ERAE Electronics Industry 32 LCD TV none User Manual

Please observe all safety precautions
when using this product.

Please read this manual carefully
before using this product.

32 LCD TV User’s Guide

2

CONTENTS

Quick and Easy Installation
Versatility and Expandability
That doesnt make you feel fatigue on your Eyes.
Flat-Panel Digital Display easy on the Eyes.

Safety Precautions

Power Supply 4

Installation 5

Use and Maintenance 5~6

Important Safety Instructions 7~8

User Guidance Information

What is the LCD TV? 9

Name of each part 10

Controls and Functions 11

Accessories 11

Mounting on a wall 12

Installation Precautions 12

Installing an Antenna 13

Remote controller 14

Precautions 15

Connections

VCR Connections 16

Cable TV Connections 17

Camcorder/ Game Console Connections 18

DVD Connections 19

DTV Connections 20

PC Connections 21

Audio Out Connections 22

Headphone Connections 22

External Adjustment 23

Basic Use

Powering the LCD TV 24

Initial Settings 24

Watching TV 25

Selecting TV/ External Input 26

Using the Menu 26

3

CONTENTS

Basic Use

To Set Location 27

Setting Channels 28

To set or erase a channel 28

Changing Picture Settings 29

Changing Sound Settings 30

Custom Sound Adjustment 31

Sound Output 31

Selecting the Menu Language 32

Setting OSD Tone Menu Background 32

Setting Blue Background 33

Setting Digital Noise Reduction 33

Application

Changing Screen Size 34

Changing the Screen Size for WSS Signal Input 35

Manual Store 35

Sorting Program 36

Editing Program Name 37

Adjusting Unclear Screen 38

To view the still picture 38

Viewing Picture in Picture 39~40

Auto Volume Level 41

Stereo Setting 41

Resetting LCD TV Setting 42

Setting Time 43

Automatic Power On/ Off 44

Teletext 45

Maintenance and Service

Trouble shooting 46

Trouble shooting Tip 47

Supported Display Modes 47~48

4

Safety Precautions

Cautions

Warnings

Power Supply

Do not use a damaged
power cord or plug or a
loose outlet.

Doing so may result in
fire or electric shock.

Do not plug several
devices into the same
outlet.

Doing so may cause
the outlet to overheat
and start a fire.

Insert the power plug
fully into the outlet.

A loose or improperly
inserted power plug
may result in fire.

Do not touch the power
plug with wet hands.

Doing so may result in
electric shock.

Be sure to ground the unit.

Failing to do so may lead to electric shock when a short circuit or overload occurs.
If necessary, install a ground fault circuit breaker. Never ground to a telephone line,
lightning rod, or metal gas pipe. (Doing so may result in fire, electric shock, or other
hazards.)

Do not bend the power
cord excessively or place
heavy objects on it.

Doing so may result in
fire or electric shock.

Always unplug the unit
before cleaning.

Not doing so may
result in fire or electric
shock.

When disconnecting the
power cord from an AC
outlet, always grasp it by
the plug.

Pulling on the cord
can damage the
internal wire and may
result in fire.

The purpose of these precautions is to
ensure user safety and prevent property
damage.
Be sure to read and observe all safety
precautions.

5

Safety Precautions

Cautions

Warnings

Installation

Warnings

Do not place the unit where it
is exposed to rain, excessive
moisture or grease.

Doing so may result in fire,
electric shock, malfunction,
or deformation.

Do not use or store flamm
able or combustible materials
near the unit.

Doing so may result in fire
or explosion.

Do not place the unit on an
unstable surface, such as a
wobbly stand or sloped table, or
on any surface whose area is
smaller than the bottom area of
the unit.

If a child climbs on the unit, it could
topple and fall onto the child,
resulting in serious injury to the
child or damage to the unit. Place
the unit on a flat stable surface

.

Do not place containers with
liquids such as flower vases,
soft drink cans, or medicine
bottles or small metallic objects
on top of the unit.

If liquid enters the unit or any
metal object falls into the unit,
it may result in short-circuit,
fire, or electric shock.

Do not place the unit in a
poorly ventilated enclosure,
such as a cabinet.

Doing so poses a serious
risk of fire.

Do not run power cords near
heat-producing appliances
such as radiators, stoves, or
irons.

The excessive heat could
melt the insulation and
expose live wires, resulting
in fire or electric shock.

Install the antenna away from
high-voltage power lines and
communication cables and
make sure it is installed
securely.

If the antenna touches a power
line, contact with the antenna
could result in fire, electric
shock, serious injury, or death.

Do not place a burning candle,
burning anti-mosquito incense,
or lighted cigarette on top of the
unit. Do not place the unit near
any heat source such as a
fireplace or space heater.

Doing so poses a serious
risk of fire.

Install the unit at an adeq­uate distance from the
wall to ensure sufficient
ventilation.

If the temperature inside
the unit rises, it may res­ultin fire.

Do not cover the unit with
a tablecloth, curtain, or
other material.

If the temperature inside
the unit rises, it may result
in fire.

Be sure to place the unit
on a level surface.

Form a drip loop where the
coaxial antenna cable enters
your building to prevent rainwater
from traveling along the cable
and coming in contact with the
antenna input terminal.

If rainwater finds its way inside
the unit, it may result in fire or
electric shock.

The following precautions are divided into "Warnings" and "Cautions".

Warning : Ignoring this precaution may result in death or serious injury.
Caution : Ignoring this precaution may result in injury or property damage.

6

Safety Precautions

Warnings

Cautions

Use and Maintenance

Do not insert any metal
objects, such as a screwdriver,
paper clip, or bent wire into
the ventilation openings or
A/V terminals.

Doing so poses a serious
risk of fire or electric shock.

Do not allow children to
climb or hang on the unit.

The unit could topple
over onto a child and
result in serious injury.

Never disassemble or modify
the unit in any way. Do not
attempt to service the unit
yourself.

Doing so may result in fire
or electric shock. If the unit
requires repair, contact the
service center.

Disconnect the power
cord from the wall outlet
during an electrical storm.

Not doing so may result
in fire or electric shock.

When not using the unit for
long periods of time, discon­nect the power cord from
the wall outlet.

Dust could accumulate over time
on the unit and cause it to
generate heat and ignite, or
deteriorate insulation, which in
turn may result in an electrical fire.

When removing the batteries
from the remote control, make
sure children do not swallow
them. Keep the batteries out
of the reach of infants and
children.

If a child has swallowed a
battery, seek medical atten-

tion immediately.

If you notice any unusual
odors or smoke around the
unit, immediately disconnect
the unit from the outlet and
contact the service center.

Failure to do so may result
in fire or electric shock.

When moving the unit, be
sure to turn off the unit and
unplug the power cord from
the wall outlet.

Moving the unit with the
power cord connected to the
outlet may cause damage to
the cord, resulting in fire or
electric shock.

Wipe off any moisture,

dirt, or dust on the power

plug pins with a clean dry

cloth.

Failure to do so may
result in fire or electric
shock.

Always use two or more
people to lift or move the
unit.

If the unit is dropped, it
could be damaged or
otherwise cause injury.

Always turn off the unit and
unplug the power cord when
cleaning the unit. Use a soft dry
cloth to clean the unit.

Never clean with industrial
strength polish, wax, benzene,
paint thinner, air freshener,
lubricant, detergent, or other
such chemicals. Also, do not
clean with a damp cloth.

It is advisable to clean the
interior of the unit at least once
a year. Contact the store of
purchase or service center for
information.

Continuing to use the unit
without cleaning off the dust
build-up inside it may result
in fire or electric shock.

Warnings

7

Safety Precautions

Important Safety Instructions

Important safeguards for you and your new product

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with a dry cloth.

7) Do not block any of the ventilation openings. Install in accordance with the manufacturer’s
instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade or the third prong is provided for your safety. When
the provided plug does not fit into your outlet, consult an electrician for replacement of the

obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

11) Only use the attachments/accessories specified by the manufacturer.

12) Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold

with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus

has been damaged in any way, such as power supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.

¥ Apparatus shall not be exposed to dripping or splashing and no objects filled with

liquids, such as vases, shall be placed on the apparatus

Always be careful when using your LCD TV. To reduce the risk of fire, electrical shock, and
other injuries, keep these safety precautions in mind when installing, using, and maintaining
your machine.

Safety Precautions

8

Important Safety Instructions

- These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock, do not perform any servicing other than that contained in

the operating instructions unless you are qualified to do so.

- Any changes or modifications not expressly approved by the party responsible for compliance
could void the users authority to operate the equipment.

Caution :

TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR ELECTRIC SHOCK HAZARD,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

WARNING

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELE-

CTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.

This symbol indicates high voltage
is present inside. It is dangerous
to make any kind of contact with
any inside part of this product.
This symbol alerts you that
important literature conceming
operation and maintenance has
been included with this product.

This reminder is provided to call the CATV system installers attention to Article 820-40 of the
National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be connected to the grounding system of the
building, as close to the point of the cable entry as practical.

NOTE TO CABLE/TV INSTALLER :

Safety Precautions

9

What is LCD TV?

What is LCD TV?

LCD (Liquid Crystal Display) is a next generation flat-panel display module. Liquid crystal material is
contained between sheets of glass and electricity causes the liquid crystal material to reflect or block
the light emitted from a light source inside the display chassis.
By incorporating this LCD display module, LCD TVs enable you to enjoy outstanding picture quality
without the worries of space limitation and harmful radiation you may have experienced with
conventional CRT TVs.

Features

- Picture-in-Picture : Enables you to simultaneously display two different image sources.

- PC Compatible Monitor : Enables you to connect PC (D-Sub) input for displaying high-resolution SXGA (1280x1024, 60Hz)

PC images.

- HDTV-Ready Display : Enables you to view high-definition digital pictures using a DVD player or HDTV set-top receiver.

- Various Picture/Sound Controls : Enables you to set the picture and sound settings for a number of different types of

programs and viewing and listening conditions.

- Auto Power On/Off Timer : Enables you to set the TV to automatically turn ON or OFF at a preset time.

- ATM : Enables you to set the TV to search for all available standard broadcast and cable TV channels and store them

automatically.

10

User Guidance Information

Front View

Names of each part

Main Power Button

- Please turn off the main power switch, if the LCD TV will

not be used for a long period of time.

Stand by Button

Source Button

- Input Source Select Button

Menu Button

- OSD Menu Display Button

Program/Channel Button

Volume Button

11

User Guidance Information

Back View

Controls and Functions

S-Video 1

SCART (Full SCART, Half SCART)

Audio out

ANT A-Terrestrial

Audio Input (Composite 2/S-Video 2)

Composite 2

S-Video 2

Headphone

AC Input

RS-232C Terminal

Analog RGB (D-SUB)

Digital RGB (DVI-D)

Component 1

Component 2

Audio Input (Component 1, 2, PC/DVI)

Audio Input (Composite 1/S-Video 1)

Composite 1

Audio out Cable

Accessories

The configuration of the components may look different from the following illustration.

Power Cord

Antenna Cable

User’s Guide

Battery 1.5V( AAA

2)

User’s Guide

SCART Cable

(Europe+Middle East only)

Remote Control

Wall Mounting

Using the Stand

Mounting on a Wall

Installation Precautions

12

User Guidance Information

Your LCD TV can be mounted on a wall as shown in the figure above.

Please secure enough space for safe use. (Please refer to A and B.)
Installation of the LCD TV in an improperly ventilated location can cause a fire or damage to the LCD TV

due to increased temperature

.

(Using the Stand)

B

(Mounting on a wall)

A

Do not install on an unstable location with support area smaller than the LCD TV.

Contact your dealer to purchase the "Adjustable-angle wall mount" required for wall-mounted installation.

13

User Guidance Information

For a House

Installing an Antenna

Using an Outdoor Antenna

To install or use an outdoor antenna, if possible, consult a qualified technician for help.

Using an Indoor Antenna

Locate a wall jack with an F-connector, and then connect the coaxial antenna cable to the wall jack.

For an Apartment or Condo Complex

Wall Jack with

F-Connector

Coaxial (Round) Antenna Cable

Copper

Wire

Copper

Wire

Coaxial (Round) Antenna Cable

Remote Controller

1. POWER : TURNS THE TV ON AND OFF(page.24)

2. SOURCE : USE TO SELECT AN INPUT SOURCE (page.26)

3. MUTE : PRESS TO TEMPORARILY CUT OFF THE SOUND (page.25)

4. SLEEP : PRESS TO SELECT A TIME FOR THE TV TO TURN OFF

AUTOMATICALLY (page.44)

5. STILL : PRESS TO STOP THE ACTION DURING A PARTICULAR

SCENE (page.38)

6. ARC (Aspect Ratio Control) : PRESS TO CHANGE THE

SCREEN SIZE (page.34)

7. MTS (Multi-Television Sound) : PRESS TO SELECT MONO

OR STEREO MODE (page.41)

8. LAST : TUNES TO THE PREVIOUS PROGRAM (page.25)

9. PSM : PICTURE STATUS MEMORY KEY (page.29)

(CUSTOM, DYNAMIC, STANDARD, MOVIE, MILD)

10. SSM : SOUND STATUS MEMORY KEY (page.30)

(CUSTOM, STANDARD, MUSIC, MOVIE, SPEECH)

PIP CONTROL KEY (page 39, 40)

11. PIP : PIP ON/OFF

12.

P.INPUT : PIP INPUT SELECT KEY

13.

P.POSITION : PIP POSITION CONTROL KEY

14.

P.SIZE : PIP AND PBP MODE CHANGE

15.

SWAP : PIP SOURCE SWAP

16.

S.SELECT : SOUND SWAP KEY

17. AUTO (

AUTO IN PROGRESS) : PRESS TO CONTROL THE

MONITOR SCREEN AUTOMATICALLY

18. TV : TV INPUT SOURCE SELECT KEY

19. MENU : DISPLAYS THE MAIN ON-SCREEN MENU

20. DISPLAY : PRESS TO DISPLAY THE CURRENT PROGRAM

AND AUDIO/ VIDEO SETTINGS (page.25)

21. (PR+, PR-) : PROGRAM, MENU CONTROL OR PAGE UP

AND DOWN KEY, STAND BY ON

22. (VOL-, VOL+) : PRESS TO INCREASE OR DECREASE

THE VOLUME OR MENU CONTROL KEY

23. ENTER : SAVE THE VALUE

TELETEXT CONTROL KEY (page 45)

24. TTXON : TEXT ON KEY

25. MIX : MIX WITH TV SCREEN

26. STORE : STORE THE USER DEFINED FAVORITE PAGE

27. FLOF LIST : EXCHANGE FLOF/LIST MODE

28. SIZE : TELE TEXT SCREEN SIZE KEY

29. HOLD : HOLD FUNCTION DURING TELETEXT DISPLAY

30. UPDATE : DISPLAY CANCEL OR TEXT UPDATE KEY

31. INDEX : TEXT INDEX KEY

32. TIME: TIME DISPLAY

33. REVEAL :

SELECT HIDDEN CONTENT DURING TELETEXT DISPLAY

34. RED, GREEN, YELLOW, BLUE : DIRECT ACCESS TELETEXT

LINKED PAGE KEY

Functions of remote control buttons

The remote control is using Infra-Red (IR). Point it towards the front of the LCD TV. The remote control may not
work correctly if it is operated out of range or out of angle.

14

User Guidance Information

Avoiding Remote Control Problems

Instering Batteries in the Remote Controller

Precautions

How to use remote controller

2. Insert the two supplied batteries (AAA, 1.5V). Ensure
that the polarities (

+

and -) of the batteries are aligned

correctly.

1. Open the cover out completely.

3. Replay the cover.

1. Check the polarity (

+

,-) of the batteries in the remote controller.

2. Check that the batteries have power.

3. Check that the LCD TV is powered and that it is properly plugged in.

4. Check if any three-wavelength lamp, special fluorescent or neon sign is turned on near the LCD TV.

CAUTION : Risk of explosion if battery is replaced by an incorrect type.

Dispose of used batteries according to the national code (Recycling program).

The remote control should be operated within 23feet(7m) and 30 to the left and the right of the IR receiver

on the front of the LCD TV.

Used batteries should be disposed properly.

15

User Guidance Information

1. Turn on the LCD TV and press on the remote controller.

2. Use to move to "Composite 1/2".

If S-Video has been connected, select "S-Video 1/2".

If SCART terminal has been connected, select SCART1 or SCART2.

3. Turn on the VCR, insert the tape and press play button.

VCR Connections

Connect the LCD TV’s Composite In terminal to the VCR’s Composite Out terminal using the Composite cable.
(Make sure the colour of the terminals and the colour of the cable are the same)

Use the S-Video cable for higher picture quality.

Connection terminals of other appliances differ by manufacture and model.

< LCD TV Back view >

< LCD TV Back view >

Composite Cable

S-Video Cable

SCART Cable

Auto Cable

Connect the SCART terminal of the LCD TV and the VCR with the SCART cable.

< VIDEO >

(R) (L)

< VIDEO >

(R) (L)

< VIDEO >

(R) (L)

Connecting to the composite terminal

Connecting to the S-Video terminal

Connecting to the SCART terminal

< LCD TV Back view >

Playing the VCR

16

Connection
