Envizen HR701 User Manual
Home Roam TV
Model: HR701
Thank you for purchasing this product.
For your safety and best performance, please read this instruction before
first use, and keep this manual for future reference.
In case that you have any further questions after reading this manual,
please contact Customer Service at 1-866-709-1999 or email to
service@envizendigital.com
100 Feet Wireless
Transmission Function*
Table of Contents
1. Safety Disclaimer........................................................................................................1
2. Introduction.................................................................................................................3
3. Features.......................................................................................................................3
4. What’s in the Box........................................................................................................3
5. Unit Functions.............................................................................................................4
5-1. Transmitter Module..............................................................................................4
5-2. Display Receiver..................................................................................................4
6. Setting up Home Roam TV.........................................................................................5
6-1. HR TV Transmitter Module Connections...........................................................5
6-2. HR TV Transmitter Module Operation................................................................6
6-3. HR TV Display Receiver Connections...................................................... .........6
6-4. HR TV Display Receiver operation.....................................................................7
7. Using Display Receiver as Independent A/V Monitor..............................................8
Troubleshooting..............................................................................................................9
Appendix.........................................................................................................................10
● Pairing the Transmitter Module and Display Receiver.............................................10
● Quick Setup Reference...............................................................................................11
Warranty .........................................................................................................................12
Safety Disclaimer
To prevent electric shock or fire hazard do not expose the unit to rain or moisture.
Warning To avoid electric shock or fire hazard,do not open the cabinet,refer servicing to
qualified person only.
This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient magnitude to
persons.
This symbol is intended to alert the user to the presence of important operating and maintenance
servicing instructions in the literature accompanying the appliance.
warning to avoid electric shock please ensure plug is inserted completely.
To reduce the risk of the fire or injury to persons or damage to the product, please read the safety
precautions before use.
Do not place Home Roam TV on or near any hot surface, such as stereo amplifier, transformer, radiator,
etc. Also, do not place anything on the top of the Home Roam TV.
constitute a risk of electric shock to
Warning: for safety we advise that it is not allowed to watch video during driving!
Please read this safety & operation
manual before you install and use the
unit,and please follow the instruction.
Pay attention to warning and do follow
them.
Route the power cord so that it is not
likely to be walked on or pinched by
items placed upon or against them,
paying particular attention to the plugs,
receptacles,and the point where the
cord exists from the appliance.
Please disconnect the unit under these
conditions:Lightning,Rainstorm or you
won't use it for a long time,this can avoid
electric shock.
Do not overload wall outlets,extension
cords or convenience receptacles
beyond their capacity,since this can
result in fire or electric shock.
Power jack is used to disconnect the
unit and should be easy accessible
everytime.
Do not place the unit on an unstable
object,the set may fall,causing serious
injury to a child or an adult,and serious
damage to the unit.
Never let any liquid spattered on the
unit.It might cause electric shock or fire
hazard.
Do not repair the unit yourself,opening
or removing the cover may expose you to
dangerous voltage or other hazards,
refer all servicing to qualified service
personnel.
Never place the unit near or over such
objects:for example,radiat or heat
register, stove
(including amplifier).
Unplug the unit from the wall outlet
before cleaning or polishing it.Do not
use liquid cleaners or aerosol cleaners,
use a cloth lightly dampened with water
for cleaning the exterior of the unit.
or other heat
sources
The power requirement of this unit is
100~240VAC,50Hz/60Hz.
Check the connection reguarly.If any
rupture of failure in insulation,call for
a maintenance man to replace them.
To ensure reliable operation,and to
protect it from overheating,the unit
must be put in somewhere well ventilated
Never place heavy object on the unit.
Notice:
Keep safety utilization of electric power
electrical wire of peripherals should
marked with safety label.and the wire
cannot be lose its security feature for
random replacement.following this can
avoid electric shock or fire hazard,in case
such accident happens,you
contact qualified technician.
should
.
1
Safety Disclaimer
Do not use power-line operated sets
near water-for example,near a bathtub,
washbowl,kitchen sink,or laundry tub,
in a wet basement,or near a swimming
pool,etc.
Unplug the unit and refer servicing to
qualified service personnel under the
following conditions:
A.when the power cord or plug is
damaged or frayed.
B.If liquid has been spilled or objects
have fallen into the unit.
C.The unit has been exposed to rain or
water.
D.If the unit does not operate normally
when following the operating
instructions.
copyrights:
the copyright protected content cannot
be copied.broadcasted,screened,cable
casted,played publicly and
rented,
unless it is authorized.
E.If the unit has fallen or the cabinet has
been damaged.
F.When the unit exhibits a distinct
change
in performance-this indicates
for service.
a need
Tips:Upon completion of any service or repairs
to the set,ask the service technician to perform
routine safety checks to determine that the unit
is in safe operating condition.
2
Introduction
Congratulations on the purchase of your Envizen Digital Home Roam TV.
Home Roam TV allows you to view any source device connected to the transmitter module on the
7” LCD Display Receiver anywhere in your home, up to 100 feet apart.
You may connect up to four source devices (Cable / Dish set top box, TV, DVD, Blu-ray, VCR or
Media Player) to Home Roam TV. (One set of cables is supplied)
Features
● 2.4Ghz wireless audio/video signal transmission
● Range: up to 100 feet
● Built-in 1500mA battery for up to 2 hours usage
● 7” TFT LCD widescreen display
● Contract Ratio: 400:1
● Brightness: 200cd/m2
What’s in the box
Display Receiver
AC/DC Adapter (2pcs)
Transmitter Module
Home Roam TV
Model: HR701
Thank you for purchasing this product.
For your safety and best performance, please read this instruction before
first use, and keep this manual for future reference.
In case that you have any further questions after reading this manual,
please contact Customer Service at 1-866-709-1999 or email to
service@envizendigital.com
Home Roam TV
Model: HR701
100 Feet Wireless
Transmission Function*
3
