EPOX MVP4G Instructions Manual

TRADEMARK

All products and company names are trademarks or registered
trademarks of their respective holders.

These specifications are subject to change without notice.

Manual Revision 6.0

September 17, 1999

MVP4G

ISA/PCI Motherboard with Onboard AGP

VGA PCI Audio, PCI IDE and Super

Multi-I/O

FeaturesMVP4G

Page 2

FEATURES

MVP4G Features:

•Intel Pentium

®

Processor, Pentium Processor with MMX technology, AMD

K5/K6, Cyrix 6x86L/6x86MX & idt C6 operating at 133 ~ 450 MHz with
321 ZIF socket 7 provides scalability to accept faster Processors in the

future.

•Designed with VIA MVP4 AGPset.

•Supports up to 768 Mega of DRAM (minimum of 16 MB) on board, You can

use 168-pin DIMM x 3. It will automatically detect Extended Data Output
(EDO) DRAM at 66MHz only or Synchronous DRAM memory (SDRAM) at
66MHz or 100MHz

•Supports (1) 16 bit ISA slots, (4) 32 bit PCI slots, (1)AMR and provides

(2) independent high performance PCI IDE interfaces capable of supporting PIO

Mode 3/4 and Ultra DMA 33/66 devices. The MVP4G supports (2) PCI
Bus Master slots and a jumperless PCI INT# control scheme which reduces
configuration confusion when plugging in PCI card(s).

•Supports ATAPI (e.g. CD-ROM) devices on both Primary and Secondary IDE

interfaces.

•Designed with lntegrated Multi I/O: (1) floppy port, (1) parallel port (EPP,

ECP), and (2) serial ports (16550 Fast UART).
Note: Japanese “Floppy 3 mode” is also supported

•Features Award Plug & Play BIOS. With Flash Memory you can always

upgrade to the current BIOS as they are released.

•MVP4G utilizes a Lithium battery which provides environmental protection

and longer battery life.

• Software power-down when using Windows

®

95/98.

• Supports ring-in feature (remote power-on through external modem,

allows system to be turned on remotely).

FeaturesMVP4G

Page 3

•Resume by Alarm - Allows your system to turn on at a preselected time.

•Supports CPU Hardware sleep and SMM (System Management Mode).

•Supports Keyboard power ON function (KBPO).

•Supports USDM software to offer motherboard various status.

•Supports the CPU and Chassis fan Auto stop in sleep mode.

•Built-in WOL (Wake On LAN) Connector.

• Built-in Sound Blaster/DirectSound AC97 Audio.

• Built-in AGP 2D/3D Graphics Accelerator.
