Page 1

AP350/MNL/070912

’

Page 2

350

table of contents

THANK YOU

Congratulations on purchasing the Allergy

Pro™ professional air puriﬁer and your

commitment to controlling the quality

of your indoor air.

Welcome to an ideal world. With the

Allergy Pro™ professional air puriﬁer,

we provide true HEPA ﬁltration

to purify the air and remove

allergens. Get ready to experience

cleaner, healthier air!

PLEASE NOTE : It is crucial

that you read and follow all the

instructions and safety warnings

SAFETY INSTRUCTIONS 2

PRODUCT BENEFITS 3

KNOWING YOUR ALLERGY PRO

™

AIR PURIFIER 4

Main Parts 4

PROPER USAGE 5

OPERATING YOUR ALLERGY PRO™ AIR PURIFIER 6

Control Panel 6

Digital Display 7

MAINTENANCE 8

Maintaining the Allergy Pro

™

Air Puriﬁer 8

in this manual for optimal

performance of your air puriﬁer

and your health and safety.

TROUBLE-SHOOTING 9

ONE-YEAR LIMITED WARRANTY 11

CUSTOMER SERVICE CONTACT INFORMATION 11

ARBITRATION AGREEMENT 12

Page 3

350

safety instructions

WARNING: RISK OF ELECTRIC SHOCK

Safety precautions should always be used when operating this or any electrical appliance. Decrease the risk of electrocution, electric shock, injury or ﬁre by reading and following all the warnings below.

Use this product only as described in this Allergy Pro To reduce the risk of electric shock, do not attempt to service the product in any way other than in the manner described in the “Maintenance” section of this guide.

Read all instructions before operating the Allergy Pro™ professional air puriﬁer. This product operates at 120V AC, 60Hz only. Do not run the power cord under carpets, or cover with throw rugs. Do not operate the product in a greasy environment such as in the kitchen. This product is

not intended to ﬁlter oil or grease from air.

Do not use the Allergy Pro™ professional air puriﬁer in bathrooms or other humid

environments, near ﬁreplaces or in areas where ﬂammable or combustible vapors or products may exist.

Always unplug the power cord from the electrical outlet when the puriﬁer is not in use,

before cleaning, inserting or removing parts or before moving to another location. Never run the air puriﬁer unless it is fully assembled. To reduce the risk of electric shock, this product has a polarized plug (one blade is wider

than the other). This plug will ﬁt into a polarized outlet only one way. If the plug does not ﬁt

into the outlet, contact qualiﬁed service personnel to install the proper outlet. Do not alter

the plug in any way. Always turn off all controls before unplugging the Allergy Pro™ professional air puriﬁer

from outlet. Attempting to service the Allergy Pro™ professional air puriﬁer in any way not described in

this owner’s guide will void the warranty and could cause serious personal injury to the user

and/or result in considerable damage to the unit. Do not place the cord near a heated surface. Never operate the Allergy Pro™ professional air puriﬁer if the plug or cord is damaged or

appears damaged. Only qualiﬁed service personnel should replace a damaged power cord. Never use the power cord to pick up, carry, drag, pull or lift the Allergy Pro™ professional air

puriﬁer. Do not pull the cord against or around sharp corners and edges. This could result in

injury to the user or damage to the cord. Always remove the plug from its power outlet by holding onto the plug itself and pulling

gently. Never pull on the cord itself to unplug it from its power outlet. Use care when operating the Allergy Pro™ professional air puriﬁer by keeping all foreign

objects, ﬁngers and other body parts, hair, loose clothing and jewelry away from openings. Never touch the Allergy Pro™ professional air puriﬁer or its plug when your hands are wet. The Allergy Pro™ professional air puriﬁer is an electrical appliance. Adult supervision is

required when operating around children.

™

professional air puriﬁer owner’s guide.

product benefits

THE REVOLUTIONARY ALLERGY PRO™ PROFESSIONAL AIR PURIFIER CLEANS AIR WITH A TRUE HEPA FILTER.

The Allergy Pro™ professional air puriﬁer boasts many great features:

True HEPA ﬁlter removes particles from the air.

Effectively removes smoke, pollen, dust, animal dander, dust mites from the air.

Powerful and quiet fan has 4 speed settings to select desired cleaning level.

High clean air efﬁciency with 300 CADR* at high setting.

A twelve hour timer to set the time of operation, from 1 hour up to 12 hours.

Built-in ionizer revitalizes air.

Low power consumption-energy efﬁcient, Energy Star approved.

*Clean Air Delivery Rate as deﬁned by ANSI standards. CADR measures the amount of particlefree air being delivered into the room. The Allergy Pro™ professional air puriﬁer boasts a CADR of 300 – an outstanding performance for an air puriﬁer.

Page 4

350

knowinG tHe allerGy pro™ air purifier

MAIN PARTS

1. Front Grill

2. True HEPA ﬁlter: Captures at least 99.97% of allergens and irritants that pass through the ﬁlter down to 0.1 microns.

3. Air-Outlet

4. Control Panel

5. Digital display: indicates setting and whether the unit is on or off

5)Digital Display

1) Front Grill

4)Control Panel

3)Air Outlet

proper usaGe

Please note: make sure the true HEPA ﬁlter is properly installed before use.

1. Keep both sides of the unit more than 4 inches away from a wall.

2. Do not blow air from a fan or air conditioner directly into the air puriﬁer.

3. Do not place the unit where the air inlet or outlet grill could come in contact with a curtain.

4. Placing the unit close to the source of air pollution can improve indoor air quality effectively.

4 inches

2) True HEPA Filter

Page 5

350

operatinG tHe allerGy pro™ air purifier

Plug the unit into an electrical outlet. The unit will be ready to run. Read the following directions to select desired settings.

CONTROL PANEL

ION

1. Press the ON/OFF button to turn on your air puriﬁer and press it again to turn it off.

2. When the air puriﬁer is turned on, the fan will run at medium speed (this is the default speed). Press the SPEED button to cycle through the fan speeds shown below:

MEDIUM HIGH BOOST LOW

TIMERSPEED ON/OFF

operatinG tHe allerGy pro™ air purifier

DIGITAL DISPLAY

1. Fan Speed Indicator

The ﬁrst bar is lit when the fan speed is on LOW. The ﬁrst two bars are lit when the fan speed is on MEDIUM. The ﬁrst three bars are lit when the fan speed is on HIGH. When all four bars are lit, the fan speed is on BOOST.

The speed selected determines how rapidly you want to sanitize the air. The “LOW” and “MEDIUM” setting is great for everyday use. The “HIGH” setting is great for areas with more airborne contaminants (such as excessive smoke, pet dander, etc), or areas used frequently by allergy-sufferers. The “BOOST” setting is best used for shorter bursts of time when you want to rapidly purify the air.

2. Timer Indicator

The digit of the timer indicates the hour(s) preset. Once the time is set, the timer will start to count down to zero and the unit will then automatically turn off.

3. ION Indicator

The ion light turns on when the ionizer is working and the light turns off when the ionizer stops.

2. Timer Indicator

3. While the fan is running, press the TIMER button to the select the desired run time

(in hours) as shown below:

1H 2H 3H 4H 5H 6H 7H

TIME OFF 12H 11H 10H 9H 8H

4. Press the ION button to turn on the ionizer while the fan is running and press it again

to turn off the ionizer.

ION

ION TIMERSPEED ON/OFF

3. ION

1. Fan Speed Indicator

Page 6

350

maintenance

The Allergy Pro™ professional air puriﬁer is almost maintenance free! Our true HEPA ﬁlter lasts up to twelve months, depending on use and environment conditions. It is recommended to replace the true HEPA ﬁlter every twelve months.

Before replacing the true HEPA ﬁlter of your Allergy Pro turn off and unplug the unit from the electrical outlet and read all safety instructions and important warnings in this owner’s manual.

REPLACING THE TRUE HEPA FILTER

1. Make sure unit is turned off and

unplugged. With the front of the unit facing forward, pull the lid towards you at the upper end of the inlet grill as shown and remove the front grill.

2. Remove the true HEPA ﬁlter by lifting

and pulling the string on both sides of the ﬁlter.

3 . Insert a new true HEPA ﬁlter, then

insert the bottom of the inlet grill ﬁrst and then snap the upper part of the inlet grill back into position.

4 . To close the front grill, ﬁrst make

sure the bottom hooks are properly in place before snapping it up to its upright and locked position.

™

professional air puriﬁer,

troublesHootinG

Before contacting our customer service department, please try the following solutions:

PROBLEM REASON SOLUTION

Unit won’t operate. 1. ON/OFF button hasn’t 1. Press ON/OFF button.

been pressed.

2. Unit is unplugged. 2. Plug in unit.

3. The inlet grill has not been 3. Check to ensure installed or put back in place ﬁlters are properly properly. installed & the inlet grill is installed & locked into place. (See instructions on pg. 8).

Reduced air ﬂow or 1. The inlet or outlet grill may 1. Ensure nothing is in poor ﬁltering. be blocked. front of or on top of the

puriﬁer.

2. The HEPA ﬁlter may be clogged. 2. Check ﬁlter and replace it if necessary. (See instructions on pg. 8).

TO ORDER A REPLACEMENT TRUE HEPA FILTER

The true HEPA ﬁlter should be changed every six months, simply contact our customer service department at 1.800.875.8577.

The Allergy Pro™ replacement true HEPA ﬁlter part number is: TPP350FA

Page 7

350

IF YOU HAVE ANY QUESTIONS REGARDING

YOUR ALLERGY PRO™ PROFESSIONAL AIR PURIFIER:

Please call customer service at:

800.875.8577

Or send mail to:

™

Allergy Pro

/ P.O. Box 9159

Van Nuys, CA 91409-8291

one-year limited warranty

ONE YEAR LIMITED WARRANTY

Your

Allergy Pro™ air puriﬁer for one year from the original purchase date. Should the product have a defect in materials or workmanship, we will repair or replace it without charge to you (a shipping and processing fee will apply). To obtain service under warranty, simply call our customer service center toll-free at

800.875.8577

This warranty does not cover damage caused by accident, misuse or any use other than as intended and described in this product manual, or damage resulting from failure to maintain and clean this product as speciﬁed in this product manual. This warranty applies only to the original purchaser of the

ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD, AND NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THIS PERIOD.

Some states do not allow limitations on the duration of implied warranties, so the above limitation may not apply to you. While this warranty gives you speciﬁc legal rights, you may also have other rights which may vary from state to state.

Allergy Pro™ air puriﬁer

CONTACT INFO FOR WARRANTY SERVICE:

Allergy Pro P.O. Box 9159 | Van Nuys, CA | 91409-8291

800.875.8577 | www.envionproducts.com

™

is warranted to be free from defects in materials and workmanship

Page 8

350

arbitration aGreement

PLEASE READ THIS AGREEMENT CAREFULLY. YOU ACCEPT THE TERMS OF THIS AGREEMENT BY RETAINING THE PRODUCT(S) SHIPPED IN CONNECTION WITH THIS AGREEMENT (THE “PRODUCTS”) FOR MORE THAN THIRTY (30) DAYS AFTER RECEIPT. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT, YOU MAY RETURN THE PRODUCT TO COMPANY WITHIN THIRTY (30) DAYS OF RECEIPT FOR A FULL REFUND.

THIS ARBITRATION AGREEMENT (“AGREEMENT”) AFFECTS YOUR LEGAL RIGHTS AND REMEDIES BY PROVIDING THAT DISPUTES BETWEEN YOU AND THE MANUFACTURER, DISTRIBUTOR AND/OR SELLER OF THIS PRODUCT (COLLECTIVELY, “COMPANY”), MUST BE RESOLVED THROUGH BINDING ARBITRATION AND NOT IN COURT. IT ALSO PROVIDES THAT ANY DISPUTE CANNOT BE RESOLVED IN A CLASS ACTION OR OTHER PROCEEDING WHERE YOU REPRESENT OTHER PERSONS OR OTHER PERSONS REPRESENT YOU, AND THAT NO CLASS OR REPRESENTATIVE ARBITRATIONS ARE PERMITTED. PLEASE CAREFULLY READ ALL TERMS IN THIS AGREEMENT.

1. RESOLUTION OF CLAIMS OR DISPUTES. Any claim or dispute between you and Company (or any of

Company’s subsidiaries or afﬁliates) arising out of or relating in any way to the Product or this Agreement shall be resolved through ﬁnal, binding arbitration. This arbitration obligation is reciprocally binding on both you and the Company and applies regardless of whether the claim or dispute involves a tort, fraud, misrepresentation, product liability, negligence, violation of a statute, or any other legal theory. Both you and Company speciﬁcally acknowledge and agree that you waive your right to bring a lawsuit based on such claims or disputes and to have such lawsuit resolved by a judge or jury.

2. LIMITATION OF LEGAL REMEDIES. All arbitrations under this Agreement shall be conducted on an individual (and not a class-wide) basis, and an arbitrator shall have no authority to award class-wide relief. You acknowledge and agree that this Agreement speciﬁcally prohibits you and the Company from commencing arbitration proceedings as a representative of others or joining in any arbitration proceedings brought by any other person. The parties agree that no class or representative actions of any type are permitted.

3. ARBITRATION PROCEDURES.

a. Before instituting an arbitration, if you have any dispute, we strongly encourage you to contact the

Company to try to resolve the matter by calling 800-218-3560, although you are not required to do so.

b. The arbitration of any claim or dispute under this Agreement shall be conducted in accordance with the

expedited procedures set for th in the JAMS Comprehensive Arbitration Rules and Procedures as those Rules exist on the date you receive the Product, including Rules 16.1 and 16.2 of those Rules. These rules and procedures are available by calling JAMS or by visiting its web site at www.jamsadr.com. The arbitration of any claim or dispute under this Agreement shall be conducted by an arbitrator who has at least ﬁve years of experience conducting arbitrations.

c. The arbitration of any claim or dispute under this Agreement shall be conducted in the State of California

or the location in which you received this Agreement. For claims of $10,000 or less, you may choose whether the arbitration proceeds in person, by telephone, or based only on submissions.

d. The Company shall pay costs for the arbitration of claims, including any JAMS Case Management Fee and

all professional fees for the arbitrator’s services. The Company shall pay the fees and costs of its own counsel, experts and witnesses and shall not be able to recoup them from you even if you do not prevail in the arbitration. Unless other wise provided by law, you acknowledge and agree that you shall pay the fees and costs of your own counsel, experts and witnesses.

4. CHOICE OF LAW. The arbitration provisions of this Agreement and any arbitration conducted pursuant to the terms of this Agreement shall be governed by the Federal Arbitration Act (9 U.S.C. Secs. 1-16). In this respect, the parties acknowledge that this Agreement involves a transaction conducted in interstate commerce. Otherwise, this Agreement and the rights of the parties hereunder shall be governed by and construed in accordance with the laws of the State of California, exclusive of conﬂict or choice of law rules.

5. SEVERABILITY. If any provision of this Agreement is declared or found to be unlawful, unenforceable or void, such provision will be ineffective only to the extent that it is found unlawful, unenforceable or void, and the remainder of the provision and all other provisions shall remain fully enforceable.

notes
