Horizontal and Vertical
BELT DRIVE
AIR HANDLING UNITS
QUICK REFERENCE GUIDE
CONFIGURATION • MODEL H, SER. B
NOTES:
1. All dimensions are inches [millimeters].
All dimensions are +
1/4" [6mm].
Metric values are soft conversion.
2. See Drawing BR-001 for rigging hole and base rail details.
3. This drawing for identification of unit configuration only. See
individual unit and section drawings for submittal details.
4. Flat filter rack will be located as required.
5. Supply plenum may not be combined with blow thru electric
heat option.
MODEL V, S ER. B • CONFIGURATION
NOTES:
1. All dimensions are inches [millimeters].
All dimensions are +
1/4" [6mm].
Metric values are soft conversion.
2. See Drawing BR-001 for rigging hole and base rail details.
3. This drawing for identification of unit configuration only. See
individual unit and section drawings for submittal details.
4. Flat filter rack will be located as required.
5. Supply plenum may not be combined with blow thru electric
heat option.
Research & Development,
Engineering, and Manufacturing.
• Variable Volume Terminals
• Fan Coils
• Air Handling Units
• Coils
• Electric Heating Devices
• Electronic Controls
6750 Bryan Dairy Rd. • Largo, FL 33777
www.enviro-tec.com
727-541-3531
©1998 Environmental Technologies, Inc.
Stock ID: CAT-REF-BDAHU
December, 1998
