WorkForce Pro
WF-6590D2TWFC
DATASHEET
Save time, money and energy with this high-capacity colour 4in-1 printer, offering increased productivity and reduced
intervention for busy offices.
Streamline document capturing and distribution, increase producitivity, reduce
intervention, printing costs and environmental impact with this scalable and
versatile business multifunction. With advanced 4-in-1 copy, scan, fax and
colour duplex printing features, the WF-6590DWF promises fast scan speeds
and a first page out time of just seven seconds1.
Environmentally-conscious
With up to 80% lower energy consumption than competitive colour lasers2, the
WF-6590DWF cuts your environmental impact. Relying on clean technology, it
produces no fan noise when not printing, no heat and no ozone gas.
Low running costs
With an up to 50% lower cost per page and a lower total cost of ownership
compared to competitive colour laser printers3, the WF-6590DWF will save
businesses money. Duplex printing and copying also saves paper.
Less intervention and high reliability
Using Epson's XXL ink cartridges, you can print up to 10,000 pages in black
and 7,000 pages in colour, which is equal to or better than colour laser
equivalents4. The maximum paper capacity of 1,581 pages means less time
spent refilling.
Fast printing and scanning
With a colour first page out time of just seven seconds1, the WF-6590DWF is
perfect for printing small print jobs quickly. Fast scan speeds and one-pass
scanning make jobs even more efficient.
Advanced document management
IT departments can take full control, customising it to automate job profiles and
workflow processes using Document CapturePro and ProServer software5 and
connecting to most document management systems.
KEY FEATURES
Save energy
Up to 80% lower energy consumption
than competitive colour lasers
XXL ink cartridges
Print up to 10,000 black & 7,000 colour
4
pages
Fast printing
Print a colour page in just 7 seconds
Save money
Up to 50% lower cost per page than
competitive colour laser printers
Smart control
Print & scan from mobile devices with
NFC connectivity
6
2

PRODUCT SPECIFICATIONS
GENERAL
Energy Use 17 W (Ready), 0.4 W (Power off), 39 W (standalone copying, ISO/IEC 24712 pattern), 2.4 W
Product dimensions 516 x 522 x 1,175 mm (Width x Depth x Height)
Compatible Operating
Systems
TECHNOLOGY
Printing Method PrecisionCore™ Print Head
Minimum Droplet Size 3.7 pl, With Variable-Sized Droplet Technology
Ink Technology DURABrite™ Pro
PRINT
First Page Out Monochrome 7 Seconds, Colour 7 Seconds
Printing Speed ISO/IEC 24734 24 Pages/min Monochrome, 24 Pages/min Colour
Duplex Printing Speed
ISO/IEC 24734
Maximum Printing Speed 34 Pages/min Colour (plain paper), 34 Pages/min Monochrome (plain paper)
Printing Resolution 4,800 x 1,200 dpi
Max Duty cycle 65,000 Pages per month
Colours Black, Cyan, Yellow, Magenta
For detailed information on printing speeds please visit http://www.epson.eu/testing.
SCAN
Scanning Resolution 1,200 dpi x 2,400 dpi (Horizontal x Vertical)
Optical Resolution (ADF) 1,200 dpi x 2,400 dpi (Horizontal x Vertical)
Output formats JPEG, TIFF, PDF
Scanner type Contact image sensor (CIS)
FAX
Type of fax Walk-up black and white and colour fax capability
Fax speed dials (max) 200 names and numbers
Page memory Up to 550 pages/ 6MB (ITU-T No. 1 chart)
Fax Functions PC Fax, Fax to E-mail, Memory Reception, Auto Redial, Speed Dial
CONNECTIVITY
Interfaces Hi-Speed USB - compatible with USB 2.0 specification, Ethernet Interface (1000 Base-T/ 100-
WLAN Security WEP 64 Bit, WEP 128 Bit, WPA PSK (AES), WPA2 Enterprise
PAPER / MEDIA HANDLING
Paper Formats A4, A5, A6, B5, C4 (Envelope), C6 (Envelope), No. 10 (Envelope), Letter, 10 x 15 cm, 13 x 18
Automatic Document Feeder 50 Pages
Duplex Yes
Output Tray Capacity 250 Sheets
Paper Tray Capacity 1,581 Sheets Standard, 1,581 Sheets maximum
Number of paper trays 3
ADDITIONAL FEATURES
LCD screen Type: Color, Touchscreen, Diagonal: 10.9 cm
(sleep mode), TEC 0.6 kWh/week
Linux, Mac OS 10.6+, Mac OS 10.7.x, Mac OS 10.8.x, Microsoft Windows XP (Home Edition /
Prof / Prof X64 / Vista), Windows Server 2003 (32/64bit), Windows Server 2008 (32/64bit),
Windows Server 2008 R2, Windows Server 2012 (64bit)
16 A4 Pages/min Monochrome, 16 A4 Pages/min Colour
Base TX/ 10-Base-T), USB host, Wireless LAN IEEE 802.11b/g/n, Wi-Fi Direct, Gigabit ethernet
interface, Ethernet interface (100 Base-TX / 10 Base-T), Near Field Communication (NFC)
cm, 20 x 25 cm, 16:9, Legal
WorkForce Pro WF-6590D2TWFC
WHAT'S IN THE BOX
Quick Setup Guide
Individual Ink Cartridges
Main unit
Warranty Documents
User manual (CD)
Power cable
Paper tray

SUPPLIES
Maintenance Box C13T671200
Ink Cartridge XL Black C13T908140
WF-6xxx Ink Cartridge Black XXL C13T907140
Ink Cartridge XL Cyan C13T908240
WF-6xxx Ink Cartridge Cyan XXL C13T907240
Ink Cartridge XL Magenta C13T908340
WF-6xxx Ink Cartridge Magenta XXL C13T907340
Ink Cartridge XL Yellow C13T908440
WF-6xxx Ink Cartridge Yellow XXL C13T907440
WF-6xxx Series Optional Cassette Maintenance Roller C13S210047
WF-6xxx Series Standard Cassette Maintenance Roller C13S210046
Business Paper 80gsm 500 sheets A4 C13S450075
LOGISTICS INFORMATION
SKU C11CD49301BX
EAN code 8715946621234
WorkForce Pro WF-6590D2TWFC
For more information please contact:
Telephone: 01952 607111 (UK)+
01 436 7742 (Republic of Ireland)
E-mail: enquiries@epson.co.uk
Chat: etalk.epson-europe.com
Fax: 0871 222 6740
+ Local call rate.
Trademarks and registered trademarks are the property of Seiko Epson Corporation or their respective owners.
Product information is subject to change without prior notice.
Web: www.epson.co.uk
www.epson.ie
1. Determined in accordance with ISO/IEC 17629 showing
the average of FPOT(sec) from the Office Category Test for
default A4 simplex and duplex. For more information,
please visit www.epson.eu/testing
2. + 3. For more information visit
www.epson.eu/inkjetsaving
4. Approx. page yield based on ISO/IEC 24711 tests in
default mode and single sided continuous printing
methodology, using the monochrome test pattern provided in
ISO/IEC 19752. Actual yield will vary depending on images
printed and usage conditions. For more information visit
www.epson.eu/pageyield
5. Requires download from Epson website
6. Please visit www.epson.eu/epe for more information.
Near Field Communication requires Epson iPrint app,
available from Epson website for Android devices.
