EPOX MU-8KHA0010 User Manual
TRADEMARK
All products and company names are trademarks or registered
trademarks of their respective holders.
These specifications are subject to change without notice.
Manual Revision 1.0
May 09, 2001
An An
An An
An
AMD SocAMD Soc
AMD SocAMD Soc
AMD Soc
kk
kk
k
et et
et et
et
A PrA Pr
A PrA Pr
A Pr
ocessor basedocessor based
ocessor basedocessor based
ocessor based
mainboard (100/133MHz)mainboard (100/133MHz)
mainboard (100/133MHz)mainboard (100/133MHz)
mainboard (100/133MHz)
SupporSuppor
SupporSuppor
Suppor
ts PC1600/PC2100 Memorts PC1600/PC2100 Memor
ts PC1600/PC2100 Memorts PC1600/PC2100 Memor
ts PC1600/PC2100 Memor
y Modulesy Modules
y Modulesy Modules
y Modules
User’User’
User’User’
User’
ss
ss
s
ManualManual
ManualManual
Manual
$ &0
T able of Contents
Section 1 Introduction
Components Checklist ........................................ 1-1
Overview
AMD DuronTM & AthlonTM Processors ............. 1-2
Accelerated Graphics Port .................................. 1-3
Ultra ATA66/100 ................................................. 1-3
Hardware Monitoring ..........................................1-3
Mainboard Form-Factor ...................................... 1-4
I/O Shield Connector .......................................... 1-5
Power-On/Off (Remote) ..................................... 1-5
System Block Diagram........................................ 1-6
Section 2 Features
Mainboard Features ............................................. 2-1
Section 3 Installation
Mainboard Detailed Layout ................................. 3-2
Easy Installation Procedure
CPU Insertion ...................................................... 3-3
Jumper Settings ................................................... 3-5
System Memory Configuration .......................... 3-6
Device Connectors .............................................. 3-8
STR (Suspend To RAM) Function ....................... 3-11
Section 4 Award BIOS Setup
BIOS Instructions................................................. 4-1
Standard CMOS Setup ......................................... 4-2
Advanced BIOS Features..................................... 4-3
Advanced Chipset Features ................................. 4-7
Page
Integrated Peripherals ......................................... 4-10
Power Management Setup ................................... 4-14
PNP/PCI Configuration Setup .............................. 4-17
PC Health Status .................................................. 4-19
Frequency/Voltage Control .................................. 4-20
Defaults Menu ..................................................... 4-21
Supervisor/User Password Setting ...................... 4-22
Exit Selecting ........................................................ 4-23
Section 5 Driver Installation
Easy Driver Installation ........................................ 5-1
Appendix
Appendix A
GHOST 5.1/6.03 Quick Users Guide .................... A-1
Appendix B
POST Codes......................................................... B-1
Appendix C
EEPROM BIOS Remover ................................... C-1
Appendix D
Update Your System BIOS .................................. D-1
Introduction
Page 1-1
Section 1
INTRODUCTION
Components Checklist
99
99
9 A. (1) Mainboard
99
99
9 B. (1) Users manual
99
99
9 C. (1) Floppy ribbon cable
99
99
9 D. (1) ATA-66/100 Hard drive ribbon cable
99
99
9 E. (1) USB Cable
99
99
9 F. (1) Driver and utility
99
99
9 G. (1) ATA-33 Hard drive ribbon cable
A
B
USERS
MANUAL
F
or
D
C
E
G
Introduction
Page 1-2
Over view
AMD DuronTM & AthlonTM Processors
The AMD AthlonTM is a seventh-generation micro architecture with an integrated
L2 cache, which is powerful enough to support the bandwidth requirements of a
large range of applications, hardware, graphics, and memory technologies. These
processors implement advanced design techniques such as:
Socket A (PGA 462)
200/266MHz system interface based on the Alpha EV6 bus protocol.
Three out-of-order, superscalar, pipelined Multimedia Units.
Three out-of-order, superscaler, pipelined Integer Units.
Fixed-sized internal instruction formats (MacroOPs).
72-entry Instruction Control Units.
AMD enhanced 3DNow! technology
L1 and L2 caches.
Dynamic branch prediction.
Socket A is the name for AMDs new socketed interface designed to support both
AMD DuronTM and AMD AthlonTM processors. This innovation is made possible
by integrating the L2 cache memory on chip with the processor. Socket A will
help enable smaller enclosures, and ultimately result in a wider variety of solutions in the market.
The AMD DuronTM & AthlonTM processors in the Socket A format continue to
deliver the ultimate performance for cutting-edge applications. Both bring to
desktop systems running industry-standard x86 software superscalar RISC
performance. Being provided in the Socket A format they are the worlds most
powerful x86 processors. They easily deliver the highest integer, floating-point,
and 3D multimedia performance for applications running on x86 platforms
around.
Introduction
Page 1-3
The AMD DuronTM processor is derived from the AMD AthlonTM processor core.
It features full-speed, on-chip cache memory, a 200MHz front side system bus,
and enhanced 3DNow! technology. Although both processors are related, there
are key differences. The AMD AthlonTM processor is targeted at the performance
segment, and as such will have more cache memory and higher clock speeds.
Accelerated Graphics Port
(AGP or A.G.P.)
Typically, 3D graphics rendering requires a tremendous amount of memory, and
demands ever increasing throughput speed as well. As 3D products for the
personal computer become more and more popular, these demands will only
increase. This will cause a rise in costs for both end users and manufacturers.
Lowering these costs as well as improving performance is the primary motivation
behind AGP. By providing a massive increase in the bandwidth available between
the video card and the processor, it will assist in relieving some of these pressures
for quite sometime.
Ultra ATA/66/100
The board provides two channel (one channel is optional) Ultra ATA/66/100 Bus
Master IDE controller, that support Ultra ATA/66/100 protocols, perfect for such
demanding applications as real-time video, multimedia, and high performance
operating system. A new IDE cable is required for Ultra ATA/66/100. This cable
is an 80 conductor cable; however the connectors are, of course, backwards
compatible with ATA/33.
Hardware Monitoring
Hardware monitoring allows you to monitor various aspects of your systems
operations and status. The features include CPU temperature, voltage and RPM of
fan.
Introduction
Page 1-4
Mainboard Form-Factor
The board is designed with ATX form factor - the new industry standard of chassis.
ATX form factor is essentially a Baby-AT baseboard rotated 90 degrees within the
chassis enclosure and a new mounting configuration for the power supply. With
these changes the processor is relocated away from the expansion slots, allowing
them all to hold full length add-in cards. ATX defines a double height aperture to
the rear of the chassis which can be used to host a wide range of onboard I/O.
Only the size and position of this aperture is defined, allowing PC manufacturers
to add new I/O features (e.g.; TV input, TV output, joystick, modem, LAN, etc.) to
systems. This will help systems integrators differentiate their products in the
marketplace, and better meet your needs.
Smaller size promotes a smaller system size.
I/O shield does not need to be retooled in an ATX 2.01 or later. The
mainboard should be used in an ATX 2.01 (or later) compliant case.
A smaller power supply can be used. High integration on mainboard
reduces the system costs.
PCI slots
Expandable I/O
5 1/4"
Bay
3 1/2"
Bay
Figure 2: Summary of ATX chassis features
CPU
Single chassis
fan for system
AT X
Power
Supply
ATX power connector
Floppy / IDE
connectors
AGP slot
Introduction
Page 1-5
Power-On/Off (Remote)
The board has a single 20-pin connector for ATX power supplies. For ATX power
supplies that support the Remote On/Off feature, this should be connected to the
systems front panel for system Power On/Off button. The systems power On/Off
button should be a momentary button that is normally open.
The board has been designed with Soft Off" functions. You can turn Off the
system from one of two sources: The first is the front panel Power On/Off
button, and the other is the "Soft Off" function (coming from the M/Bs onboard
circuit controller) that can be controlled by the operating system such
asWindows® 95/98/SE/ME or Windows®2000.
Figure 4: Simple ATX Power ON/OFF Controller
J 3
ATX
POWER SUPPLY
Case (chassis) Power
ON/OFF button (J 3)
I/O Shield Connector
The board is equipped with an I/O back panel. Please use the appropriate I/O
shield (figure 3).
Figure 3: I/O back panel layout
MIC
parallel port
Joystick/Midi port
USB port
COM1
COM2
Speaker
Line_in
PS/2 Mouse
PS/2
KEYBOARD
Introduction
Page 1-6
Figure 5: System Block Diagram
System Block Diagram
PAC
PCI Bridge
and me m ory
controller
VT8366
266/200MHz
DDR SDRAM
133/100MHz
66MHz
4X
AMD
Socket A
Processors
VT8233
I/O Bridge
)+
'%
USB 0,1 USB 2,3
USB 4,5
Mouse
Keyboard
LPC
W83697
Serial Port 1
Serial Port 2
LPT Port
FDD
1,-
1,-
HDD
(ATA-66/100)
V_Link
MA [0:13]
MDS [0:7]
MD [0:63]
.A=JKHAI
Page 2-1
Section 2
FEATURES
Mainboard Features:
PROCESSOR
- AMD Athlon TM, Duron
TM
Processors, Socket A, operating at 600MHz ~
1.1GHz
CHIPSET
- VIA KT266 AGPset (VT8366 + VT8233)
DRAM MODULE
- 184pin DDR DIMM x 3 for PC1600/2100 Memory
- DRAM Size: 64MB to 1.5GB
EXPANSION SLOT
- PCI x 6, 4X AGP x 1
ONBOARD I/O
Winbond 83697HF LPC I/O integrated with
- FDD, Parallel and Serial, Fast IR
ONBOARD PCI / IDE
- PCI Bus IDE Port with PIO /Ultra DMA-100x 2 (Up to 4 Devices)
I/O CONNECTOR
- PS/2 Mouse and PS/2 style Keyboard
- COM1, COM2, Printer, Audio-in/out, MIC & Game Port connectors
USB
- USB connector x 6 (4 for Opt.)
.A=JKHAI
Page 2-2
BIOS
- Award Plug & Play BIOS
Built-in AC97 Digital Audio (by VIA VT8233)
- Dual full-duplex Direct Sound channels
- H/W Sound Blaster Pro for DOS legacy compatibility
- FM synthesis for legacy compatibility
- Supports game and MIDI port
EXTENDED FUNCTION
- Supports Hardware Monitoring Function
- Supports exclusive KBPO(KeyBoard Power On)
- Supports CPU Vcore/VIO(2.5V) setting via BIOS
- Supports CPU Clock settings via BIOS
- Supports STR (Suspend To RAM) power saving Function
- Supports Wake-On-LAN Function
- Supports Wake-On-Modem Function
- P80P Debug (POST) Card onboard design with 7-Segment display
FORM FACTOR
- 305mm x 245mm ATX Size
Installation
Page 3-1
Installation
Page 3-2
Figure 1
Mainboard Detailed Layout
Section 3
INSTALLATION
Installation
Page 3-3
Easy Installation Procedure
The following must be completed before powering on your new system:
3-1. CPU Insertion
3-2. Jumper Settings
3-3. System memory Configuration
3-4. Device Connectors
3-5. STR Function
Section 3-1
CPU Insertion
CPU Insertion: (use AMD AthlonTM as reference)
Step 1
Open the socket by raising the actuation
lever.
Figure 2
Step 2
Insert the processor.
Ensure proper pin 1 orientation by aligning
the FC-PGA corner marking with the socket
corner closest to the actuation arm tip. The
pin field is keyed to prevent mis-oriented
insertion.
Dont force processor into socket. If it does
not go in easily, check for mis-orientation and
debris.
Make sure the processor is fully inserted
into the socket on all sides.
Figure 3
Installation
Page 3-4
Step 3
Close the socket by lowering and
locking the actuation lever.
Figure 4
Figure 5
Step 4
Thermal compound and qualified heatsink recommended by AMD are a must to
avoid CPU overheat damage. For more information about installing your CPU,
please refer to the AMD website article Socket A AMD processor and Heatsink
Installation Guide http://www.amd.com/products/cpg/athlon/pdf/23986.pdf.
Installation
Page 3-5
JCK1
CPU Host Clock Select
= 1-2 100MHz (Default)
= 2-3 133MHz
LED2
LED1
Debug card on board
(Please refer to Appendix B
for POST codes)
Section 3-3
Jumper Settings
The mainboard was designed with very few jumpers to make your installation
faster and easier.
JBAT1
CMOS Clear
= 1-2 Normal (Default)
= 2-3 Clear CMOS
Installation
Page 3-6
Section 3-4
System Memory Configuration
Memory Layout
The board supports (3) PC1600/2100 184-pin DIMMs (Dual In-line Memory
Module). The DIMMs is for DDR SDRAM (Double-Data-Rate Synchronous
DRAM) only.
Figure 6 and Table 1 show several possible memory configurations.
DDR DIMM 1
DDR DIMM 2
Bank 0/1
DDR
Synchronous
DRAM
Bank 2/3
DDR DIMM 3
Bank 4/5
yromeMlatoT
1MMIDRDD
)1/0knaB(
2MMIDRDD
)3/2knaB(
3MMIDRDD
)5/4knaB(
BM215=
mumixaM
*MARDSRDD
,BM652,BM821,BM46
1XBM215
enoN
BG1=
mumixaM
*MARDSRDD
,BM652,BM821,BM46
1XBM215
*MARDSRDD
,BM652,BM821,BM46
1XBM215
enoN
BG5.1=
mumixaM
*MARDSRDD
,BM652,BM821,BM46
1XBM215
*MARDSRDD
,BM652,BM821,BM46
1XBM215
*MARDSRDD
,BM652,BM821,BM46
1XBM215
Figure 6
Table 1
* DDR SDRAM supports 64, 128, 256, 512MB DIMM modules.
* We recommend using PC1600 Memory Module only for front-side bus
100MHz.
* DO NOT MIX the unbuffered and registered DDR SDRAM on DIMM1 ,
DIMM2 and DIMM3 socket.
* Supports PC1600 modules with 2-2-2 timing.
* Supports PC2100 modules with 2-2-2 timing.
Installation
Page 3-7
DIMM Module Installation
Figure 7 displays the notch marks and what they should look like on your DDR
DIMM memory module.
DIMMs have 184-pins and one notche that will match with the onboard DDR
DIMM socket. DIMM modules are installed by placing the chip firmly into the
socket at a 90 degree angle and pressing straight down (figure 8) until it fits tightly
into the DIMM socket (figure 9).
Figure 7
Figure 9
DIMM Module clip after installation
To remove the DIMM module simply press down both of the white clips on either
side and the module will be released from the socket.
Figure 8
DIMM Module clip before installation
CENTER KEY ZONE
(2.5 V DRAM)
Installation
Page 3-8
Section 3-5
Device Connectors
Figure 10
J2,J3: Chassis Panel Connector
Power_LED, Speaker, Reset, Power ON/Off, Turbo LED, HDD LED,
IR Conn.,
FAN1: CPU Fan
A plug-in for the CPU Fan Power
FAN2: Chassis Fan
A plug-in for the chassis Fan Power
FAN3: Power Fan
A plug-in for the Power Supply Fan Power
WOL1: WOL (Wake On LAN) Connector
WOM1:WOM (Wake On Modem) Connector
IDE1: Ultra ATA-100 Primary IDE Connector (Blue Color)
IDE2: Ultra ATA-100 Secondary IDE Connector (Blue Color)
FDD1: Floppy Controller Connector (Black Color)
PW1: ATX Power Connector
20-pin power connector
CD1: CD Audio_IN Connector
Pin1(CD_IN_Left), Pin2/Pin3(CD_Reference), Pin4(CD_IN_Right)
MIC
parallel port
Joystick/Midi port
USB port
COM1
COM2
Speaker
Line_in
PS/2 Mouse
PS/2
KEYBOARD
Installation
Page 3-9
AUX1: Auxiliary Line_IN Connector
Pin1(Left Line_IN), Pin2/Pin3(GND), Pin4(Right Line-IN)
MODEM1: Telephony Connector for Modem audio output.
Pin1(Audio_in), Pin2/Pin3(GND), Pin4(Mic-out to Modem)
#NIProloceriWemaNlangiStnemmoC
1deRccVrewoPelbaC
2etihWataD-ataD
3neerGataD+ataD
4kcalBdnuorGdnuorGelbaC
5kcalBdnuorGdnuorGesaC
6kcalBdnuorGdnuorGesaC
7kcalBdnuorGdnuorGelbaC
8neerGataD+ataD
9etihWataD-ataD
01deRccVrewoPelbaC
USB port header pin descriptions.
VCC
VCC
GND
GND
-Data
-Data
+Data
+Data
#
$
USB2/3:USB port header pins for adding four additional USB ports.
Installation
Page 3-10
Device Connectors (continued)
Reset - Closed to restart system.
(This is connected to the power button on the case. Using the Soft-Off
by Pwr-BTTN feature, you can choose either Instant Off (turns system
off immediately), or 4 sec delay (you need to push the button down for
4 seconds before the system turns off). When the system is in 4 sec
delay mode, suspend mode is enabled by pushing the button
momentarily.)
Turbo LED indicator - LED ON when higher speed is selected
IDE LED indicator - LED ON when Onboard PCI IDE Hard disks is
activate
J3
1
+
+
IR Connector
1. VCC 4. GND
2. NC 5. IRTX
3. IRRX
1
Power On/Off
J2
Speaker -
Connect to the system's speaker for beeping
1. Speaker 3. GND
2. N/C 4. GND
Power LED - Power LED connector
1. Power LED(+) 4. NC
2. N/C 5. GND
3. GND
1
1
1
Installation
Page 3-11
3-6 STR (Suspend To RAM) Function
The board supports the STR power management state by maintaining the
appropriate states on the DDR SDRAM interface signals. The power source
must be kept alive to the DDR SDRAM during STR (ACPI S3). Advanced
Configuration Power Interface (ACPI) provides more Energy Saving Features
for operating systems that supporting Instant ON and QuickStartTM function.
1. To enable the ACPI function and use the STR functionally to save your system
energy, you are recommended to confirm the following requirements:
a. Please do install all ACPI qualified add-on cards such as AGP, LAN,
Modem cards.
b. In BIOS, please select ACPI function: Enable and ACPI Suspend Type:
S3(STR) in the Power Management Setup menu.
c. Then, please install the Windows® 98SE/ME or Windows® 2000.
d. Restart your system.
e. Getting in to the Advanced of the Power Management icon of Control
Panel, and selecting the Stand By in the Power Buttons.
2. Getting start with STR function, please click the START button and choose
Shut Down. Then, select the Stand By option in the Shut Down Windows box
to get into STR mode.
Here are the differences between STR power saving mode and Green (or
Suspend) mode:
a. It is the most advanced Power Management mode
b. It cuts all the power supplied to peripherals except to Memory - max.
power saving
c. It saves and keeps all on-screen data including any executed applications to
DDR SDRAM.
Loading...
