Epson V11H874041 Product Data Sheet

EB-2042 DATA SHEET

Combining a high picture quality, a brightness of 4,400 lumens,
absolute reliability and flexible operation to deliver perfect
presentations.

Bring bright colors and sharp images to any meeting room with our
super-bright new business projector, which offers a great brightness level
of 4,400 lumens and XGA resolution. The EB-2042 is designed to project
a scalable image up to a massive 300 inches, and offers connectivity
choices including optional wireless LAN connectivity

Up to 300-inch display and outstanding quality
Epson’s 3LCD technology ensures high-quality content has more vivid colors
and brighter images. HDMI connectivity guarantees sharper and clearer
content, even at the maximum image size of 300 inches.

Simple setup and connectivity
The EB-2042 offers auto power-on and an array of connectivity options
including two HDMI ports and optional wireless LAN to stream content from
laptops or mobile devices.

Keep costs down
Project for longer with improved reliability and a longer lamp life of up to
12,000 hours in eco mode.

Home screen
The home screen offers quick and easy access to a variety of useful
functions, such as connection sources. Wireless connections can also be
made easily using the information on screen.

Universal Product Code H874

KEY FEATURES

Up to 300-inch display and great

quality
Epson's 3LCD technology with
XGA resolution

Bring presentations to life

Outstanding 4,400-lumen
brightness

Stream and share connectivity

Dual HDMI & optional wireless
connectivity

Home screen and split-screen

Quick and easy access to a variety
of useful functions

TECHNOLOGY

Projection System

3LCD Technology, RGB liquid crystal shutter

LCD Panel

0.63 inch with D10

Effective Scanning Frequency ­Analog

Pixel clock: 13.5 MHz to 162 MHz up to UXGA 60 Hz

Horizontal 15 KHz – 92 KHz Vertical 50 Hz – 85 Hz

Effective Scanning Frequency ­Digital

Pixel clock: 13.5 MHz to 162 MHz up to UXGA 60 Hz

Horizontal 15 KHz – 75 KHz Vertical 24/ 30/ 50/ 60 Hz


Colour Light Output

4,400 lumen - 2,490 lumen (economy) In accordance with IDMS15.4

White Light Output

4,400 lumen - 2,490 lumen (economy) In accordance with ISO 21118:2012

Resolution

XGA, 1024 x 768, 4:3

Contrast Ratio

15,000 : 1

Aspect Ratio

4 : 3 (native)

Lamp

230 W, 5,500 h durability, 12,000 h durability (economy mode)

Keystone Correction

Auto vertical: ± 30 °, Manual horizontal ± 30 °

Colour Reproduction

Up to 1.07 billion colors

OPTICAL

Throw Ratio

1.38 - 2.24:1

Zoom

Optical manual, Factor: 1 - 1.6

Image Size

30 inches - 300 inches

Projection Distance (Throw
Distance)

0.80 m ( 30 inch screen) to 08.50 m (300 inch screen) in Wide mode

1.36 m ( 30 inch screen) to 13.86 m (300 inch screen) in Tele mode

Projection Lens F Number

1.51 - 1.99

Focal Distance

18.2 mm - 29.2 mm

Focus

Manual

Offset

8.6 : 1

CONNECTIVITY

USB Display Function

3 in 1: Image / Mouse / Sound

Interfaces Video Inputs

VGA (RGB) (D-sub 15 pin) – 2

HDMI – 2 (of which 1 supports MHL)

Composite - 1

Interfaces Video Output

VGA (D-sub 15 pin) – 1

Interfaces Audio Inputs

Stereo mini – 2, Mic. In – 1

Interfaces Audio Output

Stereo mini – 1

Network

Ethernet interface (100 Base-TX / 10 Base-T)

Wireless LAN IEEE 802.11b/g/n (2.4GHz) (optional with ELPAP10 connected via USB port)

USB

USB Type A – 1

USB Type B – 1

Control

RS-232C D-sub 9 pin

Remote Control

1 unit, Infrared front and back reception

Epson iProjection App

Ad-Hoc / Infrastructure

ADVANCED FEATURES

Security

Kensington lock, Control panel lock, Password lock, Padlock, Security cable hole, Wireless

LAN unit lock, Wireless LAN security, Password protection

Features

AV mute slide, Auto Power On, Automatic input selection, Built-in16 W speaker,

Direct Power on/off, Document Camera Compatible, Freeze image, Home

Screen, Horizontal and vertical keystone correction, JPEG Viewer, Long lamp life, MHL

audio/video interface

`` Quick Corner, Split-Screen-Function, iProjection App

Video Colour Modes

Dynamic, Presentation, sRGB, Blackboard, Cinema

GENERAL

Energy Use

331 W (Normal mode), 227 W (Economy mode), 0.2 W (Energy saving mode)

Rated Voltage and Current

100 - 240 V AC 50/60 Hz 3.6-1.6A

Fan Noise

37 dB (normal mode)to 28 dB (economy mode)

Product Dimensions

309 x 293 x 105 mm (Width x Depth x Height)

Product Weight

3.0 Kgs

OTHER

Warranty

24 months service, Lamp: 12 months or 1,000 h

Optional warranty extension available

PRODUCT SPECIFICATIONS EB-2042

Universal Product Code H874
