Page 1
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
ERB239MSW
Original Instructions
Patent Pending 1008829.2
Read instructions fully before operating this tool
(SKU NO 61027 - J1Y-KZ12-255J)
Page 2
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
Page 3
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
Congratulations on your purchase of a quality power tool from Erbauer Ltd.
This product should give you reliable service for your peace of mind this power
tool does carry a 24-month guarantee, the terms of which are detailed below.
If this product develops a fault within the guarantee period contact your retailer.
Please retain this handbook in case you need to refer to safety, care or guarantee
information in the future.
GUARANTEE
This product carries an Erbauer Ltd guarantee of 24 months. If your product
develops a fault within this period, you should, in the rst instance contact your retailer. If
the fault occurs within the rst 24 months, you may return the goods for a full refund or
we will repair or replace the goods if you prefer. When repair is not practical or identical
goods are not available, alternative goods of similar specication and quality will usually be
provided but, failing this, you will be offered a partial or full refund depending on the time
period since purchase.
This guarantee specically excludes losses caused due to:
-Fair wear and tear
-Misuse or abuse
-Lack of routine maintenance
-Failure of consumable items (such as batteries)
-Accidental damage
-Cosmetic damage
-Failure to follow manufacturer’s guidelines
-Loss of use of the goods
-Repairs attempted by anyone, unless authorised by Erbauer Ltd.
This guarantee does not affect your statutory rights. This guarantee is only valid in the UK.
For further technical advice and spare parts, please contact your retailer quoting your
Erbauer model number.
Page 4
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
SAFETY INSTRUCTIONS
WARNING! When using electric tools basic safety precautions should always
be followed to reduce the risk of re, electric shock and personal injury including
the following.
Read all these instructions before attempting to operate this product and save these
instructions.
SAVE THESE INSTRUCTIONS
The term “power tool” in the warning refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1 Keep work area clear
- Cluttered areas and benches invite injuries.
2 Consider work area environment
- Do not expose tools to rain.
- Do not use tools in damp or wet locations.
- Keep work area well lit.
- Do not use tools in the presence of ammable liquids or gases.
3 Guard against electric shock
- Avoid body contact with earthed or grounded surfaces (e.g. pipes, radiators, ranges,
refrigerators).
4 Keep other persons away
- Do not let persons, especially children, not involved in the work touch the tool or the
extension cord and keep them away from the work area.
5 Store idle tools
- When not in use, tools should be stored in a dry locked-up place, out of reach of
children.
6 Do not force the tool
- It will do the job better and safer at the rate for which it was intended.
7 Use the right tool
- Do not force small tools to do the job of a heavy duty tool.
- Do not use tools for purposes not intended; for example do not use circular saws to cut
tree limbs or logs.
8 Dress properly
- Do not wear loose clothing or jewellery, they can be caught in moving parts.
- Non-skid footwear is recommended when working outdoors.
- Wear protective hair covering to contain long hair.
9 Use protective equipment
- Use safety glasses.
- Use face or dust mask if working operations create dust.
10 Connect dust extraction equipment
- If the tool is provided for the connection of dust extraction and collecting equipment,
ensure these are connected and properly used.
11 Do not abuse the cord
- Never yank the cord to disconnect it from the socket. Keep the cord away from heat, oil
and sharp edges.
Page 5
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
12 Secure work
- Where possible use clamps or a vice to hold the work. It is safer than using your hand.
13 Do not overreach
- Keep proper footing and balance at all times.
14 Maintain tools with care
- Keep cutting tools sharp and clean for better and safer performance.
- Follow instruction for lubricating and changing accessories.
- Inspect tool cords periodically and if damaged have them repaired by an service facility.
- Inspect extension cords periodically and replace if damaged.
- Keep handles dry, clean and free from oil and grease.
15 Disconnect tools
- When not in use, before servicing and when changing accessories such as blades, bits
and cutters, disconnect tools from the power supply.
16 Remove adjusting keys and wrenches
- Form the habit of checking to see that keys and adjusting wrenches are removed from
the tool before turning it on.
17 Avoid unintentional starting
- Ensure switch is in “off” position when plugging in.
18 Use outdoor extension leads
- When the tool is used outdoors, use only extension cords intended for outdoor use and
so marked.
19 Stay alert
- Watch what you are doing, use common sense and do not operate the tool when you are
tired.
20 Check damaged parts
- Before further use of tool, it should be carefully checked to determine that it will operate
properly and perform its intended function.
- Check for alignment of moving parts, binding of moving parts, breakage of parts,
mounting and any other conditions that may affect its operation.
- A guard or other part that is damaged should be properly repaired or replaced by an
authorised service centre unless otherwise indicated in this instruction manual.
- Have defective switches replaced by an authorised service centre.
- Do not use the tool if the switch does not turn it on and off.
21 Warning
- The use of any accessory or attachment other than one recommended in this instruction
manual may present a risk of personal injury.
22 Have your tool repaired by a qualied person
- This electric tool complies with the relevant safety rules. Repairs should only be
carried out by qualied persons using original spare parts, otherwise this may result in
considerable danger to the user.
Page 6
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
HEALTH ADVICE
Warning! When drilling, sanding, sawing or grinding, dust particles will be
produced. In some instances, depending on the materials you are working with,
this dust can be particularly harmful to you (e.g. lead from old gloss paint).You are advised
to consider the risks associated with the materials you are working with and to reduce the
risk of exposure.You should:
-Work in a well-ventilated area.
-Work with approved safety equipment, such as dust masks that are specially designed to
lter microscopic particles.
SAFETY INSTRUCTIONS FOR ALL SAWS
a. DANGER: Keep hands away from cutting area and the blade. Keep your second
hand on the handle, or motor housing. If both hands are holding the saw, they cannot
be cut by the blade.
b. Do not reach underneath the workpiece. The guard cannot protect you from the
blade below the workpiece.
c. Adjust the cutting depth to the thickness of the workpiece. Less than a full tooth of
the blade teeth should be visible below the workpiece.
d. Never hold piece being cut in your hands or across your leg. Secure the
workpiece to a stable platform. It is important to support the work properly to minimize
body exposure, blade binding, or loss of control.
e. Hold power tool by insulated gripping surfaces when performing an operation
where the cutting tool may contact hidden wiring or its own cord. Contact with a
“live” wire will also make exposed metal parts of the power tool “live” and shock the operator.
f. When ripping always use a rip fence or straight edge guide. This improves the
accuracy of cut and reduces the chance of blade binding.
g. Always use blades with correct size and shape (diamond versus round) of arbor
holes. Blades that do not match the mounting hardware of the saw will run eccentrically,
causing loss of control.
h. Never use damaged or incorrect blade washers or bolt. The blade washers and bolt
were specially designed for your saw, for optimum performance and safety of operation.
Further safety instructions for all saws
Causes and operator prevention of kickback:
− kickback is a sudden reaction to a pinched, bound or misaligned saw blade, causing an
uncontrolled saw to lift up and out of the workpiece toward the operator;
− when the blade is pinched or bound tightly by the kerf closing down, the blade stalls and
the motor reaction drives the unit rapidly back toward the operator;
− if the blade becomes twisted or misaligned in the cut, the teeth at the back edge of the
blade can dig into the top surface of the wood causing the blade to climb out of the kerf and
jump back toward the operator.
Kickback is the result of saw misuse and/or incorrect operating procedures or conditions and
can be avoided by taking proper precautions as given below.
Page 7
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
a. Maintain a rm grip with both hands on the saw and position your arms to resist
kickback forces. Position your body to either side of the blade, but not in line with
the blade. Kickback could cause the saw to jump backwards, but kickback forces can be
controlled by the operator, if proper precautions are taken.
b. When blade is binding, or when interrupting a cut for any reason, release the
trigger and hold the saw motionless in the material until the blade comes to a
complete stop. Never attempt to remove the saw from the work or pull the saw
backward while the blade is in motion or kickback may occur. Investigate and take
corrective actions to eliminate the cause of blade binding.
c. When restarting a saw in the workpiece, centre the saw blade in the kerf and
check that saw teeth are not engaged into the material. If saw blade is binding, it may
walk up or kickback from the workpiece as the saw is restarted.
d. Support large panels to minimise the risk of blade pinching and kickback. Large
panels tend to sag under their own weight. Supports must be placed under the panel on
both sides, near the line of cut and near the edge of the panel.
e. Do not use dull or damaged blades. Unsharpened or improperly set blades produce
narrow kerf causing excessive friction, blade binding and kickback.
f. Blade depth and bevel adjusting locking levers must be tight and secure before
making cut. If blade adjustment shifts while cutting, it may cause binding and kickback.
Page 8
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
ADDITIONAL SAFETY INSTRUCTIONS FOR YOUR MITRE SAW
Warning: Be sure to read and understand all instructions. Failure to
follow all instructions listed below may result in electric shock, re
and/or serious personal injury.
1. Know your power tool. Read operator’s manual carefully. Learn the applications and
limitations, as well as the specic potential hazards related to this tool.
2. Always wear safety glasses or eye shields when using this mitre saw. Everyday
eyeglasses have only impact-resistant lenses; they are not safety glasses.
3. Always protect your lungs. Wear a face mask or dust mask if the operation is dusty.
Always use dust extraction equipment to minimise dust.
4. Always protect your hearing. Wear hearing protection during extended periods of
operation.
5. Always inspect the tool cords periodically and if damaged have them repaired.
Always be aware of the cord location.
6. Always check for damaged parts. Before further use of the tool, a guard or
other part that is damaged should be carefully checked to determine if it will
operate properly and perform its intended function. Check for misalignment or
binding of moving parts, breakage of parts, and any other condition that may affect the
tool’s operation. A guard or other part that is damaged should be properly repaired or
replaced at a qualied service centre.
7. Do not abuse the cord. Never use the cord to carry the tools or pull the plug from
the socket. Keep cord away from heat, oil, sharp edges or moving parts. Replace
damaged cords immediately. Damaged cords increase the risk of electric shock.
8. Always make sure that your extension cord is in good condition. When using
an extension cord be sure to use one that is heavy enough to carry the current
that your tool will draw. An undersized cord will cause a drop in line voltage,
resulting in loss of power and overheating.
9. Always inspect and remove all nails from lumber before sawing.
10. Do not use the tool while tired or under the inuence of drugs, alcohol or
any medication. Following this rule will reduce the risk of electric shock, re or serious
personal injury.
11. Save these instructions. Refer to them frequently and use them to instruct
others who may use this tool. If someone borrows this tool, make sure they have these
instructions also.
12. When the correct blade to cut the material has been tted, this saw is
recommended for cutting wood and plastic only.
13. Do not use saw blades with High Speed Steel (HSS) or damaged or deformed
blades.
14. Replace the table insert when worn.
15. Use only saw blades recommended by the manufacturer and which have the
exact bore and diameter required for this machine.
16. Connect your mitre saw to a dust collecting device (I. D.Ø32mm) when sawing.
17. Select saw blades in relation to the material to be cut.
18. Check the maximum depth of cut.
19. When sawing long work pieces, always use extra support to provide better
support, and use clamps or other clamping devices.
Page 9
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
20. The operator is adequately trained in the use, adjustment and operation and
operation of the machine.
21. Provide for adequate room lighting at your workplace or for adequate lighting
of the immediate work area.
22. When tted with laser no exchange with different type of laser is permitted.
Repairs shall only be carried out by the laser manufacturer or an authorised
agent.
23. Refrain from removing any cut-offs or other parts of the workpiece from
the cutting area whilst the machine is running and the saw head is not the rest
position.
24. Never stand on this tool. Serious injuries could occur when this tool tips over
or when coming in contact with the saw blade.
25. Only use the saw with guards in good working order and properly maintained,
and in position.
26. Keep the oor area free of loose material e.g. chips and cut-offs.
27. Ensure the speed marked on the saw blade is at least equal to the speed
marked on the saw.
28. Warning. Not replace the laser with a different type. Instruction that repairs
shall only be carried out by the laser manufacturer or an authorised agent.
WARNING: the operation of any mitre saw can result in foreign objects being
thrown into your eyes, which can result in severe eye damage. Before beginning
power tool operation, always wear safety goggles or safety glasses with side shield and a full
face shield when needed.
WARNING: If any parts are missing, do not operate your mitre saw until the
missing parts are replaced. Failure to follow this rule could result in serious
personal injury.
Caution: Do not let familiarity with your mitre saw make you careless. Remember that a
careless fraction of a second is sufcient to cause severe injury.
Double insulation:
The tool is double insulated. This means that all the external metal parts are electrically
insulated from the mains power supply. This is done by placing insulation barriers between
the electrical and mechanical components making it unnecessary for the tool
to be earthed.
Important note
Be sure the supply is the same as the voltage given on the rating plate. The tool is tted
with a two-core cable and plug. Remove the mains plug from socket before carrying out
any adjustment or servicing.
SAFETY RULES FOR LASER LIGHT
The laser light/laser radiation used is Class 2 with maximum 1mW power and 650nm
wavelength.
These lasers do not normally present an optical hazard, although staring at the beam may
causeash blindness.
WARNING: Do not stare directly at the laser beam. A hazard may exist if you
deliberately stare into the beam, please observe all safety rules as follows:
Page 10
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
- The laser shall be used and maintained in accordance with the manufacturer’s
instructions.
- Never aim the beam at any person or an object other than the workpiece.
- The laser beam shall not be deliberately aimed at personnel and shall be prevented from
being directed towards the eye of a person for longer than 0.25s.
- Always ensure the laser beam is aimed at a sturdy workpiece without reective surfaces.
i.e. wood or rough coated surfaces are acceptable. Bright shiny reective sheet steel or the
like is not suitable for laser use as the reective surface could direct the beam back at the
operator.
- Do not change the laser light assembly with a different type. Repairs must be carried out
by the laser manufacturer or an authorised agent.
SPECIFIC SAFETY RULES & SYMBOLS
WARNING!
Do not operate machine if warning and / or instruction labels are missing or damaged.
Symbol Description
V Volts
A Amperes
Hz Hertz
Min
-1
Speed
~ Alternating Current
no No Load Speed
Double Insulated
Wear Safety Goggles
Wear Ear Protection
Wear Dust Mask
Read Instruction Manual
Laser Warning Symbol
Conforms to relevant
safety standards
General Warning
Page 11
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
KNOW YOUR SLIDING MITRE SAW
Fig 1
1. DUST BAG
2. UPPER BLADE GUARD
3. CUTTING HANDLE
4. LOWER BLADE GUARD
5. BLADE
6. TABLE INSERT
7. MITRE HANDLE
8. LASER GUIDE
9. BASE
10. TURNTABLE
11. LEFT EXTENSION TABLE
12. FENCE
13. HOLD-DOWN CLAMP
14. SLIDE CARRIAGE LOCK KNOB
6
1
3
12
10
14
2
4
7
8
9
11
5 13
Page 12
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
15. CARRYING HANDLE
16. SLIDE CARRIAGE
17. BEVEL LOCK HANDLE
18. RIGHT EXTENSION TABLE
19. MOTOR
20. POSITIVE STOP LOCKING LEVER
21. LOWER BLADE GUARD LOCK LEVER
22. LASER ON/OFF SWITCH
23. ADJUSTABLE CUTTING STOP
15
17
18
20
21
22
23
16
19
Fig 2
Page 13
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
TECHNICAL DATA
Volts: 230V~50Hz
Power input: 1800W
No-load speed: 4300min-1
Insulation class: II
Net weight: 18.5 kg
Blade: Ø254 mm ; Ø30 mm Bore
Turntable: Ø295 mm
Mitre stops: 0°,15°, 22.5°, 31.6°, 45° Left & Right
Mitre angle range: 0° to 45° Left & Right
Bevel angle range: 0° to 45° Left & Right
Maximum capacity:
Cross cut (0° Bevel x 0° Table) 77mm x 300mm
Mitre cut (0° Bevel x 45° Table) 77mm x 210mm
Bevel cut (45° Bevel x 0° Table) 52mm x 300mm
Compound cut (45° Bevel x 45° Table) 52mm x 210mm
NOISE AND VIBRATION DATA
Sound pressure level: 99.4 dB (A) (K=3dB(A))
Sound power level: 112.4 dB (A) (K=3dB(A))
Vibration level: 4.49m/s2 (K=2.5m/s2)
- The declared vibration total value has been measured in accordance with a standard test
method and may be used for comparing one tool with another.
- The declared vibration total value may also be used in a preliminary assessment of
exposure.
WARNING: The vibration emission during actual use of the power tool can differ from
the declared total value depending on the ways in which the tool is used; and of the need
to identify safety measures to protect the operator that are based on an estimation of
exposure in the actual conditions of use (taking account of all parts of the operating cycle
such as the times when the tool is switched off and when it is running idle in addition to the
trigger time).
ACCESSORIES
Allen Key 1 pc
Dust Bag 1 pc
Hold-Down Clamp 1 pc
Mitre Handle 1 pc
Page 14
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
VIBRATION
The European Physical Agents (Vibration) Directive has been brought in to help
reduce hand arm vibration syndrome injuries to power tool users. The directive
requires power tool manufacturers and suppliers to provide indicative vibration test
results to enable users to make informed decisions as to the period of time a power
tool can be used safely on a daily basis and the choice of tool.Further Advice can be
found at www.hse.gov.uk
Vibration total values (triax vector sum) determined according to EN 61029
Test specication; Standard = EN61029-1 2009.
Test prodcure GS mark.
Vibration emission value ah = 4.495m/s²
Uncertainty K = 2.5m/s²
The declared vibration emission value should be used as a minimum level should be used with
the current guidance on vibration.
Calculating the actual period of the actual period off use can be difcult and the HSE website
has further information.
The declared vibration emission been measured in accordance with a standardised test stated
above and may be used to compare one tool with another.
The declared vibration emission value may also be used in a preliminary assessment of exposure.
Warning: The vibration emission value during actual use of the power tool can differ
from the declared value depending on the ways in which the tool is used
dependant on the following examples and other variations on how the tool is used:-
How the tool is used and the materials being cut or drilled.
The tool being in good condition and well maintained
The use the correct accessory for the tool and ensuring it is sharp and in good condition.
And the tool is being used as intended by its design and these instructions.
This tool may cause hand-arm vibration syndrome
if its use is not adequately managed
Warning: identify safety measures to protect the operator that are based on an
estimation of exposure in the actual conditions of use (taking account of all parts
of the operating cycle such as the times when the tool is switched off and when it is
running idle in addition to the trigger time).Note The use of other tools will reduce the
users’ total working period on this tool. Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades. Maintain this tool in accordance with these instructions and keep well lubricated (where appropriate)
Avoid using tools in temperatures of 10C or less
Plan your work schedule to spread any high vibration tool use across a number of days.
Health Surveillance
All employees should be part of an employer’s health surveillance scheme to help identity
any vibration related diseases at an early stage, prevent disease progression and
help employees stay in work.
Page 15
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
ASSEMBLY INSTRUCTIONS
Warning: To avoid injury, do not
connect this mitre saw to the power
source until it is completely assembled and adjusted
and you have read and understood this Operator’s
Manual.
1. Installing the mitre handle
1) Thread the mitre handle (1) into the hole located
at the front of the mitre table. (See g. 3)
2. Unlocking the slide carriage
After removing the saw from the carton, loosen
the slide carriage lock knob (1). When transporting
or storing the mitre saw, the slide carriage should
always be locked in position. The slide carriage lock
knob (1) is located on the side of the slide carriage.
(See g. 4)
3. Raising the Cutting Head
1) Push down slightly on the switch handle (1)
and the lock lever (2).
2) Pull out the stop latch knob (3).
3) Allow the cutting head to rise to the up position.
(See g. 5)
Warning: To avoid injury and damage
to the saw, transport and store the mitre
saw with the cutting head locked in the down
position. Never use the stop latch to hold the cutting
head in a down position for cutting operations.
Locking
When transporting or storing the mitre saw, the cutting
head should always be locked in the down position.
1) Push the lock lever (2) and cutting head down to
its lowest position.
2) Push the stop latch knob (3) into the locking hole.
IMPORTANT
To avoid damage, never carry the mitre saw by the
cutting arm or the mitre handle. ALWAYS use both
designated carrying handles together.
Fig 4
Fig 5
1
1
2
3
Fig 3
1
Page 16
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
4. Installing the dust bag
1) Squeeze the metal collar wings (2) of the dust
bag (1).
2) Place the dust bag neck opening around the
exhaust port (3), and release the metal collar
wings. (See g. 6)
5. Installing the hold-down clamp
1) Loosen the lock knob (1) from the rear side of
the saw base (2). (See g. 7)
2) Place the hold-down clamp assembly (3) in one
of the mounting holes (4). (See g. 8).
3) Tighten the lock knob (1). (See g. 7)
Warning: When using stop block on
the right side, hold-down clamp must
also be in right side. Using hold-down clamp
on the left side during this operation can cause
kickback and serious injury to the operator.
Fig 6
Fig 7
Fig 8
1
3
2
4
3
2
1
4
Page 17
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
6. Mounting the mitre saw
Warning: To avoid injury from unexpected
saw movement:
• Switch off and unplug from power, and lock the
cutting head in the lower position using the stop latch.
• Lock the slide carriage in place by tightening the
slide carriage lock knob.
• To avoid back injury, lift the saw by using the
designated carrying handles located on the top of
the machine. When lifting, bend at your knees, not
from your back.
• Never carry the mitre saw by the power cord or by
the switch handle. Carrying the tool by the power
cord could cause damage to the insulation or the
wire connections resulting in electric shock or re.
• To avoid injury from ying debris, do not allow
visitors to stand near the saw during any cutting
operation.
• Support the saw on a level work surface.
• Bolt or clamp the saw to its support.
Mounting instructions
1) For stationary use, place the saw in the desired
location, directly on a workbench where there
is room for handling and proper support of
the workpiece. The base of the saw has four
mounting holes. Bolt the base of the mitre saw
(1) to the work surface (5),using the fastening
method as shown in Fig. 9.
2) For portable use, place the saw on a
20mm(approx) thick piece of plywood. Bolt the
base of the mitre saw securely to the plywood
using the mounting holes on the base. Use
G-clamps to clamp this mounting board to a stable
work surface at the worksite. (See g. 10)
Note: Mounting hardware is not included
with this tool. Bolts, nuts, washers and
screws must be purchased separately.
Fig 10
Fig 9
1) Hex headed bolt
2) Spring washer
3) Flat washer
4) Mitre saw base
5) Workbench
6) Flat washer
7) Spring washer
8) Hex nut
9) Lock nut
1
2
3
4
5
6
7
8
9
Page 18
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
7. Removing and installing the blade
Warning:
• Do not use a blade larger than 254 mm in diameter.
• To avoid injury from an accidental start, make
sure the switch is in the OFF position and the plug
is not connected to the power source socket.
• For clarity the operators hands are shown in
gs13 and 14. We recommend that the operator
considers wearing protective gloves when handling
or installing the blade.
Removing blade
1) Switch off and unplug from power socket.
2) The slide carriage should be locked in position
by tightening the slide carriage lock knob (1). (See
g. 11)
3) Allow the cutting head to rise to the upright
position. (See g. 11)
4) Release the lower blade guard by operating the
blade guard handle, and rotate the guard into its
upper position.
5) Locate the spindle lock (1). (See g. 12)
6) Hold the guard in position with your thumb and
press the spindle lock gently with a nger. (g.
13)Rotate the blade using the correct sized allen
key inserted into the arbor bolt (See g. 14) until
positive location is felt.
7) Keeping the spindle lock rmly pressed undo
the arbor bolt with the allen key by turning it in a
clockwise direction.
8) Remove the bolt and outer ange from the
machine.
9) With the arbor bolt and out ange removed,
gently ease the blade from the spindle and remove
downwards and away from the cutting head.
Note: Pay attention to the pieces removed, noting
their position and direction they face. Wipe the
blade collars clean of any sawdust before installing
a new blade.
Fig 11
Fig 12
Fig 13
Fig 14
1
1
Page 19
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
8. Installing Blade
Unplug the mitre saw before changing/installing the
blade.
Note: Ensure that the saw blade bore is exactly the
correct size for this machine and the diameter does
not exceed 254 mm.
1) Rotate and hold lower blade guard in its upper
position as already described.
2) Install a 254 mm blade with 30 mm arbor, making
sure the rotation arrow on the blade matches the
clockwise rotation arrow on the upper guard and the
blade teeth are pointing downward.
3) Place the outer blade collar against the blade and
on the arbor. Thread the arbor bolt onto the arbour in a
counterclockwise direction. (See g. 15)
IMPORTANT
Make sure the ats of the blade collars are
engaged with the ats on the arbor shaft.
4) Place the allen key into the arbor bolt.
5) Press the arbor lock, holding gently while turning
the blade counterclockwise. When arbour lock
engages, continue to press it in rmly while tightening
the arbor bolt securely (See g. 14).
Note: Do not press arbor lock when blade is moving.
Warning: Be sure that the arbor lock
is released so that the blade turns freely.
Lower the blade into the lower table and check
for any contact with the base or the mitre table by
spinning the blade manually. Make sure the collars
are clean and properly arranged. Check that the
lower blade guard is functioning correctly and does
not bind or stick.
Fig 15
Page 20
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
9. Aligning the laser beam
Warning: For your own safety,
never connect the plug to power source
socket until all the adjustment steps are complete
and you have read and understood the safety
and operational instructions. The laser beam
must always be correctly aligned with the blade
to ensure straight, even cutting. Your tool is
equipped with the Laser guide cutting guide using
a Class II laser beam. The laser beam will enable
the operator to preview the saw blade path
on the stock to be cut before starting the saw.
This laser guide is powered by the transformed
alternating current supply directly through the
power lead. The saw must be connected to the
power source and the laser on/off switch must be
turned on for the laser line to show.
(See g.16)
Warning:
AVOID DIRECT EYE CONTACT
Laser radiated when laser guide is turned on.
Avoid direct eye contact. Always unplug the
mitre saw from power source before making
any adjustments.
Laser Warning Label: Max output <1mW
Wavelength: 630-670nm EN 60825-1/
A1:2007. Laser radiation do not stare into
beam Class 2 Laser Product Puissance.
Note: All the adjustments for the operation
of this machine have been completed at the
factory. Due to normal wear and use, some
occasional readjustments may be necessary.
A. Check Laser Beam Alignment
1) Mark a 90° straight line across a board to
serve as a “pattern line” to test laser alignment.
Lay the board on the mitre table.
2) Plug saw into socket and turn on the laser
beam and line it up with the pattern line.
3) Lower saw blade to pattern line and if blade
is not ush with the pattern line, adjustment
may be necessary.
Fig 16
Laser ON/OFF Switch
Page 21
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
Three laser module mounting/adjustment screws are
provided. Two (1,2) are positioned on the LH side of
the laser housing, and one (3) on the RH side of the
laser housing. These screws gently hold the laser
module in place and on alignment by bearing on
the laser modules casing. It is important that during
any adjustment the pressure on the laser module
casing is maintained as closely as possible to the
factory setting. Do not over tighten any one screw –
damage to the laser casing could result.
(See g. 17&18)
B Adjusting the Angle of the Laser Guide
1) Loosen the single screw on the RH side of the
laser housing ½ a turn.
2)Turn the laser element in the desired direction to
adjust the laser angle.
3)Retighten the adjustment screw.
C Aligning the Laser Beam
1)Use the two adjusting screws on the LH side of
the laser housing.
2)Adjust both screws until laser alignment is
achieved.
Warning: Use only the correct sized
allen key when adjusting these screws. Turn one
screw at a time and only ¼ turn in either direction
before checking laser alignment. Maintain as far as
possible the original factory pressure setting that
these screws exert on the laser module.
Fig 18
Fig 17
1
3
2
Page 22
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
ADJUSTMENT INSTRUCTIONS
1. Bevel stop adjustment
Warning: To avoid injury from an
accidental start, make sure the switch is in
the OFF position and the plug is not connected to
the power source socket.
2. 90° (0°) Bevel adjustment
1) Loosen bevel lock handle (1) and rotate the cutting
arm completely to the right until it stops against the
vertical stop. Tighten the bevel lock handle.
2) Place a combination square (2) on the mitre table
with the ruler against the table and the heel of the
square against the saw blade.
3) If the blade is not 90° (0°) square with the mitre
table (5), loosen the bevel lock handle (1), tilt the
cutting head to the left, loosen the locknut (4) on the
bevel angle adjustment bolt (3) and use an allen key
to adjust the socket headed stop bolt (3) depth in or
out to increase or decrease the
bevel angle.
4) Tilt the cutting arm to back to the right at 90° (0°)
bevel and recheck for alignment.
5) Repeat steps 1 through 4 if further adjustment is
needed.
6) Tighten bevel lock handle (1) and locknut (4)
when alignment is achieved. (See g. 19)
Fig 19
2
5
4
3
1
Page 23
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
3. Bevel pointer adjustment
1) When the blade is exactly 90° (0°) to the table,
loosen the bevel indicator screw (1) using a #2 Phillips
screwdriver.
2) Adjust bevel indicator (2) to the “0°” mark on the
bevel scale and retighten the screw. (See g. 20)
4. Bevel adjustment 45° Right or Left
1) Loosen the bevel lock handle (1) and tilt the cutting
head completely to the left.
2) Using a combination square, check to see if the
blade angle is 45° to the table.
3) If the blade is not at 45° to the mitre table, tilt the
cutting arm to the right, loosen the locknut (2) on the
bevel angle adjustment bolt (3) and use an allen key to
adjust the stop bolt (3) depth in or out to increase or
decrease the bevel angle.
4) Tilt the cutting arm to the left to 45° bevel and
recheck for alignment.
5) Repeat steps 1 through 4 until the blade is at 45° to
the mitre table.
6) Tighten bevel lock handle (1) and locknut (2) when
alignment is achieved.
7) Repeat the above procedure but tilt the cutting head
completely to the right. (See g. 21)
5. Bevel Setting for Crown Moulding
The cutting arm can also be set at 33.90 right or left for
cutting crown mouldings.
1) Twist and deploy sprung-loaded crown moulding
pin (2).
2) Loosen the bevel lock handle (1) and rotate the
cutting head in the required direction until it indexes
with the moulding pin (2). Tighten the bevel lock. (See
g. 22)
6. Bevel adjustment 33.9
o
If necessary the 33.9° settings can be checked and
adjusted. A vernier angle gauge will be required and
this must be accurately set to 33.9°
1) Set the cutting head to 33.9° (RH) by deploying the
crown moulding pin. Check the angle of the blade
against the machine table using the vernier angle
gauge. (See g. 23)
Fig 20
Fig 21
Fig 22
1
2
1
2
3
2
3
1
2
3
4
3
Page 24
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
2) If adjustment is required loosen the locknut (3)
to the relevant socket headed stop screw. Adjust
the screw in or out until the correct bevel angle is
achieved. Retighten the locknut.
3) Repeat the above operation for the second (LH)
bevel setting. (See g. 23)
7. Mitre angle adjustment
The sliding compound mitre saw scale can be
easily read, showing mitre angles from 0° to 45° to
the left, and 0° to 45° to the right. The mitre saw
table has nine of the most common angle settings
with positive stops at 0°, 15°, 22.5°, 31.6°, and
45°. These positive stops position the blade at the
desired angle quickly and accurately. Follow the
process below for quickest and most accurate
adjustments.
1) Unlock the mitre table by turning the mitre
handle (1) counterclockwise.
2) Move the turntable while lifting up on the positive
stop locking lever (2) to align the indicator (3) to the
desired degree measurement.
3) If the desired angle is one of the nine positive
stops, release the positive stop locking lever,
making sure the lever snaps into position, and then
secure by tightening the mitre handle.
4) If the mitre angle desired is not one of the
nine positive stops, simply lock the mitre table
into position by turning the mitre handle in the
clockwise direction. (See g. 24)
8. Mitre scale indicator adjustment
1) Move the table to the 0° positive stop.
2) Loosen the screw (4) that holds the indicator
with a Phillips screwdriver.
3) Adjust the indicator (3) to the 0° mark and
retighten screw. (See g. 24)
9. Adjusting fence squareness
1) Loosen the four fence locking bolts (1).
2) Lower the cutting arm and lock in position.
3) Using a square (3), lay the heel of the square
against the blade and the ruler against the fence(2)
as shown.
4) Adjust the fence 90° to the blade and tighten the
four fence locking bolts. (See g. 25)
Fig 24
Fig 23
1
2
4
3
Page 25
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
Caution: If the saw has not been used recently,
recheck blade squareness to the fence and
readjust if needed.
5) After fence has been aligned, using a scrap piece
of wood, make a cut and check
‘squareness’ of the cut in the piece. Readjust if
necessary.
10. Setting cutting depth
The depth of cut can be preset for even and
repetitive shallow cuts.
1) Adjust the cutting head down (See CUTTING
HEAD Section) until the teeth of the blade are at the
desired depth.
2) While holding the upper arm in that position, turn
the stop knob (1) until it touches the stop plate (2).
3) Recheck the blade depth by moving the cutting
head front to back through the full motion of a
typical cut along the control arm. (See g. 26)
11. Adjusting cutting depth
The maximum depth travel of the cutting head was
set at the factory. Check to see that the blade does
not extend more than 6.35 mm below the table
insert, and does not touch the control arm throat or
any part of the base or table. If the maximum depth
needs readjusting:
1) Loosen the depth control screw locknut (3).
2) Pull the cutting head down until it indexes with the
depth control screw.
3) Adjust the depth control screw until the blade extends
6.35mm below the table insert.
4) Recheck the blade depth by moving the cutting
head front to back through the full motion of a cut
along the control arm. If the blade touches the inside
of the control arm, readjust the setting. Tighten the
locknut when the correct setting is achieved. (See
g. 26)
Fig 26
1
3
2
Fig 25
1
2
3
1
Page 26
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
OPERATION INSTRUCTIONS
Warning: Before using your mitre
saw be sure to read the instruction
manual carefully.
Operating instructions
1. Know your mitre saw.
Read and understand the Operator’s Manual and
labels afxed to the tool. Learn its application and
limitations as well as the potential hazards specic
to this tool. To avoid injury from accidental contact
with moving parts, do not lay out, assemble or set
up work on the mitre saw.
2. Electrical connection
Your mitre saw has a precision-built electric motor
and it should only be connected to a 230 V, 50Hz.
Power supply (normal household current). Do not
operate on direct current (DC). This large voltage
drop will cause a loss of power that will overheat
the motor. If your mitre saw does not operate
when plugged into an outlet, have a professional
electrician check the power supply.
Warning: Avoid accidental starting.
Make sure the switch is in the OFF
position before plugging the mitre saw into a power
socket.
3. Body and Hand position
Warning: Never place hands near the
cutting area. Proper positioning of your
body and hands when operating the mitre saw
will make cutting easier and safer. Keep children
away. Keep all visitors at a safe distance from the
mitre saw. Make sure bystanders are clear of the
saw and workpiece. Don’t force the saw. It will do
the job better and safer at its designed rate.
Starting a cut:
• Place hands at least 190.5 mm away from the blade –
out of the “no-hands zone” (1). (See g. 27)
• Clamp workpiece rmly against the fence to
prevent movement toward the blade.
• With the power switch OFF, bring the saw blade
down to the workpiece to see the cutting path of
the blade
Fig 27
No-Hands Zone
1
Page 27
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
• Squeeze trigger switch to start saw.
• Lower blade into workpiece with a rm
downward motion.
Finishing a cut:
• Hold the cutting arm in the down position.
• Release trigger switch and wait for all moving
parts to stop before moving your hands and
raising the cutting arm.
Before releasing jammed material:
• Release trigger switch.
• Wait for all moving parts to stop.
• Unplug the mitre saw.
4. Basic saw operations
Warning: For your convenience, your
saw has a blade brake. The brake is not
a safety device. Never rely on it to replace the
proper use of the guard on your saw. If the blade
doesn’t stop within approximately 8 seconds, wait
for the blade to stop, unplug the saw and contact
customer service.
To turn saw on
Push down the lock lever (1) and squeeze the
trigger switch (2) to turn the mitre saw ON.
Release the trigger switch to turn the saw OFF.
(See g. 28)
5. Sliding carriage system
1) For chop cutting operations on small
workpieces, slide the cutting head assembly
completely toward the rear of the unit and tighten
the carriage lock knob (1).
2) To cut wide boards up to 310 mm, the carriage
lock knob must be loosened to allow the cutting
head to slide freely. (See g. 29)
Before leaving the saw
• Never leave tool running unattended. Turn power
OFF. Wait for all moving parts to stop.
• Make workshop childproof. Lock the shop.
Disconnect master switches. Store tool away from
children and other unqualied users.
Fig 28
Fig 29
1
1
2
Page 28
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
Warning: To avoid injury from
materials being thrown, always unplug
the saw to avoid accidental starting, and remove
small pieces of material from the table cavity.
6. Mitre cut
1) When a mitre cut is required, unlock the
mitre table by turning the mitre handle (1)
counterclockwise.
2) While holding the mitre handle, lift up on the
positive stop locking lever (2).
3) Rotate the mitre table to the right or left with
the mitre handle.
4) When the table is in the desired position, as
shown on the mitre scale (3), release the positive
stop locking lever and tighten the mitre handle.
The table is now locked at the desired angle.
Positive stops are provided at 0°, 15°, 22.5°,
31.6° and 45°. (See g. 30)
IMPORTANT
Always tighten the mitre table lock handle before
performing every cutting operation.
7. Bevel cut
1) When a bevel cut is required, loosen the bevel
lock handle (1) by turning it clockwise.
2) Tilt the cutting head to the desired angle, as
shown on the bevel scale (2).
3) The blade can be positioned at any angle, from a
90° straight cut (0° on the scale) to a 45° right or left
bevel. Tighten the bevel lock handle (1) to lock the
cutting head in position. Positive stops are provided
at 0°, 33.9° and 45°.(See g 31)
Note: When cutting at 45 degrees, ensure guard
does not catch on work or machine base plate.
Fig 30
Fig 31
3
1
1
2
2
Page 29
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
8. Compound cut
A compound cut is the combination of a mitre and
a bevel cut simultaneously.
1) Loosen the bevel lock handle (1) and position
the cutting head at the desired bevel position. Lock
the bevel lock handle.
2) Loosen the mitre handle (2). Press down the
positive stop locking lever (3) and position the table
at the desired angle. Release the positive stop
locking lever and lock the mitre handle.
(See g. 32)
Note: When cutting a maximum RH compound
cut (mitre set at 45o and bevel set at 45o) the RH
fence extension should be removed:
1) Locate the fence securing and locking screw (1)
behind the RH side of the fence (2).
2) Loosen this locking screw until the fence
extension can be removed by sliding it to the right
and away from the machine.
To replace the fence extension reverse the above
procedure. (See g. 33)
9. Slide cutting wide boards up to 300mm wide
Warning:
To avoid injury:
• Never pull the cutting head assembly and
spinning blade toward you during the cut. The
blade may try to climb up on the top of the
workpiece, causing the cutting assembly and
spinning blade to kick back, forcefully. The cutting
head assembly should be drawn back completely
then pushed forward when sawing.
• Let the blade reach full speed before cutting. This
will help reduce the risk of a thrown workpiece.
To slide cut wide boards
1) Unlock the carriage lock handle (1) and allow the
cutting head assembly to move freely.
2) Set both the desired bevel angle and/or the
mitre angle and lock into position.
3) Use a hold down clamp to secure the workpiece.
4) Grasp the switch handle (2) and pull the carriage
(3) forward until the centre of the saw blade is over
the front of the workpiece (4).
5) Engage the trigger to turn the saw on.
Fig 32
Fig 34
Fig 33
1
1
1
3
4
2
2
2
3
Page 30
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
6) When the saw reaches full speed, push the
switch handle down, slowly, cutting through the
leading edge of the workpiece.
7) Slowly move the switch handle toward the
fence, completing the cut.
8) Release the trigger and allow the blade to stop
spinning before allowing the cutting head to raise
to its upper position. (See g. 34)
10. Cutting bowed material
A bowed workpiece must be positioned against
the fence and secured with a clamping devise
before cutting as shown.
Do not position workpiece incorrectly
or try to cut the workpiece without the
support of the fence. (See g. 35) This will cause
the blade to bind and could result in personal
injury.
11. Satellite workpiece support
Incorporated into the LH side of the machine base
is a removable satellite stand. Use this stand to
help support long pieces of material. To remove
the satellite stand, press the release button on the
top, and slide the stand from the machine base.
Position where convenient to adequately support
long workpieces.
To replace, simply slide the satellite stand back
into the machine base until the release button
provides positive location. (See g. 36)
Fig 35
Fig 36
Page 31
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
12. Adjustable stop plate
A stop plate designed for use during repetitive
cutting is incorporated into the extension arm on the
RH side of the machine base. The stop plate can be
deployed in two positions, inboard and outboard.
The inboard position enables repetitive cuts of
shorter lengths by positioning the stop plate close
to the blade. The outboard position is used for the
repetitive cutting of longer lengths by positioning
the stop at its maximum distance from the blade.
To deploy the stop:
1) Slide the release lock forwards.
2) Pull the stop (1) from its stored position upwards
and to the left. The stop will deploy.
3) Slide the release lock (2) backwards to lock the
stop into position.
4) To stow away, reverse the above steps.
(See g. 37)
To deploy the stop outboard:
1) Slide the sprung-loaded lock (2) forwards.
2) Whilst holding the release lock, pull the stop (1)
from its stored position upwards and to the right.
The stop will deploy to the outboard position.
3) Slide the release lock (2) backwards to lock the
stop position.
4) To stow away, reverse the above steps. (See g. 38)
Adjusting the stop plate
Deploy the stop plate as outlined above.
1) Push the release button (1) on the front of the
machine base below the stop plate.
2) Slide the extension arm (2) from the machine
base, and release the button (1) when at the
approximate required distance.
The extension arm has a micro adjustment facility
for nal positioning.
Turn the adjustment knob (3) clockwise or counter
clockwise as required for nal exact positioning of
the stop plate. (See g. 39)
13. Extension Arm
With the stop plate in its stored position the
extension arm can be used to support long
workpieces. (See g. 39)
Fig 39
1
2
3
Fig 38
1
2
Fig 37
1
2
Page 32
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
14. Cutting base moulding
Base mouldings and many other mouldings can
be cut on a compound mitre saw. The setup of
the saw depends on moulding characteristics and
applications, as shown. Perform practice cuts on
scrap material. To achieve best results:
1) Always make sure mouldings rest rmly against
fence and table. Use hold-down or G-clamps,
whenever possible, and place tape on the area
being clamped to avoid marks.
2) Reduce splintering by taping the cut area prior to
making cut. Mark cut line directly on the tape.
3)l Splintering typically happens due to wrong blade
application and thinness of the material.
Note: Always perform a dry run cut so you can
determine if the operation being attempted is
possible before power is applied to the saw.
15. Cutting crown moulding
Your compound mitre saw is suited for the difcult
task of cutting crown moulding. To t properly, crown
moulding must be compound mitred with extreme
accuracy. The two surfaces on a piece of crown
moulding that t at against the ceiling and wall are at
angles that, when added together,
equal exactly 90°. (See g. 40,41)
Most crown moulding has a top rear angle (the
section that ts at against the ceiling) of 52° and a
bottom rear angle (the section that ts at against
the wall) of 38°.
In order to accurately cut crown moulding for
a 90° inside or outside corner, lay the moulding
with its broad back surface at on the saw table.
When setting the bevel and mitre angles for
compound mitres, remember that the settings are
interdependent – changing one changes the other,
as well. (See g. 42&43)
Fig 40
Fig 41
Fig 42
F
e
n
c
e
Mitre at 45o, bevel at 0
o
F
e
n
c
e
Mitre saw table
F
e
n
c
e
Mitre saw table
Mitre saw table
Page 33
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
Bevel/Mitre Settings
Settings for standard crown moulding lying at
on compound mitre saw table
Note: The chart below references a
compound cut for crown moulding ONLY
WHEN THE ANGLE BETWEEN THE WALLS
EQUALS 90o.
KEY BEVEL
SETTING
MITRE
SETTING
TYPE OF CUT
Inside Corner-Left side
IL 33.9
0
31.60 Right
1)Position top of moulding against fence
2)Mitre table set at Right 31.6
0
3)Left side is nished piece
Inside Corner-Right side
IR 33.9
0
31.60 Left
1)Position bottom of moulding against
fence.
2)Mitre table set LEFT 31.6
0
Outside Corner-Left side
OL 33.9
0
31.60 Left
1)Position bottom of moulding against
fence.
2)Mitre table set at Left 31.6
0
3)RIGHT side is nished piece.
Outside Corner-Right side
OR 33.9
0
31.60 Right
1)Position top of moulding against fence.
2)Mitre table set at RIGHT 31.6
0
3)RIGHT side is nished piece.
Fig 43
IL
IR
OL
OR
Inside Corner
Outside Corner
Compound Cut Crown Mouldings
Page 34
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
MAINTENANCE
Danger: To avoid injury, never put
lubricants on the blade while it
is spinning.
Warning: To avoid re or toxic
reaction, never use petrol, naphtha,
acetone, lacquer thinner or similar highly volatile
solvents to clean the mitre saw.
Warning: For your safety, this saw
is double-insulated. To avoid electrical
shock, re or injury, use only parts identical to
those identied in the parts list. Reassemble
exactly as the original assembly to avoid
electrical shock.
Replacing carbon brushes
Replace both carbon brushes when either has
less than 6 mm length of carbon remaining, or
if the spring or wire is damaged or burned. To
inspect or replace brushes, rst unplug the saw.
Then remove the black plastic cap (1) on the
side of the motor (2). Remove the cap cautiously,
because it is spring loaded. Then pull out the
brush and replace. Replace for the other side. To
reassemble reverse the procedure. The ears on
the metal end of the assembly go in the same
hole the carbon part ts into. Tighten the cap
snugly, but do not overtighten. (See g. 44)
Note: To reinstall the same brushes, rst make
sure the brushes go back in the way they
came out. This will avoid serviceable brushes
undergoing a second ‘bedding in’ process that
could reduce motor performance and increases
wear.
Lower blade guard
Do not use the saw without the lower blade
guard. The lower blade guard is attached to the
saw for your protection. Should the lower guard
become damaged, do not use the saw until the
damaged guard has been replaced. Develop a
regular check to make sure the lower guard is
working properly. Clean the lower guard of any
dust or buildup with a damp cloth.
Fig 44
1
2
Page 35
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
Warning: Do not use solvents on the
guard. They could make the plastic “cloudy”
and brittle.
Warning: When cleaning the lower
guard, unplug the saw from the power source `
to avoid unexpected startup.
Sawdust
Periodically, sawdust will accumulate under the work
table and base. This could cause difculty in the
movement of the worktable when setting up a mitre cut.
Frequently blow out or vacuum up the sawdust.
Warning: If blowing sawdust, wear
proper eye protection to keep debris from
blowing into eyes.
Lubrication
All the motor bearings in this tool are lubricated with a
sufcient amount of high grade lubricant for the life of
the unit under normal operating conditions; therefore,
no further bearing lubrication is required. Lubricate
the following as necessary: Chop pivot: Apply light
machine oil. Central pivot of plastic guard: Use light
household oil (sewing machine oil ) on metal-to-metal
or metal-to-plastic guard contact areas as required
for smooth, quiet operation. Avoid excessive oil, to
which sawdust will cling. Guard arm: (which actuates
the lower guard movement) may be oiled at the rear
pivot, greased at ball bearing contact, and oiled
where the guard arm actuates the acetyl roller of the
lower guard, if the down chop motion is hard.
Page 36
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
ENVIRONMENTAL PROTECTION
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist. Check
with your Local Authority or retailer for
recycling advice.
UK PLUG REPLACEMENT
The fuse in the main plug of your power tool should
always be replaced with one of identical rating.
Check the voltage given on your power tool matches
the supply voltage.
The power tool is supplied with a tted plug, however
if you should need to t a new plug follows the
instruction below.
IMPORTANT
The wire in the mains lead are coloured in accordance
with the following code:
Blue ---Neutral
Brown ---Live
The wire that is coloured blue must be connected to
the terminal that is marked with the letter N. The wire
that is coloured brown must be connected to the
terminal that is marked with the letter L. A 13AMP
(BS1363 or BS1363/A) plug must be used and a
13 AMP fuse must be tted.
ENVIRONMENTAL PROTECTION
Waste electrical products should not be
disposed of with household waste.
Please recycle where facilities exist.
Check with your Local Authority or
retailer for recycling advice.
PLUG REPLACEMENT
The fuse in the main plug of your power tool
should always be replaced with one of
identical rating.
Check the voltage given on your power tool
matches the supply voltage.
The power tool is supplied with a fi tted plug,
however if you should need to fi t a new plug
follows the instruction below.
IMPORTANT
The wire in the mains lead are coloured in
accordance with the following code:
Blue ---Neutral
Brown ---Live
The wire that is coloured blue must be
connected to the terminal that is marked with
the letter N. The wire that is coloured brown
must be connected to the terminal that is
marked with the letter L. A 13AMP (BS1363
or BS1363/A) plug must be used and a 5 AMP
fuse must be fi tted.
A 13AMP (BS1363 or BS1363/A) plug must be
used and a 5 AMP fuse must be fi tted.
5 AMP
FUSE
BROWN
L (LIVE)
CABLE GRIP
OUTER
SLEEVE
BLUE
N (NEUTRAL)
13 AMP
Page 37
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
Declaration of Conformity
We, Importer
Erbauer (UK) Ltd.
BA22 8RT
Declare that the product:
Complies with the essential health and safety
requirements of the following directives:
2004/108/EC – EMC Directive
2006/95/EC – Low Voltage Directive
2006/42/EC – Machinery Directive
2002/95/EC – Restrictions of the Use of Certain Hazardous
Substances in electrical and electronic equipment
2002/96/EC and 2003/108/EC Waste Electrical and Electronic Equipment (WEEE)
Standards and technical specications referred to:
EN55014-1:2006
EN55014-2/A2:2008
EN61000-3-2:2006
EN61000-3-11:2000
EN61029-1:2009
EN61029-2-9:2002
EN60825-1:2007
Authorised Signatory
Date: 25/06/2010
Signature:
$ECLARATIONOF#ONFORMITY
7E)MPORTER
3CREWlX$IRECT,TD
-EAD!VENUE
(OUNDSTONE"USINESS0ARK
9EOVIL
"!24
$ECLARETHATTHEPRODUCT
-)42%3!7
3&
#OMPLIESWITHTHEESSENTIALHEALTHANDSAFETYREQUIREMENTSOFTHEFOLLOWINGDIRECTIVES
%%#%%#n%-#$IRECTIVE
%%#%%#n,OW6OLTAGE$IRECTIVE
%#n-ACHINERY$IRECTIVE
3TANDARDSANDTECHNICALSPECIlCATIONSREFERREDTO
%.!!
%.
%.!!
%.!
%.
%.
Name: Peter Harries
Erbauer (UK) Ltd
Quality Manager
Page 38
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
Page 39
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
Page 40
ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
