CeraDiodes

Standard series

Series/Type:

Date: August 2008

© EPCOS AG 2008. Reproduction, publication and dissemination of this publication, enclosures hereto and the
information contained therein without EPCOS' prior express consent is prohibited.

CeraDiodes

Standard series

Features

ESD protection to IEC 61000-4-2, level 4
Bidirectional ESD protection in one component
No change in ESD protection performance at temperatures
up to 85 °C (temperature derating)
Use of parasitic capacitance for EMI suppression and
high-frequency filtering (replacement of additional MLCC)
High surge current capability
Low parasitic inductance
Low leakage current
Fast response time <0.5 ns
Lead-free nickel barrier terminations suitable for lead-free soldering
RoHS-compatible

Applications

Interfaces, data lines, power lines and audio lines, pushbuttons,
serial ports, ICs and I/O ports
Consumer electronic products (TV, DVD player/recorder, set-top
box, game consoles, MP3 player, digital still/video camera, etc.)
EDP products (desktop and notebook computer, monitor, PDA,
printer, memory card, control unit, head set, speaker, HDD, optical
drive, etc.)
Industrial applications

Design

Multilayer technology
Nickel barrier termination (Ag/Ni/Sn) for lead-free soldering

Marking

Due to the symmetrical configuration no marking information is
needed.

Single chip

4-fold array

General technical data

Maximum DC operating voltage V
Typical capacitance C
Air discharge ESD capability to IEC 61000-4-2 V
Contact discharge ESD capability to IEC 61000-4-2 V
Leakage current

1)

(V

= 5.6 V) I

leak

Operating temperature (without derating) T
Storage temperature T

1) Except CDS2C05GTA and CDS3C05GTA V

Important notes at the end of this document.

= 3.3 V. Any operating voltage lower than V

leak

Page 2 of 19Please read Cautions and warnings and

DC,max

typ

ESD,air

ESD,contact

leak

op

stg

5.6 ... 22 V
22 ... 470 pF
15 kV
8 kV
1 µA

40/+85 °C
40/+125 °C

results in lower leakage current.

leak

CeraDiodes

Standard series

Electrical specifications and ordering codes
Maximum ratings (T

Type Ordering code

= 85 °C) and characteristics (TA= 25 °C)

op,max

V

V

BR,min

(1 mA)
V

V

clamp,max

(1 A)
V

DC,max

V

I

PP

(8/20 µs)
A

P

PP

(8/20 µs)
W

C
(1 MHz, 1 V)

pF
Array, 4-fold, 0508, no semiconductor diode equivalent
CDA4C20GTA B72714D0200A060 22 24 60 10 600 33
Array, 4-fold, 0612, no semiconductor diode equivalent
CDA5C20GTA B72724D0200A062 22 25 50 30 2200 56
Single, 0201, no semiconductor diode equivalent
CDS1C05GTA B72440D0050A060 5.6 12 35 - - 22
Single, 0402, SOD-723
CDS2C05GTA B72590D0050A060 5.6 6.4 24 10 320 180

CDS2C15GTA B72590D0150A060 15 20 46 10 670 47
Single, 0603, SOD-523
CDS3C05GTA B72500D0050A060 5.6 6.4 19 30 1000 470

CDS3C09GTA B72500D0090A060 9 10 30 30 1600 220
CDS3C15GTA B72500D0150A060 15 22 42 30 2000 160
CDS3C20GTA B72500D0200A060 22 25 50 30 2200 56

Single, 1003, SOD-323
CDS4C12GTA B72570D0120A060 12 16 46 20 1000 82

typ

1)

1)

1)

1)

Typical characteristics

1) C

measured at V = 1 V, f = 1 kHz.

typ

Important notes at the end of this document.

Page 3 of 19Please read Cautions and warnings and

CeraDiodes

Standard series

Dimensional drawings

Single device

Array device

Dimensions in mm

Case

(inch)

size

(mm)

0201
0603

0402
1005

0603
1608

1003
2508

Min. Max. Min. Max. Min. Max. Min. Max.
l 0.57 0.63 0.85 1.15 1.45 1.75 2.34 2.74
w 0.27 0.33 0.4 0.6 0.7 0.9 0.7 0.9
h 0.27 0.33 0.4 0.6 0.7 0.9 0.7 0.9
k 0.1 0.2 0.1 0.3 0.1 0.4 0.13 0.75

Dimensions in mm

Case
size

(inch)
(mm)

0508
1220

0612
1632

Min. Max. Min. Max.
l 1.8 2.2 3.0 3.4
w 1.05 1.45 1.45 1.75
h - 0.9 - 0.9
d 0.2 0.4 0.25 0.55
e 0.4 0.6 0.61 0.91
k - 0.35 - 0.35

Important notes at the end of this document.

Page 4 of 19Please read Cautions and warnings and

CeraDiodes

Standard series

Recommended solder pads

Single device

Array device

Dimensions in mm

Case size (inch)

(mm)

0201
0603

0402
1005

0603
1608

1003

2508
A 0.3 0.6 1.0 0.8
B 0.25 0.6 1.0 0.8
C 0.3 0.5 1.0 1.45

Dimensions in mm

Case size (inch)

(mm)

0508
1220

0612

1632
A 0.35 0.5
B 0.9 0.7
C 0.4 1.2
E 0.5 0.76

Important notes at the end of this document.

Page 5 of 19Please read Cautions and warnings and

CeraDiodes

Standard series

Pin configurations

Single device

Array device

Pin Description
P1 GND
P2 I/O line

Pin Description
P1 GND
P2 GND
P3 GND
P4 GND
P5 I/O line 1
P6 I/O line 2
P7 I/O line 3
P8 I/O line 4

Important notes at the end of this document.
