Epson Pro G6900WUNL, Pro G6800NL, Pro G6550WUNL, Pro G6450WUNL, Pro G6150NL Product Sheet

PowerLite® Pro G6050WNL/6150NL/6450WUNL/6550WUNL/

6750WUNL/6800NL/6900WUNL 3LCD Projectors

1

Pro G6900WUNL projector shown

with standard lens

Pro G6750WUNL projector shown

with standard lens

The premium large-venue projectors from Epson.

3 x Brighter Colors 1, and reliable performance — 3LCD, 3-chip technology

One measurement of brightness is not enough — look for both high color brightness and high

white brightness. The Pro G Series has:

Color Brightness: 4500 up to 7000 lumens 2

White Brightness: 4500 up to 7000 lumens 2

Crisp, clear resolution — XGA, WXGA or WUXGA for incredible images

Six optional lenses with lens shift — standard, wide, rear, middle or long-throw for complete flexibility

and easy exchange

Versatile connectivity — easily integrate with any system; HDBaseT 3 on select models

Convenient remote management — remotely monitor and control presentations; includes

scheduling function

Built-in edge-blending technology — seamlessly project more than one image at a time

PowerLite® Pro G6050WNL/6150NL/6450WUNL/6550WUNL/
6750WUNL/6800NL/6900WUNL 3LCD Projectors

The premium large-venue projectors from Epson.

Get uncompromising image quality and professional-grade reliability with the Pro G Series large-venue projectors. Whether

you’re presenting in a conference room, auditorium, stage or house of worship, these powerful projectors will keep your

audience captivated. Incredible color brightness and up to WUXGA resolution means images are brighter, crisper and even

more brilliant. Setup is a breeze with flexible, 360-degree installation and diverse connectivity options including HDBaseT 3.

You’ll stay in control with remote management functions and easily adapt to the environment with six optional lenses.

Edge-blending capabilities enhance the experience with panoramic images and integrated curves and corners. Point and arc

correction ensures that rectangular images are never compromised. And for the ultimate presentation, 3D stackable solutions

and low-cost glasses take it all to the next level.

G6800NL

G6450WUNL

COLOR

BRIGHTNESS

4500

LUMENS

2

BRIGHTNESS

4500

WHITE

LUMENS

2

G6550WUNL

COLOR

BRIGHTNESS

5200

LUMENS

2

BRIGHTNESS

5200

WHITE

LUMENS

2

G6050WNL

COLOR

BRIGHTNESS

5500

LUMENS

2

BRIGHTNESS

5500

WHITE

LUMENS

2

G6750WUNL/

G6900WUNL

COLOR

BRIGHTNESS

6000

LUMENS

2

BRIGHTNESS

6000

WHITE

LUMENS

2

G6150NL

COLOR

BRIGHTNESS

6500

LUMENS

2

BRIGHTNESS

6500

WHITE

LUMENS

2

COLOR

BRIGHTNESS

7000

LUMENS

2

BRIGHTNESS

7000

WHITE

LUMENS

2

3 x Brighter Colors with Epson

1

Brilliant image quality requires high color brightness
(color light output), and Epson
3 x Brighter Colors than leading competitive projectors

®

3LCD projectors have

1

.

One brightness measurement (lumens) is not enough. A
projector‘s specification needs to show both high color
brightness and high white brightness. If color brightness is
lower than white brightness, images may be dark, dull and
lose detail. If not provided, be sure to ask for a projector’s color
brightness specification.

EPSON

High color brightness and high white brightness

COMPETITOR

Color brightness significantly lower than white brightness

Actual photographs of projected images from an identical signal
source. Price, resolution and white brightness are similar for
both projectors (Epson 3LCD and 1-chip DLP competitor).
Both projectors are set to their brightest mode.

3LCD — the #1 projection technology in
the world

• All3LCDprojectorshavebothhighcolorbrightnessandhigh

1

white brightness

• All3LCDprojectorshave3chips

• 25%lowerpowerconsumptionforlowerenergycosts

• 20yearsofroad-testedreliability

Award-winning Faroudja DCDi® Cinema for
advanced video quality

Faroudja DCDi Cinema is a video enhancement technology,
used primarily for film viewing, which produces exceptional
image quality without introducing artifacts. Faroudja developed
DCDi (Directional Correlational Deinterlacing) to eliminate jaggy
images by using a unique algorithm.

4

Thebest-sellingprojectorsintheworld.

Built with image quality and reliability in mind, Epson projectors enhance communication and inspire
collaboration, while offering a low total cost of ownership. From ultraportable projectors designed for
educational settings to boardroom-ready install able business projectors, Epson has the model made
for you.

Incredible HDBaseT 3 and
diverse connectivity

Connect with virtually any system including HDBaseT,
HD-SDI, HDMI, DisplayPort, VGA, BNC and LAN connectivity.
Cutting-edge HDBaseT technology means just one single
CAT-5/6 cable carries full HD video, audio, network and control
commands. And it’s over 328 feet to accommodate large
venues. No need for additional cables, signal repeaters or
added labor.

Stacked 3D solutions

You can create an impressive viewing experience with twice
the brightness using Epson’s stacked 3D solution (requires two
projectors). Polarized filters, in combination with low-cost 3D
glasses, enables you to enjoy a 3D theater experience, right in
your own personal space.

Optional HDBaseT

For your convenience, Epson offers an optional HDBaseT
transmitter box as a companion piece to the Pro G series.
Three inputs are featured for easy installation: HDMI, LAN, and
RS-232 to output into a CAT-5/6 cable.

3

transmitter

Advanced, integrated edge-blending
technology

Enhance the experience with seamless panoramic, multi-screen
images that blend edges by matching color and brightness
perfectly, even in areas that overlap. The Pro G6800NL and
Pro G6900WUNL models take edge blending one step further
with curved surface and corner wall support. Project on
horizontal or vertical walls while also using edge blending to
heighten the experience even more.

Split Screen

Split Screen allows you to display content from two inputs
simultaneously, side by side, on a single screen. With three
layout options you can display video and presentation
materials, and run video on both screens.

DICOM Simulation Mode

DICOM (Digital Imaging and Communication in Medicine) is
a standard for handling, storing, printing and transmitting
medical imaging information. DICOM Simulation Mode is
ideal for viewing grayscale medical images, such as X-rays,
for training and educational purposes. It enables users to
reproduce images with an advanced grayscale level that
simulates DICOM Part 14.

5

6

360-degree installation

The PowerLite Pro G Series can be rotated 360 degrees in any
direction for off-axis positioning flexibility. As a result, it can be
used for a wide range of applications, such as projecting on
the ceiling or floor, or as part of a rear-projection system. Epson
technology keeps the projector running without compromising
performance or causing overheating.

Designed for rental and staging

The SDI input accommodates live video streaming. 360-degree
installation allows for virtually any placement, and an
inconspicuous black case means uncompromised presentation.
Note: SDI input available on the Pro G6900WUNL model only.

Short-throw lens

Install the projector as close as a 0.7 throw ratio to the screen
and still get the same clear, crisp projection. A 1.2x zoom and

upto69%verticalandupto31%horizontallensshiftgives

even more flexibility when you need it.

Six optional lenses

For added flexibility, the PowerLite Pro G Series offers a total of
six lenses: one standard, one wide, one rear, two middle and
one long-throw that allow users to choose the lens most suited
for their environment. A quick-release lever allows for a fast,
easy lens exchange.

Easy Management®

The EasyMP® Monitor tool makes it easy to monitor and control
all networked Epson projectors, set up email notifications,
verify and change internal settings, and more. You can also
remotely power down your projector(s) to extend the lamp life
and save energy.

Multi-PC projection

Epson Multi-PC Collaboration utility allows you to display four
individual PC screens simultaneously over the network (wired
or wireless), with another 28 users connected to the same
projector on standby mode. This feature is a great tool for
meetings or classroom projects where multiple users want to
present and compare their content.
Note: This feature available on the Pro G6050WNL/6150NL/
6450WUNL/6550WUNL/6750WUNL models only.

Schedule function

Save energy using the convenient Schedule function. And,
easily control the projector at non-networked venues. The
embedded clock inside the projector enables it to do scheduled
tasks without having the network standby mode on.

Protect your investment — long-life
electrostatic air filter

The PowerLite Pro G series electrostatic filter is designed to
protect the optical engine, lamp and electronics from small dust
particles that can enter any projector. It has a recommended
10,000- hour filter cleaning schedule
particles as small as three microns, due in part to its pleated,
expanded design.

7

and can capture

Easy maintenance

Offering convenient access to the lamps and filter, the Pro G
series makes maintenance easier than ever, even if the
projector is ceiling mounted. The lamp cover is located on the
rear side panel and there are no screws, so the lid can be
removed without any special tools.

Lens shift

Epson lens shift technology enables outstanding installation
flexibility with an incredible range of up to + or – 67° on the
vertical axis and up to + or – 30° on the horizontal axis (may
vary by model). Users can operate the lens shift functions using
the adjustment knobs on the top of the projector.

Centered lens design

Featuring a centered lens design, the Pro G series makes
installation easy to plan. Positioning the ceiling mount, screen
and projector can be performed individually and independent of
one another.

Arc correction

Using arc correction, you can adjust each side of a projected
image in an arc or barrel-shaped way, making it easier than
ever to get a perfectly rectangular image.

Convenient test patterns

Make sure your presentation is setup correctly before you
begin. The PowerLite Pro G Series features nine test patterns
including linearity, color reproduction, bleeding and tone
production. It even detects distortion.

Additional Features/Benefits

• Built-inedge-blendingtechnology— seamlessly project

overlapping images at one time

• Ultimate360-degreeinstallation— rotate for full

functionality in literally any direction

• Pointandarccorrection— adjust each side of an image

for a perfect rectangle

• 3Dstackablesolutions— for 3D applications using

passive, low-cost glasses

Listofmodels:

PL PRO G6050WNL PL PRO G6150NL PL PRO G6450WUNL PL PRO G6550WUNL

WXGA XGA WUXGA WUXGA

5500 Lumens 6500 Lumens 4500 Lumens 5200 Lumens

HDMI HDMI HDMI HDMI

Display Port Display Port Display Port Display Port

Edge Blending Edge Blending Edge Blending Edge Blending

1 Compared to leading 1-chip DLP business and education projectors based on NPD data,

July 2011 through June 2012. Color brightness (color light output) measured in accordance
with IDMS 15.4. Color brightness will vary depending on usage conditions.

2 Color brightness (color light output) and white brightness (white light output) will vary

depending on usage conditions. Color light output measured in accordance with IDMS

15.4; white light output measured in accordance with ISO 21118.

3 For select models. The PowerLite Pro G6750WUNL and G6800NL have an HDBaseT input

and the G6900WUNL has HDBaseT and SDI inputs.

4 Data source: ProjectorCentral.com Jan. 2013. Average of 1128 shipping models for which

the manufacturers provided lumens and total power data, all resolutions and brightness
levels. Energy efficiency was measured as wattage per lumen. It was measured for both
3LCD and 1-chip projectors in each of five brightness segments. 3LCD projectors averaged

less required electricity per lumen in each of the five segments.
5 Consult your user manual for input combinations.

6 This projector does not meet the DICOM standard Part 14 and should not be used as a

medical diagnostic device.
7 Recommendation based on normal room conditions. Cleaning requirements may vary

depending on use, environment and other conditions. Cleaning intervals may be adjusted to

accommodate the environment in which the projector is used.
8 See our website for convenient and reasonable recycling options at

www.epson.com/recycle
9 SmartWay is an innovative partnership of the U.S. Environmental Protection Agency that

reduces greenhouse gases and other air pollutants and improves fuel efficiency.
10 Lamp life will vary depending upon mode selected, environmental conditions and usage.

Lamp brightness decreases over time.

PL PRO G6750WUNL PL PRO G6800NL PL PRO G6900WUNL

WUXGA XGA WUXGA

6000 Lumens 7000 Lumens 6000 Lumens

HDMI HDMI HDMI

Display Port Display Port Display Port

HDBaseT HDBaseT HDBaseT and SDI

Edge Blending Adv. Edge Blending Adv. Edge Blending

For more information on Epson’s environmental
programs, go to eco.epson.com

Eco Features

• Energy-efcient3LCDlightengine

• Recyclableproduct

• EpsonAmerica,Inc.isaSmartWaySM

Transport Partner

8

9

PowerLite®Pro3LCDProjectors

Product Name Product Code UPC

PowerLite Pro G6050WNL V11H511920 0 10343 90669 3
PowerLite Pro G6150NL V11H509920 0 10343 90670 9
PowerLite Pro G6450WUNL V11H535920 0 10343 90673 0
PowerLite Pro G6550WUNL V11H513920 0 10343 90675 4
PowerLite Pro G6750WUNL V11H542920 0 10343 90677 8
PowerLite Pro G6800NL V11H532920 0 10343 90678 5
PowerLite Pro G6900WUNL V11H514920 0 10343 90679 2
Genuine Epson lamp V13H010L76 0 10343 90738 6
Replacement air filter V13H134A43 0 10343 90739 3

Computer 1

SDI

Video

3

HDBaseT

LAN

RJ-45

Audio

1 & 2

Kensington

Security

Lock Port

3

HDMI

Audio 3

RS-232c

Display Port

Remote

Monitor Out

Power

S-Video

Video

Audio

Out

Audio R & L

Control Panel

G6900WUNL
Projector shown

Specifications

Projection System

High-aperture Epson 3LCD, 3-chip technology
Projection Method
Front/rear/ceiling mount
Driving Method
Epson Poly-silicon TFT Active Matrix
Pixel Number
G6150/G6800: 786,432 dots (1024x768) x 3
G6050W: 1,024,000 dots (1280 x 800) x 3
G6450WU/G6550WU/G6750WU/G6900WU:
2,304,000 dots (1920 x 1200) x 3
Native Resolution
G6150/G6800: 1024x768 (XGA)
G6050W: 1280 x 800 (WXGA)
G6450WU/G6550WU/G6750WU/G6900WU:
1920 x 1200 (WUXGA)
Resize
640 x 480, 800 x 600, 1280 x 1024,
1400 x 1050
Aspect Ratio
Supports 4:3, 16:9, 16:10
Pixel Arrangement
Cross stripe

Color Brightness (Color Light Output)

G6050W: 5500 lumens
G6150: 6500 lumens
G6450WU: 4500 lumens
G6550WU: 5200 lumens
G6750WU/G6900WU: 6000 lumens
G6800: 7000 lumens

White Brightness (White Light Output)

G6050W: 5500 lumens
G6150: 6500 lumens
G6450WU: 4500 lumens
G6550WU: 5200 lumens
G6750WU/G6900WU: 6000 lumens
G6800: 7000 lumens
Contrast Ratio
(High Brightness, Dynamic Mode)
5000:1
Brightness Uniformity (typical)
90%
Color Reproduction

1073.74 million colors
Size (projected distance)
50" – 300"
Lens Shift
Vertical (Standard lens)
G6150/G6800: ±57 degrees
G6050W/G6450WU/G6550WU/G6750WU/
G6900WU: ±67 degrees
Horizontal: ±30 degrees

EpsonAmerica,Inc.

3840 Kilroy Airport Way, Long Beach, CA 90806

Specifications and terms are subject to change without notice. EPSON, EasyMP, Easy Management and PowerLite are registered trademarks, EPSON Exceed Your Vision is a registered logomark and Better
Products for a Better Future is a trademark of Seiko Epson Corporation. PrivateLine is a registered trademark, Duet is a trademark and Epson Connection is a service mark of Epson America, Inc. SmartWay is
a service mark of the U.S. Environmental Protection Agency. All other product and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in
these marks. Copyright 2013 Epson America, Inc. CPD-39430 4/13

2

:

2

:

Specifications (continued)

Keystone Correction

Vertical: ±30 degrees
Horizontal: ±30 degrees
Lamp Type
380 W UHE

10

Lamp Life

G6150/G6550WU: 2500/4000 hour
G6050W/G6450WU: 3000/4000 hour
G6750WU/G6800/G6900WU: 2000/4000 hour

(Normal/Eco mode)

Effective Scanning
Frequency Range

Pixel Clock

13.5 MHz – 162 MHz (up to UXGA 60 Hz)
Horizontal
15 kHz – 92 kHz
Vertical
50 Hz – 85 Hz

Video I/O

Display Performance

NTSC: 480 line
PAL: 576 line
(depends on observation of the
multi-burst pattern)
Input Signal
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/
PAL60/ SECAM/480i/576i/480p/576p/720p/
1080i/1080p
Pixel works: video chip
3D Y/C separation,
noise reduction motion compensated
Interlace-Progressive conversion
(2 – 2, 3 – 2 film detection)
Interfaces
HDMI x 1
DisplayPort x 1
Computer: D-sub 15 pin x 1
Video-1: 5-BNC x 1
Video-2: RCA x 1
Composite video: BNC x 1
S-Video x 1
Audio-in: Mini stereo x 3
Audio-in: RCA (L&R) x 1
Network: RJ-45 x 1, 100 Mbps
USB Type-A x 1, Type-B x 1
Serial: RS-232c
Hardwire remote jack x 1
Monitor-Out: D-sub 15 pin x 1
G6750WU/G6800/G6900WU: HD Base T x 1
G6900WU: HD-SDI x 1

EpsonCanadaLimited

185 Renfrew Drive, Markham, Ontario L3R 6G3

Standard Projection Lens

See brochure for information on optional lenses.
Type
Manual focus/zoom
F-number

1.65 – 2.55
Focal Length

21.28 mm – 37.94 mm
Zoom Ratio
Optical zoom 1 – 1.8
Throw Ratio Range

1.29 – 2.35 (XGA)

1.26 – 2.76 (WXGA/WUXGA)

Other Features

Operating Temperature

32 ˚ to 113 ˚F (0 ˚ to 45 ˚C)
Power Supply Voltage
100 – 240 V ±10%, 50/60 Hz AC
Power Consumption (Normal Mode)
G6150/G6550WU: 528 W
G6050W: 498 W
G6450WU: 468 W
G6750WU/G6800/G6900WU: 568 W
421 W (ECO Mode)

3.3 W Standby (Communication on)

0.41 W Standby (Communication off)
Fan Noise
39 dB (Normal Mode) Max.
31 dB (ECO Mode)
Security
Security cable hole, lens lock,

®

Kensington

lock provision

Remote Control

Features

Power, source search selection, computer,
video, A/V mute, freeze, user ID, auto, aspect,
color mode, number, page up and down,
E-zoom, volume, help, menu, enter, esc and
pointer functions
Operating Angle
Right/left:
Front: ± 60 degrees
Rear: ± 30 degrees
Upper/lower:
Front: ± 20 degrees
Rear: +10 to +50 degrees
Operating Distance
49 ft

Support

The Epson Connection SM

Pre-sales support U.S. and Canada
800-463-7766
Internet website www.epson.com

www.epson.com
www.epson.ca

Support (continued)

Service Programs

Three-year limited warranty, Epson Road Service
program, PrivateLine
support (U.S. and Canada only) and 90-day
limited lamp warranty
What’s in the Box
A PowerLite Pro G projector, power cable,
computer cable (VGA), projector remote control
with batteries, user manual CD, EasyMP
software CD, Quick Setup Sheet,
PrivateLine support card, registration card,
password protection sticker and lens lock screw

®

dedicated toll-free

Dimensions (W x D x H)

Excluding Feet, Lens

19.88" x 15.04" x 5.67"
Weight 19.6 lb
Including Feet, Lens

19.88" x 15.94" x 6.73"
Weight 21.5 lb

Accessory Part Numbers

Genuine Epson lamp (ELPLP76) V13H010L76
Replacement air filter (ELPAF43) V13H134A43
ELPLS06 — Standard lens V12H004S06
ELPLU01 — Short throw lens V12H004U01
ELPLM04 — Middle throw
zoom lens 1<1.83 - 2.45> V12H004M04
ELPLM05 — Middle throw
zoom lens 2 <1.83 - 2.53> V12H004M05
ELPLL06 — Long throw
zoom lens <1.84 - 2.32> V12H004L06
ELPLR03 — Rear projection
wide lens <2.03> V12H004R03
Quick Wireless Connect key
(ELPAP09) V12H005M09
Replacement remote control 158279900
Advanced projector ceiling mount
with precision gear ELPMBPRG
Adjustable suspended ceiling
channel kit ELPMBP01
False ceiling plate kit ELPMBP02
Structural round ceiling plate ELPMBP03
Adjustable extension column
(pipe) 8" – 11" ELPMBC01
Kensington security lock ELPSL01
50-inch portable screen
(4:3 aspect ratio) ELPSC06
60-inch portable pop-up screen
(4:3 aspect ratio) ELPSC07
80-inch portable pop-up screen
(4:3 aspect ratio) ELPSC08
Duet™ portable projector screen
(4:3/16:9 combination) ELPSC80
Distribution amplifier ELPDA01
G6750WU/G6800/G6900WU:

3

HD BaseT
G6050W/G6150/G6450/G6550WU/G6750WU:
Wireless LAN module (ELPAP07) V12H306P12

Transmitter (ELPHD01) V12H547020
