Enterasys X-PEDITION E9.1.7.0, X-Pedition Series Release Notes

50 Minuteman Rd.
Andover, MA 01810
USA
Tel: [phone]

CUSTOMER RELEASE NOTES

X-Pedition Router

System Firmware Version E9.1.7.0

System Firmware Release Date: September 2003

INTRODUCTION:

This document provides specific information relevant to version E9.1.7.0 of the System Firmware for the X-Pedition
family of products. It includes content from the E9.0.7.7 System Firmware Maintenance Release and the E9.1.3.0A
patch release.

Enterasys Networks recommends that these Release Notes be thoroughly reviewed prior to the
installation or upgrade of this product.

GLOBAL SUPPORT:

Enterasys Networks Global Technical Assistance Center
By Phone: [phone]
By Email: [e-mail]
By Web: http://www.enterasys.com/support
By Fax: [phone]
By Mail: Enterasys Networks, Inc.

35 Industrial Way
P.O. Box 5005
Rochester, NH 03866-5005

For information regarding the latest firmware available, recent releases note revisions, or if you require additional
assistance, please visit the Enterasys Networks Support web site.

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 1 of 31

F0615-J

SYSTEM FIRMWARE SPECIFICATION

SYSTEM FIRMWARE SPECIFICATION:

Before installing the E9.1.7.0 System Firmware, the Boot Firmware should be upgraded to at least version
E3.2.0.0.

Refer to the E3.2.0.0 Boot Firmware Release Notes, or any X-Pedition Getting Started Guide, for
instructions on upgrading the Boot Firmware.

System Firmware File Name Version No. Release Date

xp9170 E9.1.7.0 September 2003
xp9078 E9.0.7.8 September 2003
xp9080 E9.0.8.0 July 2003
xp9077 E9.0.7.7 July 2003
xp9076 E9.0.7.6 June 2003
xp9075 E9.0.7.5 May 2003
xp9074 E9.0.7.4 March 2003
xp9130 E9.1.3.0 March 2003
xp9073 E9.0.7.3 February 2003
xp9120 E9.1.2.0 January 2003
xp9072 E9.0.7.2 January 2003
xp9100 E9.1.0.0 December 2002
xp9071 E9.0.7.1 December 2002
xp9070 E9.0.7.0 November 2002
xp9060a E9.0.6.0A October 2002
xp9050 E9.0.5.0 August 2002
xp9040 E9.0.4.0 July 2002
xp9030 E9.0.3.0 June 2002
xp9020 E9.0.2.0 April 2002
xp9010 E9.0.1.0 March 2002
xp9000 E9.0.0.0 December 2001
xp8300 E8.3.0.0 October 2001
xp8210 E8.2.1.0 September 2001
xp8200 E8.2.0.0 June 2001
ssr8100 E8.1.0.0 February 2001
ssr8010 E8.0.1.0 October 2000
ssr8000 E8.0.0.0 September 2000
ssr3200 3.2.0.0 May 2000
ssr3100 3.1.0.0 April 2000
ssr3010 3.0.1.0 March 2000
ssr3000 3.0.0.0 October 1999
ssr2220 2.2.2.0 September 1999
ssr2200 2.2.0.0 April 1999
ssr2100 2.1.0.0 December 1998
ssr2000 2.0.0.0 November 1998
ssr1200 1.2.0.0 September 1998
ssr1100 1.1.0.0 August 1998
ssr1010 1.0.1.0 June 1998
ssr1000 1.0.0.0 April 1998

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 2 of 31

F0615-J

RELEASE NAMING CONVENTION

RELEASE NAMING CONVENTION:

Normally, the X-Pedition product family supports two active release lines. The older line is always in maintenance
only mode and receives only maintenance improvements—the newer line receives maintenance improvements
and introduces new features. For a brief time, however, the X-Pedition will support a special third line—E9.0.8.
This line introduces the Security Attack Monitor (SAM) feature on the E9.0 code base. E9.0.8 is a maintenance
only line with end of maintenance scheduled for December 2003.

The new E9.0.8 line does not alter the maintenance only characteristics of the E9.0.7.X releases as no new
features including SAM will be introduced in this line. SAM will be incorporated into the normal development line
in release E9.1.8.0.

E9.0 is the maintenance only line to which only bug fixes are provided. E9.1 is the development line that receives
new features and bug fixes. The figure below illustrates the relationships between these lines. Support for E9.0 as
the maintenance only line and E9.1 as the development line will be extended briefly beyond that shown below to
permit the release of E9.1.8.0.

E9.0.8

Maintenance Only

August

2003

December

2003

Maintenance Only

E9.0

Except
E9.0.8

Development

Maintenance Only

E9.1

Development

Maintenance Only

E9.2

December

2002

EOD or “end of development” signifies the point at which no new features will be added to the release line. EOM
or “end of maintenance” signifies the point where bug fixes are no longer applied to the line.
The naming convention is as follows.

E<R1>.<R2>.<D>.<M>

Where:

R1 – Release line digit 1
R2 – Release line digit 2
D – A release during the development period
M – A release during the maintenance-only period

September

2003

June
2004

March

2005

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 3 of 31

F0615-J

RELEASE NAMING CONVENTION

A release line is defined by the first two digits in the name, e.g. E9.0 and E9.1. The third digit increments with
each release during the development phase of a line. For example, E9.0.7.0 is the seventh development release
for the E9.0 line. The fourth digit is incremented with each release during the maintenance-only period of a
release line. Thus E9.0.7.4 is the fourth maintenance-only release for the E9.0 line.

Should a bug fix be required between regularly scheduled releases, a patch release is provided. Patch releases
are designated with a trailing letter. For example, E9.0.6.0B is the second patch to the sixth development release
of the E9.0 line. E9.0.7.2A is the first patch to the second maintenance-only release of the E9.0 line.

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 4 of 31

F0615-J

HARDWARE / FIRMWARE COMPATIBILITY

HARDWARE / BOOT FIRMWARE/ SYSTEM FIRMWARE COMPATIBILITY:

The Minimum Boot Firmware Version is a function of:

• The hardware installed in the system (as listed below).

• The version of VFS used. For more information on VFS versions see the “PCMCIA Card VFS Version” sub-

section in the “INSTALLATION AND CONFIGURATION NOTES” section of the X-Pedition Boot Firmware
Release Notes.

• The need for new features or corrections that are provided in a specific version.
The issue of determining minimum Boot Firmware version can be avoided by installing version E3.2.0.0 (or later)

of the Boot Firmware.
NOTE: In some cases, the Minimum System Firmware Version depends upon the revision of a particular model

number. The revision number appears on the serial number sticker attached to the front of all Enterasys Networks
hardware assemblies. These numbers are interpreted as follows:

AAAA XXXX XXXX XXRR

Two Letter Assembly Revision Number
Four Digit “940” Assembly Number

Example:

3570 0000 0000 000A

This number is broken down as follows:

• Assembly number 9403570 (In this case, the SSR-POS21-04)

• The assembly has a revision number of “0A”

For the two SSR-PCMCIA part numbers listed below, sub-part numbers (e.g., 35-028-02) are also listed. Find the
sub-part number on the SSR-PCMCIA card. Match it with a sub-part number to aid in determining the minimum
System Firmware and Boot Firmware versions.

For detailed information on managing the Boot Firmware, please refer to version E3.2.0.0 (or later) of the
X-Pedition Boot Firmware Release Notes.

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 5 of 31

F0615-J

HARDWARE / FIRMWARE COMPATIBILITY

This version of System Firmware supports the X-Pedition Router hardware listed in the following table:

Minimum

Part Description

System
Firmware
Version

5SSRM-02 Router module for the Matrix E5 E8.0.1.0 1.1.0.8
6SSRLC-FX-AA 8-port 100BASE-FX (MT-RJ) module for 5SSRM-02 and 6SSRM-02 3.0.50.11
6SSRLC-LX-AA 2-port 1000BASE-LX module for 5SSRM-02 and 6SSRM-02 3.0.50.11
6SSRLC-LX70-AA 1-port 1000BASE-LX 70 KM module for 5SSRM-02 and 6SSRM-02 3.0.50.11
6SSRLC-SER-AA 2-port Serial module (No compression or encryption) for 5SSRM-02 and 6SSRM-02 3.0.50.11
6SSRLC-SERC-AA 4-port Serial module with compression (No encryption) for 5SSRM-02 and 6SSRM-02 3.0.50.11
6SSRLC-SERCE-AA 4-port Serial module with compression & encryption for 5SSRM-02 and 6SSRM-02 3.0.50.11
6SSRLC-SX-AA 2-port 1000BASE-SX module for 5SSRM-02 and 6SSRM-02 3.0.50.11
6SSRLC-TX-AA 8-port 1000BASE-TX module for 5SSRM-02 and 6SSRM-02 3.0.50.11
6SSRM-02 Router module for the Matrix E6 (SS6000) and Matrix E7 3.0.50.11 1.1.0.8
ER16-04 4-port 1000BASE GBIC module [T-Series] for ER16 E8.0.0.0
ER16-08 8-port 1000BASE GBIC module [T-Series] for ER16 E8.0.0.0
ER16-AC AC Power Supply for ER16 E8.0.0.0
ER16-ATM29-02 2-port ATM OC-3c base module [T-Series] for ER16 E8.3.0.0
ER16-CK Clock module for ER16 E8.0.0.0
ER16-CM3-128 Control Module 3 (291 MHz CPU) with 128MB for ER16 E8.0.0.0 E3.0.0.0
ER16-CM4-256 Control Module 4 (380 MHz CPU) with 256MB for ER16 E8.2.0.0 E3.1.0.0
ER16-CS X-Pedition ER16 Chassis with 16 slots. Includes ER16-CK, ER16-FN, and ER16-SF E8.0.0.0
ER16-DC DC Power Supply for ER16 E8.0.0.0
ER16-FDDI-02 2-port FDDI base module [T-Series] for ER16 E8.3.0.1
ER16-FN Fan Tray module for ER16 E8.0.0.0
ER16-GTX32-04 4-port 1000BASE-TX module for ER16 E9.0.0.0
ER16-GTX32-08 8-port 1000BASE-TX module for ER16 E9.0.0.0
ER16-HFX31-24 24-port 100BASE-FX module [T-Series] for ER16 (MMF) E8.3.0.0
ER16-HFX39-24 24-port 100BASE-FX module [T-Series] for ER16 (SMF) E8.3.0.0
ER16-HSSI-02-CK 2-port HSSI module for ER16 with external clocking E8.3.0.0
ER16-OS16-01 1-port 10-Gigabit Ethernet module for ER16 (1 slot configuration) E9.1.7.0 E3.2.0.0

ER16-OS26-01 1-port 10-Gigabit Ethernet module for ER16 (2 slot configuration) E9.1.0.0 E3.2.0.0

ER16-POS-21-04 4-port OC-3/STM-1 Packet over SONET/SDH MMF module [T-Series] ER16 E9.0.3.0

ER16-POS-29-04 4-port OC-3/STM-1 Packet over SONET/SDH SMF module [T-Series] for ER16 E9.0.3.0

ER16-POS-31-02 2-port OC-12/STM-4 Packet over SONET/SDH MMF module [T-Series] for ER16 E9.0.3.0

ER16-POS-39-02 2-port OC-12/STM-4 Packet over SONET/SDH SMF module [T-Series] for ER16 E9.0.3.0

ER16-SERC-04-AA 4-port Serial module with compression for X-Pedition ER16 E8.3.0.0
ER16-SERCE-04-A 4-port Serial module with compression and encryption for X-Pedition ER16 E8.3.0.0
ER16-SF Switching Fabric module for ER16 E8.0.0.0
ER16-SX-08 8-port 1000BASE-SX module [T-Series] for ER16 E8.0.0.0
ER16-TX-24 24-port 10/100BASE-TX module [T-Series] for ER16 E8.0.0.0
ER16-TX-32 32-port 10/100BASE-TX module [T-Series] for ER16 E8.0.0.0
SSR-16 X-Pedition 8600 Chassis with 16 slots. Comes with SSR-FAN-16 and SSR-SF-16. 1.2.0.0
SSR-2-B128 X-Pedition 2000 Chassis with 16-ports 10/100 TX ,128 MB memory, and 2 open slots 3.1.0.0 1.1.0.9
SSR-2-FX 8-port 100BASEFX (MT-RJ) module for X-Pedition 2000 2.1.0.1
SSR-2-FX-AA 8-port 100BASEFX (MT-RJ) module for X-Pedition 2000 3.0.0.0
SSR-2-GSX X-Pedition 2100 Chassis with 8-ports 1000BASE-SX and 64MB Memory 2.2.0.1 1.1.0.5
SSR-2-HSSI-AA 2-port HSSI module for X-Pedition 2000 E8.0.0.0
SSR-2-LX 2-port 1000BASE-LX module for X-Pedition 2000 1.2.0.0
SSR-2-LX-AA 2-port 1000BASE-LX module for X-Pedition 2000 3.0.0.0

Minimum
Boot
Firmware
Version

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 6 of 31

F0615-J

HARDWARE / FIRMWARE COMPATIBILITY

Minimum

Part Description

System
Firmware
Version

SSR-2-LX70 1-port 70 km 1000BASE-LX module for X-Pedition 2000 2.0.0.0
SSR-2-LX70-AA 1-port 70 km 1000BASE-LX module for X-Pedition 2000 3.0.0.0
SSR-2-SER 2-port Serial module (No compression or encryption) for X-Pedition 2000 2.1.0.0
SSR-2-SER-AA 2-port Serial module (No compression or encryption) for X-Pedition 2000 3.0.0.0
SSR-2-SERC 4-port Serial module with compression (No encryption) for X-Pedition 2000 2.1.0.0
SSR-2-SERC-AA 4-port Serial module with compression (No encryption) for X-Pedition 2000 3.0.0.0
SSR-2-SERCE 4-port Serial module with compression and encryption for X-Pedition 2000 2.1.0.0
SSR-2-SERCE-AA 4-port Serial module with compression and encryption for X-Pedition 2000 3.0.0.0
SSR-2-SX 2-port 1000BASE-SX module for X-Pedition 2000 1.2.0.0
SSR-2-SX-AA 2-port 1000BASE-SX module for X-Pedition 2000 3.0.0.0
SSR-2-TX 8-port 10/100 TX module for X-Pedition 2000 1.2.0.0
SSR-2-TX-AA 8-port 10/100 TX module for X-Pedition 2000 3.0.0.0
SSR-8 X-Pedition 8000 Chassis with 8 slots. Comes with SSR-FAN-8. 1.0.0.0
SSR-ARE Advanced Routing Engine (currently supports AppleTalk) for X-Pedition 8000/8600 E8.1.0.0
SSR-ATM29-02 2-port ATM OC-3c base module [T-Series] for X-Pedition 8000/8600 3.1.0.0
SSR-CM2-128 Control Module 2 (198 MHz CPU) with 128 MB memory for X-Pedition 8000/8600 1.1.0.0 1.1.0.2
SSR-CM2-64 Control Module 2 (198 MHz CPU) with 64 MB memory for X-Pedition 8000/8600 1.1.0.0 1.1.0.2
SSR-CM2B-64 Control Module 2 (198 MHz CPU) with 64 MB memory for X-Pedition 8000/8600 E9.0.0.0 E3.2.0.0
SSR-CM3-128 Control Module 3 (291 MHz CPU) with 128MB memory for X-Pedition 8000/8600 E8.0.0.0 E3.0.0.0
SSR-CM4-256 Control Module 4 (375/380 Mhz CPU) with 256MB memory for X-Pedition 8000/8600 E8.2.0.0 E3.1.0.0
SSR-FAN-16 Fan Tray module for X-Pedition 8600 1.0.0.0
SSR-FAN-8 Fan Tray module for X-Pedition 8000 1.0.0.0
SSR-FDDI-02 2-port FDDI base module [T-Series] for X-Pedition 8000/8600 3.2.0.0
SSR-GLH39-02 2-port 1000 LLX / LH module (SCLX for SMF) [T-Series] for X-Pedition 8000/8600 3.1.0.0
SSR-GLX19-02 2-port 1000 LX module (SCLX for MMF or SMF) with 4 MB for X-Pedition 8000/8600 1.0.0.0
SSR-GLX29-02 2-port 1000 LX module (SCLX for MMF or SMF) with 16 MB for X-Pedition 8000/8600 1.0.0.0
SSR-GLX29-02-AA 2-port 1000 LX module (SCLX for MMF or SMF) with 16 MB for X-Pedition 8000/8600 3.0.0.0
SSR-GLX39-02 2-port 1000 LX module (SCLX for MMF or SMF) [T-Series] for X-Pedition 8000/8600 3.1.0.0
SSR-GLX39-04 4-port 1000 LX module (SCLX for MMF or SMF) [T-Series] for X-Pedition 8000/8600 E8.3.0.0
SSR-GLX70-01 1-port 70 Km 1000BASE-LX module with 16 MB for X-Pedition 8000/8600 2.0.0.0
SSR-GLX70-01-AA 1-port 70 Km 1000BASE-LX module with 16 MB for X-Pedition 8000/8600 3.0.0.0
SSR-GSX11-02 2-port 1000 SX module (SCSX for MMF Only) with 4 MB for X-Pedition 8000/8600 1.0.0.0
SSR-GSX21-02 2-port 1000 SX module (SCSX for MMF Only) with 16 MB for X-Pedition 8000/8600 1.0.0.0
SSR-GSX21-02-AA 2-port 1000 SX module (SCSX for MMF Only) with 16 MB for X-Pedition 8000/8600 3.0.0.0
SSR-GSX31-02 2-port 1000 SX module (SCSX for MMF Only) [T-Series] for X-Pedition 8000/8600 3.1.0.0
SSR-GSX31-04 4-port 1000 SX module (SCSX for MMF Only) [T-Series] for X-Pedition 8000/8600 E8.3.0.0
SSR-GTX32-02 2-port 1000 TX module (Cat 5 RJ-45) [T-Series] for X-Pedition 8000/8600 3.1.0.0
SSR-GTX32-04 4-port 1000 TX module (Cat 5 RJ-45) [T-Series] for X-Pedition 8000/8600 E9.0.0.0
SSR-HFX11-08 8-port 100 FX module (MMF SC) with 4 MB for X-Pedition 8000/8600 1.0.0.0
SSR-HFX21-08 8-port 100BASE-FX module (MMF SC) with 16 MB for X-Pedition 8000/8600 1.0.0.0
SSR-HFX21-08-AA 8-port 100BASE-FX module (MMF SC) with 16 MB for X-Pedition 8000/8600 3.0.0.0
SSR-HFX29-08 8-port 100BASE-FX SMF module with 16 MB for X-Pedition 8000/8600 2.0.0.0
SSR-HFX29-08-AA 8-port 100BASE-FX SMF module with 16 MB for X-Pedition 8000/8600 2.0.0.0
SSR-HSSI-02 2-port HSSI module for X-Pedition 8000/8600 2.1.0.0
SSR-HSSI-02-AA 2-port HSSI module for X-Pedition 8000/8600 3.0.0.0
SSR-HSSI-02-CK 2-port HSSI module for X-Pedition 8000/8600 with external clocking E8.3.0.0
SSR-HTX12-08 8-port 10/100 TX module (Cat 5 RJ-45) with 4 MB for X-Pedition 8000/8600 1.0.0.0
SSR-HTX12-08-AA 8-port 10/100 TX module (Cat 5 RJ-45) with 4 MB for X-Pedition 8000/8600 3.0.0.0
SSR-HTX22-08 8-port 10/100 TX module (Cat 5 RJ-45) with 16 MB for X-Pedition 8000/8600 1.0.1.0
SSR-HTX22-08-AA 8-port 10/100 TX module (Cat 5 RJ-45) with 16 MB for X-Pedition 8000/8600 3.0.0.0

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 7 of 31

F0615-J

Minimum
Boot
Firmware
Version

HARDWARE / FIRMWARE COMPATIBILITY

Minimum

Part Description

System
Firmware
Version

SSR-HTX32-16 16-port 10/100 TX module (Cat 5 RJ-45) with 16 MB [T-Series] for X-Pedition

SSR-MEM-128 128MB Memory Upgrade Kit for SSR-CM2-64, SSR-CM2-128, SSR-CM3-128, and

SSR-MEM-256 256MB ECC Memory Upgrade Kit for SSR-CM4-256 and ER16-CM4-256 E9.0.7.4 or

SSR-PCMCIA
35-028-01
35-053-01
35-053-02
35-053-03
37-002-01
SSR-PCMCIA
35-028-02
35-053-04
37-010-01

SSR-POS21-04 4-port OC-3/STM-1 Packet over SONET/SDH MMF module [T-Series] for X-Pedition

SSR-POS21-04
Assy 3570 Rev0A+

SSR-POS29-04 4-port OC-3/STM-1 Packet over SONET/SDH SMF module [T-Series] for X-Pedition

SSR-POS29-04
Assy 3569 Rev0A+

SSR-POS31-02 2-port OC-12/STM-4 Packet over SONET/SDH MMF module [T-Series] for X-Pedition

SSR-POS31-02
Assy 3568 Rev0A+

SSR-POS39-02 2-port OC-12/STM-4 Packet over SONET/SDH SMF module [T-Series] for X-Pedition

SSR-POS39-02
Assy 3567 Rev0A+

SSR-PS-16 AC Power Supply module for X-Pedition 8600 1.0.0.0
SSR-PS-16-DC DC Power Supply module for X-Pedition 8600 1.0.0.0
SSR-PS-8 AC Power Supply module for X-Pedition 8000 1.0.0.0
SSR-PS-8-DC DC Power Supply module for X-Pedition 8000 1.0.0.0
SSR-SERC-04 4-port Serial module with compression for X-Pedition 8000/8600 2.1.0.0
SSR-SERC-04-AA 4-port Serial module with compression for X-Pedition 8000/8600 3.0.0.0
SSR-SERCE-04 4-port Serial module with compression and encryption for X-Pedition 8000/8600 2.1.0.0
SSR-SERCE-04-AA 4-port Serial module with compression and encryption for X-Pedition 8000/8600 3.0.0.0
SSR-SF-16 Switching Fabric module for X-Pedition 8600 1.2.0.0
XP-2100 X-Pedition 2100 Chassis with 8-ports 1000BASE-SX, 64MB Memory E9.0.1.0 E3.2.0.0
XP-2400 X-Pedition 2400 Chassis with 16-ports 10/100 TX, 128MB expandable memory, and 2

XP-2400-256 X-Pedition 2400 Chassis with 16-ports 10/100 TX, 256MB memory, and 2 card slots. E9.0.0.0 E3.2.0.0
XP-2400-DC X-Pedition 2400 Chassis with 16-ports 10/100 TX, 128MB expandable memory, and 2

XP-2-ATM29-02 2-port ATM OC-3c base module [T-Series] for X-Pedition 2400 E9.0.0.0
XP-2-FX-AA 8-port 100BASEFX (MT-RJ) module for X-Pedition 2400 E9.0.0.0
XP-2-HSSI-CK 2-port HSSI module for X-Pedition 2400 E9.0.0.0
XP-2-LX-AA 2-port 1000BASE-LX module for X-Pedition 2400 E9.0.0.0

8000/8600

ER16-CM3-128

8MB PCMCIA card for SSR-CM2-64, SSR-CM2-128, SSR-CM3-128, SSR-CM4-256,
ER16-CM3-128, and ER16-CM4-256

8MB PCMCIA card for SSR-CM2-64, SSR-CM2-128, SSR-CM3-128, SSR-CM4-256,
ER16-CM3-128, and ER16-CM4-256

8000/8600
4-port OC-3/STM-1 Packet over SONET/SDH MMF module [T-Series] for X-Pedition

8000/8600

8000/8600
4-port OC-3/STM-1 Packet over SONET/SDH SMF module [T-Series] for X-Pedition

8000/8600

8000/8600
2-port OC-12/STM-4 Packet over SONET/SDH MMF module [T-Series] for X-Pedition

8000/8600

8000/8600
2-port OC-12/STM-4 Packet over SONET/SDH SMF module [T-Series] for X-Pedition

8000/8600

card slots.

card slots; DC-powered

3.1.0.0

1.1.0.0 1.1.0.2

E9.1.3.0

1.0.0.0 1.0.0.0

3.0.1.6,

3.0.1.7,

3.1.0.8
and up
excluding

3.2.0.0

3.1.0.0

E9.0.0.1

3.1.0.0

E9.0.0.1

3.1.0.0

E9.0.0.1

3.1.0.0

E9.0.0.1

E9.0.0.0 E3.2.0.0

E9.0.0.0 E3.2.0.0

Minimum
Boot
Firmware
Version

E3.3.0.0

E3.0.0.0

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 8 of 31

F0615-J

HARDWARE / FIRMWARE COMPATIBILITY

Minimum

Part Description

System
Firmware
Version

XP-2-LX70-AA 1-port 70 km 1000BASE-LX module for X-Pedition 2400 E9.0.0.0
XP-2-SER-AA 2-port Serial module (No compression or encryption) for X-Pedition 2400 E9.0.0.0
XP-2-SERC-AA 4-port Serial module with compression (No encryption) for X-Pedition 2400 E9.0.0.0
XP-2-SERCE-AA 4-port Serial module with compression and encryption for X-Pedition 2400 E9.0.0.0
XP-2-SX-AA 2-port 1000BASE-SX module for X-Pedition 2400 E9.0.0.0
XP-2-TX-AA 8-port 10/100 TX module for X-Pedition 2400 E9.0.0.0
XP-PCMCIA-16AT 16MB ATA PCMCIA card for SSR-CM2-64, SSR-CM2-128, SSR-CM3-128, SSR-

CM4-256, ER16-CM3-128, and ER16-CM4-256

XP-PCMCIA-32AT 32MB ATA PCMCIA card for SSR-CM2-64, SSR-CM2-128, SSR-CM3-128, SSR-

CM4-256, ER16-CM3-128, and ER16-CM4-256

XP-PCMCIA-16LN 16MB PCMCIA card for SSR-CM2-64, SSR-CM2-128, SSR-CM3-128, SSR-CM4-

256, ER16-CM3-128, and ER16-CM4-256

E8.2.0.0 E3.1.0.0

E8.2.0.0 E3.1.0.0

3.0.1.6,

3.0.1.7,

3.1.0.8
and up,

excluding

3.2.0.0

The following table lists hardware not supported in this System Firmware release. The last System Firmware
release to support this hardware was series 3.0.X.X.

Part Description

SSR-2-B SSR2000 with 32 MB
SSR-2-B-AA SSR2000 with 32 MB
SSR-CM-128 Control Module 1 with 128 MB memory for SSR8000 and SSR8600
SSR-CM-64 Control Module 1 with 64 MB memory for SSR8000 and SSR8600

Minimum
Boot
Firmware
Version

E3.0.0.0

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 9 of 31

F0615-J

HARDWARE / FIRMWARE COMPATIBILITY

The following table lists supported hardware that is System Firmware and Boot Firmware version independent.

Part Description

APHY-21 SSR-ATM29-02 1 port OC-3 MMF Physical Interface Module
APHY-22 SSR-ATM29-02 1 port OC-3 UTP Physical Interface Module
APHY-29IR SSR-ATM29-02 1 port OC-3 SMF-IR Physical Interface Module
APHY-67 SSR-ATM29-02 1 port DS-3/T3 Physical Interface Module (Coax)
APHY-77 SSR-ATM29-02 1 port E-3 Physical Interface Module (Coax)
APHY-82 SSR-ATM29-02 1 port T-1 Physical Interface Module (UTP)
APHY-92 SSR-ATM29-02 1 port E-1 Physical Interface Module (UTP)
FPHY-01 SSR-FDDI-02 MMF DAS/SAS with SC connectors
FPHY-02 SSR-FDDI-02 UTP SAS with RJ-45 connector
FPHY-09 SSR-FDDI-02 SMF DAS/SAS with SC connectors
XP-APHY-21 ER16-ATM29-02/XP-2-ATM29-02 1 port OC-3 MMF Physical Interface Module
XP-APHY-22 ER16-ATM29-02/XP-2-ATM29-02 1 port OC-3 UTP Physical Interface Module
XP-APHY-29IR ER16-ATM29-02/XP-2-ATM29-02 1 port OC-3 SMF-IR Physical Interface Module
XP-APHY-67 ER16-ATM29-02/XP-2-ATM29-02 1 port DS-3/T3 Physical Interface Module (Coax)
XP-APHY-77 ER16-ATM29-02/XP-2-ATM29-02 1 port E-3 Physical Interface Module (Coax)
XP-APHY-82V ER16-ATM29-02/XP-2-ATM29-02 1 port T-1 Physical Interface Module (UTP) with

over current/voltage protection.

XP-APHY-92V ER16-ATM29-02/XP-2-ATM29-02 1 port E-1 Physical Interface Module (UTP) with

over current/voltage protection.
XP-FPHY-01 ER16-FDDI-02 MMF DAS/SAS with SC connectors
XP-FPHY-02 ER16-FDDI-02 UTP SAS with RJ-45 connector
XP-FPHY-09 ER16-FDDI-02 SMF DAS/SAS with SC connectors
GPIM-01 ER16 Gigabit Ethernet Physical Interface Module, 1000BASESX
GPIM-08 ER16 Gigabit Ethernet Physical Interface Module, Long Haul (70Km)
GPIM-09 ER16 Gigabit Ethernet Physical Interface Module, 1000BASELX
SSR-2-RACKMOUNT Rack Mount Kit for X-Pedition 2000 and X-Pedition 2100
SSR-449DTE-02 4 meter 2 lead cable with 2 male RS449 DTE (male) connectors
SSR-530DTE-02 4 meter 2 lead cable with 2 male RS530 (male) connectors
SSR-HSSI-CAB 3 meter HSSI cable, male to male connector
SSR-V35-DTE-02 4 meter 2 lead cable with 2 male V35 DTE (male) connectors
SSR-X21DTE-02 4 meter 2 lead cable and 2 make X21 DTE (male) connectors

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 10 of 31

F0615-J

g
g

g
p

p

HARDWARE REQUIREMENTS

HARDWARE REQUIREMENTS TABLE:

NOTE: X-Pedition line card hardware makes use of three basic ASIC versions (pre AA-series, AA-series and T-

series). The features supported by each line card are roughly defined by which series of ASIC hardware
is used on that card.

The following table shows the hardware supporting specific features in this release:

Pre
AA

AA – Series T – Series

X-Pedition
Feature Set /
Part Number

5SSRM-02

5SSRM-02 Router Module for the Matrix E5 X X X X X X X X X X

6SSRM-02

6SSRM-02

5SSRM-02 /

6SSRM-02

6SSRLC-FX-AA 8-port 100BASE-FX (MT-RJ) X X X X X X X X X X
6SSRLC-LX-AA 2-port 1000BASE-LX X X X X X X X X X X
6SSRLC-LX70-AA 1-port 1000BASE-LX 70 KM X X X X X X X X X X
6SSRLC-SER-AA 2-port Serial X X X X X X X X X X
6SSRLC-SERC-AA 4-port Serial, compression X X X X X X X X X X

6SSRLC-SERCE-AA

6SSRLC-SX-AA 2-port 1000BASE-SX X X X X X X X X X X
6SSRLC-TX-AA 8-port 10/100BASE-TX X X X X X X X X X X

XP 2000

SSR-2-B128 X-Pedition 2000 X X X X X X X X X X
SSR-2-FX 8-port 100BASEFX X
SSR-2-FX-AA 8-port 100BASEFX X X X X X X X X X X
SSR-2-HSSI-AA 2-port HSSI X X X X X X X X X X
SSR-2-LX 2-port 1000BASE-LX
SSR-2-LX-AA 2-port 1000BASE-LX X X X X X X X X X
SSR-2-LX70 1-port 70 km 1000BASE-LX
SSR-2-LX70-AA 1-port 70 km 1000BASE-LX X X X X X X X X X
SSR-2-SER 2-port Serial X
SSR-2-SER-AA 2-port Serial X X X X X X X X X X
SSR-2-SERC 4-port Serial, compression X
SSR-2-SERC-AA 4-port Serial, compression X X X X X X X X X X

SSR-2-SERCE

SSR-2-SERCE-AA

SSR-2-SX 2-port 1000BASE-SX
SSR-2-SX-AA 2-port 1000BASE-SX X X X X X X X X X
SSR-2-TX 8-port 10/100 TX X
SSR-2-TX-AA 8-port 10/100 TX X X X X X X X X X X

XP 2100
SSR-2-GSX (AA) X-Pedition 2100 X X X X X X X X X
XP-2100 X-Pedition 2100 X X X X X X X X X

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 11 of 31

F0615-J

Router Module for the Matrix E6 &
E7

4-port Serial, compression &
encryption

4-port Serial, compression &
encryption
4-port Serial, compression &
encryption

Description

Weighted Fair Queuing

Network Address

X X X X X X X X X X

X X X X X X X X X X

X

X X X X X X X X X X

Per Flow Rate Limitin

Translation

Server Load Balancin

Flow Aggregate Rate

Limitin

Per Protocol VLAN

Established Bit ACL

TOS Rewrite

sulation

Layer 4 Bridging

Multiple IPX

Enca

Per Port Rate Limiting

Aggregate Rate Limiting

Jumbo Frame Support

Weighted Fair Queuing

Weighted Random Early

Detection

lication

802.1Q Multicast Port

Re

g
g

g
p

p

HARDWARE REQUIREMENTS

Pre
AA

AA – Series T – Series

X-Pedition
Feature Set /
Part Number

XP 2400

XP-2400 X-Pedition 2400 X X X X X X X X X X
XP-2-ATM29-02 2-port ATM OC-3 X X X X X X X X X X X X X X X
XP-2-FX-AA 8-port 100BASEFX X X X X X X X X X X
XP-2-HSSI-AA 2-port HSSI X X X X X X X X X X
XP-2-LX-AA 2-port 1000BASE-LX X X X X X X X X X
XP-2-LX70-AA 1-port 70 km 1000BASE-LX X X X X X X X X X
XP-2-SER-AA 2-port Serial X X X X X X X X X X
XP-2-SERC-AA 4-port Serial, compression X X X X X X X X X X

XP-2-SERCE-AA

XP-2-SX-AA 2-port 1000BASE-SX X X X X X X X X X
XP-2-TX-AA 8-port 10/100 TX X X X X X X X X X X

XP 8000 / 8600
SSR-ARE Advanced Routing Engine
SSR-ATM29-02 2-port ATM OC-3 X X X X X X X X X X X X X X X
SSR-FDDI-02 2-port FDDI X X X X X X X X X X X 1 X X X
SSR-GLH39-02 2-port 1000 LLX/LH X X X X X X X X X X X X X X X
SSR-GLX19-02 2-port 1000 LX – 4 MB
SSR-GLX29-02 2-port 1000 LX – 16 MB
SSR-GLX29-02-AA 2-port 1000 LX – 16 MB X X X X X X X X X
SSR-GLX39-02 2-port 1000 LX X X X X X X X X X X X X X X X
SSR-GLX39-04 4-port 1000 LX X X X X X X X X X X X X X X X
SSR-GLX70-01 1-port 70 km 1000BASE-LX
SSR-GLX70-01-AA 1-port 70 km 1000BASE-LX X X X X X X X X X
SSR-GSX11-02 2-port 1000 SX – 4 MB
SSR-GSX21-02 2-port 1000 SX – 16 MB
SSR-GSX21-02-AA 2-port 1000 SX – 16 MB X X X X X X X X X
SSR-GSX31-02 2-port 1000 SX X X X X X X X X X X X X X X X
SSR-GSX31-04 4-port 1000 SX X X X X X X X X X X X X X X X
SSR-GTX32-02 2-port 1000 TX X X X X X X X X X X X X X X X
SSR-GTX32-04 4-port 1000 TX X X X X X X X X X X X X X X X
SSR-HFX11-08 8-port 100BASE-FX – 4 MB X
SSR-HFX21-08 8-port 100BASE-FX – 16 MB X
SSR-HFX21-08-AA 8-port 100BASE-FX – 16 MB X X X X X X X X X X
SSR-HFX29-08 8-port 100BASE-FX SMF X
SSR-HFX29-08-AA 8-port 100BASE-FX SMF X X X X X X X X X X
SSR-HSSI-02 2-port HSSI X
SSR-HSSI-02-AA 2-port HSSI X X X X X X X X X X
SSR-HSSI-02-CK 2-port HSSI with external clocking X X X X X X X X X X
SSR-HTX12-08 8-port 10/100 TX – 4 MB X
SSR-HTX12-08-AA 8-port 10/100 TX – 4 MB X X X X X X X X X X
SSR-HTX22-08 8-port 10/100 TX – 16 MB X
SSR-HTX22-08-AA 8-port 10/100 TX – 16 MB X X X X X X X X X X
SSR-HTX32-16 16-port 10/100 TX – 16 MB X X X X X X X X X X X X X
SSR-POS21-04 4-port OC-3/STM-1 POS MMF X X X X X X X X X X X X X X X
SSR-POS29-04 4-port OC-3/STM-1 POS SMF X X X X X X X X X X X X X X X
SSR-POS31-02 2-port OC-12/STM-4 POS MMF X X X X X X X X X X X X X X X
SSR-POS39-02 2-port OC-12/STM-4 POS SMF X X X X X X X X X X X X X X X

SSR-SERC-04 4-port Serial, compression X
SSR-SERC-04-AA 4-port Serial, compression X X X X X X X X X X

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 12 of 31

F0615-J

4-port Serial, compression &
encryption

Description

Weighted Fair Queuing

Network Address

X X X X X X X X X X

Per Flow Rate Limitin

Translation

Server Load Balancin

Flow Aggregate Rate

Limitin

Per Protocol VLAN

Established Bit ACL

TOS Rewrite

sulation

Layer 4 Bridging

Multiple IPX

Enca

Per Port Rate Limiting

Aggregate Rate Limiting

Jumbo Frame Support

Weighted Fair Queuing

Weighted Random Early

Detection

lication

802.1Q Multicast Port

Re

g
g

g
p

p

HARDWARE REQUIREMENTS

Pre
AA

AA – Series T – Series

X-Pedition
Feature Set /
Part Number

SSR-SERCE-04

SSR-SERCE-04-AA

ER16
ER16-04 4-port 1000BASE GBIC X X X X X X X X X X X X X X X
ER16-08 8-port 1000BASE GBIC X X X X X X X X X X X X X X X
ER16-ATM29-02 2-port ATM OC3 X X X X X X X X X X X X X X X
ER16-FDDI-02 2-port FDDI X X X X X X X X X X X 1 X X X
ER16-GTX32-04 4-port 1000BASE-TX X X X X X X X X X X X X X X X
ER16-GTX32-08 8-port 1000BASE-TX X X X X X X X X X X X X X X X
ER16-HFX31-24 24-port 100BASE-FX (MMF) X X X X X X X X X X X X X X
ER16-HFX39-24 24-port 100BASE-FX (SMF) X X X X X X X X X X X X X X
ER16-HSSI-02-CK 2-port HSSI with external clocking X X X X X X X X X X

ER16-OS16-01 1-port 10-Gigabit Ethernet module

ER16-OS26-01 1-port 10-Gigabit Ethernet module

ER16-POS-21-04 4-port OC-3/STM-1 Packet over

ER16-POS-29-04 4-port OC-3/STM-1 Packet over

ER16-POS-31-02 2-port OC-12/STM-4 Packet over

ER16-POS-39-02 2-port OC-12/STM-4 Packet over

ER16-SERC-04-AA 4-port Serial, compression X X X X X X X X X X

ER16-SERCE-04-A

ER16-SX-08 8-port 1000BASE-SX X X X X X X X X X X X X X X X
ER16-TX-24 24-port 10/100BASE-TX X X X X X X X X X X X X X X
ER16-TX-32 32-port 10/100BASE-TX X X X X X X X X X X X X X X

1

SSR-FDDI-02 jumbo frame support is limited to 4500 bytes.

2

The ER16-OS16-01 and ER16-OS26-01 perform aggregate rate limiting in firmware only.

4-port Serial, compression &
encryption
4-port Serial, compression &
encryption

for ER16 (1 slot configuration)

for ER16 (2 slot configuration)

SONET/SDH MMF module [T­Series] for ER16

SONET/SDH SMF module [T-Series]
for ER16

SONET/SDH MMF module [T­Series] for ER16

SONET/SDH SMF module [T-Series]
for ER16

4-port Serial, compression &
encryption

Description

Weighted Fair Queuing

Network Address

X

X X X X X X X X X X

X X X X X X X X X X X 2 X X X X

X X X X X X X X X X X 2 X X X X

X X X X X X X X X X X X X X X

X X X X X X X X X X X X X X X

X X X X X X X X X X X X X X X

X X X X X X X X X X X X X X X

X X X X X X X X X X

Per Flow Rate Limitin

Translation

Server Load Balancin

Flow Aggregate Rate

Limitin

Per Protocol VLAN

Established Bit ACL

TOS Rewrite

sulation

Layer 4 Bridging

Multiple IPX

Enca

Per Port Rate Limiting

Aggregate Rate Limiting

Jumbo Frame Support

Weighted Fair Queuing

Weighted Random Early

Detection

802.1Q Multicast Port

lication

Re

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 13 of 31

F0615-J

NETWORK MANAGEMENT SOFTWARE SUPPORT

NETWORK MANAGEMENT SOFTWARE SUPPORT:

The following table displays information on the Network Management Software that supports this release:

NMS Platform Version Part Number

NetSight Element Manager 3.1 NS-EM-CD

NS-EM-LIC-1
NS-EM-LIC-5
NS-EM-LIC-10
NS-EM-LIC-20

NetSight Atlas Console 1.2 NSA-CD

NSA-LIC

NetSight Atlas Console Lite 1.2 NSA-L-CD

NSA-L-LIC

NetSight Atlas Inventory Manager 1.3 NSA-IM-CD

NSA-IM-LIC

NetSight Atlas Router Services Manager 2.0 NSA-RSM-CD

NSA-RSM-LIC

NOTE: Network Management Software may not utilize the latest features in the System Firmware. Enterasys
Networks recommends reviewing the release notes included with the user’s specific Network Management
Platform for more information.

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 14 of 31

F0615-J

INSTALLATION AND CONFIGURATION NOTES

INSTALLATION AND CONFIGURATION NOTES:

Password Recovery

If an X-Pedition password is lost and the user is unable to log in or enter Enable mode, please refer to the
Enterasys Global Knowledgebase at http://knowledgebase.enterasys.com/esupport/
enter TK0306-9.

. Click Search by ID and

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 15 of 31

F0615-J

NEW FEATURES AND ENHANCEMENTS IN E9.1.7.0:

NEW FIRMWARE SUPPORT

The E9.1.7.0 system firmware provides support for the new features and enhancements below. For more
information on any of these enhancements, please see the Enterasys X-Pedition User Reference Manual or
Native CLI Reference Manual.

10-Gig Support of Link Aggregation

SmartTRUNK no protocol link aggregation is now supported on 10-Gig interface modules (ER16-OS26-01 and
ER16-OS16-01). This capability permits users to aggregate two or more 10-Gig interfaces and removes the
restriction previously identified as F3493. No support for DEC Hunt Group or 802.3ad (LACP) is provided at this
time although 10-Gig compatibility with 802.3ad is planned for a subsequent release.

PIM-SM Support of 802.1Q trunks

Compatibility between PIM-SM multicast routing and 802.1Q trunks is now provided allowing users to utilize PIM­SM multicast capabilities on interfaces with 802.1Q tagged packets.

AppleTalk Features

Two new AppleTalk capabilities are introduced with this release: QoS and CPU utilization.

All ingress and egress AppleTalk traffic is normally passed through the system on the low priority queue. Using a
CLI command, one can now specify which of the four X-Pedition queues (control, high, medium or low) will carry
AppleTalk egress traffic thus providing a measure of outbound QoS control.

Introduced in this release is an informational error message that is generated when the CPU utilization of the
Advanced Routing Engine (ARE), which supports AppleTalk data forwarding, exceeds 95% for one minute.

File Delete Command Enhancement

For ER16 or 8x00 systems configured with two control modules, users may now delete files from the backup
control module using the file delete command.

Display of Host Name in Syslog Messages

Introduced in this release is an improvement to Syslog message output that includes the host name. The
message format is <###> Mmm dd hh:mm:ss HOSTNAME MESSAGE where:

Mmm dd – month and day
hh:mm:ss – hour:minute:second
HOSTNAME – the name of the host machine
MESSAGE – the actual message

NEW FEATURES AND ENHANCEMENTS IN E9.1.7.0

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 16 of 31

F0615-J

NEW FEATURES AND ENHANCEMENTS IN E9.1.7.0

Display of the System FPGA Revision

A capability has been added that permits the display of the system FPGA revision number as illustrated in the
example below.

SYSTEM# system show hardware
Hardware Information :

System type : ER16, Rev. 0
CPU Module type : CPU-ER16 (CM4), Rev. 0
Processor : R7000, Rev 3.2, 380.00 MHz

Icache size : 16 Kbytes, 32 bytes/line

Dcache size : 16 Kbytes, 32 bytes/line
CPU Board frequency : 95.00 MHz
Backplane frequency : 62.50 MHz

System FPGA : Rev. 20 Å New Line

Switching Fabrics : 1 (Active = Fabric 2)
PCMCIA card : 32MB flash memory card (mounted on slot0: or slot1:)
System Memory size : 256 Mbytes
Network Memory size : 256 Mbytes
MAC Addresses

System : 0001f4:c2ff6d

10Base-T CPU Port : 0001f4:c2ff6e

Internal Use : 0001f4:c2ff6f -> 0001f4:c2ffac
CPU Mode : Active
Redundant CPU slot : Not present

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 17 of 31

F0615-J

NEW HARDWARE SUPPORT

10-Gigabit Ethernet (ER16-OS16-01)

This release introduces support for the ER16-OS16-01, an optical fiber-based 10-Gigabit Ethernet module for the
ER16 platform. This one slot card provides a single modular port of IEEE 802.3ae standards-based connectivity
and its optical interfaces are based on fully compliant IEEE 802.3ae SC duplex fiber-optic connectors. Supported
interfaces include the following:

Part Number Connectivity Description Maximum Length

10GBASE-ER Single port 1550 nm serial SMF 40 km
10GBASE-LR Single port 1310 nm serial SMF 10 km

NEW FEATURES AND ENHANCEMENTS IN E9.1.7.0

10GBASE-LX4 Single port 1310 nm serial SMF

Single port 1310 nm serial MMF

10GBASE-SR Single port 850 nm serial MMF 300 m

10 km
300 m

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 18 of 31

F0615-J

ISSUES RESOLVED IN E9.1.7.0

ISSUES RESOLVED IN E9.1.7.0:

The following tables provide brief descriptions of the issues resolved in this release. E9.1.7.0 includes all issues
resolved in the E9.0.7.7 System Firmware Maintenance Release (see the E9.0.7.7 Release Notes for details).

10-Gigabit I.D.

Priority queue settings on the ER16-OS26-01 may cause the X-Pedition to experience ingress buffer
overflows.

Entering the port show mc-vlan-encap all-ports command from the CLI erroneously displays the
ER16-OS26-01 system ports.

Access Control List (ACL) I.D.

If a user applies multiple ACLs to a port, the acl show command may not display all of the ports in
the "Applied Port(s)" field.

When using the acl-edit <acl_name> command to edit ACL data, users cannot remove all
commands associated with the ACL from the active configuration without rebooting the router.

Advanced Routing Engine (ARE) I.D.

The ARE learns MAC addresses from all forwarded AppleTalk packets. The ARE should learn MAC
addresses from AARP Response packets only.

The appletalk ping <address> command will fail if the target address belongs to an AppleTalk
interface on the same router that initiated the ping.

Border Gateway Protocol (BGP) I.D.

Although the BGP Import policy filters routes correctly, these routes do not appear in the route table. F4347

Command Line Interface (CLI) I.D.

The system image command options use inconsistent naming schemes and may generate
messages that are unclear to users. Furthermore, default behavior varies between commands.

If a serial console session times out after the X-Pedition prompts the operator for a reply to a
command they entered, the router may core the next time the console is activated.

Negating or removing a command that contains a quoted string from the active configuration may
cause the router to core.

When a user adds commands to the CLI through a cut-and-paste operation, the router may display
the “more” prompt before the CLI finishes processing the commands.

When a user enters the copy active to scratchpad command from a CLI session, then closes the
session without issuing the logout or exit command, future CLI sessions will hang when attempting
to perform any operations that involve accessing the active configuration.

Users cannot select the unicast or multicast options with the ip-router policy import source and

ip-router policy aggr-gen destination commands.

Distance Vector Multicast Protocol (DVMRP) I.D.

Clients attached to a DVMRP-enabled interface that is also an 802.2Q trunk port may see multicast
traffic requested by a client in a different VLAN that is also part of that trunk port.

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 19 of 31

F0615-J

F4188

F4319

F4115
F4357

F4328

F4142

F4147

F3609

F4272

F4299

F4325

F4387

F4448

F4316

ISSUES RESOLVED IN E9.1.7.0

Hot Swap I.D.

Under rare circumstances, the system may occasionally core when hot swapping a line card into the
router.

Internet Protocol (IP) I.D.

If an X-Pedition with ip enable reverse flow all configured receives an invalid TCP/UDP packet of a
specific type, the router may core.

Layer-4 I.D.

An X-Pedition configured with Layer-4 bridging will respond incorrectly to an ICMP request that is
not destined for the router.

Link Aggregate Control Protocol (LACP) I.D.

LACP SmartTRUNK connections that use either the default timeout value or the “short” timeout
value may not successfully restore the connection with another system that has rebooted.

Load Balancing I.D.

The load-balancing group and server options app-int and ping-int will not function properly if set to
a value greater than 255.

Memory I.D.

When a user adds ports to a SmartTRUNK via the smarttrunk add ports <portlist> to <smarttrunk>
command, a small memory leak may occur if the command fails.

If an X-Pedition SSH client using SSHv1 fails to connect to a remote SSH server during the key
exchange phase, the router may leak up to several hundred bytes of memory (based on system
configuration).

Multicast I.D.

When a multicast index changes, some flows may not update to the new index, causing the
X-Pedition to send untagged flows over a Q-trunk.

UDP multicast packets with a TTL=1 cause the X-Pedition to allocate Q-trunk replication indices
without an associated hardware flow.

Open Shortest Path First (OSPF) I.D.

Under extremely rare circumstances, the X-Pedition may core if it attempts to calculate the SPF on
an entry that is no longer valid when the router adds or deletes large amounts of OSPF ASE routes.

The default route is missing from the route table for a stubby or totally stubby area. F4554

Protocol Independent Multicast (PIM-SM) I.D.

An unlikely sequence of route changes may cause the X-Pedition to core.

If the X-Pedition’s configuration contains the pim igmp trace local-options none and ip-router
global set trace-state on commands, PIM IGMP trace messages continue to display on the screen.

F2333

F4345

F4359
F4297

F4405
F3910

F4421

F4443

F4456

F3794

F4446

F4273

F3283
F3758

F4313

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 20 of 31

F0615-J

ISSUES RESOLVED IN E9.1.7.0

Protocol Independent Multicast (PIM-SM) I.D.

When running PIM in an equal cost multi-path environment, if a multicast traffic link goes down and
comes back up, the client may receive duplicate packets.

If a user comments the pim global start command out of the configuration, the router will write a
Layer-3 drop flow when it receives a new multicast stream. The status of the stream does not
change when the command is commented back into the configuration.

An X-Pedition running PIM-SM will not allow the re-routing of multicast traffic out of the Q-trunk port
on which it was received. Furthermore, the router may assign a multicast stream to an incorrect
replication index

If PIM-SM is enabled on an interface associated with a VLAN whose ID is greater than 2,047, the
router may drop packets.

If a multicast server sends traffic across a Q-trunk to a PIM-SM-enabled router during a reboot, the
client may not receive the packets after the router finishes booting.

Remote Authentication Dial-In Service (RADIUS) I.D.

An issue was found and corrected that involves users who authenticate through an X-Pedition to a
RADIUS server. Contact Enterasys Networks Global Technical Assistance Center for additional
information.

Remote Monitor (RMON) I.D.

Packet and byte counts for RMON2 tables are inaccurate. F4031

Changing the RMON configuration from rmon set lite| standard| professional default-tables yes
to rmon set lite| standard| professional default-tables no while RMON is enabled may cause the
router to core.

When a user executes the help (?) option for the rmon show packet-capture captured-packets
command, a description is not available for the control-index option.

Secure Shell (SSH) I.D.

The SSH client leaks 136 bytes of memory for each outbound SSH client session established to a
remote SSH server. To reclaim this memory, users must reboot the X-Pedition.

Continuous attempts (in quick succession) to connect to another device via SSH may cause the
router to stop responding.

Simple Network Management Protocol (SNMP) I.D.

The read-only community string may discover a read-write community string when querying
particular MIBs.

The snmp set mib command lists MIBs that users may not enable or disable. F4141

When querying a ctCDP MIB on a VLAN whose ID is greater than 512, the X-Pedition may core. F4303

The X-Pedition implements the any option of the snmp set group command only partially. F4382

SmartTRUNK I.D.

The smarttrunk show distribution command may display statistics for a blocked STP-enabled
SmartTRUNK.

Using the vlan multi-add command to add a non-existing SmartTRUNK port to a multi-VLAN group
will cause the router to core.

F4436

F4440

F4500
F4523
F4676

F4518
F4463

F4601
F4439

F3720

F4331

F4386

F3432

F4234

F3396

F4186

F4508

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 21 of 31

F0615-J

ISSUES RESOLVED IN E9.1.7.0

SmartTRUNK I.D.

When SmartTRUNK links carrying multicast traffic go down in a Layer-2 IGMP environment, traffic
may not fail over to active links in the SmartTRUNK. Furthermore, after the downed links are re­established, multicast traffic may travel over more than one link in the SmartTRUNK, causing the
client to receive duplicate packets.

Spanning Tree Protocol (STP) I.D.

Entering the system show hardware command when STP is enabled on the X-Pedition may cause
the router to delay BPDUs and cause a network re-span.

Syslog I.D.

Login Audit messages will not report the IP address of a remote Telnet or SSH login if no local users
or passwords are configured on the router.

System I.D.

If the X-Pedition’s startup configuration contains the system set dst-manual command, the system
time will advance one hour each time the router reboots.

Terminal Access Controller Access Control System (TACACS+) I.D.

An issue was found and corrected that involves users who authenticate through an X-Pedition to a
TACACS+ server. Contact Enterasys Networks Global Technical Assistance Center for additional
information.

F4546

F3491
F3565

F3932

F2808

F3720

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 22 of 31

F0615-J

KNOWN RESTRICTIONS AND LIMITATIONS

KNOWN RESTRICTIONS AND LIMITATIONS:

Known Restrictions and Limitations are sorted alphabetically by topic heading.

10-Gigabit Ethernet I.D.

PIM is not currently supported. F2025

If a single smarttrunk add ports command contains more than one 10-Gig port, hot swapping one
of the ports out of, then back into the router prevents the port from rejoining the SmartTRUNK.

Hot swapping an ER16-OS16-01 or ER16-OS26-01 module that belongs to a SmartTRUNK out of
the router will disable all ports in the SmartTRUNK.

Asynchronous Transfer Mode (ATM) I.D.

The X-Pedition does not support bridging over ATM with the following frame types: 802.2 IPX, 802.3
Raw, and Ethernet Snap.

Broadcast Monitor (BMON) I.D.

When BMON is enabled on a port, if the Layer-2 table for a port is repeatedly filled with
incrementing source MAC addresses, the X-Pedition will be unable to remove enough entries to
keep pace and will produce the following error message:

%L2TM-E-DMND_DEL, could not remove enough entries from L2

Cabletron Discovery Protocol (CDP) I.D.

CDP identifies some adjacent device types (such as switches, routers, etc.) incorrectly.

A CDP packet’s “device-ip” field may be set incorrectly when transmitted.

Distance Vector Multicast Routing Protocol (DVMRP) I.D.

Multicast packets are not tagged before entering an 802.1Q trunk port that connects to another
router.

Dynamic Host Configuration Protocol (DHCP) I.D.

After a reboot, a previously assigned DHCP lease address may be reassigned to another router. F1976

Flow Control I.D.

Flow Control on X-Pedition Gigabit ports will not slow their link partners to meet the maximum
receive rate.

The port set <port> auto-negotiation-flowctl off command will produce the same effect as the
port set <port> auto-negotiation-flowctl both command.

F4528

F4575

H0041

F1414

F1324
F1750

F1475
F1748

F3612

F1683
H0031

F1832
H0031

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 23 of 31

F0615-J

KNOWN RESTRICTIONS AND LIMITATIONS

Multicast I.D.

On a non-T-series line card, it is recommended that access ports be used when running a multicast
routing protocol such as PIM or DVMRP, due to the fact that multicast packets can be replicated to
only one IP VLAN in an 802.1Q trunk port.

On a T-series line card, multicast packets will be replicated to multiple IP VLANs in an 802.1Q trunk
port. The following table summarizes this capability:

Unique VLAN IDs Per Port Number of Ports Per Card

8 16 (32 on the ER16)

16 8 (16 on the ER16)

32 1,2, and 4 (2,4, and 8 on the ER16)

Hardware
Limitation

When using Cisco IP/TV version 3.2, multicast traffic that crosses several consecutive Q-trunk links

F4495

may experience a slight delay when setting up the hardware flows. This can cause the first IP/TV
client on a subnet's Video and Audio stream to be out of sync (by less than 1 second) and the
stream will not play properly on the first try. Stopping or pausing the stream, then restarting it will
usually re-sync the buffers. Other clients on the subnet do not experience delays.

Network Management I.D.

Changing the status of an SNMP target to “disable” (through the snmp set target xxx status

F2074

disable command) will not disable the target. Instead, it will continue to send traps.

Power On Self-Test (POST) I.D.

Entering the system set poweron-selftest quick command in the ER16’s configuration causes the

F0619

system to display the following errors during "DIAG BOOT TEST":

%DDT-E-MEMORY_ALIASING, Memory error @ 0x70000000 ; Possible aliasing with: 0x70800000
%DDT-E-MEMORY_ALIASING, Memory error @ 0x70000004 ; Possible aliasing with: 0x70800004
%DDT-E-MEMORY_ALIASING, Memory error @ 0x70000008 ; Possible aliasing with: 0x70800008
%DDT-I-MEM_MAX_ERRORS, Max Errors Reached; Suppressing further errors for this test
%DDT-I-MEM_INFO, $Memory Failure : SOPP Memory MAIN DRAM [16775168 bytes]
%DDT-E-SOPP_MEM_TEST, (Slot 5) : SOPP Memory Test : FAILED
%DDT-E-GE_MODULE, GE Module (Slot 5) : FAILED

These errors are incorrect and should be ignored.

Protocol Independent Multicast (PIM-SM) I.D.

When an IP interface is configured on a VLAN, and configured to run PIM, multicast data traffic

F2013

exiting the interface will be sent on all ports belonging to the VLAN.

PIM-SM and PIM IGMP cannot be enabled on an interface including a SmartTRUNK. F2025

DVMRP and PIM will not exchange route information or traffic when both exist on the same router.

F2161

Firmware versions E9.0.5.0 or later do not allow PIM and DVMRP to operate simultaneously.

OSPF-ASE routes and BGP routes may not import into the multicast Router Information Base (RIB)

F2162

without a reboot.

The X-Pedition does not support more than one PIM sparse domain configuration. F2165

PIM IGMP does not allow for static joins at this time. F2166

If multiple WAN Virtual Circuits are added to a VLAN, and an interface is created from that VLAN,

F2167

multicast traffic will be flooded out both VCs on the interface.

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 24 of 31

F0615-J

KNOWN RESTRICTIONS AND LIMITATIONS

Protocol Independent Multicast (PIM-SM) I.D.

Using the all option of the pim sparse set interface configuration command fails to set the timer
options. Users must set these options individually, using each interface name and IP address.

Entering the pim sparse set component mrt-spt-mult # command from configuration mode places
the command in the router’s active configuration; however, the command does not appear in the
configuration for GateD and is therefore not set. To view the configuration for GateD, enter the

ip-router show configuration-file command.

Quality of Service (QoS) I.D.

The qos set l2 command has no effect when the low, medium, or high priority parameters are
specified.

Example:

Entering the following command,

qos set l2 name HIGHP in-port-list et.7.2 dest-mac any priority high vlan 100

will not establish the priority of the L2 flow to high on vlan 100. Instead, the default priority of low
will remain in effect for this flow.

NOTE: The control priority parameter will function as expected.

Remote Monitor (RMON) I.D.

RMON must be enabled in the CLI configuration before RMON MIBs may be accessed via SNMP. F0832

Hot-swapping out a SERC line card and then hot-swapping the same card back in will cause RMON
to cease gathering statistics on that card.

Routing Information Protocol (RIP) I.D.

RIPv2 will not export route tag information learned from other RIP routers. F1681

Simple Network Management Protocol (SNMP) I.D.

The snmp show trap command will not display any updated target information unless the
X-Pedition is rebooted.

Spanning Tree Protocol (STP) I.D.

Traffic will not recover when Frame-Relay connections with a lower STP path cost are restored. F2141

F3251

F3253

F1950

F2227

F2068

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 25 of 31

F0615-J

INFORMATIONAL NOTES AND STATEMENTS

INFORMATIONAL NOTES AND STATEMENTS:

This section contains items previously listed in the Known Restrictions and Limitations section. These items are
not limitations, but informational statements and notes about the firmware and hardware features of the
X-Pedition products.

The following tables lists the designations used to denote where information on the statement is now located. If
there is no manual designation, the information has not yet been moved to the correct reference materials. Once
moved, the manual location will be noted.

Book Designation

X-Pedition Error Reference Manual ERM
X-Pedition Native CLI Reference Manual CLI
X-Pedition User Reference Manual URM
X-Pedition 8000/8600 Getting Started Guide
X-Pedition ER16 Getting Started Guide

6SSRM-02 Manual

Because important changes were introduced to Spanning Tree in E8.0.1.0 to prevent loops and
backplane ports from blocking, a minimum System Firmware version of E8.0.1.0 is recommended
for the 6SSRM-02 in a Matrix E7. The new changes are incorporated in firmware version 04.06.05
for the 6E2xx-xx, 6H2xx-xx, 6E3xx-xx, 6H3xx-xx, and 6G3xx-xx, and firmware version 04.11.06 for
the 6E1xx-xx, 6H1xx-xx, and 6M1xx-xx.

Routing Manual

Aggressive internal testing has uncovered a weakness in some configurations containing static
routes. Configurations using only dynamic routing are unaffected.

Erroneously configured static routes may produce a routing loop. As a result, excessive CPU
utilization can occur when an improperly configured upstream router sends ICMP redirect messages
to a downstream router. It appears this problem has been present in the Enterasys Networks
System Firmware since the 2.1.0.0 release.

Routing protocols (e.g. OSPF, BGP, RIP) automatically discover and correct any loops in dynamic
routing configurations. In these cases, no excessive CPU utilization will occur.

SERIAL Module Manual

Ports on SERIAL modules that have not been configured with the port set command before their
cables are connected may not process received data when an unused port receives status changes
from a CSU/DSU (Channel Service Unit/Data Service Unit).

Workaround: hot-swap out and hot-swap back in the affected module with the system hotswap
command and avoid connecting anything to WAN ports that will not be in use.

Spanning Tree Protocol (STP) Manual

X-Peditions with System Firmware version E8.2.0.3 and above will switch VLAN-tagged
BPDUs received on a trunk port as normal traffic rather than processing it. Since older X-Pedition
System Firmware versions are known to incorrectly forward VLAN-tagged BPDUs when STP is
disabled, Enterasys Networks recommends upgrading the X-Peditions on both sides of a Q-trunk
connection to System Firmware version E8.2.0.3 or above. If this is not feasible, STP or BPDU
filtering should be enabled on ports connected to possible BPDU sources.

GSG

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 26 of 31

F0615-J

COMPLIANCE / STANDARD SUPPORT

COMPLIANCE SUPPORT:

Compliance Level Compliant

Year 2000 Yes

IEEE STANDARDS MIB SUPPORT:

Standard Title

IEEE 802.3ad LACP

IEEE STANDARDS SUPPORT:

Standard Title

IEEE 802.1D Spanning Tree
IEEE 802.1p Traffic Prioritization
IEEE 802.1Q VLAN Trunking
IEEE 802.1w Rapid Spanning Tree
IEEE 802.3 10 Mbps Ethernet
IEEE 802.3ad LACP (Link Aggregation)
IEEE 802.3u 100BASE-T Ethernet
IEEE 802.3x Full Duplex Ethernet

IEEE 802.3z 1000 Mbps Ethernet

IETF STANDARDS SUPPORT:

RFC No. Title

RFC 768 User Datagram Protocol
RFC 791 Internet Protocol
RFC 792 Internet Control Message Protocol
RFC 793 Transmission Control Protocol
RFC 826 An Ethernet Address Resolution Protocol
RFC 854 Telnet Protocol Specification
RFC 894 IP over Ethernet
RFC 951 Bootstrap Protocol (BOOTP)
RFC 1058 RIP v1
RFC 1105 BGP
RFC 1157 SNMPv1
RFC 1163 BGP-2
RFC 1256 ICMP Router Discover Message
RFC 1265 BGP Protocol Analysis
RFC 1267 BGP-3
RFC 1293 Inverse ARP
RFC 1332 PPP Internet Protocol Control Protocol (IPCP)
RFC 1349 Type of Service in the Internet Protocol Suite

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 27 of 31

F0615-J

COMPLIANCE / STANDARD SUPPORT

RFC No. Title

RFC 1350 The TFTP Protocol (Revision 2)
RFC 1397 BGP Default Route Advertisement
RFC 1483 Multiprotocol Encapsulation over ATM Adaptation Layer 5
RFC 1490 Multiprotocol Interconnect over Frame Relay
RFC 1519 CIDR
RFC 1552 The PPP Internetwork Packet Exchange Control Protocol (IPXCP)
RFC 1570 PPP LCP Extensions
RFC 1583 OSPF v2
RFC 1631 IP Network Address Translator
RFC 1638 PPP Bridging Control Protocol (BCP)
RFC 1657 BGP-4 Definitions of Managed Objects
RFC 1661 PPP (Point-to-Point Protocol)
RFC 1662 PPP in HDLC-like Framing
RFC 1723 RIP v2
RFC 1771 BGP-4
RFC 1772 Application of BGP in the Internet
RFC 1812 Router Requirements
RFC 1966 BGP Route Reflection
RFC 1990 PPP Multi-Link Protocol
RFC 1997 BGP Communities Attribute
RFC 2131 Dynamic Host Configuration Protocol
RFC 2138 RADIUS
RFC 2225 Classical IP and ARP over ATM
RFC 2236 Internet Group Management Protocol, Version 2
RFC 2338 VRRP
RFC 2391 Load Sharing using IP Network Address Translation (Load Balance)

IETF DRAFT STANDARDS SUPPORT:

Draft No. Title

draft-ietf-pim-sm-v2-new-02

draft-ietf-idmr-dvmrp-v3-10

draft-ietf-idr-bgp-4-17

PIM-SM

DVMRP

Breaking Ties (Phase 2), Sect. 9.1.2.2

draft-ylonen-ssh-protocol-00 SSH-1 IETF draft

draft-ietf-secsh-architecture-14
draft-ietf-secsh-transport-16
draft-ietf-secsh-userauth-17
draft-ietf-secsh-connect-17

SSH-2 IETF drafts
draft-ietf-secsh-assignednumbers-03
draft-ietf-secsh-dh-group-exchange-04
draft-ietf-secsh-fingerprint-01

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 28 of 31

F0615-J

COMPLIANCE / STANDARD SUPPORT

IETF STANDARDS MIB SUPPORT:

RFC No. Title

RFC 1471 PPP LCP (Link Control Protocol)
RFC 1472 PPP Security Protocol
RFC 1473 PPP IP NCP (Network Control Protocol)
RFC 1474 PPP Bridge NCP
RFC 1493 Definitions of Managed Objects for Bridges
RFC 1512 FDDI MIB
RFC 1595 SONET / SDH MIB
RFC 1657 BGP4 MIB
RFC 1695 ATM MIB
RFC 1724 RIPv2 MIB
RFC 1742 AppleTalk Management Information Base II
RFC 1757 Remote Network Monitoring (RMON) Management Information Base
RFC 1850 OSPF MIB
RFC 1901 Introduction to Community-based SNMPv2 (SNMPV2c)
RFC 1907 SNMP v2 MIB
RFC 2011 Internet Protocol (IP) MIB using SMIv2
RFC 2012 Transmission Control Protocol (TCP) MIB using SMIv2
RFC 2013 User Datagram Protocol (UDP) MIB using SMIv2
RFC 2021 Remote Network Monitoring Version 2 (RMON 2)
RFC 2096 IP Forwarding MIB
RFC 2115 Frame Relay DTE using SMIv2
RFC 2358 Ethernet Like Interface MIB
RFC 2358 Ethernet-like Interface Types MIB
RFC 2495 E1 / DS1 MIB
RFC 2496 E3 / DS3 MIB
RFC 2576 Coexistence between Version1, Version2, and Version 3 of Internet-

standard Network Management Framework
RFC 2618 RADIUS Authentication Client
RFC 2668 IEEE 802.3 Medium Attachment Units (MAUs) MIB
RFC 2674 IETF Q MIB for Bridge with Traffic Classes, Multicast Filtering and VLAN

Extension
RFC 2737 Entity MIB
RFC 2787 VRRP
RFC 2790 Host Resources MIB
RFC 2863 Interfaces Group using SMIv2
RFC 3411 An Architecture for Describing Simple Network Management Protocol

(SNMP) Management Frameworks
RFC 3412 Message Processing and Dispatching for the Simple Network Management

Protocol (SNMP)
RFC 3413 Simple Network Management Protocol (SNMP) Applications
RFC 3414 User-based Security Model USM) for version 3 of the Simple Network

Management Protocol (SNMPv3)
RFC 3415 View-based Access Control Model (VACM) for the Simple Network

Management Protocol (SNMP)
RFC 3416 Version 2 of the Protocol Operations for the Simple Network Management

Protocol (SNMP)

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 29 of 31

F0615-J

COMPLIANCE / STANDARD SUPPORT

IETF EXPERIMENTAL MIB SUPPORT:

Function Draft

DVMRP Draft 4
IGMP Draft 5

FRAME RELAY STANDARD SUPPORT:

Standard Title

Frame Relay Forum FRF.1.1 User-to-Network (UNI) Implementation Agreement
Frame Relay Forum FRF.3.1 Multiprotocol Encapsulation Implementation Agreement
ITU-T Q.922/ANSI T1.618 ISDN Core Aspects of Frame Relay Protocol
ITU-T Q.933 Access Signaling Annex A
ITU-T I.122/ANSI T1S1 Standards-Based Frame Relay Specification
ITU-T Annex D/ANSI T1.617 Additional Procedures for PVCs Using Unnumbered Information Frames

FDDI STANDARD SUPPORT:

Standard Title

ANSI X3T9.5 Fiber Distributed Data Interface (FDDI)
ANSI X3T9.5/84-49 Rev 7.2 FDDI Station Management (SMT)
ANSI X3.139-1987 FDDI Media Access Control (MAC)
ANSI X3.148-1988 FDDI Physical Layer Protocol (PHY)
ANSI X3.166-1990 FDDI Physical Medium Dependent (PMD)

ENTERASYS NETWORKS PRIVATE ENTERPRISE MIB SUPPORT:

Title Description

NOVELL-IPX-MIB Novell Netware
CTRON-SSR-HARDWARE-MIB Device specific hardware objects
CTRON-SSR-POLICY-MIB L2 filters, L3 ACL set/get ability
CTRON-SSR-SERVICE-MIB Status of major subsystems
CTRON-SSR-CAPACITY-MIB New with 3.0 use for performance/capacity
CTRON-SSR-CONFIG Retrieve/send configuration file via tftp
NOVEL-RIP-SAP-MIB Novell Netware RIP SAP
CT-CONTAINER-MIB Cabletron container MIB
CTRON-CHASSIS-MIB Cabletron chassis MIB (6SSRM-02 Only)
DEC-ELAN-MIB FDDI Extensions
CTIF-EXT-MIB MIB-II Extnsns
CTRON-CDP-MIB Cabletron Discovery Protocol MIB
CTRON-DOWNLOAD-MIB Cabletron Download MIB

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 30 of 31

F0615-J

COMPLIANCE / STANDARD SUPPORT

Enterasys Networks Private Enterprise MIBs are available in ASN.1 format from the Enterasys Networks Support
web site at: http://www.enterasys.com/support/mibs/. Indexed MIB documentation is also available.

SNMP TRAP SUPPORT:

RFC No. Title

RFC 1157 linkDown, linkUp, authenticationFailure Traps
RFC 1493 newRoot, topologyChange Traps
RFC 1850 OSPF Traps

ENTERASYS NETWORKS PRIVATE ENTERPRISE TRAP SUPPORT:

Title

envPowerSupplyFailed
envPowerSupplyRecovered
envFanFailed
envFanRecovered
envTempExceeded
envTempNormal
envHotSwapIn
envHotSwapOut
envBackupControlModuleOnline
envBackupControlModuleFailure
envLineModuleFailure
envCPUThresholdExceeded
polAclDenied

10/02/03 P/N: 9038090-53 Subject to Change Without Notice Page: 31 of 31

F0615-J
