SHOULD YOU ENCOUNTER ANY PROBLEMS WITH YOUR UNIT CALL
0845 27 27 810
ECO2 Wall
Mr Venty ECO2 WALL
MOISTURE
The typical household creates around
100 pints per week - from showers,
baths, cooking etc.
CHEMICAL EMISSIONS
From everyday household furnishings,
building products etc.
FUMES
From tobacco products, exhaust
gases etc.
DUST
From furniture, carpets, bedding etc.
= Poor Air Quality = Condensation, Damp & Mould
In a dwelling of 4 people, each will contribute
approximately 4 pints of moisture per day –
through showers, boiling kettles, cooking etc
totalling over 100 pints of liquid per week. Other
airborne contaminants which exist in a typical
dwelling like dust, tobacco products, exhaust
gases – even chemical emissions from furnishing
and building products further deteriorate air
quality.
In older, less energy ecient dwellings, there is
a natural escape for this hot, damp problem air –
through ill-tting windows and doors, uncarpeted
oorboards, lofts without insulation and so forth.
Improved building features such as cavity wall
insulation, double-glazing and draft proong
prohibit ‘natural ventilation’. Stale, humid air is
trapped – increasing the condensation problem
in the dwelling.
THE CAUSE OF CONDENSATION, DAMP AND MOULD
SHOULD YOU ENCOUNTER ANY PROBLEMS WITH YOUR CALL
0845 27 27 810
ECO2 Wall
HOW DOES MY ECO2 WALL UNIT WORK?
The ECO2 Wall work by supplying fresh, ltered air throughout the home to transform a stagnant and
stale atmosphere into a fresh, healthy and condensation-free environment.
The
ECO2 Wall delivers air into a home via a single input, usually located in a central hallway.
HOW DOES MY ECO2 WALL UNIT HELP?
It prevents the build-up of moisture in the house, controlling steam/condensation during bathing and
cooking to prevent the formation of black mould on walls, behind cupboards etc. It will also help to stop
general dampness and musty smells caused by poor ventilation.
THE BENEFITS
Say goodbye to condensation & mould
Whole house ventilation
Improved air quality
Musty odours removed
Streaming windows stopped
Condensation control
Enhanced heat distribution
Benets allergy and asthma suerers
SHOULD YOU ENCOUNTER ANY PROBLEMS WITH YOUR UNIT CALL
0845 27 27 810
ECO2 Wall
ENERGY SAVING BENEFITS
Your ECO2 Wall also helps to save energy in the following ways:
Minimum Energy Consumption
Using the latest technology, the units are powered by ultra-low watt motors to achieve low running costs.
Heat Distribution
Warm air accumulates at ceiling level. This air can be up to 7°C higher than the internal air at ground
level. By introducing an air supply, the ECO2 Wall helps to redistribute heat around the home to further
reduce heating costs.
No need to open windows
To reduce humidity and condensation during the heating season, signicant energy loss occurs
by opening windows. The ECO2 Wall provides fresh, ltered air to the home and reduces humidity
without the need to open windows, saving energy and heat loss.
HEALTH BENEFITS:
Reduces mould spores, a trigger for respiratory problems and allergies
Reduces house dust mite populations by lowering humidity levels - a main trigger for asthma and
allergies
HOW DO I CONTROL MY ECO2 WALL UNIT?
Standard automatic mode: On auto the ow rate of the unit will be set at the appropriate level for your home
during installation. To enable or disable the heater press the heater enable switch on or o.
WHAT FEATURES DOES MY ECO2 WALL UNIT HAVE?
The intelligent low temperature comfort heater* is designed to temper the air during periods of low external
temperatures. It is capable of holding incoming air temperatures accurately at 10°C. With the function enabled,
the heater may be on 10% of the time, depending on the fan speed setting and only at loft temperatures at
or below 10°C. The unit has an automatic increased airow setting. This function increases airow rates per
setting by 10% to deliver additional air into the property at temperatures above 19°C.
*Heater may be omitted on request by the customer.
MAINTENANCE
After 3 years the lter located in the unit must be replaced. Screws located on the edge of the cover must
be removed and the cover loosened and removed. Pull on the foam pad on the side of the unit to remove
the lter. Replace the lter and covers ensuring all duct work is securely in place. Work to be carried out by a
technically competent person. When carrying work out to this unit it should be isolated from the main power
supply at the fuse spur.
HOW MUCH DOES MY ECO2 WALL UNIT COST TO RUN?
The ECO2 Wall is very energy ecient. On a constant medium setting with the heater enabled, the unit will cost
around £30* a year to run. With the heater disabled the unit will cost less than £6* a year.
*Based on an average electricity unit price of 15p.
Costs will vary year on year depending on atmospheric conditions and unit settings.
SHOULD YOU ENCOUNTER ANY PROBLEMS WITH YOUR CALL
0845 27 27 810
ECO2 Wall
HELPFUL HINTS AND TIPS
Keeping your home condensation free:
• Try to keep the house as warm as possible for as long as possible
• Do not dry clothes over any radiators
• Vent your tumble dryer outside
• Do not use paran / Calor gas type heating
Energy bills:
To minimise energy bills you may need to adjust the central heating down if the input is in the same
room as your thermostat.
SHOULD YOU ENCOUNTER ANY PROBLEMS WITH YOUR UNIT CALL
0845 27 27 810
ECO2 Wall
WARRANTY CONDITIONS AND EXCLUSIONS
The ECO
2
Wall is covered by a 5 year warranty.
Do not turn your unit o. It is important that the unit runs continuously.
EnviroVent oer customers a full Supply and Fit service. This service also entitles our customers a
unique 5 years parts and labour guarantee and if within the 5 years of installation the unit breaks down,
we will repair it – FREE of charge.
Should you buy the fan from an approved wholesaler the product is protected by a 5 years parts
guarantee and in the highly unlikely event of any problems you can call our helpline number or return
it to the approved wholesaler.
Please note that proof of purchase by the way of a receipt is required and that any fans bought from an
unapproved source, including but not limited to eBay, will render the guarantee invalid.
What should I do if I have a problem?
If, after thoroughly reading this booklet, you feel that your unit is not working correctly, you can
telephone the number shown at the bottom of this page (operational from 8:30am to 5:00pm Monday
to Friday), and ask for technical assistance.
We appreciate you choosing this quality EnviroVent product, which is designed and manufactured to
the highest specication in Harrogate, North Yorkshire. We are condent that you will be delighted
with the performance of the system and the resulting improvement in air quality in your home after the
installation of the unit.
Your warranty covers any defect or break down that arises due to faulty materials or construction.
Terms of Warranty
• The system must be correctly installed and operated according to the instructions contained in the
user guide supplied.
• Periodic cleaning and maintenance must be carried out by a technically competent person.
• The warranty will be rendered invalid if the unit is turned o. Turning the unit o can damage it.
• The warranty does not cover accidental damage, misuse or abuse.
• The warranty is in addition to your statutory or legal rights.
• The guarantee will only be honoured from approved suppliers (i.e. not eBay or similar), and proof of
purchase must be provided.
• A further 5 year warranty can be obtained subject to the level of service carried out at the 5 year
point.
EnviroVent Ltd
EnviroVent House
Hornbeam Business Park
Harrogate
HG2 8PA
T 0845 27 27 807
F 01423 810 910
E enquiries@envirovent.com
www.homeventilation.co.uk
E&OE | MKT ENV251-V3-28.03.14
Due to our policy of continuous innovation and
improvement EnviroVent reserves the right to alter
products specication and appearance without
notice.
For additional information see the installation guide
