Enterasys Networks IRM2 User Manual

IRM2 User's Guide

Notice

Enterasys Networks reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made.
The hardware, firmware, or software described in this manual is subject to change without notice. IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL, INDIRECT,
Virus Disclaimer
Cabletron has tested its software with current virus checking technologies. However, because no anti­virus system is 100% reliable, we strongly caution you to write protect and then verify that the Licensed Software, prior to installing it, is virus-free with an anti-virus system in which you have confidence.
Enterasys Networks makes no representations or warranties to the effe ct that the Lice nsed Software is virus-free.
Copyright  2000 by Enterasys Networks. All rights reserved. Printed in the United States of America. Order Number: 9031597-04 April 2000
Enterasys Networks P.O. Box 5005 Rochester, NH 03866-5005
Enterasys, NetSight, and Matrix E7 are trademarks of Enterasys Networks. Cabletron Systems, SPECTRUM, BRIM, DNI, FNB, INA, Integrated Network Architecture,
LANVIEW, LANVIEW Secure, Multi Media Access Center , MiniMMAC , and TRMM ar e registered trademarks, and Bridge/Router Interface Mo dules, BRIM-A100, CRBRIM-W/E, CRXMIM, CXRMIM, Desktop Network Interface, Distributed LAN Monitoring, Distributed Network Server, DLM, DNSMIM, E1000, E2000, E3000, EFDMIM, EMM-E6, EMME, EPIM, EPIM-3PS, EPIM-A, EPIM-C, EPIM-F1, EPIM-F2, EPIM-F3, EPIM-T, EPIM-T1, EPIM-X, ESXMIM, ETSMIM, ETWMIM, FDCMIM-04, FDCMIM-08, FDMMIM, FDMMIM-04, Flexible Network Bus, FOMIM, FORMIM, HubSTACK, IRBM, IRM, IRM-2, IRM-3, Media Interface Module, Micro M MAC, MIM, MMAC, MMAC-3, MMAC-3FNB, MMAC-5, MMAC-5FNB, MMAC-8, MMAC-8FNB, MMAC-M8FNB, MMAC-Plus, MRX, MRXI , MRXI-24, MultiChannel, NB20E, NB25E, NB30, NB35, NBR-220/420/620, RMIM, SecureFast Switch, SecureFast Packet Switching, SFS, SFPS, SPECTRUM Element Manager, SPECTRUM for Open Systems, SPIM-A, SPIM-C, SPIM-F1, SPIM-F2, SPIM-T, SPIM-T1, TPMIM, TPMIM-22, TPMIM-T1, TPRMIM, TPRMIM-36, TPT-T, TRBMIM, TRMM-2, TRMMIM, and TRXI are trademarks of Cabletron Systems, Inc.
i
AppleTalk, Apple, Macintosh, and TokenTalk are registered trademarks; and Apple Remote Access and EtherTalk are trademarks of Apple Computer, Inc.
SmartBoost is a trademark of American Power Conversion ST is a registered trademark and C++ is a trademark of AT&T Banyan and VINES are registered trademarks of Banyan Systems, Inc. cisco, ciscoSystems, and AGS+ are register ed trad emarks; and cBus, cisco Router, CRM, IGS, and MGS
are trademarks of cisco Systems, Inc. GatorBox is a registered trademark; and GatorMail, GatorMIM, GatorPrint, GatorShare, GatorStar,
GatorStar GX-M, and XGator are trademarks of Cayman Systems, Inc. CompuServe is a registered trademark of CompuServe Incorporated X Window System is a trademark of Consortium, Inc. CTERM, DECnet, and ULTRIX are registered trademarks; and DEC, DEC C++, DECnet-DOS,
DECstation, VAX DOCUMENT, VMA, and VT are trademarks of Digital Equipment Corporation Fore Systems, ForeRunner, and ForeRunner ASX-100 are trademarks of Fore Sys tems, Inc. PC/TCP is a registered trademark of FTP Software, Inc. HP OpenView is a registered trademark of Hewlett-Packard, Inc. AIX, IBM, OS/2, NetView, and PS/2 are registered trademarks; and AT, Micro Channel, PC, PC-DOS,
PC/XT, Personal Computer AT, Operating System/2, Personal System/2, RISC System/6000, and Workplace Shell are trademarks of International Business Machines Corporation
i960 microprocessor is a registered trademark; and Intel and Multichannel are trademarks of Intel Corporation
Microsoft, MS-DOS, and Windows are registered trademarks of Microsoft Corporation Chameleon, ChameleonNFS, Chameleon 32, IPX/link, and NEWT are trademarks of
NETMANAGE, Inc. NetWare and Novell are registered trademarks; and Internetwork Packet Exchange (IPX), IPX, and
Network File System (NFS) are trademarks of Novell, Inc. Motif and MS are r egist ered tr ademarks; and Open Softwar e Fou ndation, OS F, OSF/1, and OSF/Moti f
are trademarks of The Open Software Foundation, Inc. Silicon Graphics and IRIS are registered trademarks; and Indigo and IRIX are trademarks of Silicon
Graphics, Inc. NFS, PC-NFS, SPARC, Sun Microsystems, and Sun Workstation are registered trademarks; and
OpenWi ndows, SPARCstation, SPARCstation IPC, SPARCstation IPX, Sun, Sun-2, Sun-3, Sun-4, Sun386i, SunNet, SunOS, SunSPARC, and SunView are trademarks of Sun Microsystems, Inc.
OPEN LOOK and UNIX are registered trademarks of Unix System Laboratories, Inc. Ethernet, NS, Xerox Network Systems and XNS are trademarks of Xerox Corporation ANNEX, ANNEX-II, ANNEX-IIe, ANNEX-3, ANNEX-802.5, MICRO-ANNEX-XL, and MICRO-
ANNEX-ELS are trademarks of Xylogics, Inc. MAXserver and Xyplex are trademarks of Xyplex, Inc.
ii
Restricted Rights Notice
(Applicable to licenses to the United States Government only.)
1. Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at DFARS
252.227-7013. Enterasys Networks, 35 Industrial Way, Rochester, New Hampshire 03867-0505.
2. (a) This computer software is submitted with restricted rights. It may not be used, reproduced, or
disclosed by the Government except as provided in paragraph (b) of this Notice or as otherwise expressly stated in the contract.
(b) This computer software may be:
(1) Used or copied for use in or with the computer or computers for which it was acquired,
including use at any Government installation to which such computer or computers may be transferred;
(2) Used or copied for use in a backup computer if any computer for which it w as acquired
is inoperative;
(3) Reproduced for safekeeping (archives) or backup purposes;
(4) Modified, adapted, or combined with other computer software, provided that the
modified, combined, or adapted portions of the derivative software incorporating restricted computer software are made subject to the same restricted rights;
(5) Disclosed to and reproduced for use by support service contractors in accordance with
subparagraphs (b) (1) through (4) of this clause, provided the Government makes such disclosure or reproduction subject to these restricted rights; and
(6) Used or copied for use in or transferred to a replacement computer.
(c) Notwithstanding the foregoing, if this computer software is published copyrighted computer
software, it is licensed to the Government, without disclosure prohibitions, with the minimum rights set forth in paragraph (b) of this clause.
(d) Any other rights or limitations regarding the use, duplication, or disclosure of this computer
software are to be expressly stated in, or incorporated in, the contract.
(e) This Notice shall be marked on any reproduction of this computer software, in whole or in part.
iii
iv
Chapter 1 Introduction
Using This Manual........................................................................................................1-1
Related Manuals............................................................................................................ 1-2
Software Conventions.................................................................................................. 1-3
Using the Mouse....................................................................................................1-3
Common IRM2 Window Fields...........................................................................1-4
Using Window Buttons.........................................................................................1-5
Getting Help ......................................... ...... ...... ..... ........................................................1-6
Using On-line Help................................................................................................1-6
Getting Help from the Enterasys Global Call Center.......................................1-7
Chapter 2 The IRM2 Chassis View
Viewing Chassis Information...................................................................................... 2-2
Front Panel Information........................................................................................2-3
Menu Structure....................................................................................................... 2-4
MIM Port Status Displays.....................................................................................2-8
Selecting a Port Status View.......................................................................... 2-8
Port Status Color Codes............................... ...... ...........................................2-11
The Physical Chassis View..................................................................................2-11
The Chassis Manager Window.......................................................................... 2-12
Viewing Hardware Types...................................................................................2-13
Device Type ................................................................................................... 2-13
Module Type..................................................................................................2-13
Managing the Hub...................................................................................................... 2-14
Setting the Device Date and Time ..................................................................... 2-14
Resetting Device Counters ................................................................................. 2-15
Restarting the Device .......................................... ...... ..... ..................................... 2-15
Configuring the Front Panel Repeater Port Association............................. ...2-16
Setting a Board Name..........................................................................................2-17
Enabling Boards...................................................................................................2-17
Enabling and Disabling Ports ............................................................................ 2-18
Viewing I/F Summary Information.................................................................. 2-18
Interface Performance Statistics/Bar Graphs...........................................2-19
Viewing Interface Detail..............................................................................2-21
Testing and Disabling the Current Interface....................................................2-24
Using the Applications menu............................................................................2-24

Contents

v
Contents
Chapter 3 Statistics
Statistics..........................................................................................................................3-1
Accessing the Statistics Windows........................................................................3-2
Statistics Defined....................................................................................................3-3
Using the Total and Delta Radio Buttons ...........................................................3-4
Timer Statistics...............................................................................................................3-5
Accessing the Timer Statistics Windows ............................................................3-5
Setting the Ti mer Statistics Interval.....................................................................3-7
Summary Statistics........................................................................................................3-7
Accessing the Summary Statistics Windows .....................................................3-8
Configuring Summary Statistics..........................................................................3-9
Performance Graph...................................................... ...............................................3-10
Accessing the Performance Graph Windows ..................................................3-10
Configuring the Performance Graph................................................................3-12
Chapter 4 Source Address Functions
Find Source Address.....................................................................................................4-1
Using Port Locking and Unlocking............................................................................4-2
Using Source Addressing.............................................................................................4-4
Setting the Device Ageing Time........................................................................... 4-5
Chapter 5 Alarm Limits
Accessing the Alarm Limits Windows.......................................................................5-1
Configuring Alarms......................................................................................................5-6
Setting the Alarm Limits Time Interval..............................................................5-6
Setting Alarm Limits .............................................................................................5-7
Chapter 6 Trap Selection
Accessing the Trap Selection Windows......................................................................6-1
Trap Definitions............................................................................................................. 6-2
Configuring Traps .........................................................................................................6-4
Chapter 7 Redundancy
Accessing the Redundancy Window.......................................................................... 7-1
Establishing Redundancy ............................................................................................7-3
Selecting and Naming a Circuit...........................................................................7-3
Entering the Physical Addresses of Devices to be Polled................................7-4
Assigning Backup Ports and Port Priority to the Circuit.................................7-5
Setting the Polling Interval and Number of Retries..........................................7-6
Activating the Circuit...................................................................................................7-7
Testing the Circuits....................................................... ...... ...........................................7-8
vi
Chapter 8 Redundancy (Continued)
Reconfiguring a Circuit................................................................................................7-9
Changing Port Status........................................................................................... 7-10
Resetting a Circuit.................................................................................................7-11
Index
Contents
vii
Contents
viii
Chapter 1

Introduction

How to use this guide; related guides; software conventions; getting help; IRM2 firmware versions
Welcome to the Enterasys Systems NetSight Element Manager for the IR M2
User’s Guide. W e have designed this guide to serve as a simple refer ence for using
NetSight Element Manager for the IRM2.
The IRM2 is an IEEE 802.3-compliant repeater module designed to be installed in
a Cabletron Systems Multi Media Access Center (MMAC
without the Flexible Network Bus (FNB™). The IRM2 occupies the first
(management) slot of the MMAC hub, and controls non-intelligent Ethernet
modules installed to its left. It retimes and regenerates Ethernet data packets
throughout the chassis, and performs automated management such as port
segmentation. With NetSight Element Manager, you can gather a full array of
statistical information from the IRM2 at the device, board, and port levels —
including data throughput statistics and error breakdowns. You can also set
alarms and traps for the hub, configure redundant circuits, or set port security
parameters based on Ethernet source address locking.

Using This Manual

Each chapter in this guide describes one major functionality or a collection of
several smaller functionalities of the IRM2 device module. This guide contains
information about software functions which ar e a ccessed dir ectly from the device
icon; for information about functions which are accessed via the menu bar across
the top of the map window, consult the User’s Guide and Tools Guide included in
this package, as well as any management platform-specific documentation that
accompanied NetSight Element Manager.
Chapter 1, Introduction, provides a list of related documentation, describes
certain software conventions, and shows you how to contact the Enterasys Global
Call Center.
®
) hub, either with or
1-1
Introduction
Chapter 2, The IRM2 Chassis View, describes the visual display of the IRM2-controlled chassis and explains how to use the mouse within the Chassis
View; the operation of several chassis-level management functions — such as changing the chassis display, naming boards, enabling and disabling boards and ports, and setting device date and time — is also described here.
Chapter 3, Statistics, describes the Statistics, Timer Statistics, Summary Statistics, and Performance Graph selections available at the repeater, board, and port levels. Each of these selections provides a slightly different view of the network information being collected by your IRM2.
Chapter 4, Source Address Functions, describes how to display the Source Address lists, how to set the ageing time, and how to locate the port being used by a specific source address; it also discusses the effects of port locking.
Chapter 5, Alarm Limits, provides instructions on setting Alarm Limits for the repeater, or for an individual board or port.
Chapter 6, Trap Selection, details how to use the Trap Selection window to determine whether your IRM2 will send certain common SNMP traps to your Enterasys management station.
Chapter 7, Redundancy, describes how to configure redundant circuits for your IRM2 repeater, to ensure that vital network connections remain open and active.
We assume that you have a general working knowledge of Ethernet IEEE 802.3­and FDDI-type data communications networks and their physical layer components, and that you are familiar with general bridging concepts.

Related Manuals

The IRM2 User’s Guide is only part of a complete document set designed to provide comprehensive information about the features available to you through NetSight Element Manager. Other guides which include important information related to managing the IRM2 include:
Enterasys’ NetSight Element Manager User’s Guide Enterasys’ NetSight Element Manager Tools Guide Enterasys’ NetSight Element Manager Remote Administration Tools User’s
Guide
Enterasys’ NetSight Element Manager Remo te Monitoring (RMON) User’s Guide Enterasys’ NetSight Element Manager Alarm and Event Handling User’s Guide Enterasys’ Network Troubleshooting Guide Microsoft Corporation’s Microsoft Windows User’s Guide
For more information about the capabilities of the IRM2, consult the appropriate hardware documentation.
1-2 Related Manuals

Software Conventions

NetSight Element Manager’s user interface contains a number of elements which
are common to most windows and which operate the same regardless of which
window they appear in. A brief description of some of the most common
elements appears below; note that the information provided here is not repeated
in the descriptions of specific windows and/or functions.

Using the Mouse

This document assumes you are using a Windows-compatible mouse with two
buttons; if you are using a three button mouse, you should ignore the operation of
the middle button when following procedures in this document. Procedures
within the NetSight Element Manager document set refer to these buttons as
follows:
Introduction
Left Mouse Button
Right Mouse Button
Figure 1-1. Mouse Buttons
For many mouse operations, this document assumes that the left (primary) mouse
button is to be used, and references to activating a menu or button will not
include instructions about which mouse button to use.
However, in instances in which right (secondary ) m ouse button functionality is
available, instructions will explic itly refer to right mouse button usage. Also, in
situations where you may be switching between mouse buttons in the same area
or window, instru ctions may also explicitly refer to both left and right mouse
buttons.
Instructions to perform a mouse operation include the following terms:
• Pointing means to position the mouse cursor over an area without pressing
either mouse button.
• Clicking means to position the mouse pointer over the indicated target, then
press and release the appropriate mouse button. This is most commonly used to select or activate objects, such as menus or b uttons.
Software Conventions 1-3
Introduction
• Double-clicking means to position the mouse pointer over the indicated
target, then press and release the mouse button two times in rapid succession.
This is commonly used to activate an object’s default operation, such as
opening a window from an icon. Note that there is a distinction made between
“click twice” and “double-click,” since “click twice” implies a slower motion.
• Pressing means to position the mouse pointer over the indicated target, then
press and hold the mouse button until the de scribed action is completed. It is
often a pre-cursor to Drag operations.
• Dragging means to move the mouse pointer across the screen while holding
the mouse button down. It is often used for drag-and-drop operations to copy
information from one window of the screen into another, and to highlight
editable text.

Common IRM2 Window Fields

Similar descriptive information is displayed in boxes at the top of most device-specific windows in NetSight Element Manager, as illustrated in
Figure 1-2, below.
Device Name
IP Address
Figure 1-2. Sample Window Showing Informat ional Boxes
Device Name
Displays the user-defined name of the device. The device name can be changed via the System Group window; see the Gener ic SNMP User’s Guide for details.
Location
MAC Address
1-4 Software Conventions
Introduction
IP Address
Displays the device’s IP (Internet Protocol) address. This will be the IP address
used to define the device icon. IP addresses are assigned via Local Management
for the IRM2; they cannot be changed via NetSight Element Manager.
Location
Displays the user-defined location of the device. The location is entered through
the System Group window; see the Generic SNMP User’s Guide for details.
MAC Address
Displays the manufact u rer-set MAC address of the IRM2 with which NetSight
Element Manager is communicating. This address is factory-set and cannot be
altered.
Informational fields describing the boards and/or ports being modeled are also
displayed in most windows:
Board Number
Displays the number indicating the position of the monitored boar d in the chassis.
Board Name
Displays the user-entered name for the board. You can change the board name via
the Name option available from the Board m enu.
Port Number
Displays the number of the monitored port.
Port Name
Displays the user-defined name of the port. You can change the port name via the
Name option available from the Port menu.
Active Users
Indicates the number of users processing information through the IRM2 repeater,
board, or port, as determined by MAC addresses.
Uptime
Displays the amount of time, in a days hh:mm:ss format, that the IRM2 has been
running since the last start-up.

Using Window Buttons

The button that appears at the bottom of most windows allows you to
exit a window and terminate any unsaved changes you have made. You may also
have to use this button to close a window after you have made any necessary
changes and set them by clicking on an , , or button.
Software Conventions 1-5
Introduction
An , , or button appears in win d ows that have configurable values; it allows you to confirm and SET changes you have made to those values. In some windows, you may have to use this button to confirm each individual set; in other windows, you can set several values at once and confirm the sets with one click on the button.
The button brings up a Help text box with information specific to the current window. For more information concerning Help buttons, see Getting Help, page 1-6 .
The command buttons, for example , call up a menu listing the windows, screens, or commands available for that topic.
Any menu topic followed by... (three dots) — for example Statistics... — calls up a window or screen associated with that topic.

Getting Help

This section describes two different methods of getting help for questions or concerns you may have while using NetS ight Element Manager.

Using On-line Help

You can use the IRM2 window buttons to obtain information specific to the device. When you click on a Help button, a window will appear which contains context-sensitive on-screen documentation that will assist you in the use of the windows and their associated command and menu options. Note that if a Help button is grayed out, on-line help has not yet been implemented for the associated window.
From the Help menu accessed from the Chassis View window menu bar, you can access on-line Help specific to the Chassis View window, as well as bring up the Chassis Manager window for reference . Refer to Chapter 2 for information on the Chassis View and Chassis Manager windows.
All of the online help windows use the standard Microsoft Windows help facility. If you
NOTE
are unfamiliar with this feature of Windows, you can select H
elp —>How to Use Help from the primary NetSight Element Manager window , or
or H consult your Microsoft Windows product User’s Guide.
elp from the menu,
1-6 Getting Help

Getting Help from the Enterasys Global Call Center

If you need technical support related to NetSight Element Manager, contact the
Enterasys Global Call Center via one of the following methods:
By phone: (603) 332-9400
24 hours a day, 365 days a year
By mail: Enterasys Networks
Technical Support
Rochester, NH 03866-5005 By Internet mail: support@ctron.com FTP: ftp.ctron.com (134.141.197.25)
Login anonymous Password your email address
By BBS: (603) 335-3358
Modem Setting 8N1: 8 data bits, 1 stop bit, No parity
Send your questions, comments, an d suggestions regarding NetSight documentation to NetSight Technical Communications via the following address:
Introduction
NOTE
Netsight_docs@enterasys.com
To locate product specific information, refer to the Enterasys Web site:
http://www.enterasys.com/.
For the highest firmware versions successfully tested with NetSight Element Manager
2.2.1, refer to the Readme file from the NetS ig ht Element Manager program gr oup. If you have an earlier version of firmware and experience problems, contact the Global Technical Assistanc e Ce nter.
Getting Help 1-7
Introduction
1-8 Getting Help
Chapter 2

The IRM2 Chassis View

Information displayed in the Chassis View window; the physical and logical chassis views; the Chassis Manager window; Hub management functions
The IRM2 Chassis View window is the main screen that immediately informs you of the current configuration of your MMAC chassis via a graphical display of the chassis front panel. The default Logical View shows the boards installed in your MMAC according to the physical slots they occupy, and displays the condition of individual ports on those boards; the Physical View provides a graphical representation of the actual board faces. The Chassis View window serves as a single point of access to all other IRM2 windows and screens, which are discussed at length in the following chapters.
To access the IRM2 Chassis View window, use one of the following options:
1. In any map, list, or tree view, double-click on the IRM2 you wish to manage;
or
1. In any map, list, or tree view, click the left mouse button once to select the
IRM2 you wish to manage.
2. Select Manage—>Node from the primary window menu bar, or select the
Manage Node toolbar button.
or
1. In any map, list, or tree view, click the right mouse button once to select the
IRM2 you wish to manage.
2. On the resulting menu, click to select Manage.
2-1
The IRM2 Chassis View

Viewing Chassis Information

The IRM2 Chassis View window (Figure 2-1) provides a g raph ic r e pr ese nta tion of the IRM2 and the hub in which it is installed, including a color-coded port display which immediately informs you of the current configuration and status of all the boards and ports installed in the MMAC chassis.
Figure 2- 1. IRM2 Chassis View Window
By clicking in designated areas of the chassis graphical display (as detailed later in this chapter), or by using the menu bar at the top of the Chassis View window, you can access all of the menus that lead to more detailed device-, repeater-, board-, and port-level windows.
When you move the mouse cursor over a management “hot spot” the cursor icon will
TIP
2-2 Viewing Chassis Information
change into a “hand” ( ) to indicate that clicking in the current location will bring up a management option.
Note that up to 24 ports can be displayed s i multaneously on a module. If a module has a
NOTE
higher port density than 24 ports, Up and Down arrows will appear at the top and bottom of the port stack so that you can scroll through the remaining ports.

Front Panel Infor matio n

The areas outside the main MIM display area provide the following device information:
IP
The Internet Protocol address assigned to the IRM2; this field will display the IP address you have used to create the IRM2 icon. IP addresses are assigned via Local Management.
Port Locking/Unlocking
The port locked and unlocked symbols indicate whether port locking is enabled or disabled, respectively. See Chapter 4, Source Address Functions, for further information.
The IRM2 Chassis View
Connection Status
This color-coded area i ndicates the current state of communication between NetSight Element Manager and the IRM2.
• Green indicates the IRM2 is responding to device polls (valid connection).
• Magenta indicates that the IRM2 is in a temporary stand-by mode while it
responds to a physical change in the hub ( a board is inserted or r emoved); note that board and port menus are inactive during this stand-by state.
• Blue indicates an unknown contact status — polling has not yet been
established with the IRM2.
• Red indicates the IRM2 is not responding to device polls (device is off line, or
device polling has failed across the network for some other reason).
UpTime
The amount of time, in a days hh:mm:ss format, that the IRM2 has been running since the last start-up.
Port Status
If management for your device supports a variable port display (detailed in Port Status Displays later in this chapter), this field will show the display currently in
effect. If only a single port display is available--or if the default view is in effect--this field will state Default.
Viewing Chassis Information 2-3
The IRM2 Chassis View
MAC
The physical layer address assigned to the IRM2 interface with which NetSight Element Manager is communicating. MAC addresses are hard-coded in the device, and are not configurable.
Boot Prom
The revision of BOOT PROM installed in the IRM2.
Firmware
The revision of device firmware stored in the IRM2’s FLASH PROMs.
Time
The current time, in a 24-hour hh:mm:ss format, set in the IRM2’s internal clock.
Date
The current date, in an mm/dd/yyyy format, set in the IRM2’s internal clock.
You can set the date and time by using the Edit Device Date and Edit Device Time
NOTE
options on the Device menu, or by using the I-bar cursors in the Chassis Type window; see Setting the Device Date and Time, page 2-14, f or details.
In accordance with Year 2000 compliance requirements, NetSight Element Manage r now displays and allows you to set all date s with four-digit ye ar values..

Menu Structure

By clicking on various areas of the IRM2 Chassis View display, you can access menus with device-, repeater-, board-, and port-level options, as well as utility applications which apply to the device. The follo wing illustration displays the menu structure and indicates how to use the mouse to access the various menus:
2-4 Viewing Chassis Information
The IRM2 Chassis View
Figure 2- 2. IRM2 Chassis View Menu Structure
The Device Menu
From the Device Menu at the Chassis View window menu bar, you can access the following selections:
evice Type..., which displays a window containing a description of the
• D
device being modeled (i.e., IRM2).
• Edit Device T
internal clock.
ystem Group..., which allows you to manage the IRM2 via SNMP MIB II.
• S
Refer to the Generic SNMP User’s Guide for further information.
ime... and Edit Device Date..., which allow you to set the IRM2’s
Viewing Chassis Information 2-5
The IRM2 Chassis View
• I/F Summary, which displays a window showing statistics for the traffic
• Ex
The View Menu
The View menu lets you change the information displayed in the Chassis View:
• L
• P
• R
The Port Status Menu
The Port Status menu allows you to select the status information that will be displayed in the port text boxes in the logical Chassis View window:
processed by each network interface on your device. Refer to Viewing I/F
Summary Information, page 2-18.
it, which closes the IRM2 Chassis View window.
ogical brings up the default display, which contains port status informa tion
and provides access to board- and port-level menus.
hysical provides a graphic representation of the actual module faces,
showing how ports are arranged on the MIM face and what connector types are present.
edundancy brings up a window that allows you to configure a redundancy
scheme for the IRM2 and its associated modules. See Chapter 7, Redundancy, for further information.
oad will display the portion of network load processed by each port as a
• L
percentage of the theoretical maximum load (10Mbits/sec) of an Ethernet network.
• Port T
• S
• E
For more information on the port display options available via this menu, see
Selecting a Port Status View, in this chapter.
The Repeater Menu
This menu displays selections pertaining to the repeater network supported by the IRM2. It has the following selections:
• Statistics..., which brings up the repeater-level Statistics windows; see
• Timer Statistics..., which opens the repeater-level Timer Statistics windows;
• Summary Statistics..., which accesses r epeater-level statistics broken down by
ype will display each port’s topology: Station (STA) or Trunk (TRK).
tatus allows yo u to select one of three status type displays: Admin/Link,
Admin, or Link.
rrors allows you to display the percentage per port of the specific Error type
you select.
Chapter 3, Statistics, for more information.
see Chapter 3 for more information.
individual board; see Chapter 3.
• Performance Graph..., which opens the Performance Graph windows; see Chapter 3.
2-6 Viewing Chassis Information
The IRM2 Chassis View
• Find Source Address..., which allows you to locate the port through which a
MAC address is communicating; see Chapter 4, Source Address Functions.
• Lock/Unlock Ports..., which allows you to protect the hub from unauthorized
access; see Chapter 4, Source Address Functions.
• Alarm Limits..., which launches the repeater-level alarms window; see
Chapter 5, Alarm Limits, for alarm configuration information.
• Trap Selection..., which allows you to selectively enable and disable certain
SNMP traps generated by the IRM2; see Chapter 6, Trap Selection.
• Reset Counters, which lets you refresh the IRM2’s statistical counters to zero.
This option is discussed later in this chapter.
• Restart..., which you ca n use to perform a warm b oot of the IRM2 . This option
is discussed later in this chapter.
The Utilities Menu
The Utilities menu provides access to any utilities provided by NetSight Element Manager for use with the IRM2 module. This includes the MIB Tree utility, which provides direct access to the IRM2’s MIB information. Refer to your Utilities
User’s Guide for information on this utility.
The Help Menu
The Help Menu has three selections:
ibs Supported, which brings up the Chassis Manager window, described
• M
later in this chapter.
hassis Manager Help, which brings up a help window with information
• C
specifically related to using the Chassis Manager and Cha ssis View windows.
bout Chassis Manager..., which brings up a version window with the
• A
Chassis Manager application in use.
The Board Menu
The Board menu for the IRM2 module and its associated modules provides the following selections. If the board you are monitoring is not recognized by the IRM2 — for example, if it is a mid-chassis intelligent module such as a GatorMIM — the single board-level selection available is Module Type...:
• Statistics... (see Chapter 3)
• Timer Statistics... (see Chapter 3)
• Summary Statistics... (see Chapter 3)
• Performance Graph... (see Chapter 3)
• Module Type..., which brings up a window containing a description of the
selected board; see Viewing Hardware Types , page 2-13.
• Alarm Limits... (see Chapter 5)
Viewing Chassis Information 2-7
The IRM2 Chassis View
• Name..., which allows you to assign a name to the selected boa rd; this name
• Enable, which allows you to enable all ports on the selected board; see
The Port Menus
For Ethernet MIM ports, menu selections will include Statistics, Timer Statistics, Performance Graph, and Alarm Limits (the same options provided on the
repeater and board menus); Enable and Disable at the port level; and an additional port-specific selection:
• Source Addressing..., which displays the current source address table for each
The IRM2 Module itself (Board 1) has one additional port-related option:
• Port Association..., which lets you select which of its two front panel ports —
will be displayed in many board-level window s. See Setting a Board Name,
page 2-17, for details.
Enabling Boards, page 2-17.
port. See Chapter 4, Source Address Functions, for more information.
AUI or Fiber Optic —þwill be used as the repeater interface for a connected network segment.

MIM Port Status Displays

When you open the Chassis View window, each port on the IRM2 and the associated MIMs installed in the hub will display its Admin/Link status (defined below); to change this status display, select one of the options on the Port Status menu, as described in the following sections.
Selecting a Port Status View
To change the status view of your ports:
1. Click on P a menu will appear.
2. Drag down (and to the right, if necessary) to select the status information you want to display. The port text boxes will display the appropriate status information.
Port status view options are:
Load
If you choose L load processed by each port during the last polling interval. This percentage reflects the network load generated by devices con nected to th e po rt compared to the theoretical maximum load (10 Mbits/sec) of an Ethernet network.
ort Status on the menu bar at the top of the Chassis View window;
oad, the port text boxes will display the percentage of network
2-8 Viewing Chassis Information
NOTE
The IRM2 Chassis View
In NetSight Element Manager, the polling interval is set via the Tools—>Options window available from the primary window menu bar.
Refer to the NetSight Element Manager User’s Guide for full information on setting device polling intervals.
Port Type
If you choose Port T
ype, each port status box will display that port’s topology
status: station or trunk. A station port (displayed as STA) is one which has zero or one source addresses in its source address table; a trunk port (designated TRK) has two or more source addresses in its table. If a board does not support the Port Type option, its port status boxes will remain blank. For more information about the source address table, see Chapter 4, Source Address Functions.
Status
You can view three status categories for your ports, which reflect six possible Admin/Link, Admin, or Link status conditions:
• Admin/Link — ON, OFF, SEG (segmented), or NLK (not linked)
• Admin — ON or OFF
• Link — LNK (link), NLK (not linked), or N/A (not available) If you have selected the A
dmin/Link status mode, a port is considered:
• ON if the port is enabled and has a valid link.
• OFF if it has not been enabled or if it has been disabled through management
action.
SEG (segmented) if the port has been enabled by management and has a valid connection, but has been segmented by the repeater because 33 consecutive collisions have occurred on the attached segment, or the collision detector was on for more than 2.4 µs.
Viewing Chassis Information 2-9
Loading...
+ 61 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
