Envision Peripherals EN7410 User Manual

EN7410

17” TFT LCD Monitor

User’s Manual

By Envision Peripherals Inc.

www.ENVISIONdisplay.com

FOR YOUR SAFETY

Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference.

FCC Class B Radio Frequency Interference Statement

WARNING: (FOR FCC CERTIFIED MODELS)

NOTE: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4. Consult the dealer or an experienced radio/TV technician for help.

As an ENERGY STAR that this product meets the ENERGY STAR

Partner Envision Peripherals Inc. has determined

guidelines for energy efficiency.

WARNING:

To prevent fire or shock hazard, do not expose the monitor to rain or moisture. Dangerously high voltages are present inside the monitor. Do not open the cabinet. Refer servicing to qualified personnel only.

PRECAUTIONS:

• Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen

sink, laundry tub, swimming pool or in a wet basement.

• Do not place the monitor on an unstable cart, stand, or table. If the monitor

falls, it can injure a person and cause serious damage to the appliance. Use only a cart or stand recommended by the manufacturer or sold with the monitor. If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit instructions.

• Slots and openings in the back and bottom of the cabinet are provided for

ventilation. To ensure reliable operation of the monitor and to protect it from overheating, be sure these openings are not blocked or covered. Do not place the monitor on a bed, sofa, rug, or similar surface. Do not place the monitor near or over a radiator or heat register. Do not place the monitor in a bookcase or cabinet unless proper ventilation is provided.

• Do not install the monitor in a location near heat sources such as radiators or

air ducts, or in a place subject to direct sunlight, or excessive dust or mechanical vibration or shock.

• The monitor should be operated only from the type of power source

indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company.

• The monitor is equipped with a three-pronged grounded plug, a plug with a

third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an electrician install the correct outlet or ground the appliance safely. Do not defeat the safety purpose of the grounded plug.

• Unplug the unit during a lightning storm or when it will not be used for long

period of time. This will protect the monitor from damage due to power surges.

• Do not overload power strips and extension cords. Overloading can result in

fire or electric shock.

• Never push any object into the slot on the monitor cabinet. It could short

circuit parts causing a fire or electric shock. Never spill liquids on the monitor.

• Do not attempt to service the monitor by yourself. Opening or removing

covers can expose you to dangerous voltages and other hazards. Please refer all servicing to qualified service personnel.

• Do not pull or bend the power cable and signal cable or place the monitor or

any heavy objects on the cables. If the cables are damaged, they may cause fire or electric shock.

• If you notice any abnormal phenomenon such as strange noise, smoke or

smells, unplug the monitor and contact your dealer or the nearest service center immediately.

• When moving the monitor, always turn off the switch, unplug the monitor,

and disconnect the signal cable. If the cables are not properly disconnected when moving the monitor, it may cause fire or electric shock.

• Do not touch the plug with wet hands. Pulling or inserting the plug with wet

hands may cause electric shock.

• To disconnect the power cable or signal cable, always pull the cable by the

plug. Never pull on the cable as this may cause fire or electric shock.

• To ensure satisfactory operation, use the monitor only with UL listed

computers which have appropriate configured receptacles marked between 100 - 240V AC, Min. 5A.

• The wall socket shall be installed near the equipment and shall be easily

accessible.

ERGONOMICS RECOMMENDATIONS

Do not operate the monitor in a dark room or against a bright background. For optimal viewing comfort, the monitor should be just below eye level and 30-60 cm (16-24 inches) away from your eyes. When using the monitor over a prolonged period of time, a ten-minute-break per hour is recommended.

iii

GENERAL NOTES

The following symptoms are normal with LCD monitor and do not indicate a problem.

• Due to the nature of the fluorescent light, the screen may flicker during initial

use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears.

• You may find slightly uneven brightness on the screen depending on the

desktop pattern you use.

• The LCD panel used in this monitor is a very high technology product with

3,932,160 thin film transistors giving you fine picture details. Occasionally, a few non-active pixels may appear on the screen as a fixed point of red, green, blue, white or black. Please note that this does not indicate a defective panel.

• Due to the nature of the LCD screen, an after-image of the previous screen

may remain after switching the image when the same image has been displayed for a long time. The monitor will slowly recover from this.

• LCD monitors have a fixed size & number of pixels. Due to this, an

interpolation is necessary to operate the monitor in a resolution below its native resolution which may slightly de-grade the display quality. Therefore, it is highly recommended to operate this monitor at its native resolution of 1280x1024 @ 60Hz.

OTHER NOTES

• The screen surface is very soft. Do not rub, touch or tap the screen surface

with sharp object such as pen or pencil. This contact may scratch or damage the screen. These damages are not covered under the warranty.

• Turn your computer OFF before installing your new monitor. Refer to your

computer manual for the proper shut down procedure.

• Save the original shipping carton and packing materials, as they will come in

handy if you ever have to ship your monitor.

• For maximum protection, repackage your monitor as it was originally packed

at the factory.

• To keep the monitor looking new, periodically clean the case & surface of the

TFT-LCD panel with a soft non-fibrous cloth lightly dampened with a glass cleaner. Do not use any paper products to clean the screen. Never spay the glass cleaner directly on the monitor. Never use strong solvents such as thinner, benzene, or abrasive cleaners, since these will damage the case & panel. As a safety precaution, always unplug the monitor before cleaning it.

Disclaimer

Envision Peripherals Inc. makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Further, Envision Peripherals Inc. reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation to notify any person of such revision or changes.

Microsoft and Windows are registered trademarks of Microsoft Corporation. All other trademarks remain the property of their respective owners.

Reference Information

For future reference, write the following information about your monitor in the space below. The serial number is found on the back of the product or on the bottom of its stand.

Monitor Information

Product Name: EN7410

Serial Number:

Date of Purchase:

Dealer Information

Dealer:

Telephone Number:

Address:

Table of Contents

1 Important Safety Instructions...........................................i

2 Features.............................................................................2

3 Unpacking the Monitor.....................................................3

4 Hardware Installation .......................................................4

5 Windows driver installation .............................................5

6 Setting the Display Resolution........................................ 6

Choosing the Best Resolution ............................. 6

Supported Graphics Modes and Refresh Rate

Selection.............................................................. 7

7 Adjusting the Monitor..................................................9-12

8 Frequently Asked Questions ....................................13-15

9 Specifications ............................................................16-17
