Enterasys RoamAbout
RBT-4102, RBT-4102-BG, RBT-4102C,
RBT-4102C-EU, and RBT-4102-EU
Wireless Access Point
®
Installation Guide
P/N 9034148-16
NOTICE
ELECTRICAL HAZARD: Only qualified personnel should perform installation
procedures.
Riesgo Electrico: Solamente personal calificado debe realizar
procedimientos de instalacion.
Elektrischer Gefahrenhinweis: Installationen sollten nur durch
ausgebildetes und qualifiziertes Personal vorgenommen werden.
ENTERASYS NETWORKS reserves the right to make changes in specifications and
other information contained in this document and its web site without prior notice. The
reader should in all cases consult ENTERASYS NETWORKS to determine whether any
such changes have been made.
The hardware, firmware, or software described in this document is subject to change
without notice.
IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL,
INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING
BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS
DOCUMENT, WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN IF
ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE
KNOWN OF, THE POSSIBILITY OF SUCH DAMAGES.
Enterasys Networks, Inc.
50 Minuteman Road
Andover, MA 01810
© 2007 Enterasys Networks, Inc. All rights reserved.
Part Number: 9034148-16 July 2007
ENTERASYS, ENTERASYS NETWORKS, ENTERASYS ROAMABOUT, LANVIEW,
NETSIGHT, ROAMABOUT, WEBVIEW, and any logos associated therewith, are
trademarks or registered trademarks of Enterasys Networks, Inc. in the United States and
other countries.
All other product names mentioned in this manual may be trademarks or registered
trademarks of their respective companies.
Documentation URL: http://www.enterasys.com/support/manuals
Documentacion URL: http://www.enterasys.com/support/manuals
Dokumentation im Internet: http://www.enterasys.com/support/manuals
i
Compliances
COMPLIANCES
RBT-4102, RBT-4102-BG, and RBT-4102-EU
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
• Consult the dealer or an experienced radio/TV technician for help
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment. This
device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to
channels 1 through 11.
IMPORTANT NOTE:
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance
of 70 centimeters (27.5 inches) between the radiator and your body. This transmitter
must not be co-located or operating in conjunction with any other antenna or transmitter.
ii
Wireless 5 GHz Band Statements:
A
N826
As the Access Point can operate in the 5150-5250 MHz frequency band it is limited by
the FCC, Industry Canada and some other countries to indoor use only so as to reduce
the potential for harmful interference to co-channel Mobile Satellite systems.
High power radars are allocated as primary users (meaning they have priority) of the
5250-5350 MHz and 5650-5850 MHz bands. These radars could cause interference and
/or damage to the access point when used in Canada.
The term “IC:” before the radio certification number only signifies that Industry Canada
technical specifications were met.
Wireless 4.9 GHz Band Statement:
Installation and operation requires an approved license from the FCC.
Industry Canada - Class B
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus as set out in the interference-causing equipment standard entitled
“Digital Apparatus,” ICES-003 of Industry Canada.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux
appareils numériques de Classe B prescrites dans la norme sur le matérial brouilleur:
“Appareils Numériques,” NMB-003 édictée par l’Industrie.
Industry Canada Statement
Operation is subject to the following two conditions:
1) This device may not cause interference and
2) This device must accept any interference, including interference that may cause
undesired operation of the device
This device has been designed to operate with an antenna having a maximum gain of
23 dB. Antenna having a higher gain is strictly prohibited per regulations of Industry
Canada. The required antenna Impedance is 50 ohms.
To reduce potential radio interference to other users, the antenna type and its gain should
be so chosen that the EIRP is not more than required for successful communication.
Because high power radars are allocated as primary users (meaning they have priority) in
5250-5350 MHz, these radars could cause interference and/or damage to license exempt
LAN devices.
RBT-4102-EU
Australia/New Zealand AS/NZS 4771
Japan Telec Approval
iii
Compliances
003NY05152
003GZ05053
003WY05076
003UX05009
EC Conformance Declaration
Marking by the above symbol indicates compliance with the Essential Requirements of
the R&TTE Directive of the European Union (1999/5/EC). This equipment meets the
following conformance standards:
• EN 60950 (IEC 60950) - Product Safety
• EN 301 893 - Technical requirements for 5 GHz radio equipment
• EN 300 328 - Technical requirements for 2.4 GHz radio equipment
• EN 301 489-1 / EN 301 489-17 - EMC requirements for radio equipment
Countries of Operation & Conditions of Use in the European Community
This device is intended to be operated in all countries of the European Community.
Requirements for indoor vs. outdoor operation, license requirements and allowed
channels of operation apply in some countries as described below:
Note: The user must use the configuration utility provided with this product to ensure the
channels of operation are in conformance with the spectrum usage rules for European
Community countries as described below.
• This device requires that the user or installer properly enter the current country of operation
in the command line interface as described in the user guide, before operating this device.
• This device will automatically limit the allowable channels determined by the current country
of operation. Incorrectly entering the country of operation may result in illegal operation and
may cause harmful interference to other system. The user is obligated to ensure the device
is operating according to the channel limitations, indoor/outdoor restrictions and license
requirements for each European Community country as described in this document.
• This device employs a radar detection feature required for European Community operation
in the 5 GHz band. This feature is automatically enabled when the country of operation is
correctly configured for any European Community country. The presence of nearby radar
operation may result in temporary interruption of operation of this device. The radar detection
feature will automatically restart operation on a channel free of radar.
• The 5 GHz Turbo Mode feature is not allowed for operation in any European Community
country. The current setting for this feature is found in the 5 GHz 802.11a Radio Settings
Window as described in the user guide.
• The 5 GHz radio's Auto Channel Select setting described in the user guide must always
remain enabled to ensure that automatic 5 GHz channel selection complies with European
requirements. The current setting for this feature is found in the 5 GHz 802.11a Radio
Settings Window as described in the user guide.
• This device is restricted to indoor use when operated in the European Community using the
5.15 - 5.35 GHz band: Channels 36, 40, 44, 48, 52, 56, 60, 64.
• This device may be operated indoors or outdoors in all countries of the European Community
using the 2.4 GHz band: Channels 1 - 13, except where noted below.
- In France outdoor operation is only permitted using the 2.4 - 2.454 GHz band:
Channels 1 - 7.
iv
Operation Using 5 GHz Channels in the European Community
The user/installer must use the provided configuration utility to check the current channel
of operation and make necessary configuration changes to ensure operation occurs in
conformance with European National spectrum usage laws as described below and
elsewhere in this document.
Allowed 5GHz Channels in Each European Community Country
Allowed Frequency Bands Allowed Channel Numbers Countries
5.15 - 5.35* & 5.470 - 5.725 GHz 36, 40, 44, 48, 52, 56, 60, 64,
100, 104, 108, 112, 116, 120,
124, 128, 132, 136, 140
5 GHz Operation Not Allowed None Greece, Hungary
* Outdoor operation is not allowed using 5.15-5.35 GHz bands (Channels 36 - 64).
Austria, Belgium,
Cyprus, Czech
Republic, Denmark,
Estonia, Finland,
France, Germany,
Iceland, Ireland, Italy,
Latvia, Liechtenstein,
Lithuania, Luxembourg,
Malta, Netherlands,
Norway, Poland,
Portugal, Slovakia,
Slovenia, Spain,
Sweden, Switzerland,
U.K.
Countries of Operation & Conditions of Use in the Asia, Pacific, and Middle
East Communities
This device is intended to be operated in all countries listed below of the Asia, Pacific,
and Middle East Community. Requirements for indoor vs. outdoor operation, license
requirements and allowed channels of operation apply in some countries as described
below:
Note: The user must use the configuration utility provided with this product to ensure the
channels of operation are in conformance with the spectrum usage rules for countries
as described below.
• This device requires that the user or installer properly enter the current country of operation
in the command line interface as described in the user guide, before operating this device.
• This device will automatically limit the allowable channels determined by the current country
of operation. Incorrectly entering the country of operation may result in illegal operation and
may cause harmful interference to other system.
The user is obligated to ensure the device is operating according to the channel limitations,
indoor/outdoor restrictions and license requirements for each country as described in this
document.
• This device employs a radar detection feature required for operation in the 5 GHz band. This
feature is automatically enabled when the country of operation is correctly configured for any
of the countries listed below. The presence of nearby radar operation may result in temporary
interruption of operation of this device. The radar detection feature will automatically restart
operation on a channel free of radar.
v
Compliances
• The 5 GHz Turbo Mode feature is not allowed for operation in any of the countries. The
current setting for this feature is found in the 5 GHz 802.11a Radio Settings Window as
described in the user guide.
• The 5 GHz radio's Auto Channel Select setting described in the user guide must always
remain enabled to ensure that automatic 5 GHz channel selection complies with
requirements. The current setting for this feature is found in the 5 GHz 802.11a Radio
Settings Window as described in the user guide.
• This device is restricted to indoor use when operated using the 5.15 - 5.35 GHz band:
Channels 36, 40, 44, 48, 52, 56, 60, 64.
Operation Using 5 GHz Channels in the Asia, Pacific, and Middle East
Community
The user/installer must use the provided configuration utility to check the current channel
of operation and make necessary configuration changes to ensure operation occurs in
conformance with the spectrum usage laws as described below and elsewhere in this
document.
Asia, Pacific, and Middle East usage of 5GHz Channels
Country Allowed Frequency Band Allowed Channel Numbers Usage
Singapore 5.15 - 5.35 GHz 36 - 64 Indoors only
Israel 5.15 - 5.35 GHz 36 - 64 Indoors/Outdoors
Korea 5.15 - 5.35
5.725 - 5.825
36 - 64
149- 161
Indoors only
Indoors/Outdoors
vi
RBT-4102C and RBT-4102C-EU
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
• Consult the dealer or an experienced radio/TV technician for help
FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment. This device complies
with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels
1 through 11.
IMPORTANT NOTE:
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 70
centimeters (27.5 inches) between the radiator and your body. This transmitter must not be
co-located or operating in conjunction with any other antenna or transmitter.
Wireless 5 GHz Band Statements:
As the Access Point can operate in the 5150-5250 MHz frequency band it is limited by the
FCC, Industry Canada and some other countries to indoor use only so as to reduce the
potential for harmful interference to co-channel Mobile Satellite systems.
High power radars are allocated as primary users (meaning they have priority) of the
5150-5250 MHz and 5650-5850 MHz bands. These radars could cause interference and /or
damage to the access point when used in Canada.
The term “IC:” before the radio certification number only signifies that Industry Canada
technical specifications were met.
Industry Canada - Class B
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital
apparatus as set out in the interference-causing equipment standard entitled “Digital
Apparatus,” ICES-003 of Industry Canada.
vii
Compliances
A
N826
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux
appareils numériques de Classe B prescrites dans la norme sur le matérial brouilleur:
“Appareils Numériques,” NMB-003 édictée par l’Industrie.
Industry Canada Statement
Operation is subject to the following two conditions:
1) This device may not cause interference and
2) This device must accept any interference, including interference that may cause undesired
operation of the device
This device has been designed to operate with an antenna having a maximum gain of 23 dB.
Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The
required antenna Impedance is 50 ohms.
To reduce potential radio interference to other users, the antenna type and its gain should be
so chosen that the EIRP is not more than required for successful communication.
RBT-4102C-EU
Australia/New Zealand AS/NZS 4771
Japan Telec Approval
003NY05152
003GZ05053
003WY05076
003UX05009
EC Conformance Declaration
Marking by the above symbol indicates compliance with the Essential Requirements of the
R&TTE Directive of the European Union (1999/5/EC). This equipment meets the following
conformance standards:
• EN 60950 (IEC 60950) - Product Safety
• EN 301 893 - Technical requirements for 5 GHz radio equipment
• EN 300 328 - Technical requirements for 2.4 GHz radio equipment
• EN 301 489-1 / EN 301 489-17 - EMC requirements for radio equipment
viii
Countries of Operation & Conditions of Use in the European Community
This device is intended to be operated in all countries of the European Community.
Requirements for indoor vs. outdoor operation, license requirements and allowed channels of
operation apply in some countries as described below:
Note: The user must use the configuration utility provided with this product to ensure the
channels of operation are in conformance with the spectrum usage rules for European
Community countries as described below.
• This device requires that the user or installer properly enter the current country of operation
in the command line interface as described in the user guide, before operating this device.
• This device will automatically limit the allowable channels determined by the current country
of operation. Incorrectly entering the country of operation may result in illegal operation and
may cause harmful interference to other system. The user is obligated to ensure the device
is operating according to the channel limitations, indoor/outdoor restrictions and license
requirements for each European Community country as described in this document.
• The 5 GHz Turbo Mode feature is not allowed for operation in any European Community
country. The current setting for this feature is found in the 5 GHz 802.11a Radio Settings
Window as described in the user guide.
• The 5 GHz radio's Auto Channel Select setting described in the user guide must always
remain enabled to ensure that automatic 5 GHz channel selection complies with European
requirements. The current setting for this feature is found in the 5 GHz 802.11a Radio
Settings Window as described in the user guide.
• This device is restricted to indoor use when operated in the European Community using the
5.15 - 5.25 GHz band: Channels 36, 40, 44, 48.
• This device may be operated indoors or outdoors in all countries of the European Community
using the 2.4 GHz band: Channels 1 - 13, except where noted below.
- In France outdoor operation is only permitted using the 2.4 - 2.454 GHz band:
Channels 1 - 7.
ix
Compliances
Operation Using 5 GHz Channels in the European Community
The user/installer must use the provided configuration utility to check the current channel of
operation and make necessary configuration changes to ensure operation occurs in
conformance with European National spectrum usage laws as described below and elsewhere
in this document.
Allowed 5GHz Channels in Each European Community Country
Allowed Frequency Bands Allowed Channel Numbers Countries
5.15 - 5.25* GHz 36, 40, 44, 48 Austria, Belgium,
* Outdoor operation is not allowed using 5.15-5.25 GHz bands (Channels 36 - 48).
Cyprus, Czech
Republic, Denmark,
Estonia, Finland,
France, Germany,
Greece, Hungary,
Iceland, Ireland, Italy,
Latvia, Liechtenstein,
Lithuania, Luxembourg,
Malta, Netherlands,
Norway, Poland,
Portugal, Slovakia,
Slovenia, Spain,
Sweden, Switzerland,
U.K.
Countries of Operation & Conditions of Use in the Asia, Pacific, and Middle
East Communities
This device is intended to be operated in all countries listed below of the Asia, Pacific, and
Middle East Community. Requirements for indoor vs. outdoor operation, license requirements
and allowed channels of operation apply in some countries as described below:
Note: The user must use the configuration utility provided with this product to ensure the
channels of operation are in conformance with the spectrum usage rules for countries
as described below.
• This device requires that the user or installer properly enter the current country of operation
in the command line interface as described in the user guide, before operating this device.
• This device will automatically limit the allowable channels determined by the current country
of operation. Incorrectly entering the country of operation may result in illegal operation and
may cause harmful interference to other system. The user is obligated to ensure the device
is operating according to the channel limitations, indoor/outdoor restrictions and license
requirements for each country as described in this document.
• This device employs a radar detection feature required for operation in the 5 GHz band. The
presence of nearby radar operation may result in temporary interruption of operation of this
device.
• The 5 GHz Turbo Mode feature is not allowed for operation in any of the countries. The
current setting for this feature is found in the 5 GHz 802.11a Radio Settings Window as
described in the user guide.
• The 5 GHz radio's Auto Channel Select setting described in the user guide must always
x
remain enabled to ensure that automatic 5 GHz channel selection complies with
requirements. The current setting for this feature is found in the 5 GHz 802.11a Radio
Settings Window as described in the user guide.
• This device is restricted to indoor use when operated using the 5.15 - 5.25 GHz band:
Channels 36, 40, 44, 48.
Operation Using 5 GHz Channels in the Asia, Pacific, and Middle East
Community
The user/installer must use the provided configuration utility to check the current channel of
operation and make necessary configuration changes to ensure operation occurs in
conformance with the spectrum usage laws as described below and elsewhere in this
document.
Asia, Pacific, and Middle East usage of 5GHz Channels
Country Allowed Frequency Band Allowed Channel Numbers Usage
Singapore 5.15 - 5.35 GHz 36 - 64 Indoors only
Israel 5.15 - 5.35 GHz 36 - 64 Indoors/Outdoors
Korea 5.15 - 5.35
5.725 - 5.825
36 - 64
149- 161
Indoors only
Indoors/Outdoors
EC-Konformitätserklärung
Die Kennzeichnung mit dem obigen Symbol zeigt die Übereinstimmung mit den wichtigen
Anforderungen der R&TTE-Direktive der Europäischen Union (1999/5/EC) an. Dieses Gerät
erfüllt die folgenden Konformitätsstandards:
• EN 60950 (IEC 60950) - Produktsicherheit
• EN 301 893 - Technische Anforderungen für 5-GHz-Hochfrequenzgeräte
• EN 300 328 - Technische Anforderungen für 2,4-GHz-Hochfrequenzgeräte
• EN 301 489-1 / EN 301 489-17 - EMV-Anforderungen für Hochfrequenzgeräte
• Bei der Verwendung des Geräts in der Europäische Gemeinschaft im 5,15 - 5,25 GHz-Band
ist es auf die Verwendung in Räumen beschränkt: Kanäle 36, 40, 44, 48.
• Bei der Verwendung des 2,4-GHz-Bands darf das Gerät in allen Ländern der Europäischen
Gemeinschaft sowohl in Räumen als auch im Freien benutzt werden: Kanäle 1 - 13, außer
wenn unten aufgeführt.
- In Frankreich ist der Betrieb im Freien nur bei der Verwendung des 2,4 - 2,454 GHz-Bands
zugelassen: Kanäle 1 - 7.
xi
Compliances
DECLARATION OF CONFORMITY IN LANGUAGES OF THE EUROPEAN
COMMUNITY
English Hereby, Enterasys, declares that this Radio LAN device is in compliance with
Finnish (FI) Valmistaja Enterasys vakuuttaa täten että Radio LAN device tyyppinen laite on
Dutch (NL) Hierbij verklaart Enterasys dat het toestel Radio LAN device in overeenstem-
French (FR) Par la présente Enterasys déclare que l'appareil Radio LAN device est con-
Swedish (SE) Härmed intygar Enterasys att denna Radio LAN device står I överensstäm-
Danish (DK) Undertegnede Enterasys erklærer herved, at følgende udstyr Radio LAN de-
German (DE) Hiermit erklärt Enterasys, dass sich dieser/diese/dieses Radio LAN device in
the essential requirements and other relevant provisions of Directive 1999/5/
EC.
A copy of the original Declaration of conformity can be obtained from
Enterasys Networks, 50 Minuteman Road, Andover, Ma 01810, USA.
direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin
muiden ehtojen mukainen.
Yhdenmukaisuuden alkuperäisen julistuksen kopio voidaan saada
Enterasys Networks, 50 Minuteman Road, Andover, Ma 01810, USA.
ming is met de essentiële eisen en de andere relevante bepalingen van richtlijn
1999/5/EG.
Bij deze Enterasys dat deze Radio LAN device voldoet aan de essentiële eisen
en aan de overige relevante bepalingen van Richtlijn 1999/5/EC.
Een exemplaar van de oorspronkelijke Verklaring van overeenstemming kan
worden verkregen uit Enterasys Networks, 50 Minuteman Road,
Andover, Ma 01810, USA.
forme aux exigences essentielles et aux autres dispositions pertinentes de la
directive 1999/5/CE.
Une copie de la déclaration originale de la conformité peut être obtenue à partir
Enterasys Networks, 50 Minuteman Road, Andover, Ma 01810, USA.
melse med de väsentliga egenskapskrav och övriga relevanta bestämmelser
som framgår av direktiv 1999/5/EG.
EN kopia om original Tillkännagivande av likheten kanna bli få från
Enterasys Networks, 50 Minuteman Road, Andover, Ma 01810, USA.
vice overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/
EF.
EN afskrift i den selvstændig Påstand i lighed kan opnåede af Enterasys Networks, 50 Minuteman Road, Andover, Ma 01810, USA.
Übereinstimmung mit den grundlegenden Anforderungen und den anderen relevanten Vorschriften der Richtlinie 1999/5/EG befindet".
Eine Kopie der ursprünglichen Erklärung der Übereinstimmung kann von erhalten werden Enterasys Networks, 50 Minuteman Road, Andover, Ma 01810,
USA.
xii
Greek (GR) με την παρουσα Enterasys δηλωνει οτι radio LAN device συμμορφωνεται
Italian (IT) Con la presente Enterasys dichiara che questo Radio LAN device è conforme
Spanish (ES) Por medio de la presente Enterasys declara que el Radio LAN device cumple
Portuguese
(PT)
προσ τισ ουσιωδεισ απαιτησεισ και τισ λοιπεσ σΧετικεσ διαταξεισ τησ οδηγιασ
1999/5/εκ.
Ένα αντίγραφο της αρχικής ∆ιακήρυξης της συμμόρφωσης μπορεί να ληφθεί
από Enterasys Networks, 50 Minuteman Road, Andover, Ma 01810, USA.
ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva
1999/5/CE.
Una copia della dichiarazione originale di conformità può essere ottenuta da
Enterasys Networks, 50 Minuteman Road, Andover, Ma 01810, USA.
con los requisitos esenciales y cualesquiera otras disposiciones aplicables o
exigibles de la Directiva 1999/5/CE.
Una copia del declaración original de la conformidad se puede obtener de Enterasys Networks, 50 Minuteman Road, Andover, Ma 01810, USA.
Enterasys declara que este Radio LAN device está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Uma cópia da declaração original do conformity pode ser obtida de
Enterasys Networks, 50 Minuteman Road, Andover, Ma 01810, USA.
xiii
Compliances
SAFETY COMPLIANCE
Power Cord Safety
Please read the following safety information carefully before installing the access point:
WARNING: Installation and removal of the unit must be carried out by qualified personnel only.
• The unit must be connected to an earthed (grounded) outlet to comply with international
safety standards.
• Do not connect the unit to an A.C. outlet (power supply) without an earth (ground)
connection.
• The appliance coupler (the connector to the unit and not the wall plug) must have a
configuration for mating with an EN 60320/IEC 320 appliance inlet.
• The socket outlet must be near to the unit and easily accessible. You can only remove power
from the unit by disconnecting the power cord from the outlet.
• This unit operates under SELV (Safety Extra Low Voltage) conditions according to IEC
60950. The conditions are only maintained if the equipment to which it is connected also
operates under SELV conditions.
France and Peru only
This unit cannot be powered from IT
powered by 230 V (2P+T) via an isolation transformer ratio 1:1, with the secondary connection
point labelled Neutral, connected directly to earth (ground).
†
Impédance à la terre
Important! Before making connections, make sure you have the correct cord set. Check it
(read the label on the cable) against the following:
†
supplies. If your supplies are of IT type, this unit must be
Power Cord Set
U.S.A. and Canada The cord set must be UL-approved and CSA certified.
The minimum specifications for the flexible cord are:
- No. 18 AWG - not longer than 2 meters, or 16 AWG.
- Type SV or SJ
- 3-conductor
The cord set must have a rated current capacity of at least 10 A.
The attachment plug must be an earth-grounding type with NEMA
5-15P (15 A, 125 V) or NEMA 6-15P (15 A, 250 V) configuration.
Denmark The supply plug must comply with Section 107-2-D1, Standard
Switzerland The supply plug must comply with SEV/ASE 1011.
U.K. The supply plug must comply with BS1363 (3-pin 13 A) and be fitted
DK2-1a or DK2-5a.
with a 5 A fuse which complies with BS1362.
The mains cord must be <HAR> or <BASEC> marked and be of type
HO3VVF3GO.75 (minimum).
xiv
Power Cord Set
Europe The supply plug must comply with CEE7/7 (“SCHUKO”).
The mains cord must be <HAR> or <BASEC> marked and be of type
HO3VVF3GO.75 (minimum).
IEC-320 receptacle.
xv
Compliances
HAZARDOUS SUBSTANCES
This product complies with the requirements of European Directive, 2002/95/EC, Restriction of
Hazardous Substances (RoHS) in Electrical and Electronic Equipment
EUROPEAN WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT
(WEEE) NOTICE
In accordance with Directive 2002/96/EC of the European Parliament on waste electrical and
electronic equipment (WEEE):
1. The symbol above indicates that separate collection of electrical and electronic equipment
is required and that this product was placed on the European market after August 13, 2005,
the date of enforcement for Directive 2002/96/EC.
2. When this product has reached the end of its serviceable life, it cannot be disposed of as
unsorted municipal waste. It must be collected and treated separately.
3. It has been determined by the European Parliament that there are potential negative
effects on the environment and human health as a result of the presence of hazardous
substances in electrical and electronic equipment.
4. It is the users’ responsibility to utilize the available collection system to ensure WEEE is
properly treated.
For information about the available collection system, please go to
http://www.enterasys.com/services/support/
353 61 705586 (Ireland).
, or contact Enterasys Customer Support at
xvi
ENTERASYS NETWORKS, INC. FIRMWARE LICENSE AGREEMENT
BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT,
CAREFULLY READ THIS LICENSE AGREEMENT.
This document is an agreement (“Agreement”) between the end user (“You”) and
Enterasys Networks, Inc. on behalf of itself and its Affiliates (as hereinafter defined)
(“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys
software program/firmware installed on the Enterasys product (including any
accompanying documentation, hardware or media) (“Program”) in the package and
prevails over any additional, conflicting or inconsistent terms and conditions appearing on
any purchase order or other document submitted by You. “Affiliate” means any person,
partnership, corporation, limited liability company, or other form of enterprise that directly
or indirectly through one or more intermediaries, controls, or is controlled by, or is under
common control with the party specified. This Agreement constitutes the entire
understanding between the parties, and supersedes all prior discussions,
representations, understandings or agreements, whether oral or in writing, between the
parties with respect to the subject matter of this Agreement. The Program may be
contained in firmware, chips or other media.
BY INSTALLING OR OTHERWISE USING THE PROGRAM, YOU REPRESENT THAT
YOU ARE AUTHORIZED TO ACCEPT THESE TERMS ON BEHALF OF THE END
USER (IF THE END USER IS AN ENTITY ON WHOSE BEHALF YOU ARE
AUTHORIZED TO ACT, “YOU” AND “YOUR” SHALL BE DEEMED TO REFER TO
SUCH ENTITY) AND THAT YOU AGREE THAT YOU ARE BOUND BY THE TERMS OF
THIS AGREEMENT, WHICH INCLUDES, AMONG OTHER PROVISIONS, THE
LICENSE, THE DISCLAIMER OF WARRANTY AND THE LIMITATION OF LIABILITY. IF
YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT OR ARE NOT
AUTHORIZED TO ENTER INTO THIS AGREEMENT, ENTERASYS IS UNWILLING TO
LICENSE THE PROGRAM TO YOU AND YOU AGREE TO RETURN THE UNOPENED
PRODUCT TO ENTERASYS OR YOUR DEALER, IF ANY, WITHIN TEN (10) DAYS
FOLLOWING THE DATE OF RECEIPT FOR A FULL REFUND.
IF YOU HAVE ANY QUESTIONS ABOUT THIS AGREEMENT, CONTACT ENTERASYS
NETWORKS, LEGAL DEPARTMENT AT (978) 684-1000.
You and Enterasys agree as follows:
1. LICENSE. You have the non-exclusive and non-transferable right to use only the one
(1) copy of the Program provided in this package subject to the terms and conditions
of this Agreement.
2. RESTRICTIONS. Except as otherwise authorized in writing by Enterasys, You may
not, nor may You permit any third party to:
(i) Reverse engineer, decompile, disassemble or modify the Program, in whole or
in part, including for reasons of error correction or interoperability, except to the
extent expressly permitted by applicable law and to the extent the parties shall
not be permitted by that applicable law, such rights are expressly excluded.
Information necessary to achieve interoperability or correct errors is available
from Enterasys upon request and upon payment of Enterasys’ applicable fee.
(ii) Incorporate the Program, in whole or in part, in any other product or create
xvii
Compliances
derivative works based on the Program, in whole or in part.
(iii) Publish, disclose, copy, reproduce or transmit the Program, in whole or in part.
(iv) Assign, sell, license, sublicense, rent, lease, encumber by way of security
interest, pledge or otherwise transfer the Program, in whole or in part.
(v) Remove any copyright, trademark, proprietary rights, disclaimer or warning
notice included on or embedded in any part of the Program.
3. APPLICABLE LAW. This Agreement shall be interpreted and governed under the
laws and in the state and federal courts of the Commonwealth of Massachusetts
without regard to its conflicts of laws provisions. You accept the personal jurisdiction
and venue of the Commonwealth of Massachusetts courts. None of the 1980 United
Nations Convention on Contracts for the International Sale of Goods, the United
Nations Convention on the Limitation Period in the International Sale of Goods, and
the Uniform Computer Information Transactions Act shall apply to this Agreement.
4. EXPORT RESTRICTIONS. You understand that Enterasys and its Affiliates are
subject to regulation by agencies of the U.S. Government, including the U.S.
Department of Commerce, which prohibit export or diversion of certain technical
products to certain countries, unless a license to export the Program is obtained from
the U.S. Government or an exception from obtaining such license may be relied upon
by the exporting party.
If the Program is exported from the United States pursuant to the License Exception
CIV under the U.S. Export Administration Regulations, You agree that You are a civil
end user of the Program and agree that You will use the Program for civil end uses
only and not for military purposes.
If the Program is exported from the United States pursuant to the License Exception
TSR under the U.S. Export Administration Regulations, in addition to the restriction
on transfer set forth in Section 1 or 2 of this Agreement, You agree not to (i) reexport
or release the Program, the source code for the Program or technology to a national
of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus,
Cambodia, Cuba, Georgia, Iraq, Kazakhstan, Laos, Libya, Macau, Moldova,
Mongolia, North Korea, the People’s Republic of China, Russia, Tajikistan,
Turkmenistan, Ukraine, Uzbekistan, Vietnam, or such other countries as may be
designated by the United States Government), (ii) export to Country Groups D:1 or
E:2 (as defined herein) the direct product of the Program or the technology, if such
foreign produced direct product is subject to national security controls as identified on
the U.S. Commerce Control List, or (iii) if the direct product of the technology is a
complete plant or any major component of a plant, export to Country Groups D:1 or
E:2 the direct product of the plant or a major component thereof, if such foreign
produced direct product is subject to national security controls as identified on the
U.S. Commerce Control List or is subject to State Department controls under the U.S.
Munitions List.
xviii
5. UNITED STATES GOVERNMENT RESTRICTED RIGHTS. The enclosed Program
(i) was developed solely at private expense; (ii) contains “restricted computer
software” submitted with restricted rights in accordance with section 52.227-19 (a)
through (d) of the Commercial Computer Software-Restricted Rights Clause and its
successors, and (iii) in all respects is proprietary data belonging to Enterasys and/or
its suppliers. For Department of Defense units, the Program is considered
commercial computer software in accordance with DFARS section 227.7202-3 and
its successors, and use, duplication, or disclosure by the Government is subject to
restrictions set forth herein.
6. DISCLAIMER OF WARRANTY. EXCEPT FOR THOSE WARRANTIES
EXPRESSLY PROVIDED TO YOU IN WRITING BY ENTERASYS, ENTERASYS
DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING
BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY,
SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE
AND NON- INFRINGEMENT WITH RESPECT TO THE PROGRAM. IF IMPLIED
WARRANTIES MAY NOT BE DISCLAIMED BY APPLICABLE LAW, THEN ANY
IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THIRTY (30) DAYS
AFTER DELIVERY OF THE PROGRAM TO YOU.
7. LIMITATION OF LIABILITY. IN NO EVENT SHALL ENTERASYS OR ITS
SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING,
WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS, PROFITS,
BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, SPECIAL,
INCIDENTAL, CONSEQUENTIAL, OR RELIANCE DAMAGES, OR OTHER LOSS)
ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM, EVEN IF
ENTERASYS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
THIS FOREGOING LIMITATION SHALL APPLY REGARDLESS OF THE CAUSE
OF ACTION UNDER WHICH DAMAGES ARE SOUGHT.
THE CUMULATIVE LIABILITY OF ENTERASYS TO YOU FOR ALL CLAIMS RELATING
TO THE PROGRAM, IN CONTRACT, TORT OR OTHERWISE, SHALL NOT EXCEED
THE TOTAL AMOUNT OF FEES PAID TO ENTERASYS BY YOU FOR THE RIGHTS
GRANTED HEREIN.
xix
Compliances
8. AUDIT RIGHTS. You hereby acknowledge that the intellectual property rights associated
with the Program are of critical value to Enterasys and, accordingly, You hereby agree
to maintain complete books, records and accounts showing (i) license fees due and paid,
and (ii) the use, copying and deployment of the Program. You also grant to Enterasys and
its authorized representatives, upon reasonable notice, the right to audit and examine
during Your normal business hours, Your books, records, accounts and hardware devices
upon which the Program may be deployed to verify compliance with this Agreement,
including the verification of the license fees due and paid Enterasys and the use, copying
and deployment of the Program. Enterasys’ right of examination shall be exercised
reasonably, in good faith and in a manner calculated to not unreasonably interfere with
Your business. In the event such audit discovers non-compliance with this Agreement,
including copies of the Program made, used or deployed in breach of this Agreement, You
shall promptly pay to Enterasys the appropriate license fees. Enterasys reserves the right,
to be exercised in its sole discretion and without prior notice, to terminate this license,
effective immediately, for failure to comply with this Agreement. Upon any such
termination, You shall immediately cease all use of the Program and shall return to
Enterasys the Program and all copies of the Program.
9. OWNERSHIP. This is a license agreement and not an agreement for sale. You
acknowledge and agree that the Program constitutes trade secrets and/or
copyrighted material of Enterasys and/or its suppliers. You agree to implement
reasonable security measures to protect such trade secrets and copyrighted material.
All right, title and interest in and to the Program shall remain with Enterasys and/or its
suppliers. All rights not specifically granted to You shall be reserved to Enterasys.
10. ENFORCEMENT. You acknowledge and agree that any breach of Sections 2, 4, or
9 of this Agreement by You may cause Enterasys irreparable damage for which
recovery of money damages would be inadequate, and that Enterasys may be
entitled to seek timely injunctive relief to protect Enterasys’ rights under this
Agreement in addition to any and all remedies available at law.
11. ASSIGNMENT. You may not assign, transfer or sublicense this Agreement or any of
Your rights or obligations under this Agreement, except that You may assign this
Agreement to any person or entity which acquires substantially all of Your stock or
assets. Enterasys may assign this Agreement in its sole discretion. This Agreement
shall be binding upon and inure to the benefit of the parties, their legal
representatives, permitted transferees, successors and assigns as permitted by this
Agreement. Any attempted assignment, transfer or sublicense in violation of the
terms of this Agreement shall be void and a breach of this Agreement.
12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of
this Agreement must be in writing and will not be construed as a waiver of any
subsequent breach of such term or condition. Enterasys’ failure to enforce a term
upon Your breach of such term shall not be construed as a waiver of Your breach or
prevent enforcement on any other occasion.
xx
13. SEVERABILITY. In the event any provision of this Agreement is found to be invalid,
illegal or unenforceable, the validity, legality and enforceability of any of the remaining
provisions shall not in any way be affected or impaired thereby, and that provision
shall be reformed, construed and enforced to the maximum extent permissible. Any
such invalidity, illegality or unenforceability in any jurisdiction shall not invalidate or
render illegal or unenforceable such provision in any other jurisdiction.
14. TERMINATION. Enterasys may terminate this Agreement immediately upon Your
breach of any of the terms and conditions of this Agreement. Upon any such
termination, You shall immediately cease all use of the Program and shall return to
Enterasys the Program and all copies of the Program.
xxi
Compliances
xxii
Loading...
