Ensemble Designs BE-91 Specifications

BrightEye 91

HD Upconverter with AES Audio

Easy To Use

BrightEye 91 is an upconverter with analog composite and
SD SDI inputs. Feed the analog composite or SD SDI output
of a camera to a BrightEye 91 and upconvert to HD. You can
take the HD signal from the BrightEye 91 into a switcher
or projection system. Upconverting existing SD equipment
lets you leverage the equipment you already have and
operate in the HD domain.

A special Mirror Output Mode can be enabled, causing the
output image to be ipped left to right for use with on­camera talent. An external reference input allows genlock
to a house reference. All vertical interval data and closed
captioning is faithfully passed.

Upconvert Before Distribution

While some cameras may have rewire out, using the video
output and upconverting before distribution is preferable
since longer cable runs can be achieved and quality is
superior. Additionally, the BrightEye 91’s reference input
allows you to time the upconverted video output for use
with a production switcher.

Audio Processing

BrightEye 91 handles both embedded audio and discrete
AES digital audio inputs. Sixteen channels of embedded
audio are supported in BrightEye 91. If the incoming video
has embedded audio, the audio will be safely bypassed
around the video processing and lipsync will be preserved.
Audio mixing is available for two of the four embedded
groups of audio.

Front Panel and Software Control

Input selection, gain control, and test pattern controls are
provided through the front panel interface. Audio presence LEDs
indicate which channels are detected. Controls for crop, letterbox
and pillarbox are accessed from the front panel or BrightEye Mac
or PC software. Video and audio levels and the audio mixer can be
adjusted through BrightEye Mac or PC software.

Audio Monitoring

Audio monitoring is easy with BrightEye 91’s convenient 3.5
mm mini jack. Just select the audio channels you want to
monitor from the front panel and plug in a headset.

Monitoring with HDMI

The HDMI connector on the rear of the unit provides a future
proof monitoring interface. Plug it into most LCD monitors
for condence monitoring of your feed.

126

www.ensembledesigns.com tel [phone]

BrightEye 91

Use with Cameras and Projection Systems

Turn Analog Camera into Digital HD Source

SD Digital and Analog Composite Video Inputs

AES Inputs

Analog Audio Monitor Output

Mirror Output Mode for On-Camera Talent

Graticule and Safe Generator

HDMI Output for Monitoring

Frame Sync

12 and 16 bit processing

Passes Embedded Audio

www.ensembledesigns.com tel [phone]

127

BrightEye 91

Specications

Analog Video Input

Number One
Type Analog Composite PAL or NTSC
Resolution Digitized at 12 bits
Impedance 75 Ω
Return Loss >40 dB
Input DC +/-1 volt DC
Input Hum <100 mV

Serial Digital Input

Number One
Signal Type 270 Mb/s SD Serial Digital
(SMPTE 259M)
Impedance 75 Ω
Return Loss >15 dB
Max Cable Length 300 meters for 270 Mb/s
Automatic Input Cable Equalization

Reference Input

Number One
Type 1 V P-P Composite Video
PAL or NTSC
or Tri-Level Sync
Impedance 75 Ω
Return Loss >40 dB

AES/EBU Digital Outputs

Number Four (total of eight channels)
(selectable as inputs or outputs)
Type AES3id
Connector Coaxial, 75 Ω
Bit Depth 24 Bit
Sample Rate 48 KHz
Synchronous to video output
Reference Level -18 or -20 dBFS (selectable)

Embedded Output (In Serial Output)

Group Assign Two of four groups
Channels Sixteen passed
Bit Depth 24 Bit

Monitor Output

Number One
Connector HDMI
Type Follows SDI out

Audio Monitoring Output

Number One
(select from eight channels)
Connector 3.5 mm stereo mini jack

Serial Digital Output

Number Two
Type HD Serial Digital 1.485 Gb/s
SMPTE 274M, 292M or 296M
Processing 12 and 16 bit
Impedance 75 Ω
Return Loss >15 dB
Max Cable Length 100 meters for HD
(Belden 1694A)
HD Standards Supported
1080i (SMPTE 274M -4,5,6) 50, 59.94 or 60 Hz
720p (SMPTE 296M -1,2,3) 50, 59.94 or 60 Hz
1080p (SMPTE 274M -9,10,11) 23.98, 24, 25 Hz
1080sF (RP211 -14,15,16) 23.98, 24, 25 Hz

AES/EBU Digital Inputs

Number Four (total of eight channels)
(selectable as inputs or outputs)
Type AES3id
Connector Coaxial, 75 Ω
Bit Depth 20 and 24 Bit
Sample Rate 30 KHz to 96 KHz
(Sample Rate Converted
internally to 48 KHz)
Reference Level -18 or -20 dBFS (selectable)

General Specications

Size 5.625” W x 1.7” H x 5.5” D
(143 mm x 40 mm x 140 mm)
including connectors
Power 12 volts, 11 watts
(100-230 VAC modular power
supply not included)
Temperature Range 0 to 40° C ambient
Relative Humidity 0 to 95%, non-condensing

128

www.ensembledesigns.com tel [phone]

BrightEye 91

Upconversion

Composite or
Tri-Level Ref In

Genlock

Audio Mux

SD SDI/Composite

Video In

AES Digital Audio

Inputs

Analog

Decoder

Auto-Selecting

AES Transmitters

AES Receivers

SDI

Receiver

Audio

Demux

Ch 1/2

Ch 3/4

Ch 5/6

Ch 7/8

Audio

Processing

SDI Driver

HD SDI Out

HDMI Out

Headphone

Jack

Tie Back

To AES I/O

Ports

HDMI

Xmtr

Monitor

Amp

Audio I/O selectable as:
Mux 8 = 8 inputs or
Mux 4 = 4 in/4 out or
Demux = 8 outputs

Provides embedded pass through of all 16 audio channels
