2.2.4 AT+UBXCFGDAT – Display / Set GPS DATUM

This command will display or set the GPS Datum.

Syntax: AT+UBXCFGDAT=<n>

EG_GenLoc31e_988_CL_002_UK Page 15 / 22

<n>

0 to 215 Datum identifier (Default value is 0, corresponding to WGS84)

Examples :

Command Possible Responses
AT+UBXCFGDAT

AT+UBXCFGDAT=0

AT+UBXCFGDAT?

AT+UBXCFGDAT=(0-215)
OK

OK
Current Datum: 0 - WGS84

OK

Display syntax

Set Datum to 0 (WGS84)

Display current Datum
setting. In this case 0
(WGS84)

2.2.5 AT+UBXCFGDPM – Display / Set GPS module Dynamic Platform Model

This command will display or set the Dynamic Platform Model used by the GPS module thus adjusting the
navigation engine to the expected environment. This can result in a better interpretation of the
measurements and hence more accurate position output.

Syntax: AT+UBXCFGPM=<n>

<n>

1 Stationary – Velocity is constrained to 0 m/s
2 Pedestrian – Assuming low accelerations, portable devices moved by manpower
3 Automotive – Assuming low vertical acceleration, passenger car dynamics
4 Sea – Zero vertical velocity, applications at sea
5 Airborne <1g – Dynamic range greater than car and greater vertical acceleration
6 Airborne <2g – Typical airplane environment
7 Airborne <4g – Extreme dynamic environment

Examples :

Command Possible Responses
AT+UBXCFGDPM

AT+UBXCFGDPM=3

AT+UBXCFGDPM?

AT+UBXCFGDPM=(1-7)
OK

OK
+UBXCFGDPM: 3

OK

Display syntax

Select Automotive Dynamic
Platform Model

Display current Dynamic
Platform Model setting. In
this case 3 (Automotive)

2.2.6 AT+UBXSHOW – Display UBX frames

This command will display the UBX frames exchanged between the UART2 and the GPS module.

Syntax: AT+UBXSHOW=<n>

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

EG_GenLoc31e_988_CL_002_UK Page 16 / 22

<n>

0 Turns off display of UBX frames
1 Display RX frames only
2 (Display TX frames only
3 Display RX and TX frames
n+80 Display with ascii interpretation

Examples :

Command Possible Responses
AT+UBXSHOW

AT+UBXSHOW=(0-3) + (80 for ASCII)

Display syntax

OK

AT+ UBXSHOW=1

Enable display of RX frames
only

OK

AT+ UBXSHOW=2

Enable display of TX frames
only

OK

AT+ UBXSHOW=3

Enable display of both RX
and TX frames

OK

AT+ UBXSHOW=83

AT+ UBXSHOW?

OK
+UBXSHOW=83

OK

Enable display of both RX
and TX frames and ascii
interpretation
Display current setting for
UBXSHOW. In this case RX,
TX frames and ascii
interpretation

AT+ UBXSHOW=0

Turns off display of UBX
frames

OK

Example a) - Display of RX frames only :

AT+UBXSHOW=1

OK
AT+UBXCFGDAT?

- <UBX RX> CFG_DAT:

B5 62 06 06 34 00 00 00 57 47 53 38 34 00 00 00
00 40 A6 54 58 41 88 6D 74 96 1D A4 72 40 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 E2 A5

Current Datum: 0 - WGS84

OK

- <UBX RX> ACK_ACK:

B5 62 05 01 02 00 06 06 14 3D

Example b) - Display of RX and TX frames with ascii interpretation :

AT+UBXSHOW=83

OK
AT+UBXCFGDAT?

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

EG_GenLoc31e_988_CL_002_UK Page 17 / 22

- <UBX TX> CFG_DAT:

B5 62 06 06 00 00 0C 2A µb.....*

- <UBX RX> CFG_DAT:

B5 62 06 06 34 00 00 00 57 47 53 38 34 00 00 00 µb..4...WGS84...
00 40 A6 54 58 41 88 6D 74 96 1D A4 72 40 00 00 .@¦TXAˆmt–.¤r@..

00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ................

00 00 00 00 00 00 00 00 00 00 E2 A5 ..........â¥

Current Datum: 0 - WGS84

OK

- <UBX RX> ACK_ACK:

B5 62 05 01 02 00 06 06 14 3D µb.......=

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

EG_GenLoc31e_988_CL_002_UK Page 18 / 22

2.3 Serial Flash commands

These commands provide a means of accessing the optional serial flash memory. Refer to the data sheet
for the type of flash used for detailed information.

2.3.1 AT+SFHELP – Display serial flash commands

This command will display a list of the available commands to access and manage the serial flash.

Syntax: AT+SFHELP

Example :

Command Possible Responses
AT+SFHELP

------------------------- SERIAL FLASH -------------------------

AT+SFHELP.................Display list of commands

AT+SFTYPE.................Display manufacturer, memory size and erase

block size(s)

AT+SFSR...................Display Status Register

AT+SFWRTEXT=addr,"text"...Write an ascii text to the address addr
AT+SFRD=start,length(,a)..Read length bytes from start address, (a=1:
ascii dump)

AT+SFWEL=x................Display or modify Write Enable Latch bit:

0=Disabled, 1=Enabled

AT+SFBP=x.................Display or modify Block Protection bits:

1=Protected, 0=Unprotected

AT+SFEB=x(,s).............Erase block, size (default 64Kbytes)

AT+SFECHIP................Erase entire memory

OK

Note: Display Serial Flash command list

2.3.2 AT+SFTYPE – Display serial flash type

This command will display the manufacturer, type, memory size and erase block size in bytes of the serial
flash (if present).

Syntax: AT+SFTYPE

Examples :

Command Possible Responses
AT+SFTYPE

------------- SERIAL FLASH ------------­Manufacturer: SST (0xBF), Type: SST25VF016B (0x2541)
Size: 2097152 Bytes
Erase Blocks: 64KB 32KB 4KB

Display
information
about
detected
serial flash

OK

AT+SFTYPE

No Serial Flash detected
OK

No serial
flash is
present

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

2.3.3 AT+SFSR – Display status register contents

This command will display the contents of the status register in the serial flash. Displayed value is in
hexadecimal format.

Syntax: AT+SFSR

Example :

Command Possible Responses Notes
AT+SFSR

2.3.4 AT+SFWEL – Display / modify Write Enable Latch bit

This command will display or modify the Write Latch Enable (WEL) bit in the status register. Note that the
WEL bit must be set (enabled) and the appropriate BP bit(s) must be cleared (unprote cted) before attempting
to modify the memory.
The WEL bit will be cleared to 0 (disabled) after a write to the status register, the block protection bits or the
memory.

Syntax: AT+SFWEL=<n>

+SFSR: 0x1C
OK

EG_GenLoc31e_988_CL_002_UK Page 19 / 22

Status register contains
0x1C

<n>

0 Disabled
1 Enabled

Examples :

Command Possible Responses Notes
AT+SFWEL

AT+SFWEL=0

AT+SFWEL=1

AT+SFWEL?

AT+SFWEL=x (0=Disabled, 1=Enabled)
OK

OK

OK
+SFWEL: 1

OK

Display syntax

Set WEL bit to 0

Set WEL bit to 1

Display current value of
WEL bit. In this case 1

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

2.3.5 AT+SFBP – Display / modify Block Protection bits

This command will display or modify the block protection bits in the status register. Note that the WEL bit
must be set (enabled) before attempting to modify the BP bit(s). Also, the WEL bit must be set (enabled) and
the appropriate BP bit(s) must be cleared (unprotected) before attempting to modify the memory.

Syntax: AT+SFBP=<n>

EG_GenLoc31e_988_CL_002_UK Page 20 / 22

<n>

0 Unprotected
1 Protected

Examples :

Command Possible Responses Notes
AT+ SFBP

AT+SFBP=1

AT+SFBP=0

AT+SFBP?

AT+SFBP=x (0=Unprotected, 1=Protected)
OK

OK

OK
+SFBP: 0

OK

Display syntax

Set all BP bits to 1

Set all BP bits to 0

Display current value of BP
bits. In this case 0

2.3.6 AT+SFWRTEXT – Write ascii text string to memory

This command will write an ascii text string to the serial flash memory. Note that the WEL bit must be set
(enabled) and the appropriate BP bit(s) must be cleared (unprotected) before attempting to modify the
memory.

Syntax: AT+SFWRTEXT=<n>,“ascii text”

<n> Start address (0 to maximum memory size (decimal value)
“ascii text” ascii text string

Example :

Command Possible Responses
AT+SFWRTEXT=50,”An ascii text string”

20 bytes written to address 0x00000032

OK

Note: The ascii text string is written to the flash starting
at address 50 (0x00000032)

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

EG_GenLoc31e_988_CL_002_UK Page 21 / 22

2.3.7 AT+SFRD – Display the contents of the memory

This command will read the contents of specified address range of the serial flash memory and dump it to
the terminal.

Syntax: AT+SFRD=<s>, <n>, <a>

<s> Start address (0 to maximum memory size, decimal value)
<n> length (1 to 512, decimal value)
<a> ascii dump (default 0: none, 1: ascii dump)

Examples :

Command Possible Responses
AT+SFRD=8,100

AT+SFRD=start,length(,a) (a=1: ascii dump)

OK

Note: Display syntax

AT+SFRD=8,100

100 bytes read starting at address 0x00000008...

-- ADDR -- 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F
0x00000000 FF FF FF FF FF FF FF FF
0x00000010 FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF
0x00000020 FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF
0x00000030 FF FF 41 6E 20 61 73 63 69 69 20 74 65 78 74 20
0x00000040 73 74 72 69 6E 67 FF FF FF FF FF FF FF FF FF FF
0x00000050 FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF
0x00000060 FF FF FF FF FF FF FF FF FF FF FF FF

OK

Note: Dump the contents of address range 8 (0x08) to 100 (0x64) with no
ascii dump

AT+SFRD=8,100,1

100 bytes read starting at address 0x00000008...

-- ADDR -- 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F ---- ASCII ----­0x00000000 FF FF FF FF FF FF FF FF яяяяяяяя
0x00000010 FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF яяяяяяяяяяяяяяяя
0x00000020 FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF яяяяяяяяяяяяяяяя
0x00000030 FF FF 41 6E 20 61 73 63 69 69 20 74 65 78 74 20 яяAn ascii text
0x00000040 73 74 72 69 6E 67 FF FF FF FF FF FF FF FF FF FF stringяяяяяяяяяя
0x00000050 FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF яяяяяяяяяяяяяяяя
0x00000060 FF FF FF FF FF FF FF FF FF FF FF FF яяяяяяяяяяяя

OK

Note: Dump the contents of address range 8 (0x08) to 100 (0x64) with ascii
dump

AT+SFRD=10000000
,100

Flash - Address is out of Range

ERROR

Note: The specified start address is greater than that supported by the
flash

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.

2.3.8 AT+SFEB – Erase block

This command will erase the specified block. Note that the WEL bit must be set (enabled) and the
appropriate BP bit(s) must be cleared (unprotected) before attempting to modify the memory.

Syntax: AT+SFEB=<n>,<s>

EG_GenLoc31e_988_CL_002_UK Page 22 / 22

<n> Block number (0 to maximum number of blocks - 1, decimal value)
<s> Block size (default 64K. Select either 1,2,4,8,16,32,64,128 kilobyte block size, decimal value)

Examples :

Command Possible Responses Notes
AT+SFEB

AT+SFEB=0

AT+SFEB=0,4

AT+SFEB=0

AT+SFEB=0

AT+SFEB=0,16
AT+SFEB=185

AT+SFEB=x(,s) (s default = 64
(KBytes))

OK
Erasing block 0 (0x10000 bytes).
Please wait...
Block 0 erased

OK
Erasing block 0 (0x1000 bytes).
Please wait...
Block 0 erased

OK
Flash - Write Latch Disabled

ERROR
Flash - Blocks protected

ERROR
ERROR

Flash - Block Number is out of Range
ERROR

Display Syntax

Block 0 of size 64Kbytes has
been successfully erased

Block 0 of size 4Kbytes has
been successfully erased

The WEL bit has not been
set. Unable to erase block

The appropriate BP bit has
not been cleared. Unable to
erase block
The specified block size is
not supported by the flash
The specified block number
is greater than that
supported by the flash

2.3.9 AT+SFECHIP – Erase chip

This command will erase the entire contents of the serial flash memory. Note that the WEL bit must be set
(enabled) and all the BP bits must be cleared (unprotected) before attempting to modify the memory.

Syntax: AT+SFECHIP

Examples :

Command Possible Responses Notes
AT+SFECHIP

AT+SFECHIP

AT+SFECHIP

Erasing device memory. Please wait...
Memory erased

OK
Flash - Write Latch Disabled

ERROR
Flash - Blocks protected

ERROR

The entire flash memory has
been successfully erased

The WEL bit has not been
set. Unable to erase chip

The BP bits have not been
cleared. Unable to erase
chip

Descriptions and non-contractual illustrations in this document are given as an indication only.

ERCO&GENER reserves the right to make any modifications.
