LabelWorks LW-Z700FK
DATASHEET
Sturdy and practical industrial label maker designed to boost
productivity at a highly competitive price
Destined to become a valuable tool for installers of mechanical, electrical and
network IT equipment is this sturdy, practical and cost-effective industrial label
maker. Featuring hot keys, a mixed label length function and other hands-free
features, label-making on the LW-Z700FK is all about boosting productivity with
the latest features, but at a competitive price.
Durable design
Aimed at tough environments, the LW-Z700FK has a hard carry case for
valuable protection, while a large carry handle makes it mobile.
Hands-free use
Hot keys cut-down on typing while repetitive jobs are streamlined thanks to its
innovative Pick & Print feature, which automatically prints the next label in a preset series when it detects that the user has selected the previous label.
Easy to use
With tape detection, an automatic cutter and Drop Stop function, labelling
cables, wiring, small pipes and other electrics or machinery has never been
easier.
Plenty of choice
The LW-Z700FK offers six different widths from 4-24mm, and 100 label designs.
Tapes are suited to all kinds of environments, with the addition of both magnetic
and heat-shrink tape to a roster that already includes heat-resistant, glow in the
dark, reflective and iron-on labels, among others.
Professional results
As well as fast-printing in 180dpi quality, the bundled Epson Label Editor
software makes it quick and simple to transfer a image of a company logo to the
LW-Z700FK for using on cable labels, adding a professional touch.
Economic to run
With smaller margins and tapes up to 9m long, the LW-Z700FK achieves an
impressively low total cost of ownership.
KEY FEATURES
Pick & Print
Streamline repetitive tasks
Fast 180dpi print
Professional-looking results
Practical design
Hard case, carry handle and magnet for
easy mounting
Print logos and images
Data download function with easy-touse software
Plenty of choice
50 lengths, six widths & 100 label
designs
PRODUCT SPECIFICATIONS
PRINTING
Embedded (standalone) Label Editor (computer linked)
Printing technology Thermal transfer
Tape width 4 mm, 6 mm, 9 mm, 12 mm, 18 mm, 24 mm
Printing resolution 180 dpi
Printable Dot Numbers 128 dot numbers
Print speed 30 mm/sec
Number of printable lines 8 Lines custom
Maximum text length 180 characters per line custom
Multi-block 50 custom
Drop Stop Yes
Pick & Print Yes
PRINT SETTINGS
Embedded (standalone) Label Editor (computer linked)
Special formats General, Punch Block, Patch Panel, Block-66, Wrap, Flag, Face Plate, Mix-Length
Repeat printing 2 - 99 1 - 999
Auto increment 0-9, a-z, A-Z, Up to 4 digits Yes, 0-9, a-z, A-Z, Alphabetic, Numerical,
Date, Time
Enlargement printing Yes Yes
Mirror printing Yes Yes
Vertical printing Yes Yes
Barcodes Code 128, Code 39, EAN-13, ITF, UPC-A, UPC-ECoda bar (NW-7), Code 128, Code 39, Data
Matrix, EAN-128, EAN-13, EAN-8, GS1-128,
GS1-DataBar, ITF, MaxiCode, PDF417, QR
Code, UPC-A, UPC-E
Wire wrap Yes Yes
Flag Yes Yes
Margin setting 1mm, 3mm, 4mm, 10mm, width/3, width 1mm, Manual, Auto
FONTS & STYLES
Embedded (standalone) Label Editor (computer linked)
Fonts Roman, Sans serif Depending on user's PC
Frames 98 Frames Tables 3 Tables Layout Alignment Left, Right, Center, Justified Left, Right, Center, Manual
Character spacing Narrow, Wide, Normal Character width Narrow, Normal, Custom, Smaller, Small, Wide -
MEMORY
Embedded (standalone) Label Editor (computer linked)
Memory alphanumeric - Depending on user's PC
Memory accent - Depending on user's PC
Accent learning Yes Symbols 530 1,427
Saved Label Design 100 Depending on user's PC / 372 templates
available
Last label Yes View history, Browse
HARDWARE
Embedded (standalone) Label Editor (computer linked)
Cutter Auto, Half
Detection Cover open, Tape end, Tape type & colours, Tape width
Handle Yes
Power lamp Yes
Feed button Yes
KEYBOARD
Embedded (standalone) Label Editor (computer linked)
Keyboard type QWERTY
Number of keys 66
DISPLAY
Embedded (standalone) Label Editor (computer linked)
Display Resolution 140 x 80 dots
Display backlight Yes( with control)
Display preview Yes Graphic
Display language Danish, Dutch, English, Finnish, French, German, Italian, Portuguese
OTHER FUNCTIONS
Embedded (standalone) Label Editor (computer linked)
Auto power off Yes Yes
Unit switch mm/inch mm/inch
Clock No -
LabelWorks LW-Z700FK
WHAT'S IN THE BOX
1 x 4m Tape
AC adapter
AC cable
Battery (OT-BY20)
Carrying Case
Magnetic attachment
Main unit
USB cable
UK AC cable
PRODUCT SPECIFICATIONS
GENERAL
Batteries 6 x AAA, Not included
Battery Li-ion
Low battery indicator Yes
Product dimensions 136 x 298 x 90 mm (Width x Depth x Height)
Product weight 1,100 g, without tape & batteries
Colour Black, Red
CONNECTIVITY
Interfaces USB 1.1 Type A, USB 1.1 Type B
Compatible Operating
Systems
System requirements Approx. 100 MB HDD space
PC Display requirements XGA (1024 x 768) or higher
Included Software Epson Label Editor
Embedded (standalone) Label Editor (computer linked)
Embedded (standalone) Label Editor (computer linked)
Windows 10, Windows 7, Windows 8.1
LabelWorks LW-Z700FK
SUPPORTED CONSUMABLES
LabelWorks LW-Z700FK
Tape Width Tape Series
4 mm Heat Shrink Tube (HST) Tape Abc 123 LK-4WBA3
4 mm Heat Shrink Tube (HST) Tape Abc 123 LK-4YBA3
4 mm Standard Abc 123 LK-1WBN
4 mm Pastel color Abc 123 LK-1YBP
6 mm Transparent Abc 123 LK-2TBN
6 mm Pastel color Abc 123 LK-2RBP
6 mm Standard Abc 123 LK-2WBN
6 mm Pastel color Abc 123 LK-2YBP
9 mm Strong adhesive Abc 123 LK-3TBW
9 mm Strong adhesive Abc 123 LK-3WBW
9 mm Pastel color Abc 123 LK-3YBP
9 mm Pastel color Abc 123 LK-3RBP
9 mm Standard Abc 123 LK-3WBN
9 mm Transparent Abc 123 LK-3TBN
9 mm Standard Abc 123 LK-3WRN
9 mm Strong adhesive Abc 123 LK-3YBW
12 mm Heat Resistant Abc 123 LK-4WBH
12 mm Satin Ribbon Tape Abc 123 LK-4LBK
12 mm Transparent Abc 123 LK-4TWN
12 mm Satin Ribbon Tape Abc 123 LK-4RKK
12 mm Transparent Abc 123 LK-4TBN
12 mm Fluorescent Abc 123 LK-4YBF
12 mm Heat Shrink Tube (HST) Tape Abc 123 LK-4WBA5
12 mm Strong adhesive Abc 123 LK-4YBW
12 mm Iron-on Abc 123 LK-4WBQ
12 mm Metallic color Abc 123 LK-4KBM
12 mm Strong adhesive Abc 123 LK-4TBW
12 mm Pastel color Abc 123 LK-4RBP
12 mm Satin Ribbon Tape Abc 123 LK-4PBK
12 mm Matte Abc 123 LK-4SBE
12 mm Matte paper Abc 123 LK-4WBB
12 mm Metallic color Abc 123 LK-4SBM
12 mm Standard Abc 123 LK-4WBN
12 mm Vivid Abc 123 LK-4BWV
12 mm Strong adhesive Abc 123 LK-4WBW
12 mm Fluorescent Abc 123 LK-4GBF
12 mm Standard Abc 123 LK-4WRN
12 mm Satin Ribbon Tape Abc 123 LK-4HKK
12 mm Heat Shrink Tube (HST) Tape Abc 123 LK-4YBA5
12 mm Satin Ribbon Tape Abc 123 LK-4KBK
12 mm Pastel color Abc 123 LK-4YBP
12 mm Standard Abc 123 LK-4WLN
18 mm Glow-in-the-Dark Abc 123 LK-5ZBU
18 mm Fluorescent Abc 123 LK-5GBF
18 mm Standard Abc 123 LK-5WRN
18 mm Pastel color Abc 123 LK-5RBP
18 mm Standard Abc 123 LK-5WBN
18 mm Matte Abc 123 LK-5SBE
18 mm Pastel color Abc 123 LK-5YBP
18 mm Reflective Abc 123 LK-5SBR
18 mm Magnetic Label Tape Abc 123 LK-5WB2
18 mm Transparent Abc 123 LK-5TBN
18 mm Strong adhesive Abc 123 LK-5WBW
18 mm Strong adhesive Abc 123 LK-5TBW
18 mm Fluorescent Abc 123 LK-5YBF
18 mm Transparent Abc 123 LK-5TWN
18 mm Vivid Abc 123 LK-5BWV
18 mm Strong adhesive Abc 123 LK-5YBW
18 mm Magnetic Label Tape Abc 123 LK-5YB2
24 mm Standard Abc 123 LK-6WBN
24 mm Matte Abc 123 LK-6SBE
24 mm Transparent Abc 123 LK-6TBN
24 mm Heat Shrink Tube (HST) Tape Abc 123 LK-6YBA14
24 mm Magnetic Label Tape Abc 123 LK-6WB2
24 mm Pastel color Abc 123 LK-6RBP
24 mm Heat Shrink Tube (HST) Tape Abc 123 LK-6WBA11
24 mm Heat Shrink Tube (HST) Tape Abc 123 LK-6YBA11
24 mm Heat Shrink Tube (HST) Tape Abc 123 LK-6WBA14
24 mm Pastel color Abc 123 LK-6YBP
24 mm Cable wrap Abc 123 LK-6WBC
24 mm Magnetic Label Tape Abc 123 LK-6YB2
Tape & Text (Ink Ribbon)
Colour
Customer Code
LOGISTICS INFORMATION
SKU C51CF25110
EAN code 8715946621401
Multiple Order Quantity 1 Units
Country of Origin China
