Page 1

WELLBEING SERIES

Installation & Maintenance Instructions

WALL TOP ASSEMBLY

DUAL MIXER / SEQUENTIAL BASIN MIXER

SEQUENTIAL SHOWER MIXER

BASIN / SINK SET

I00077_Oct 17

Call 1300 369 273 www.enware.com.au

Enware Australia Pty Limited 9 Endeavour Rd Caringbah NSW 2229 Australia Ph: +61 2 8556 4000 Fax: +61 2 8556 4055

NOTE: THIS DOCUMENT IS TO BE LEFT ONSITE WITH FACILITY MANAGER AFTER INSTALLATION

Page 2

Page 3

www.enware.com.au Call 1300 369 273 3

WELLBEING SERIES

Installation & Maintenance Instructions

technical data

Working Pressure Range 50-800 kPa Recommended Maximum Pressure 500 kPa* Working Temperature Range 5 °C – 85 °C *

For use with potable water only.

compliance

*Enware products are to be installed in accordance with the Plumbing Code of Australia and AS/NZS3500.

Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local

Government regulaons when considering the choice of, and the installaon of these products.

Thermostac Mixing Valves and Pressure Reducon Valves may be required to comply

with maximum temperature and pressure

requirements.

please note

Enware Australia advises due to ongoing Research

and Development, specicaons may change without noce.

before installation

Before Proceeding With Installaon

• Ensure all operang & dimensional specicaons are suitable for the intended installaon.

• Ensure all supply lines are ushed thoroughly to remove debris prior to the installaon of

this product as per AS/NZS 3500.1. Strainers (40 mesh) are recommended if debris is an ongoing problem.

Component specicaons may change on some

export models.

Page 4

4 Call 1300 369 273 www.enware.com.au

WALL TOP ASSEMBLY

G5/8" (BSP

CLOSED

OPEN

CLOSED

OPEN

installation

WBWTCD65-LTC | WBWTCD65-RTC

Wall Depth Adjustment

FINISHED WALL

80 min.

100 max.

)

20 ADJ.

RECESS BODY

MAX 18 mm MIN 0 mm

* For deeper wall recess use extended SBA (Max. 33 mm)

LTC an-clockwise to close | RTC clockwise to close

Page 5

www.enware.com.au Call 1300 369 273 5

MAX 18Nm

MAX 30Nm

“CLICK”

Page 6

6 Call 1300 369 273 www.enware.com.au

SEQUENTIAL SHOWER MIXER

installation

WBSHSQ65

G1/2" (BSP)

FEMALE OUTLET

25 ADJ.

FULL WARM

Ø75

105 max.

FULL COLD

CLOSED

Page 7

www.enware.com.au Call 1300 369 273 7

1 2

OFF POSITION

NOGGING POSITION

1000mm FROM FLOOR

x shower into posion

MIN 50mm MAX 75mm

FINISHED WALL

“CLICK”

Page 8

8 Call 1300 369 273 www.enware.com.au

DUAL MIXER

Ø55

SEQUENTIAL BASIN MIXER

installation

WBDMCD65-165 | WBDSQ65-165

CLOSED

Ø55

OPEN

Ø55

CLOSED

FULL COLD

FULL WARM

A B

165 Spout 165 215 220 Spout 220 230

Page 9

www.enware.com.au Call 1300 369 273 9

Cut tap hole on bench, with clearance around tap hole for spacer stabilizer

1 2

BENCHTOP CUTOUT

spacer stabilizer must be used for

bench thickness less than 10mm

SPACER STABILIZER

Page 10

10 Call 1300 369 273 www.enware.com.au

BASIN/SINK SET

installation

WBBCD65-165

165

80 20 max.

OPEN OPEN

150 - 300

(CUT TO SUIT ON SITE)

G1/2" (BSP) WITH OLIVE

COMPRESSION FITTING

cut holes to suit outlet

and handle posions

1 2

Ø22

Ø33

165

Ø55 TYP

CLOSEDCLOSED

1 x spout

cutout

2 x body

cutout

Page 11

www.enware.com.au Call 1300 369 273 11

THREAD SEALANT

“CLICK”

109

Page 12

12 Call 1300 369 273 www.enware.com.au

WALL TOP ASSEMBLY parts WBWTCD65-LTC | WBWTCD65-RTC

1 Red Fibre Washer 9 SBA Locknut 2 Spline Adaptor Octagon Insert 10 Handle Base 3 Dome 11 Handle 65mm Insert 4 O-Ring 12 Indicator –Red 5 Washer – S/S 13 Fricon Bush 6 Washer – Nylon 14 Indicator – Blue 7 Screw M5x20 S/S 15 Indicator - Yellow 8 SBA Spindle Q/Turn 80mm

Page 13

www.enware.com.au Call 1300 369 273 13

SEQUENTIAL SHOWER MIXER parts WBSHSQ65

1 Shower Mixer Body 7 Washer – S/S 2 Sequenal Mixer Cartridge - 180° 8 Screw M5 x 35 S/S 3 Cartridge Retaining Nut 9 Handle 65mm Insert 4 Spline Adaptor Octagon Insert 10 Indicator – Grey 5 Handle Base 11 Dress Ring – Shower 6 Washer - Nylon 12 Colour Indicators

Page 14

14 Call 1300 369 273 www.enware.com.au

DUAL MIXER parts WBDMCD65-165

1 Dual Mixer Body 15 O-Ring 2 Spout 16 Hose 350mm Blue 3 Fricon Brush 17 Fixing Bolt M6x80 4 Spout Fixing Insert 18 Fixing Plate Washer Nitrile 5 Grub Screw M5x15 19 Fixing Plate Brass 6 SBA Spindle Q/Turn 55mm RTC 20 Handle Base 7 SBA Locknut 21 Handle 65mm Insert 8 Red Fibre Washer 22 Indicator – Red 9 Washer – S/S 23 Indicator – Blue 10 Washer – Nylon 24 Indicator - Yellow 11 Screw – M5x20 S/S 25 Hose 350mm Red 12 Spline Adaptor Octagon Insert 26 Fixing Nut M6x42 13 SBA Spindle Q/Turn 55mm LTC 27 Mixer Plasc Spacer Stabilizer 14 Dress Ring – Hob Mixer Base

Page 15

www.enware.com.au Call 1300 369 273 15

SEQUENTIAL BASIN MIXER parts WBBSQ65-165

1822

1 Sequenal Mixer Body 13 Dress Ring – Hob Mixer Base 2 Spout 165mm 14 O-Ring 3 Grub Screw M5x15 15 Hose 350mm Blue 4 Fricon Bush 16 Fixing Plate Washer Nitrile 5 Spout Fixing Insert 17 Fixing Plate Brass 6 Sequenal Mixer Cartridge - 90° 18 Handle 65mm Insert 7 Cartridge Retaining Nut 19 Indicator – Grey 8 Spline Adaptor Octagon Insert 20 Screw M5x35 9 Colour Indicators Mixer Body 21 Fixing Bolt M6x80 10 Handle Base 22 Hose 350mmm Red 11 Washer – Nylon 23 Fixing Nut M6x42 12 Washer – S/S 24 Mixer Plasc Spacer Stabilizer

Page 16

16 Call 1300 369 273 www.enware.com.au

BASIN MIXER parts WBBCD65-165

1 Dress Ring – Hob Spout 12 Dome 2 O-Ring 13 Washer – S/S 3 Spout Base 14 Washer – Nylon 4 Spout 165mm 15 Screw M5x20 5 Spout Fixing Insert 16 SBA Spindle Q/Turn Contra 55mm 6 Grub Screw M5x12 17 Handle Base 7 Fricon Bush 18 Handle 65mm Insert 8 SBA Spindle Q/Turn 55mm 19 Indicator – Red 9 SBA Locknut 20 Indicator – Blue 10 Red Fibre Washer 21 Indicator – Yellow 11 Spline Adaptor Octagon Insert 22 Basin / Sink Tee Kit

Page 17

www.enware.com.au Call 1300 369 273 17

TROUBLESHOOTING

PROBLEM CAUSE RECTIFICATION

Water leaking from outlet Water dripping and does not

shut o

Water is leaking from spindle O-ring on SBA/Cartridge is

Water is not owing from tap Poor water ow from outlet

Handle is wobbly Handle feels loose

Debris caught in seal of cartridge or SBA

Ceramic discs are worn or damaged

Tap seat is damaged (for SBA only)

worn or damaged

Water turned o. Turn water on.

Aerator or Flow control is blocked by debris.

Spline adaptor (octagon insert) is missing

Remove cartridge/SBA and inspect. Remove debris and/or replace cartridge/SBA if damaged

Replace SBA/cartridge

Refurbish tap seat using a

reseang tool. If necessary - t reseang kit.

Replace SBA/Cartridge

Remove tap and wash debris

from aerator/ow control.

Install an inline strainer.

Ensure spline adaptor is installed correctly

Handle does not align perfectly straight

Wall ange does not screw into

thread of SBA

Wall ange does not screw

down onto wall surface

Due to handles being spline mounted, handles may be oset slightly from vercal or straight. This is normal and unavoidable

Tap bodies are set too far into the wall

Tap bodies are set too far out Use a trouble dome or ange

Use extended recess spindle (SBA only)

extender

Page 18

18 Call 1300 369 273 www.enware.com.au

Page 19

www.enware.com.au Call 1300 369 273 19

SERVICE & MAINTENANCE

spout & tap handles

Occasionally the handle screws should be checked

for ghtness and a visual inspecon made of all other connecons on the tap assembly. Ensure that the spout and the tap handles are secure, and ghten if

necessary.

aerator

Spout aerator should be checked periodically for debris. Use Aerator Key to unscrew spout aerator. If aerator doesn’t come out completely, turn tap on to

ush the aerator out.

sequential mixer cartridge

To replace mixer cartridge, unscrew cartridge retaining nut with Enware Cartridge Key (WBSQKEY). Pull cartridge out and replace with new component.

Fit cartridge retaining nut back on, and ghten using Enware Cartridge Key. Do not overghten.

(Recommended - 20Nm)

cleaning

Enware Product should be cleaned with a so damp cloth using only mild liquid detergent or soap and

water.

Do not use cleaning agents containing a corrosive acid, scouring agent or solvent chemicals. Do not use cream cleaners, as they are abrasive. Epoxy coated surfaces should only be cleaned with a cloth and clear water or mild detergent. Use of unsuitable cleaning agents may damage the surface. Any damage caused in this way will not be covered by warranty.

Inspect and reverse rinse aerator to clear any debris. Replace aerator if necessary.

To t aerator back, insert aerator into p of spout

using care to avoid damage to the aerator O-ring by

ensuring the aerator is square to the spout outlet, and nger ghten half a turn. Use Aerator Key to ghten aerator into posion. Do not overghten.

Page 20

20 Call 1300 369 273 www.enware.com.au

SPARE PARTS

PART ENWARE PRODUCT CODE

Handle Assembly (Includes Blue, Red, Yellow colour indicators)

Handle Colour Indicator Pack (Blue, Red, Yellow)

Colour Indicator Pack

(For Sequenal Mixer)

Grey handle indicator, 4 colour indicators for body

WB65

WBIND

WBSQIND

Wall Top Assembly Handle Assembly + Dome+ SBA Ceramic Disc

RTC (Clockwise to Close)

LTC (An-Clockwise to Close)

SBA Ceramic Disc - Hob

RTC (Clockwise to Close)

LTC (An-Clockwise to Close)

SBA Ceramic Disc - Recess Wall 80mm

RTC (Clockwise to Close)

LTC (An-Clockwise to Close)

SBA Ceramic Disc - Recess Wall 95mm (Extended 15mm)

RTC (Clockwise to Close)

LTC (An-Clockwise to Close) Sequenal Mixer Cartridge

(90° RTC - Sink / Basin Mixer)

WBWTCD65-LTC WBWTCD65-RTC

WBBCDSBA-LTC WBBCDSBA-RTC

WBWCDSBA-LTC WBWCDSBA-RTC

WBWCDSBA15-LTC WBWCDSBA15-RTC

WBSQSBA

Sequenal Mixer Cartridge

WBSQSHSBA

(180° RTC - Shower Mixer)

Spline Adaptor for SBA

WBCDOCT (Wall/Hob) WBDMCDOCT (Dual Mixer)

WBSQOCT (Sequenal Mixer)

Dome – Basin/Sink/Wall

WBCDFLAN

Page 21

www.enware.com.au Call 1300 369 273 21

SPARE PARTS

PART ENWARE PRODUCT CODE

Dress Ring – Hob Mount Spout

WBBFLAN

Dress Ring – Hob Mixer Base

Flange – Sequenal Shower Mixer

With colour indicators – Blue, Red, Yellow, Grey

Flange – Wall Spout

Spout 165mm

Spout 220mm

WBMIXFLAN

WBSQSHFLAN

WBWFLAN

WB165-5 (For Basin Set 6 lpm) WB165-6 (For Basin Set 4 lpm) WBMIX165-5 (For Mixer 6 lpm) WBMIX165-6 (For Mixer 4 lpm)

WB220-5 (For Sink Set 6 lpm) WB220-6 (For Sink Set 4 lpm) WBMIX220-5 (For Mixer 6 lpm) WBMIX220-6 (For Mixer 4 lpm)

Hob Spout Base

Spout 220mm Bath

Wall Spout 165mm

Wall Spout 220mm

Wall Spout Base

WBHBASE

WBW-220

WBWB-165-5 (6 Lpm) WBWB-165-6 (4 Lpm)

WBWS-220-5 (6 Lpm) WBWS-220-6 (4 Lpm)

WBWBASE

Spout Fixing Insert

WBHEX

(Convert swivel to xed)

Page 22

22 Call 1300 369 273 www.enware.com.au

PRODUCT WARRANTY FOR AUSTRALIA Eecve 1 September 2014

Enware Australia Pty Limited (ACN 003 988 314) (“we” or “us”) warrants that this product (also referred to as “our goods”) will be free from all defects in materials and workmanship for 12 months* from the date of purchase. Our liability

under this warranty is limited at our opon to the repair or replacement of the defecve product or part, the cost of repair of the defecve product or part or the supply of an equivalent product or part, in each case if we are sased the loss or damage

was due to a defect in the materials or workmanship of the product or part. All products must be installed in accordance with the manufacturer’s

instrucons, the PCA, and AS/NZS3500 including any other applicable regulatory requirements.

making a claim

To make a claim under this warranty you must

nofy us in wring within 7 days of any alleged defect in the product coming to your aenon

and provide us with proof of your purchase of the product together with a completed Product

ServiceRequest form (ENF091), which is available on request from our oce or website (see contact details below). All nocaons and accompanying forms must be sent to us marked for the aenon

of the Enware Australia Pty Limited, 9 Endeavour Road, Caringbah NSW 2229. We can also be contacted by telephone (1300 369 273) or by email ([email protected]). Your costs in making a claim under this warranty, including all freight,

collecon and delivery costs, are to be borne and

paid by you. We also reserve the right at our cost to inspect any alleged defect in the product wherever it is located or installed or on our premises.

exceptions

This warranty does not apply in respect of any damage or loss due to or arising from:

a) Failure by you or any other person to follow

any instrucons for use (including instrucons and direcons relang to the handling, storage, installaon, ng, connecon, adjustment or repair

of the product) published or provided by us;

b) Failure by you or any other person responsible

for the ng, installaon or other work on the

product to follow or conform to applicable laws, standards and codes (including the AS/NZ 3500 set of Standards, all applicable State and Territory Plumbing Codes, the Plumbing Code of Australia

and direcons and requirements of local and other statutory authories); or

c) Any act or circumstance beyond our control

including faulty installaon or connecon, accident,

abnormal use, acts of God, damage to buildings, other structures or infrastructure and loss or

damage during product transit or transportaon.

other conditions

Except as provided or referred to in this document, we accept no other or further liability for any

damages or loss (including indirect, consequenal or

economic loss) and whether arising in contract, tort

or otherwise. Any benets available to you under this warranty are in addion to any non-excludable

rights or remedies you may have under applicable

legislaon, including as a “consumer” under the

Australian Consumer Law. To that extent you need to be aware that: Our goods come with guarantees that cannot be excluded under the Australian

Consumer Law. You are entled to a replacement or refund for a major failure and for compensaon for

any other reasonably foreseeable loss or damage.

You are also entled to have the goods repaired or replaced if the goods fail to be of acceptable quality

and the failure does not amount to a major failure.

* 1 Year parts and labour on the complete assembly.

Aer 1 year, a further 4 years parts only warranty is applicable to sequenal valve cartridge.
