MVP4M
ISA/PCI Motherboard with Onboard AGP
VGA, PCI Audio, PCI IDE and Super
Multi-I/O
TRADEMARK
All products and company names are trademarks or
registered trademarks of their respective holders.
These specifications are subject to change without notice.
Manual Revision 1.0
May 10, 1999
FeaturesMVP4M
FEATURES
MVP4M Features:
•Intel Pentium® Processor, Pentium Processor with MMX technology,
AMDK5/K6, Cyrix 6x86L/6x86MX & idt C6 operating at 133 ~ 500
MHz with 321 ZIF socket 7 provides scalability to accept faster
Processors in the future.
•Designed with VIA MVP4 AGPset.
•Supports up to 512 Mega of DRAM (minimum of 16 MB) on board,
You can use 168-pin DIMM x 2.
•Supports (1) 16 bit ISA slots, (3) 32 bit PCI slots, (1) AMR Slot and provides
(2) independent high performance PCI IDE interfaces capable of supporting
PIO Mode 3/4 and Ultra DMA 33/66 devices. The MVP4M supports (3)
PCI Bus Master slots and a jumperless PCI INT# control scheme which reduces configuration confusion when plugging in PCI card(s).
•Supports ATAPI (e.g. CD-ROM) devices on both Primary and Secondary
IDE interfaces.
•Designed with lntegrated Multi I/O: (1) floppy port, (1) parallel port
(EPP,ECP), and (2) serial ports (16550 Fast UART).
Note: Japanese “Floppy 3 mode” is also supported
•Features Award Plug & Play BIOS. With Flash Memory you can always
upgrade to the current BIOS as they are released. (http://www.
please visit our Technical Support section for the latest updates)
•MVP4M utilizes a Lithium battery which provides environmental
protection and longer battery life.
®
• Software power-down when using Windows
95/98.
2themax.com
Page 2
FeaturesMVP4M
•Supports ring-in feature (remote power-on through external modem,
allows system to be turned on remotely.
•Resume by Alarm - Allows your system to turn on at a preselected time.
•Supports CPU Hardware sleep and SMM (System Management Mode).
•Supports USDM software to offer motherboard various status.
•Supports the CPU and Chassis fan Auto stop in sleep mode.
•Built-in WOL (Wake On
• Built-in Sound Blaster/DirectSound AC97 Audio.
• Built-in AGP 2D/3D Graphics Accelerator.
LAN) Connector.
Page 3
InstallationMVP4M
MVP4M Detailed Layout
Page 4
Figure 1
InstallationMVP4M
Easy Installation Procedure
The following must be completed before powering on your new system:
Configure Jumpers
System Memory Configuration
Device Connectors
Configure Jumpers
We design this motherboard with the two DIP Switch to make your install fast and
easy.
Note: The DIP Switch as depicted as shown (Figure 1) in their correct
physical orientation.
SW1: CPU Vcore Voltage Selection
1WS
1234 5
NOV1.2
NOV2.2
NOV4.2
NOV8.2
NONOV9.2
NONOV2.3
UPC
erocV
SW2: CPU Speed Selection
2WS
1234
NOzHM66
NONOzHM38
NONOzHM09
NONOzHM59
NONONOzHM001
NONONOzHM501
NONONOzHM511
suB
kcolC
NOzHM57
2WS
566
NOX2
NONOX5.2
NOX3
NONOX4
NONONOX5.4
NONOX5
UPC
reilpitluM
X5.3
NOX5.5
Page 5
InstallationMVP4M
CPU Type
Pentium/MMX
AMD K5/K6
IDT-C6
166MHzPR200ONONON66MHz
250MHzPR366ONONONONON100MHz
200MHzPR266ONON66MHz
250MHzPR333ONONON83MHz
300MHz*PR433ONONONON100MHz
233MHzPR300ON66MHz
333MHz*PR466ONON95MHz
350MHz*PR500ONONON100MHz
266MHz*PR333ONONON66MHz
333MHz*PR466ONONONON83MHz
380MHz*PR533ONONONON95MHz
400MHz*PR550ONONONONON100MHz
300MHzONONONON66MHz
450MHzONONONONONON100MHz
333MHzONONON66MHz
*500MHzONONONONON100MHz
366MHzONON66MHz
*550MHzONONONON100MHz
Cyrix /IBM
6x86MX/MII
PR233ONONON75MHz
PR266ONONONON83MHz
PR300ONONONON95MHz
PR300ONON75MHz
PR400ONONON95MHz
PR333ON75MHz
*PR400ONON83MHz
*PR400ONONON75MHz
1234567
SW2
CPU
Bus
Clock
JP1Clear COMS
1-2 : 1-2 Normal(default)
2-3 : Clear CMOS
CPU
Multiplier
2.5X
3X
3.5X
4X
4.5X
5X475MHzONONONON95MHz
5.5X
* Reserved
J7
Page 6
WOL (Wakup On LAN) Connector
Reserved for NIC (Network Interface Card) to
Wake the System.
InstallationMVP4M
System Memory Configuration
Memory Layout
The MVP4M supports (2) 168-pin DIMMs (Dual In-line Memory Module).
The DIMMs can be either EDO (Extended Data Out) or SDRAM (Synchronized
DRAM). The DIMMs may be installed using just one chip.
• We recommend using SDRAM DIMM can not mixing
with EDO DIMM modules.
• DIMM SDRAM may be 83MHz (-12ns), 100MHz (-10ns) or
125MHz (-8ns) bus speed.
• No Registered DIMM support.
Figure 2 and Table 1 show several possible memory configurations using
DIMM 1
DIMM 2
Bank 0
Bank 1
-Synchronous
-EDO
Figure 2
yromeMlatoT
BM652=
mumixaM
BM215=
mumixaM
1MMID
)0knaB(
*MARDS/ODE
,BM46,BM23,BM61,BM8
enoN
1XBM652,BM821
*MARDS/ODE
,BM46,BM23,BM61,BM8
1XBM652,BM821
2MMID
)1knaB(
*MARDS/ODE
1XBM652,BM821
* SDRAM only supports 8, 16, 32, 64, 128, 256MB DIMM modules.
Table 1
,BM46,BM23,BM61,BM8
Page 7
InstallationMVP4M
Device Connectors
Please install the motherboard into the chassis.
Now that your motherboard is installed you are ready to connect all your
connections (figure 6).
parallel port
PS/2 Mouse
PS/2
KEYBOARD
J2,J3:Chassis Panel Connector
• Power_LED, Speaker, Reset, Power_ON/OFF, Turbo LED and
HDD LED, IR Connector
J4:CPU Fan Power
• A plug-in for the CPU Fan Power
J6:Chassis Fan Power
• A plug-in for the chassis Fan Power
J7:WOL (Wake On
JP1: CMOS Clear
AUX1: AUX Audio_in
CD1: CD-ROM Audio_in
COM2: RS232 COM2 Connector
IDE1: Primary IDE Connector
IDE2: Secondary IDE Connector
FDD1: Floppy Controller Connector
PW1: ATX Power Connector
• 20-pin power connector
USB Conn.: The second and third USB port (Cable optional)
USB port
COM1 VGA1
Figure 6
LAN) Connector
Speaker
Joystick/Midi
Line_in
MIC
Page 8
Device Connectors (continued)
(This is connected to the power button on the case. Using the
Soft-Off by Pwr-BTTN feature, you can choose either Instant
immediately), or 4 sec delay (you need to
J3
Off (turns system off
hold the button down for 4 seconds before the system turns off).
When the system is in 4 sec delay mode, there is a special feature
to make the system to go into suspend mode when the button is
pressed momentarily.)
Power On/Off
1
T urbo LED indicator - LED ON when higher speed is selected
+
IDE LED indicator - LED ON when Onboard PCI IDE Hard
+
disks is activate
IR Connector
1. VCC 4. GND
2. NC 5. IRTX
3. IRRX
1
InstallationMVP4M
J2
Power LED - Power LED connector
1. Power LED(+)4. NC
2. N/C5. GND
3. GND
1
Speaker - Connect to the system's speaker for beeping
1. Speaker3. GND
2. N/C4. GND
1
Reset - Closed to restart system.
1
Page 9
