C-Series C3
Policy-based Gigabit Ethernet Stackable L2/L3/L4 Edge Switch
High-availability design assures
reliable network operations
Granular QoS capabilities support
converged multimedia networks
DATASHEET
Benefits
Aligns network resource utilization
with business goals and priorities
PoE and IPv4 & IPv6 routing
support a variety of networks
and devices
Investment protection via lifetime
warranty
1.54 Tbps capacity and
571.2 Mpps
Product Overview
The Enterasys C3 is a high-performance, Gigabit Ethernet edge switch that provides scalable,
wire-rate performance in support of the bandwidth-intensive and delay-sensitive requirements of
today’s demanding applications. With support for 16,000 MAC addresses, the C3 is an excellent
choice for environments that require complete multi-layer switching capabilities and support for
high density 10/100/1000 Ethernet ports, 10GE ports, and dynamic routing capabilities. The
C3 is well-suited for Gigabit Ethernet networks as well as 100 Mbps networks that are about to
migrate to a predominantly Gigabit Ethernet network with 10GE and/or dynamic IPv4 / IPv6 routing
requirements. In addition to its complete multi-layer switching capabilities, the C3 also supports
both IPv4 and IPv6 routing as well as multicast routing protocols. Along with a switch capacity of
192 Gbps, the C3 provides up to 48 10/100/1000 Ethernet ports as well as 2 10GE uplink ports.
Leveraging the C3’s wire-rate stacking capability, as many as 8 C3s (both 24-port and 48-port
combinations) can be interconnected in a single stack to create a virtual switch that provides 1.54
Tbps of capacity and up to 384 10/100/1000 Ethernet ports as well as 16 10GE uplink ports.
Robust QoS features enable strong support for integrated multimedia networks, including Voice over
IP (VoIP) and video, as well as all types of data-intensive applications. The C3’s highly customizable
Layer 2/3/4 packet classification capabilities work together with the 8 hardware-based priority
queues associated with each Ethernet port to support a suite of differentiated services with as
many as 8 distinct priority levels. In conjunction with its non-blocking L2 switching and L3 routing
architecture, the C3’s intelligent queuing mechanisms ensure that mission-critical applications
receive prioritized access to network resources.
Business Alignment
• Granular QoS capabilities support
converged multimedia networks
• Aligns network resource utilization with
business goals and priorities
• Reliable network operation for missioncritical applications
Operational Efficiency
• Scalable architecture supports
continued growth of network capacity
• Consolidated management capabilities
reduce network operational expenses
• Security capabilities without the
high overhead
Security
• Network resources securely allocated
according to user roles
• Network security maintained
concurrently with user mobility
• Architecture designed with integral
network security
Support and Service
• Industry-leading customer satisfaction
and first call resolution rates
• Personalized services, including site
surveys, network design, installation,
and training
• Lifetime warranty
The C3 provides a secure network by utilizing its authentication and security features, which can be
applied at the port level or at the user level. Making use of the NMS Policy Manager or a standard
CLI, the Enterasys role-based architecture enables a network administrator to define distinct roles
or profiles that represent operational groups within a business (e.g., employee, executive, guest,
etc). Multiple users/devices per port can be authenticated via IEEE 802.1X, MAC address, or web
authentication, and then assigned a pre-defined operational role. Network operations can be easily
tailored to meet business-oriented requirements by providing each role with individualized access
to network services and applications (e.g., a guest should have different network access privileges
than an employee).
There is nothing more important
than our customers.
Page 2
The C-Series product line provides high port density in a 1U footprint and
is environmentally friendly by design. By maximizing port density within a
given amount of rack space, the C3 minimizes its cooling requirements.
The C3’s overall electrical requirement is further reduced by a low current
draw and an extreme tolerance for high environmental temperatures. A
highly-scalable architecture and a lifetime warranty ensures that a C3
network investment will sustain a secure, feature-rich and cost-effective
network well into the future.
Reliability and Availability
The C3 design incorporates redundancy and failure protection
mechanisms complete with automatic failover and recovery capabilities
to provide a reliable network. An integral power supply is the primary
source of power for the C3 and complete power redundancy is provided
by an optional external power supply. In addition to the standard version
of the C3, there is also a redundant Power over Ethernet (PoE) version of
the C3 which supports network devices that require external power such
as wireless access points, VoIP phones, and network cameras. A virtual
switch can be created by interconnecting as many as 8 C3s in a single
stack, which can be managed via a single IP address with redundant
management connections. The C3’s closed-loop stacking (CLS) capability
utilizes bi-directional switch interconnects to maintain connectivity
within the virtual switch despite any physical switch-level failure. Up to 8
Ethernet ports can be grouped together to create a multi-link aggregation
group (LAG). A LAG’s Ethernet ports can be collocated on a single C3
or they can be distributed across multiple C3s within a stack to prevent
a switch-level failure from disrupting data communications. The C3
also supports equal cost multipath protocol (ECMP) and virtual router
redundancy protocol (VRRP) to strengthen its ability to quickly recover
from a network failure.
Advanced Quality of Service
Robust QoS features enable strong support for integrated multimedia
networks, including VoIP and video, as well as all types of data-intensive
applications. The C3 provides highly customizable Layer 2/3/4 packet
classification capabilities, which can be based upon physical port ID,
MAC address, IP subnet, IP address, IP protocol type, IP Type of Service
(ToS), differentiated services code point (DSCP), and TCP/UDP port. The
C3 provides 8 hardware-based priority queues per Ethernet port, which
work together with its packet classification capabilities to support a suite
of differentiated services with as many as 8 distinct priority levels. The
strict and weighted round robin queuing algorithms ensure that missioncritical applications receive prioritized access to network resources.
Security
The C3 provides a secure network by utilizing its authentication and
security features, which can be applied at the port level or at the user
level. Making use of the NMS Policy Manager or a standard CLI, the
Enterasys role-based architecture enables a network administrator to
define distinct roles or profiles that represent operational groups within
a business (e.g., employee, executive, guest, etc). Multiple users/
devices per port can be authenticated via IEEE 802.1X, MAC address,
or web authentication, and then assigned a pre-defined operational
role. Administrators can easily transition from RFC 3580 and complex
ACL deployments to the Enterasys role-based policy framework in a
seamless fashion, without the need to make changes to their RADIUS
infrastructure (e.g., adding filter-ID). In addition, the C3 also supports
access control lists (ACLs) for supplementary network security. Network
operations can be easily tailored to meet business-oriented requirements
by providing each role with individualized access to network services and
applications (e.g., a guest should have different network access privileges
than an employee).
Investment Protection
The C3 is a cost-effective, feature-rich, stackable switch that provides
a broad set of features today and will continue to deliver benefits well
into the future. Customers can grow and/or enhance their networks while
protecting their investment by adding C3s into existing C-Series networks
and/or stacks. When multiple C3s are stacked together, each switch in
the stack assumes the feature set that is common to all switches in the
stack to ensure operational compatibility. All C-Series products include
a lifetime warranty that continues for 5 years after the date of product
discontinuation. For more information regarding warranty terms and
conditions please go to http://www.enterasys.com/support/warranty.aspx.
Performance & Scalability
The C3 provides scalable, wire-rate performance in support of the
bandwidth-intensive and delay-sensitive requirements of today’s
demanding applications. Along with a switch capacity of 192 Gbps, the
C3 provides up to 48 10/100/1000 Ethernet ports as well as 2 10GE
uplink ports. Leveraging the C3’s wire-rate stacking capability, as many
as 8 C3s (both 24-port and 48-port combinations) can be interconnected
in a single stack to create a virtual switch that provides 1.54 Tbps of
capacity and up to 384 10/100/1000 Ethernet ports as well as 16 10GE
uplink ports. The C3 supports hundreds of distinct policies (rules) that
enable granular definition of network access capabilities for each role, thus
aligning network resource utilization with business goals and priorities.
Page 2
Page 3
Standards and Protocols
MAC Address Table Size
16,000
VLANs
4,096 VLAN IDs
1,024 VLAN Entries per Stack
Embedded Services
Ingress Rate Limiting
IP TOS Rewrite
Layer 2/3/4 Classification
Multi-layer Packet Processing
Switching Services
IEEE 802.1AB – LLDP
ANSI/TIA-1057 – LLDP-MED
IEEE 802.1D – MAC Bridges
IEEE 802.1s – Multiple Spanning Trees
IEEE 802.1t – 802.1D Maintenance
IEEE 802.1w – Rapid Spanning Tree
Reconvergence
IEEE 802.3 – Ethernet
IEEE 802.3ab – GE over Twisted Pair
IEEE 802.3ad – Link Aggregation
IEEE 802.3ae – 10 Gigabit Ethernet (fiber)
IEEE 802.3af – PoE
IEEE 802.3i – 10Base-T
IEEE 802.3u – 100Base-T, 100Base-FX
IEEE 802.3z – GE over Fiber
Full/half duplex auto-sense support on all ports
IGMP Snooping v1/v2/v3
Jumbo Frame support (9,216 bytes)
Loop Protection
One-to-One and Many-to-One Port Mirroring
Port Description
Protected Ports
Per-port Broadcast/Multicast/Unknown Unicast
Suppression
Spanning Tree Backup Root
STP Pass Thru
VLAN Support
Generic Attribute Registration Protocol (GARP)
Generic VLAN Registration Protocol (GVRP)
IEEE 802.1p – Traffic classification
IEEE 802.1q – VLAN Tagging
Protocol-based VLANs with Enterasys Policy
IEEE 802.3ac – VLAN Tagging Extensions
Port-based VLAN (private port/private VLAN)
Tagged-based VLAN
VLAN Marking of Mirror Traffic
Quality of Service
8 Priority Queues per Port
802.3x Flow Control
IP DSCP – Differentiated Services Code Point
IP Precedence
IP Protocol
Queuing Control – Strict and Weighted
Round Robin
Source/Destination IP Address
Source/Destination MAC Address
Security
ARP Spoof Protection
DHCP Spoof Protection
Dynamic and Static MAC Locking
EAP Pass Thru
IEEE 802.1X Port Authentication
MAC-based Port Authentication
RADIUS Accounting for MAC Authentication
RADIUS Client
RFC 3580 – IEEE 802.1X RADIUS Usage
Guidelines
Multi-user Authentication per Gigabit Port
Password Protection (encryption)
Secured Shell (SSHv2)
Secured Socket Layer (SSL)
User and IP Phone Authentication
Web-based Port Authentication
IPv4 Routing & Multicast
Access Control Lists (ACLs)
ARP & ARP Redirect
DVMRP
Extended ACLs
IP Helper Address
RFC 826 – Ethernet ARP
RFC 1058 – RIP v1
RFC 1256 – ICMP Router Discovery Messages
RFC 2236 – IGMPv2
RFC 2328 – OSPF version 2
RFC 2338 – IP Redundancy VRRP
RFC 2362 – PIM-SM
RFC 2453 – RIP v2
RFC 3046 – DHCP/BootP Relay
RFC 3768 – VRRP – Virtual Router
Redundancy Protocol
Static Routes
VLAN-based ACLs
IPv6 Routing
RFC 1981 – Path MTU for IPv6
RFC 2373 – IPv6 Addressing
RFC 2460 – IPv6 Protocol Specification
RFC 2461 – Neighbor Discovery
RFC 2462 – Stateless Autoconfiguration
RFC 2463 – ICMPv6
RFC 2464 – IPv6 over Ethernet
RFC 2473 – Generic Packet Tunneling in IPv6
RFC 2711 – IPv6 Router Alert
RFC 2740 – OSPFv3
RFC 2893 – Transition Mechanisms for IPv6
Hosts and Routers (6 over 4 configured)
RFC 3315 – DHCPv6 (stateless + relay)
RFC 3484 – Default Address Selection for IPv6
RFC 3493 – Basic Socket Interface for IPv6
RFC 3513 – Addressing Architecture for IPv6
RFC 3542 – Advanced Sockets API for IPv6
RFC 3587 – IPv6 Global Unicast
Address Format
RFC 3736 – Stateless DHCPv6
Dual IPv4/IPv6 TCP/IP Stack
MIB Support
Enterasys Entity MIB
Enterasys Policy MIB
Enterasys VLAN Authorization MIB
ANSI/TIA-1057 – LLDP-MED MIB
IEEE 802.1AB – LLDP MIB
IEEE 802.1X MIB – Port Access
IEEE 802.3ad MIB – LAG MIB
RFC 826 – ARP and ARP Redirect
RFC 951, RFC 1542 – DHCP/BOOTP Relay
RFC 1213 – MIB/MIB II
RFC 1493 – BRIDGE-MIB
RFC 1643 – Ethernet-like MIB
RFC 1724 – RIPv2 MIB Extension
RFC 1850 – OSPF MIB
RFC 2096 – IP Forwarding Table MIB
RFC 2131, RFC 3046 – DHCP Client/Relay
RFC 2233 – IF-MIB
RFC 2271 – SNMP Framework MIB
RFC 2465 – IPv6 MIB
RFC 2466 – ICMPv6 MIB
RFC 2618 – RADIUS Authentication Client MIB
RFC 2620 – RADIUS Accounting Client MIB
RFC 2668 – Managed Object Definitions for
802.3 MAUs
RFC 2674 – P-BRIDGE-MIB
RFC 2674 – QBRIDGE-MIB VLAN Bridge MIB
RFC 2737 – Entity MIB (physical branch only)
RFC 2787 – VRRP-MIB
RFC 2819 – RMON-MIB
RFC 2933 – IGMP MIB
RFC 2934 – PIM MIB for IPv4
RFC 3413 – SNMP v3 Applications MIB
RFC 3414 – SNMP v3 User-based Security
Module (USM) MIB
RFC 3584 – SNMP Community MIB
RFC 3621 – Power over Ethernet MIB
Page 3
Page 4
Standards and Protocols (cont.)
Management
Alias Port Naming
Command Line Interface (CLI)
Configuration Upload/Download
Editable Text-based Configuration File
TFTP Client
Multi-configuration File Support
NMS Automated Security Manager
NMS Console
NMS Inventory Manager
NMS Policy Manager
Node/Alias Table
RFC 768 – UDP
RFC 783 – TFTP
RFC 791 – IP
RFC 792 – ICMP
RFC 793 – TCP
RFC 826 – ARP
RFC 854 – Telnet
RFC 951 – BootP
RFC 1157 – SNMP
RFC 1321 – The MD5 Message-Digest
Algorithm
RFC 1901 – Community-based SNMPv2
RFC 2271 – SNMP Framework MIB
RFC 3176 – sFlow
RFC 3413 – SNMPv3 Applications
RFC 3414 – User-based Security Model for
SNMPv3
RFC 3415 – View-based Access Control Model
for SNMP
RFC 3826 – Advanced Encryption Standard
(AES) for SNMP
RMON (Stats, History, Alarms, Events, Filters,
Packet Capture)
Secure Copy (SCP)
Secure FTP (SFTP)
Simple Network Management Protocol (SNMP)
v1/v2c/v3
Simple Network Time Protocol (SNTP)
SSH v2
RFC 3164 – The BSD Syslog Protocol
TACACS+ for Management Authentication,
Authorization and Auditing
Web-based Management
Webview via SSL Interface
Switch Model Specifications
C3G124-24 C3G124-24P C3G124-48 C3G124-48P
Performance
Throughput Capacity
wire-speed Mpps
(switch / stack)
Switching Capacity
(switch / stack)
Stacking Capacity
(switch / stack)
Aggregate Throughput
Capacity (switch / stack)
PoE Specifications
802.3af Compliance N/A Yes N/A Yes
System Power N/A 375 watts per switch with up
Physical Specifications
Dimensions (H x W x D) H: 4.4 cm (1.73”)
Net Weight 5.05 kg (11.11 lb) 6.25 kg (13.75 lb) 5.35 kg (11.77 lb) 6.55 kg (14.41 lb)
MTBF 160,505 hours 114,280 hours 106,916 hours 79,905 hours
Physical Ports • (24) 10/100/1000 auto-
Power Requirements
Nominal Input Voltage 100 – 240 VAC 100 – 240 VAC 100 – 240 VAC 100 – 240 VAC
Input Frequency 50 – 60 Hz 50 – 60 Hz 50 – 60 Hz 50 – 60 Hz
Input Current 0.8 A Max 7.5 A Max 1.4 A Max 7.5 A Max
Power Consumption 63 watts 481 watts 131 watts 567 watts
35.7 Mpps / 285.7 Mpps 35.7 Mpps / 285.7 Mpps 71.4 Mpps / 571.2 Mpps 71.4 Mpps / 571.2 Mpps
48 Gbps / 384 Gbps 48 Gbps / 384 Gbps 96 Gbps / 768 Gbps 96 Gbps / 768 Gbps
96 Gbps / 768 Gbps 96 Gbps / 768 Gbps 96 Gbps / 768 Gbps 96 Gbps / 768 Gbps
144 Gbps / 1.15 Tbps 144 Gbps / 1.15 Tbps 192 Gbps / 1.54 Tbps 192 Gbps / 1.54 Tbps
N/A 375 watts per switch with up
H: 4.4 cm (1.73”)
W: 44.1 cm (17.36”)
D: 36.85 cm (14.51”)
• (48) 10/100/1000 autosensing, auto-negotiating,
MDI/MDI-X RJ45 ports
• (4) mini-GBIC combo ports
• (2) dedicated stacking ports
• (1) DB9 console port
• (1) RPS port
to 15.4 watts per port
Per-port switch power monitor:
• Enable/disable
• Priority safety
• Overload & short circuit
protection
H: 4.4 cm (1.73”)
W: 44.1 cm (17.36”)
D: 36.85 cm (14.51”)
• (48) 10/100/1000 PoE autosensing, auto-negotiating,
MDI/MDI-X RJ45 ports
• (4) mini-GBIC combo ports
• (2) dedicated stacking ports
• (1) DB9 console port
• (1) RPS port
W: 44.1 cm (17.36”)
D: 36.85 cm (14.51”)
sensing, auto-negotiating,
MDI/MDI-X RJ45 ports
• (4) mini-GBIC combo ports
• (2) dedicated stacking ports
• (1) DB9 console port
• (1) RPS port
to 15.4 watts per port
Per-port switch power monitor:
• Enable/disable
• Priority safety
• Overload & short circuit
protection
H: 4.4 cm (1.73”)
W: 44.1 cm (17.36”)
D: 36.85 cm (14.51”)
• (24) 10/100/1000 PoE autosensing, auto-negotiating,
MDI/MDI-X RJ45 ports
• (4) mini-GBIC combo ports
• (2) dedicated stacking ports
• (1) DB9 console port
• (1) RPS port
Page 4
Page 5
Switch Model Specifications (cont.)
C3G124-24 C3G124-24P C3G124-48 C3G124-48P
Temperature
IEC 6-2-1
Standard Operating
Temperature
IEC 6-2-14
Non-Operating
Temperature
Heat Dissipation 215 BTUs/Hr 284 BTUs/Hr 447 BTUs/Hr 561 BTUs/Hr
Humidity
Operating Humidity 5% - 95% non-condensing 5% - 95% non-condensing 5% - 95% non-condensing 5% - 95% non-condensing
Vibration
Shock
Drop
Agency and Regulatory
Standard Specifications
Safety UL 60950-1, CSA 22.1
EMC FCC Part 15 (Class A),
0° to 50° C
(32° to 122° F)
-40° to 70° C
(-40° to 158° F)
IEC 68-2-6, IEC68-2-36 IEC 68-2-6, IEC68-2-36 IEC 68-2-6, IEC68-2-36 IEC 68-2-6, IEC68-2-36
IEC 68-2-29 IEC 68-2-29 IEC 68-2-29 IEC 68-2-29
IEC 68-2-32 IEC 68-2-32 IEC 68-2-32 IEC 68-2-32
60950, EN 60950-1, and
IEC 60950-1
ICES-003 (Class A), BSMI,
VCCI V-3, AS/NZS CISPR 22
(Class A), EN 55022 (Class
A), EN 55024, EN 610003-2, and EN 61000-3-3
0° to 50° C
(32° to 122° F)
-40° to 70° C
(-40° to 158° F)
UL 60950-1, CSA 22.1
60950, EN 60950-1, and IEC
60950-1
FCC Part 15 (Class A), ICES003 (Class A), BSMI, VCCI
V-3, AS/NZS CISPR 22 (Class
A), EN 55022 (Class A), EN
55024, EN 61000-3-2, and EN
61000-3-3
0° to 50° C
(32° to 122° F)
-40° to 70° C
(-40° to 158° F)
UL 60950-1, CSA 22.1
60950, EN 60950-1, and IEC
60950-1
FCC Part 15 (Class A), ICES-003
(Class A), BSMI, VCCI V-3, AS/
NZS CISPR 22 (Class A), EN
55022 (Class A), EN 55024, EN
61000-3-2, and EN 61000-3-3
0° to 50° C
(32° to 122° F)
-40° to 70° C
(-40° to 158° F)
UL 60950-1, CSA 22.1
60950, EN 60950-1, and IEC
60950-1
FCC Part 15 (Class A), ICES-003
(Class A), BSMI, VCCI V-3, AS/
NZS CISPR 22 (Class A), EN
55022 (Class A), EN 55024, EN
61000-3-2, and EN 61000-3-3
C3K122-24 C3K122-24P C3K172-24
Performance
Throughput Capacity
wire-speed Mpps
(switch / stack)
Switching Capacity
(switch / stack)
Stacking Capacity
(switch / stack)
Aggregate Throughput Capacity
(switch / stack)
PoE Specifications
802.3af Compliance N/A Yes N/A
System Power N/A 375 watts per switch with up to 15.4
65.5 Mpps / 523.8 Mpps 65.5 Mpps / 523.8 Mpps 65.5 Mpps / 523.8 Mpps
88 Gbps / 704 Gbps 88 Gbps / 704 Gbps 88 Gbps / 704 Gbps
96 Gbps / 768 Gbps 96 Gbps / 768 Gbps 96 Gbps / 768 Gbps
184 Gbps / 1.47 Tbps 184 Gbps / 1.47 Tbps 184 Gbps / 1.47 Tbps
N/A
watts per port
Per-port switch power monitor:
• Enable/disable
• Priority safety
• Overload & short circuit protection
Page 5
Page 6
Switch Model Specifications (cont.)
C3K122-24 C3K122-24P C3K172-24
Physical Specifications
Dimensions (H x W x D) H: 4.4 cm (1.73”)
Net Weight 5.125 kg (11.3 lbs) 6.325 kg (13.9 lbs) 5.075 kg (11.2 lbs)
MTBF 134,714 hours 98,759 hours 166,032 hours
Physical Ports • ( 24) 10/100/1000 auto-sensing,
Power Requirements
Nominal Input Voltage 100 – 240 VAC 100 – 240 VAC 100 – 240 VAC
Input Frequency 50 – 60 Hz 50 – 60 Hz 50 – 60 Hz
Input Current 1.5 A 7.5 A Max 1.5 A
Power Consumption 96 watts 551 watts 65 watts
Temperature
IEC 6-2-1
Standard Operating Temperature
IEC 6-2-14
Non-Operating Temperature
Heat Dissipation 326 BTUs/Hr 394 BTUs/Hr 223 BTUs/Hr
Humidity
Operating Humidity 5% - 95% non-condensing 5% - 95% non-condensing 5% - 95% non-condensing
Vibration
Shock
Drop
Agency and Regulatory Standard
Specifications
Safety UL 60950-1, CSA 22.1 60950, EN
EMC FCC Part 15 (Class A), ICES-003
W: 44.1 cm (17.36”)
D: 36.85 cm (14.51”)
auto-negotiating, MDI/MDI-X
RJ45 ports
• (4) mini-GBIC combo ports
• (1) expansion slot
• (2) dedicated stacking ports
• (1) DB9 console port
• (1) RPS port
0° to 50° C
(32° to 122° F)
-40° to 70° C
(-40° to 158° F)
IEC 68-2-6, IEC68-2-36 IEC 68-2-6, IEC68-2-36 IEC 68-2-6, IEC68-2-36
IEC 68-2-29 IEC 68-2-29 IEC 68-2-29
IEC 68-2-32 IEC 68-2-32 IEC 68-2-32
60950-1, and IEC 60950-1
(Class A), BSMI, VCCI V-3, AS/NZS
CISPR 22 (Class A), EN 55022 (Class
A), EN 55024, EN 61000-3-2, and
EN 61000-3-3
H: 4.4 cm (1.73”)
W: 44.1 cm (17.36”)
D: 36.85 cm (14.51”)
• (24) 10/100/1000 PoE auto-sensing,
auto-negotiating, MDI/MDI-X
RJ45 ports
• (4) mini-GBIC combo ports
• (1) expansion slot
• (2) dedicated stacking ports
• (1) DB9 console port
• (1) RPS port
0° to 50° C
(32° to 122° F)
-40° to 70° C
(-40° to 158° F)
UL 60950-1, CSA 22.1 60950, EN
60950-1, and IEC 60950-1
FCC Part 15 (Class A), ICES-003 (Class
A), BSMI, VCCI V-3, AS/NZS CISPR
22 (Class A), EN 55022 (Class A), EN
55024, EN 61000-3-2, and EN 610003-3
H: 4.4 cm (1.73”)
W: 44.1 cm (17.36”)
D: 36.85 cm (14.51”)
• (24) mini-GBIC ports
• (1) expansion slot
• (2) dedicated stacking ports
• (1) DB9 console port
• (1) RPS port
0° to 50° C
(32° to 122° F)
-40° to 70° C
(-40° to 158° F)
UL 60950-1, CSA 22.1 60950, EN
60950-1, and IEC 60950-1
FCC Part 15 (Class A), ICES-003 (Class
A), BSMI, VCCI V-3, AS/NZS CISPR
22 (Class A), EN 55022 (Class A),
EN 55024, EN 61000-3-2, and EN
61000-3-3
Page 6
Page 7
Redundant Power Supply Equipment Specifications
C2RPS-CHAS2 Power Shelf
Power Supply Slots
2
Dimensions (H x W x D)*
48.2 cm (19.0”) x 5.5 cm (2.2”) x 18.0 cm (7.0”)
Weight
0.95 kg (2.09 lbs)
Note: dimensions include integrated rack mount ears
C2RPS-CHAS8 Power Shelf
Power Supply Slots
8
Dimensions (H x W x D)*
44.0 cm (117.3”) x 22.26 cm (8.77”) x 26.4 cm (10.4”)
Weight
5.27 kg (11.6 lbs)
C2RPS-PSM Power Supply
Dimensions (H x W x D)
19.6 cm (7.7”) x 5.2 cm (2.04”) x 25.7 cm (10.1”)
Net Weight (Unit Only)
1.75 kg (3.85 lbs)
Gross Weight (Packaged Unit)
3.20 kg (7.04 lbs)
MTBF
300,000 hours
Operating Temperature
5° C to 40° C (41° F to 104° F)
Storage Temperature
-30° C to 73° C (-22° F to 164° F)
Operating Relative Humidity
10% to 90%
AC Input Frequency Range
50-60 Hz
AC Input Voltage Range
100 - 240 VAC
Maximum Output Power
156 W continuous
C2RPS-POE Power Supply
Dimensions (H x W x D)*
4.45 cm (1.75”) x 44.5 cm (17.5”) x 16.5 cm (6.5”)
Net Weight (Unit Only)
3.47 kg (7.63 lbs)
Gross Weight (Packaged Unit)
4.95 kg (10.89 lbs)
MTBF
589,644 hours at 25° C (77° F)
Operating Temperature
5° C to 40° C (41° F to 104° F)
Storage Temperature
-30° C to 73° C (-22° F to 164° F)
Operating Relative Humidity
10% to 90%
AC Input Frequency Range
50-60 Hz
AC Input Voltage Range
100 - 240 VAC
Maximum Output Power
500 W continuous
Page 7
Page 8
Ordering Information
C3 Switches
Part Number Description
C3G124-24 C3 with (24) 10/100/1000 RJ45 ports, (4) mini-GBIC combo ports, and (2) dedicated stacking ports.
C3G124-24P C3 with (24) 10/100/1000 PoE RJ45 ports, (4) mini-GBIC combo ports, and (2) dedicated stacking ports.
C3G124-48 C3 with (48) 10/100/1000 RJ45 ports, (4) mini-GBIC combo ports, and (2) dedicated stacking ports.
C3G124-48P C3 with (48) 10/100/1000 PoE RJ45 ports, (4) mini-GBIC combo ports, and (2) dedicated stacking ports.
C3K122-24 C3 with (24) 10/100/1000 RJ45 ports, (4) mini-GBIC combo ports, (1) expansion slot that can house (2) 10GE
C3K122-24P C3 with (24) 10/100/1000 PoE RJ45 ports, (4) mini-GBIC combo ports, (1) expansion slot that can house (2)
C3K122-24P-10G C3 with (24) 10/100/1000 PoE RJ45 ports, (4) mini-GBIC combo ports, (2) 10GE XFP ports, and (2) dedicated
C3K172-24 C3 with (24) mini-GBIC ports, (1) expansion slot that can house (2) 10GE XFP ports, and (2) dedicated
C3K-2XFP Dual 10GE IOM for C3K stackable switches
Optional Software Licenses
C3L3-LIC C3 advanced IPv4 routing license (per switch) – OSPF, PIM-SM, DVMRP, and VRRP
C3IPv6-LIC C3 IPv6 routing license (per switch)
Cables
C2CAB-SHORT Stacking cable for connecting adjacent switches (30 cm)
C2CAB-LONG Stacking cable for connecting top switch to bottom switch (1 m)
C2CAB-2M Stacking cable for all B3/C3 models (2 m)
C2CAB-5M Stacking cable for 48-port B2/C2 models and all B3/C3 models (5 m)
SSCON-CAB Console Cable (for use on all A2, B2, B3, C2, and C3 switches)
Redundant Power Supply Equipment
C2RPS-CHAS2 2-slot RPS chassis (supports up to 2 C2RPS-PSMs)
C2RPS-CHAS8 8-slot RPS chassis (supports up to 8 C2RPS-PSMs)
C2RPS-PSM 150-watt redundant Non-PoE power supply with one DC cable
C2RPS-SYS 8-slot RPS chassis plus 1 C2RPS-PSM (chassis supports up to 8 C2RPS-PSMs)
C2RPS-POE 500-watt redundant PoE power supply with one DC cable
Total active ports per switch: (24) Gigabit ports.
Total active ports per switch: (24) Gigabit ports.
Total active ports per switch: (48) Gigabit ports.
Total active ports per switch: (48) Gigabit ports.
XFP ports, and (2) dedicated stacking ports.
Total active ports per switch: (24) Gigabit + (2) 10GE ports.
10GE XFP ports, and (2) dedicated stacking ports.
Total active ports per switch: (24) Gigabit + (2) 10GE ports.
stacking ports.
Total active ports per switch: (24) Gigabit + (2) 10GE ports.
stacking ports.
Total active ports per switch: (24) Gigabit + (2) 10GE ports.
Transceivers
Enterasys transceivers provide connectivity options for Ethernet over
twisted pair copper and fiber optic cables with transmission speeds
from 100 Megabits per second to 10 Gigabits per second. All Enterasys
transceivers meet the highest quality for extended life cycle and the best
possible return on investment. For detailed specifications, compatibility
and ordering information please go to http://www.enterasys.com/products/
transceivers-ds.pdf.
Page 8
Page 9
Warranty
As a customer-centric company, Enterasys is committed to providing
quality products and solutions. In the event that one of our products
fails due to a defect, we have developed a comprehensive warranty that
protects you and provides a simple way to get your products repaired or
media replaced as soon as possible.
C-Series switches come with a lifetime warranty against manufacturing
defects. For full warranty terms and conditions please go to http://www.
enterasys.com/support/warranty.aspx.
Service and Support
Enterasys Networks provides comprehensive service offerings that range
from Professional Services to design, deploy, and optimize customer
networks, customized technical training, to service and support tailored
to individual customer needs. Please contact your Enterasys account
executive for more information about Enterasys Service and Support.
Contact Us
For more information, call Enterasys Networks toll free at 1-877-801-7082,
or +1-978-684-1000 and visit us on the Web at enterasys.com
Patented Innovation
© 2009 Enterasys Networks, Inc. All rights reserved. Enterasys Networks reserves the right to change
specifications without notice. Please contact your representative to confirm current specifications.
Please visit http://www.enterasys.com/company/trademarks.aspx for trademark information.
11/09
Delivering on our promises. On-time. On-budget.
Loading...
