Erbauer ERB049DRH User Manual

1100W BREAKER

ERB049DRH

WARRANTY

YEARS

PDH150B-M-070927.indd 1 2007-9-27 11:19:49

PDH150B-M-070927.indd 2 2007-9-27 11:19:49

1100W BREAKER

GUARANTEE

This

product carries a guarantee of 24 months. If your product develops a
fault within this period, you should in the first instance contact the retailer where the
item was purchased.

This guarantee specifically excludes losses caused due to:

- Fair wear and tear

- Misuse or abuse

- Lack of routine maintenance

- Failure of consumable items (such as batteries)

- Accidental damage

- Cosmetic damage

- Failure to follow manufacturer’s guidelines

- Loss of use of the goods

This guarantee does not affect your statutory rights. This guarantee is only valid in the UK.

For further technical advice, spare parts or repair service (outside of guarantee) please
contact the customer helpline number on 0845 607 6380

Congratulations on your purchase of a quality power tool from Erbauer (UK)
Ltd. This product should give you reliable service but for your peace of mind
this

power tool does carries a 24-month guarantee, the terms of

which are detailed below.

If this product develops a fault within the guarantee period contact your
retailer.

Please retain this handbook in case you need to refer to safety, care or guarantee
information in the future.

PDH150B-M-070927.indd 3 2007-9-27 11:19:49

SAFETY INSTRUCTIONS

Warning! Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric shock, fire and/or serious

injury.

Save all warnings and instructions for future reference.

The term “power tool” in the warnings refers to your mains-operated (corded) power
tool or battery-operated (cordless) power tool.

1. Work area safety

a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the

presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.

c. Keep children and bystanders away while operating a power tool.

Distractions can cause you to lose control.

2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any

way. Do not use any adapter plugs with earthed (grounded) power tools.

Unmodified plugs and matching outlets will reduce risk of electric shock.

b. Avoid body contact with earthed or grounded surfaces, such as pipes,

radiators, ranges and refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.

c. Do not expose power tools to rain or wet conditions. Water entering a

power tool will increase the risk of electric shock.

d. Do not abuse the cord. Never use the cord for carrying, pulling or

unplugging the power tool. Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the risk of electric shock.

e. When operating a power tool outdoors, use an extension cord suitable

for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric

shock.

f. If operating a power tool in a damp location is unavoidable, use a

residual current device (RCD) protected supply. Use of an RCD reduces the
risk of electric shock.

3. Personal safety
a. Stay alert, watch what you are doing and use common sense when

operating a power tool. Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication. A moment of inattention

while operating power tools may result in serious personal injury.

b. Use personal protective equipment. Always wear eye protection.

Protective equipment such as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions will reduce personal injuries.

c. Prevent unintentional starting. Ensure the switch is in the off-position

before connecting to power source and/or battery pack, picking up
or carrying the tool. Carrying power tools with your finger on the switch or

energising power tools that have the switch on invites accidents.

d. Remove any adjusting key or wrench before turning the power tool on.

PDH150B-M-070927.indd 4 2007-9-27 11:19:49

1100W BREAKER

A wrench or a key left attached to a rotating part of the power tool may result in
personal injury.

e. Do not overreach. Keep proper footing and balance at all times. This

enables better control of the power tool in unexpected situations.

f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair,

clothing and gloves away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.

g. If devices are provided for the connection of dust extraction and

collection facilities, ensure these are connected and properly used. Use
of dust collection can reduce dust-related hazards.

4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your

application. The correct power tool will do the job better and safer at the rate for

which it was designed.

b. Do not use the power tool if the switch does not turn it on and off. Any

power tool that cannot be controlled with the switch is dangerous and must be
repaired.

c. Disconnect the plug from the power source and/or the battery pack from

the power tool before making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures reduce the risk of starting

the power tool accidentally.

d. Store idle power tools out of the reach of children and do not allow

persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.

e. Maintain power tools. Check for misalignment or binding of moving

parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained power tools.

f. Keep cutting tools sharp and clean. Properly maintained cutting tools with

sharp cutting edges are less likely to bind and are easier to control.

g. Use the power tool, accessories and tool bits etc. in accordance with

these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from those

intended could result in a hazardous situation.

5. Service
a. Have your power tool serviced by a qualified repair person using only

identical replacement parts. This will ensure that the safety of the power tool is

maintained.

PDH150B-M-070927.indd 5 2007-9-27 11:19:50

HEALTH ADVICE

Warning! When drilling, sanding, sawing or grinding, dust particles will be

produced. In some instances, depending on the materials you are working with,
this dust can be particularly harmful to you (e.g. lead from old gloss paint).
You are advised to consider the risks associated with the materials you are working
with and to reduce the risk of exposure. You should:

- Work in a well-ventilated area.

- Work with approved safety equipment, such as those dust masks that are specially
designed to filter microscopic particles.

ADDITIONAL SAFETY RULES FOR YOUR BREAKER

1. Always wear ear protectors. Exposure to noise can cause hearing loss.

2. Always use auxiliary handles supplied with the tool. Loss of control can cause per

-

sonal injury.

3. Safety boots are recommended at all times.

4. Proper safety gloves are also recommended.

5. Always wear a dust mask.

6. Always check walls and ceiling to avoid hidden power cables and pipes. A metal

detector can be obtained from any good DIY store for this purpose.

7. Before starting to work, always check that the chisel is properly locked in the chuck.

8. Hold the tool firmly with both hands while working and provide for secure footing.

The tool is more securely guided with both hands.

9. The screw of machine can come loose easily, and causing a breakdown or accident.

Check tightness of screw carefully before operation.

10. Do not touch the chisel or parts close to the chisel immediately after operation. They

may be extremely hot and could burn your skin.

11. In cold weather or when the tool has not been used for a long time. Let the tool

warm up for a while by operating it under no load. This will loosen up the lubrica

-

tion.

12. Some material contains chemicals which may be toxic. Take caution to prevent dust

inhalation and skin contact. Follow material supplier safety data.

Double insulation:

The tool is double insulated. This means that all the external metal parts are electrically
insulated from the mains power supply. This is done by placing insulation barriers
between the electrical and mechanical components making it unnecessary for the tool
to be earthed.

PDH150B-M-070927.indd 6 2007-9-27 11:19:50

1100W BREAKER

SYMBOLS

Read the manual Warning Wear gloves

Wear dust mask,eye & ear protection

Conforms to relevant safety standards

Important note

Be sure the supply is the same as the voltage given on the rating plate. The tool is fitted
with a two-core cable and plug.
Remove the mains plug from socket before carrying out any adjustment or servicing.

PDH150B-M-070927.indd 7 2007-9-27 11:19:50

1. LOCK SLEEVE

2. AUXILIARY HANDLE

3. GREASE BOX COVER

4. ANTI-VIBRATION MAIN HANDLE

5. ON/OFF SWITCH

6. SOFT GRIP HANDLE

7. CARBON BRUSH COVER (ON BOTH SIDES)

8. AUXILIARY HANDLE LOCKING KNOB

9. POINT CHISEL AND FLAT CHISEL

10. CARBON BRUSH

11. GREASE TANK

9

1110

1

2 3 4

5

6

7

8

PDH150B-M-070927.indd 8 2007-9-27 11:19:50

1100W BREAKER

TECHNICAL DATA

Voltage: 230V~50Hz

Power: 1100W

Impact rate: 3,800min

-1

Impact energy: 12J

Protection class:

/II

Net weight: 7.5kg

SOUND PRESSURE LEVEL& SOUND POWER LEVEL:

The guaranteed value according to 2000/14/EC is: LwA=103dB

Vibration level

ACCESSORIES

Auxiliary handle 1pc
Grease tank 1pc
Flat chisel 2pcs
Carbon brush 2pcs

Vibration total values determined according to EN60745

Chiseling

Vibration emission value ah.Cheq=16.082m/s2 (main
handle)
Vibration emission value ah.Cheq=19.283m/s

2

(auxiliary

handle)

Uncertainty K=1.831m/s

2

PDH150B-M-070927.indd 9 2007-9-27 11:19:50

1

2

2

OPERATION INSTRUCTIONS

Note: Before using the tool, read the
instruction book carefully.

1. Adjusting the auxiliary handle (See Fig

1)

For your personal safety we recommend using
the auxiliary handle at all times.
To adjust the handle, loosen the handle lock knob
anti-clockwise. Rotate the handle around the
handle collar and/or rotate the handlebar to the
desired position as shown in Fig 1. Tighten the
lock knob fully.

2. Fitting the chisel (See Fig 2)

Clean the chisel shank and apply grease before
installing the chisel. Hold the rotary grip, pull
back the lock sleeve and insert the tool into the
chisel holder. Turn the chisel and push it in until a
resistance is felt, the shaft drops completely into
the chisel holder. Once you are satisfied it has
seated, release the black lock sleeve. This should
lock the tool into position.
After installing always make sure that the tool is
securely held in the chisel holder by trying to pull
it out.
If the tool is not located, repeat the installation
operation again.

3. Remove the chisel (See Fig 2)

To remove the tool, pull back the lock sleeve, hold
and pull the tool out.

4. Operating the On / Off switch (See Fig 3)

Press the on/off switch in for operation and
release to stop.

5. Chiseling operation

Position the chisel at the desired location. Then
switch on the machine. Do not force the tool.
Light pressure will gives best result.

6. Dust collector (See Fig 4)

Use the dust collector to prevent dust from falling
over the tool or on yourself when performing
overhead operations. Attach the dust collector to
the chisel as shown in Fig 5.

Fig 2

Fig 1

Fig 4

Fig 3

PDH150B-M-070927.indd 10 2007-9-27 11:19:50

1100W BREAKER

Warning: Always wear eye protection

with this tool when performing
overhead operations.

7. Lubrication machine (See Fig 5)

The machine has a grease-packed lubrication
system. Regularly check if there is sufficient
grease. To check and add grease, remove screws
on the grease box cover using a screwdriver. If
the grease is not enough, filling grease into the
box using only the hammer grease provided
with your tool. The grease specification is general
purpose lithium based.

8. Change the carbon brushes (See Fig
6&7)

Warning! Remove the mains plug from

socket before changing the carbon brushes.

Replace the carbon brushes as follows:

a) Unscrew the brush cover.
b) Remove the carbon brushes.
c) If the carbon brush has worn down to about
6mm, it should be replaced. Always replace the
brushes in pair.
d) Insert the new brush and replace the brush
cover.

Warning: Keep the container of grease

away from children.

MAINTENANCE

1. There are no user serviceable parts in your
power tool.

2. Never use water or chemical cleaners to clean
your power tool. Wipe clean with a dry cloth.

3. Always store your power tool in a dry place.

4. Keep the motor ventilation slots clean.

5. If you see some sparks flashing in the ventilation
slots, this is normal and will not damage your
power tool.

6. If the supply cord of this power tool is damaged,
it must be replaced by a specially prepared cord
available through the service organisation.

Fig 5

Fig 6

Fig 7

PDH150B-M-070927.indd 11 2007-9-27 11:19:51

TROUBLESHOOTING

1. If your power tool does not start, check the plug
on the mains supply first.

2. If your power tool work efficiency is too low,
please add some grease in the grease box.

3. If your power tool use in low efficiency, please
check whether the tool is blunt.

4. If a fault can not be rectified return the tool to
an authorised dealer for repair.

ENVIRONMENTAL PROTECTION

Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. For further

information visit www.recycle-more.co.uk

PDH150B-M-070927.indd 12 2007-9-27 11:19:51

1100W BREAKER

PLUG REPLACEMENT

If you need to replace the fitted plug then follow
the instructions below.

IMPORTANT

The wires in the mains lead are coloured in
accordance with the following code:

Blue – Neutral
Brown – Live

As the colours of the wires in the mains lead
of this appliance may not correspond with the
coloured
markings identifying the terminals in your plug,
proceed as follows. The wire which is coloured
blue must be connected to the terminal which
is marked with N. The wire which is coloured
brown must be connected to the terminal which
is marked with L.
Warning: Never connect live or neutral wires to
the earth terminal of the plug. Only fit an approved
BS1363/A plug and the correct rated fuse.
Note: If a moulded plug is fitted and has to be
removed take great care in disposing of the
plug and severed cable, it must be destroyed to
prevent engaging into a socket.

13 AMP
FUSE

BROWN
L (LIVE)

BLUE

N (NEUTRAL)

OUTER
SLEEVE

CABLE GRIP

PDH150B-M-070927.indd 13 2007-9-27 11:19:51

Declaration of Conformity

We, Importer

Erbauer (UK) LTD BA22 8RT

Declare that the product

1100W BREAKER

ERB049DRH

Complies with the following Directives,

EC Machinery Directive 98/37/EC

EC Low Voltage Directive 2006/95/EC

EC Electromagnetic Compatibility Directive 89/336/EEC amended by 93/68/EEC

Noise Emission in the Environment by Equipment for Use Outdoors Directive

2000/14/EC amended by 2005/88/EEC

- Conformity Assessment Procedure as per Annex VI

- Measured Sound Power Level 101dB

- Declared Guaranteed Sound Power Level 103dB

- The notified body involved

Name: TUV Rheinland Luxemburg GmbH

2002/95/EC Restrictions of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment

Standards and technical specifications referred to:

EN 60745-1:2003+A1:2003

EN 60745-2-6:2003+A11:2007

EN 55014-1:2000+A1:2001+A2:2002

EN 55014-2:1997+A1:2001

EN 61000-3-2:2000+A2:2005

EN 61000-3-3:1995+A1:2001+A2:2005

EN ISO3744:1995

2007

Authorised Signatory

Date: 01/01/07

Signature:

Name: Peter Harries
Erbauer (UK) Ltd
Quality Manager

PDH150B-M-070927.indd 14 2007-9-27 11:19:52

PDH150B-M-070927.indd 15 2007-9-27 11:19:52

PDH150B-M-070927.indd 16 2007-9-27 11:19:52
