Envision Peripherals G2219 User Manual

TABLE OF CONTENTS

FOR YOUR SAFETY -------------------------------------------------- 1

SAFETY PRECAUTIONS -------------------------------------- 2 SPECIAL NOTES ON LCD MONITORS ------------------- 3

BEFORE YOU OPERATE THE MONITOR --------------------- 3

FEATURES -------------------------------------------------------- 3 PACKING LIST --------------------------------------------------- 3 INSTALLATION INSTRUCTIONS --------------------------- 4 CONTROLS AND CONNECTORS -------------------------- 5 ADJUSTING THE VIEWING ANGLE ----------------------- 6

OPERATING INSTRUCTIONS ------------------------------------- 7

GENERAL INSTRUCTIONS ---------------------------------- 7 FRONT PANEL CONTROL NG ------------------------------ 8 HOW TO ADJUST A SETTING ------------------------------ 9 ADJUSTING THE PICTURE ----------------------------- 10-13 PLUG AND PLAY ----------------------------------------------- 14

TECHNICAL SUPPORT(FAQ) ---------------------------------15-16

ERROR MESSAGE & POSSIBLE SOLUTION -------- 17

APPENDIX -------------------------------------------------------------- 18

SPECIFICATIONS -------------------------------------------18-19 FACTORY PRESET TIMING TABLE ----------------------CONNECTOR PIN ASSIGNMENT --------------------------

ISO 14001 Certification ---------------------------------------------- 22

Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference.

FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS)

NOTE: This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4. Consult the dealer or an experienced radio/TV technician for help.

NOTICE:

1. The changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate the equipment.

2. Shielded interface cables and AC power cord, if any, must be used in order

to comply with the emission limits.

3. The manufacturer is not responsible for any radio or TV interference

caused by unauthorized modification to this equipment. It is the responsibilities of the user to correct such interference.

WARNING:

To prevent fire or shock hazard, do not expose the monitor to rain or moisture. Dangerously high voltages are present inside the monitor. Do not open the cabinet. Refer servicing to qualified personnel only.

PRECAUTIONS

 Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen

sink, laundry tub, swimming pool or in a wet basement.

 Do not place the monitor on an unstable cart, stand, or table. If the monitor

falls, it can injure a person and cause serious damage to the appliance. Use only a cart or stand recommended by the manufacturer or sold with the monitor. If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit instructions.

 Slots and openings in the back and bottom of the cabinet are provided for

ventilation. To ensure reliable operation of the monitor and to protect it from overheating, be sure these openings are not blocked or covered. Do not place the monitor on a bed, s ofa, rug, or similar surface. Do not place the monitor near or over a radiator or heat register. Do not place the monitor in a bookcase or cabinet unless proper ventilation is provided.

 The monitor should be operated only from the type of power source indicated

on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company.

 The monitor is equipped with a three-pronged grounded plug, a plug with a

third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the safety purpose of the grounded plug.

 Unplug the unit during a lightening storm or when it will not be used for long

period of time. This will protect the monitor from damage due to power surges.

 Do not overload power strips and extension cords. Overloading can result in

fire or electric shock.

 Never push any object into the slot on the monitor cabinet. It could short

circuit parts causing a fire or electric shock. Never spill liquids on the monitor.

 Do not attempt to service the monitor by yourself; opening or removing

covers can expose you to dangerous voltages and other hazards. Please refer all servicing to qualified service personnel.

 To ensure satisfactory operation, use the monitor only with UL listed

computers which have appropriate configured receptacles marked between 100 - 240V AC, Min. 5A.

 The wall socket shall be installed near the equipment and shall be easily

accessible.

SPECIAL NOTES ON LCD MONITORS

The following symptoms are normal with LCD monitor and do not indicate a problem.

NOTES

• Due to the nature of the fluorescent light, the screen may flicker during initial

use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears.

• You may find slightly uneven brightness on the screen depending on the

desktop pattern you use.

• The LCD screen has effective pixels of 99.99% or more. It may include

blemishes of 0.01% or less such as a missing pixel or a pixel lit all of the time.

• Due to the nature of the LCD screen, an afterimage of the previous screen

may remain after switching the image when the same image has been displayed for a long time. The monitor will slowly recover from this.

• When the screen becomes black or flashing, or cannot illuminate any more,

contact your dealer or service center to replace parts. Don’t repair the screen by yourself!

BEFORE YOU OPERATE THE MONITOR

FEATURES

• 558mm diagonal TFT Color LCD Monitor

• Crisp, Clear Display for Windows

• Recommened Resolutions: 1680 X1050@60Hz

• Ergonomic Design

• Space Saving, Compact Case Design

CHECKING THE CONTENTS OF THE PACKAGE

The product package should include the following items:

1. LCD Monitor

2. Owner's Manual

3. Power Cord

4. Signal Cable

5. DVI Cable

INSTALLATION INSTRUCTIONS

SWIVEL BASE

Install Remove

Figure 1 Installing and Removing the Swivel Base

POWER CORD Power Source:

1. Make sure that the power cord is the correct type required in your area.

2. This LCD monitor has an External universal power supply that allows operation in either 100/120V AC or 220/240V AC voltage area (No user adjustment is required.)

3. Connect the AC-power cord into your LCD monitor’s power input socket, The AC-power cord may be connected to either a wall power outlet or the power outlet socket on your PC, depending on the type of power cord supplied with your LCD monitor.

CONTROLS AND CONNECTORS

Power input socket

DVI input socket

D-SUB input socket

SIGNAL CABLE

Connecting the Signal Cable: Plug the Signal Cable one end to LCD monitor’s

“DSUB-Input” socket, the other end to the computer's VGA port and tighten the two screws on the cable connector.

Connecting the Power Cord: Plug the AC-power cord into the External Adapter. Then plug the DC-jack power cable into DC-IN Inlet.

Connecting the DVI Cable: Connect one end of the 24-pin DVI cable to the back of the monitor and connect the other end to the computer’s DVI port.

Caution: If the AC outlet is not grounded (with three holes), install the proper grounding adapter (not supplied).

Figure 2 Connecting Cables

ADJUSTING THE VIEWING ANGLE

• For optimal viewing it is recommended to look at the full face of the monitor,

then adjust the monitor’s angle to your own preference.

•

Hold the stand so you do not topple the monitor when you change the

monitor’s angle.

• You are able to adjust the monitor’s angle from -5° to 20°.

Figure 3

NOTES

• Do not touch the LCD screen when you change the angle. It may cause

damage or break the LCD screen.

• Careful attention is required not to catch your fingers or hands when you

change the angle.
