Epilady EP720-04 Instruction Manual

Advanced infrared laser technology

Model No.: EP720-04

Instruction Manual

1

Warnings:

ATTENTION Do not use this appliance near bathtubs, showers,

basins or other vessels containing water.

Safety Chart:

Check if you can use the appliance. Women 18 and older; use

below the nose line.

• This sign anywhere in the brochure indicates safety and risks

fully.

• This appliance is exclusively for home use.

• This appliance is intended for removal of facial hairs and small
body areas, e.g, under arms, or other intimate areas.

• Use only the USB cable delivered with the appliance.

• Do not drop the appliance.

• Do not switch on the appliance if the appliance shows visible
signs of damage.

• This appliance can be used by adult persons

from 18 years

of age.

Children should not play with the appliance.

• Although the device is equipped with a safety sensors, do
not point the device towards the eyes, yours or anyone
else’s. Do not look directly into the device.

• Never open the body of the appliance. The manufacturer's
guarantee does not cover any damage caused by mishandling.

• Keep the device out of reach of children.

• Never submerge or wet the appliance.

2

1. Check your Skin Tone:

Match your skin tone of the area(s) you wish to treat to the skin
tones shown below to determine if you can safely use this device.
The appliance is intended for use only on Type I (white) to Type III
(beige) skin tones.

Type I

(white)

Type II

(Ivory)

Type III
(beige)

Type IV

(Light

brown)

Type V

(Medum

brown)

Type VI

(Dark

brown)

X X

2. Check your Hair Color:

The appliance works on all hair.

3. Where you can and cannot use this appliance:

Black RedBlondeGrayLight

Brown

Medium

Brown

Dark

Brown

White

X

WHERE TO USE THIS APPLIANCE

The appliance can be used on the
following areas of the body:

Women’s Facial Hair (cheeks

& below)

Underarms
Bikini Line

WHERE NOT TO USE THIS APPLIANCE

The appliance is not safe for use on
the following areas of the body:

Eye Areas (eyes, eyebrows, and

eyelashes)

Ears
Nipples
Genitals
Anus

X

X

X

3

4. Who should not use the appliance? Contraindications.
DO NOT use the appliance:

• On or around the eyes, eyebrows, or eyelashes, anywhere

on or around the ears, nipples, genitals, or around the anus.
These areas may have more sensitive skin, a darker skin tone,
and using the appliance there may cause skin injury or skin
pigmentation changes.

• On tattoos, dark brown or black spots (such as dark freckles,

birthmarks, moles or warts). Tattoos or dark spots may absorb
too much light energy which could cause skin swelling,

or whitening of the skin.

• If you have epilepsy or light-induced seizures or migraines.

•

sensitivity to light (photosensitivity) or are taking medication
that makes the skin more sensitive to light, including non-

cetaminophen), tetracyclines, phenothiazines, thiazide,

Hydroxi Acids (BHAs), Retin-A, Accutane and/or topical
retinoids.

• If you have any skin condition in the treatment area, including

acne, sores, psoriasis, eczema, burns, herpes simplex,
wounds or a rash. These conditions can make the skin more
sensitive to the light treatment and could make the treatment

not sure if your skin condition has healed enough to use the
device, then please consult with your doctor.

• If you have been treated with Accutane® (isotretinoin) within

light treatment and could make the treatment uncomfortable

4

• Do not use the device if you are allergic to hydroquinone or

•
in this age group are unknown.

• DO NOT use on any area where you may want your hair to
grow back.

• DO NOT use on a man's face, jaw or neck.

• DO NOT use if you are
pregnant, trying to become
pregnant (conceiving) or

skin sensitivity and the risk of skin damage.

DO NOT use the appliance if your skin tone matches one

“Not Safe”. If you use the appliance on
medium brown, dark brown or black skin tones - all
indicated as “Not Safe” for treatment - the skin may
absorb too much light, resulting in burning, discoloring, or
scarring.

How to use your appliance:
How it works: the laser beam
impacts the hair and the follicle
(“root”) under the skin surface.
On impact, the beam heats the follicle, weakening it and
impeding its future growth.

Not safe

skin tones:

Type IV&

Type V

1 2 3

5

1. Ensure skin is clean with no oily products and
completely dry before to proceed.

2.
compatibility of the device with your skin. The

skin reacts naturally well to laser treatment.

3. Choose a concealed area of your body, such as
a thigh.

4. Use the On-Off switch and turn on the device.

Laser-beam opening to the treated hair.

5. Attach the Laser-beam opening to your skin.
The laser automatically will operate and will
treat the hair for approximately 1 second.

6. The buzzer will beep indicating that the laser

7. After 5 minutes check the treated area.

8. If the treated spot appears red or irritated, please wait 24

9. Otherwise consult your doctor.

10. After you made sure that your skin reacts well to laser, you
can use it as follows:

14. Using the device may cause slight tingling sensation. This
means that the beam “hit” the follicle. However, if the use of
the device is accompanied by pain, a burning sensation,
a burn, swelling of the skin, or any other unusual reaction,

15. Use Absolute for two times a week for 16- 24 weeks, then do
periodic

touch up treatments as needed if new hair appears.

started treating and will stop beeping at the
end of the treating the single hair.

6

Battery operation:
Attention:

1. Turns blinking red when the device is connected to the
power adaptor and is charging.

2. Turns orange when the device is connected to the
power adaptor and ready to use.

3. When the device is connected to the power adaptor and
is charged, the device will not operate and you cannot
treat yourself.

4. Turns green when the device is operating and targets the
laser to the hair.

6.

Cleaning:

•

Clean the appliance after each use.

•

using ONLY a dry soft cloth.

• Hold the device with the laser-beam opening facing downwards,

and using circular motions, clean the opening. Do not insert the
swab into the device, but only clean the outer rim which touched
the skin.

• Do not wet the appliance.

• Store the appliance in a cool and dry place AWAY from the reach of

children.

Temperature (Cº) Operation 10° - 40°

Storage -40° - 70°

Relative humidity Operation 15%-90%

Atmospheric Pressure (kPa)

1000-700

5.

Turns orange when the device is connected to the power

adaptor and the devise is fully charged.

The charging port is located at the bottom of the unit.

tip

7

Troubleshooting:

No indicator lights are on: Use the power button and

turn on the device and check the device is charged.

No Buzzer and no impulse: The device is not resting
securely against the skin. Please make sure the device
tip is secure against the skin.

Warning :
(1) Never let children use the appliance.
(2) Never plug the appliance with wet hands.
(3) Do not attempt to repair your device.
(4)

it is

only for a moment.

(5) DO NOT use perfumed products for several hours before or after a

treatment.

(6) Always unplug the appliance during use.
(7) Never submerge or wet the appliance/adaptor.
(8) Do not insert metal objects into the device to avoid electric shock.

Guarantee:

The warranty shall apply in the country in which the product
was sold via an authorized dealer. If the product should become
defective within the warranty period, please contact the dealer
where you bought the product. The warranty does not include
damage to the product by accident, misuse, abuse, alteration
to product, or if it is

used in a manner other than described,

This warranty shall not apply if the product has been
dismantled or repaired by a non-authorized person.

8

This marking indicates that this product should not be dis-

prevent possible harm to the environment or human health

or contact the retailer where the product was

purchased. They can take

this product for environmental safe recycling.

9

Symbols

Type BF Applied Part

Hazards

CLASS 1M LASER PRODUCT

INVISIBLE LASER RADIATION

DO NOT VIEW DIRECTLY

WITH OPTICAL INSTRUMENTS

IEC60825-1:2007

Pmax =500 mW λ=808 nm

Complies with 21 CFR 1040.10

and 1040.11 except for

deviations pursuant to Laser

Notice No.50, dated June

24,2007
