Enterasys GPIM-02 Reference Sheet

PN 9033805-02 Page 1 of 2

GPIM-02 Reference Sheet

The GPIM-02 Gigabit Ethernet Port Interface Module is an RJ45 interface device that can be installed into an
Enterasys Networks device that supports Enterasys Networks Gigabit Ethernet Port Interface Modules.

Features and Specifications

• 1000BASE-T compliant, RJ45

• Meets IEEE 802.3ab specifications

• Hot pluggable

• Auto-Negotiation supported according to IEEE 802.3 Clause 28

• Drive distance 100 meters via Category 5 cabling

Installation

To install the GPIM-02, refer to the installation instructions for optional Gigabit Ethernet Interface Modules
described in the user’s guide for the host device.

Regulatory Compliance

This equipment meets the following safety and electromagnetic compatibility (EMC) requirements:

Note: Check the documentation of your host device to see if it will support the GPIM-02.
In order for 2nd/3rd Generation SmartSwitch/Matrix products to recognize that a GPIM-02 is installed, the host device
should have one of the following firmware versions installed:

• For firmware in the 5.x track, version 5.05.05 or higher must be used.

• For firmware in the 4.x track, version 4.08.52 or higher must be used.

The GPIM-02 supports only 1000Mb/s; 10Mb/s and 100Mb/s speeds are not supported.
The Vertical Horizon series of products does not support the GPIM-02.

Safety: UL 60950, CSA C22.2 No. 60950, 73/23/EEC, EN 60950, IEC 60950,

EN 60825, 21 CFR 1040.10

Electromagnetic Compatibility (EMC): 47 CFR Parts 2 and 15, CSA C108.8, 89/336/EEC, EN 55022, EN 61000-3-2,

EN 61000-3-3, EN 55024, AS/NZS CISPR 22, VCCI V-3

Getting Help

PN 9033805-02 Page 2 of 2

Getting Help

For additional support related to the modules or this document, contact Enterasys Networks using one of the
following methods:

Enterasys Networks, Inc., 50 Minuteman Road, Andover, MA 01810

© 2004 Enterasys Networks, Inc. All rights reserved.

Part Number: 9033805-02 September 2004

ENTERASYS NETWORKS, GPIM-02, MATRIX, SMARTSWITCH, and any logos associated therewith, are trademarks or
registered trademarks of Enterasys Networks, Inc. in the United States and other countries. All other product names mentioned
in this manual may be trademarks or registered trademarks of their respective companies.

World Wide Web http://www.enterasys.com/support

Phone [phone] or 1-800-872-8440 (toll-free in U.S. and Canada)

For the Enterasys Networks Support toll-free number in your country:

http://www.enterasys.com/support/gtac-all.html

Internet mail [e-mail]

To expedite your message, please type [eth] in the subject line.

To send comments or suggestions concerning this document to the Technical Writing Department:

[e-mail]

To expedite your message, please type [techwriting] in the subject line, and include the document Part Number in the email
message.
