Epson CW-C6000, CW-C6500 User Manual
External I/O
Technical Reference Guide
Series Series
Overview
External I/O Specification
Commands
Printer Statuses and Signals
Timing
Extended I/F Signal Operation Mode Settings
Appendix
M00123701
Rev.B
Cautions
• No part of this document may be reproduced, stored in a retrieval system, or transmitted in any form or by
any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation.
• The contents of this document are subject to change without notice. Please contact us for the latest information.
• While every precaution has been taken in the preparation of this document, Seiko Epson Corporation
assumes no responsibility for errors or omissions.
• Neither is any liability assumed for damages resulting from the use of the information contained herein.
• Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third par-
ties for damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of: accident,
misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or
(excluding the U.S.) failure to strictly comply with Seiko Epson Corporation’s operating and maintenance
instructions.
• Seiko Epson Corporation shall not be liable against any damages or problems arising from the use of any
options or any consumable products other than those designated as Original EPSON Products or EPSON
Approved Products by Seiko Epson Corporation.
Trademarks
EPSON is a registered trademark of Seiko Epson Corporation.
Exceed Your Vision is registered trademarks or trademarks of Seiko Epson Corporation.
All other trademarks are the property of their respective owners and used for identification purpose only.
©Seiko Epson Corporation 2019-2021.
2
Restriction of Use
When this product is used for applications requiring high reliability/safety such as transportation devices
related to aviation, rail, marine, automotive etc.; disaster prevention devices; various safety devices etc.; or functional/precision devices etc., you should use this product only after giving consideration to including fail-safes
and redundancies into your design to maintain safety and total system reliability. Because this product was not
intended for use in applications requiring extremely high reliability/safety such as aerospace equipment, main
communication equipment, nuclear power control equipment, or medical equipment related to direct medical
care etc., please make your own judgment on this product’s suitability after a full evaluation.
About this Manual
Aim of the Manual
This manual was created to provide information on development, design, and installation of systems and development and design of printer applications for developers.
Manual Content
The manual is made up of the following sections:
Chapter 1 Overview
Chapter 2 External I/O Specification
Chapter 3 Commands
Chapter 4 Printer Statuses and Signals
Chapter 5 Timing
Chapter 6 Extended I/F Signal Operation Mode Settings
Chapter 7 Appendix
3
Key to Symbols
The symbols in this manual are identified by their level of importance, as defined below. Read the following carefully before
handling the product.
WARNING
CAUTION
c IMPORTANT
Q NOTE
You must follow warnings carefully to avoid serious bodily injury.
Provides information that must be observed to prevent damage to the equipment or loss of
data.
• Possibility of sustaining physical injuries.
• Possibility of causing physical damage.
• Possibility of causing information loss.
Indicates information with which you must comply when using the product. Mishandling due
to ignoring this information may cause the product to fail or malfunction.
Indicates supplementary explanations and information you should know.
Safety Precautions on Handling
• Shut down your equipment immediately if it produces smoke, a strange odor, or unusual
WARNING
noise. Continued use may lead to fire or electric shock. Immediately unplug the equipment.
• Only disassemble this product as described in this manual. Do not make modifications to
the unit. Tampering with this product may result in injury, fire, or electric shock.
• Never insert or disconnect the power plug with wet hands. Doing so may result in severe
shock.
• Do not allow foreign matter to fall into the equipment. Penetration by foreign objects may
lead to fire or shock.
• If water or other liquid spills into this equipment, unplug the power cord immediately. Continued usage may lead to fire or shock.
• Handle the power cord with care. Improper handling may lead to fire or shock.
∗ Do not modify or attempt to repair the cord.
∗ Do not place any object on top of the cord.
∗ Avoid excessive bending, twisting, and pulling.
∗ Do not place cord near heating equipment.
∗ Check that the plug is clean before plugging it in.
∗ Be sure to push the prongs all the way in.
• Be sure to set this equipment on a firm, stable, horizontal surface. Product may break or
cause injury if it falls.
• Do not use in locations subject to high humidity or dust levels. Excessive humidity and dust
may cause equipment damage, fire, or shock.
• Do not place heavy objects on top of this product. Never stand or lean on this product.Equipment may fall or collapse, causing breakage and possible injury.
4
Contents
■ Restriction of Use ....................................................................................................................3
■ About this Manual ..................................................................................................................3
Aim of the Manual ............................................................................................................................................................. 3
Manual Content .................................................................................................................................................................. 3
Key to Symbols.................................................................................................................................................................... 4
Safety Precautions on Handling ................................................................................................................................... 4
■ Contents....................................................................................................................................5
Overview...........................................................................................................9
■ Functionality............................................................................................................................9
■ External device ..................................................................................................................... 10
External I/O Specification .............................................................................11
■ Connector.............................................................................................................................. 11
■ Signal Definitions................................................................................................................. 11
Pulse signal.........................................................................................................................................................................11
Level signal.........................................................................................................................................................................12
■ Pin Assignment and Specification for I/O Signals.......................................................... 13
■ Specification for I/O Signals (I/O Power Supply/SG Not Separated) .......................... 17
Commands .....................................................................................................19
■ List of Commands ................................................................................................................19
■ Setting Commands .............................................................................................................. 23
End print signal (output) mode settings .................................................................................................................23
Mode setting for data ready signal (output) ..........................................................................................................25
Mode setting for clogged nozzle detected signal (output)..............................................................................26
Mode setting for head maintenance signal (output)..........................................................................................27
Mode setting for printer ready signal (output) .....................................................................................................28
Mode setting for warning signal (output)...............................................................................................................29
Mode setting for error signal (output)......................................................................................................................30
Ink low signal (output) mode setting .......................................................................................................................31
Ink cartridge exchange signal (output) mode setting........................................................................................32
Paper out signal (output) mode setting ..................................................................................................................33
Mode setting for pause signal (input) ......................................................................................................................34
Mode setting for head cleaning signal (input) ......................................................................................................35
Mode setting for clogged nozzle check signal (input) .......................................................................................36
Mode setting for feed signal (input)..........................................................................................................................37
Mode setting for start print signal (input)...............................................................................................................38
5
Mode setting for re-print signal (input)................................................................................................................... 39
■ Acquisition Commands for Setting Values...................................................................... 40
Acquisition commands for mode setting values for end print signal (output)......................................... 40
Acquisition commands for mode setting values for data ready signal (output)...................................... 40
Acquisition commands for mode setting values for clogged nozzle detected signal (output).......... 41
Acquisition commands for mode setting values for head maintenance signal (output)...................... 41
Acquisition commands for mode setting values for printer ready signal (output) ................................. 42
Acquisition commands for mode setting values for warning signal (output)........................................... 42
Acquisition commands for mode setting values for error signal (output) ................................................. 42
Acquisition of mode setting value for ink low signal (input)........................................................................... 43
Acquisition of mode setting value for ink cartridge exchange signal (input)........................................... 43
Acquisition command of mode setting value for paper out signal (input)................................................ 44
Acquisition commands for mode setting values for pause signal (input) .................................................. 44
Acquisition commands for mode setting values for head cleaning signal (input).................................. 45
Acquisition commands for mode setting values for clogged nozzle check signal (input) ................... 45
Acquisition commands for mode setting values for feed signal (input) ..................................................... 45
Acquisition commands for mode setting values for start print signal (input) .......................................... 46
Acquisition commands for mode setting values for re-print signal (input) ............................................... 46
Printer Statuses and Signals ........................................................................ 47
Timing............................................................................................................. 49
■ Basic Timing for Label Printing.......................................................................................... 49
■ Basic Timing for Pausing..................................................................................................... 50
■ Basic Timing for Label Feeding.......................................................................................... 51
When "backfeed operation time settings" is set to "backfeed after printing"........................................... 51
When "backfeed operation time settings" is set to "backfeed before printing".......................................52
■ Basic Timing for Nozzle Check and Head Cleaning........................................................ 53
Extended I/F Signal Operation Mode Settings........................................... 55
■ End Print Signal Mode Settings......................................................................................... 55
■ Data Ready Signal Mode Settings..................................................................................... 55
■ Clogged Nozzle detected Signal Mode Settings............................................................ 56
■ Head Maintenance Signal Mode Settings ....................................................................... 56
■ Printer Ready Signal Mode Settings ................................................................................. 56
■ Warning Signal Mode Settings .......................................................................................... 57
■ Error Signal Mode Settings................................................................................................. 57
■ Ink Low Signal Mode Settings............................................................................................ 57
■ Ink Cartridge Exchange Signal Mode Settings ............................................................... 57
6
■ Paper Out Signal Mode Settings ....................................................................................... 58
■ Mode Setting for Pause Signal .......................................................................................... 58
■ Mode Setting for Head Cleaning Signal .......................................................................... 58
■ Mode Setting for Clogged Nozzle Check Signal............................................................. 58
■ Mode Setting for Feed Signal ............................................................................................ 59
■ Mode Setting for Start Print Signal................................................................................... 59
■ Mode Setting for Re-print Signal ...................................................................................... 59
Appendix.........................................................................................................61
■ Cautions for Setting Jumpers ............................................................................................ 61
■ Figure of Jumper Settings and I/O Power Supply and Ground Connections ........... 62
I/O signal specifications when I/O power supply and SG are separated .....................................................63
■ Switching the I/O Power Supply and SG.......................................................................... 65
■ FAQ.......................................................................................................................................... 69
7
8
Chapter 1 Overview
External I/O (D-Sub25 pin)
Input signal
(Control of the printer)
Output signal
(Check the printer status)
Synchronize
USB or Ethernet (Used to transmit commands)
External device
Overview
This guide describes the external I/O specifications for the CW-C6000 Series/CW-C6500 Series. Please develop
your device to match these specifications.
Functionality
Using the external I/O signal allows the user to perform synchronous control of the printer and external devices
and to check the printer status.
Signal transmission between the printer and external device uses a D-Sub 25 cable.
Also, use a USB cable or Ethernet cable to send commands, which set the operation for the external I/O, from
the host PC.
System structure
1
A system using the external I/O can be structured as follows.
9
External device
The following external devices can be connected.
• Automatic application machine
• Roll rewinder
• Devices that must sync with the printer other than the above
The number of possible connections is one.
Q NOTE
10
External I/O Specification
This section describes the external I/O for the printer.
Connector
The external I/O connectors are as follows.
D-sub25 connector (female connector)
Screws: Metric screws
13 1
25 14
Chapter 2 External I/O Specification
Be sure to use the screws to affix the connection cable and ensure the cable does not fall out.
Q NOTE
Signal Definitions
Pulse signal
A pulse signal is a square wave with a fixed short-term width. A low active pulse is a signal that changes sharply
from High to Low, maintains a low state for a short period of time, and then sharply changes back to High. A
High active pulse is a signal that changes sharply from Low to High, maintains a High state for a short period of
time, and then sharply changes back to Low.
If a pulse signal meets the specification for pulse width, the time for the pulse width does not matter.
Pulse width of input signal
As shown in below, input pulse signals that can be received must have a pulse width of 20 msec or more.
Maintain the low state stable for a pulse width of 20 msec.
2
Min. 20 msec
11
Minimum interval between input pulse signals
Min. 50 msec
Proper operation
cannot be
guaranteed.
Min. 20 msec
As shown below, the interval between input pulse signals that can be received should be 50 ms or more.
Proper operation cannot be guaranteed if the input pulse signal is less than 50 msec.
Level signal
A level signal is a signal that maintains a Low and/or High state for a certain length of time, and refers to the
time during which that state is maintained. A Low active level signal changes from High to Low, and the time
during which it maintains the Low state is the active state. A High active level signal changes from Low to High,
and the time during which it maintains the High state is the active state. If both Low and High are significant,
both the Low state and the High state are each maintained for a certain length of time.
Minimum time input level signals that can be received are maintained
As shown below, input level signals that can be received must be maintained for 20 msec or more.
12
Chapter 2 External I/O Specification
Pin Assignment and Specification for I/O Signals
The pin assignment and specification for I/O signals are shown below.
Perform settings so that the specifications of the printer and external device match.
Input-
Pin Signal
1 Signal Ground - - Ground for I/O signals.
2 Reserved - - This signal is reversed for the system.
3 Reserved - -
4 Reserved - -
Output
*1
Pulse/Level Description
Set a jumper on CN100 to keep Signal Ground
and Frame Ground separate.
5 Reserved - -
6 Reserved - -
7 Signal Ground - - Ground for I/O signals.
Set a jumper on CN100 to keep Signal Ground
and Frame Ground separate.
8Ink Low
9 IO Power - - Provides 5 V (±10 %) power supply to external
10 Start print
*2
*3, 4
Output Level Indicates whether the printer is in an ink low
state.
• L: Ink low
• H: No ink low
devices.
The maximum current that can be provided is
180 mA.
Set a jumper on CN200 to provide an external I/
O power supply, while also keeping Signal
Ground and Frame Ground separate.
Input Pulse/Level Sends an instruction to start printing.
• In pulse mode, printing starts if a change from
High to Low is detected. Detection occurs
only when the state of the "End print" signal is
High, and does not occur while printing is in
progress.
To print a new label, first return the signal to
High, and then change it again from High to
Low.
• In level mode, printing starts if this signal is
Low. Detection occurs only when the state of
the "End print" signal is High. Printing of new
labels will continue until Low is detected.
• Signal logic: Low active
2
13
Pin Signal
Input-
Output
*1
Pulse/Level Description
11 Feed
12 Pause
*3
*3
13 Re-print
Input Level Sends an instruction to feed the paper.
• When the printer is in the Ready or Pause
state, the printer feeds paper if this signal is
Low.
• For labels, if this signal changes to High while
the printer is feeding paper, feeding will stop
when the edge of the next label is detected.
• For continuous paper, if this signal changes to
High while the printer is feeding paper,
feeding will stop after the detection time has
elapsed.
• Signal logic: Low active
Input Pulse Sends an instruction to pause the printer.
• The printer is paused if a change from High to
Low is detected.
• While the printer is paused, if a change from
High to Low is detected again, the printer will
be unpaused.
• Signal logic: Low active
*3
Input Pulse If the label reprinting function is enabled, an
instruction to reprint the label that was last
printed is sent from an external device.
• The label is reprinted if a change from High to
Low is detected.
• Signal logic: Low active
14 Clogged nozzle check
15 Head Cleaning
16 Warning
17 Error
*2
*3
*2
*3 *5
Input Pulse Sends an instruction to check the head for a
clogged nozzle.
• The head is checked for a clogged nozzle if a
change from High to Low is detected.
• Signal logic: Low active
Input Pulse Sends an instruction for head cleaning.
• The head is cleaned if a change from High to
Low is detected.
• Signal logic: Low active
Output Level Indicates whether the printer is in a warning
state.
• L: Warning
• H: No warning
Output Level Indicates whether the printer is in an error state.
• L: Error
• H: No error
14
Pin Signal
Input-
Output
*1
Chapter 2 External I/O Specification
Pulse/Level Description
18 End print
*2 *4
Output Pulse/Level The meaning of this signal varies depending on
the values that are set for end print signal mode,
as indicated below.
• Mode 0:
End print signal OFF (End print signal not
output)
• Mode 1:
Indicates that the printer feeds paper during
Low.
• Mode 2:
Indicates that the printer feeds paper during
High.
• Mode 3 (default):
Indicates that, for a pulse with a Low duration
of 20 msec, printing ends and the printer
feeds paper to the predetermined position.
• Mode 4:
Indicates that, for a pulse with a High
duration of 20 msec, printing ends and the
printer feeds paper to the predetermined
position.
* Refer to
pa
back
"Basic Timing for Label Printing" on
ge 49 for more information about whether
feeding is included when feeding paper.
2
19 Printer ready
20 Reserved - - This signal is reversed for the system.
21 Head maintenance
22 Ink cartridge exchange
23 Data ready
*2
*2
*2
*2
Output Level Indicates whether the printer is in the ready
state.
• L: Ready
• H: Not Ready
Output Level Indicates whether the printer is undergoing
head maintenance. During head maintenance,
the printer is undergoing either a nozzle check
or head cleaning.
• L: Head maintenance in progress
• H: Head maintenance not in progress
Output Level Indicates whether the printer requires an ink
cartridge exchange.
• L: Ink cartridge exchange required
• H: Ink cartridge exchange not required
Output Level Indicates that the generation of print data has
completed in the printer.
• L: Print data preparation complete
• H: Print data preparation not complete
15
Pin Signal
Input-
Output
*1
Pulse/Level Description
24 Clogged nozzle detected
25 Paper out
*2
*2 *5
Output Level Indicates whether the printer has detected a
clogged nozzle in the head.
• L: Clogged nozzle detected
• H: Clogged nozzle not detected
* The results of the previous nozzle check are
applied.
* Even if nozzle clogging is not specified (when
a nozzle check is not performed, or if a warning occurs while the state of the nozzles is
unclear), the value at that time is maintained.
Output Level Indicates whether the printer is in a paper out
state.
• L: Paper out
• H: No paper out
∗1 Input and output directions are described as viewed from the printer.
Input: Signal input to the printer from an external device.
Output: Signal output from the printer to an external device.
∗2 The logic for output signals can be reversed.
The information provided in the Description column is based on the default signal logic.
If the signal logic is reversed, it will be the opposite.
∗3 The logic for input signals is low active. (The logic for input signals cannot be reversed.)
∗4 The "Start print" signal and "End print" signal can be switched between pulse and level.
∗5 The results of the previous nozzle check are applied to the clogged nozzle detected signal (pin 24). Therefore,
during a nozzle check, issue a nozzle check command (pin 14) before checking the clogged nozzle detected signal
(pin 24). Refer to timing "Timing" on page 49.
16
Chapter 2 External I/O Specification
Printer side External device side
External device
output
Printer input
Specification for I/O Signals (I/O Power Supply/SG Not Separated)
This section describes the I/O signal (I/O power supply/SG not separated) specifications.
Refer to “"I/O signal specifications when I/O power supply and SG are separated" on page 63 for information
a
bout I/O signals (I/O power supply/SG separated).
Input/Output Item Value
Input signal to the printer Type of output port on the
external device
Low level VOL_max. 0.8 V
High level Sink current (leakage current) Max. 10 uA
Output signal from printer Type of output port on the
printer
Low level VOL_max. 0.8 V
High level VOH_min. 4.0 V
∗1 The sink current is also limited by the current limiting resistor (R = 1 kΩ).
∗2 Do not use this as a drive for a high-current load such as a coil.
∗3 This depends on the pull-up resistance (Rpu = 10 kΩ) of the printer and the input resistance of the external
device.
Regardless of whether an external device is connected or the connected external device is
CAUTION
turned on or off, when the printer is turned on, the power supply voltage and signal are output
from the I/O power supply pin and output signal pin of the external I/O connector. Connect an
external device under this assumption.
Open drain or open collector output
Sink current Min. 2 mA
Max. 7 mA
Open collector output (pull-up resistor is on the
printer)
Allowable sink current Max. 1.8 mA
*3
*1
*2
2
Example input signal circuit
+5 V
R
FGSG SG
17
Example output signal circuit
Printer side External device side
External device
input
Printer output
+5 V
Rpu
FGSG SG
18
Chapter 3 Commands
Commands
This section describes the commands of the external I/O. You can acquire each signal's mode settings and
printer setting values.
List of Commands
The signal specifications for the external I/O are as follows.
No.
1External I/O out-
2 Data ready signal mode setting ^S(CNA,A,c
3 Clogged nozzle detected signal
Command
name category
put signal settings
Command function Command and parameters
End print signal mode setting ^S(CNA,B,c
c = D/E/N/0 - 4
0/D: End print signal OFF (End print signal not
1: Normal: High, When feeding paper: Low
2/E: Normal: Low, When feeding paper: High
3: Normal: High, For 20 msec after printing:
4/N: Normal: Low, For 20 msec after printing:
c= D/E/0/1/2
0/D: Off
1: Normal: High, When an event occurs: Low
2/E: Normal: Low, When an event occurs: High
^S(CNA,D,c
mode setting
c= D/E/0/1/2
0/D: Off
1: Normal: High, When an event occurs: Low
2/E: Normal: Low, When an event occurs: High
output)
Low
High
3
4 Head maintenance mode setting ^S(CNA,M,c
c= D/E/0/1/2
0/D: Off
1: Normal: High, When an event occurs: Low
2/E: Normal: Low, When an event occurs: High
5 Printer ready signal mode setting ^S(CNA,O,c
c= D/E/0/1/2
0/D: Off
1: Normal: High, When an event occurs: Low
2/E: Normal: Low, When an event occurs: High
6 Warning signal mode setting ^S(CNA,W,c
c= D/E/0/1/2
0/D: Off
1: Normal: High, When an event occurs: Low
2/E: Normal: Low, When an event occurs: High
19
No.
Command
name category
Command function Command and parameters
7External I/O out-
put signal settings
8 Ink low signal mode setting ^S(CNA,J,c
9 Ink cartridge exchange signal
10 Paper out signal mode setting ^S(CNA,P,c
Error signal mode setting ^S(CNA,E,c
c= D/E/0/1/2
0/D: Off
1: Normal: High, When an event occurs: Low
2/E: Normal: Low, When an event occurs: High
c= D/E/0/1/2
0/D: Off
1: Normal: High, When there is little ink
2/E: Normal: Low, When there is little ink
^S(CNA,I,c
mode setting
c= D/E/0/1/2
0/D: Off
1: Normal: High, When ink must be
2/E: Normal: Low, When ink must be replaced:
c= D/E/0/1/2
0/D: Off
1: Normal: High, When there is no paper:
2/E: Normal: Low, When there is no paper:
remaining: Low
remaining: High
replaced: Low
High
Low
High
20
Chapter 3 Commands
No.
11 External I/O input
12 Head cleaning signal mode
13 Clogged nozzle check signal mode
14 Feed signal mode setting ^S(CNI,F,c
Command
name category
signal settings
Command function Command and parameters
Pause signal mode setting ^S(CNI,P,c
c= 0/1
0: Ignore pause signal.
1: Switch the pause state if Low is asserted
^S(CNI,C,c
setting
setting
c= 0/1
0: Ignore cleaning signal.
1: Clean if Low is asserted for the cleaning
^S(CNI,D,c
c= 0/1
0: Ignore clogged nozzle check signal.
1: Check for clogged nozzle if Low is
c= 0/3
0: Ignore feed label signal.
1: Continue feeding the label as long as Low
for the pause signal for 20 msec or longer.
signal for 20 msec or longer.
asserted for the clogged nozzle check signal for 20 msec or longer.
3
is asserted.
15 Mode setting for start print signal ^S(CNI,S,c
c= 0/1/3
0: Ignore start print signal. (Normal print
1: Issue a label if Low is asserted for the start
3: Continue issuing labels as long as Low is
16 Mode setting for re-print signal ^S(CNI,R,c
c= 0/1
0: Ignore reprint label signal.
1: Reprint the previously printed label if Low
mode in which the printer receives and
prints data, without using the start print
signal input to the external I/O.)
print signal for 20 msec or longer.
asserted for the start print signal.
is asserted for the reprint label signal for
20 msec or longer.
21
Loading...
