ENTES ES-32LS User guide

WATT-HOUR METER with RS-485 COMMUNICATION (SINGLE PHASE)

ES-32LS

ENGLISH

Front Panel Connection Diagram

Neutral Output

6 4

GND A

Load

3

N

Neutral Input

B

1

phase input

phase output

L

RS-485

Neutral Output
Neutral Input

GND
B

RS-485

A

Counter
6+1 digit (000000,0 kWh)

S

ES-32LS 230V 5(32) A

Pulse LED

Phase Output

Phase Input

By flashing, the LED on the front panel makes it possible toobserve whether the

measuring is active or not.

The LCD display on the front panel makes easy and accurate power reading possible.
Note: User can not reset index. If the value of index exceed 999999.9, it is resetted
automatically and continue to count.

Watt-Hour Meter with LCD

In today's world, Efficient Power Management is very important for low-cost. Measuring process must
have been fulfilled with certain accuracy for precise analysing and measuring the energy.
ES-32LS measures the active watt hour consumption directly and error free in single phase systems
and it shows the total watt hour consumption.
The most important features of the device are its reliability, small size, light weight, modern design, and
easy installation.

Communication

This device has RS-485 communication infstructure for remote monitoring.

At first start, device displays the screen located below for 1 second. Here;

read and written at the ModBus registers address.

Show ModBus register adress between 001-247First 3 digits : s

Shows communication baudrate as 0=1200, 1=2400,2=4800, 3=9600,4=19200, 5=384005th digit :

Shows parity type as 0 = No, 1 = Odd, 2 = Even Parity type. These parameters can be also7th digit :

247 5 2

Parity

Factory settings

1-247 1-100

0:1200, 1:2400, 2:4800,
3:9600, 4:19200, 5:38400

0:No, 1:Odd, 2:Even

0-15258

0-65535

0-65535

3

0

0

0

-

*

ModBus register adress:

R/W

Adres

1

2

3

4

5

6

Definition Range

R/W

Modbus address

R/W

Baud rate

Parity

R/W

Index

R

(High 16 bit)(Wh)

Index

R

(Low 16 bit)(Wh)

Voltage (100xV)

R

Address Baud

Index values are shown with this formula

Index = 65536 x register[4] + register[5]

Cautions

1. Connect the ES-32LS's terminals as shown in connection diagram.

ES-32LS does not require any periodical maintenance.2.
Installing, repairing and operation should be performed by authorized person.3.
Do not open the device. It does not include any parts that can be handled by users.4.
Do not use the device out of its purpose.5.
Before operating your device, make sure that all connections are made properly.6.
Please contact your dealer for any type of service required.7.
Entes A.Ş. will not be responsible,8.

if your device fails because of improper installation.
if your device fails because of natural disasters (fire, lighting, etc.).
if your device fails because of liquid penetration into the device or contact to any liquid for any
reason.
if the device or its software is interfered for any purposes.
if the serial number on the device is damaged.
if the device is out of order because of improper and careless use.
if the device is out of order defected during transportation out of Entes's responsibility.

Applications

Some applications of ES-32LS are:

Factories
Shopping Malls
Airports
Railway Stations

Stores
Building Complexes
Hotels
Hospitals

Schools
Holiday Villages
Marinas
Industrial Exhibition Halls.

Technical Specifications

:

Operating Voltage (Un)
Operating Frequency
Rated Current (In)
Current Range ( I)
Accuracy
Power Consumption
Display
Data retention duration
Pulse LED
Communication interface
Communication baudrate
Parity
ModBus Adress
Operating Temperature
Storage Temperature
Box Protection Class
Cable Section
EMC / Pollution Stability

Surge Voltage Test

TestEFT
Installation
Weight

Please look at labels on the device.

:

50/60 Hz.

:

5 A (maximum 32A)

`

:

0.02-32A

:

Class B (EN-50470-1)

:

< 2 VA

:

6+1 digit = 999999,9 kWh

:

> 40 year

:

When the current is more than 0.02A it blinks proportional to the consumed energy.

:

RS-485 ModBus RTU

:

1200, 2400, 4800, 9600, 19200, 38400

:

No, Odd, Even

:

1-247

:

- °C .... + 5 °C25 5

:

- °C .... + °C40 70

:

IP51

:

4 mm²

4 kV 1.2 / 50 µs. (IEC 1000-4-5)
4 kV (IEC 1000-4-4)
Standart DIN mount (DIN EN60715)
60 gr. (excluding the packet)

Dimensions:

63

49

29

62

45

35

87

19

Current (mA)

R

7

8

R

Frequency (100xHz)

9

10

11

12

The last two digits of the device serial number is used as modbus address

*

factory default value. If the last two digits are “00”, 100 is used for device’s
Modbus address. All devices in the package are placed in order.

Power Factor

R

(1000x)

Active Power

R

(100xkW)

Reactive Power

R

(100xkVAr)

Apparent Power

R

(100xkVA)

0-65535

0-65535

0-65535

0-65535

0-65535

0-65535

-

-

-

Note: Should not be used for billing purposes.
