Page 1
Multilingual Quick Installation Guide
Ultra Slim 2-Port HDMI 2.0 Splitter
332716
Ultra Slim 4-Port HDMI 2.0 Splitter
332717
H/W Version: 1
Page 2
English
1. Product overview
Equip 332716
Equip 332717
2. Product Specification
1. Supports video resolutions up to 4K/60Hz
2. Supports 3D display, HDR and HDCP2.2
3. Ultra-slim design
4.
Supports smart EDID control
1. Power LED 4.
2.
Copy EDID LED 5. HDMI Input LED
3.
Mixed EDID LED
1.
DC/5V
2.
HDMI Input
1. Copy EDID LED
2.
Mixed EDID LED
5.
Power LED
1.
DC/5V
2.
HDMI Output
HDMI Output LED
3.
HDMI Output
4.
EDID Button
3.
HDMI Input LED
4.
HDMI Output LED
3.
HDMI Input
4.
EDID Button
Page 3
Deutsch
1. Gerätekomponenten
Equip 332716
1. Power LED 4. HDMI Output 2 LED
2. Copy EDID LED 5. HDMI Output 1 LED
3. Mixed EDID LED 6. HDMI Input LED
Equip 332717
1. Copy EDID LED 5. HDMI Output 3 LED
2. Mixed EDID LED 6. HDMI Output 2 LED
3. HDMI Input LED 7. HDMI Output 1 LED
4. HDMI Output 4 LED 8. Power LED
2. Produktspezifikationen
1.
Unterstützt Videoauflösung bis zu 4K/60Hz
2. Unterstützt 3D-Anzeige, HDR, HDCP2.2
3. Unterstützt 3D-Videoübertragung
Unterstützt automatisches Ein- und Ausschalten
4.
Page 4
Français
1. Aperçu du produit
Equip 332716
1. Power LED 4. HDMI Output 2 LED
2. Copy EDID LED 5. HDMI Output 1 LED
3. Mixed EDID LED 6. HDMI Input LED
Equip 332717
1. Copy EDID LED 5. HDMI Output 3 LED
2. Mixed EDID LED 6. HDMI Output 2 LED
3. HDMI Input LED 7. HDMI Output 1 LED
4. HDMI Output 4 LED 8. Power LED
Caractéristiques du produit
2.
1.
Prend en charge des résolutions vidéo jusqu'à 4K/60Hz
2. Prend en charge les l'affichage 3D, HDR, HDCP2.2
3. Design ultra-fin
4.
Prend en charge le contrôle intelligent EDID
Page 5
Español
1.
Descripción del producto
Equip 332716
1. Power LED 4. HDMI Output 2 LED
2. Copy EDID LED 5. HDMI Output 1 LED
3. Mixed EDID LED 6. HDMI Input LED
Equip 332717
1. Copy EDID LED 5. HDMI Output 3 LED
2. Mixed EDID LED 6. HDMI Output 2 LED
3. HDMI Input LED 7. HDMI Output 1 LED
4. HDMI Output 4 LED 8. Power LED
Especificación del producto
2.
1.
Admite resoluciones de vídeo de hasta 4K/60Hz
2. Soporta la visualización en 3D, HDR, HDCP2.2
3. Diseño ultraplano
Control EDID inteligente de Soporta
4.
Page 6
Italiano
1. Descrizione del prodotto
Equip 332716
1. Power LED 4. HDMI Output 2 LED
2. Copy EDID LED 5. HDMI Output 1 LED
3. Mixed EDID LED 6. HDMI Input LED
Equip 332717
1. Copy EDID LED 5. HDMI Output 3 LED
2. Mixed EDID LED 6. HDMI Output 2 LED
3. HDMI Input LED 7. HDMI Output 1 LED
4. HDMI Output 4 LED 8. Power LED
Specifiche del prodotto
2.
1. Supporta risoluzioni video fino a 4K/60Hz
2. Supporta la visualizzazione 3D, HDR, HDCP2.2
3. Design ultrasottile
Supporta il controllo EDID intelligenti
4.
Page 7
Portuguese
1. Resumo do produto
Equip 332716
1. Power LED 4. HDMI Output 2 LED
2. Copy EDID LED 5. HDMI Output 1 LED
3. Mixed EDID LED 6. HDMI Input LED
Equip 332717
1. Copy EDID LED 5. HDMI Output 3 LED
2. Mixed EDID LED 6. HDMI Output 2 LED
3. HDMI Input LED 7. HDMI Output 1 LED
4. HDMI Output 4 LED 8. Power LED
2.
Especificações do produto
1. Suporta resolução de vídeo até 4K/60Hz
2. Suporta exibição 3D, HDR, HDCP2.2
3. Design ultrafino
4. Suporta Controle EDID inteligente
