Enterasys Networks 2E43-27R, 2E42-27R, 8H02-16, 2E42-27, 2E43-27 User Manual

Fast Ethernet SmartSwitch Modules

Management Module Guide

(8H02_16, 2E42_27, 2E42_27R, 2E43-27, 2E43-27R)

Notice

Cabletron Systems reserves the right to make changes in speciﬁcations and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made.

The hardware, ﬁrmware, or software described in this manual is subject to change without notice. IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL,

INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH DAMAGES.

Virus Disclaimer

Cabletron has tested its software with current virus checking technologies. However, because no anti-virus system is 100% reliable, we strongly caution you to write protect and then verify that the Licensed Software, prior to installing it, is virus-free with an anti-virus system in which you have conﬁdence.

Cabletron Systems makes no representations or warranties to the effect that the Licensed Software is virus-free.

Cabletron Systems, Inc. P.O. Box 5005 Rochester, NH 03866-5005

SPECTRUM , the SPECTRUM IMT/VNM logo, DCM , IMT , and VNM are registered

trademarks, and SpectroGRAPH , SpectroSERVER , Inductive Modeling Technology ,

Device Communications Manager , SmartSwitch , and Virtual Network Machine are

trademarks of Cabletron Systems, Inc.

9032073 E2

Restricted Rights Notice

(Applicable to licenses to the United States Government only.)

1. Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013.

Cabletron Systems, Inc., 35 Industrial Way, Rochester, New Hampshire 03866-5005.

2. (a) This computer software is submitted with restricted rights. It may not be used,

reproduced, or disclosed by the Government except as provided in paragraph (b) of this Notice or as otherwise expressly stated in the contract.

(b) This computer software may be:

(1) Used or copied for use in or with the computer or computers for which it was

acquired, including use at any Government installation to which such computer or computers may be transferred;

(2) Used or copied for use in a backup computer if any computer for which it was

acquired is inoperative; (3) Reproduced for safekeeping (archives) or backup purposes; (4) Modified, adapted, or combined with other computer software, provided that the

modified, combined, or adapted portions of the derivative software incorporating

restricted computer software are made subject to the same restricted rights; (5) Disclosed to and reproduced for use by support service contractors in accordance with

subparagraphs (b) (1) through (4) of this clause, provided the Government makes

such disclosure or reproduction subject to these restricted rights; and (6) Used or copied for use in or transferred to a replacement computer.

computer software, it is licensed to the Government, without disclosure prohibitions, with the minimum rights set forth in paragraph (b) of this clause.

(d) Any other rights or limitations regarding the use, duplication, or disclosure of this

computer software are to be expressly stated in, or incorporated in, the contract.

(e) This Notice shall be marked on any reproduction of this computer software, in whole or in

part.

Fast Ethernet SmartSwitch Module

ii Management Module Guide

Preface

What Is in This Guide.......................................................................................................... ix

Conventions ............................................................................................................................x

Related SPECTRUM Documentation....................................................................................x

Other Related Documentation.............................................................................................xi

Chapter 1 Introduction

What Is in This Chapter.....................................................................................................1-1

Fast Ethernet SmartSwitch Modules................................................................................1-1

SPECTRUM Support.......................................................................................................... 1-2

Accessing SPECTRUM Views from the Device Icon..................................................1-2

Accessing Device-Speciﬁc Subviews............................................................................1-5

SPECTRUM Views Roadmap ............................................................................................ 1-6

SPMA Support....................................................................................................................1-8

Chapter 2 Device Views

What Is in This Chapter.....................................................................................................2-1

Interface Device View......................................................................................................... 2-1

Interface Icon................................................................................................................ 2-3

Interface Icon Subviews Menu.............................................................................. 2-4

Interface Label....................................................................................................... 2-4

Administrative Status Label................................................................................. 2-4

Interface Type Label.............................................................................................. 2-5

MAC Address Label...............................................................................................2-6

Network Information Label ..................................................................................2-6

Gauge Label...........................................................................................................2-7

Interface Options Panel...............................................................................................2-7

Gauge Control Panel.................................................................................................... 2-7

Chassis Device View......................................................................................................... 2-11

Chassis Device Icon.................................................................................................... 2-12

Device Type Label................................................................................................ 2-13

Device Icon Subviews Menu................................................................................ 2-13

Application Label................................................................................................. 2-13

Bridging Icon Subviews Menu............................................................................2-13

Interface Labels...................................................................................................2-14

Interface Icon Subviews Menu............................................................................ 2-15

FDDI Label .......................................................................................................... 2-15

FDDI Icon Subviews Menu ................................................................................. 2-15

9032073 E2

iii

Chapter 2 Device Views (continued)

Logical Ports Labels.............................................................................................2-16

Logical Ports Icon Subviews Menu .....................................................................2-16

Physical Device View........................................................................................................2-17

Chapter 3 Conﬁguration Views

What Is in This Chapter.....................................................................................................3-1

Device Conﬁguration View.................................................................................................3-2

Device Conﬁguration Information...............................................................................3-2

Interface Conﬁguration Table Information.................................................................3-3

Port Conﬁguration - CSIIfPort View..................................................................................3-5

FddiMAC Device Conﬁguration View................................................................................3-6

Station Conﬁguration...................................................................................................3-6

SMT Information..........................................................................................................3-8

Port Conﬁguration View .....................................................................................................3-8

Chapter 4 Event and Alarm Messages

What Is in This Chapter.....................................................................................................4-1

Device Events and Alarms..................................................................................................4-1

Chapter 5 Application Views

What Is in This Chapter.....................................................................................................5-1

Common Applications Not Covered Here..........................................................................5-1

Device Application View .....................................................................................................5-2

Interface Remap Application..............................................................................................5-5

Fast Ethernet Application ..................................................................................................5-7

Fast Ethernet Port Table..............................................................................................5-7

Fast Ethernet Conﬁguration View...............................................................................5-7

Operational Mode............................................................................................5-8

Advertised Ability............................................................................................5-9

Received Technology......................................................................................5-10

FDDI FNB Application.....................................................................................................5-11

FDDI Station List View..............................................................................................5-11

ATM Client Application....................................................................................................5-13

ATM Client Application VCL View............................................................................5-13

Download Application View..............................................................................................5-17

Index

Fast Ethernet SmartSwitch Module

iv Management Module Guide

Figures

Chapter 1 Introduction

Figure 1-1. Using Double-Click Zones to Access SPECTRUM Views ...................................1-3

Figure 1-2. Using the Icon Subviews Menu to Access SPECTRUM Views .......................... 1-4

Figure 1-3. Accessing Device-Speciﬁc Subviews .................................................................... 1-5

Figure 1-4. SPECTRUM Views Roadmap .............................................................................. 1-7

Figure 1-5. SPMA Applications View ...................................................................................... 1-8

Chapter 2 Device Views

Figure 2-1. Interface Device View ...........................................................................................2-2

Figure 2-2. Interface Icon ........................................................................................................2-3

Figure 2-3. Gauge Control Panel .............................................................................................2-8

Figure 2-4. Chassis Device View ........................................................................................... 2-11

Figure 2-5. Chassis Device Icon ............................................................................................2-12

Figure 2-6. Physical Device View .......................................................................................... 2-17

Chapter 3 Conﬁguration Views

Figure 3-1. Link Error Rate Estimate ....................................................................................3-9

Chapter 5 Application Views

Figure 5-1. Device Application View (Icon Mode) .................................................................. 5-3

Figure 5-2. Device Application View (List Mode) ................................................................... 5-4

Figure 5-3. Interface Remap Table .........................................................................................5-6

Figure 5-4. Fast Ethernet Conﬁguration View ....................................................................... 5-8

9032073 E2

Fast Ethernet SmartSwitch Module

vi Management Module Guide

Tables

Chapter 2 Device Views

Table 2-1. Interface Icon Subviews Menu.............................................................................. 2-4

Table 2-2. Administrative Status for the Physical or MIB II Application...........................2-4

Table 2-3. Administrative Status for the Bridging Application ........................................... 2-5

Table 2-4. Interface Types ...................................................................................................... 2-5

Table 2-5. Totals Mode: Attributes and Corresponding Color.............................................. 2-9

Table 2-6. Rates Mode: Attributes and Corresponding Color............................................... 2-9

Table 2-7. Device Icon Subviews Menu................................................................................ 2-13

Table 2-8. Application Label Icon Subviews Menu ............................................................. 2-14

Table 2-9. Interface Status for the Bridging Application ................................................... 2-14

Table 2-10. Interface Status for the Physical (MIB II) Application..................................... 2-15

Table 2-11. FDDI Label Icon Subviews Menu....................................................................... 2-15

Table 2-12. Logical Ports Icon Subviews Menu..................................................................... 2-16

Chapter 3 Conﬁguration Views

Table 3-1. Interface Types ...................................................................................................... 3-3

Table 3-2. FDDI Ring States .................................................................................................. 3-6

Table 3-3. SMT MAC Configurations..................................................................................... 3-7

Chapter 4 Event and Alarm Messages

Table 4-1. Fast Ethernet SmartSwitch Module Events and Alarms ...................................4-1

Chapter 5 Application Views

Table 5-1. Current Operational Mode Values and Descriptions .......................................... 5-9

Table 5-2. Advertised Ability Mode Values and Descriptions.............................................. 5-9

Table 5-3. Received Technology Mode Values and Descriptions........................................5-10

Table 5-4. FDDI FNB Application Subviews menu ............................................................ 5-11

Table 5-5. FDDI Node Classes.............................................................................................. 5-12

Table 5-6. ATM Client Application Subviews menu........................................................... 5-13

9032073 E2

vii

Fast Ethernet SmartSwitch Module

viii Management Module Guide

Chapter Description

Preface

Use this guide as a reference for the SPECTRUM Fast Ethernet SmartSwitc h Module management software. Before using this guide, you should be familiar with SPECTRUM’s functions and navigational techniques as described in the

Administrator’s Reference and the Operator’s Reference .

For the purposes of this guide, a Fast Ethernet SmartSwitch Module is referred to as a “device.”

What Is in This Guide

The organization of the Fast Ethernet SmartSwitch Module Management

Module Guide is as follows:

Chapter 1

Introduction

Chapter 2

Device Views

Chapter 3

Conﬁguration Views

Chapter 4

Event and Alarm Messages

Chapter 5

Application View s

Describes the devices, the management module software, and the model types.

Describes the Device views representing the devices.

Describes the Conﬁguration views for the devices and the network management information provided by the views.

Lists and explains the event and alarm messages generated in the Event Log or Alarm Manager for the device model type.

Describes the Application views and the application-speciﬁc information for the devices.

9032073 E2

Conventions

This guide uses the following conventions:

• Menu selections and buttons referenced in text appear in bold ; for example, Conﬁguration or Detail .

• Buttons appear as shadowed boxes when describing their use; for example:

Help

• Menu navigation appears in order of selection; for example,

Subviews -> Utilities -> Application .

• Referenced chapter titles and section headings appear in italics .

• Referenced documents appear in bold italics .

• A Fast Ethernet SmartSwitch Module is referred to as a “device.”

Introduction

Chapter 1

What Is in This Chapter

This chapter introduces the SPECTRUM management module covering the Fast Ethernet SmartSwitch Modules described below. It describes the following:

• Fast Ethernet SmartSwitch Modules

• SPECTRUM Support

- Accessing SPECTRUM Views from the Device Icon

- Accessing Device-Speciﬁc Subviews

• SPECTRUM Views Roadmap

• SPMA Support

Fast Ethernet SmartSwitch Modules

The 8H02-16, 2E42-27, 2E42-27R, 2E43-27, and 2E43-27R Fast Ethernet SmartSwitch Modules are all high performance Ethernet switching devices that provide Fast Ethernet uplinks.

The 8H02-16 is a 16-port device having 14 standard 10Base-T front panel ports that are supported by RJ-45 connectors and two 100Base-TX or multimode ﬁber 100Base-FX uplinks using Fast Ethernet Port Interface Modules.

9032073 E2

The 2E42-27 and 2E42-27R devices expand the capabilities of the 8H02-16 by providing 27 ports including 24 standard Ethernet ports with RJ-45 connectors, two slots for Fast Ethernet Port Interface Modules, and one slot for a High Speed Interface Module to provide a high-speed ATM uplink or FDDI connectivity. The 2E42-27 has a single power supply and the 2E42-27R has dual redundant power supplies.

1-1

SPECTRUM Support

The 2E43-27 and 2E43-27R provide the same feature set as the 2E42-27 and 2E42-27R but come equipped with two RJ21 connectors to support 24 ports of switched Ethernet rather than the 24 RJ45’s. This allows the use of Telco cables in the wiring closets with patch panels to reduce the complexity of cable management.

All ﬁve devices offer RMON, port redirection, broadcast suppression, and full duplex support on all interfaces, with support for IEEE Auto-Negotiation on the 100Base-TX ports.

SPECTRUM Support

When modeling a device, the model type SS8H appears in the Select Model Type dialog box. The names listed below refer to the model names used in SPECTRUM to specify attributes, actions, and associations for Fast Ethernet SmartSwitch Modules:

• 8H02_16 (Fast Ethernet SmartSwitch Module, Model 8H02-16)

• 2E42_27 (Fast Ethernet SmartSwitch Module, Model 2E42-27)

• 2E42_27R (Fast Ethernet SmartSwitch Module, Model 2E42-27R)

• 2E43_27 (Fast Ethernet SmartSwitch Module, Model 2E43-27)

• 2E43_27R (Fast Ethernet SmartSwitch Module, Model 2E43-27R)

Accessing SPECTRUM Views from the Device Icon

The Device icon provides access to SPECTRUM views that display devicespeciﬁc information. Access these views using double-click zones (Figure 1-1) or Icon Subviews menus (Figure 1-2).

To access the Icon Subviews menu, do the following:

1. Highlight the icon.

2. From the View menu, select Icon Subviews or click the applicable mouse button (middle or right). Refer to the Operator’s Reference for information on conﬁguring your mouse.

Introduction Fast Ethernet SmartSwitch Module 1-2 Management Module Guide

SPECTRUM Support

Accessing SPECTRUM Views from the Device Icon

Figure 1-1. Using Double-Click Zones to Access SPECTRUM Views

Accesses the Conﬁguration views; refer

to Chapter 3, Conﬁguration V iews .

Accesses the Device Topology view;

refer to the Operator’s Reference.

Model Name

Accesses the Device views; refer t

Chapter 2, Device V iews .

8H02_16

Accesses the Performance view;

refer to the Operator’s Reference.

Accesses the Conﬁguration views; refer to

Chapter 3, Conﬁguration V iews .

Accesses the Device views;

refer to Chapter 2, Device

Views.

Accesses the Device Topology view;

refer to the Operator’s Reference.

Model Name

8H02_16

Accesses the Application views; refer

to Chapter 5, Application Views.

Accesses the Performance view;

refer to the Operator’s Referenc

Accesses the Application views; refer

to Chapter 5, Application Views.

9032073 E2 Introduction

1-3

SPECTRUM Support Accessing SPECTRUM Views from the Device Icon

Figure 1-2. Using the Icon Subviews Menu to Access SPECTRUM Views

Model Name

8H02_16

View

Go Back Go Up Icon Subviews View Path New View Bookmarks View History Current View Info... Notes... Jump by name... Zoom Map Hierarchy Page

Ctrl+b

Close Navigate A Performance Notes... Utilities Zoom Device DevTop

Ctrl+c

larms

Chassis Interface Physical

Introduction Fast Ethernet SmartSwitch Module 1-4 Management Module Guide

Accessing Device-Speciﬁc Subviews

Icon Subviews menus provide access to views that display device-speciﬁc information. Figure 1-3 shows an example of an Icon Subviews menu for the Bridging icon located within the Chassis Device view. The device-speciﬁc Icon Subviews menu selections are described under the applicable section within this guide. The menu selections that are common to all devices are described in the Administrator’s Reference and the Operator’s Reference.

To access the Icon Subviews menu using the View menu, do the following:

1. Highlight the icon.

2. From the View menu, select Icon Subviews. To access the Icon Subviews menu using the mouse button, do the following:

1. Position the mouse pointer on the icon.

2. Click the applicable mouse button (middle or right). Refer to the

Operator’s Reference for information on conﬁguring your mouse.

SPECTRUM Support

Accessing Device-Speciﬁc Subviews

Figure 1-3. Accessing Device-Speciﬁc Subviews

2E42-27R

Bridging

FWD

Close Ctrl +C Navigate A

larms

Performance

Notes... Utilities Bridge Performance Bridge Detail Bridge Model Information Special Database Spanning T ree Information Static Database Table Transparent Bridge Info

FWD

Common

Device Speciﬁc

9032073 E2 Introduction

1-5

SPECTRUM V iews Roadmap

SPECTRUM Views Roadmap

Figure 1-4 shows a “roadmap” of the SPECTRUM views for this device. These views are accessible from double-click zones (Figure 1-1) and Icon Subviews menus (Figure 1-2 and Figure 1-3).

Introduction Fast Ethernet SmartSwitch Module 1-6 Management Module Guide

Figure 1-4. SPECTRUM Views Roadmap

Performance View, refer to the

Operator’s Reference

Device Views , refer to Chapter

2, Device Views

SPECTRUM V iews Roadmap

Interface Device View

Chassis Device View

Physical Device View

FDDI Conﬁguration View

Model Name

8H02_16

Conﬁguration Views,

refer to Chapter 3,

Conﬁguration Views

DevTop View, refer to the

Operator’s Reference

Application Views, refer

to Chapter 5, Application

View

CSIIfPort Conﬁguration View

Device Conﬁguration View

Port Conﬁguration View

Fast Ethernet Application

Interface Remap Application

DownLoad Application

ATM_Client Application

FDDI Application

Bridging Application, refer to

the Application View

Reference

MIB II Application, refer to the

Application View Reference.

RS-232 Application, refer to the

Application View Reference.

9032073 E2 Introduction

1-7

SPMA Support

SPECTRUM also supports SPECTRUM Portable Management Application (SPMA) functionality for these devices. Figure 1-5 shows an example of an SPMA Applications view. To open the SPMA Applications view, do the following:

1. Highlight the Device icon.

2. From the View menu, select Icon Subviews -> Utilities ->

Applications.

Figure 1-5. SPMA Applications View

Applications

Example of type 8H02_16

Community Names Frame Priorities

Broadcast Suppression MAC Priorities

Port Priorities Basic Alarms

Bridging of type CSIBridge

Bridge View

MIB II of type SNMP2_Agent

Generic SNMP (MIB I II)

Download App of type CtDownLoadApp

TFTP Download

System Resources

Trap Table

The SPMA Applications view provides the buttons, described below, that are used to access SPMA-speciﬁc views and dialog boxes. For more information, refer to the SPECTRUM Portable Management Application for the 2E42

SmartSwitch User’s Guide or the SPECTRUM Portable Management Application Tools Guide.

Introduction Fast Ethernet SmartSwitch Module 1-8 Management Module Guide

SPMA Support

Community Names

This button accesses the Community Names Tool, which allows you to change device community names. Refer to Chapter 3, Using the SPMA Community Names T ool, of the Tools Guide.

Frame Priorities

This button accesses the Frame Priorities window, which allows you to set the priority in which frames types are queued for transmission by the device. Refer to the 2E42 User’s Guide.

System Resources

This button accesses a window that displays current physical and logical system resources and utilizations on the device. Refer to the 2E42 User’s

Guide.

Broadcast Suppression

This button allows you to monitor broadcast trafﬁc statistics on each interface and set thresholds to limit broadcast trafﬁc over the device. Refer to the 2E42

User’s Guide.

MAC Priorities

This button accesses the MAC Priorities window, which allows you to set the priority in which frames are queued by MAC address for transmission by the device. Refer to the 2E42 User’s Guide.

Trap Table

This button accesses the SNMP Trap Tool, which allows you to establish which network management workstations on your network receive trap alarms from a selected device. Refer to Chapter 6, Using the SNMP Traps Tool, of the Tools Guide.

Port Priorities

This button accesses the Port Priority window, which allows you to set the priority in which frames are queued on selected ports for transmission by the device. Refer to the 2E42 User’s Guide.

Basic Alarms

This button allows you to conﬁgure alarms and events for each available interface. Refer to the 2E42 User’s Guide.

9032073 E2 Introduction

1-9

SPMA Support

Bridge View

This button provides an overview of bridging information for each port and allows you to access all other bridge-related options. Refer to the 2E42 User’s

Guide.

Generic SNMP (MIB I II)

This button accesses the MIB I, MIB II Tool, which allows you to change MIB I and MIB II object values. Refer to Chapter 2, Using the MIB I, MIB II Tool, of the Tools Guide.

TFTP Download

This button accesses the TFTP Download Tool, which allows you to upgrade ﬁrmware on Cabletron devices equipped with Flash EEPROMs. Refer to Chapter 5, Using the TFTP Download Tool, of the Tools Guide.

Introduction Fast Ethernet SmartSwitch Module 1-10 Management Module Guide

Device Views

What Is in This Chapter

This chapter describes the following Device views and subviews available for the Fast Ethernet SmartSwitch Modules.

• Interface Device view

• Chassis Device view

• Physical Device view

Chapter 2

Refer to Chapter 1, Introduction, for information on accessing SPECTRUM views from the Device icon and accessing device-speciﬁc subviews.

Interface Device View

This section describes the Interface icons and the Interface Options panel displayed in the Interface Device view. This view provides dynamic conﬁguration and performance information for each interface on the device. If the conﬁguration changes, SPECTRUM modiﬁes the Device view after the next polling cycle to reﬂect the new conﬁguration. This view also provides a Device icon that allows you to monitor the device operation and to access other device-speciﬁc views. Figure 2-1 shows an example of the Interface Device view for the Model 8H02-16. The views for the Model 2E42-27 and Model 2E43-27 are similar except for the number of Interface icons.

9032073 E2

2-1

Interface Device View

Figure 2-1. Interface Device View

Primary Landscape of 8H02_16

* File View Help?

Model Contact

Description

Location

Model Name

8H02_16

ETHERNET

0:01D:17:2F:B6

ETHERNET

0:01D:17:2F:B7

ETHERNET

0:01D:17:2F:B8

Filter

Interface Description

ETHERNET

0:01D:17:2F:BE

ETHERNET

0:01D:17:2F:BF

ETHERNET

0:01D:17:2F:BG

Network Address

Primary Application

Physical

ETHERNET

0:01D:17:2F:C2

ETHERNET

0:01D:17:2F:C3

ETHERNET

0:01D:17:2F:C4

Interface Options PanelDevice Icon

Bridging

Network Information

ETHERNET

0:01D:17:2F:CA

ETHERNET

0:01D:17:2F:CB

ETHERNET

0:01D:17:2F:CC

System Up Time

Manufacturer Device T ype

Serial Number

ADDRESS

Interface Icons

ETHERNET

0:01D:17:2F:B9

ETHERNET

0:01D:17:2F:BH

ETHERNET

0:01D:17:2F:C5

ETHERNET

0:01D:17:2F:CD

Device Views Fast Ethernet SmartSwitch Module 2-2 Management Module Guide

Interface Icon

These icons represent the interfaces or ports of the device. The icons identify the type of interface or port (e.g., Ethernet) and provide statistical information. Figure 2-2 shows an example of an Interface icon, its Icon Subviews menu, and its labels/double-click zones

The callouts (a through f) displayed in the illustration below identify the

NOTES

Figure 2-2. Interface Icon

label and, if available, the view to which it provides double-click zone access. For example, the icon area referred to by callout (b) displays the administrative status and provides double-click access to the Port Conﬁguration - CSIIfPort view.

The menu displayed in the illustration is the Icon Subviews menu for that Interface icon.

Interface Device View

Interface Icon

Icon Subviews Menu

Close Ctrl +c Navigate A

larms Performance Notes... Utilities Conﬁguration Model Information

a. Interface Label b. Administrative Status Label/Port Conﬁguration-CSIIfPort View c. Interface Type Label d. MAC Address Label/CSI Interface Port Model Information View e. Network Information Label/Network Information Panel Dialog Box f. Gauge Label/Performance - CSIIfPort View

(a) (b)

ETHERNET

0:0:1D:F:FD:B6

(e) (f)

9032073 E2 Device Views

2-3

Interface Device View Interface Icon

Interface Icon Subviews Menu

Table 2-1 describes the Interface icon device-speciﬁc subviews menu selections. For information on accessing device-speciﬁc subviews menus, see Chapter 1, Introduction.

Table 2-1. Interface Icon Subviews Menu

Menu Selection Description

Conﬁguration Opens the Device Conﬁguration view described

in Chapter 3, Conﬁguration V iew.

Model Information Opens the Model Information view described in

the Operator’s Reference.

Interface Label

This label displays the interface (port) number.

Administrative Status Label

This label displays the status of this interface. Double-click this label to open the Port Conﬁguration - CSIIfP ort view described in Chapter 3, Conﬁguration Views . Table 2-2 and Table 2-3 list the possible states relative to the application selected (Physical or Bridging). The default application for this view is Physical (MIB-II). To select the application to be displayed, click the

Filter menu button in the Interface Options panel. (Refer to the Interface Options Panel description later in this chapter for more information on the

Filter menu button.)

Table 2-2. Administrative Status for the Physical or MIB II Application

Color Status Description

Green ON Port is operational. Blue OFF Port is off. Yellow TST Port is in the test mode.

Device Views Fast Ethernet SmartSwitch Module 2-4 Management Module Guide

Table 2-3. Administrative Status for the Bridging Application

Color Status Description

Green FWD Bridge port is forwarding. Blue DIS Port is disabled. Magenta LST Bridge is in the listening mode. Magenta LRN Bridge is in the learning mode Orange BLK Bridge port is in the blocking mode. Red BRK Bridge port is broken. Blue UNK Status is unknown.

Interface Type Label

This label displays the interface type. Table 2-4 lists the possible interface types.

Table 2-4. Interface Types

Interface Device View

Interface Icon

Type Description

Other None of the following Reg1822 Regular 1822 HDH1822 HDLC Distant Host protocol DDNX25 Defense Data Network X.25 rfc877X25 RFC877 X.25 Ethernet Ethernet CSMA/CD iso88023 ISO CSMA/CD iso88024 ISO token bus iso88025 ISO token ring iso88026 ISO man starLan StarLAN IEEE 802.3 Prot10MB ProNET 10 Mbps Prot80MB ProNET 80 Mbps HyChan Hyperchannel FDDI Fiber Distributed Data Interface LAPB X.25 Line Access Procedure, Balanced SDLC IBM Synchronous Data Link Control protocol T1 T1 link (USA and Japan)

9032073 E2 Device Views

2-5

Interface Device View Interface Icon

Table 2-4. Interface Types (Continued)

Type Description

CEPT T1 link (Europe) BasicISDN Basic Integrated Services Digital Network PrimISDN Proprietary Integrated Services Digital

Network PPSerial Proprietary Point to Point Serial PPP Point to Point Protocol SFTWARLPBK Software Loopback CLNPoverIP Connectionless Network Protocol over IP Enet3MB Ethernet 3 Mbps XNSoverIP Xerox Network Service Protocol over IP SLIP Generic Serial Line IP ULTRA UL TRA T echnologies T-3 T3 link SMDS Switched Multimegabit Data Service FrameRelay T1 Frame relay

MAC Address Label

This label displays the MAC address of the device interface. Double-click this label to open the CSI Interface Port Model Information View displa y described in the Operator’s Reference.

Network Information Label

This label displays user-selectable network information (Address, Name, or Mask). The default is Address.

To change this label’s display, use the Interface Options panel described later in this chapter, or do the following:

1. Double-click the label to open the Network Information Panel dialog box.

2. Click the network information entry you wish to display.

3. Click OK.

Device Views Fast Ethernet SmartSwitch Module 2-6 Management Module Guide

Gauge Label

This label displays the performance statistic determined by the Gauge Control Panel for this interface. (Refer to the Gauge Control Panel description later in this chapter for more information.) Double-click this label to open the Performance - CSIIfPort view described in the Operator’s Reference.

Interface Options Panel

This area of the Interface Device view (Figure 2-1) allows you to modify the presentation of a highlighted icon. Double-click a non-text area of this panel to open the Gauge Control Panel view described later in this chapter. The Interface Options panel provides the information described below.

Filter

This menu button allows you to select the application to be displayed by the Interface icons. You can select other applications such as IP routing if the SPECTRUM Routing Services Management Module is loaded. For more information, refer to the Routing Services Management Module Guide.

Interface Device View

Interface Options Panel

Network Information

This menu button allows you to select the type of information displayed in the Network Information label of the highlighted icon. Possible selections are ADDRESS, NAME, or MASK.

Interface Description

This ﬁeld provides a description of the highlighted interface. If no interface is highlighted, this ﬁeld is empty or shows the interface previously highlighted.

Gauge Control Panel

This view (Figure 2-3) allows you to change the type of statistical information displayed on the Gauge label of the Interface icon. To access the Gauge Control Panel view, double-click the background of the Interface Options panel, or do the following:

1. Highlight the Interface Options panel.

2. From the View menu, select Icon Subviews -> Gauge Control Panel.

9032073 E2 Device Views

2-7

Interface Device View Gauge Control Panel

Figure 2-3. Gauge Control Panel

Gauge Control Panel

Gauge Mode Selected Attribute

Rates Load

Rates Totals Load In Percentages Load Out

Gauge Type In Packet Rate

Numeric % Discard

Numeric Linear % Filtered

Packet Rate

Out Packet Rate

Apply Keep Settings Reset Close

Default

Gauge Buttons

The Gauge Control Panel provides the following:

• Gauge Mode area

• Selected Attribute area

• Gauge Type area

• Gauge buttons

Gauge Mode

This area allows you to select the type of information shown on the Gauge label of the Interface icon: Rates, Totals, or Percentages. The Percentages selection displays the percentage of the selected interface compared to the rest of the interfaces.

The color displayed on the Gauge label depends upon the particular mode and statistical attribute selected. Table 2-5 and Table 2-6 list the attributes and their corresponding colors for the Totals mode and Rates mode, respectively.

Device Views Fast Ethernet SmartSwitch Module 2-8 Management Module Guide

Table 2-5. Totals Mode: Attributes and Corresponding Color

Selected Attribute Color

Errors Orange In Packets Blue Out Packets Blue In Octets Green Out Octets Green Discards Tan Forwarded Purple Host Bound Yellow Transmitted White Filtered Gray

Interface Device View

Gauge Control Panel

Table 2-6. Rates Mode: Attributes and Corresponding Color

Selected Attribute Color

Load Green Load In Green Load Out Green Packet Rate Blue In Packet Rate Blue Out Packet Rate Blue % Discard Tan % Filtered Gray %Forwarded Violet %Host Bound Yellow %Error Orange %Transmitted White

Selected Attribute

This area allows you to select the statistical attribute displayed on the Interface icon’s Gauge label. The label changes color to reﬂect the attribute selected.

9032073 E2 Device Views

2-9

Interface Device View Gauge Control Panel

Gauge Type

This area allows you to select either a numeric or linear display on the Gauge label.

Gauge Buttons

The following describes the Gauge buttons:

Apply

Applies the current settings to the Gauge label for as long as the view is open.

Keep Settings

Saves the current settings while SpectroGRAPH is running. Settings return to default when you restart SpectroGRAPH.

Reset

Returns the settings to the previously saved values.

Closes the Gauge Control Panel view.

Default

Returns the settings to the SPECTRUM default.

Device Views Fast Ethernet SmartSwitch Module 2-10 Management Module Guide

Chassis Device View

This view uses a Chassis Device icon to provide a logical representation of the device chassis and its interfaces or ports. The Chassis Device icon provides menu and double-click zone access to the views that monitor the interfaces.

Figure 2-4 shows an example of the Chassis Device view for the 2E42-27R device.

Figure 2-4. Chassis Device View

Landscape of type 2E42_27R

Chassis Device View

*File View

Model Name Contact Description Location

Bridging

FWD

2E42-27R

FWD

Primary Application

FWD

Net Address

FWD

Help?

System Up Time Manufacturer Device T ype

FDDI 1.1

FWD

Serial Number

UNK

CON

FWD

Bridging

FWD

Chassis Device Icon

9032073 E2 Device Views

2-11

Chassis Device View Chassis Device Icon

Chassis Device Icon

This icon is a logical representation of the physical device and its front panel interfaces or ports. This section describes the information available from the Chassis Device icon. Figure 2-5 shows an example of the Chassis Device icon for the 2E42-27R device.

The callouts displayed in this illustration identify the label name and the

NOTES

Figure 2-5. Chassis Device Icon

view to which it provides double-click access. For example, Device Type Label/Device Conﬁguration View displays the device model number and provides double-click access to the Device Conﬁguration view.

The menus displayed in the illustration are the Icon Subviews menus for that label.

Device Icon Subviews

Close Ctrl +c Navigate A

larms Performance Notes... Utilities Conﬁguration Application Display Model Information Application View Module Notes

Device Type Label/

Device Conﬁguration View

2E42-27R

Bridging

FWD

Application Label/

CSI Bridge Performance View

Bridging Icon Subviews

Close Ctrl +c Navigate A

larms Performance Notes... Utilities Bridge Performance Bridge Detail Bridge Model Information Special Database Spanning T ree Information Static Database Table Transparent Bridge Info

FWD

Interface Labels/

Performance - CSIIfPort View

FWD

Interface Icon Subviews

Close Ctrl +c Navigate A

larms Performance Notes... Utilities Conﬁguration

UNK

FDDI 1.1

FWD

FDDI Label/ FDDI Views

Logical Ports/

Port Conﬁguration View

CON

Device Views Fast Ethernet SmartSwitch Module 2-12 Management Module Guide

Device Type Label

This label identiﬁes the type of device. (Refer to Figure 2-5.) Double-click this area to open the Device Conﬁguration view described in Chapter 3, Conﬁguration Views .

Device Icon Subviews Menu

Table 2-7 lists each of the device-speciﬁc Icon Subviews menu selections available for this device. For information on accessing device-speciﬁc subviews, see Chapter 1, Introduction.

Table 2-7. Device Icon Subviews Menu

Menu Selection Description

Conﬁguration Opens the Device Conﬁguration view described in Chapter 3,

Conﬁguration Views .

Application Display Opens the Application menu selection. This menu selection

allows you to select the physical or bridging application.

Chassis Device View

Chassis Device Icon

Model Information Opens the Model Information view described in the

Application View Opens the Application view described in Chapter 5,

Module Notes Opens the Module Notes dialog box.

Application Label

This label provides access to the Bridging Icon Subviews menu. (Refer to

Figure 2-5.) Double-click the Application label to open the CSI Bridging

Performance view described in the Operator’s Reference.

Bridging Icon Subviews Menu

Table 2-8 lists speciﬁc Icon Subviews menu selections for the Application Label. For information on accessing device-speciﬁc subviews, see Chapter 1, Introduction.

Operator’s Reference.

Application Views .

9032073 E2 Device Views

2-13

Chassis Device View Chassis Device Icon

Table 2-8. Application Label Icon Subviews Menu

Menu Selection Description

Bridge Performance Opens the Performance view described in the

Operator’s Reference.

Bridge Detail Opens the Detail view described in the Operator’s

Reference.

Bridge Model Information Opens the Model Information view described in the

Operator’s Reference. Special Database Opens the Special Database view. Spanning Tree

Information Static Database Table Opens the Static Database Table view described in

Transparent Bridge Info Opens the Transparent Bridge Information view,

Opens the Spanning Tree Information view

described in the Application View Reference.

the Application View Reference.

with Forwarding Database and Port Tables

described in the Application View Reference.

Interface Labels

These labels identify the number and activity status of each port. (Refer to Figure 2-5.) Table 2-9 and Table 2-10 list the possible states relative to the application selected. Double-click the label to open the Performance CSIIfPort view described in the Operator’s Reference.

Table 2-9. Interface Status for the Bridging Application

Color Status Description

Device Views Fast Ethernet SmartSwitch Module 2-14 Management Module Guide

Chassis Device View

Chassis Device Icon

Table 2-10. Interface Status for the Physical (MIB II) Application

Color Status Description

Green ON Port is operational. Blue OFF Port is off. Yellow TST Port is in the test mode.

Interface Icon Subviews Menu

This menu’s Conﬁguration option opens the Conﬁguration dialog box, which allows you to enable or disable the selected port. For information on accessing device-speciﬁc subviews, see Chapter 1, Introduction.

FDDI Label

This label provides access to the FDDI Icon Subviews menu. (Refer to Figure 2-5.) Double-click this label to open the FDDI Application views described in the Operator’s Reference.

FDDI Icon Subviews Menu

Table 2-11 describes each of the Icon Subviews menu selections available for FDDI. For information on accessing device-speciﬁc subviews, see Chapter 1, Introduction.

Table 2-11. FDDI Label Icon Subviews Menu

Menu Selection Description

FDDI Performance Opens the FDDI Performance view. (Not available for

FddiNoMAC). FDDI Conﬁguration Opens the FDDI Conﬁguration view. FDDI Station List Opens the FDDI Station List view. (Not available for

FddiNoMAC). FDDI Model

Information

Opens the Model Information view for FDDI.

9032073 E2 Device Views

2-15

Chassis Device View Chassis Device Icon

Logical Ports Labels

These labels provide access to the Logical Port Icon Subviews menu. Double-click a label to open the Port Conﬁguration View.

Logical Ports Icon Subviews Menu

Table 2-12 describes each of the Icon Subviews menu selections. For information on accessing device-speciﬁc subviews, see Chapter 1, Introduction.

Table 2-12. Logical Ports Icon Subviews Menu

Menu Selection Description

Port Notes Opens the Port Notes facility. Enable/Disable Port Enables or disables the selected port. Port Conﬁguration

View

Opens the Port Conﬁguration view.

Device Views Fast Ethernet SmartSwitch Module 2-16 Management Module Guide

Physical Device View

This view provides a static image of the device and its ports or interfaces and does not change to reﬂect conﬁguration status. Figure 2-6 is an example of the Physical Device view for the 8H02-16 device.

Figure 2-6. Physical Device View

Landscape of type 8H02_16

*File View Help?

Physical Device View

Model Name Contact Description Location

Net Address

Prime Application

SmartSwitch 10/100

WITH Secure

8H02-16

Fast

Virtual Networking

PWR OPR

Reset

COM

2X 3X

4X5X6X

Bridging

8X9X10X

System Up Time Manufacturer Device T ype Serial Number

12X

11X

13X14X

Smart

SWITCH

9032073 E2 Device Views

2-17

Physical Device View

Device Views Fast Ethernet SmartSwitch Module 2-18 Management Module Guide

Conﬁguration Views

What Is in This Chapter

This chapter describes the Conﬁguration views available for the F ast Ethernet SmartSwitch Modules. These views display network conﬁguration and operating information for the device and its interfaces.

The following Conﬁguration views are available for this device:

• Device Conﬁguration

• Port Conﬁguration - CSIIfPort

• FddiMAC Device Conﬁguration

• Port Conﬁguration

Chapter 3

9032073 E2

Refer to Chapter 1, Introduction, for information on Accessing SPECTRUM Views from the Device Icon and Accessing Device-Speciﬁc Subviews.

3-1

Device Conﬁguration View

This view provides device -speciﬁc conﬁguration information as well as access to other views that allow you to conﬁgure device components.

Device Conﬁguration Information

This section of the Conﬁguration view displays the following device-speciﬁc information.

Contact Status

Indicates whether a connection with the device has been established. This view also provides the following SPMA view buttons that allow you to

conﬁgure this device. Refer to the SPECTRUM Portable Management Application Tools Guide for details on the views accessible from these buttons.

Component Table

Opens the Community Name window, which provides information on the F ast Ethernet SmartSwitch Module components.

Download Application

Opens the TFTP Download View, which enables you to upgrade the ﬁrmware for a Fast Ethernet SmartSwitch Module from a TFTP Boot or Bootp Server.

Trap Table

Opens the Trap Table, which allows you to set up your workstation to be notiﬁed of traps received and sent by the Fast Ethernet SmartSwitc h Module.

Conﬁguration Views Fast Ethernet SmartSwitch Module 3-2 Management Module Guide

Interface Conﬁguration Table Information

This table within the Device Conﬁguration view provides the following conﬁguration information about the device’s interfaces or ports.

Number of Interfaces

Displays the number of interfaces or ports available for this device.

Index

Displays the interface or port number.

Type

Displays the type of hardware interface or port. Table 3-1 lists the possible interface types.

Table 3-1. Interface Types

Type Description

Network

Device Conﬁguration View

PPSerial Proprietary Point to Point Serial

9032073 E2 Conﬁguration Views

3-3

Device Conﬁguration View Interface Conﬁguration Table Information

Table 3-1. Interface Types (Continued)

Type Description

PPP Point to Point Protocol SFTWARLPBK Software Loopback CLNPoverIP Connectionless Network Protocol over IP Enet3MB Ethernet 3 Mbps XNSoverIP Xerox Network Service Protocol over IP SLIP Generic Serial Line IP ULTRA UL TRA T echnologies T-3 T3 link SMDS Switched Multimegabit Data Service FrameRelay T1 Frame relay

Phy Address

Displays the physical (MAC) address of the interface or port.

Max Frame Size

Displays the maximum frame size for the interface or port.

Oper Status

Displays the current operational state of this interface or port (Up, Down, or Testing).

Conﬁguration Views Fast Ethernet SmartSwitch Module 3-4 Management Module Guide

Port Conﬁguration - CSIIfPort View

This view provides information on the conﬁguration and operating status of the device interfaces or ports.

To access the Port Conﬁguration - CSIIfPort view for a particular interface or port, do the following:

1. Within the Interface Device view, highlight the Interface icon.

2. From the View menu, select Icon Subviews -> Conﬁguration. This view provides the following information:

Interface Index

Displays the numerical value identifying the interface or port.

Interface Type

Displays the type of interface or port.

Operation Status

Displays the current operating status of the interface or port. Possible values are On, Off, and Test.

Admin Status

Displays the current administrative status of the interface or port. Possible values are On, Off, and Test.

IF Description

Provides a description of the interface or port.

9032073 E2 Conﬁguration Views

3-5

FddiMAC Device Conﬁguration View

The FddiMAC Device Conﬁguration view provides conﬁguration and operating status information.

To access this view, do the following:

1. Highlight the FddiMAC icon in the Application view (Icon mode) or the FddiMAC text label (List mode).

2. From the View menu, select Icon Subviews -> Conﬁguration or click the applicable mouse button (middle or right) and select Conﬁguration.

Station Conﬁguration

This section of the FddiMAC Device Conﬁguration view provides the following conﬁguration information on the FDDI station.

Ring State

The current state of the FDDI Ring. Table 3-2 lists the possible states and their descriptions.

Table 3-2. FDDI Ring States

Ring

States

Isolated The concentrator is not attached to the ring. Non-Op The concentrator is attempting to enter the ring. Ring-Op The ring is operational. Detect The claim/beacon process of the FDDI ring protocol has exceeded

one second. This indicates a potential problem.

Non-Op-Dup The ring failed to complete the claim/beacon process because a

duplicate FDDI address has been detected.

Ring-Op-Dup The ring is operational, but a duplicate FDDI address has been

detected.

Directed The claim/beacon process did not complete within nine seconds.

The concentrator is now sending directed beacons to indicate a problem.

Trace A problem has been detected with the station or its upstream

neighbor . A trace is being sent to notify the upstream neighbor of the problem. The concentrator and all stations between the concentrator and its upstream neighbor can perform self-tests.

Description

Conﬁguration Views Fast Ethernet SmartSwitch Module 3-6 Management Module Guide

MAC Conﬁguration

The actual conﬁguration of the station. T able 3-3 lists the possible conﬁgurations and their descriptions.

Table 3-3. SMT MAC Conﬁgurations

FddiMAC Device Conﬁguration View

Station Conﬁguration

Ring

States

Isolated The path is not inserted into any path. Local_A The A port is inserted into a local path and the B port is not. Local_B The B port is inserted into a local path and the A port is not. Local_AB Both A and B are inserted into a local path. Local_S The S port is inserted into a local path. Wrap_A The secondary path is wrapped to the A port. Wrap_B The secondary path is wrapped to the B port. Wrap_AB The primary path is wrapped to the B port and the secondary path

is wrapped to the A port. Wrap_S The primary port is wrapped to the S port. C_Wrap_A The primary and secondary paths are joined internally in the

station and wrapped to the A port. Regarding token ﬂow, all

resources on the secondary path precede those of the primary path. C_Wrap_B The primary and secondary paths are joined internally in the

station and wrapped to the B port. Regarding token ﬂow, all

resources on the secondary path precede those of the primary path. C_Wrap_S The primary and secondary paths are joined internally in the

station and wrapped to the S port. Regarding token ﬂow, all

resources on the secondary path precede those of the primary path.

Description

Thru The primary path enters the A port and emerges from the B port.

The secondary path enters the B port and emerges from the A port.

Current MAC Path

The ring that this station resides on. Possible entries are Primary, Secondary, or Local.

MAC Address

The MAC (physical) address of this station.

MAC Count

The number of MACs supported by this station.

Non Master Ports

The number of non-master ports on this station.

Master Ports

The number of master ports on this station.

9032073 E2 Conﬁguration Views

3-7

Port Conﬁguration View SMT Information

SMT Information

This section of the FddiMAC Device Conﬁguration view provides the following conﬁguration information on the FDDI SMT:

SMT V ersion

The version of Station Management (SMT) running.

OBS Present

Indicates whether an Optical Bypass Switch (OBS) is connected.

T-Notify (sec)

The timer value, in seconds, used in Neighbor Notiﬁcation Protocol. The allowed range is from 2 to 30 seconds.

T-Req (milli sec)

The Target Token Rotation Time (TTRT) bid, in milliseconds, made by this concentrator.

T-Neg (milli sec)

The winning TTRT bid, in milliseconds, on the ring.

TVX (milli sec)

The valid transmission time, in milliseconds.

Port Conﬁguration View

The Port Conﬁguration view provides information on the conﬁguration and operating status of the ports. To access this view, do the following:

1. Highlight the Logical Port icon in the Chassis Device view.

2. From the View menu, select Icon Subviews -> Port Conﬁguration View.

The Port Management section of the FDDI Port Conﬁguration view provides the following information:

Port Action

Allows you to enable/disable the port. The state returns to “Other” once the port has been Enabled/Disabled.

Port State

The status of this port. Possible states are disabled, connecting, standby, and active.

Port Type

The type of port. Possible port types are A_Port, B_Port, Slave, or Master.

Conﬁguration Views Fast Ethernet SmartSwitch Module 3-8 Management Module Guide

Link Error Rate Estimate

The link error rate estimate is a cumulative long-term average of the bit error rate, which represents the quality of the physical link. The link error rate estimate is computed when the port is connected and every 10 seconds thereafter. It ranges from 10-4 to 10 example, if the port’ s link error rate estimate is computed to be 10-5, the value reported in this ﬁeld would be 5, which represents an actual rate of 1,250 bit errors per second. A lower link error rate estimate indicates a higher bit error rate as shown in Figure 3-1.

Figure 3-1. Link Error Rate Estimate

.000000125

.00000125

.0000125

.000125

.00125

Bit Errors per Second

.0125

.125

1.25

12.5 125

1250

12500

Port Conﬁguration View

-15

and is reported as a whole integer. For

45 678910111213 14 15

Reported Link Error Rate Estimate (n)

Link Error Monitor Count

The aggregate link error monitor count. This count is set to zero on station power up and increments each time the port’s link error monitor detects an error. An increasing link error monitor count usually indicates a problem with the connectors or the cable between this port and the node.

Link Error Rate Cutoff

The link error rate threshold at which a link connection is ﬂagged as faulty and the port disabled by SMT. The default link error rate cutoff threshold is 7, which represents 12.5 bit errors per second.

Link Error Rate Alarm

The link error rate threshold above which an alarm for the port will be generated. The default link error rate alarm threshold is 8, which represents

1.25 bit errors per second.

Link Error Monitor Reject Count

The link error monitor count of the times the link has been rejected.

9032073 E2 Conﬁguration Views

3-9

Port Conﬁguration View

Conﬁguration Views Fast Ethernet SmartSwitch Module 3-10 Management Module Guide

Chapter 4

Event and Alarm Messages

What Is in This Chapter

This chapter lists the types of events and alarms generated by the Fast Ethernet SmartSwitch Modules and provides any probable cause messages corresponding to these alarms.

Device Events and Alarms

Table 4-1 lists the SPECTRUM database directory paths (in bold) and the messages displayed for the Event Log and Alarm Manager when applicable.

Table 4-1. Fast Ethernet SmartSwitch Module Events and Alarms

Message in the Event Log

CsEvFormat/Event00010306

{d “%w- %d %m-, %Y - %T”} - A(n) {t} device, named {m}, has been cold started. (event [{e}])

CsEvFormat/Event00010307

{d “%w- %d %m-, %Y - %T”} - A(n) {t} device, named {m} has been warm started, (event [{e}])

Alarm Manager Probable Cause

Message

No probable cause message

9032073 E2

4-1

Device Events and Alarms

Table 4-1. Fast Ethernet SmartSwitch Module Events and Alarms (Continued)

Message in the Event Log

CsEvFormat/Event00010308

{d “%w- %d %m-, %Y - %T”} - A(n) {t} device, named {m}, has detected a communication Link Down. (event [{e}])

CsEvFormat/Event00010309

{d “%w- %d %m-, %Y - %T”} - A(n) {t} device, named {m}, has detected a communication Link Up. (event [{e}])

CsEvFormat/Event0001030a

{d “%w- %d %m-, %Y - %T”} - A(n) {t} device, named {m}, has detected an Authentication Failure. (event [{e}])

CsEvFormat/Event0001030b {d “%w- %d %m-, %Y - %T”} - A(n) {t}

device, named {m}, has detected an EGP Neighbor Loss. EGP Neighbor IP address is {0 1}. (event [{e}])

Alarm Manager Probable Cause

Message

CsPCause/Prob00010308

Communication link is down.

No probable cause message

CsPCause/Prob0001030a

Authorization failure. Other user is trying to connect to device with an invalid community string.

CsPCause/Prob0001030b

Lost contact with EGP neighbor.

CsEvFormat/Event000d01a0

{d “%w- %d %m-, %Y - %T”} - A Port Interface Module has been inserted into port {I 3} of interface {I 1} on {m} ({t}). (event [{e}]).

CsEvFormat/Event000d01a1

{d “%w- %d %m-, %Y - %T”} - A Port Interface Module has been removed from port {I 3} of interface {I 1} on {m} ({t}). (event [{e}])

CsEvFormat/Event000d01a2

{d “%w- %d %m-, %Y - %T”} Network conﬁguration change reported by {m} ({t}). Device linked to port {I 3} on interface {I 1}. (event [{e}])

CsPCause/Prob000d01a0

A Port Interface Module has been physically inserted.

CsPCause/Prob000d01a1

A Port Interface Module has been physically removed.

CsPCause/Prob000d01a2

A device supporting link integrity, ﬁber optic or twisted pair, has made a valid connection (link) to this port.

Event and Alarm Messages Fast Ethernet SmartSwitch Module 4-2 Management Module Guide

Device Events and Alarms

Table 4-1. Fast Ethernet SmartSwitch Module Events and Alarms (Continued)

Message in the Event Log

CsEvFormat/Event000d01a3

{d “%w- %d %m-, %Y - %T”} - Port {I 3} on interface {I 1} of {m} ({t}), has unsegmented. (event [{e}]).

CsEvFormat/Event000d0351

{d “%w- %d %m-, %Y - %T”} - Front panel redundant port {I 1} has been activated by device {m} of type {t}. (event [{e}])

CsEvFormat/Event000d0001

{d “%w- %d %m-, %Y - %T”} - {m} of type {t} has reported a root change. (event [{e}])

CsEvFormat/Event000d0002

{d “%w- %d %m-, %Y - %T”} - Bridge {m} of type (t) has reported a network topology change (event [{e}]).

Alarm Manager Probable Cause

Message

CsPCause/Prob000d01a3

A device previously linked with this port has been removed, powered down, or the cable segment has a fault.

CsPCause/Prob000d0351 A new port has been activated for the front

panel redundant circuit. This does NOT indicate this port is usable, but is being tested.

CsPCause/Prob000d0001

This bridge has become the new root of the Spanning Tree.

CsPCause/Prob000d0002

A port has transitioned from the Learning state to the Forwarding state , or from the F orw arding state to the Blocking state.

CsEvFormat/Event00830000

{d “%w- %d %m-, %Y - %T”} - DLM LostContact trap for Destination Address {0 1}, Owner Address {0 2} from {t} device, named {m}. (event [{e}]).

CsEvFormat/Event00830001 {d “%w- %d %m-, %Y - %T”} - DLM

Threshold Trap for Destination Address {0 1}, Owner {0 2}, OID sequence {I 3}, OID Object {0 4} from {t} device, named {m}. (event [{e}]).

CsEvFormat/Event00830002

{d “%w- %d %m-, %Y - %T”} - DLM ReestabContact Trap for Destination Address {0 1}, Owner Address {0 2} from {t} device, named {m}. (event [{e}])}.

No probable cause message

9032073 E2 Event and Alarm Messages

4-3

Device Events and Alarms

Event and Alarm Messages Fast Ethernet SmartSwitch Module 4-4 Management Module Guide

Application Views

What Is in This Chapter

This chapter describes the device-speciﬁc applications listed below for the F ast Ethernet SmartSwitch Modules. The corresponding application model type is shown in parentheses.

• Interface Remap (CtIfRemapApp)

• Fast Ethernet (FastEnetApp)

• FDDI FNB Application (FddiMAC)

• ATM Application (ATM_Client)

• DownLoad App (CtDownLoadApp)

Chapter 5

Common Applications Not Covered Here

This device supports the following common applications described in the Application View Reference:

• Bridging (CSIBridge)

- Spanning Tree (Ct_Stp_App)

- Static (Static_App)

- Transparent (CT_Tp_Appl)

• MIB-II (SNMP2_Agent)

- ICMP (ICMP_App)

- IP (IP2_App)

- System (System2_App)

- UDP (UDP2_App)

• RS-232 App (RFC1317App)

9032073 E2

5-1

Device Application View

The following major application is available if you purchase the associated Cabletron product. The application is described within the documentation supplied with the product.

• Standard RMON (RMON App)

- Ethernet Probe 1(RMONEthProbe) through Ethernet Probe 16 (RMONEthProbe)

Device Application View

This view shows the common and device-speciﬁc applications supported by this device and provides access to application-speciﬁc information.

Refer to Chapter 1, Introduction, for information on Accessing SPECTRUM Views from the Device Icon.

Figure 5-1 shows an example of an Application view in the Icon mode. Figure 5-2 shows an example of an Application view in the List mode.

To change the displa y mode , from the View menu select Mode -> List or Icon.

Application Views Fast Ethernet SmartSwitch Module 5-2 Management Module Guide

Figure 5-1. Device Application View (Icon Mode)

Landscape of type 2E42_27R

*File View Help?

Device Application View

Model Name

Contact

Description Location

Bridging

CSIBridge

Spanning Tree

CT_Stp_App

Static_App

Static

Network Address

Primary Application

FddiMAC

Model Name

2E42_27R

Fddi 1.1

FddiMAC

Bridging

System Up Time Manufacturer Device T ype Serial Number

MIB-II

SNMP2_Agent

SNMP2_Age

ICMP

ICMP_App

IP2_App

Transparent

CT_Tp_Appl

System

System2_App

9032073 E2 Application Views

5-3

Device Application View

Figure 5-2. Device Application View (List Mode)

Landscape of type 2E42_27R

*File View Help?

Model Name Contact

Description Location

Cabletron

Network Address

Primary Application

SS8H

CSIBridge CT_Stp_App Static_App CT_Tp_Appl

FddiMAC

SNMP2_Agent ICMP_App IP2_App System2_App UDP2_App

Bridging

System Up Time Manufacturer Device T ype Serial Number

CtIfRemapApp

CtDownLoadApp FastEnetApp

Application Views Fast Ethernet SmartSwitch Module 5-4 Management Module Guide

Interface Remap Application

The name of the model type used to model the application is CtIfRemapApp. The application provides the ability to map one or more interfaces to another interface. A map is deﬁned by creating a row in the Interface Remap Table (described below) to specify the source and destination interfaces. When a source interface is remapped to a destination interface, the destination interface transmits all packets received or transmitted on the source interface. Counters on the destination interface increment for all packets transmitted by normal bridging or due to the interface remap. Figure 5-3 shows a view of the Interface Remap Table.

Access the Interface Remap Table as follows:

1. Highlight the CtIfRemapApp icon (Icon mode) or text label (List mode).

2. From the View menu, select Icon Subviews -> Port Remap. The Interface Remap Table provides the following information:

Number Entries

The number of active entries in the Interface Remap Table.

Interface Remap Application

Physical Errors Enable

Physical error remapping can be Enabled, Disabled, or Unsupported. Unsupported indicates that the device is incapable of remapping physical errors.

Max Number Entries

The maximum number of entries allowed in the Interface Remap Table.

Sort

Used to sort the Interface Remap Table.

Find

Used to search the Interface Remap Table for a speciﬁc interface.

Update

Used to update the Interface Remap Table.

Source Port

The source interface that will have packets redirected to the destination interface as deﬁned by Destination.

Destination The interface that will see all packets redirected from Source Port.

9032073 E2 Application Views

5-5

Interface Remap Application

Port Redirect

This button opens the Port Redirect view, where you can add or delete an entry from the table.

Figure 5-3. Interface Remap Table

Landscape of type 2E42_27R

*File View Help?

Name Contact Description Location

CtIfRemapApp

Network Address

Primary Application

Interface Remap Table

Number Entries Physical Errors Enable

Sort

Source Port

Find

Update

Port Redirect

Bridging

Enable

System Up Time Manufacturer Device T ype Serial Number

Max Number Entries

Destination

Application Views Fast Ethernet SmartSwitch Module 5-6 Management Module Guide

Fast Ethernet Application

The name of the model type used to model the application is FastEnetApp. The application provides the Fast Ethernet Port Table and Fast Ethernet Conﬁguration view, which allow you to conﬁgure ports for Ethernet or Fast Ethernet transmission or use Auto-Negotiation to determine transmission mode.

Fast Ethernet Port Table

Access this table as follows:

1. Highlight the FastEnetApp icon (Icon mode) or text label (List mode).

2. From the View menu, select Icon Subviews -> Control Table. The Fast Ethernet Port Table provides the following information:

Interface

The interface number to which this Fast Ethernet information applies.

Fast Ethernet Application

Port Group

The port group number to which this Fast Ethernet information applies.

Port

The physical port number to which this Fast Ethernet information applies.

Operational Mode

The current operational mode of this port.

Fast Ethernet Conﬁguration View

This view (Figure 5-4) allows you to conﬁgure ports for Ethernet or Fast Ethernet transmission or to use Auto-Negotiation in determining transmission mode. Open this view by double-clicking any entry in the Fast Ethernet Port Table. The Fast Ethernet Conﬁguration view carries the Interface, Port Group, and Port information over from the Port Table.

9032073 E2 Application Views

5-7

Fast Ethernet Application Fast Ethernet Conﬁguration View

Figure 5-4. Fast Ethernet Conﬁguration View

Landscape of type 2E42_27R

*File View Help?

Model Name Contact Description Location

Interface

Auto-Negotiation 10BaseT 10BaseTFD

10BaseT 10BaseTFD 100BaseTX

Network Address

Primary Application

Port Group

Operational Mode

100BaseTX 100BaseTXFD 100BaseT4

Advertised Ability

100BaseTXFD

100BaseT4

100BaseFX

Bridging

100BaseFX 100BaseFXFD

100BaseFXFD

System Up Time Manufacturer Device T ype Serial Number

Port

Received Technology

Undeﬁned

Auto-Negotiation

Not-Detected

10BaseT 10BaseTFD 100BaseTX

100BaseTXFD

100BaseT4 100BaseFX

100BaseFXFD

Operational Mode

These selections indicate the current operational mode of this port. If you select Auto-Negotiation, you can select as many modes as needed from the Advertised Ability selections. You can only select one Operational Mode: either Auto-Negotiation or one of the speciﬁc modes. Table 5-1 lists the current operational modes, their values, and their descriptions.

Application Views Fast Ethernet SmartSwitch Module 5-8 Management Module Guide

Fast Ethernet Application

Fast Ethernet Conﬁguration View

Table 5-1. Current Operational Mode Values and Descriptions

Operational

Mode

Auto-Negotiation 2 Auto-Negotiation/Parallel Detection 10Base-T 8 10Base-T 10Base-TFD 16 Full Duplex 10Base-T 100Base-TX 32 100Base-TX 100Base-TXFD 64 Full Duplex 100Base-TX 100Base-T4 128 100Base-T4 100Base-FX 256 100Base-FX 100Base-FXFD 512 Full Duplex 100Base-FX

Value Description

Advertised Ability

These selections indicate the advertised ability of the local hardware. They become active on ports that have Auto-Negotiation enabled. Auto-Negotiation allows the FE-100TX RJ-45 port to self-conﬁgure to 10 or 100 Mbps depending on the speed of the attached device. The interfaces can also dynamically conﬁgure themselves for full duplex or half duplex (standard mode) operation when both ends of the link support Auto-Negotiation. When only one link partner supports Auto-Negotiation, the mode defaults to half duplex.

Both local and remote management for the Fast Ethernet SmartSwitch Module provide the ability to disable Auto-Negotiation if desired. A port that does not support Auto-Negotiation will be read as “other” (1).

Table 5-2 lists the Advertised Ability modes, their values, and their descriptions.

Table 5-2. Advertised Ability Mode Values and Descriptions

Advertised

Ability

10Base-T 8 10Base-T 10Base-TFD 16 Full Duplex 10Base-T 100Base-TX 32 100Base-TX 100Base-TXFD 64 Full Duplex 100Base-TX 100Base-T4 128 100Base-T4

Value Description

9032073 E2 Application Views

5-9

Fast Ethernet Application Fast Ethernet Conﬁguration View

Table 5-2. Advertised Ability Mode Values and Descriptions

Advertised

Ability

100Base-FX 256 100Base-FX 100Base-FXFD 512 Full Duplex 100Base-FX

Value Description

Received Technology

These selections indicate the advertised ability of the remote hardware or link partner. These modes are read-only. Table 5-3 lists the Received Technology modes, their values, and their descriptions.

Table 5-3. Received Technology Mode Values and Descriptions

Received

Technology

Undeﬁned 1 Undeﬁned Auto-Negotiation 2 Auto-Negotiation/Parallel Detection Not-Detected 4 Link Partner does not support Auto-

10Base-T 8 10Base-T 10Base-TFD 16 Full Duplex 10Base-T 100Base-TX 32 100Base-TX 100Base-TXFD 64 Full Duplex 100Base-TX 100Base-T4 128 100Base-T4 100Base-FX 256 100Base-FX 100Base-FXFD 512 Full Duplex 100Base-FX

Value Description

Negotiation

Application Views Fast Ethernet SmartSwitch Module 5-10 Management Module Guide

FDDI FNB Application

This section describes the FDDI FNB application supported by this device. The name of the model type used to model the application is FddiMAC. This application is available when the appropriate High Speed Interface Module (HSIM) is installed.

Table 5-4 lists the application-speciﬁc subviews available from the Icon Subviews menu for the FDDI FNB application.

Table 5-4. FDDI FNB Application Subviews menu

Menu Selection Description

DevTop Opens the Device Topology view described in the Operator’s

Reference.

Station List Opens the FDDI Station List view described below. Acknowledge Allows you to acknowledge an alarm condition. Conﬁguration Opens the Device Conﬁguration view described in Chapter 3,

Conﬁguration Views .

FDDI FNB Application

Model Information Opens the Model Information view described in the

FDDI Station List View

This view displays information about the devices connected to the FDDI ring and provides the following functionality and information.

Update

This button updates the contents of the Station Table.

MAC/Canonical

This button controls which type of address is shown in the Station List. It toggles between MAC (Physical) and Canonical (Ethernet) and displays the format not currently selected.

Set Filter/Clear Filter

Set Filter Opens the Filter Dialog box for the selected column of the Station table. Type a character string to search the column.

Clear Filter returns the Station table to its normal state.

Operator’s Reference.

9032073 E2 Application Views

5-11

FDDI FNB Application FDDI Station List View

Sort Up

This button has three possible states: Sort Up, Sort Down, and Unsort. Sort Up organizes the list within a selected column from the lowest

alphanumeric value to the highest. Sort Down organizes the list within a selected column from the highest

alphanumeric value to the lowest. Unsort returns the ﬁelds to their normal state.

Station Address

Displays the MAC or Canonical address of this node on the ring.

Node Class

Displays the type of FDDI ring device. Table 5-5 lists the possible node classes.

Table 5-5. FDDI Node Classes

Node Class Description

Station An FDDI node capable of receiving, transmitting, and repeating

data.

Concentrator An FDDI node that provides attachment points for stations that

are not directly connected to the FDDI ring.

Ring T opology

Displays the current state of this FDDI node.

Master Ports

Displays the number of master ports on this node. Values range from 0 to 255.

Upstream Neighbor

Displays the canonical or MAC address of the last node to receive the token before this node.

Application Views Fast Ethernet SmartSwitch Module 5-12 Management Module Guide

ATM Client Application

This section describes the ATM Client application supported by this device. This application is available when the appropriate High Speed Interface Module (HSIM) is installed.

Table 5-6 lists the application-speciﬁc subviews available from the Icon Subviews menu for the ATM Client application:

Table 5-6. ATM Client Application Subviews menu

Menu Selection Description

Conﬁguration Opens the Device Conﬁguration view described in Chapter

3, Conﬁguration V iews .

Model Information Opens the Model Information view described in the

Operator’s Reference.

VCL Table Opens the ATM Client Application VCL (Virtual Channel

Link) Table view described later in this chapter.

Interfaces Opens the Interfaces view described later in this chapter.

ATM Client Application

ATM Client Application VCL View

This view provides a table containing detailed information about the virtual channels passing through this application. The ATM Client Application Virtual Channel Link view provides the following information.

Admin Status

This object is implemented only for a VCL that terminates a VCC (i.e., one that is not cross-connected to other VCLs). Its value speciﬁes the desired administrative state of the VCL. The Up state indicates that the trafﬁc ﬂow for this VCL is enabled. The Down state indicates that the trafﬁc ﬂow for this VCL is disabled.

Oper Status

This object shows the current operational status of the VCL. The Up and Down states indicate that the VCL is currently operational or not operational, respectively. The Unknown state indicates that the status of this VCL cannot be determined.

Last Change

This is the value of the MIB II’s sysUpTime object at the time the VCL entered its current operational state. If the current state was entered prior to the last re-initialization of the agent, then this object contains a zero value.

RTD (Receive Trafﬁc Description) Index

The value of this object identiﬁes the row in the ATM Trafﬁc Descriptor Table that applies to the receive direction of this VCL.

9032073 E2 Application Views

5-13

ATM Client Application ATM Client Application VCL View

TTD (Transmit Trafﬁc Description) Index

The value of this object identiﬁes the row of the ATM Trafﬁc Descriptor Table that applies to the transmit direction of this VCL.

AAL (ATM Adaptation Layer) Type

An instance of this object only exists when the local VCL endpoint is also the VCC endpoint and the AAL is in use. The type of AAL used on this VCC includes AAL1, AAL3/4, and AAL5. “Other” indicates a user-deﬁned AAL type. “Unknown” indicates that the AAL type cannot be determined.

Transmit Size

This is the maximum AAL5 CPCS SDU size, in octets , that is supported on the transmit direction of this VCC. An instance of this object only exists when the local VCL endpoint is also the VCC endpoint and the AAL5 is in use.

Receive Size

This is the maximum AAL5 CPCS SDU size, in octets , that is supported on the receive direction of this VCC. An instance of this object only exists when the local VCL endpoint is also the VCC endpoint and the AAL5 is in use.

Encaps Type

This is the type of data encapsulation used over the AAL5 SSCS layer. An instance of this object only exists when the local VCL endpoint is also the VCC endpoint and the AAL5 is in use. The deﬁnitions reference RFC 1483 Multiprotocol Encapsulation over ATM AAL5 and to the ATM Forum LAN Emulation speciﬁcation.

VCL CC (Cross Connect) Id

This object is implemented only for a VCL that is cross-connected to other VCLs that belong to the same VCC. All such associated VCLs have the same value for this object, and all their cross-connections are identiﬁed by entries in the Cross Connect Table for which VCL CC Id has the same value. The value of this object is initialized by the agent after the associated entries in the Cross Connect Table have been created.

Row Status

This object is used to create, delete, or modify a row in this table. To create a new VCL, this object is initially set to “createAndW ait” or “createAndGo.” This object must not be set to “active” unless the following columnar objects exist in this row:

• RTD Index

• XTD Index

• AAL Type (if the local VCL endpoint is also the VCC endpoint)

• Transmit Size (for AAL5 connections only)

• Receive Size (for AAL5 connections only)

• Encaps Type (for AAL5 connections only)

Application Views Fast Ethernet SmartSwitch Module 5-14 Management Module Guide

NOTE

ATM Client Application

ATM Client Application VCL View

The Community Name ﬁeld in the Communication Information Panel of the Model Information view must be set to “private” in order to change the ﬁelds in the table views.

To make a change to the rows in the table view, do the following:

1. In the Communication Information panel of the Virtual Link view, change the Community Name ﬁeld to “private.”

2. From the Icon Subviews menu, select Table V iew.

3. Set the path information for the row you wish to create, change, or remove.

4. Press Return and click on OK.

5. To create or change a row, click on the Create button, change the applicable ﬁelds in the Change view, and click the right mouse button. Click OK.

6. Click on the Validate Row button and return to the Application Table view to see the change.

7. To remove a row, click on the Remove button and then the Update button. The row will then be removed from the table view.

The Virtual Channel Link table can be sorted, searched, and updated using the following buttons within the view:

Sort

This button allows you to sort the table based on the column heading you select. To use the Sort feature, select a column heading and click on the Sort button. The table is rearranged according to the chosen column.

Find

This button allows you to search the table for a speciﬁc entry. To use the Find feature, select a column heading, click on the Find button, and enter a search string in the dialog box.

Update

This button allows you to update information in the table. Double-clicking on a ﬁeld entry opens the interface-speciﬁc ATM Switch

Application Virtual Channel Link view, which contains the following information. You can change these ﬁelds.

Interface

This ﬁeld displays the interface index for this VPI and VCI.

9032073 E2 Application Views

5-15

ATM Client Application ATM Client Application VCL View

VPI (Virtual Path Identiﬁer)

This ﬁeld displays the VPI value of the VCL. The maximum VPI value cannot exceed the value allowable by the Interface MaxVPI Bits.

VCI (Virtual Channel Identiﬁer)

This ﬁeld displays the VCI value of the VCL. The maximum VCI value cannot exceed the value allowable by the Interface MaxVCI Bits.

Admin Status

This object is implemented only for a VCL that terminates a VCC (i.e., one that is NOT cross-connected to other VCLs). Its value speciﬁes the desired administrative state of the VCL. The Up state indicates that the trafﬁc ﬂow is enabled for this VCL. The Down state indicates that the trafﬁc ﬂow is disabled for this VCL.

Oper Status

This object indicates the current operational status of the VCL. The Up and Down states indicate that the VCL is currently operational or not operational, respectively. The Unknown state indicates that the status of this VCL cannot be determined.

Row Status

• RTD Index

• XTD Index

• AAL Type (if the local VCL endpoint is also the VCC endpoint)

• Transmit Size (for AAL5 connections only)

• Receive Size (for AAL5 connections only)

• Encaps Type (for AAL5 connections only)

Encaps Type

This is the type of data encapsulation used over the AAL5 SSCS layer. An instance of this object only exists when the local VCL endpoint is also the VCC endpoint, and AAL5 is in use. The deﬁnitions reference RFC 1483 Multiprotocol Encapsulation over ATM AAL5 and to the ATM Forum LAN Emulation speciﬁcation.

AAL (ATM Adaptation Layer) Type

This is the type of AAL used on this VCC, which includes AAL1, AAL3/4, and AAL5. An instance of this object only exists when the local VCL endpoint is also the VCC endpoint, and AAL is in use. The other may be a user-deﬁned AAL type. The Unknown type indicates that the AAL type cannot be determined.

Last Change

The value of MIB II’s sysUpTime object at the time this VCL entered its current operational state. If the current state was entered prior to the last reinitialization of the agent, then this object contains a zero value.

Application Views Fast Ethernet SmartSwitch Module 5-16 Management Module Guide

Download Application View

Cross Connect Id

This object is implemented only for a VCL that is cross-connected to other VCLs that belong to the same VCC. All such associated VCLs have the same value of this object, and all their cross-connections are identiﬁed by entries in the Cross Connect Table for which VCL CC Id has the same value. The value of this object is initialized by the agent after the associated entries in the Cross Connect Table have been created.

Xmit Descr Index

The value of this object identiﬁes the row of the ATM Trafﬁc Descriptor Table that applies to the transmit direction of this VCL.

Transmit Size

An instance of this object only exists when the local VCL endpoint is also the VCC endpoint, and AAL5 is in use. The maximum AAL5 CPCS SDU size in octets that is supported on the transmit direction of this VCC.

Rcv Descr Index

The value of this object identiﬁes the row in the ATM Trafﬁc Descriptor Table that applies to the receive direction of this VCL.

Receive Size

An instance of this object only exists when the local VCL endpoint is also the VCC endpoint, and AAL5 is in use. The maximum AAL5 CPCS SDU size in octets that is supported on the receive direction of this VCC.

Download Application View

This application provides download functionality for this device. The model type for this application is CtDownLoadApp. Access the Download Application view as follows:

1. Within the Application view, highlight the CtDownLoadApp icon (Icon mode) or model type name (List mode).

2. From the View menu, select Icon Subviews -> Download Application.

The Download Application view is an SPMA view, which is described in the SPECTRUM Portable Management Application Tools Guide.

9032073 E2 Application Views

5-17

Download Application View

Application Views Fast Ethernet SmartSwitch Module 5-18 Management Module Guide

Index

Numerics

2E42-27 1-1 2E42-27R 1-1 2E43-27 1-1 2E43-27R 1-1 8H02-16 1-1

A_Port 3-8 Accessing

Device-Speciﬁc Subviews 1-5 SPECTRUM Views 1-2, 1-6

Address

Canonical 5-12 MAC 2-6, 3-4 Mac 3-7

Network 2-7 Administrative Status Label 2-4 Alarm

Link Error Rate 3-9 Alarm Messages 4-1 Application Label 2-13 Application View 5-1 ATM Client Application 5-13 ATM Client Application Subviews 5-13 Attribute Selected 2-8 Auto Negotiation 5-7

B_Port 3-8 Beacon 3-6 Bridging Application Interface Status 2-14

Canonical 5-12 Chassis Device View 2-1, 2-11

Bridging Icon Subviews Menu 2-13

FDDI Icon Subviews Menu 2-15

Interface Icon Subviews Menu 2-14, 2-15

Logical Port Icon Subview Menu 2-16 Chassis Manager Application View 5-4 Claim/Beacon Process 3-6 Community String Conﬁguration View 5-8 Component Table

Accessing 3-2

Button 3-2 Concentrator 5-12

Isolated 3-6 Conﬁguration Information 2-1 Conﬁguration View 5-13

FddiMAC Device 3-6 Conﬁguration Views 3-1

Device 3-1, 3-2

Port Conﬁguration CSIIfPort 3-1, 3-5 Conﬁguring Ports 5-7 Control Table

Advertised Ability 5-9

Operatonal Mode 5-7

Received Technology 5-10 CSIBridge 5-1 Ct_Stp_App 5-1 CtDownLoadApp 5-1 CtIfRemapApp 5-5 Current MAC Path 3-7

Default Button 2-10 Detect 3-6 Device Application View

Icon mode 5-2

List mode 5-2 Device Conﬁguration View 3-2

FddiMAC 3-6

Interface Conﬁguration Table 3-3 Device Views 2-1

Chassis 2-1, 2-11

Interface 2-1, 2-2

Physical 2-1 Directed 3-6 Documentation

Conventions x

9032073 E2

Organization ix DownLoad App 5-1 Download Application

Accessing 3-2

Button 3-2

View 5-17

Enable/Disable Port 2-16 Environmental Device View 2-11 Error

Monitor Count

Link 3-9

Monitor Reject Count

Link 3-9

Rate Alarm

Link 3-9

Rate Cutoff

Link 3-9

Rate Estimate

Link 3-9

Event Messages 4-1

Fast Ethernet Application 5-7 Fast Ethernet Conﬁguration View 5-7 Fast Ethernet Port Table 5-7 Fast Ethernet SmartSwitch Module 1-1 FastEnetApp 5-1 FDDI

Conﬁguration 2-15

FNB Application 5-11

Icon Subviews Menu 2-15

MAC

Device Conﬁguration View 3-6 Model Information 2-15 Node Class 5-12 Performance 2-15 Station List 2-15 Station List View 5-11

FddiMAC Device Conﬁguration 3-1 Filter 2-7

Gauge

Buttons 2-10

Control Panel 2-7 Label 2-7 Mode 2-10 Selected Attribute 2-10 Type 2-10

HDLC 2-5 HSIM-A5DP 5-1 HSIM-F6 5-1

ICMP_App 5-1 Icon Modiﬁcation 2-7 Interface

Bridging Application Status 2-14 Conﬁguration Table 3-3 Description 2-7 Icon, Device View 2-3 Monitoring 2-11 Options Panel 2-7 Status of 2-4

Type 2-5, 3-3 Interface Device View 2-1, 2-2 Interface Icon, Device View

Administrative Status Label 2-4

Gauge Label 2-7

Illustration 2-3

Interface Number label 2-4

Interface Type Label 2-5

MAC Address Label 2-6

Network Information Label 2-6 Interface Label 2-4, 2-14 Interface Number Label 2-4 Interface Options Panel 2-10 Interface Remap Application 5-5 Interface Remap Table

Destination 5-5

Max Number Entries 5-5

Number Entries 5-5

Physical Errors Enable 5-5

Port Redirect 5-6

Sort 5-5

Source Port 5-5 Interfaces View 5-13 IP Application 5-1

Index Fast Ethernet SmartSwitch Module 2 Management Module Guide

Keep Settings Button 2-10

Non-Op 3-6

Non-Op Dup 3-6

Notice i

Label and Double-Click Zones 2-3 Link Error Monitor

Count 3-9 Reject Count 3-9

Link Error Rate

Alarm 3-9 Cutoff 3-9 Estimate 3-9

Logical Port Labels 2-16

MAC

Address 3-7 Conﬁguration 3-7

Count 3-7 MAC Address Label 2-6 Mapping Interfaces 5-5 Mask

Network 2-7 Master 3-8
